Lexus RZ (2023 year). Manual in english - page 19

601

10

10-2. Customizable features

Veh
icle speci

fic

ations

10-2.Customizable features

■

Set by selecting

Stop the vehicle in a place where oper-
ations can be performed safely,
engage the parking brake, and change
the shift position to P.

1

Select

 on the center display.

2

Select “Vehicle customise” or
“Driving assist”.

3

Select the item to change the set-
tings of from the list.

The setting of each items can be changed.

For details, see the customizable items list.
For functions that can be turned on/off,

select

 (ON)/

 (OFF).

■

Set by selecting

Stop the vehicle in a place where oper-
ations can be performed safely,
engage the parking brake, and change
the shift position to P.

1

Select

 on the center display.

2

Select “Vehicle customise” or
“Driving assist”.

3

Select the item to change the set-
tings of from the list.

The setting of each items can be changed.

For details, see the customizable items list.

Each time

 is selected, the setting is

enabled/disabled.
When enabling is selected, the item display

will be emphasized.

User customization function
outline

Your vehicle includes a variety of
electronic features that can be per-
sonalized to suit your preferences.
The settings of these features can
be changed using the center dis-
play or at any authorized Lexus
retailer or Lexus authorized
repairer, or any reliable repairer.

NOTICE

While performing customization, make

sure that the EV system is operating, in

order to prevent the 12-volt battery from

becoming discharged.

Method to change settings

Changing using the center dis-
play

602

10-2. Customizable features

■

Using the

 icon

Some vehicle customize settings can also
be changed through the

 icon.

603

10

10-2. Customizable features

Veh
icle speci

fic

ations



 Settings that can be changed using the center display



 Settings that can be changed by any authorized Lexus retailer or Lexus

authorized repairer, or any reliable repairer

Definition of symbols: O = Available, — = Not available

The language, units of measure, etc. of some items displayed on the meter or
multi-information display will be changed according to settings on the center dis-
play. Refer to “MULTIMEDIA OWNER’S MANUAL”.

*

: This setting changes in accordance with My Settings.

*

: This setting changes in accordance with My Settings.

Customizable features

Some function settings are changed simultaneously with other functions being
customized. Contact any authorized Lexus retailer or Lexus authorized
repairer, or any reliable repairer for further details.

Gauges, meters and multi-information display

Function

Default setting

Customized setting

Meter display type

*

Type 1

Type 2

O

—

Type 3

Stop light indicator

On

Off

O

—

Suggestion function

*

On

On (when the vehi-

cle is stopped)

O

O

Off

Head-up Display (if equipped)

Function

Default setting

Customized setting

Display

*

On

Off

O

—

Display mode

*

Normal

Maximum

O

—

Minimum

604

10-2. Customizable features

*

: This setting changes in accordance with My Settings.

Steering wheel switches (vehicles with a head-up display)

Function

Default setting

Customized setting

Right steering wheel switch

favorite functions

*

Display control

Driving mode select

switch

O

—

Custom

Left steering wheel switch

favorite functions

*

Audio

Climate

O

—

Custom

Switch sensor high sensitivity

mode (winter glove mode)

*

Off

On

O

—

Door lock

Function

Default setting

Customized setting

Door lock switch indicator illu-

mination time

30 seconds

60 seconds

—

O

600 seconds

1200 seconds

Inside door opener switch

operation adjustment (door

opening function adjustment)

Short

Mid

—

O

Long

Multi-information dis-

play/buzzer operation when a

door opener switch inside the

vehicle is operated

On

Off

—

O

605

10

10-2. Customizable features

Veh
icle speci

fic

ations

*1

: This setting changes in accordance with My Settings

*2

: All doors are automatically unlocked when driver’s door is opened within approximately

45 seconds after turning the power switch off.

Inside/outside door opener

switch operating method

Unlatch while push-

ing switch

0.6 Seconds

—

O

Operating from
inside the cabin:

0.6 Seconds

Operating from out-

side:

Unlatch while push-

ing switch

Operating from
inside the cabin:

Unlatch while push-

ing switch

Operating from out-

side:

0.6 Seconds

Unlocking using a mechanical

key

All doors unlocked in

one step

Driver’s door

unlocked in one step,

all doors unlocked in

two step

—

O

Shift position linked door lock-

ing function

*1

Off

On

O

O

Shift position linked door

unlocking function

*1

Off

On

O

O

Driver’s door linked door

unlocking function

*1,2

On

Off

O

O

Security

Function

Default setting

Customized setting

Intrusion sensor and tilt sensor

*

On

Off

O

—

Function

Default setting

Customized setting

606

10-2. Customizable features

*

: If  equipped

*1

: Configured by operating the

 switch of the lower back door.

