Lexus RZ450E (2023 year). Manual in english

595

10-2. Customizable features

Vehi

cle

spec

ifi

tions

: This setting changes in accordance with My Settings

Steering in custom mode

Normal

Sport

—

Air conditioning operation in

customized mode

Normal

Eco

—

Range

Automatic air conditioning system

Function

Default setting

Customized setting

Automatic switching between

outside air mode and recircu-

lated air mode when the

AUTO switch is on (AUTO

switch linked air mode chang-

ing)

Off

Automatic turning on of the

A/C switch when the AUTO

switch is turned on (AUTO

switch linked A/C switch)

Off

Steering wheel heater tem-

perature adjustment in AUTO

mode

Standard

-2 (cooler) to 2

(warmer)

Driver's seat seat heater/venti-

lator temperature adjustment

in AUTO mode

Standard

-2 (cooler) to 2

(warmer)

Front passenger's seat seat

heater/ventilator temperature

adjustment in AUTO mode

Standard

-2 (cooler) to 2

(warmer)

Illumination

Function

Default setting

Customized setting

Time elapsed before the lights

turn off

15 seconds

Off

7.5 seconds

30 seconds

Function

Default setting

Customized setting

596

10-2. Customizable features

: This setting changes in accordance with My Settings

: If equipped

Operation after the power

switch is turned off

Off

—

Operation when you approach

the vehicle with the electronic

key on your person

Off

—

Operation when the doors are

unlocked

Off

—

Footwell lights

Off

—

Door-trim ornament lights,

inside handle lights and center

auxiliary box lights

Off

—

Time elapsed before the outer

foot lights turn off

15 seconds

Off

7.5 seconds

30 seconds

Operation of the outer foot

lights when you approach the

vehicle with the electronic key

on your person

Off

—

Operation of the outer foot

lights when the doors are

unlocked

Off

—

Operation of the outer foot

lights when a door is opened

Off

—

Fading out of the outer foot

lights when they turn off

Long

Short

—

Operation of interior lights and

outer foot lights after the doors

are locked

Off

—

Color selection

*1,2

Silky white

Custom

—

Brightness control

*1,2

Maximum

Desired brightness

—

Function

Default setting

Customized setting

597

10-2. Customizable features

Vehi

cle

spec

ifi

tions

Charging system

Function

Default setting

Customized setting

Charging current

Max

16A

—

Charging limit

Full

90%

—

80%

70%

60%

50%

DC charging power

Max

125 kW

—

100 kW

75 kW

50 kW

Connector lock

Auto Lock

Off

—

Auto Lock & Unlock

Battery cooler

Off

—

Power switch

Function

Customized setting

ACC customization

Enabling/Disabling ACC mode

On/Off

—

598

10-3. Initialization

10-3.Initialization

Items to initialize

Must be initialized for normal sys-
tem operation after such cases as
the 12-volt battery being recon-
nected, or maintenance being per-
formed on the vehicle:

Item

When to ini-

tialize

Reference

Power back

door (if

equipped)



After
recon-
necting or
changing
the 12-volt
battery

P.103

Lexus park-

ing

assist-moni-

tor (if

equipped)



After
recon-
necting or
changing
the 12-volt
battery

Refer to

“MULTIME-

DIA

OWNER’S

MANUAL”.

Panoramic
view moni-

tor (if

equipped)



After
recon-
necting or
changing
the 12-volt
battery

Refer to

“MULTIME-

DIA

OWNER’S

MANUAL”.

Tire pressure

warning sys-

tem



When the
specified
tire infla-
tion pres-
sure has
changed,
such as
due to car-
ried load,
etc.



When the
tire infla-
tion pres-
sure is
changed
such as
when the
tire size is
changed.

P.446

Item

When to ini-

tialize

Reference

599

For owners

11-1. For owners

Reporting safety defects for U.S.

owners ........................................

600

Reporting safety defects for

Canadian owners...................

600

Seat belt instructions for Cana-

dian owners (in French)........

601

SRS airbag instructions for Cana-

dian owners (in French).......

602

Headlight aim instructions for

Canadian owners (in French)
........................................................

607

600

11-1. For owners

11-1.For owners

Reporting safety defects for
U.S. owners

If you believe that your vehicle has a
defect which could cause a crash or
could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in addition
to notifying the Lexus Division of
Toyota Motor Sales, U.S.A., Inc.
(Toll-free: 1-800-25-LEXUS).

If NHTSA receives similar com-
plaints, it may open an investigation,
and if it finds that a safety defect
exists in a group of vehicles, it may
order a recall and remedy campaign.
However, NHTSA cannot become
involved in individual problems
between you, your dealer, or Lexus
Division of Toyota Motor Sales,
U.S.A., Inc.

To contact NHTSA, you may call the
Vehicle Safety Hotline toll-free at
1-888-327-4236 (TTY:
1-800-424-9153); go to

http://www.safercar.gov

; or write to:

Administrator, NHTSA, 1200 New
Jersey Ave. SE., Washington, DC
20590. You can also obtain other
information about motor vehicle
safety from

http://www.safercar.gov

Reporting safety defects for
Canadian owners

Canadian customers who wish to
report a safety-related defect to
Transport Canada, Defects Investi-
gations and Recalls, may telephone
the toll-free hotline
1-800-333-0510, mail Transport
Canada - ASFAD, 330 Sparks
Street, Ottawa, ON, K1A 0N5, or
complete the online form at
https://www.tc.gc.ca/recalls.

601

11-1. For owners

For
owners

See the seat belt section for more
detailed seat belt instructions in
English.



Déroulez la sangle diagonale de
telle sorte qu'elle passe bien sur
l'épaule, sans pour autant être en
contact avec le cou ou glisser de
l'épaule.



Placez la sangle abdominale le plus
bas possible sur les hanches.



Réglez la position du dossier de
siège. Asseyez-vous le dos droit et
calez-vous bien dans le siège.



Ne vrillez pas la ceinture de sécu-
rité.

Nettoyez avec un chiffon ou une
éponge humidifiés avec de l'eau savon-
neuse tiède. Vérifiez régulièrement
que les ceintures ne sont pas usées,
effilochées ou entaillées excessive-
ment.

