Lexus RZ450E (2023 year). Manual in english

563

Vehi

cle

spec

ifi

tions

Vehicle specifications

10-1. Specifications

Maintenance data.....................

564

Tire information...........................

571

10-2. Customizable features

User customization function out-

line ................................................

580

Method to change settings ...

580

Customizable features............

582

10-3. Initialization

Items to initialize ........................

598

564

10-1. Specifications

10-1.Specifications

: Unladen vehicle

■

Vehicle identification number

The vehicle identification number (VIN) is the legal identifier for your vehicle. This
is the primary identification number for your Lexus. It is used in registering the
ownership of your vehicle.
This number is stamped on the top left of the instrument panel.

This number is also stamped under the right-hand front seat.

Maintenance data

Dimensions and weight

Overall length

189.2 in. (4805 mm)

Overall width

74.6 in. (1895 mm)

Overall height

64.4 in. (1635 mm)

Wheelbase

112.2 in. (2850 mm)

Tread

Front

63.4 in. (1610 mm)

Rear

63.8 in. (1620 mm)

Vehicle capacity weight
(Occupants + luggage)

950 lb. (430 kg)

Seating capacity

5 (Front 2, Rear 3)

Vehicle identification

566

10-1. Specifications



Rear electric motor (traction motor)

Front electric motor (traction motor)

Model

1XM

Type

Permanent magnet synchronous motor

Maximum output

150 kW

Maximum torque

196.4 ft•lbf (266.3 N•m, 27.2 kgf•m)

Rear electric motor (traction motor)

Model

1YM

Type

Permanent magnet synchronous motor

Maximum output

80 kW

Maximum torque

124.3 ft•lbf (168.5 N•m, 17.2 kgf•m)

Traction battery

Type

Lithium-ion battery

Voltage

3.7 V/cell

Capacity

201 Ah

Quantity

96 cells

Nominal voltage

355.2 V

567

10-1. Specifications

icle

ific

atio

: The coolant capacity is a reference quantity.

If replacement is necessary, contact your Lexus dealer.

Cooling system

Capacity

7.8 qt. (7.4 L, 6.5 Imp. qt.)

Coolant type

Use either of the following:



“Toyota Genuine Traction Battery Coolant”



Similar high-quality ethylene glycol-based, low electric
conductivity coolant, non-amine and non-borate coolant
with azole additives.

Do not use plain water alone.

NOTICE

■

Cooling system coolant

In order to ensure maximum performance of the traction battery cooling system and limit

risks of battery short-circuit and other damage to your vehicle, Lexus recommends using

“Toyota Genuine Traction Battery Coolant” or similar high-quality ethylene glycol-based,

low electric conductivity coolant, non-amine and non-borate coolant with azole addi-

tives.

Lexus cannot guarantee that the use of a product other than “Toyota Genuine Traction

Battery Coolant” will prevent risks of battery short circuit or other damage.

Never use water as it will cause damage.

Do not reuse coolant that has been removed from the radiator.

568

10-1. Specifications

: The coolant capacity is a reference quantity.

If replacement is necessary, contact your Lexus dealer.

: The fluid capacity is a reference quantity.

If replacement is necessary, contact your Lexus dealer.

Heater system

Capacity

6.9 qt. (6.5 L, 5.2 Imp. qt.)

Coolant type

Use either of the following:



“Toyota Super Long Life Coolant”



Similar high-quality ethylene glycol-based non-silicate,
non-amine, non-nitrite, and non-borate coolant with
long-life hybrid organic acid technology

Do not use plain water alone.

Electrical system (12-volt battery)

Open voltage at 68°F (20°C):

12.0 V or higher
(Turn the power switch off and turn on the high
beam headlights for 30 seconds.)

Charging rates:

5 A max.

Front eAxle

Fluid capacity

4.1 qt. (3.9 L, 3.4 Imp. qt.)

Fluid type

“Toyota Genuine e-Transaxle fluid TE”

NOTICE

■

Front eAxle fluid type

Using transaxle fluid other than the above type may cause abnormal noise or vibration, or

ultimately damage the front eAxle of your vehicle.