*2

: If equipped

*3

: When the towing hitch is installed, the kick sensor does not work

Power back door (if equipped)

Function

Default setting

Customized setting

Back door automatic open and

stop position

5

Stop at the desired

position (height)

*1

O

—

1 to 5

Power back door operations

On

Off

O

—

Operation buzzer volume

3

1

O

—

2

Kick Sensor

*2,3

On

Off

O

—

Kick operation buzzer

*2,3

On

Off

—

O

The function that validates the

 switch of the wire-

less remote control when lock-

ing the door

Off

On

—

O

Close & lock (walk away) func-

tion

On

Off

—

O

Hands free close & lock (walk

away) function

*2

Off

On

—

O

Smart entry & start system and wireless remote control

Function

Default setting

Customized setting

Operation signal (Emergency

flashers)

*

On

Off

O

O

607

10

10-2. Customizable features

Veh
icle speci

fic

ations

*

: This setting changes in accordance with My Settings.

*

: This setting changes in accordance with My Settings.

Time elapsed before automatic

door lock function is activated

if door is not opened after

being unlocked

*

30 seconds

60 seconds

—

O

120 seconds

Open door warning buzzer

On

Off

—

O

Smart entry & start system

Function

Default setting

Customized setting

Smart entry & start system

On

Off

O

O

Smart door unlocking

*

All the doors

Driver’s door

O

O

Time elapsed before unlocking

all the door when gripping and

holding the driver’s door han-

dle

2 seconds

Off

—

O

1.5 seconds

2.5 seconds

Front passenger seat and rear seat reminder function

Function

Default setting

Customized setting

Front passenger seat and rear

seat reminder function

On

Off

O

—

Wireless remote control

Function

Default setting

Customized setting

Unlocking operation

*

All doors unlocked in

one step

Driver’s door

unlocked in one step,

all doors unlocked in

two step

O

O

Function

Default setting

Customized setting

608

10-2. Customizable features

*

: This setting changes in accordance with My Settings.

*

: This setting changes in accordance with My Settings.

Power back door unlocking

operation

Press and hold

(short)

One short press

—

O

Push twice

Press and hold (long)

Off

Driving position memory (if equipped)

Function

Default setting

Customized setting

Driver’s seat movement when

exiting the vehicle

*

Standard

Off

O

O

Partial

Steering wheel movement

*

Tilt only

Telescopic only

O

—

Tilt and telescopic

Off

Outside rear view mirrors

Function

Default setting

Customized setting

Automatic mirror folding and

extending operation

Linked to the lock-

ing/unlocking of the

doors

Off

—

O

Linked to operation

of the power switch

Power windows

Function

Default setting

Customized setting

Mechanical key linked opera-

tion

Off

On

—

O

Wireless remote control linked

operation

Off

On

—

O

Function

Default setting

Customized setting

609

10

10-2. Customizable features

Veh
icle speci

fic

ations

*

: This setting changes in accordance with My Settings

ASC (Active Sound Control)

Function

Default setting

Customized setting

ASC (Active Sound Control)

volume

Medium

High

O

—

Low

Off

Automatic light control system

Function

Default setting

Customized setting

Light sensor sensitivity

*

Standard

-2 to 2

O

O

Extended Headlight lighting
system (time elapsed before

headlights automatically turn

off)

30 seconds

60 seconds

—

O

90 seconds

120 seconds

Lights

Function

Default setting

Customized setting

Welcome lighting

On

Off

—

O

Adaptive High-beam System (if equipped)

Function

Customized settings

Adaptive High-beam System

ON/OFF

—

O

Brightness and illuminated area

adjustment of the high beams accord-

ing to the vehicle speed

15 km/h / 30 km/h / 80 km/h

—

O

Intensity adjustment of the high

beams when driving around a curve
(illuminates the area in the direction

vehicle is turning more brightly)

ON/OFF

—

O

610

10-2. Customizable features

*

: This setting changes in accordance with My Settings.

*

: This setting changes in accordance with My Settings.