Seat belt instructions for
Canadian owners (in French)

The following is a French explana-
tion of seat belt instructions
extracted from the seat belt section
in this manual.

Utilisation des ceintures de
sécurité

AVERTISSEMENT

Inspectez le système de ceintures de

sécurité régulièrement. Contrôlez

l'absence de coupures, d'effilochages et

de pièces desserrées. N'utilisez pas une

ceinture de sécurité endommagée avant

qu'elle ne soit remplacée. Une ceinture

de sécurité endommagée ne permet pas

de protéger un occupant de blessures

graves ou mortelles.

Traitement des ceintures de
sécurité

602

11-1. For owners

See the SRS airbag section for more detailed SRS airbag instructions in English.

Coussin gonflable conducteur/coussin gonflable du passager avant SRS

Contribuent à réduire l’impact au niveau de la tête et du thorax du conducteur et du pas-
sager avant

Coussins gonflables de genoux SRS

Permettent de réduire le choc pour le conducteur et le passager avant

Coussins gonflables latéraux SRS

Contribuent à réduire l’impact au niveau du thorax des occupants des sièges avant

Coussins gonflables rideaux SRS

• Contribuent à réduire l’impact au niveau de la tête des occupants des sièges avant et des

sièges arrière latéraux

• Peut contribuer à empêcher les occupants d’être éjectés du véhicule en cas de tonneau

Votre véhicule est équipé de COUSS-
INS GONFLABLES INTELLIGENTS
conçus selon les normes de sécurité

américaines applicables aux véhicules
à moteur (FMVSS208). L'ensemble
des capteurs de coussins gonflables

SRS airbag instructions for Canadian owners (in French)

The following is a French explanation of SRS airbag instructions extracted
from the SRS airbag section in this manual.

Coussins gonflables SRS

603

11-1. For owners

For
owners

(ECU) régule le déploiement des
coussins gonflables sur la base des
informations qu'il reçoit des capteurs,
etc., indiqués ci-dessus dans le schéma
illustrant les composants du système.
Parmi ces informations figurent la grav-
ité du choc et l'occupation du véhicule
par les passagers. Le déploiement
rapide des coussins gonflables est
obtenu au moyen d'une réaction
chimique dans les dispositifs pyrotech-
niques, qui produit un gaz inoffensif
permettant d'amortir le mouvement
des occupants.

AVERTISSEMENT

■

Précautions relatives aux coussins

gonflables SRS

Respectez les précautions suivantes. Le

non-respect de ces précautions peut

occasionner des blessures graves, voire

mortelles.

●

Le conducteur et tous les passagers

doivent porter correctement leur cein-

ture de sécurité.

Les coussins gonflables SRS sont des dis-
positifs supplémentaires à utiliser avec
les ceintures de sécurité.

●

Le coussin gonflable conducteur SRS

se déploie avec une force con-

sidérable et peut occasionner des

blessures graves, voire mortelles, tout

particulièrement si le conducteur se

trouve très près du coussin gonflable.

L'autorité fédérale chargée de la sécu-

rité routière aux États-Unis (NHTSA)

conseille:

La zone à risque du coussin gonflable
conducteur se situant dans les premiers
2 à 3 in. (50 à 75 mm) de déploiement,
vous placer à 10 in. (250 mm) de votre
coussin gonflable conducteur vous
garantit une marge de sécurité suffisante.
Cette distance est à mesurer entre le
centre du volant et le sternum. Si votre
position de conduite actuelle vous place
à moins de 10 in. (250 mm) du coussin
gonflable conducteur, vous pouvez
changer votre position de conduite de
plusieurs façons:
• Reculez votre siège le plus possible, de

manière à pouvoir encore atteindre

confortablement les pédales.

• Inclinez légèrement le dossier de

siège. Bien que les véhicules aient une

conception différente, un grand nom-

bre de conducteurs peuvent s'asseoir

à une distance de 10 in. (251 mm),

même avec le siège conducteur com-

plètement avancé, simplement en

inclinant un peu le dossier de siège. Si

vous avez des difficultés à voir la route

après avoir incliné le dossier de votre

siège, utilisez un coussin ferme et

antidérapant pour vous rehausser ou

remontez le siège si votre véhicule est

équipé de cette fonction.

604

11-1. For owners

AVERTISSEMENT

• Si votre volant est réglable, inclinez-le

vers le bas. Cela a pour effet d'orienter

le coussin gonflable en direction de

votre poitrine plutôt que de votre tête

et de votre cou. Réglez votre siège

selon les recommandations de la

NHTSA, tout en conservant le con-

trôle du véhicule avec les pédales et le

volant, et en préservant la vue des

commandes du tableau de bord.

●

Si vous attachez une rallonge de cein-

ture de sécurité à une boucle de cein-

ture de sécurité de siège avant sans

l'attacher au pêne de la ceinture de

sécurité, le système de coussins gon-

flables SRS détermine que l’occupant

a attaché sa ceinture de sécurité, bien

que la ceinture de sécurité ne soit pas

bouclée. Dans ce cas, les coussins

gonflables frontaux SRS peuvent ne

pas se déployer correctement lors

d’une collision, ce qui peut occasion-

ner des blessures graves, voire mor-

telles. Veillez à porter la ceinture de

sécurité correctement en cas d’utilisa-

tion d’une rallonge de ceinture de

sécurité.

●

Le coussin gonflable frontal SRS se

déploie avec une force considérable et

peut occasionner des blessures

graves, voire mortelles, tout particu-

lièrement si le passager avant se

trouve très près du coussin gonflable.

Le siège du passager avant doit être

éloigné le plus possible du coussin

gonflable, avec le dossier réglé de

façon à ce que le passager avant soit

assis bien droit dans le siège.

●

Les nourrissons et les enfants qui ne

sont pas correctement assis et/ou

attachés peuvent être grièvement

blessés ou tués par le déploiement

d'un coussin gonflable. Un nourrisson

ou un enfant trop petit pour utiliser une

ceinture de sécurité doit être cor-

rectement attaché au moyen d'un

siège de sécurité enfant. Lexus recom-

mande vivement d'installer tous les

nourrissons et enfants sur les sièges

arrière du véhicule et de prévoir pour

eux des systèmes de retenue adaptés.

