Lexus LC500C (2024 year). Manual in english

123

2-1. Instrument cluster

Vehi

cle

status

inform

ati

on a

nd i

ndic
ators



Center Display

The image shows all the arrows as an
example. The actual display will vary
depending on conditions.

Gasoline engine

Electric motor (traction motor)

Hybrid battery (traction battery)

Tires

■

Hybrid battery (traction battery) status

The display changes in 8 levels according

to the remaining charge amount of the

hybrid battery (traction battery).

●

The figure shows the multi-information

display as an example for explanation.

●

These images are examples only, and

may vary slightly from actual conditions.

Low

High

■

Remaining charge amount warning of

hybrid battery (traction battery)

●

The buzzer sounds intermittently when

the hybrid battery (traction battery)

remains without charging while the shift

lever is in N, or the remaining charge

amount drops below a certain level. If the

remaining charge amount drops further,

the buzzer sounds continuously.

●

When a warning message is shown on

the multi-information display and the

buzzer sounds, follow the instructions

displayed on the screen to perform trou-

bleshooting.

■

Display procedure

Select

on the main menu.

Select “Trip information”.

Select “Current”.

■

Display

Resetting the history data

Fuel consumption in the past 15
minutes

Current fuel consumption

Average vehicle speed since the
engine <hybrid system> was started.

Trip range

Elapsed time since the engine
<hybrid system> was started.

Use the displayed average fuel consump-
tion as a reference.
The image is an example only, and may
vary slightly from actual conditions.

A
B
C
D

Current screen

A
B

C
D

E
F

124

2-1. Instrument cluster

■

Display procedure

Select

on the main menu.

Select “Trip information”.

Select “History”.

■

Display

Latest fuel consumption

Best recorded fuel consumption

Previous fuel consumption record

Resetting the history data

Updating the latest fuel consump-
tion data

Use the displayed average fuel consump-
tion as a reference.
The image is an example only, and may
vary slightly from actual conditions.

■

Updating the history data

Update the latest fuel consumption by

selecting “Update” to measure the current

fuel consumption again.

■

Resetting the data

The fuel consumption data can be deleted

by selecting “Clear data”.

■

Trip range

Displays the estimated maximum distance

that can be driven with the quantity of fuel

remaining.

This distance is computed based on your

average fuel consumption.

As a result, the actual distance that can be

driven may differ from that displayed.

History screen

A
B
C
D

125

fore
dri
ving

Before driving

3-1. Key information

Keys .................................................

126

3-2. Opening, closing and locking the

doors and trunk

Doors...............................................

130

Trunk................................................

134

Smart access system with push-

button start.................................

137

3-3. Adjusting the seats

Front seats.....................................

143

Driving position memory ........

145

Head restraints............................

149

3-4. Adjusting the steering wheel and

mirrors

Steering wheel..............................

151

Inside rear view mirror.............

152

Outside rear view mirrors......

153

3-5. Opening and closing the win-

dows

Power windows...........................

156

3-6. Opening and closing the soft top

roof

Soft top roof (Convertible) ....

160

126

3-1. Key information

3-1.Key information

The following keys are provided with
the vehicle.

Electronic keys

• Operating the smart access system with

push-button start (



P.137)

• Operating the wireless remote control

function

Mechanical keys

Key number plate

Card key (electronic key) (if
equipped)

Operating the smart access system with
push-button start (



P.137)

■

Card key (if equipped)

●

The card key is not waterproof.

●

The mechanical key that is stored inside

the card key should be used only if a

problem arises, such as when the card

key does not operate properly.

●

If the battery cover is not installed and the

battery falls out or if the battery was

removed because the key got wet, rein-

stall the battery with the positive terminal

facing the Lexus emblem.

■

When riding in an aircraft

When bringing an electronic key onto an

aircraft, make sure you do not press any

buttons on the electronic key while inside

the aircraft cabin. If you are carrying an

electronic key in your bag etc., ensure that

the buttons are not likely to be pressed

accidentally. Pressing a button may cause

the electronic key to emit radio waves that

could interfere with the operation of the air-

craft.

■

Electronic key battery depletion

●

The standard battery life is 1 to 2 years.

(The card key battery life is from one year

to one year and a half.)

●

If the battery becomes low, an alarm will

sound in the cabin when the engine

<hybrid system> is stopped.

●

Electronic keys that will not be used for

long periods of time can be set to the bat-

tery-saving mode in advance. (



P.139)

●

As the electronic key always receives

radio waves, the battery will become

depleted even if the electronic key is not

used. The following symptoms indicate

that the electronic key battery may be

depleted. Replace the battery when nec-

essary. (



P.368)

• The smart access system with push-but-

ton start or the wireless remote control

does not operate.

• The detection area becomes smaller.

• The LED indicator on the key surface

does not turn on.

You can replace the battery by yourself

Keys

Key types

B
C
D

127

3-1. Key information

fore
dri
ving

(



P.368). However, as there is a danger

that the electronic key may be damaged, it
is recommended that replacement be car-
ried out by your Lexus dealer.

●

To avoid serious deterioration, do not

leave the electronic key within 3 ft. (1 m)

of the following electrical appliances that

produce a magnetic field:

• TVs

• Personal computers

• Cellular phones, cordless phones and

battery chargers

• Recharging cellular phones or cordless

phones

• Table lamps

• Induction cookers

■

Replacing the battery



P.368

■

Confirmation of the registered key

number

The number of keys already registered to

the vehicle can be confirmed. Ask your

Lexus dealer for details.

■

If “A New Key has been Registered

Contact Your Dealer for Details” is

shown on the multi-information display

This message will be displayed each time

the driver’s door is opened when the doors

are unlocked from the outside for approxi-

mately 10 days after a new electronic key

has been registered.

If this message is displayed but you have not

had a new electronic key registered, ask

your Lexus dealer to check if an unknown

electronic key (other than those in your

possession) has been registered.

NOTICE

■

To prevent key damage

●

Do not drop the keys, subject them to

strong shocks or bend them.

●

Do not expose the keys to high tem-

peratures for long periods of time.

●

Do not get the keys wet or wash them

in an ultrasonic washer etc.

●

Do not attach metallic or magnetic

materials to the keys or place the keys

close to such materials.

●

Do not disassemble the keys.

●

Do not attach a sticker or anything else

to the surface of the electronic key.