Rear eAxle

Fluid capacity

3.3 qt. (3.1 L, 2.7 Imp. qt.)

Fluid type

“Toyota Genuine e-Transaxle fluid TE”

569

10-1. Specifications

icle

ific

atio

: The fluid capacity is a reference quantity.

If replacement is necessary, contact your Lexus dealer.

: Minimum pedal clearance when depressed with a force of 67.5 lbf (300 N, 30.6 kgf)

while the EV system is operating.

: Make sure to confirm that the brake warning light (yellow) does not illuminate. (If the

brake warning light illuminates, refer to P.482.)

NOTICE

■

Rear eAxle fluid type

Using transaxle fluid other than the above type may cause abnormal noise or vibration, or

ultimately damage the rear eAxle of your vehicle.

Brakes

Pedal clearance

2.3 in. (57.5 mm) Min.

Pedal free play

0.04



0.24 in. (1



6 mm)

Brake pad wear limit

0.04 in. (1.0 mm)

Parking brake indicator

When pushing the parking brake switch for 1 to 4
seconds: turns off
When pulling the parking brake switch for 1 to 4
seconds: comes on

Fluid type

FMVSS No. 116 DOT 3 or SAE J1703
FMVSS No. 116 DOT 4 or SAE J1704

Steering

Free play

Less than 1.2 in. (30 mm)

570

10-1. Specifications



Vehicles with 18-inch wheels



Vehicles with 20-inch wheels

Tires and wheels

Tire size

Front tires: 235/60R18 103V
Rear tires: 255/55R18 105V

Tire inflation pressure
(Recommended cold tire
inflation pressure)



Front

38 psi (260 kPa, 2.6 kgf/cm

or bar)



Rear

38 psi (260 kPa, 2.6 kgf/cm

or bar)

Wheel size

Front wheels: 18



7 1/2 J

Rear wheels: 18



8 J

Wheel bolt torque

103 ft•lbf (140 N•m, 14.3 kgf•m)

Tire size

Front tires: 235/50R20 104V
Rear tires: 255/45R20 105W

Tire inflation pressure
(Recommended cold tire
inflation pressure)



Front

38 psi (260 kPa, 2.6 kgf/cm

or bar)



Rear

35 psi (240 kPa, 2.4 kgf/cm

or bar)

Wheel size

Front wheels: 20



8 J

Rear wheels: 20



9 1/2 J

Wheel bolt torque

103 ft•lbf (140 N•m, 14.3 kgf•m)

571

10-1. Specifications

Vehi

cle

spec

ifi

tions

Tire size
DOT and Tire Identification Number (TIN)
Location of treadwear indicators
Tire ply composition and materials

Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies
in a tire.

Radial tires or bias-ply tires

A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL” is a bias-ply tire.

TUBELESS or TUBE TYPE

A tubeless tire does not have a tube and air is directly put into the tire. A tube type tire has a
tube inside the tire and the tube maintains the air pressure.

Load limit at maximum cold tire inflation pressure
Maximum cold tire inflation pressure

This means the pressure to which a tire may be inflated.

Uniform tire quality grading

For details, see P.573that follows.

Summer tires or all season tires

An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a summer tire.

Tire information

Typical tire symbols

A
B
C
D

572

10-1. Specifications



Type A

DOT symbol

Tire Identification Number (TIN)
Tire manufacturer's identification
mark
Tire size code
Manufacturer's optional tire type
code (3 or 4 letters)
Manufacturing week
Manufacturing year



Type B

DOT symbol

Tire Identification Number (TIN)
Tire manufacturer's identification
mark
Manufacturer's code

Manufacturing week
Manufacturing year

: The DOT symbol certifies that the tire

conforms to applicable Federal Motor
Vehicle Safety Standards.

■

Typical tire size information

The illustration indicates typical tire
size.