Projection distance adjustment of the

low beams according to the distance

to a preceding vehicle

ON/OFF

—

O

Illumination of the cornering lights

when starting off

ON/OFF

—

O

High beam light distribution control

for rain

ON/OFF

—

O

Upper level high beam light distribu-

tion control

ON/OFF

—

O

Light distribution control for urban

areas

ON/OFF

—

O

Multi weather light system-linked

operation

ON/OFF

—

O

Multi Weather Lights (if equipped)

Function

Default setting

Customized setting

Multi Weather Lights

On

Off

—

O

Pre-Collision System

Function

Customized setting

Pre-Collision System

ON/OFF

O

—

Warning timing

*

Later / Default / Earlier

O

—

Front Crossing Traffic Alert (if equipped)

Function

Customized setting

Front crossing traffic alert

ON/OFF

O

—

Alert timing

*

Later / Default / Earlier

O

—

Function

Customized settings

611

10

10-2. Customizable features

Veh
icle speci

fic

ations

*

: This setting changes in accordance with My Settings.

*

: This setting changes in accordance with My Settings.

*

: This setting changes in accordance with My Settings.

Lane Departure Alert system

Function

Customized settings

Lane Departure Alert system

*

ON/OFF

O

—

Alert timing

*

Default / Earlier

O

—

Alert options

*

Vibration / Audible

O

—

Lane Change Assist (if equipped)

Function

Customized setting

Lane Change Assist

*

ON/OFF

O

—

Dynamic Radar Cruise Control / Speed Limiter

Function

Customized setting

Extended Resume Time

*

ON/OFF

O

—

Overtake prevention

*

ON/OFF

O

—

Acceleration setting

*

High / Mid / Low

O

—

Speed setting (short press)

*

1 km/h / 5 km/h / 10 km/h or 1 mph /

5 mph / 10 mph

O

—

Speed setting (long press)

*

1 km/h / 5 km/h / 10 km/h or 1 mph /

5 mph / 10 mph

O

—

DRCC (RSA)

*

ON/OFF

O

—

Speed limit offset

*

-5 to +5

O

—

Guide message

*

ON/OFF

O

—

Curve speed reduction

*

High / Mid / Low / OFF

O

—

612

10-2. Customizable features

*

: This setting changes in accordance with My Settings.

*1

: This setting changes in accordance with My Settings.

*2

: The customized setting varies according to country

Proactive Driving Assist

Function

Customized setting

Proactive Driving Assist (PDA)

*

ON/OFF

O

—

Support sensitivity

*

Low / Mid / High

O

—

Steering Assist (SA)

*

ON/OFF

O

—

Deceleration Assist (DA)

*

ON/OFF

O

—

Obstacle Anticipation Assist (OAA)

*

ON/OFF

O

—

Road Sign Assist

Function

Customized setting

Road Sign Assist

*1

ON/OFF

O

—

Excess speed notification method

*1

None / Visual / Visual&Audible

O

—

Other notifications method

*1

None / Visual / Visual&Audible

O

—

Excess speed notification level

*1*2

10 km/h (5 mph) / 5 km/h (3 mph) /

2 km/h (1 mph)

O

—

Speed limit change notification

*1*2

ON/OFF

O

—

Driver break suggestion

Function

Customized setting

Driver break suggestion

ON/OFF

O

—

613

10

10-2. Customizable features

Veh
icle speci

fic

ations

*

: This setting changes in accordance with My Settings.

*

: This setting changes in accordance with My Settings.

*1

: Parking assist volume is a function that controls the buzzer volume of the Lexus parking

assist-sensor, RCTA, and RCD all together.

*2

: This setting changes in accordance with My Settings.

Driver monitor

Function

Customized setting

Warning function

*

ON/OFF

O

—

Lexus parking assist-sensor

Function

Default setting

Customized setting

Lexus parking assist-sensor

*

On

Off

O

—

Parking assist volume

*1

Function

Default setting

Customized setting

Parking assist volume

*2

Mid

Low

O

—

High

BSM (Blind Spot Monitor)

Function

Default setting

Customized setting

Blind spot monitor

On

Off

O

—

Alert timing for presence of

approaching vehicle (sensitiv-

ity)

Intermediate

Early

O

—

Late

Outside rear view mirror indi-

cator brightness

Bright

Dim

O

—

Buzzer warning

ON

OFF

O

—

614

10-2. Customizable features

*

: This setting changes in accordance with My Settings.

*

: The sound volume is linked among the Lexus parking assist-sensor, RCTA, and RCD.

*

: This setting changes in accordance with My Settings.

*

: This setting changes in accordance with My Settings.