●

Do not place the keys near objects that

produce magnetic fields, such as TVs,

audio systems and induction cookers.

●

Do not place the keys near medical

electrical equipment such as low-fre-

quency therapy equipment or micro-

wave therapy equipment, and do not

receive medical attention with the keys

on your person.

■

Carrying the electronic key on your

person

Carry the electronic key 3.9 in. (10 cm)

or more away from electric appliances

that are turned on. Radio waves emitted

from electric appliances within 3.9 in. (10

cm) of the electronic key may interfere

with the key, causing the key to not func-

tion properly.

■

In case of a smart access system with

push-button start malfunction or

other key-related problems



P.415

■

When an electronic key is lost



P.413

■

Handling the card key (if equipped)

●

If the battery or card key terminals get

wet, the battery may corrode and the

card key may stop working.

If the key is dropped into water, or if

drinking water, etc. is spilled on the

key, immediately remove the battery

cover and wipe the battery and termi-

nals. (To remove the battery cover,

lightly grasp and pull it.) If the battery is

corroded, have your Lexus dealer

replace the battery.

128

3-1. Key information

The electronic keys are equipped with
the following wireless remote control:

Locks the doors (

Unlocks the doors (

Opens the windows

(



P.130)

Opens the trunk (



P.136)

Sounds the alarm (



P.128)

: This setting must be customized at your

Lexus dealer.

■

Theft deterrent panic mode

When

is pressed for longer than

about one second, an alarm will sound
intermittently and the vehicle lights will flash
to deter any person from trying to break
into or damage your vehicle.
To stop the alarm, press any button on the

electronic key.

To take out the mechanical key, push
the release button and take the key out.

The mechanical key can only be inserted in
one direction, as the key only has grooves
on one side. If the key cannot be inserted in
a lock cylinder, turn it over and re-attempt
to insert it.
After using the mechanical key, store it in
the electronic key. Carry the mechanical
key together with the electronic key. If the
electronic key battery is depleted or the
entry function does not operate properly,
you will need the mechanical key.
(



P.415)

NOTICE

●

Do not crush the battery cover or use

a screwdriver to remove the battery

cover.

Forcibly removing the battery cover

may bend or damage the key.

●

If the battery cover is frequently

removed, the battery cover may

become loose.

●

When installing the battery, make sure

to check the direction of the battery.

Installing the battery in the wrong

direction may cause the battery to

deplete rapidly.

●

The surface of the card key may be

damaged, or its coating may peel off in

the following situations:

• The card key is carried together with

hard objects, such as coins and keys.

• The card key is scraped with a sharp

object, such as the tip of a mechanical

pencil.

• The surface of the card key is wiped

with thinner or benzene.

Wireless remote control

A
B
C

Using the mechanical key

129

3-1. Key information

fore
dri
ving

■

When required to leave the vehicle’s

key with a parking attendant

Turn the trunk opener main switch off and

lock the glove box (



P.305) as circum-

stances demand.

Remove the mechanical key for your own

use and provide the attendant with the elec-

tronic key only.

■

If you lose your mechanical keys



P.413

■

If a wrong key is used

The key cylinder rotates freely, isolated

from the internal mechanism.

■

Card key (if equipped)

●

If it is difficult to take out the mechanical

key, push down the release button using

a pen tip etc. If it is still difficult to pull it

out, use a coin etc. (



P.128)

●

To store the mechanical key in the card

key, insert it while pressing the release

button.

NOTICE

■

Handling the card key (if equipped)

●

Do not apply excess force when

inserting the mechanical key into the

card key. Doing so may damage the

card key.

130

3-2. Opening, closing and locking the doors and trunk

3-2.Opening, closing and locking the doors and trunk

■

Smart access system with push-
button start

Carry the electronic key to enable this
function.

Push the depression on the front
edge of the driver’s door handle to
unlock the door. Push the depres-
sion on the front edge of the pas-
senger’s door handle to unlock
both side doors.

The outside door handles will be extended.
The extended outside door handles are
automatically retracted in approximately
60 seconds.
The doors cannot be unlocked for 3 sec-
onds after the doors are locked.

: The door unlock settings can be

changed.

Push the rear edge of the extended
door handle to lock the doors.

If the outside door handles are extended,
they will be retracted.
After locking the doors, check that the
door is securely locked with the door lock
indicator (



P.133).

■

Wireless remote control

Locks both side doors

The outside door handles will be retracted
if they have been extended. After locking
the doors, check that the door is securely
locked with the door lock indicator
(



P.133).

Unlocks both side doors

Pressing the button unlocks the driver’s
door. Pressing the button again within 5
seconds unlocks the other door.
The outside door handles will be extended.
Press and hold to open the windows.

: This setting must be customized at your

Lexus dealer.

■

Side window open/close function linked

to door operation

When a door is opened, its window opens

slightly. When a door is closed, its window

closes completely.

■

Speed-linked outside door handle

retracting function

When the vehicle speed reaches 6 mph (10

km/h), the outside door handles will be

retracted.

■

To extend the outside door handles

retracted automatically

The outside door handle can be extended

by pushing the depression on the front

edge of it. To lock the doors, push the rear

edge of the outside door handle after

extending it once.

Doors

Unlocking and locking the doors
from the outside

131

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

■

Switching the door unlock function

It is possible to set which doors the entry

function unlocks using the wireless remote

control.

Turn the engine switch <power switch>

off.

When the indicator light on the key sur-
face is not on, press and hold

for approximately 5

seconds while pressing and holding

The setting changes each time an operation

is performed, as shown below. (When

changing the setting continuously, release

the buttons, wait for at least 5 seconds, and

repeat step

To prevent unintended triggering of the
alarm, unlock the doors using the wireless
remote control and open and close a door
once after the settings have been changed.

(If a door is not opened within 60 seconds
after

is pressed, the doors will be

locked again and the alarm will automati-
cally be set.)
In a case that the alarm is triggered, imme-
diately stop the alarm. (



P.95)

■

Impact detection door lock release sys-

tem

In the event that the vehicle is subject to a

strong impact, both side doors are

unlocked. Depending on the force of the

impact or the type of accident, however, the

system may not operate.

■

Operation signals

A buzzer sounds and the emergency flash-

ers flash to indicate that the doors have

been locked/unlocked. (Locked: once;

Unlocked: twice)
A buzzer sounds to indicate that the win-

dows are operating.
Convertible: Depending on the open-

ing/closing state of the soft top roof, the

buzzer may be delayed.