Tire use

(P = Passenger car, T = Temporary use)

Section width (millimeters)
Aspect ratio (tire height to section
width)
Tire construction code

(R = Radial, D = Diagonal)

Wheel diameter (inches)
Load index (2 digits or 3 digits)
Speed symbol (alphabet with one
letter)

Typical DOT and Tire Identifica-
tion Number (TIN)

A
B
C

Tire size

E
F

B
C

E
F

573

10-1. Specifications

Vehi

cle

spec

ifi

tions

■

Tire dimensions

Section width
Tire height
Wheel diameter

Bead
Sidewall
Shoulder
Tread
Belt
Inner liner
Reinforcing rubber
Carcass
Rim lines
Bead wires
Chafer

This information has been prepared in
accordance with regulations issued by
the National Highway Traffic Safety
Administration of the U.S. Department
of Transportation.
It provides the purchasers and/or pro-
spective purchasers of Lexus vehicles
with information on uniform tire quality
grading.
Your Lexus dealer will help answer any
questions you may have as you read
this information.

■

DOT quality grades

All passenger vehicle tires must con-
form to Federal Safety Requirements in
addition to these grades. Quality
grades can be found where applicable
on the tire sidewall between tread
shoulder and maximum section width.
For example: Treadwear 200 Traction
AA Temperature A

■

Treadwear

The treadwear grade is a comparative
rating based on the wear rate of the tire
when tested under controlled condi-
tions on a specified government test
course.
For example, a tire graded 150 would
wear one and a half (1 - 1/2) times as
well on the government course as a tire
graded 100.
The relative performance of tires
depends upon the actual conditions of
their use, however, and may depart sig-
nificantly from the norm due to varia-

Tire section names

A
B
C

A
B
C
D

E
F

Uniform Tire Quality Grading

574

10-1. Specifications

tions in driving habits, service practices
and differences in road characteristics
and climate.

■

Traction AA, A, B, C

The traction grades, from highest to
lowest, are AA, A, B and C, and they
represent the tire’s ability to stop on
wet pavement as measured under con-
trolled conditions on specified govern-
ment test surfaces of asphalt and
concrete.
A tire marked C may have poor trac-
tion performance.
Warning: The traction grade assigned
to this tire is based on braking (straight
ahead) traction tests and does not
include cornering (turning) traction.

■

Temperature A, B, C

The temperature grades are A (the
highest), B, and C, representing the
tire’s resistance to the generation of
heat and its ability to dissipate heat
when tested under controlled condi-
tions on a specified indoor laboratory
test wheel.
Sustained high temperature can cause
the material of the tire to degenerate
and reduce tire life, and excessive tem-
perature can lead to sudden tire failure.
Grade C corresponds to a level of per-
formance which all passenger car tires
must meet under the Federal Motor
Vehicle Safety Standard No. 109.
Grades B and A represent higher lev-
els of performance on the laboratory
test wheel than the minimum required
by law.

Warning: The temperature grades for
this tire are established for a tire that is
properly inflated and not overloaded.
Excessive speed, underinflation, or
excessive loading, either separately or
in combination, can cause heat buildup
and possible tire failure.

Glossary of tire terminology

Tire related term

Meaning

Cold tire inflation

pressure

Tire pressure when

the vehicle has been

parked for three

hours or more, or

has not been driven

more than 1 mile or

1.5 km under that

condition

Maximum inflation

pressure

The maximum cold

inflated pressure to
which a tire may be

inflated, shown on
the sidewall of the

tire

Recommended

inflation pressure

Cold tire inflation

pressure recom-

mended by a manu-

facturer

575

10-1. Specifications

Vehi

cle

spec

ifi

tions

Accessory weight

The combined

weight (in excess of

those standard items

which may be

replaced) of trans-

mission, power

steering, power

brakes, power win-

dows, power seats,

radio and heater, to

the extent that these

items are available

as factory-installed

equipment (whether

installed or not)

Curb weight

The weight of a

motor vehicle with

standard equip-

ment, including the
maximum capacity

of traction battery

and coolant, and if

so equipped, air

conditioning and

additional weight

optional traction

motor

Maximum loaded

vehicle weight

The sum of:

(a) Curb weight

(b) Accessory

weight

(d) Production
options weight

Tire related term

Meaning

Normal occupant

weight

150 lb. (68 kg)

times the number of
occupants specified

in the second col-

umn of Table 1

that

follows

Occupant distribu-

tion

Distribution of occu-

pants in a vehicle as

specified in the third

column of Table 1

below

Production options

weight

The combined

weight of installed

regular production

options weighing

over 5 lb. (2.3 kg) in

excess of the stan-

dard items which

they replace, not

previously consid-

ered in curb weight

or accessory weight,
including heavy duty

brakes, ride level-

ers, roof rack, heavy

duty 12-volt battery,

and special trim

Rim

A metal support for

a tire or a tire and

tube assembly upon
which the tire beads

are seated

Rim diameter

(Wheel diameter)

Nominal diameter of

the bead seat

Rim size designation

Rim diameter and

width

Tire related term

Meaning

576

10-1. Specifications

Rim type designa-

tion

The industry manu-

facturer's designa-

tion for a rim by style

or code

Rim width

Nominal distance

between rim flanges

Vehicle capacity

weight (Total load

capacity)

The rated cargo and

luggage load plus

150 lb. (68 kg)

times the vehicle’s

designated seating

capacity

Vehicle maximum

load on the tire

The load on an indi-

vidual tire that is

determined by dis-

tributing to each

axle its share of the

maximum loaded

vehicle weight, and

dividing by two

Vehicle normal load

on the tire

The load on an indi-

vidual tire that is

determined by dis-

tributing to each

axle its share of curb

weight, accessory

weight, and normal

occupant weight

(distributed in

accordance with

Table 1

below), and

dividing by two

Weather side

The surface area of

the rim not covered

by the inflated tire

Tire related term

Meaning

Bead

The part of the tire

that is made of steel

wires, wrapped or

reinforced by ply

cords and that is

shaped to fit the rim

Bead separation

A breakdown of the

bond between com-

ponents in the bead

Bias ply tire

A pneumatic tire in

which the ply cords

that extend to the

beads are laid at

alternate angles

substantially less

than 90 degrees to

the centerline of the

tread

Carcass

The tire structure,

except tread and

sidewall rubber

which, when inflated,

bears the load

Chunking

The breaking away

of pieces of the

tread or sidewall

Cord

The strands forming

the plies in the tire

Cord separation

The parting of cords

from adjacent rub-

ber compounds

Cracking

Any parting within

the tread, sidewall,
or innerliner of the

tire extending to

cord material

Tire related term

Meaning

577

10-1. Specifications

Vehi

cle

spec

ifi

tions

A pneumatic tire

with an inverted

flange tire and rim

system in which the

rim is designed with

rim flanges pointed

radially inward and
the tire is designed

to fit on the under-

side of the rim in a

manner that

encloses the rim

flanges inside the air

cavity of the tire

Extra load tire

A tire designed to

operate at higher

loads and at higher

inflation pressures

than the corre-

sponding standard

tire

Groove

The space between

two adjacent tread

ribs

Innerliner

The layer(s) forming

the inside surface of

a tubeless tire that
contains the inflat-
ing medium within

the tire

Innerliner separa-

tion

The parting of the

innerliner from cord

material in the car-

cass

Tire related term

Meaning

Intended outboard

sidewall

(a) The sidewall that

contains a white-

wall, bears white let-

tering, or bears

manufacturer,

brand, and/or model
name molding that is

higher or deeper

than the same mold-

ing on the other

sidewall of the tire,

(b) The outward fac-

ing sidewall of an

asymmetrical tire

that has a particular

side that must

always face outward

when mounted on a

vehicle

Light truck (LT) tire

A tire designated by

its manufacturer as

primarily intended

for use on light-

weight trucks or

multipurpose pas-

senger vehicles

Load rating

The maximum load

that a tire is rated to

carry for a given

inflation pressure

Maximum load rat-

ing

The load rating for a

tire at the maximum
permissible inflation

pressure for that tire

Maximum permissi-

ble inflation pressure

The maximum cold

inflation pressure to

which a tire may be

inflated

Tire related term

Meaning

578

10-1. Specifications

Measuring rim

The rim on which a

tire is fitted for physi-

cal dimension

requirements

Open splice

Any parting at any

junction of tread,

sidewall, or inner-

liner that extends to

cord material

Outer diameter

The overall diameter

of an inflated new

tire

Overall width

The linear distance

between the exteri-

ors of the sidewalls

of an inflated tire,

including elevations

due to labeling, dec-

orations, or protec-

tive bands or ribs

Passenger car tire

A tire intended for

use on passenger

cars, multipurpose

passenger vehicles,

and trucks, that have

a gross vehicle

weight rating

(GVWR) of 10,000

lb. or less.