Safe Exit Assist

Function

Default setting

Customized setting

Safe Exit Assist

On

Off

O

—

Outside rear view mirrors dis-

play

*

On

Off

O

—

Detection sensitivity

*

Middle

High

O

—

Low

RCTA (Rear Crossing Traffic Alert)

Function

Default setting

Customized setting

RCTA (Rear Crossing Traffic

Alert)

*

On

Off

O

—

Buzzer volume of RCTA when

operating

*

Level 2

Level 1

O

—

Level 3

RCD (Rear Camera Detection)

Function

Default setting

Customized setting

RCD (Rear camera detection)

*

On

Off

O

—

PKSB (Parking Support Brake)

Function

Default setting

Customized setting

PKSB (Parking Support Brake)

*

On

Off

O

—

615

10

10-2. Customizable features

Veh
icle speci

fic

ations

*1

: This settings can be changed on the Advanced Park guidance screen. (



P.396)

*2

: If equipped

*3

: The default setting varies according to country.

Lexus Teammate Advanced Park

*1

 (if equipped)

Function

Default setting

Customized setting

Remote Park

*2

On

Off

O

—

Vehicle speed during opera-
tion

Normal

Slow

O

—

Fast

Distance to objects

Normal

Far

O

—

Preferred parking method

Parallel

Perpendicular

O

—

Preferred parking direction

Forward

Reverse

O

—

Preferred exit direction (per-
pendicular)

*3

Right

Left

O

—

Preferred exit direction (paral-
lel)

*3

Left

Right

O

—

Camera view when parking

Normal

Wide

O

—

Camera view when exiting

Wide

Normal

O

—

Parking path adjustment

0 (Centered)

-3 (Inward) to +3

(Outward)

O

—

Road width adjustment

Normal

Slightly narrow

O

—

Narrow

Park position adjustment (for-
ward)

0 (Centered)

-3 (Rearward) to 3

(Frontward)

O

—

Park position adjustment
(reverse)

0 (Centered)

-3 (Rearward) to 3

(Frontward)

O

—

Rear accessory setting

Off

10 cm (3.9 in.)

O

—

20 cm (7.9 in.)

30 cm (11.8 in.)

40 cm (15.7 in.)

Clear registered parking space

—

—

O

—

616

10-2. Customizable features

*

: This setting changes in accordance with My Settings

Driving mode select switch

Function

Default setting

Customized setting

Powertrain control in custom

mode

Normal

Sport

O

—

Eco

Range

Steering in custom mode

Normal

Sport

O

—

Air conditioning operation in

customized mode

Normal

Eco

O

—

Range

Automatic air conditioning system

Function

Default setting

Customized setting

Automatic switching between

outside air mode and recircu-

lated air mode when the

AUTO switch is on (AUTO

switch linked air mode chang-

ing)

*

On

Off

O

O

Automatic turning on of the

A/C switch when the AUTO

switch is turned on (AUTO

switch linked A/C switch)

*

On

Off

O

O

Steering wheel heater temper-

ature adjustment in AUTO

mode

*

Standard

-2 (cooler) to 2

(warmer)

O

O

Driver's seat seat heater/venti-

lator temperature adjustment

in AUTO mode

*

Standard

-2 (cooler) to 2

(warmer)

O

O

Front passenger's seat seat

heater/ventilator temperature

adjustment in AUTO mode

*

Standard

-2 (cooler) to 2

(warmer)

O

O

617

10

10-2. Customizable features

Veh
icle speci

fic

ations

Illumination

Function

Default setting

Customized setting

Time elapsed before the lights

turn off

*1

15 seconds

Off

O

O

7.5 seconds

30 seconds

Operation after the power

switch is turned off

On

Off

—

O

Operation when you approach

the vehicle with the electronic

key on your person

On

Off

—

O

Operation when the doors are

unlocked

On

Off

—

O

Footwell lights

On

Off

—

O

Door-trim ornament lights,

inside handle lights and center

auxiliary box lights

On

Off

—

O

Time elapsed before the outer

foot lights turn off

*1

15 seconds

Off

O

O

7.5 seconds

30 seconds

Operation of the outer foot

lights when you approach the

vehicle with the electronic key

on your person

On

Off

—

O

Operation of the outer foot

lights when the doors are

unlocked

On

Off

—

O

Operation of the outer foot

lights when a door is opened

On

Off

—

O

Fading out of the outer foot

lights when they turn off

Long

Short

—

O

Operation of interior lights and

outer foot lights after the doors

are locked

On

Off

—

O

618

10-2. Customizable features

*1

: This setting changes in accordance with My Settings

*2

: If equipped

Color selection

*1,2

Silky white

Custom

O

—

Brightness control

*1,2

Maximum

Desired brightness

O

—

Charging system

Function

Default setting

Customized setting

Charging current

Max

16A

O

—

8A

Charging limit

Full

90%

O

—

80%

70%

60%

50%

DC charging power

Max

125 kW

O

—

100 kW

75 kW

50 kW

Battery cooler

On

Off

O

—

Power switch

Function

Customized setting

ACC customization

Enabling/Disabling ACC mode

On/Off

O

—

Function

Default setting

Customized setting

619

10

10-3. Initialization

Veh
icle speci

fic

ations

10-3.Initialization

Items to initialize

Must be initialized for normal sys-
tem operation after such cases as
the 12-volt battery being recon-
nected, or maintenance being per-
formed on the vehicle:

Item

When to ini-

tialize

Reference

Power back

door (if

equipped)



After
recon-
necting or
changing
the 12-volt
battery

P.112

Lexus park-

ing

assist-moni-

tor (if

equipped)



After
recon-
necting or
changing
the 12-volt
battery

Refer to

“MULTIME-

DIA

OWNER’S

MANUAL”.

Panoramic
view moni-

tor (if

equipped)



After
recon-
necting or
changing
the 12-volt
battery

Refer to

“MULTIME-

DIA

OWNER’S

MANUAL”.

Tire pressure

warning sys-

tem



When the
specified
tire infla-
tion pres-
sure has
changed,
such as
due to car-
ried load,
etc.



When the
tire infla-
tion pres-
sure is
changed
such as
when the
tire size is
changed.

P.474

Item

When to ini-

tialize

Reference

620

10-3. Initialization

621

Index

.

Supplement .................................

622

Alphabetical Index ...................

626

622

Supplement

1-1.Supplement

Supplement

Both genuine Lexus and a wide variety
of other spare parts and accessories
for Lexus vehicles are currently availa-
ble in the market. Should it be deter-
mined that any of the genuine Lexus
parts or accessories supplied with the
vehicle need to be replaced, Lexus
recommends that genuine Lexus parts
or accessories, be used to replace
them. Other parts or accessories of
matching quality can also be used.
Lexus cannot accept any liability or
guarantee spare parts and accessories
which are not genuine Lexus products,
nor for replacement or installation
involving such parts. In addition, dam-
age or performance problems result-
ing from the use of non-genuine Lexus
spare parts or accessories may not be
covered under warranty.
Also, remodeling like this will have an
effect on advanced safety equipment
such as Lexus Safety System + and
there is a danger that it will not work
properly or the danger that it may work
in situations where it should not be
working.

Installing electronic devices and radios
increases the risk of cyber attacks
through the installed parts, which may

lead to unexpected accidents and
leakage of personal information.
Lexus does not make any guarantees
for problems caused by installing
non-genuine Lexus products.

This vehicle is equipped with sophisti-
cated computers that record certain
data regarding vehicle controls and
operations.

■

Data recorded by the computers

Certain data, such as the following, is
recorded depending on the operation
timing and status of each function.



Electric motor speed (traction
motor speed)



Accelerator status



Brake status



Vehicle speed



Operation status of the driving
assist systems



Images from the cameras

Your vehicle is equipped with cameras.
Contact any authorized Lexus retailer or
Lexus authorized repairer, or any reliable
repairer for the location of recording cam-
eras.

The recorded data varies according to
the vehicle grade level, options and
destinations with which it is equipped.
These computers do not record con-
versations or sounds, and only record

Accessories, spare parts and
modification of your Lexus

Cyber Attack Risk

Vehicle data recording

623

Supplement

images outside of the vehicle in certain
situations.

■

Data usage

Lexus may use the data recorded in
this computer to diagnose malfunc-
tions, conduct research and develop-
ment, and improve quality.
Lexus will not disclose the recorded
data to a third party except:



With the consent of the vehicle
owner or with the consent of the les-
see if the vehicle is leased



In response to an official request by
the police, a court of law or a gov-
ernment agency



For use by Lexus in a lawsuit



For research purposes where the
data is not tied to a specific vehicle
or vehicle owner

Image information recorded by the vehicle

can be erased by any authorized Lexus

retailer or Lexus authorized repairer, or any

reliable repairer.
The image recording function can be disa-

bled. However, if the function is disabled,

data from when systems operate will not be

available.
If you wish to stop the collection of Lexus

Safety System + data by the Toyota servers

for the purpose of research and develop-

ment and provision to individual services,

contact any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer.