■

Security feature

If a door is not opened within approximately

60 seconds after the vehicle is unlocked,

the security feature automatically locks the

vehicle again.

■

Open door warning buzzer

If an attempt to lock the doors is made when

a door is not fully closed, a buzzer sounds

continuously for 5 seconds. Fully close the

door to stop the buzzer, and lock the vehi-

cle once more.

■

Setting the alarm

Locking the doors will set the alarm system.

(



P.95)

■

Conditions affecting the operation of

the smart access system with push-but-

ton start or wireless remote control



P.139

■

If the smart access system with push-

button start or the wireless remote con-

trol does not operate properly

Use the mechanical key to lock and unlock

Multi-information

display/Beep

Unlocking function

Exterior: Beeps 3

times

Interior: Pings

once

Pushing the depres-
sion on the front edge
of the driver’s door
handle unlocks only
the driver’s door.

Pushing the depres-
sion on the front edge
of the passenger’s
door handle unlocks
both side doors.

Exterior: Beeps

twice

Interior: Pings

once

Pushing the depres-
sion on the front edge
of either door handle
unlocks both side
doors.

132

3-2. Opening, closing and locking the doors and trunk

the doors. (



P.415)

Replace the key battery with a new one if it

is depleted. (



P.368)

■

If the 12-volt battery is discharged

The doors cannot be locked and unlocked

using the smart access system with push-

button start or wireless remote control.

Lock or unlock the doors using the

mechanical key. (



P.415)

■

Customization

Settings (e.g. unlocking function using a

key) can be changed.

(Customizable features:



P.459)

■

Door lock switches

Locks both side doors

The indicator

comes on.

Unlocks both side doors

The indicator

turns off.

■

Inside door handles

Pull the inside door handle to unlock
the door.

The door lock indicator

turns off.

The doors can be opened by pulling the
inside door handle even if the door lock
indicator

illuminates.

WARNING

■

To prevent an accident

Observe the following precautions while

driving the vehicle.

Failure to do so may result in a door

opening and an occupant being thrown

out of the vehicle, resulting in death or

serious injury.

●

Ensure that both side doors are prop-

erly closed and locked.

●

Do not pull the inside handle of the

doors while driving.

The doors may be opened even if they

are locked.

■

Side window open/close function

linked to door operation

Do not hold the upper edge of the side

window when you close the door. Other-

wise, your fingers or hand may be caught

in the window.

■

When entering and exiting the vehi-

cle

Do not step on the scuff plate. Slipping

on the surface may result in injury.

Unlocking and locking the doors
from the inside

133

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

■

Door lock indicator

The door lock indicator turns on when the

door is locked. When the engine switch

<power switch> is off, the door lock indica-

tor will turn off automatically after 30 sec-

onds.

■

If a symbol indicating one or both side

doors open is shown on the multi-infor-

mation display

The hood, one or both side of the doors, or

trunk are not fully closed. If the vehicle

reaches a speed of 3 mph (5 km/h), the

master warning light flashes and a buzzer

sounds to indicate that the door(s) are not

fully closed. Make sure to close hood, both

side doors and trunk.

■

Customization

The time elapsed before the door lock indi-

cator turns off can be changed.

(Customizable features:



P.459)

The following functions can be set or
canceled:

For instructions on customizing, refer to
P.459.

Automatic door locking and
unlocking systems

Function

Operation

Speed linked
door locking
function

Both side doors are
automatically locked
when vehicle speed is
approximately 12 mph
(20 km/h) or higher.

Shift position
linked door lock-
ing function

Both side doors are
automatically locked
when the shift position
is shifted to a position
other than P.

Shift position
linked door
unlocking func-
tion

Both side doors are
automatically unlocked
when the shift position
is shifted to P.

Driver’s door
linked door
unlocking func-
tion

Both side doors are
automatically unlocked
when driver’s door is
opened within approxi-
mately 45 seconds
after turning the engine
switch <power switch>
off.

134

3-2. Opening, closing and locking the doors and trunk

Trunk

The trunk can be opened using the
trunk opener switch, entry function
or wireless remote control.

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

■

Before driving

●

Make sure that the trunk lid is fully

closed. If the trunk lid is not fully

closed, it may open unexpectedly

while driving and hit near-by objects or

luggage in the trunk may be thrown

out, causing an accident.

●

Do not allow children to play in the

trunk.

If a child is accidentally locked in the

trunk, they could suffer from heat

exhaustion, suffocation or other inju-

ries.

●

Do not allow a child to open or close

the trunk lid.

Doing so may cause the trunk lid to

open unexpectedly, or cause the

child’s hands, head, or neck to be

caught by the closing trunk lid.

■

Important points while driving

Never let anyone sit in the trunk. In the

event of sudden braking or a collision,

they are susceptible to death or serious

injury.

■

Using the trunk

Observe the following precautions.

Failure to do so may cause parts of the

body to be caught, resulting in serious

injury.

●

Remove any heavy loads, such as

snow and ice, from the trunk lid before

opening it. Failure to do so may cause

the trunk lid to suddenly shut again

after it is opened.

●

When opening or closing the trunk lid,

thoroughly check to make sure the

surrounding area is safe.

●

If anyone is in the vicinity, make sure

they are safe and let them know that

the trunk is about to open or close.

●

Use caution when opening or closing

the trunk lid in windy weather as it may

move abruptly in strong wind.

●

On an incline it is more difficult to

open or close the trunk lid than on a

level surface, so beware of the trunk lid

unexpectedly opening or closing by

itself. Make sure that the trunk lid is

fully open and secure before using the

trunk.

●

When opening the trunk lid, take care

so that it does not hit anyone in the

face or any other part of the body.

●

When closing the trunk lid, take extra

care to prevent your fingers etc. from

being caught.

●

When closing the trunk lid, make sure

to press it lightly on its outer surface. If

the trunk grip is used to fully close the

trunk lid, it may result in hands or arms

being caught.

135

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

■

Trunk opener switch

Press the trunk opener switch.
Convertible: When the doors has been
locked using the entry function or wire-
less remote control, the trunk cannot
be opened.