Ply

A layer of rub-

ber-coated parallel

cords

Ply separation

A parting of rubber

compound between

adjacent plies

Tire related term

Meaning

Pneumatic tire

A mechanical

device made of rub-

ber, chemicals, fab-

ric and steel or other

materials, that, when

mounted on an

automotive wheel,

provides the traction

and contains the gas

or fluid that sustains

the load

Radial ply tire

A pneumatic tire in

which the ply cords

that extend to the

beads are laid at

substantially 90

degrees to the cen-

terline of the tread

Reinforced tire

A tire designed to

operate at higher

loads and at higher

inflation pressures

than the corre-

sponding standard

tire

Section width

The linear distance

between the exteri-

ors of the sidewalls

of an inflated tire,

excluding eleva-

tions due to labeling,

decoration, or pro-

tective bands

Sidewall

That portion of a tire

between the tread

and bead

Sidewall separation

The parting of the

rubber compound

from the cord mate-

rial in the sidewall

Tire related term

Meaning

579

10-1. Specifications

Vehi

cle

spec

ifi

tions

: Table 1—Occupant loading and distribu-

tion for vehicle normal load for various
designated seating capacities

Snow tire

A tire that attains a

traction index equal

to or greater than

110, compared to the

ASTM E-1136 Stan-

dard Reference Test

Tire, when using the

snow traction test as

described in ASTM

F-1805-00, Stan-

dard Test Method

for Single Wheel

Driving Traction in a

Straight Line on

Snow-and Ice-Cov-

ered Surfaces, and

which is marked with

an Alpine Symbol

(

) on at least

one sidewall

Test rim

The rim on which a

tire is fitted for test-

ing, and may be any

rim listed as appro-

priate for use with

that tire

Tread

That portion of a tire

that comes into con-

tact with the road

Tread rib

A tread section run-

ning circumferen-
tially around a tire

Tread separation

Pulling away of the

tread from the tire

carcass

Tire related term

Meaning

Treadwear indica-

tors (TWI)

The projections

within the principal

grooves designed to

give a visual indica-

tion of the degrees

of wear of the tread

Wheel-holding fix-

ture

The fixture used to

hold the wheel and

tire assembly

securely during test-

ing

Designated

seating

capacity,

Number of

occupants

Vehicle nor-

mal load,

Number of

occupants

Occupant

distribution

in a normally

loaded vehi-

cle

2 through 4

2 in front

5 through 10

2 in front, 1 in

second seat

11 through 15

2 in front, 1 in

second seat,

1 in third seat,

1 in fourth

seat

16 through

2 in front, 2

in second

seat, 2 in

third seat, 1 in

fourth seat

Tire related term

Meaning

580

10-2. Customizable features

10-2.Customizable features

■

Set by selecting

Stop the vehicle in a place where oper-
ations can be performed safely,
engage the parking brake, and change
the shift position to P.

Select

on the center display.

Select “Vehicle customize” or
“Driving assist”.

Select the item to change the set-
tings of from the list.

The setting of each items can be changed.

For details, see the customizable items list.
For functions that can be turned on/off,

select

(ON)/

(OFF).

■

Set by selecting

Stop the vehicle in a place where oper-
ations can be performed safely,
engage the parking brake, and change
the shift position to P.

Select

on the center display.

Select “Vehicle customize” or
“Driving assist”.

Select the item to change the set-
tings of from the list.

The setting of each items can be changed.

For details, see the customizable items list.

Each time

is selected, the setting is

enabled/disabled.
When enabling is selected, the item display

will be emphasized.