Les sièges arrière sont plus sûrs pour

les nourrissons et les enfants que le

siège du passager avant.

●

Ne vous asseyez pas sur le bord du

siège et ne vous appuyez pas contre la

planche de bord.

●

Ne laissez pas un enfant rester debout

devant le coussin gonflable passager

avant SRS ou s'asseoir sur les genoux

du passager avant.

●

Les occupants des sièges avant ne

doivent en aucun cas tenir d'objets sur

leurs genoux.

605

11-1. For owners

For
owners

AVERTISSEMENT

●

Ne vous appuyez pas contre la porte,

le rail latéral de toit ou les montants

avant, latéraux ou arrière.

●

Ne laissez personne s'agenouiller sur

un siège en appui contre la porte ou

sortir la tête ou les mains à l'extérieur

du véhicule.

●

Ne fixez rien et ne posez rien sur des

emplacements tels que la planche de

bord, la garniture du volant et la partie

inférieure du tableau de bord.

●

Ne fixez rien à des emplacements tels

que les portes, la vitre du pare-brise,

les vitres latérales, les montants avant

ou arrière, des rails latéraux de toit et

des poignées de maintien. (À l'excep-

tion de l'étiquette de limitation de

vitesse



P.512)

●

Ne suspendez aucun cintre ou objet

dur aux crochets à vêtements. Ces

éléments peuvent se transformer en

projectiles si les coussins gonflables

rideaux SRS se déploient, le choc pou-

vant entraîner des blessures graves,

voire mortelles.

●

Si un cache en vinyle est fixé sur la

zone où le coussin gonflable de

genoux SRS se déploie, assurez-vous

de le retirer.

●

N'utilisez aucun accessoire de siège

recouvrant les zones de déploiement

des coussins gonflables SRS, car il ris-

que de gêner le déploiement des

coussins gonflables SRS. De tels

accessoires peuvent empêcher les

coussins gonflables SRS de se

déployer correctement, peuvent dés-

activer le système ou entraîner le

déploiement involontaire des coussins

gonflables SRS, ce qui peut éventuel-

lement occasionner des blessures

graves, voire mortelles.

●

Évitez de faire subir des chocs ou des

pressions excessives aux composants

des systèmes de coussins gonflables

SRS, aux portes avant ou à leur zone

adjacente. En effet, cela pourrait

entraîner un dysfonctionnement des

coussins gonflables SRS.

606

11-1. For owners

AVERTISSEMENT

●

Ne touchez aucun composant des

coussins gonflables SRS immédiate-

ment après leur déploiement (gon-

flage), car ils peuvent être chauds.

●

Si vous avez des difficultés à respirer

après le déploiement des coussins

gonflables SRS, ouvrez une porte ou

une vitre pour faire entrer de l'air frais,

ou bien descendez du véhicule si cela

ne présente pas de danger. Essuyez

tout résidu dès que possible afin

d'éviter d'éventuelles irritations de la

peau.

●

Si une zone renfermant un coussin

gonflable SRS est endommagée ou

craquelée, faites-la remplacer par

votre concessionnaire Lexus.

●

Ne placez rien sur le siège du pas-

sager avant, comme un coussin par

exemple. Cela a pour conséquence de

répartir le poids du passager sur toute

la surface du siège, ce qui empêche le

capteur de détecter correctement le

poids du passager. En conséquence,

les coussins gonflables frontaux SRS

du siège du passager avant risquent de

ne pas se déployer en cas de collision.

■

Modification et mise au rebut des

composants du système de coussins

gonflables SRS

Ne mettez pas votre véhicule au rebut et

ne procédez à aucune des modifications

suivantes sans consulter votre conces-

sionnaire Lexus.

Les coussins gonflables SRS peuvent ne

pas fonctionner correctement ou se

déployer involontairement, ce qui peut

provoquer des blessures graves, voire

mortelles.

●

Dépose, repose, démontage ou répa-

ration des coussins gonflables SRS

●

Réparation, dépose ou modification

des pièces suivantes ou de leurs alen-

tours

• Volant

• Tableau de bord

• Planche de bord

• Sièges

• Garnissage des sièges

• Montants avant

• Montants latéraux

• Montants arrière

• Rails latéraux de toit

• Panneaux de portes avant

• Garniture de porte avant

• Haut-parleurs de porte avant

●

Modifications des panneaux de portes

avant (par exemple, perçage de trous

dans les panneaux)

●

Réparation ou modification des pièces

suivantes ou de leurs alentours

• Aile avant

• Pare-chocs avant

• Côtés de l'intérieur du véhicule

●

Installation des pièces suivantes ou

accessoires

• Pare-buffle ou pare-kangourou

• Chasse-neige

• Treuils

• Porte-bagages de toit

●

Modifications apportées à la suspen-

sion du véhicule

●

Installation d’appareils électroniques,

tels que des émetteurs/récepteurs

radios mobiles (émetteurs RF) et des

lecteurs CD

607

11-1. For owners

For
owners

Boulon de réglage A
Boulon de réglage B

Avant de vérifier le réglage des phares,
confirmez les points suivants.



La zone autour du phare n'est pas
déformée.



Le véhicule est stationné sur un sol
plat.



La pression de gonflage des pneus
est au niveau recommandé.



Une personne est assise sur le siège
conducteur.



Le véhicule a rebondi plusieurs fois

AVERTISSEMENT

●

Modifications apportées à votre

véhicule pour les personnes atteintes

d'un handicap physique

Headlight aim instructions
for Canadian owners (in
French)

The following is a French explana-
tion of headlight aim instructions
from the headlight aim section in
this manual.

