3-5. Opening and closing the windows

3-5.Opening and closing the windows

The power windows can be opened
and closed by one-touch operation of
the switches.

Closing

One-touch closing

*1, 2

Opening

One-touch opening

: To stop the window partway, operate

the switch in the opposite direction.

: Convertible: It does not operate when

the rear quarter windows are stopped
partway.

The side windows and rear quarter
windows can be opened and closed by
one-touch operation

of the switches.

Opening the palm rest

Operating the switch

Closing

Opening

One-touch opening

: Only one-touch opening

: To stop the window partway, operate

the switch in the opposite direction.

■

The power windows can be operated

when

The engine switch <power switch> is in ON.

■

Operating the power windows after

turning the engine <hybrid system> off

The power windows can be operated for

approximately 45 seconds after the engine

switch <power switch> is turned to ACC or

turned off. They cannot, however, be oper-

ated once either door is opened.

■

Jam protection function



Except Convertible

If an object becomes jammed between the
window and the window frame while the

Power windows

Opening and closing the power
windows

Opening and closing the side
windows and rear quarter win-
dows (Convertible)

157

3-5. Opening and closing the windows

fore
dri
ving

window is closing, window movement is
stopped and the window is opened slightly.



Convertible

If an object becomes jammed between the
window and the soft top roof while the win-
dow is closing, window movement is
stopped and the window is opened slightly.

■

Catch protection function



Window

If an object becomes caught between the
door and window while the window is open-
ing, window movement is stopped.



Rear quarter window (Convertible)

If an object becomes caught between the
rear quarter window and vehicle body while
the rear quarter window is opening, win-
dow movement is stopped.

■

When the window cannot be opened or

closed

When the jam protection function or catch

protection function operates unusually and

the door window cannot be opened or

closed, perform the following operations

with the power window switch of that door.

●

Stop the vehicle. With the engine switch

<power switch> in ON, within 4 seconds

of the jam protection function or catch

protection function activating, continu-

ously operate the power window switch

in the one-touch closing direction or one-

touch opening direction so that the door

window can be opened and closed.

●

If the door window cannot be opened

and closed even when performing the

above operations, perform the following

procedure for function initialization.



Except Convertible

Close both side doors.

Turn the engine switch <power switch>

to ON.

Pull and hold the power window switch

in the one-touch closing direction and

completely close the door window.

Release the power window switch for a

moment, resume pulling the switch in

the one-touch closing direction, and

hold it there for approximately 6 sec-

onds or more.

Press and hold the power window

switch in the one-touch opening direc-

tion. After the door window is com-

pletely opened, continue holding the

switch for an additional 1 second or

more.

Release the power window switch for a

moment, resume pushing the switch in

the one-touch opening direction, and

hold it there for approximately 4 sec-

onds or more.

Pull and hold the power window switch

in the one-touch closing direction

again. After the door window is com-

pletely closed, continue holding the

switch for a further 1 second or more.

If you release the switch while the window is

moving, start again from the beginning.

If the window reverses and cannot be fully

closed or opened, have the vehicle

inspected by your Lexus dealer.



Convertible

Close both side doors.

Turn the engine switch to ON.

Close the soft top roof, and then close

the side windows and rear quarter win-

dows.

Pull and hold the power window switch

in the one-touch closing direction for

approximately 6 seconds or more.

Press and hold the power window

switch in the one-touch opening direc-

tion. After the door window is com-

pletely opened, continue holding the

switch for an additional 1 second or

more.

Release the power window switch for a

moment, resume pushing the switch in

the one-touch opening direction, and

hold it there for approximately 4 sec-

onds or more.

Pull and hold the power window switch

in the one-touch closing direction

again. After the door window is com-

pletely closed, continue holding the

switch for a further 1 second or more.

If you release the switch while the window is

moving, start again from the beginning.

If the window reverses and cannot be fully

158

3-5. Opening and closing the windows

closed or opened, have the vehicle

inspected by your Lexus dealer.

■

When the rear quarter windows cannot

be opened or closed (Convertible)

When the jam protection function or catch

protection function operates unusually and

the rear quarter window cannot be opened

or closed, perform the following operations

with the all window control switch.

●

Stop the vehicle. With the engine switch

in ON, within 4 seconds of the jam pro-

tection function or catch protection func-

tion activating, continuously operate the

all window control switch in the closing

direction or one-touch opening direction

so that the rear quarter window can be

opened and closed.

●

If the rear quarter window cannot be

opened and closed even when perform-

ing the above operations, perform the

following procedure for function initial-

ization.

Close both side doors.

Turn the engine switch to ON.

Close the soft top roof, and then close

the side windows.

Pull and hold the all window control

switch in the closing direction for

approximately 6 seconds or more.

Press and hold the all window control

switch in the one-touch opening direc-

tion. After the side windows and rear

quarter windows are completely

opened, continue holding the switch for

an additional 1 second or more.

Release the all window control switch

for a moment, resume pressing and

holding the switch in the one-touch

opening direction for approximately 4

seconds or more.

Pull and hold the power window switch

in the one-touch closing direction to

close the side windows.

Pull and hold the all window control

switch in the one-touch closing direc-

tion again. After the rear quarter win-

dows are completely closed, continue

holding the switch for a further 1 second

or more.

If you release the switch while the windows

are moving, start again from the beginning.

If the windows reverse and cannot be fully

closed or opened, have the vehicle

inspected by your Lexus dealer.

■

Door lock linked window operation

●

The power windows can be opened and
closed using the mechanical key.

(



P.415)

●

The power windows can be opened using
the wireless remote control.

(



P.130)

: These settings must be customized at

your Lexus dealer.

■

Power windows open warning buzzer

The buzzer sounds and “Window Open” is

shown on the multi-information display in

the instrument cluster when the engine

switch <power switch> is turned off and the

driver’s door is opened with the power win-

dows open.

■

Customization

Settings (e.g. linked door lock operation)

can be changed.

(Customizable features:



P.459)

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

■

Closing the windows

●

The driver is responsible for all the

power window operations, including

the operation for the passengers. In

order to prevent accidental operation,

especially by a child, do not let a child

operate the power windows. It is possi-

ble for children and other passengers

to have body parts caught in the power

window. Also, when riding with a child,

it is recommended to use the window

lock switch. (



P.159)

●

Check to make sure that all passen-

gers do not have any part of their body

in a position where it could be caught

when a window is being operated.

159

3-5. Opening and closing the windows

fore
dri
ving

This function can be used to prevent
children from accidentally opening or
closing a passenger window and rear
quarter window

Press the switch.

The indicator

will come on and the

passenger window and rear quarter win-
dow

will be locked.

: Convertible

■

The power windows can be operated

when

The engine switch <power switch> is in ON.

■

When the 12-volt battery is discon-

nected

The window lock switch is disabled. If nec-

essary, press the window lock switch after

reconnecting the 12-volt battery.

WARNING

●

When using the wireless remote con-

trol or mechanical key and operating

the power windows, operate the

power window after checking to make

sure that there is no possibility of any

passenger having any of their body

parts caught in the window. Also do

not let a child operate window by the

wireless remote control or mechanical

key. It is possible for children and other

passengers to get caught in the power

window.