User customization function
outline

Your vehicle includes a variety of
electronic features that can be per-
sonalized to suit your preferences.
The settings of these features can
be changed using the center dis-
play or at your Lexus dealer.

NOTICE

While performing customization, make

sure that the EV system is operating, in

order to prevent the 12-volt battery from

becoming discharged.

Method to change settings

Changing using the center dis-
play

582

10-2. Customizable features



Settings that can be changed using the center display



Settings that can be changed by your Lexus dealer

Definition of symbols: O = Available, — = Not available

The language, units of measure, etc. of some items displayed on the meter or
multi-information display will be changed according to settings on the center dis-
play. Refer to “MULTIMEDIA OWNER’S MANUAL”.

: This setting changes in accordance with My Settings.

: The setting can be changed on “Notifications” of

: This setting changes in accordance with My Settings.

Customizable features

Some function settings are changed simultaneously with other functions being
customized. Contact your Lexus dealer for further details.

Gauges, meters and multi-information display

Function

Default setting

Customized setting

Meter display type

Type 1

Type 2

—

Type 3

Stop light indicator

Off

—

Suggestion function

On (when the vehi-

cle is stopped)

Off

Head-up Display (if equipped)

Function

Default setting

Customized setting

Display

Off

—

Display mode

Normal

Maximum

—

Minimum

583

10-2. Customizable features

Vehi

cle

spec

ifi

tions

: This setting changes in accordance with My Settings.

Steering wheel switches (vehicles with a head-up display)

Function

Default setting

Customized setting

Right steering wheel switch

favorite functions

Display control

Driving mode select

switch

—

Custom

Left steering wheel switch

favorite functions

Audio

Climate

—

Custom

Switch sensor high sensitivity

mode (winter glove mode)

Off

—

Door lock

Function

Default setting

Customized setting

Door lock switch indicator illu-

mination time

30 seconds

60 seconds

—

600 seconds

1200 seconds

Inside door opener switch

operation adjustment (door

opening function adjustment)

Short

Mid

—

Long

Multi-information dis-

play/buzzer operation when a

door opener switch inside the

vehicle is operated

Off

—

584

10-2. Customizable features

: This setting changes in accordance with My Settings

: All doors are automatically unlocked when driver’s door is opened within approximately

45 seconds after turning the power switch off.

Inside/outside door opener

switch operating method

Unlatch while push-

ing switch

0.6 Seconds

—

Operating from
inside the cabin:

0.6 Seconds

Operating from out-

side:

Unlatch while push-

ing switch

Operating from
inside the cabin:

Unlatch while push-

ing switch

Operating from out-

side:

0.6 Seconds

Unlocking using a mechanical

key

Driver’s door

unlocked in one step,

all doors unlocked in

two step

All doors unlocked in

one step

—

Shift position linked door lock-

ing function

Off

Automatic door unlocking

function

Shift position linked

door unlocking

operation

Off

Driver’s door linked

door unlocking

operation

Function

Default setting

Customized setting

585

10-2. Customizable features

Vehi

cle

spec

ifi

tions

: Configured by operating the

switch of the lower back door.

: If equipped

Power back door (if equipped)

Function

Default setting

Customized setting

Back door automatic open and

stop position

Stop at the desired

position (height)

—

1 to 5

Power back door operations

Off

—

Operation buzzer volume

—

Kick Sensor

Off

—

Kick operation buzzer

Off

—

The function that validates the

switch of the wire-

less remote control when lock-

ing the door

Off

—

Close & lock (walk away) func-

tion

Off

—

Hands free close & lock (walk

away) function

Off

—

Smart access system with push-button start and wireless remote control

Function

Default setting

Customized setting

Operation buzzer

Lexus buzzer

Normal buzzer

—

Operation buzzer volume

Off

1 to 7

Operation signal (Emergency

flashers)

Off

586

10-2. Customizable features

: This setting changes in accordance with My Settings.