■

Smart access system with push-
button start

While carrying the electronic key,
press the button.
When both side doors are unlocked
using one of the following methods, the
trunk can be opened without the elec-
tronic key:
• Entry function
• Wireless remote control
• Door lock switches
• Automatic door unlocking system
• Mechanical key

WARNING

●

Do not pull on the trunk damper stay

to close the trunk lid, and do not hang

on the trunk damper stay.

Doing so may cause hands to be

caught or the trunk damper stay to

break, causing an accident.

●

Do not attach any accessories other

than genuine Lexus parts to the trunk

lid. Such additional weight on the trunk

lid may cause the lid to suddenly shut

again after it is opened.

NOTICE

■

Trunk damper stays

The trunk is equipped with damper stays

that hold the trunk lid in place.

Observe the following precautions. Fail-

ure to do so may cause damage to the
trunk damper stay

, resulting in mal-

function.

●

Do not attach any foreign objects,

such as stickers, plastic sheets, or

adhesives to the damper stay rod.

●

Do not touch the damper stay rod with

gloves or other fabric items.

●

Do not attach any accessories other

than genuine Lexus parts to the trunk

lid.

●

Do not place your hand on the damper

stay or apply lateral forces to it.

Opening the trunk

136

3-2. Opening, closing and locking the doors and trunk

■

Wireless remote control

Press and hold the switch.

A buzzer sounds.

■

When the operation of the soft top roof

has not been completed (Convertible)

The trunk lid cannot be opened. Wait until

the soft top roof is fully opened or closed

before opening the trunk lid. (



P.160)

■

Trunk light

The trunk light turns on when the trunk is

opened.

■

Function to prevent the trunk being

locked with the electronic key inside

●

When both side doors are locked, clos-

ing the trunk lid with the electronic key

left inside the trunk will sound an alarm.

In this case, the trunk lid can be opened

by pressing the trunk release button on

the trunk lid.

●

If the spare electronic key is put in the

trunk with both side doors locked, the key

confinement prevention function is acti-

vated so the trunk can be opened. In

order to prevent theft, take all electronic

keys with you when leaving the vehicle.

●

If the electronic key is put in the trunk

with both side doors locked, the key may

not be detected depending on the loca-

tion of the key and the surrounding radio

wave conditions. In this case, the key con-

finement prevention function cannot be

activated, causing the trunk to be locked

when the trunk lid is closed. Make sure to

check where the key is before closing the

trunk.

●

The key confinement prevention function

cannot be activated if either door is

unlocked. In this case, open the trunk

using the trunk opener switch.

●

If the trunk lid is closed by a hand having

the electronic key when the both side

doors are locked, a warning buzzer may

sound. In this case, the trunk is not locked.

Do not close the trunk lid by a hand hav-

ing the electronic key.

■

Internal trunk release lever

The trunk lid can be opened by pulling the

glow-in-the-dark lever located on the inside

of the trunk to the side.
The lever will continue to glow for some

time after the trunk lid is closed.

■

If the smart access system with push-

button start or the wireless remote con-

trol does not operate properly

Use the trunk opener switch to unlock the

trunk. (



P.415)

Replace the key battery with a new one if it

is depleted. (



P.368)

■

If a symbol indicating the trunk opens is

shown on the multi-information display



P.133

■

If the 12-volt battery is discharged

The trunk cannot be locked and unlocked

using the smart access system with push-

button start or wireless remote control.

Lock or unlock the trunk using the mechan-

ical key. (



P.417)

■

Customization

The trunk unlocking operation can be

changed. (Customizable features:



P.459)

Using the trunk grip, lower the trunk

Closing the trunk

137

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

without applying force to the side and
push the trunk down from the outside
to close it.

The trunk opener switch can be tem-
porarily disabled to protect luggage
stored in the trunk against theft.
Turn the trunk opener main switch in
the glove box off to disable the trunk
opener.

Off

When the trunk opener main switch is off,
the trunk lid cannot be opened even with
the wireless remote control or entry func-
tion.

■

When leaving a key to the vehicle with a

parking attendant



P.129

■

Antenna location



Except Convertible

Protecting luggage against theft

A
B

Smart access system with
push-button start

The following operations can be
performed simply by carrying the
electronic key (including the card
key) on your person, for example in
your pocket. The driver should
always carry the electronic key.



Locks and unlocks the doors
(



P.130)



Opens the trunk (



P.135)



Starts the engine <hybrid system>
(



P.180, 184)

138

3-2. Opening, closing and locking the doors and trunk



Convertible

Antennas outside the cabin

Antennas inside the cabin

Antenna inside the trunk

Antenna outside the trunk

■

Effective range (areas within which the

electronic key is detected)



Except Convertible



Convertible

When locking or unlocking the doors
The system can be operated when the
electronic key is within about 2.3 ft. (0.7

m) of an outside door handle. (Only the
doors detecting the key can be oper-
ated.)

When opening the trunk
The system can be operated when the
electronic key is within about 2.3 ft. (0.7
m) of the trunk release button.

When starting the engine <hybrid sys-
tem> or changing engine switch <power
switch> modes
The system can be operated when the
electronic key is inside the vehicle.

■

If an alarm sounds or a warning message

is displayed

An alarm sounds and warning messages

are displayed on the multi-information dis-

play to protect against unexpected acci-

dents or theft of the vehicle resulting from

erroneous operation. When a warning

message is displayed, take appropriate

measures based on the displayed message.
When only an alarm sounds, circumstances

and correction procedures are as follows.

●

When an exterior alarm sounds once for

5 seconds

Situation

Correction proce-

dure

The trunk was
closed while the
electronic key was
still inside the trunk
and both side doors
were locked.

Retrieve the elec-
tronic key from the
trunk and close the
trunk lid.

An attempt was
made to lock the
vehicle while a door
was open.

Close both side
doors and lock the
doors again.

139

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

●

When an interior alarm sounds continu-

ously

■

If “Key Detected in Vehicle” is shown on

the multi-information display

An attempt was made to lock the doors

using the smart access system with push-

button start while the electronic key was still

inside the vehicle. Retrieve the electronic

key from the vehicle and lock the doors

again.

■

Battery-saving function

The battery-saving function will be acti-

vated in order to prevent the electronic key

battery and the 12-volt battery from being

discharged while the vehicle is not in opera-

tion for a long time.

●

In the following situations, the smart

access system with push-button start may

take some time to unlock the doors.