●

When exiting the vehicle, turn the

engine switch <power switch> off,

carry the key and exit the vehicle along

with the child. There may be accidental

operation, due to mischief, etc., that

may possibly lead to an accident.

■

Jam protection function

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

●

The jam protection function may not

work if something gets jammed just

before the window is fully closed. Be

careful not to get any part of your body

jammed in the window.

■

Catch protection function

●

Never use any part of your body or

clothing to intentionally activate the

catch protection function.

●

The catch protection function may not

work if something gets caught just

before the window is fully opened. Be

careful not to get any part of your body

or clothing caught in the window.

Preventing accidental opera-
tion (window lock switch)

160

3-6. Opening and closing the soft top roof

3-6.Opening and closing the soft top roof



Exterior

Soft top roof

Luggage cover



Interior

Multi-information display (



P.110)

Displays opening/closing status of the soft
top roof.

Roof switch

Operation display of the soft top
roof

Displays operating parts of the soft top
roof linked to operation of the roof switch.

Bar display

The bar is displayed linked to the operation
display. The bar will turn to gray when the
operation of the soft top roof has com-
pleted.

Open the palm rest. (



P.156)

Operate the switch.

Open

The side windows and rear quarter win-
dows operate linked to opening or closing
the soft top roof.

Soft top roof (Convertible)

The soft top roof can be opened or
closed by the switch operation.

System components

A
B

Multi-information display

Opening or closing the soft top
roof

161

3-6. Opening and closing the soft top roof

fore
dri
ving

Opening/closing status of the soft top roof
will be displayed on the multi-information
display.
When the operation of the soft top roof has
completed, the bar will turn to gray and the
buzzer will sound.
To close the side windows and rear quarter
windows, press the power window switch.
(



P.156)

■

Operational conditions

●

The vehicle speed is less than approxi-

mately 31 mph (50 km/h) (However, it is

recommended that the soft top roof is

opened or closed when the vehicle is

stopped.)

●

The engine is running (The soft top roof

can operate with the engine switch in

ON, however, in order to prevent 12-volt

battery discharge, it is recommended to

start the engine.)

●

The trunk lid is closed

■

Situations in which the soft top roof

operation stops partway

In the following situation, operation of the

soft top roof stops partway.

●

When releasing the roof switch while the

soft top roof is operating

●

The vehicle speed is approximately 31

mph (50 km/h) or higher.

●

If there is a malfunction in the system

●

When operate the soft top roof repeat-

edly in a short period of time

●

If the 12-volt battery is discharged

■

Situations in which the soft top roof may

not operate properly

In the following situation, the soft top roof

may not operate properly.

●

When the jam protection function or

catch protection function of the power

windows operates

●

When starting the engine while operating

the roof switch (The soft top roof that is

operating stops partway or returns to the

previous position.)

●

If the roof switch has not been operated

for a long period of time during the oper-

ation of the soft top roof. (“Soft Top

Operation Not Completed Soft Top Will

Move Soon” is displayed on the multi-

information display for approximately 10

seconds, and then the soft top will move

slowly.)

●

When the roof switch is operated on a

steep incline or large step

●

When driving on uneven road surfaces

●

In strong wind

■

Switch operation when the operational

conditions are not met

If the soft top roof is fully closed and the

vehicle is stopped, continuously operating

the roof switch can operate the side win-

dows and rear quarter windows only even if

the operational conditions of the soft top

roof are not met

■

While the soft top roof is operating

●

The trunk opener switch cannot be oper-

ated. Press the switch after the operation

of the soft top roof has been completed.

(



P.135)

●

The side windows and rear quarter win-

dows cannot be operated using the

power window switch or all window con-

trol switch. They can be operated when

the soft top roof operation partway stops,

however, they cannot be fully closed.

■

If water splashes on the soft top roof,

such as in the rain or in a car wash

Wipe away any water before opening the

soft top roof. To prevent wrinkles, it is rec-

ommended to open the soft top roof after it

has completely dried.

■

Soft top roof open warning buzzer

A buzzer sounds if opening or closing the

soft top roof is not completed. Open or

close the soft top roof as soon as possible.

■

If a 12-volt battery terminal has been

disconnected and reconnected

If “Soft Top Operation Not Completed” is

displayed on the multi-information display

after the engine has been started, perform

the following procedure.

162

3-6. Opening and closing the soft top roof



When the soft top roof of the rear win-

dow side stops near the fully closing posi-

tion.

Operate the roof switch to open the

soft top roof, and release the switch with

the luggage cover opened.

Operate the roof switch to fully close

the soft top roof.



When the rear soft top roof stops near

the fully opening position.

Operate the roof switch to fully close the

soft top roof.
If the luggage cover does not operate by
performing the procedure above, check
that a warning message is displayed on the
multi-information display or the operational
conditions are met. If the luggage cover still
does not operate, have the vehicle
inspected by your Lexus dealer.

■

If the soft top roof cannot be operated properly when the roof switch is operated

In the following situations, perform the actions specified in the table, and then operate the

switch again.

●

Soft top roof operation stops partway

Situation

Warning message

Action

The engine switch is
turned to OFF or
ACC while the soft
top roof is operating.

Start the engine, or turn the engine switch
to ON, and then operate the roof switch.

The vehicle speed
exceeds approxi-
mately 31 mph (50
km/h) while the soft
top roof is operating.

“SLOW DOWN to
Compelete Soft Top
Operation”

Decelerate to approximately 31 mph (50
km/h), and then operate the roof switch.

The trunk lid is
opened using the
mechanical key while
the soft top roof is
operating.

Close the trunk lid, and then operate the
roof switch.

A collision is
detected.

Contact your Lexus dealer.

The catch protection
function of a power
window is activated.



P.157

The soft top roof is
operated manually.

“SLOW DOWN to
Compelete Soft Top
Operation”
“Soft Top Operation
Not Completed”

Manually return the soft top roof to the
previous position. If the soft top roof cannot
be operated, repeat opening and closing
operations several times.

163

3-6. Opening and closing the soft top roof

fore
dri
ving

●

Soft top roof operation does not start

The outside tempera-
ture is low.

Operate the roof switch again.

The voltage of the 12-
volt battery drops.

Start the engine, and then operate the roof
switch.

A thing is put in the
operating range of the
soft top roof, which
prevents the soft top
roof from operating.

Remove the thing on the upper part of the
windshield frame, luggage cover, storing
space of the soft top roof.

The vehicle is driven
in the strong head
wind with the soft top
roof not fully closed.

Partway open the soft top roof after stop-
ping or decelerating the vehicle, and then
close it.

The soft top roof is
malfunctioning.

“Soft Top System Mal-
function See Owner’s
Manual”

If the soft top roof cannot be operated
even when operating the switch several
times, have the vehicle inspected by your
Lexus dealer.

Situation

Warning message

Action

The engine switch is
turned to OFF or
ACC.

Start the engine or turn the engine switch
to ON, and then operate the roof switch.

The vehicle is driven
at the speed of
approximately 31 mph
(50 km/h) or higher.

“Soft Top System
Unavailable Speed
must be under
50km/h”

Decelerate to approximately 31 mph (50
km/h), and then operate the roof switch.

The trunk lid is
opened.

“Soft Top System
Unavailable Close
Trunk Lid”

Close the trunk lid, and then operate the
roof switch.