Time elapsed before automatic

door lock function is activated

if door is not opened after

being unlocked

60 seconds

Off

30 seconds

120 seconds

Open door warning buzzer

Off

—

Smart access system with push-button start

Function

Default setting

Customized setting

Smart access system with

push-button start

Off

—

The doors that are unlocked

using the smart access system

with push-button start can be

selected

Driver’s door

All the doors

Number of consecutive door

lock operations

2 times

As many as desired

—

Time elapsed before unlocking

all the door when gripping and

holding the driver’s door han-

dle

2 seconds

Off

—

1.5 seconds

2.5 seconds

Rear seat reminder function

Function

Default setting

Customized setting

Rear seat reminder function

Off

—

Function

Default setting

Customized setting

587

10-2. Customizable features

Vehi

cle

spec

ifi

tions

: This setting changes in accordance with My Settings.

Wireless remote control

Function

Default setting

Customized setting

Unlocking operation

Driver’s door

unlocked in one step,

all doors unlocked in

two step

All doors unlocked in

one step

Panic function

Off

—

Power back door unlocking

operation

Press and hold

(short)

One short press

—

Push twice

Press and hold (long)

Off

Locking operation when door

opened

Off

Driving position memory (if equipped)

Function

Default setting

Customized setting

Driver’s seat movement when

exiting the vehicle

Standard

Off

Partial

Steering wheel movement

Tilt only

Telescopic only

—

Tilt and telescopic

Off

Outside rear view mirrors

Function

Default setting

Customized setting

Automatic mirror folding and

extending operation

Linked to the lock-

ing/unlocking of the

doors

Off

—

Linked to operation

of the power switch

588

10-2. Customizable features

: This setting changes in accordance with My Settings

: This setting changes in accordance with My Settings.

: Except for Canada

Power windows

Function

Default setting

Customized setting

Mechanical key linked opera-

tion

Off

—

Wireless remote control linked

operation

Off

On (open only)

—

ASC (Active Sound Control)

Function

Default setting

Customized setting

ASC (Active Sound Control)

volume

Medium

High

—

Low

Off

Automatic light control system

Function

Default setting

Customized setting

Light sensor sensitivity

Standard

-2 to 2

Time elapsed before head-
lights automatically turn off

after doors are closed

30 seconds

Off

60 seconds

90 seconds

Windshield wiper linked head-

light illumination

Off

—

Lights

Function

Default setting

Customized setting

Daytime running lights

*1*2

Off

Welcome lighting

Off

—

589

10-2. Customizable features

Vehi

cle

spec

ifi

tions

: This setting changes in accordance with My Settings.

Adaptive High-beam System (if equipped)

Function

Customized settings

Adaptive High-beam System

ON/OFF

—

Brightness and illuminated area

adjustment of the high beams accord-

ing to the vehicle speed

9 mph (15 km/h) / 19 mph (30 km/h)

/ 50 mph (80 km/h)

—

Projection distance adjustment of the

low beams according to the distance

to a preceding vehicle

ON/OFF

—

Upper level high beam light distribu-

tion control

ON/OFF

—

Multi weather light system-linked

operation

ON/OFF



Pre-Collision System

Function

Customized setting

Pre-Collision System

ON/OFF

—

Warning timing

Later / Default / Earlier

—

Front Cross Traffic Alert (if equipped)

Function

Customized setting

Front Cross Traffic Alert

ON/OFF

—

Alert timing

Later / Default / Earlier

—

590

10-2. Customizable features

: This setting changes in accordance with My Settings.

Lane Departure Alert system

Function

Customized settings

Lane Departure Alert system

ON/OFF

—

Alert timing

Default / Earlier

—

Alert options

Vibration / Audible

—

Lane Change Assist (if equipped)

Function

Customized setting

Lane Change Assist

ON/OFF

—

Dynamic Radar Cruise Control

Function

Customized setting

Extended Resume Time

ON/OFF

—

Acceleration setting

High / Mid / Low

—

Guide message

ON/OFF

—

Curve speed reduction

High / Mid / Low / OFF

—

Proactive Driving Assist

Function

Customized setting

Proactive Driving Assist (PDA)

ON/OFF

—

Support sensitivity

Low / Mid / High

—

Steering Assist (SA)

ON/OFF

—

591

10-2. Customizable features

Vehi

cle

spec

ifi

tions

: This setting changes in accordance with My Settings.