Boulons de réglage du mouve-
ment vertical

Vérification du réglage des
phares

610

Supplement

1-1.Supplement

Supplement

A wide variety of non-genuine spare
parts and accessories for Lexus vehi-
cles are currently available in the mar-
ket. You should know that Toyota does
not warrant these products and is not
responsible for their performance,
repair, or replacement, or for any dam-
age they may cause to, or adverse
effect they may have on, your Lexus
vehicle.
This vehicle should not be modified
with non-genuine Lexus products.
Modification with non-genuine Lexus
products could affect its performance,
safety or durability, and may even vio-
late governmental regulations. In addi-
tion, damage or performance
problems resulting from the modifica-
tion may not be covered under war-
ranty.
Also, remodeling like this will have an
effect on advanced safety equipment
such as Lexus Safety System + 3 and
there is a danger that it will not work
properly or the danger that it may work
in situations where it should not be
working.

Installing electronic devices and radios
increases the risk of cyber attacks
through the installed parts, which may
lead to unexpected accidents and

leakage of personal information.
Lexus does not make any guarantees
for problems caused by installing
non-genuine Lexus products.

This vehicle is equipped with sophisti-
cated computers that record certain
data regarding vehicle controls and
operations.

■

Data recorded by the computers

: The recorded data varies according to

the vehicle grade level and options with
which it is equipped.

Certain data, such as the following, is
recorded depending on the operation
timing and status of each function.



Basic vehicle behavior related data
(electric motor speed, accelera-
tor/brake pedal operation, vehicle
speed, etc.)



Operating state of the driving sup-
port systems (recorded during sys-
tem operation, includes basic
vehicle behavior related data)



Driving support system sensor data



Image data (images from the front,
rear, vehicle periphery, and driver
monitor cameras)

: The vehicle has multiple cameras. For

details on from which cameras images
are recorded, contact your Lexus
dealer.



Location information

Accessories, spare parts and
modification of your Lexus

Cyber Attack Risk

Vehicle data recording

611

Supplement

These computers do not record con-
versations, sounds, or images of the
inside of the vehicle.
Also, personal information which may
be used to identify the owner of the
vehicle (name, gender, age, etc.) is not
recorded.

■

Usage of recorded data and per-
sonal information by the Lexus
Safety System + 3

The operating state of each system,
data from each sensor, image data
(images from the front/rear cameras),
and position information is recorded by
the Lexus Safety System + 3 in the fol-
lowing situations. Toyota obtains this
information when the vehicle is
brought to the dealership or when sent
to the Toyota servers.



In certain collisions or collision-like
situations



When driving on roads with certain
traffic situations, such as congestion,
poor road surfaces, poor weather,
etc.



When driving on certain roads, such
as roads which were recently
opened or extended



After the EV system is started, for a
certain amount of time

To learn more about the vehicle data
collected, used and shared by Lexus,
please visit http://www.lexus.com/pri-
vacyvts/.

■

Data provision and use purpose by
third parties

Data recorded by the computers may
be used for collision analysis, malfunc-
tion diagnosis, automated driving,
advanced safety and map related tech-
nologies (technology, product devel-
opment, product improvement, etc.)
and products and services which use
data (maps used for automated driving
and advanced safety technologies,
driving condition analysis, analysis of
the driving environment, such as road
infrastructure, traffic condition com-
munication, etc. Herein referred to as
“individual services”.)
Also, this data may be used for cus-
tomer support related to a collision,
collision analysis or resolution.
In situations such as the following, Toy-
ota may disclose the recorded data to
a third party:



When the consent of the vehicle
owner (or the lessee if the vehicle is
leased) has been given



When officially requested by the
police, a court of law or a govern-
ment agency



When it is to be used by Toyota in a
lawsuit



When data is to be used research
purposes after processing so that
the data is not tied to a specific vehi-
cle or vehicle owner

In addition to the above, Toyota may

612

Supplement

disclose the data recorded by the
Lexus Safety System + 3 to a third
party in the following situations:



When separate consent of the vehi-
cle owner (or the lessee if the vehi-
cle is leased) has been given. This
includes situations when the user
subscribes to an individual service
which is provided by a second party
and uses vehicle recorded data,
where the provider has obtained the
user’s consent for providing data to
a third-party



When providing data to a company
involved in autonomous driving soft-
ware, etc. for the purpose of
research and development (tech-
nology, product development, prod-
uct improvement, etc.) of automated
driving, advanced safety and map
related technologies



When providing image data and
position information to a company
involved in map creation, etc. for the
purpose of research and develop-
ment map related technologies



When providing image data and
position information to a local gov-
ernment for the purpose of road
maintenance, etc.



When providing processed image
data and position information to
traffic condition communication
individual services



When providing image data from
near a fire, or other area that emer-

gency services are dispatched, to
the fire department of a local gov-
ernment which has entered a sepa-
rate contract with Lexus

Image information recorded by the vehicle

can be erased by your Lexus dealer.
The image recording function can be dis-

abled. However, if the function is disabled,

data from when systems operate will not be

available.
If you wish to stop the collection of Lexus

Safety System + 3 data by the Toyota serv-

ers for the purpose of research and devel-

opment and provision to individual services,

contact your Lexus dealer.

This vehicle is equipped with an event
data recorder (EDR). The main pur-
pose of an EDR is to record, in certain
crash or near crash-like situations, such
as an air bag deployment or hitting a
road obstacle, data that will assist in
understanding how a vehicle’s systems
performed. The EDR is designed to
record data related to vehicle dynam-
ics and safety systems for a short
period of time, typically 30 seconds or
less.
The EDR in this vehicle is designed to
record such data as:
• How various systems in your vehicle

were operating;

• Whether or not the driver and pas-

senger safety belts were buck-
led/fastened;

• How far (if at all) the driver was

depressing the accelerator and/or

Event data recorder

613

Supplement

brake pedal; and,

• How fast the vehicle was traveling.
These data can help provide a better
understanding of the circumstances in
which crashes and injuries occur.
NOTE: EDR data are recorded by your
vehicle only if a non-trivial crash situa-
tion occurs; no data are recorded by
the EDR under normal driving condi-
tions and no personal data (e.g., name,
gender, age, and crash location) are
recorded. However, other parties, such
as law enforcement, could combine the
EDR data with the type of personally
identifying data routinely acquired
during a crash investigation.
To read data recorded by an EDR, spe-
cial equipment is required, and access
to the vehicle or the EDR is needed. In
addition to the vehicle manufacturer,
other parties, such as law enforcement,
that have the special equipment, can
read the information if they have
access to the vehicle or the EDR.