The voltage of the 12-
volt battery drops.

“Soft Top System
Unavailable Low
Power”

Start the engine, and then operate the roof
switch.

Situation

Warning message

Action

164

3-6. Opening and closing the soft top roof

The soft top roof is
operated repeatedly
in a short period of
time.

“Opening Function
Unavailable System
Overheated”
“Function Temporar-
ily Unavailable Sys-
tem Overheated”

Wait for a while and then operate the roof
switch. Depending on the situation, “Soft
Top System Available” is displayed on the
multi-information display indicating that
the roof switch can be operated. If the roof
switch cannot be operated, operate the
soft top roof manually (



P.424) or have

the vehicle inspected by your Lexus dealer.

The roof switch is
operated while the
luggage cover lock is
operating.

Operate the roof switch again.

The jam protection
function or catch pro-
tection function of a
power windows is
activated.



P.156

The soft top roof is
operated manually.

“SLOW DOWN to
Compelete Soft Top
Operation”
“Soft Top Operation
Not Completed”

Manually return the soft top roof to the
previous position. If the soft top roof cannot
be operated, repeat opening and closing
operations several times.

Situation

Warning message

Action

165

3-6. Opening and closing the soft top roof

fore
dri
ving

●

Soft top roof opens slowly

Situation

Warning message

Action

The roof switch is
released for a long
period of time while
opening or closing the
soft top roof.

“Soft Top Moving Do
Not Forget To Close”
“Soft Top Operation
Not Completed Do
Not Forget To Close”



When the engine is running or the
engine switch is in ON

“Soft Top Operation Not Completed Soft
Top Will Move Soon” is displayed on the
multi-information display for approxi-
mately 10 seconds, and then the operation
is restricted and the soft top roof moves
slowly.



When the roof switch can be operated

When the roof switch is operated while the
soft top roof moves slowly, the soft top roof
moves corresponding the switch opera-
tion.
However, if the soft top roof has been
operated repeatedly in a short period of
time, it may be only closed. (



P.162)



When the roof switch cannot be oper-
ated

Wait for a while with the soft top roof oper-
ation stops, and then operate the roof
switch. If the soft top roof does not operate,
have the vehicle inspected by your Lexus
dealer.

166

3-6. Opening and closing the soft top roof

The roof switch is
released for a long
period of time while
opening or closing the
soft top roof.

“Soft Top Moving Do
Not Forget To Close”
“Soft Top Operation
Not Completed Do
Not Forget To Close”



When the engine switch is in ACC or
OFF

The operation is restricted and the soft top
roof moves slowly.



When starting the engine or turning the
engine switch to ON

The operation is stopped. After it stops,
when the roof switch is operated, the soft
top roof moves corresponding the switch
operation.
However, if the soft top roof has been
operated repeatedly in a short period of
time, it may be only closed. (



P.162)



When the engine switch is not operated

Wait for a while until the soft top roof oper-
ation is stopped. After it stops, when the
roof switch is operated, the soft top roof
moves corresponding the switch opera-
tion.
However, if the soft top roof has been
operated repeatedly in a short period of
time, it may be only closed. (



P.162)

Situation

Warning message

Action

WARNING

■

When opening or closing the soft top

roof

Observe the following.
Failure to do so may result in death or

serious injury.

●

Check to make sure that all passen-

gers do not have any part of their body

in a position where it could be caught

when the soft top roof is being oper-

ated. If a part of the body or an object

is likely to be caught, or if the body is

caught, stop the operation immedi-

ately.

●

If anyone is in the vicinity or in the vehi-

cle, make sure they are safe and let

them know that the soft top roof is

about to open or close.

●

When the rear seat is occupied, be

careful that the soft top roof does not

hit the passenger.

●

Pay extra attention to the operation of

the soft top roof and the safety of the

area around the vehicle while opening

or closing the soft top roof.

●

Take extra care to prevent your fin-

gers etc. from being caught in moving

parts.

●

Do not operate the soft top roof while

the vehicle is backing up. The driver’s

rearward vision may be blocked, lead-

ing to an accident.

●

When the soft top roof starts to move

slowly, be careful not to be caught in

the soft top roof.

167

3-6. Opening and closing the soft top roof

fore
dri
ving

WARNING

●

When exiting the vehicle, turn the

engine switch off, carry the key and

exit the vehicle along with the child.

There may be accidental operation,

due to mischief, etc., that may possibly

lead to an accident.

■

While the vehicle is driven

Observe the following precautions.
Failure to do so may result in serious

injury or an accident.

●

Do not operate the soft top roof more

than necessary.

●

Do not drive the vehicle with the soft

top roof half-opened.

●

Do not stand on the seat, sit on the

package tray (



P.55), or lean out of

the vehicle.

■

When a child is in the vehicle

Observe the following precautions.
Failure to do so may result in death or

serious injury.

●

Do not allow a child operate the soft

top roof.

●

Never let a child sit in the storing

space of the soft top roof.

●

Keep children away from the movable

range of the soft top roof.

NOTICE

■

To prevent damage to the soft top

roof

●

Make sure that there is no obstacle

within a height of 25.6 in. (65 cm)

from the soft top roof.

Also, be careful when passing a place

with height restriction, such as a tunnel

or underground passage.

●

Do not put anything in the storing

space of the soft top roof.

●

Do not sit on or put luggage on the soft

top roof or luggage cover.

●

When there is snow or luggage on the

soft top roof or luggage cover, remove

it before operating the roof switch.

●

Do not open or close the soft top roof

when anything is put on the trunk lid.

●

Do not close the soft top roof when

anything is put on the upper part of the

windshield frame.

●

Do not open or close the soft top roof

when the outside temperature is

23.0°F (-5°C) or lower or the side

windows and rear quarter windows

are frozen.

●

Do not leave the soft top roof not fully

opened or closed for a long period of

time.

●

Do not leave the soft top roof opened

for a long period of time. The soft top

roof may have wrinkles or deteriorate.

●

When opening the trunk lid using the

mechanical key, fully open or close the

soft top roof.

●

Do not install a roof luggage carrier to

the soft top roof.

●

Do not operate the soft top roof manu-

ally except in an emergency.

(



P.431)

169

Driving

4-1. Before driving

Driving the vehicle.....................

170

Cargo and luggage...................

176

Vehicle load limits......................

178

Trailer towing...............................

179

Dinghy towing .............................

179

4-2. Driving procedures

Engine (ignition) switch (LC500)

.........................................................

180

Power (ignition) switch

(LC500h)..................................

184

EV drive mode (LC500h).....

188

Automatic transmission

(LC500).....................................

190

Hybrid transmission (LC500h)

.........................................................

196

Turn signal lever.........................

203

Parking brake .............................

204

Brake Hold...................................

206

4-3. Operating the lights and wipers

Headlight switch........................

208

AHB (Automatic High Beam)

..........................................................

211

Windshield wipers and washer

.........................................................

214

4-4. Refueling

Opening the fuel tank cap......

218

4-5. Using the driving support sys-

tems

Lexus Safety System + 2.5.....

221

PCS (Pre-Collision System).

225

LTA (Lane Tracing Assist) ....

235

RSA (Road Sign Assist)..........