• The electronic key has been left within

approximately 6 ft. (2 m) of the outside of

the vehicle for 10 minutes or longer.

• The smart access system with push-but-

ton start has not been used for 5 days or

longer.

●

If the smart access system with push-but-

ton start has not been used for 14 days or

longer, the doors cannot be unlocked at

the passenger door. In this case, push the

depression on the front edge the driver’s

door handle, or use the wireless remote

control or mechanical key, to unlock the

doors.

■

Turning an electronic key to battery-

saving mode

When battery-saving mode is set, battery

depletion is minimized by stopping the

electronic key from receiving radio waves.

Press

twice while pressing and

holding

. Confirm that the elec-

tronic key indicator flashes 4 times.
While the battery-saving mode is set, the
smart access system with push-button start
cannot be used. To cancel the function,
press any of the electronic key buttons.

●

Electronic keys that will not be used for

long periods of time can be set to the bat-

tery-saving mode in advance.

■

When electronic key function stops

If the position of the electronic key has not

changed for a certain amount of time such

as when the electronic key is left some-

where, the function of the electronic key

stops to reduce depletion of the battery. In

this case, function can automatically be

restored by moving the position of the key

such as by lifting it up.

■

Conditions affecting operation

The smart access system with push-button

start uses weak radio waves. In the follow-

ing situations, the communication between

the electronic key and the vehicle may be

affected, preventing the smart access sys-

tem with push-button start, wireless remote

control and engine immobilizer system

<immobilizer system> from operating prop-

erly.

(Ways of coping:



P.415)

Situation

Correction proce-

dure

The engine switch
<power switch> was
turned to ACC
while the driver’s
door was open (or
the driver’s door
was opened while
the engine switch
<power switch> was
in ACC).

Turn the engine
switch <power
switch> off and close
the driver’s door.

The engine switch
<power switch> was
turned off while the
driver’s door was
open.

Close the driver’s
door.

140

3-2. Opening, closing and locking the doors and trunk

●

When the electronic key battery is

depleted

●

Near a TV tower, electric power plant,

gas station, radio station, large display,

airport or other facility that generates

strong radio waves or electrical noise

●

When carrying a portable radio, cellular

phone, cordless phone or other wireless

communication device

●

When the electronic key is in contact

with, or is covered by the following metal-

lic objects

• Cards to which aluminum foil is attached

• Cigarette boxes that have aluminum foil

inside

• Metallic wallets or bags

• Coins

• Hand warmers made of metal

• Media such as CDs and DVDs

●

When other wireless keys (that emit

radio waves) are being used nearby

●

When carrying the electronic key

together with the following devices that

emit radio waves

• Another electronic key or a wireless key

that emits radio waves

• Personal computers or personal digital

assistants (PDAs)

• Digital audio players

• Portable game systems

●

If window tint with a metallic content or

metallic objects are attached to the rear

window

●

When the electronic key is placed near a

battery charger or electronic devices

●

When the vehicle is parked in a pay park-

ing spot where radio waves are emitted

■

Note for the entry function

●

Even when the electronic key is within the

effective range (detection areas), the sys-

tem may not operate properly in the fol-

lowing cases:

• The electronic key is too close to the win-

dow or outside door handle, near the

ground, or in a high place when the doors

are locked or unlocked.

• The electronic key is near the ground or

in a high place, or too close to the rear

bumper center when the trunk is opened.

• The electronic key is on the instrument

panel, rear package tray or floor, or in the

door pockets or glove box when the

engine <hybrid system> is started or

engine switch <power switch> modes are

changed.

●

Do not leave the electronic key on top of

the instrument panel or near the door

pockets when exiting the vehicle.

Depending on the radio wave reception

conditions, it may be detected by the

antenna outside the cabin and the doors

will become lockable from the outside,

possibly trapping the electronic key

inside the vehicle.

●

As long as the electronic key is within the

effective range, the doors may be locked

or unlocked by anyone. However, only

the doors detecting the electronic key

can be used to unlock the vehicle.

●

Even if the electronic key is not inside the

vehicle, it may be possible to start the

engine <hybrid system> if the electronic

key is near the window.

●

The doors may unlock or lock if a large

amount of water splashes on the door

handle, such as in the rain or in a car

wash, when the electronic key is within

the effective range. (The doors will auto-

matically be locked after approximately

60 seconds if the doors are not opened

and closed.)

●

If the wireless remote control is used to

lock the doors when the electronic key is

near the vehicle, there is a possibility that

the door may not be unlocked by the

entry function. (Use the wireless remote

control to unlock the doors.)

●

When the lock operation is performed

using the lock sensor, recognition signals

will be shown up to two consecutive

times. After this, no recognition signals

will be given.

●

If the door handle becomes wet while the

electronic key is within the effective

range, the door may lock and unlock

repeatedly. In this case, follow the follow-

ing correction procedures to wash the

vehicle:

• Place the electronic key in a location 6 ft.

(2 m) or more away from the vehicle.

(Take care to ensure that the key is not

141

3-2. Opening, closing and locking the doors and trunk

fore
dri
ving

stolen.)

• Set the electronic key to battery-saving

mode to disable the smart access system

with push-button start. (



P.139)

●

If the electronic key is inside the vehicle

and a door handle becomes wet during a

car wash, a message may be shown on

the multi-information display and a

buzzer will sound outside the vehicle. To

turn off the alarm, lock both side doors.

●

If an outside door handle is not retracted

during a car wash, a door may be opened

or an outside door handle may be dam-

aged. Make sure that the outside door

handles are retracted before using the

car wash.

●

A sudden handle operation or a handle

operation immediately after entering the

effective range may prevent the doors

from being unlocked. Touch the door

unlock sensor and check that the doors

are unlocked before pulling the door

handle again.

●

Unlocking the vehicle may take more

time if another electronic key is within the

effective range.

■

When the vehicle is not driven for

extended periods

●

To prevent theft of the vehicle, do not

leave the electronic key within 6 ft. (2 m)

of the vehicle.

●

The smart access system with push-but-

ton start can be deactivated in advance.

●

Setting the electronic key to battery-sav-

ing mode helps to reduce key battery

depletion. (



P.139)

■

To operate the system properly

●

Make sure to carry the electronic key

when operating the system. Do not get

the electronic key too close to the vehicle

when operating the system from the out-

side of the vehicle.