Disclosure of the EDR data

Lexus will not disclose the data recorded in
an EDR to a third party except when:
• An agreement from the vehicle’s owner

(or the lessee for a leased vehicle) is
obtained

• In response to an official request by the

police, a court of law or a government
agency

• For use by Lexus in a lawsuit
However, if necessary, Lexus may:
• Use the data for research on vehicle

safety performance

• Disclose the data to a third party for

research purposes without disclosing
information about the specific vehicle or
vehicle owner

The SRS airbag and seat belt preten-
sioner devices in your Lexus contain
explosive chemicals. If the vehicle is
scrapped with the airbags and seat belt
pretensioners left as they are, this may
cause an accident such as fire. Be sure
to have the systems of the SRS airbag
and seat belt pretensioner removed
and disposed of by a qualified service
shop or by your Lexus dealer before
you scrap your vehicle.

The word “QR Code” is registered
trademark of DENSO WAVE
INCORPORATED in Japan and other
countries.

Precautions for scrapping your
Lexus

“QR code”

614

Alphabetical Index

Alphabetical Index

A/C

Air conditioning filter .................................441
Front automatic air conditioning system

.........................................................................204

Front seat concentrated airflow mode

(S-Flow) ......................................................207

My Room Mode ...........................................65

ABS (Anti-lock Brake System).............. 262
AC charging..................................................... 49
AC charging cable ........................................ 35

CCID (Charging Circuit Interrupting

Device)...........................................................36

If the AC charging connector cannot be

unlocked........................................................40

If the charging connector cannot be

unlocked.....................................................540

Indicator ..................................................37, 541
Maintenance ....................................................37
Safety functions...............................................37

ACA (Active Cornering Assist)........... 262
ACCESSORY mode..................................139
Acoustic Vehicle Alerting System.......... 23
Active Cornering Assist (ACA)........... 262
Adaptive High-beam System.................. 168
Advanced Park ............................................ 374
AHB ..................................................................... 171
AHS.................................................................... 168
Air conditioning filter...................................441
Air conditioning system

Air conditioning filter .................................441
Defogger ..........................................................181
Front automatic air conditioning system

.........................................................................204

Front seat concentrated airflow mode

(S-Flow) ......................................................207

Airbags

Front passenger occupant classification

system ..........................................................407

SRS airbags ..................................................399

Alarm................................................................... 95

Warning buzzer......................................... 472

Anchor brackets..................................... 70, 79
Antennas (smart access system with

push-button start)........................................84

Anti-lock Brake System (ABS).............. 262

ABS warning light......................................474

Approach warning........................................321
Automatic headlight leveling system ... 168
Automatic headlight leveling system

(Headlight)

Function...........................................................168

Automatic High Beam ................................. 171
Automatic light control system................166

Back door ........................................................ 103

If the back door cannot be opened... 531

Back-up light

Replacing light bulbs.................................561

Battery (12-volt battery)

If the 12-volt battery is discharged ...506
Preparing and checking before winter

...........................................................................183

Battery (traction battery)

Charging..................................................49, 56
Location...............................................................21
Traction battery cooler ..............................43
Traction battery heater...............................43

Battery Electric Vehicle driving tips....... 28
Brake

Brake system warning light .................. 472
Fluid.................................................................. 569
Regenerative braking ................................. 22

Brake assist .................................................... 262
Brake hold

Brake hold operated indicator ...........482
Warning messages..................................488

Buzzer

Driver monitor.............................................276

Buzzers

Open window warning .............................98

615

Alphabetical Index

Camera

Driver monitor............................................. 276

Card key ............................................................ 82
Care

Seat belts........................................................ 422
Wheels and wheel ornaments............420

Cargo capacity...............................................102
Catch protection function ..........................98
CCID (Charging Circuit Interrupting

Device) ............................................................ 36

Indicator .............................................................37

Center console light.....................................216
Charging

AC charging................................................... 49
AC charging cable......................................35
Charging components...............................32
Charging indicator .......................................37
Charging methods ...................................... 43
Charging procedure .........................49, 56
Charging schedule function ...................60
Charging time may increase..................48
Charging tips..................................................45
DC charging...................................................56
Display..............................................45, 64, 65
If the charging port lid cannot be opened

.........................................................................533

Information related to charging display

..........................................................45, 64, 65

Locking and unlocking the AC charging

connector......................................................39

My Room Mode ...........................................65
Opening and closing the charging port

lids......................................................................32

Power sources precautions......................41
Power sources that can be used............41
Safety functions......................................37, 46
Things to know before charging .......... 46
When charging cannot be carried out

...........534, 535, 536, 537, 538, 539

Charging equipment .................................... 32

Charging methods......................................... 43

AC charging ...................................................49
DC charging...................................................56

Charging port lid

If the charging port lid cannot be opened

..........................................................................533

Charging ports

Charging port lid .......................................... 32
Locking and unlocking the AC charging

connector......................................................39

Opening and closing.................................. 32

Charging schedule function ......................60

Setting.................................................................64

Charging tips.................................................... 45
Charging-linked functions

My Room Mode............................................43
Traction battery cooler ..............................43
Traction battery heater...............................43
Traction battery warming control.........43

Child restraint system

Fixed with a LATCH system....................77
Fixed with a seat belt................................... 73
Front passenger occupant classification

system...........................................................407

Points to remember.....................................69
Riding with children.....................................68
Types of child restraint system installation

method............................................................70

Using an anchor bracket ..........................79

Child safety .......................................................68

Child restraint system.................................70
Power window lock switch....................100
Seat belt extender precautions.............123
Seat belt precautions ..................................68

Child-protector lock.....................................68
Cleaning

Seat belts........................................................422
Wheels and wheel ornaments............420

Clock ..................................................................241
Coolant

Checking .......................................... 435, 436

616

Alphabetical Index

Cornering lights

Replacing light bulbs................................. 561

Courtesy lights

Location............................................................216

Cruise control

Dynamic radar cruise control ...............312

Curtain shield airbags ...............................399
Customizable features..............................580