244

Dynamic radar cruise control

with full-speed range............

247

Driving mode select switch ..

257

Intuitive parking assist.............

259

BSM (Blind Spot Monitor)....

266

Active rear wing........................

275

Fixed rear wing ..........................

278

Driving assist systems..............

279

4-6. Driving tips

Hybrid electric vehicle driving

tips (LC500h) ........................

285

Winter driving tips....................

287

170

4-1. Before driving

4-1.Before driving

■

Starting the engine <hybrid sys-
tem>



P.180, 184

■

Driving

With the brake pedal depressed,
shift the shift position to D.

Check that the shift position indicator

shows D.

If the parking brake is set, release
the parking brake. (



P.204)

Gradually release the brake pedal
and gently depress the accelerator
pedal to accelerate the vehicle.

■

Stopping

Depress the brake pedal.

If necessary, set the parking brake.

LC500h: If the vehicle is to be stopped for

an extended period of time, shift the shift

position to P. (



P.198)

■

Parking the vehicle

Depress the brake pedal to stop
the vehicle completely.

If the parking brake is released, set
the parking brake. (



P.204)

Shift the shift position to P. (



P.191,

198)

Check that the shift position indicator

shows P and the parking brake indicator is

illuminated.

Press the engine switch <power
switch> to stop the engine <hybrid
system>.

Slowly release the brake pedal.

Lock the door, making sure that
you have the electronic key on your
person.

If parking on a hill, block the wheels as

needed.

■

Starting off on a steep uphill

Firmly depress the brake pedal and
shift the shift position to D.

The hill-start assist control will be activated.

Set the parking brake. (



P.204)

Release the brake pedal and gently
depress the accelerator pedal to
accelerate the vehicle.

Release the parking brake.
(



P.204)

■

For fuel-efficient driving (LC500h)

Keep in mind that hybrid electric vehicles

are similar to conventional vehicles, and it is

necessary to refrain from activities such as

sudden acceleration. (



P.285)

■

When parking the vehicle (Convertible)

In order to prevent theft or effect of the

weather on the environment of the vehicle

cabin, close the soft top roof when parking

the vehicle.

■

Driving in the rain

●

Drive carefully when it is raining, because

visibility will be reduced, the windows

may become fogged-up, and the road

will be slippery.

●

Drive carefully when it starts to rain,

because the road surface will be espe-

cially slippery.

●

Refrain from high speeds when driving on

an expressway in the rain, because there

may be a layer of water between the tires

and the road surface, preventing the

Driving the vehicle

The following procedures should be
observed to ensure safe driving:

Driving procedure

171

4-1. Before driving

Driving

steering and brakes from operating

properly.

■

Engine speed while driving

In the following conditions, the engine

speed may become high while driving. This

is due to automatic up-shifting control or

down-shifting implementation to meet driv-

ing conditions. It does not indicate sudden

acceleration.

●

The vehicle is judged to be driving uphill

or downhill

●

When the accelerator pedal is released

●

When the brake pedal is firmly or quickly

depressed

■

Restraining the engine <hybrid system>

output (Brake Override System)

●

When the accelerator and brake pedals

are depressed at the same time, the

engine <hybrid system> output may be

restrained.

●

A warning message is displayed on the

multi-information display while the sys-

tem is operating. (



P.388)

■

Restraining sudden start (Drive-Start

Control)

●

When the following unusual operation is

performed, the engine <hybrid system>

output may be restrained.

• When the shift position is shifted from R

to D, D to R, N to R, P to D

or P to R

includes M) with the accelerator pedal

depressed, a warning message appears

on the multi-information display. If a

warning message is shown on the multi-

information display, read the message

and follow the instructions.

• When the accelerator pedal is depressed

too much while the vehicle is in reverse.

: Depending on the situation, the shift posi-

tion may not be changed.

●

While Drive-Start Control is being acti-

vated, your vehicle may have trouble

escaping from the mud or fresh snow. In

such case, deactivate TRAC (



P.281)

to cancel Drive-Start Control so that the

vehicle may become able to escape from

the mud or fresh snow.

■

Breaking in your new Lexus

To extend the life of the vehicle, observing

the following precautions is recommended:

●

For the first 186 miles (300 km):

Avoid sudden stops.

●

For the first 621 miles (1000 km):

• Do not drive at extremely high speeds.

• Avoid sudden acceleration.

• Do not drive continuously in low gears.

• Do not drive at a constant speed for

extended periods.

■

Drum-in-disc type parking brake sys-

tem

Your vehicle has a drum-in-disc type park-

ing brake system. This type of brake system

needs bedding-down of the brake shoes

periodically or whenever the parking brake

shoes and/or drum are replaced. Have

your Lexus dealer perform the bedding

down operation.

■

Operating your vehicle in a foreign

country

Comply with the relevant vehicle registra-

tion laws and confirm the availability of the

correct fuel. (



P.442)

■

Brake pads and discs (vehicles with LSD

[Limited Slip Differential])

The brake pads and discs are designed for

use under high load conditions. Therefore,

brake noise may be generated depending

on the vehicle speed, braking force and

vehicle environment (temperature, humid-

ity, etc.).

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

■

When starting the vehicle

LC500: Always keep your foot on the

brake pedal while stopped with the

engine running. This prevents the vehicle

from creeping.
LC500h: Always keep your foot on the

brake pedal while stopped with the

“READY” indicator is illuminated. This

prevents the vehicle from creeping.

172

4-1. Before driving

WARNING

■

When driving the vehicle

●

Do not drive if you are unfamiliar with

the location of the brake and accelera-

tor pedals to avoid depressing the

wrong pedal.

• Accidentally depressing the accelera-

tor pedal instead of the brake pedal

will result in sudden acceleration that

may lead to an accident.

• When backing up, you may twist your

body around, leading to a difficulty in

operating the pedals. Make sure to

operate the pedals properly.

• Make sure to keep a correct driving

posture even when moving the vehicle

only slightly. This allows you to depress

the brake and accelerator pedals

properly.

• Depress the brake pedal using your

right foot. Depressing the brake pedal

using your left foot may delay

response in an emergency, resulting in

an accident.

●

LC500h: The driver should pay extra

attention to pedestrians when the vehi-

cle is powered only by the electric

motor (traction motor). As there is no

engine noise, the pedestrians may mis-

judge the vehicle’s movement. Even

though the vehicle is equipped with the

vehicle proximity notification system,

drive with care as pedestrians in the

vicinity may still not notice the vehicle if

the surrounding area is noisy.

●

Do not drive the vehicle over or stop

the vehicle near flammable materials.

The exhaust system and exhaust gases

can be extremely hot. These hot parts

may cause a fire if there is any flamma-

ble material nearby.

●

During normal driving, do not turn off

the engine <hybrid system>. Turning

the engine <hybrid system> off while

driving will not cause loss of steering

or braking control, however, power

assist to the steering will be lost. This

will make it more difficult to steer

smoothly, so you should pull over and

stop the vehicle as soon as it is safe to

do so.

In the event of an emergency, such as

if it becomes impossible to stop the

vehicle in the normal way:



P.376

●

Use engine braking (downshift) to

maintain a safe speed when driving

down a steep hill.