This vehicle is equipped with an event
data recorder (EDR). The main pur-
pose of an EDR is to record, in certain
crash or near crash-like situations, such
as an airbag deployment or hitting a
road obstacle, data that will assist in
understanding how a vehicle’s systems
performed. The EDR is designed to
record data related to vehicle dynam-
ics and safety systems for a short
period of time, typically 30 seconds or
less. However, data may not be
recorded depending on the severity
and type of a crash.
The EDR in this vehicle is designed to
record such data as:
• How various systems in your vehicle

were operating;

• How far (if at all) the driver was

depressing the accelerator and/or
brake pedal; and,

• How fast the vehicle was traveling.
These data can help provide a better
understanding of the circumstances in
which crashes and injuries occur.
NOTE: EDR data are recorded by your
vehicle only if a non-trivial crash situa-
tion occurs; no data are recorded by
the EDR under normal driving condi-
tions and no personal data (e.g., name,
gender, age, and crash location) are
recorded. However, other parties, such
as law enforcement, could combine the
EDR data with the type of personally

Event data recorder

624

Supplement

identifying data routinely acquired dur-
ing a crash investigation.
To read data recorded by an EDR, spe-
cial equipment is required, and access
to the vehicle or the EDR is needed. In
addition to the vehicle manufacturer,
other parties, such as law enforcement,
that have the special equipment, can
read the information if they have
access to the vehicle or the EDR.



Disclosure of the EDR data

Lexus will not disclose the data recorded in
an EDR to a third party except when:
• An agreement from the vehicle’s owner

(or the lessee for a leased vehicle) is
obtained

• In response to an official request by the

police, a court of law or a government
agency

• For use by Lexus in a lawsuit
However, if necessary, Lexus may:
• Use the data for research on vehicle

safety performance

• Disclose the data to a third party for

research purposes without disclosing
information about the specific vehicle or
vehicle owner

The installation of an RF-transmitter
system in your vehicle could affect
electronic systems such as:



EV system



Lexus Safety System +



Anti-lock brake system



SRS airbag system



Seat belt pretensioner system

Be sure to check with any authorized
Lexus retailer or Lexus authorized
repairer, or any reliable repairer for
precautionary measures or special
instructions regarding installation of an
RF-transmitter system.
Further information regarding fre-
quency bands, power levels, antenna
positions and installation provisions for
the installation of RF-transmitters, is
available on request at any authorized
Lexus retailer or Lexus authorized
repairer, or any reliable repairer.
High voltage parts and cables on the
battery electric vehicles emit approxi-
mately the same amount of electro-
magnetic waves as the conventional
gasoline powered vehicles or home
electronic appliances despite of their
electromagnetic shielding.
Unwanted noise may occur in the
reception of the radio frequency trans-
mitter (RF-transmitter).

The SRS airbag and seat belt
pretensioner devices in your Lexus
contain explosive chemicals. If the

Precautions for installation of an
RF-transmitter system

Precautions for scrapping your
Lexus

625

Supplement

vehicle is scrapped with the airbags
and seat belt pretensioners left as they
are, this may cause an accident such as
fire. Be sure to have the systems of the
SRS airbag and seat belt pretensioner
removed and disposed of by any
authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer before you scrap your vehicle.

The word “QR Code” is registered
trademark of DENSO WAVE
INCORPORATED in Japan and other
countries.

“QR code”

626

Alphabetical Index

Alphabetical Index

A

A/C

Air conditioning filter............................... 468
Front automatic air conditioning system

.........................................................................209

Front seat concentrated airflow mode

(S-Flow) ........................................................212

My Room Mode............................................64

ABS (Anti-lock Brake System) ............. 268
AC charging .................................................... 50
AC charging cable

If the AC charging connector cannot be

unlocked ........................................................ 43

If the charging connector cannot be

unlocked .....................................................570

ACA (Active Cornering Assist)........... 268
ACCESSORY mode..................................149
Acoustic Vehicle Alerting System...........29
Active Cornering Assist (ACA)........... 268
Adaptive High-beam System .................. 172
Advanced Park.............................................387
AHB.................................................................... 175
AHS .................................................................... 172
Air conditioning filter................................. 468
Air conditioning system

Air conditioning filter............................... 468
Defogger.........................................................185
Front automatic air conditioning system

.........................................................................209

Front seat concentrated airflow mode

(S-Flow) ........................................................212

Airbag manual on-off system.....................82
Airbags

Airbag manual on-off system.................82
SRS airbags ..................................................428

Alarm ...................................................................97

Warning buzzer........................................500

Antennas (smart entry & start system)...87
Anti-lock Brake System (ABS) ............. 268