Daytime running light system...................166
DC charging..................................................... 56
Defogger

Outside rear view mirrors ......................182
Rear window defogger ............................182
Windshield.......................................................181

Digital Key.........................................................88
Digital Rear-view Mirror............................127
Dimension ...................................................... 564
Dinghy towing..................................................98
DIRECT4........................................................ 262
Display

Charging.........................................45, 64, 65
Dynamic radar cruise control ...............315
Intuitive parking assist..............................348
RCD (Rear Camera Detection)........362

Distance to empty ............................. 241, 253
Do-it-yourself maintenance.................... 426
Door

Child-protector lock...................................68
If a door cannot be opened .................529
Smart access system with push-button

start...................................................................84

Door courtesy lights

Location............................................................216

Door trim ornament lights .........................216
Doors

Close & lock (walk away) function ..... 94
Door lock switches...................................... 94
Impact detection door lock release sys-

tem.................................................................... 92

Driver’s and front passenger’s seat belt

reminder light..............................................476

Driver’s seat position memory

Memory recall function.......................... 200

Drive-Start Control (DSC)

Sudden start restraint control............. 398

Driving

Battery Electric Vehicle driving tips....28
Winter drive tips..........................................185

Driving position memory

Memory recall function................199, 200
Position memory......................................... 199

Driving time ........................................253, 257
Dynamic radar cruise control ..................312

Warning message.......................................321

ECB (Electronically Controlled Brake Sys-

tem) ................................................................ 262

Eco heat/cool ...............................................208
EDR (Event data recorder).......................612
EDSS.................................................................336
Electric motor (traction motor)

Location...............................................................21

Electric Power Steering (EPS) .............. 262
Electric power steering system

Electric power steering system warning

light ................................................................475

Electric Vehicle system features................21
Electric Vehicle system precautions...... 24
Electricity consumption..... 252, 253, 257
Electronic key .................................................. 82

Battery-saving function..............................82
If the electronic key does not operate

properly..........................................505, 522

Replacing the battery...............................523

Electronically Controlled Brake System

(ECB) ............................................................ 262

Emergency Driving Stop System .........336
Emergency flashers

Switches..........................................................469

Emergency shut off system .......................471

617

Alphabetical Index

Emergency towing....................................... 551
Emergency, in case of

A warning light turns on/flashes........ 472
If a warning message is displayed.....483
If the battery is discharged................... 506
If the electronic key does not operate

properly.......................................... 505, 522

If the EV system will not start.504, 506,

510, 511

If the vehicle is submerged or water on

the road is rising......................................470

If you have a flat tire....................................512
If your vehicle overheats........................557
Stopping the vehicle in an emergency

.........................................................................469

Towing with a tow truck.........................549
Towing with another vehicle................. 551
Using a flatbed truck............................... 550

EPS (Electric Power Steering) .............. 262
EV system

Acoustic Vehicle Alerting System........23
Battery Electric Vehicle driving tips....28
Driving range..................................................30
Electric Vehicle system precautions ...24
Emergency shut off system ............27, 471
Features............................................................... 21
How to use AC charging......................... 49
How to use DC charging ........................56
If the EV system will not start.504, 506,

510, 511

Overheating.................................................557
Power (ignition) switch............................ 138
Regenerative braking..................................22
Starting the EV system ............................ 138

Event data recorder (EDR).......................612

FCTA................................................................ 307
FCTA (Front Cross Traffic Alert)......... 307
Flat tire

Emergency tire puncture repair kit ....512

Floor mats.......................................................... 20

Fluid

Brake............................................................... 569
Transmission................................................568
Washer .......................................................... 440

Footwell lights .................................................216
Front automatic air conditioning system

..........................................................................204

Front Cross Traffic Alert .......................... 307
Front Cross Traffic Alert (FCTA)......... 307
Front fog lights

Replacing light bulbs.................................561

Front passenger occupant classification

system ........................................................... 407

Front position lights

Light switches ............................................... 166

Front seats ........................................................120

Adjustment..................................................... 120
Head restraints............................................... 121
Memory recall function................199, 200
Power easy access system ....................198

Front side marker lights

Light switch.................................................... 166
Replacing light bulbs.................................561

Front turn signal lights (bulb type)

Replacing light bulbs.................................561

Fuses

Replacing ......................................................560

Garage door opener...................................157
Gauges

Changing the instrument panel light

brightness.................................................. 258

Displayed content....................................... 251
Head-up display.........................................249
Indicators........................................................240
Multi-information display...........246, 247
Warning lights.............................................238

Hands Free Power Back Door................. 114

618

Alphabetical Index

Head restraints................................................ 121
Headlight

Cleaner.............................................................179
Replacing light bulbs................................. 561

Headlight switch

Light switches................................................166

Head-up display........................................... 249
Heated steering wheel................................210
Heater coolant

Preparing and checking before winter

.......................................................................... 183

Heaters

Front automatic air conditioning system

.........................................................................204

Outside rear view mirrors ......................182
Traction battery heater .............................. 43

High mounted stoplight

Replacing light bulbs................................. 561

Hill-start assist control............................... 262
Hood................................................................. 433

Open ...............................................................433

Hooks

Retaining hooks (floor mat).....................20

Horn....................................................................187

I/M test ............................................................ 429
Identification

Vehicle............................................................564

If the 12-volt battery is discharged ....... 522
Ignition switch (power switch)

Changing the power switch modes ..139
How to start the EV system .................. 138

Immobilizer system........................................ 94
Impact detection door lock release system

............................................................................. 92

Indicators

Charging cable...............................................37
Charging indicator ...................................... 34
Charging indicator (CCID).....................37
Error warning indicator..............................37
Power indicator..............................................37

Initialization

Items to initialize ........................................598

Inside handle lights........................................216
Inside rear view mirror................................127
Inspection ....................................................... 444
Interior lights....................................................217
Intuitive parking assist

Function......................................................... 348
Intuitive parking assist OFF indicator481
Warning message.................................... 350

Jack

Lifting the vehicle with a floor jack ... 456
Vehicle-equipped jack .......................... 460