Using the brakes continuously may

cause the brakes to overheat and lose

effectiveness. (



P.190, 196)

●

Do not adjust the positions of the

steering wheel, the seat, or the inside

or outside rear view mirrors while driv-

ing.

Doing so may result in a loss of vehicle

control.

●

Always check that all passengers’

arms, heads or other parts of their

body are not outside the vehicle.

●

Do not drive in excess of the speed

limit. Even if the legal speed limit per-

mits it, do not drive over 85 mph (140

km/h) unless your vehicle has high-

speed capability tires. Driving over 85

mph (140 km/h) may result in tire fail-

ure, loss of control and possible injury.

Be sure to consult a tire dealer to

determine whether the tires on your

vehicle are high-speed capability tires

or not before driving at such speeds.

■

When driving on slippery road sur-

faces

●

Sudden braking, acceleration and

steering may cause tire slippage and

reduce your ability to control the vehi-

cle.

173

4-1. Before driving

Driving

WARNING

●

Sudden acceleration, engine braking

due to shifting, or changes in engine

speed could cause the vehicle to skid,

resulting in an accident.

●

After driving through a puddle, lightly

depress the brake pedal to make sure

that the brakes are functioning prop-

erly. Wet brake pads may prevent the

brakes from functioning properly. If

the brakes on only one side are wet

and not functioning properly, steering

control may be affected.

■

When shifting the shift position

●

LC500: Do not let the vehicle roll

backward while a forward driving

position is selected, or roll forward

while the shift position is in R.

Doing so may cause the engine to stall

or lead to poor brake and steering

performance, resulting in an accident

or damage to the vehicle.

LC500h: Do not let the vehicle roll

backward while a forward driving

position is selected, or roll forward

while the shift position is in R.

Doing so may result in an accident or

damage to the vehicle.

●

Do not shift the shift position to P while

the vehicle is moving.

Doing so can damage the transmission

and may result in a loss of vehicle con-

trol.

●

Do not shift the shift position to R while

the vehicle is moving forward.

Doing so can damage the transmission

and may result in a loss of vehicle con-

trol.

●

Do not shift the shift position to a driv-

ing position while the vehicle is moving

backward.

Doing so can damage the transmission

and may result in a loss of vehicle con-

trol.

●

LC500: Changing the shift position to

N while the vehicle is moving will dis-

engage the engine from the transmis-

sion. Engine braking is not available

when N is selected.

LC500h: Changing the shift position

to N while the vehicle is moving will

disengage the hybrid system. Regen-

erative braking is not available with the

hybrid system disengaged.

●

Be careful not to change the shift posi-

tion with the accelerator pedal

depressed. Changing the shift posi-

tion to any positions other than P or N

may lead to unexpected rapid acceler-

ation of the vehicle that may cause an

accident and result in death or serious

injury.

After changing the shift position, make

sure to confirm the current shift posi-

tion displayed on the shift position indi-

cator inside the meter.

■

Brake pad wear

If any of the following situations occurs,

have the brake pads visually checked

and replaced by your Lexus dealer as

soon as possible.

●

If the thickness of the brake pads

exceeds the brake pad wear limit

when visually checking all four brake

pads (for the brake pad wear limit,

refer to P.447)

●

If “Brake Pad Wear Visit Your Dealer”

is displayed (only the right-side pads

can be detected)

Rotor damage may result if the pads are

not replaced when needed. Moderate

levels of the brake pad and disc wear

allow enhanced braking power. As a

result, the discs may wear more quickly

than conventional brake discs. There-

fore, when replacing the brake pads,

Lexus recommends that you also have

the thickness of the discs measured. It is

dangerous to drive the vehicle when the

wear limits of the brake pads and/or

those of the brake discs are exceeded.

174

4-1. Before driving

WARNING

■

When the vehicle is stopped

●

LC500: Do not race the engine.

If the vehicle is in any gear other than P

or N, the vehicle may accelerate sud-

denly and unexpectedly, causing an

accident.

LC500h: Do not depress the acceler-

ator pedal unnecessarily.

If the shift position is in any position

other than P or N, the vehicle may

accelerate suddenly and unexpect-

edly, causing an accident.

●

LC500: In order to prevent accidents

due to the vehicle rolling away, always

keep depressing the brake pedal while

the engine is running, and apply the

parking brake as necessary.

LC500h: In order to prevent acci-

dents due to the vehicle rolling away,

always keep depressing the brake

pedal while stopped with the

“READY” indicator is illuminated, and

apply the parking brake as necessary.

●

If the vehicle is stopped on an incline,

in order to prevent accidents caused

by the vehicle rolling forward or back-

ward, always depress the brake pedal

and securely apply the parking brake

as needed.

●

Avoid revving or racing the engine.

Running the engine at high speed

while the vehicle is stopped may cause

the exhaust system to overheat, which

could result in a fire if combustible

material is nearby.

■

When the vehicle is parked

●

Do not leave glasses, cigarette light-

ers, spray cans, or soft drink cans in the

vehicle when it is in the sun.

Doing so may result in the following:

• Gas may leak from a cigarette lighter

or spray can, and may lead to a fire.

• The temperature inside the vehicle

may cause the plastic lenses and plas-

tic material of glasses to deform or

crack.

• Soft drink cans may fracture, causing

the contents to spray over the interior

of the vehicle, and may also cause a

short circuit in the vehicle’s electrical

components.

●

Do not leave cigarette lighters in the

vehicle. If a cigarette lighter is in a

place such as the glove box or on the

floor, it may be lit accidentally when

luggage is loaded or the seat is

adjusted, causing a fire.

●

Do not attach adhesive discs to the

windshield or windows. Do not place

containers such as air fresheners on

the instrument panel or dashboard.

Adhesive discs or containers may act

as lenses, causing a fire in the vehicle.

●

Do not leave a door or window open if

the curved glass is coated with a met-

allized film such as a silver-colored

one. Reflected sunlight may cause the

glass to act as a lens, causing a fire.

175

4-1. Before driving

Driving

WARNING

●

LC500: Always apply the parking

brake, shift the shift position to P, stop

the engine and lock the vehicle.

Do not leave the vehicle unattended

while the engine is running.

If the vehicle is parked with the shift

position in P but the parking brake is

not set, the vehicle may start to move,

possibly leading to an accident.

LC500h: Always apply the parking

brake, shift the shift position to P, stop

the hybrid system and lock the vehicle.

Do not leave the vehicle unattended

while the “READY” indicator is illumi-

nated.

If the vehicle is parked with the shift

position in P but the parking brake is

not set, the vehicle may start to move,

possibly leading to an accident.

●

LC500: Do not touch the exhaust

pipes while the engine is running or

immediately after turning the engine

off.

Doing so may cause burns.

LC500h: Do not touch the exhaust

pipes while the “READY” indicator is

illuminated or immediately after turn-

ing the hybrid system off.

Doing so may cause burns.

■

When taking a nap in the vehicle

Always turn the engine <hybrid system>

off. Otherwise, if you accidentally move

the shift lever or depress the accelerator

pedal, this could cause an accident or fire

due to engine <hybrid system> overheat-

ing. Additionally, if the vehicle is parked

in a poorly ventilated area, exhaust gases

may collect and enter the vehicle, lead-

ing to death or a serious health hazard.