Deceleration Assist (DA)

ON/OFF

—

Obstacle Anticipation Assist (OAA)

ON/OFF

—

Road Sign Assist

Function

Customized setting

Road Sign Assist

ON/OFF

—

Excess speed notification method

None / Visual / Visual&Audible

—

Other notifications method

None / Visual / Visual&Audible

—

Excess speed notification level

5 mph(10 km/h) / 3 mph(5 km/h) / 1

mph(2 km/h)

—

Driver break suggestion

Function

Customized setting

Driver break suggestion

ON/OFF

—

Traffic Jam Assist (if equipped)

Function

Customized setting

Traffic Jam Assist

ON/OFF

—

Driver Monitor Camera Recording

ON/OFF

—

Driver monitor (if equipped)

Function

Customized setting

Warning function

ON/OFF

—

Function

Customized setting

592

10-2. Customizable features

: This setting changes in accordance with My Settings.

: Parking assist volume is a function that controls the buzzer volume of the intuitive park-

ing assist, RCTA, and RCD all together.

: This setting changes in accordance with My Settings.

Intuitive parking assist (if equipped)

Function

Default setting

Customized setting

Intuitive parking assist

Off

—

Parking assist volume

(if equipped)

Function

Default setting

Customized setting

Parking assist volume

Mid

Low

—

High

BSM (Blind Spot Monitor)

Function

Default setting

Customized setting

Blind spot monitor

Off

—

Alert timing for presence of

approaching vehicle (sensitiv-

ity)

Intermediate

Early

—

Late

Outside rear view mirror indi-

cator brightness

Bright

Dim

—

Buzzer warning

OFF

—

Safe Exit Assist

Function

Default setting

Customized setting

Safe Exit Assist

Off

—

Outside rear view mirrors dis-

play

Off

—

593

10-2. Customizable features

Vehi

cle

spec

ifi

tions

: This setting changes in accordance with My Settings.

: The sound volume is linked among the intuitive parking assist, RCTA, and RCD.

: This setting changes in accordance with My Settings.

Detection sensitivity

Middle

High

—

Low

RCTA (Rear Cross Traffic Alert)

Function

Default setting

Customized setting

RCTA (Rear Cross Traffic

Alert)

Off

—

Buzzer volume of RCTA when

operating

Level 2

Level 1

—

Level 3

RCD (Rear Camera Detection) (if equipped)

Function

Default setting

Customized setting

RCD (Rear camera detection)

Off

—

PKSB (Parking Support Brake) (if equipped)

Function

Default setting

Customized setting

PKSB (Parking Support Brake)

Off

—

Lexus Teammate Advanced Park

(if equipped)

Function

Default setting

Customized setting

Vehicle speed during opera-
tion

Normal

Slow

—

Fast

Function

Default setting

Customized setting

594

10-2. Customizable features

: This settings can be changed on the Advanced Park guidance screen. (



P.379)

Distance to objects

Normal

Far

—

Preferred parking method

Parallel

Perpendicular

—

Preferred parking direction

Forward

Reverse

—

Preferred exit direction (per-
pendicular)

Right

Left

—

Preferred exit direction (paral-
lel)

Left

Right

—

Camera view when parking

Normal

Wide

—

Camera view when exiting

Wide

Normal

—

Parking path adjustment

0 (Centered)

-3 (Inward) to +3

(Outward)

—

Road width adjustment

Normal

Slightly narrow

—

Narrow

Park position adjustment (for-
ward)

0 (Centered)

-3 (Rearward) to 3

(Frontward)

—

Park position adjustment
(reverse)

0 (Centered)

-3 (Rearward) to 3

(Frontward)

—

Rear accessory setting

Off

3.9 in. (10 cm)

—

7.9 in. (20 cm)

11.8 in. (30 cm)

15.7 in. (40 cm)

Clear registered parking space

—

Driving mode select switch

Function

Default setting

Customized setting

Powertrain control in custom

mode

Normal

Sport

—

Eco

Range

Function

Default setting

Customized setting

Lexus RZ450E (2023 year). Manual in english - page 18