Depending on the position and holding

condition of the electronic key, the key

may not be detected correctly and the

system may not operate properly. (The

alarm may go off accidentally, or the door

lock prevention function may not oper-

ate.)

●

Do not leave the electronic key inside the

trunk.

The key confinement prevention function

may not operate, depending on the loca-

tion of the key (the inside edge of the

trunk), conditions (inside a metal bag,

close to metallic objects) and the radio

waves in the surrounding area. (



P.136)

■

If an electronic key does not work prop-

erly

●

If the doors cannot be locked or

unlocked and the trunk cannot be

opened, perform the following.

• Bring the electronic key close to the door

handle and perform a lock or unlock

operation.

• Bring the electronic key close to the but-

ton on the trunk (



P.135) and press the

button.

• Use the wireless remote control.
If the doors cannot be locked or unlocked
by perform the above, use the mechanical
key. (



P.415)

Convertible for Canada: However, if the
mechanical key is used while the alarm sys-
tem is set, the warning will sound.

●

If the engine <hybrid system> cannot be

started, refer to P.416

■

Customization

Settings (e. g. smart access system with

push-button start) can be changed.

(Customizable features:



P.459)

If the smart access system with push-button

start has been deactivated in a customized

setting, refer to the explanations for the fol-

lowing operations.

●

Locking and unlocking the doors and

opening the trunk:

Use the wireless remote control or

mechanical key. (



P.130, 136, 415)

●

Starting the engine <hybrid system> and

changing engine switch <power switch>

modes:



P.416

●

Stopping the engine <hybrid system>:



P.181, 186

142

3-2. Opening, closing and locking the doors and trunk

WARNING

■

Caution regarding interference with

electronic devices

●

People with implantable cardiac pace-

makers, cardiac resynchronization

therapy-pacemakers or implantable

cardioverter defibrillators should keep

away from the smart access system

with push-button start antennas.

(



P.137)

The radio waves may affect the opera-

tion of such devices. If necessary, the

entry function can be disabled. Ask

your Lexus dealer for details, such as

the frequency of radio waves and tim-

ing of the emitted radio waves. Then,

consult your doctor to see if you

should disable the entry function.

●

User of any electrical medical device

other than implantable cardiac pace-

makers, cardiac resynchronization

therapy-pacemakers or implantable

cardioverter defibrillators should con-

sult the manufacturer of the device for

information about its operation under

the influence of radio waves.

Radio waves could have unexpected

effects on the operation of such medi-

cal devices.

Ask your Lexus dealer for details on dis-

abling the entry function.

143

3-3. Adjusting the seats

fore
dri
ving

3-3.Adjusting the seats

Seat position adjustment

Seatback angle adjustment

Head restraint height adjustment (if
equipped) (



P.149)

Seat cushion (front) angle adjust-
ment

Vertical height adjustment

Lumbar support adjustment

■

When adjusting the seat

●

Make sure that any surrounding passen-

gers or objects are not contact the seat.

●

Take care when adjusting the seat so that

the head restraint does not touch the ceil-

ing.

●

Vehicles with power head restraint:

Depending on the position of the front

seat, the front head restraint may not be

able to be adjusted upward if it is close to

the ceiling.

■

Seat-linked function

●

This function operates when the seat is

moved forward, backward or in the

reclining direction a certain distance or

more.

●

Vehicles with power head restraint:

When the seat is adjusted forward a cer-

tain distance or more, the head restraint

moves down.

●

Vehicles with power head restraint:

When the seat is raised a certain distance

or more, the seat stops and the head

restraint moves down.

■

Power easy access system

The driver’s seat and steering wheel move

in accordance with engine switch <power

switch> mode and the driver’s seat belt con-

dition. (



P.145)

Front seats

The seats can be adjusted (longitu-
dinally, vertically, etc.). Adjust the
seat to ensure the correct driving
posture.

Adjustment procedure

A
B
C

E
F

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat

position to ensure that other passen-

gers are not injured by the moving

seat.

●

Do not put your hands under the seat

or near the moving parts to avoid

injury.

Fingers or hands may become

jammed in the seat mechanism.

●

Make sure to leave enough space

around the feet so they do not get

stuck.

144

3-3. Adjusting the seats

■

Before entering/exiting the rear
seats



Remove the seat belt from the seat
belt guide. (



P.33)



Stow the sun visor.

■

Entering/exiting the rear seat

Pull the lever.

The front seat will lower automatically.

Fold the seatback completely for-
ward.

The front seat will move forward and the
head restraint will move downward

auto-

matically.

: Power type only

■

Returning the front seat to its origi-
nal position

Move the seatback backward until it
locks. The front seat will return to its
original position automatically.

■

Lever-operated “Front, Fold & Return”

seat

●

After the front seat is moved forward by

operating the “Front, Fold & Return” seat

lever, if a power seat adjusting switch or a

driving position memory switch is

pressed, the front seat will not return to its

original position even if the front seat-

back is moved backward until it locks.

●

The lever-operated “Front, Fold &

Return” seat will not operate in the fol-

lowing situations:

• The seat belt of the seat to be operated is

fastened.

• The engine switch <power switch> is in

ON and the shift position is in a position

other than P.

●

Operation of the lever-operated “Front,

Fold & Return” seat will stop in the follow-

ing situations:

• A power seat adjusting switch or a driv-

ing position memory switch is pressed.

• The seat belt of the seat which is operat-

ing is fastened.

• The engine switch <power switch> is in

ON and the shift position is changed to a

position other than P.

●

If the front seat is close to the sun visor or

other surrounding parts, frontwards and

WARNING

■

Seat adjustment

To reduce the risk of sliding under the lap

belt during a collision, do not recline the

seat more than necessary.

If the seat is too reclined, the lap belt may

slide past the hips and apply restraint

forces directly to the abdomen, or your

neck may contact the shoulder belt,

increasing the risk of death or serious

injury in the event of an accident.

Adjustments should not be made while

driving as the seat may unexpectedly

move and cause the driver to lose con-

trol of the vehicle.

Entering/exiting the rear seats
(lever-operated “Front, Fold &
Return” seat)

145

3-3. Adjusting the seats

fore
dri
ving

upwards movement may be restricted.