■

When braking

●

When the brakes are wet, drive more

cautiously.

Braking distance increases when the

brakes are wet, and this may cause

one side of the vehicle to brake differ-

ently than the other side. Also, the

parking brake may not securely hold

the vehicle.

●

If the electronically controlled brake

system does not operate, do not follow

other vehicles closely and avoid hills or

sharp turns that require braking.

In this case, braking is still possible, but

the brake pedal should be depressed

more firmly than usual. Also, the brak-

ing distance will increase. Have your

brakes fixed immediately.

●

The brake system consists of 2 or

more individual hydraulic systems; if

one of the systems fails, the other(s)

will still operate. In this case, the brake

pedal should be depressed more

firmly than usual and the braking dis-

tance will increase. Have your brakes

fixed immediately.

NOTICE

■

When driving the vehicle

●

Do not depress the accelerator and

brake pedals at the same time while

driving, as this may restrain the engine

<hybrid system> output.

●

Do not use the accelerator pedal or

depress the accelerator and brake

pedals at the same time to hold the

vehicle on a hill.

■

Avoiding damage to vehicle parts

●

Do not turn the steering wheel fully in

either direction and hold it there for an

extended period of time.

Doing so may damage the power

steering motor.

●

When driving over bumps in the road,

drive as slowly as possible to avoid

damaging the wheels, underside of the

vehicle, etc.

■

If you get a flat tire while driving

A flat or damaged tire may cause the fol-

lowing situations. Hold the steering

wheel firmly and gradually depress the

brake pedal to slow down the vehicle.

●

It may be difficult to control your vehi-

cle.

176

4-1. Before driving

Cargo capacity depends on the total
weight of the occupants.
(Cargo capacity) = (Total load capac-
ity)



(Total weight of occupants)

NOTICE

●

The vehicle will make abnormal

sounds or vibrations.

●

The vehicle will lean abnormally.

Information on what to do in case of a flat

tire (



P.410)

■

When encountering flooded roads

Do not drive on a road that has flooded

after heavy rain etc. Doing so may cause

the following serious damage to the vehi-

cle:

●

Engine stalling

●

Short in electrical components

●

Engine damage caused by water

immersion

In the event that you drive on a flooded

road and the vehicle is flooded, be sure

to have your Lexus dealer check the fol-

lowing:

●

Brake function

●

Changes in quantity and quality of oil

and fluid used for the engine, transmis-

sion, differential, etc.

●

Lubricant condition for the propeller

shaft, bearings and suspension joints

(where possible), and the function of

all joints, bearings, etc.

If the shift control system is damaged by

flooding, it may not be possible to shift

the shift position to P, or from P to other

positions. In this case, contact your Lexus

dealer.

■

When parking the vehicle

Always set the parking brake, and shift

the shift position to P. Failure to do so

may cause the vehicle to move or the

vehicle may accelerate suddenly if the

accelerator pedal is accidentally

depressed.

Cargo and luggage

Take notice of the following infor-
mation about storage precautions,
cargo capacity and load:

WARNING

■

Things that must not be carried in the

trunk

The following things may cause a fire if

loaded in the trunk:

●

Receptacles containing gasoline

●

Aerosol cans

■

Storage precautions

Observe the following precautions.

Failure to do so may prevent the pedals

from being depressed properly, may

block the driver’s vision, or may result in

items hitting the driver or passengers,

possibly causing an accident.

●

Stow cargo and luggage in the trunk

whenever possible.

●

Do not place cargo or luggage in or on

the following locations.

• At the feet of the driver
• On the front passenger or rear seats

(when stacking items)

• On the package tray
• On the instrument panel
• On the dashboard
• In front of the Center Display

●

Secure all items in the occupant com-

partment.

Capacity and distribution

177

4-1. Before driving

Driving

Steps for Determining Correct Load
Limit



(1) Locate the statement “The com-
bined weight of occupants and cargo
should never exceed XXX kg or XXX
lbs.” on your vehicle’s placard.
(2) Determine the combined weight of
the driver and passengers that will be
riding in your vehicle.
(3) Subtract the combined weight of
the driver and passengers from XXX
kg or XXX lbs.
(4) The resulting figure equals the
available amount of cargo and luggage
load capacity.
For example, if the “XXX” amount
equals 1400 lbs. and there will be five
150 lb passengers in your vehicle, the
amount of available cargo and luggage
load capacity is 650 lbs. (1400

−

750



150) = 650 lbs.)

(5) Determine the combined weight of
luggage and cargo being loaded on
the vehicle. That weight may not safely
exceed the available cargo and lug-
gage load capacity calculated in Step
4.
(6) If your vehicle will be towing a
trailer, load from your trailer will be
transferred to your vehicle. Consult
this manual to determine how this
reduces the available cargo and lug-
gage load capacity of your vehicle.
(



P.178)

Lexus does not recommend towing a
trailer with your vehicle. Your vehicle is not
designed for trailer towing.

Cargo capacity

Total load capacity (vehicle capac-
ity weight) (



P.440)

When 2 people with the combined
weight of A lb. (kg) are riding in your
vehicle, which has a total load capacity
(vehicle capacity weight) of B lb. (kg),
the available amount of cargo and lug-
gage load capacity will be C lb. (kg) as
follows:

lb. (kg) - A

lb. (kg) = C

lb. (kg)

: A = Weight of people

: B = Total load capacity

: C = Available cargo and luggage load

WARNING

■

Capacity and distribution

●

Do not exceed the maximum axle

weight rating or the total vehicle

weight rating.

●

Even if the total load of occupant’s

weight and the cargo load is less than

the total load capacity, do not apply

the load unevenly. Improper loading

may cause deterioration of steering or

braking control which may cause

death or serious injury.

Calculation formula for your
vehicle

A
B

178

4-1. Before driving

In this condition, if 2 more passengers with
the combined weight of D lb. (kg) get on,
the available cargo and luggage load will
be reduced E lb. (kg) as follows:

C lb. (kg) - D

lb. (kg) = E

lb. (kg)

: D = Additional weight of people

: E = Available cargo and luggage load

As shown in the example above, if the
number of occupants increases, the
cargo and luggage load will be
reduced by an amount that equals the
increased weight due to the additional
occupants. In other words, if an
increase in the number of occupants
causes an excess of the total load
capacity (combined weight of occu-
pants plus cargo and luggage load),
you must reduce the cargo and lug-
gage on your vehicle.

■

Total load capacity and seating capacity

These details are also described on the tire

and loading information label. (



P.363)

Vehicle load limits

Vehicle load limits include total
load capacity, seating capacity,
towing capacity and cargo capac-
ity.



Total load capacity (vehicle
capacity weight):



P.440

Total load capacity means the com-
bined weight of occupants, cargo
and luggage.



Seating capacity:



P.440

Seating capacity means the maxi-
mum number of occupants whose
estimated average weight is 150 lb.
(68 kg) per person.



Towing capacity

Lexus does not recommend towing
a trailer with your vehicle.



Cargo capacity

Cargo capacity may increase or
decrease depending on the weight
and the number of occupants.

WARNING

■

Overloading the vehicle

Do not overload the vehicle.

It may not only cause damage to the tires,

but also degrade steering and braking

ability, resulting in an accident.