Jack handle ....................................................460
Jam protection function...............................98

Power back door........................................103

Key

If a key has been lost ................................522
Keyless entry ...................................................84

Keyless entry

Smart access system with push-button

start ...................................................................84

Keys...................................................................... 82

Electronic key .................................................82
If the electronic key does not operate

properly..........................................505, 522

Knee airbags .................................................399

Lane Change Assist ................................... 294
Lane change Assist (LCA)...................... 294
Lane Departure Alert (LDA) ................. 297
Lane Tracing Assist ....................................288
LATCH anchors ..............................................77
LCA .................................................................. 294
LCA (Lane change Assist)...................... 294

619

Alphabetical Index

LDA (Lane Departure Alert) ................. 297
Lever

Auxiliary catch lever.................................433
Hood lock release lever.........................433
Wiper lever..................................................... 177

Lexus Climate Concierge .......................203
Lexus Safety System + 3 ..........................268

Cruise control .............................................325
Driver monitor............................................. 276
Dynamic radar cruise control ...............312
FCTA (Front Cross Traffic Alert) .....307
LCA (Lane change Assist)...................294
LDA (Lane Departure Alert)............... 297
LTA (Lane Tracing Assist)....................288
PCS (Pre-Collision System)................278
PDA (Proactive driving assist) ...........302
RSA (Road Sign Assist) .......................... 310
Traffic Jam Assist .........................................331

Lexus Teammate Advanced Park........ 374
License plate lights

Headlight switch ..........................................166
Replacing light bulbs................................. 561

Light bulbs

Replacing........................................................ 561

Lights

Emergency flashers..................................469
Headlight switch ..........................................166

Linked mirror function when reversing134
Lock

Smart access system with push-button

start...................................................................84

Window lock switch .................................100

Locking and unlocking the AC charging

connector ....................................................... 39

LTA....................................................................288

Maintenance

AC charging cable.......................................37
Do-it-yourself maintenance ...................431
General maintenance............................. 427
Maintenance data......................................564

Maintenance requirements ..................425

Max cool .........................................................209
Max heat .........................................................208
Memory recall function ..............................199
Meter

Changing the instrument panel light

brightness.................................................. 258

Mirror

Digital Rear-view Mirror..........................127
Inside rear view mirror..............................127

Mirrors

Outside rear view mirrors.......................134

Moter compartment

Steam comes out from under the hood

..........................................................................557

Multi-information display

Charging.........................................45, 64, 65
Dynamic radar cruise control............... 315
Operating....................................................... 251
Warning messages.................................. 483

My Room Mode.............................................. 65

Starting My Room Mode..........................65

My Settings ......................................................196

Odometer

Changing/resetting..................................245
Function............................................................241

Opener

Hood................................................................433

Outer foot lights.............................................216
Outside rear view mirrors .........................134

Adjustment......................................................134
Folding/extending...................................... 135
Heaters............................................................. 182
RCTA function............................................357

Outside temperature...................................241

620

Alphabetical Index

Overheating.................................................. 557

Paddle shift switches................................... 150
Panic mode ....................................................... 93
Parking assist sensors (intuitive parking

assist).............................................................348

Parking brake..................................................154

Parking brake engaged warning buzzer

...........................................................................154

Parking brake indicator..........................482

Parking lights

Light switch.....................................................166

Parking Support Brake function (for

rear-crossing vehicles) ............................371

Function............................................................371

Parking Support Brake function (rear

pedestrians)................................................ 372

Function.......................................................... 372

Parking Support Brake function (static

objects).........................................................368

Function..........................................................368

PCS (Pre-Collision System)

Function..........................................................278
PCS warning light..................................... 479

PDA (Proactive driving assist)...............302
Personal lights.................................................218
PKSB (Parking Support Brake).............365
Power (ignition) switch

Changing the power switch modes ..139
How to start the EV system .................. 138

Power back door.......................................... 103

Adjusting the open position of the back

door..................................................................118

Hands Free Power Back Door..............114
Jam protection function........................... 103

Power control unit coolant

Capacity............................................567, 568
Checking .......................................................435
Preparing and checking before winter

.......................................................................... 183

Radiator..........................................................436

Power outlets .....................................224, 225
Power sources...................................................41
Power steering (Electric power steering

system).......................................................... 262

Power switch

Stopping the vehicle in an emergency

..........................................................................469

Power windows

Door lock linked window operation...99
Jam protection function.............................98
Operation.........................................................99
Window lock switch..................................100

Pre-Collision System (PCS)

Function..........................................................278

Radar cruise control (dynamic radar cruise

control) ...........................................................312

Radiant heaters ............................................... 211
Radiator

Overheating.................................................557

Rain-sensing windshield wipers .............. 177
RCD (Rear Camera Detection)

Function........................................................... 361

RCTA function ............................................. 357
Rear doors

If the rear doors cannot be opened from

the inside...................................................... 531

Rear fog lights

Replacing light bulbs.................................561

Rear passengers’ seat belt reminder light

...........................................................................476

Rear seats .........................................................120

Head restraints............................................... 121

Rear side marker lights

Light switch.................................................... 166
Replacing light bulbs.................................561

Rear turn signal light

Replacing light bulbs.................................561

Rear view mirror

Inside rear view mirror..............................127

621

Alphabetical Index

Rear window defogger

Window............................................................182

Regenerative braking....................................22
Replacing

Fuses ............................................................... 560
Light bulbs...................................................... 561
Tire ....................................................................459

Replacing the battery ................................523
Riding with children

12-volt battery precautions...................526
Child-protector lock...................................68

Road Sign Assist ........................................... 310
Road Sign Assist (RSA) ............................. 310
Rotary shifter...................................................144
RSA .................................................................... 310
RSA (Road Sign Assist) ............................. 310

Safety Connect...............................................412
Seat belt reminder light..............................476
Seat belt reminder lights............................476
Seat belts

Adjusting the height ...................................126
Care ................................................................. 422
Child restraint system installation......... 70
Emergency Locking Retractor.............125
Fastening and releasing ...........................125
Riding with children....................................123
Seat belt extender .......................................123
Seat belt pretensioners...........................399
Seat belt reminder light .......................... 476
Seat belt reminder lights ........................ 476