■

Jam protection function

While the driving position is recalling or the

power easy access system is operating, if an

object is stuck behind the front seat, the

front seat will stop and then move slightly

forward.
While the lever-operated “Front, Fold &

Return” seat is operating, if an object is

stuck either in front of or behind the front

seat, the front seat will stop and then move

in the opposite direction slightly.
When the jam protection function operates,

the seat stops at a position other than the

set seat position. Check the seat position.

The seat and steering wheel are auto-
matically adjusted to allow the driver to
enter and exit the vehicle easily.
When all of the following have been
performed, the seat and steering wheel
are automatically adjusted to a position
that allows the driver to enter and exit
the vehicle easily.



The shift position has been shifted to
P.



The engine switch <power switch>
has been turned off.



The driver’s seat belt has been
unfastened.

WARNING

■

Lever-operated “Front, Fold &

Return” seat

●

Before operating the lever-operated

“Front, Fold & Return” seat, ensure

that any surrounding passengers or

objects will not contact the seat.

●

Make sure the seatback is locked

securely before driving.

●

Never operate the lever-operated

“Front, Fold & Return” seat while the

vehicle is moving.

■

Jam protection function

Do not use a hand, foot, or any other part

of your body to intentionally activate the

jam protection function.

Driving position memory

This feature automatically adjusts
the positions of the driver’s seat,
steering wheel, outside rear view
mirrors and head-up display (if
equipped) to make entering and
exiting the vehicle easier or to suit
your preferences.
Up to 3 different driving positions
can be recorded.
Each electronic key (including a
card key) can be registered to
recall your preferred driving posi-
tion.

Power easy access system

146

3-3. Adjusting the seats

When any of the following has been
performed, the driver’s seat and steer-
ing wheel automatically return to their
original positions.



The engine switch <power switch>
has been turned to ACC or ON.



The driver’s seat belt has been fas-
tened.

■

Operation of the power easy access

system

●

When exiting the vehicle, the power easy

access system may not operate if the seat

is already close to the rearmost position,

etc.

●

If the seat or power head restraint (if

equipped) position is adjusted during the

power easy access system operation, the

automatic operating will stop. (The seat

will change to manual operation.)

●

If the seat or power head restraint (if

equipped) position is adjusted during or

after the power easy access system oper-

ation when the driver is exiting the vehi-

cle, the power easy access system will not

operate when entering the vehicle.

●

Vehicles with power head restraint: If the

head restraint is close to the ceiling when

the driver is exiting the vehicle, the head

restraint may move down during the

power easy access system operation.

Also, the head restraint may be restricted

from being adjusted upward after the

power easy access system operates.

When the driver is entering the vehicle,

the head restraint returns to its original

position.

■

Customization

The seat movement amount settings of the

power easy access system can be custom-

ized.

(Customizable features:



P.459)

Turn the engine switch <power
switch> to ON.

Check that the shift position is in P.

Adjust the driver’s seat, steering
wheel, outside rear view mirrors
and head-up display to the desired
positions.

While pressing the “SET” button, or
within 3 seconds after the “SET”
button is pressed, press button “1”,
“2” or “3” until the buzzer sounds.

If the selected button has already been

preset, the previously recorded position

will be overwritten.

■

Seat positions that can be memorized

(



P.143)

The adjusted positions other than the posi-

tion adjusted by lumbar support switch can

be recorded.

■

In order to correctly use the driving

position memory function

If a seat position is already in the furthest

possible position and the seat is operated in

the same direction, the recorded position

Recording a driving position into
memory

147

3-3. Adjusting the seats

fore
dri
ving

may be slightly different when it is recalled.

Turn the engine switch <power
switch> to ON.

Check that the shift position is in P.

Press one of the buttons for the
driving position you want to recall
until the buzzer sounds.

■

To stop the position recall operation

part-way through

Perform any of the following:

●

Press the “SET” button.

●

Press button “1”, “2” or “3”.

●

Operate any of the seat adjustment

switches (only cancels seat position

recall).

●

Operate the tilt and telescopic steering

control switch (only cancels steering

wheel position recall).

●

Operate the head-up display position

adjustment switch (if equipped) (only

cancels head-up display position recall).

■

Operating the driving position memory

after turning the engine switch <power

switch> off

Recorded seat positions can be activated

up to 180 seconds after the driver’s door is

opened and another 60 seconds after it is

closed again.

■

When the recorded seat position can-

not be recalled

The seat position may not be recalled in

some situations when the seat position is

recorded in a certain range. For details,

contact your Lexus dealer.

■

Registering procedure

Record your driving position to button
“1”, “2” or “3” before performing the
following:
Carry only the key you want to regis-
ter, and then close the driver’s door.
If 2 or more keys are in the vehicle, the
driving position cannot be recorded
properly.

Turn the engine switch <power
switch> to ON.

Check that the shift position is in P.

Recall the driving position that you
want to record.

While pressing the recalled button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds.

If the button could not be registered, the

buzzer sounds continuously for approxi-

WARNING

■

Seat adjustment caution

Take care during seat adjustment so that

the seat does not strike the rear passen-

ger or squeeze your body against the

steering wheel.

Recalling a driving position

Registering/canceling/recall a
driving position to an electronic
key (including a card key) (mem-
ory recall function)

148

3-3. Adjusting the seats

mately 3 seconds.

■

Cancelation procedure

Carry only the key you want to can-
cel and then close the driver’s door.

If 2 or more keys are in the vehicle, the

driving position cannot be canceled prop-

erly.

Turn the engine switch <power
switch> to ON.

Check that the shift position is in P.

While pressing the “SET” button,
press and hold the door lock switch
(either lock or unlock) until the
buzzer sounds twice.

If the button could not be canceled, the

buzzer sounds continuously for approxi-

mately 3 seconds.

■

Recall procedure

Make sure that the doors are
locked before recalling the driving
position. Carry the electronic key
that has been registered to the driv-
ing position, and then unlock and
open the driver’s door using the
smart access system with push-but-
ton start or wireless remote control.

The driving position will move to the

recorded position (not including the steer-

ing wheel and head-up display).
If the driving position is in a position that

has already been recorded, the seat and

outside rear view mirrors will not move.

Turn the engine switch <power
switch> to ACC or ON, or fasten a
seat belt.

The steering wheel and head-up display

will move to the recorded position.

■

Recalling the driving position using the

memory recall function

●

Different driving positions can be regis-

tered for each electronic key. Therefore,

the driving position that is recalled may

be different depending on the key being

carried.