180

4-2. Driving procedures

4-2.Driving procedures

Press the parking brake switch to
check that the parking brake is set.
(



P.204)

The parking brake indicator will come on.

Firmly depress the brake pedal.

Except Convertible:

and a mes-

sage will be displayed on the multi-infor-

mation display.

If it is not displayed, the engine cannot be

started.

Press the engine switch shortly and
firmly.

When operating the engine switch, one

short, firm press is enough. It is not neces-

sary to press and hold the switch.
The engine will crank until it starts or for up

to 30 seconds, whichever is less.
Continue depressing the brake pedal until

the engine is completely started.
The engine can be started from any engine

switch mode.

■

Engine switch illumination

According to the situation, the engine

switch illumination operates as follows.

●

When a door is opened, or the engine

switch mode is changed from ACC or

ON to off, the engine switch illumination

slowly blinks.

●

Except Convertible: When depressing

the brake pedal with carrying the elec-

tronic key on your person, the engine

switch illumination rapidly blinks.

●

When the engine switch is in ACC or

ON, the engine switch illumination illumi-

nates.

■

If the engine does not start

●

The engine immobilizer system may not

have been deactivated. (



P.94)

Contact your Lexus dealer.

●

If a message related to start-up is shown

on the multi-information display, read the

message and follow the instructions.

●

If the door is unlocked with the mechani-

cal key, the engine cannot be started

using the smart access system with push-

button start. Refer toP.416 to start the

engine. However, if the electronic key is

carried inside the vehicle and the doors

are locked (



P.132), engine can be

started.

■

If the 12-volt battery is discharged

The engine cannot be started using the

Engine (ignition) switch
(LC500)

Performing the following opera-
tions when carrying the electronic
key on your person starts the
engine or changes engine switch
modes.

Starting the engine

181

4-2. Driving procedures

Driving

smart access system with push-button start.

Refer to P.418 to restart the engine.

■

Electronic key battery depletion



P.126

■

Conditions affecting operation



P.139

■

Notes for the entry function



P.140

■

If there is a malfunction in the smart

access system with push-button start

If “Access System with Elec. Key Malfunc-

tion” is displayed on the multi-information

display, the system may be malfunctioning.

Have the vehicle inspected by your Lexus

dealer immediately.

■

Electronic key battery



P.368

■

Operation of the engine switch

●

If the switch is not pressed shortly and

firmly, the engine switch mode may not

change or the engine may not start.

●

If attempting to restart the engine imme-

diately after turning the engine switch off,

the engine may not start in some cases.

After turning the engine switch off, please

wait a few seconds before restarting the

engine.

■

Customization

If the smart access system with push-button

start has been deactivated in a customized

setting, refer to P.415.

Stop the vehicle completely.

If the parking brake is in manual
mode, set the parking brake.
(



P.204)

Press the P position switch.
(



P.191)

Check that the shift position indicator

shows P and the parking brake indicator is

illuminated.

Press the engine switch.

The engine will stop, and the meter display

will be extinguished (the shift position indi-

cator will be extinguished a few seconds

after the meter display).

Check that “ACCESSORY” or
“IGNITION ON” is not shown on
the meter.

■

Automatic engine shut off feature

●

The vehicle is equipped with a feature

that automatically shuts off the engine

when the shift position is in P with the

engine running for an extended period.

●

The engine will automatically shut off

after approximately 1 hour if it has been

WARNING

■

When starting the engine

Always start the engine while sitting in

the driver’s seat. Do not depress the

accelerator pedal while starting the

engine under any circumstances.

Doing so may cause an accident result-

ing in death or serious injury.

NOTICE

■

When starting the engine

●

Do not race a cold engine.

●

If the engine becomes difficult to start

or stalls frequently, have your vehicle

checked by your Lexus dealer imme-

diately.

■

Symptoms indicating a malfunction

with the engine switch

If the engine switch seems to be operat-

ing somewhat differently than usual, such

as the switch sticking slightly, there may

be a malfunction. Contact your Lexus

dealer immediately.

Stopping the engine

182

4-2. Driving procedures

left running while the shift position is in P.

●

The timer for the automatic engine shut

off feature will reset if the brake pedal is

depressed or if the shift position is in a

position other than P.

●

After the vehicle is parked, if the door is

locked with the door lock switch

(



P.132) from the inside or the mechan-

ical key (



P.415) from the outside, the

automatic engine shut off feature will be

disabled. The timer for the automatic

engine shut off feature will be re-enabled

if the driver’s door is opened.

■

Automatic P position selection function



P.192

Modes can be changed by pressing
the engine switch with the brake pedal
released. (The mode changes each
time the switch is pressed.)

WARNING

■

Stopping the engine in an emergency

●

If you want to stop the engine in an

emergency while driving the vehicle,

press and hold the engine switch for

more than 2 seconds, or press it briefly

3 times or more in succession.

(



P.376)

However, do not touch the engine

switch while driving except in an emer-

gency. Turning the engine off while

driving will not cause loss of steering

or braking control, however, power

assist to the steering will be lost. This

will make it more difficult to steer

smoothly, so you should pull over and

stop the vehicle as soon as it is safe to

do so.

●

If the engine switch is operated while

the vehicle is running, a warning mes-

sage will be shown on the multi-infor-

mation display and a buzzer sounds.

●

When restarting the engine after an

emergency shutdown, press the

engine switch.

■

When parking

Exhaust gases include harmful carbon

monoxide (CO), which is colorless and

odorless. Observe the following precau-

tions.
Failure to do so may cause exhaust gases

to enter the vehicle and may lead to an

accident caused by light-headedness, or

may lead to death or a serious health

hazard.

●

If the vehicle is in a poorly ventilated

area or a closed area, such as a

garage, stop the engine.

●

Do not leave the vehicle with the

engine running for a long time. If such

a situation cannot be avoided, park the

vehicle in an open space and ensure

that exhaust fumes do not enter the

vehicle interior.

●

Do not leave the engine running in an

area with snow build-up, or where it is

snowing. If snowbanks build up around

the vehicle while the engine is running,

exhaust gases may collect and enter

the vehicle.

Changing engine switch modes

183

4-2. Driving procedures

Driving

“ACCESSORY”

“IGNITION ON”

Off

The emergency flashers can be used.

ACC

Some electrical components such as the
audio system can be used.
“ACCESSORY” will be displayed on the
meter.

All electrical components can be used.
“IGNITION ON” will be displayed on the
meter.

■

Auto power off function

If the vehicle is left in ACC for more than

20 minutes or ON (the engine is not run-

ning) for more than an hour with the shift

position in P, the engine switch will auto-

matically turn off. However, this function

cannot entirely prevent the 12-volt battery

discharge. Do not leave the vehicle with the

engine switch in ACC or ON for long peri-

ods of time when the engine is not running.

■

When the shift control system malfunc-

tions

When attempting to turn the engine switch

off while there is a malfunction in the shift

control system, the engine switch mode

may change to ACC. In this case, ACC

may be turned off by applying the parking

brake and pressing the engine switch again.
If there is a malfunction in the system, have

the vehicle inspected by your Lexus dealer

immediately.

A
B

NOTICE

■

To prevent 12-volt battery discharge

●

Do not leave the engine switch in

ACC or ON for long periods of time

without the engine running.