Seat heaters...................................................... 211
Seat ventilators...............................................213
Seats

Adjustment......................................................120
Child seats/child restraint system installa-

tion....................................................................69

Head restraints ...............................................121
Memory recall function ............................199
Power easy access system.................... 198

Sensor

Automatic headlight system.................. 166
Inside rear view mirror..............................175
Intuitive parking assist............................. 348
Radar sensor................................................345
Raindrop sensor.......................................... 178

Service plug...................................................... 24
Shift position

Changing the shift ...................................... 145
Changing the shift range ........................150
Intended use of each shift position......144

Side airbags ...................................................399
Side marker lights

Light switch.................................................... 166

Side turn signal lights

Replacing light bulbs.................................561

Smart access system with push-button

start

Antenna location...........................................84
Battery-saving function..............................82
Entry functions.....................................92, 108
If the electronic key does not operate

properly.......................................................522

Starting the EV system.............................138

Snow tires ........................................................ 183
SOC (State of Charge) gauge................241
Specifications................................................ 564
Speedometer ..................................................241
Starting the EV system............................... 138
Steering wheel................................................126

Adjustment......................................................126
Electric power steering system warning

light ................................................................475

Power easy access system ....................198

Stop/tail lights

Replacing light bulbs.................................561

Stopping the vehicle in an emergency469
Sun visors..........................................................175
Switch

Horn .................................................................. 187

Switches

Adjustment..................................................... 120

622

Alphabetical Index

Advanced Park main switch................379
Door lock.......................................................... 94
Dynamic radar cruise control switch 315
Emergency flashers..................................469
Garage door opener ................................157
Ignition switch............................................... 138
Intuitive parking assist switch...............349
Light switches................................................166
Meter control.................................................251
Outside rear view mirrors ......................134
Paddle shift switches................................. 150
PKSB (Parking Support Brake) switch

.........................................................................366

Power windows.............................................99
RCD (Rear Camera Detection) switch

.........................................................................362

“SOS” button .................................................412
SYNC switch ..............................................204
Tilt and telescopic steering control switch

...........................................................................126

Vehicle-to-vehicle distance switch ....315
VSC OFF switch.......................................263
Washer.............................................................179
Window lock switch .................................100

SYNC

SYNC (synchronize) switch ...............204

Tachometer......................................................241
Tail lights

Light switch.....................................................166

The Secondary Collision Brake ............ 262
Theft deterrent system

Alarm ..................................................................95
Immobilizer system...................................... 94

Tire

If you have a flat tire....................................512
Replacing the tire.......................................459
Rotating the tires........................................457
Tire inflation pressure..............................454

Tire inflation pressure

Maintenance data......................................570

Tire information..............................................571

Glossary.........................................................574
Size....................................................................572
Tire identification number......................572
Uniform Tire Quality Grading............573

Tire pressure warning system ................ 446

Registering ID codes ................................ 451
Registration of the position of each wheel

......................................................................... 448

Selecting wheel set ...................................453
Setting the tire pressure..........................449
Tire pressure warning light................... 477
Valves and transmitters......................... 448
Warning messages.................................. 485

Tires

Information......................................................571
Size................................................................... 570
Snow tires .......................................................183

Tool....................................................................460
Top tether strap................................................79
Total load capacity...................................... 564
Towing

Dinghy towing................................................98
Towing with a tow truck........................ 549
Towing with another vehicle.................551
Trailer towing..................................................97
Using a flatbed truck...............................550

TRAC (Traction Control) ........................ 262
Traction battery

Charging..................................................49, 56
Location...............................................................21
Specification ................................................ 566
Traction battery cooler ..............................43
Traction battery heater...............................43

Traction Control (TRAC) ........................ 262
Traffic Jam Assist...........................................331
Trailer towing ....................................................97
Transmission

Downshifting restriction warning buzzer

...........................................................................150

Operation........................................................144

Transmitters...................................................448

623

Alphabetical Index

Trip meter

Changing/resetting..................................245
Function............................................................241

Vehicle data recording.............................. 610
Vehicle identification number................ 564
Vehicle Stability Control (VSC) ........... 262
VSC (Vehicle Stability Control) ........... 262

Warning buzzer............................................472
Warning buzzers

Approach warning......................................321
Intuitive parking assist..............................354
Open door.......................................................89
Open window................................................98

Warning lights....................................238, 472

ABS warning light ..................................... 474
Brake system warning light .................. 472
Charging system warning light .......... 473
Driver’s and front passenger’s seat belt

reminder light........................................... 476

Driving assist information indicator... 481
Dynamic radar cruise control indicator

........................................................................ 480

Electric power steering system warning

light ................................................................475

Intuitive parking assist OFF indicator481
LDA indicator............................................. 480
Low traction battery warning light.... 473
LTA indicator............................................... 479
Parking brake indicator..........................482
PCS warning light..................................... 479
Proactive Driving Assist indicator.... 480
Rear passengers’ seat belt reminder light

......................................................................... 476

Slip indicator ................................................. 481
Tire pressure warning light....................477

Warning messages.....................................483

Washer ..............................................................179

Adding............................................................ 440
Preparing and checking before winter

...........................................................................183

Switches............................................................179

Weight

Cargo capacity............................................ 102
Weight............................................................ 564

Wheel

Replacing ...................................................... 459

Wheel bolt wrench .....................................460
Wheels

Size................................................................... 570

Window lock switch .................................... 100
Windows

If the windows do not open or close556
Rear window defogger............................ 182
Washer .............................................................179

Windshield wiper and washer........ 177, 179
Wireless remote control

Battery-saving function..............................82
Open door warning buzzer....................89
Operation signals.........................................92
Replacing the battery...............................523

For information regarding the

equipment listed below, refer to
the “MULTIMEDIA OWNER’S
MANUAL”.

· Voice control system
· Navigation system
· Audio/visual system
· Panoramic view monitor
· Lexus parking assist monitor

Lexus RZ450E (2023 year). Manual in english - page 19