ABS warning light .....................................502

Approach warning ..................................... 330
Automatic headlight leveling system.... 172
Automatic headlight leveling system

(Headlight)

Function ............................................................172

Automatic High Beam................................ 175
Automatic light control system ...............170
Automatic Rear Flashing Hazard Lights

..........................................................................422

B

Back door...........................................................112

If the back door cannot be opened...561

Back-up light

Replacing light bulbs...............................590

Battery (12-volt battery)

If the 12-volt battery is discharged ... 533
Preparing and checking before winter

........................................................................... 187

Battery (traction battery)

Charging................................................. 50, 55
Location............................................................. 27
Traction battery cooler ..............................44
Traction battery heater...............................44

Battery Electric Vehicle driving tips........34
Brake

Brake system warning light..................500
Fluid..................................................................599
Regenerative braking .................................28

Brake assist.................................................... 268
Brake hold

Brake hold operated indicator...........509
Warning messages....................................515

Buzzer

Driver monitor............................................ 283

Buzzers

Open window warning............................108

627

Alphabetical Index

C

Camera

Driver monitor.............................................283

Card key.............................................................84
Care

Seat belts........................................................454
Wheels and wheel ornaments............452

Catch protection function.........................108
Center console light ...................................222
Charging

AC charging...................................................50
Charging components..............................38
Charging methods ...................................... 44
Charging procedure ........................ 50, 55
Charging schedule function ...................59
Charging time may increase ..................49
Charging tips..................................................46
DC charging...................................................55
Display.............................................. 46, 63, 64
If the charging port lid cannot be opened

.........................................................................563

Information related to charging display

.......................................................... 46, 63, 64

Locking and unlocking the AC charging

connector...................................................... 42

My Room Mode............................................64
Opening and closing the charging port

lids .....................................................................40

Safety functions.............................................. 47
Things to know before charging .......... 47
When charging cannot be carried out

.......................564, 565, 566, 567, 569

Charging equipment.................................... 38
Charging methods .........................................44

AC charging...................................................50
DC charging...................................................55

Charging port lid

If the charging port lid cannot be opened

.........................................................................563

Charging ports

Charging port lid ..........................................38
Locking and unlocking the AC charging

connector ......................................................42

Opening and closing..................................40

Charging schedule function.......................59

Setting.................................................................63

Charging tips ....................................................46
Charging-linked functions

My Room Mode............................................44
Traction battery cooler ..............................44
Traction battery heater...............................44

Child restraint system

Points to remember.....................................67
Riding with children .....................................66

Child safety........................................................66

Child restraint system.................................67
Installing child restraints.............................67
Power window lock switch......................110
Seat belt extender precautions............ 133
Seat belt precautions ..................................66

Child-protector lock......................................66
Cleaning

Seat belts........................................................454
Wheels and wheel ornaments............452

Clock.................................................................247
Coolant

Checking...........................................463, 465

Cornering lights............................................. 172

Lights..................................................................172
Replacing light bulbs...............................590

Courtesy lights

Location.......................................................... 222

Cruise control

Dynamic radar cruise control................321

Curtain shield airbags............................... 428
Customizable features ...............................601

D

Daytime running light system...................170

628

Alphabetical Index

DC charging .....................................................55
Defogger

Outside rear view mirrors......................186
Rear window defogger............................186
Windshield.....................................................185

Digital Rear-view Mirror............................136
Dimension...................................................... 594
DIRECT4 ....................................................... 268
Display

Charging......................................... 46, 63, 64
Dynamic radar cruise control .............324
Lexus parking assist-sensor...................361
RCD (Rear Camera Detection)........375

Distance to empty............................ 247, 259
Do-it-yourself maintenance.................... 458
Door

Child-protector lock...................................66
If a door cannot be opened ................ 559
Smart entry & start system.......................87

Door courtesy lights

Location.......................................................... 222

Door trim ornament lights........................222
Doors

Door lock switches......................................95
Impact detection door lock release sys-

tem....................................................................93

Double locking system .................................96
Driver’s and front passenger’s seat belt

reminder light ............................................ 503

Driver’s seat position memory

Memory recall function ..........................206

Drive-Start Control (DSC)

Sudden start restraint control.............. 427

Driving

Battery Electric Vehicle driving tips.... 34
Winter drive tips..........................................189

Driving position memory

Memory recall function .............205, 206
Position memory........................................205

Driving time........................................259, 263

Dynamic radar cruise control..................321

Warning message.................................... 330

E

eCall ................................................................. 438

“SOS” button............................................... 438

ECB (Electronically Controlled Brake Sys-

tem)................................................................ 268

EDR (Event data recorder)......................623
EDSS .................................................................349
Electric motor (traction motor)