●

If the passenger’s door is unlocked with

the smart access system with push-but-

ton start, the driving position cannot be

recalled. In this case, press the driving

position button which has been set.

■

Customization

The unlock door settings of the memory

recall function can be changed.

(Customizable features:



P.459)

149

3-3. Adjusting the seats

fore
dri
ving



Manual type

Pull the head restraints up.

Down

Push the head restraint down while press-
ing the lock release button



Power type

Down

■

About the head restraints (power type)

Depending on the position of the front seat,

the front head restraint may not be able to

be adjusted upward if it is close to the ceil-

ing.

■

Adjusting the height of the head

restraints

Make sure that the head restraints are

adjusted so that the center of the head

restraint is closest to the top of your ears.

Pull the head restraint up while press-
ing the lock release button

If the head restraint touches the ceiling,
making the removal difficult, change
the seat height or angle. (



P.143)

Head restraints

Head restraints are provided for
front seats.
Convertible: For removing and
installation of the head restraint,
contact your Lexus dealer.

WARNING

■

Head restraint precautions

Observe the following precautions

regarding the head restraints. Failure to

do so may result in death or serious

injury.

●

Adjust the head restraints to the cor-

rect position at all times.

●

Manual type: After adjusting the head

restraints, push down on them and

make sure they are locked in position.

●

Manual type: Do not drive with the

head restraints removed.

Vertical adjustment

Removing the head restraints
(manual type head restraint
except for Convertible)

151

3-4. Adjusting the steering wheel and mirrors

fore
dri
ving

3-4.Adjusting the steering wheel and mirrors

Operating the switch moves the steer-
ing wheel in the following directions:

Down

Toward the driver

Away from the driver

■

The steering wheel can be adjusted

when

The engine switch <power switch> is in

ACC or ON.

■

Automatic adjustment of the steering

position

A desired steering position can be entered

to memory and recalled automatically by

the driving position memory system.

(



P.145)

■

Power easy access system

The steering wheel and driver’s seat move

in accordance with power switch mode and

the driver’s seat belt condition. (



P.145)

Press on or close to the

mark.

Steering wheel

Adjustment procedure

WARNING

■

Caution while driving

Do not adjust the steering wheel while

driving.

Doing so may cause the driver to mis-

handle the vehicle and cause an acci-

dent, resulting in death or serious injury.

Sounding the horn

152

3-4. Adjusting the steering wheel and mirrors

The height of the rear view mirror can
be adjusted to suit your driving pos-
ture.
Adjust the height of the rear view mir-
ror by moving it up and down.

Responding to the level of brightness
of the headlights of vehicles behind, the
reflected light is automatically
reduced.
Turn the automatic anti-glare function
mode on/off

When the automatic anti-glare function is
in ON mode, the indicator

illuminates.

The function will set to ON mode each
time the engine switch <power switch> is
turned to ON.
Pressing the button turns the function to
OFF mode. (The indicator

also turns

off.)

■

To prevent sensor error

To ensure that the sensors operate prop-

erly, do not touch or cover them.

Inside rear view mirror

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

Adjusting the height of rear view
mirror

WARNING

■

Caution while driving

Do not adjust the position of the mirror

while driving.

Doing so may lead to mishandling of the

vehicle and cause an accident, resulting

in death or serious injury.

Anti-glare function

153

3-4. Adjusting the steering wheel and mirrors

fore
dri
ving

■

When using the outside rear view mir-

rors in a cold weather

When it is cold and the outside rear view

mirrors are frozen, it may not be possible to

fold/extend them or adjust the mirror sur-

face. Remove the ice, snow, etc. covering

the outside rear view mirrors.

To select a mirror to adjust, press
the switch.

The indicator comes on.

Left

Right

Pressing the same switch again will put the
switch in neutral.

To adjust the mirror, press the
switch.

Right

Down

Left

■

Mirror angle can be adjusted when

The engine switch <power switch> is in

ACC or ON.

■

Defogging the mirrors

The outside rear view mirrors can be

cleared using the mirror defoggers. Turn on

the rear window defogger to turn on the

outside rear view mirror defoggers.

(



P.293)

■

Auto anti-glare function

When the anti-glare inside rear view mirror

is set to automatic mode, the outside rear

view mirrors will activate in conjunction

with the anti-glare inside rear view mirror to

reduce reflected light. (



P.152)

■

Automatic adjustment of the mirror

angle

A desired mirror face angle can be entered

to memory and recalled automatically by

the driving position memory. (



P.145)

Outside rear view mirrors

The rear view mirror’s position can
be adjusted to enable sufficient
confirmation of the rear view.

WARNING

■

Important points while driving

Observe the following precautions while

driving.

Failure to do so may result in loss of con-

trol of the vehicle and cause an accident,

resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side

mirrors must be extended and prop-

erly adjusted before driving.

Adjustment procedure

A
B

A
B
C
D

154

3-4. Adjusting the steering wheel and mirrors

■

Using the switch

Press the switch to fold the mirrors.

Press it again to extend them to the original
position.

■

Setting automatic mode

Automatic mode allows the folding or
extending of the mirrors to be linked to
locking/unlocking of the doors.
Press the “AUTO” switch to set auto-
matic mode.

The indicator

will come on.

Pressing the switch once more will return
to manual mode.

■

When disconnecting and reconnecting

12-volt battery terminals

The automatic folding/extending mirror

function will return to off as default. To turn

the function on, press the switch again to

select on.

■

Customization

The automatic mirror folding and extending

operation can be changed.

(Customizable features:



P.459)

When either “L” or “R” of the mirror
select switch is selected, the outside
rear view mirrors will automatically
angle downwards when the vehicle is
reversing in order to give a better view
of the ground.
To disable this function, select neither
“L” nor “R”.

■

Adjusting the mirror angle when
the vehicle is reversing

With the shift position in R, adjust the
mirror angle at a desired position.

WARNING

■

When the outside rear view mirror

defoggers are operating

Do not touch the outside rear view mir-

ror surfaces, as they can become very

hot and burn you.

Folding and extending the mir-
rors

WARNING

■

When a mirror is moving

To avoid personal injury and mirror mal-

function, be careful not to get your hand

caught by the moving mirror.

Linked mirror function when
reversing

Lexus LC500C (2024 year). Manual in english - page 4