●

If “ACCESSORY” or “IGNITION

ON” is displayed on the meter, the

engine switch is not off.

Exit the vehicle after turning the

engine switch off.

184

4-2. Driving procedures

Press the parking brake switch to
check that the parking brake is set.
(



P.204)

The parking brake indicator will come on.

Firmly depress the brake pedal.

and a message will be displayed on

the multi-information display.

If it is not displayed, the hybrid system can-

not be started.
When the shift position is N, the hybrid sys-

tem cannot start.
Shift the shift position to P when starting

the hybrid system. (



P.198)

Press the power switch shortly and
firmly.

When operating the power switch, one

short, firm press is enough. It is not neces-

sary to press and hold the switch.
If the “READY” indicator turns on, the

hybrid system will operate normally.
Continue depressing the brake pedal until

the “READY” indicator is illuminated.
The hybrid system can be started from any

power switch mode.

Check that the “READY” indicator
is illuminated.

If the “READY” indicator changes from a

flashing light to a solid light and the buzzer

sounds, the hybrid system is starting nor-

mally.
The vehicle will not move when the

“READY” indicator is off.
The vehicle can move when the “READY”

indicator is on even if the engine is

stopped. (The gasoline engine starts or

stops automatically in accordance with the

state of the vehicle.)

■

Power switch illumination

According to the situation, the power

switch illumination operates as follows.

●

When a door is opened, or the power

switch mode is changed from ACC or

ON to off, the power switch illumination

slowly blinks.

●

When depressing the brake pedal with

carrying the electronic key on your per-

son, the power switch illumination rapidly

blinks.

●

When the power switch is in ACC or

ON, the power switch illumination illumi-

nates.

■

If the hybrid system does not start

●

The immobilizer system may not have

been deactivated. (



P.94)

Contact your Lexus dealer.

●

If a message related to start-up is shown

on the multi-information display, read the

message and follow the instructions.

●

If the door is unlocked with the mechani-

Power (ignition) switch
(LC500h)

Performing the following opera-
tions when carrying the electronic
key on your person starts the hybrid
system or changes power switch
modes.

Starting the hybrid system

185

4-2. Driving procedures

Driving

cal key, the hybrid system cannot be

started using the smart access system

with push-button start. Refer to P.416 to

start the hybrid system. However, if the

electronic key is carried inside the vehi-

cle and the doors are locked (



P.132),

hybrid system can be started.

■

When the ambient temperature is low,

such as during winter driving conditions

●

When starting the hybrid system, the

flashing time of the “READY” indicator

may be long. Leave the vehicle as it is

until the “READY” indicator is steady on,

as steady means the vehicle is able to

move.

●

When the hybrid battery (traction bat-

tery) is extremely cold (below approxi-

mately -22°F [-30°C]) under the

influence of the outside temperature, it

may not be possible to start the hybrid

system. In this case, try to start the hybrid

system again after the temperature of the

hybrid battery increases due to the out-

side temperature increase etc.

■

Sounds and vibrations specific to a

hybrid electric vehicle



P.88

■

If the 12-volt battery is discharged

The hybrid system cannot be started using

the smart access system with push-button

start. Refer to P.418 to restart the hybrid

system.

■

Electronic key battery depletion



P.126

■

Conditions affecting operation



P.139

■

Notes for the entry function



P.140

■

If there is a malfunction in the smart

access system with push-button start

If “Access System with Elec. Key Malfunc-

tion” is displayed on the multi-information

display, the system may be malfunctioning.

Have the vehicle inspected by your Lexus

dealer immediately.

■

If the “READY” indicator does not

come on

In the event that the “READY” indicator

does not come on even after performing

the proper procedures for starting the vehi-

cle, contact your Lexus dealer immediately.

■

If the hybrid system is malfunctioning



P.92

■

Electronic key battery



P.368

■

Operation of the power switch

●

If the switch is not pressed shortly and

firmly, the power switch mode may not

change or the hybrid system may not

start.

●

If attempting to restart the hybrid system

immediately after turning the power

switch off, the hybrid system may not start

in some cases. After turning the power

switch off, please wait a few seconds

before restarting the hybrid system.

■

Customization

If the smart access system with push-button

start has been deactivated in a customized

setting, refer to P.415.

WARNING

■

When starting the hybrid system

Always start the hybrid system while sit-

ting in the driver’s seat. Do not depress

the accelerator pedal while starting the

hybrid system under any circumstances.

Doing so may cause an accident result-

ing in death or serious injury.

NOTICE

■

When starting the hybrid system

If the hybrid system becomes difficult to

start, have your vehicle checked by your

Lexus dealer immediately.

186

4-2. Driving procedures

Stop the vehicle completely.

If the parking brake is in manual
mode, set the parking brake.
(



P.204)

Press the P position switch.
(



P.198)

Check that the shift position indicator

shows P and the parking brake indicator is

illuminated.

Press the power switch.

The hybrid system will stop, and the meter

display will be extinguished (the shift posi-

tion indicator will be extinguished a few

seconds after the meter display).

Check that “ACCESSORY” or
“IGNITION ON” is not shown on
the meter.

■

Automatic hybrid system shut off fea-

ture

●

The vehicle is equipped with a feature

that automatically shuts off the hybrid sys-

tem when the shift position is in P with the

hybrid system operating for an extended

period.

●

The hybrid system will automatically shut

off after approximately 1 hour if it has

been left running while the shift position is

in P.

●

The timer for the automatic hybrid system

shut off feature will reset if the brake

pedal is depressed or if the shift position

is in a position other than P.

●

After the vehicle is parked, if the door is

locked with the door lock switch

(



P.132) from the inside or the mechan-

ical key (



P.415) from the outside, the

automatic hybrid system shut off feature

will be disabled. The timer for the auto-

matic hybrid system shut off feature will

be re-enabled if the driver’s door is

opened.

■

Automatic P position selection function



P.199

NOTICE

■

Symptoms indicating a malfunction

with the power switch

If the power switch seems to be operat-

ing somewhat differently than usual, such

as the switch sticking slightly, there may

be a malfunction. Contact your Lexus

dealer immediately.

Stopping the hybrid system

WARNING

■

Stopping the hybrid system in an

emergency

●

If you want to stop the hybrid system in

an emergency while driving the vehi-

cle, press and hold the power switch

for more than 2 seconds, or press it

briefly 3 times or more in succession.

(



P.376)

However, do not touch the power

switch while driving except in an emer-

gency. Turning the hybrid system off

while driving will not cause loss of

steering or braking control, however,

power assist to the steering will be lost.

This will make it more difficult to steer

smoothly, so you should pull over and

stop the vehicle as soon as it is safe to

do so.

●

If the power switch is operated while

the vehicle is running, a warning mes-

sage will be shown on the multi-infor-

mation display and a buzzer sounds.

●

When restarting the hybrid system

after an emergency shutdown, press

the power switch.

■

When parking

Exhaust gases include harmful carbon

monoxide (CO), which is colorless and

odorless. Observe the following precau-

tions.
Failure to do so may cause exhaust gases

to enter the vehicle and may lead to an

accident caused by light-headedness, or

may lead to death or a serious health

hazard.

Lexus LC500C (2024 year). Manual in english - page 5