Location............................................................. 27

Electric Power Steering (EPS).............. 268
Electric power steering system

Electric power steering system warning

light................................................................503

Electric Vehicle system features ..............27
Electric Vehicle system precautions...... 30
Electricity consumption..... 258, 259, 263
Electronic key...................................................84

Battery-saving function..............................84
If the electronic key does not operate

properly............................................532, 551

Replacing the battery.............................. 552

Electronically Controlled Brake System

(ECB)............................................................ 268

Emergency brake signal ...........................269
Emergency Driving Stop System..........349
Emergency flashers

Switches..........................................................497

Emergency shut off system......................499
Emergency towing ..................................... 578
Emergency, in case of

A warning light turns on/flashes .......500
If a warning message is displayed......510
If the battery is discharged ................... 533
If the electronic key does not operate

properly............................................532, 551

If the EV system will not start...531, 533,

538, 539

629

Alphabetical Index

If the vehicle is submerged or water on

the road is rising..................................... 498

If you have a flat tire................................. 540
If your vehicle overheats....................... 586
Stopping the vehicle in an emergency

.........................................................................497

Towing with a tow truck.........................576
Towing with another vehicle................578
Using a flatbed truck................................ 577

EPS (Electric Power Steering).............. 268
EV system

Acoustic Vehicle Alerting System....... 29
Battery Electric Vehicle driving tips.... 34
Driving range..................................................36
Electric Vehicle system precautions...30
Emergency shut off system..........33, 499
Features..............................................................27
How to use AC charging.........................50
How to use DC charging.........................55
If the EV system will not start...531, 533,

538, 539

Overheating................................................ 586
Power (ignition) switch............................ 148
Regenerative braking.................................28
Starting the EV system............................. 148

Event data recorder (EDR)......................623
Extended Headlight Lighting system......171

Headlights .........................................................171

F

FAST/ECO..................................................... 212
FCTA..................................................................315
FCTA (Front Crossing Traffic Alert)....315
Flat tire

Emergency tire puncture repair kit . 540

Floor mats...........................................................26
Fluid

Brake............................................................... 599
Transmission ...................................598, 599
Washer .......................................................... 468

Fog lights...........................................................192
Footwell lights................................................222
Front automatic air conditioning system

......................................................................... 209

Front Cross Traffic Alert............................315
Front Crossing Traffic Alert (FCTA)....315
Front fog lights................................................192

Replacing light bulbs...............................590

Front position lights

Light switches ............................................... 170

Front seats........................................................129

Adjustment..................................................... 129
Head restraints.............................................130
Memory recall function..............205, 206
Power easy access system ...................204

Front side marker lights

Light switch .................................................... 170
Replacing light bulbs...............................590

Front turn signal lights (bulb type)

Replacing light bulbs...............................590

Fuses

Replacing ......................................................589

G

Gauges

Changing the instrument panel light

brightness...................................................264

Displayed content......................................257
Head-up display........................................ 255
Indicators........................................................246
Multi-information display ...........252, 253
Warning lights.............................................244

H

Hands Free Power Back Door................ 122
Head restraints...............................................130
Headlight

Cleaner ............................................................183
Replacing light bulbs...............................590

630

Alphabetical Index

Headlight switch

Light switches................................................170

Headlights

Extended Headlight Lighting system..171

Head-up display .......................................... 255
Heated steering wheel ............................... 216
Heater coolant

Preparing and checking before winter

...........................................................................187

Heaters

Front automatic air conditioning system

.........................................................................209

Outside rear view mirrors......................186
Traction battery heater .............................. 44

High mounted stoplight

Replacing light bulbs............................... 590

Hill-start assist control............................... 268
Hood .................................................................. 461

Open..................................................................461

Hooks

Retaining hooks (floor mat)..................... 26

Horn....................................................................193

I

Identification

Vehicle............................................................594

If the 12-volt battery is discharged.........551
Ignition switch (power switch)

Changing the power switch modes ..149
How to start the EV system .................. 148

Immobilizer system ........................................95
Impact detection door lock release system

.............................................................................93

Indicators

Charging indicator ........................................41

Initialization

Items to initialize .......................................... 619

Inside handle lights ......................................222
Inside rear view mirror................................136
Inspection........................................................472

Installing a CRS to a front passenger seat

............................................................................ 68

Interior lights ..................................................223

J

Jack

Lifting the vehicle with a floor jack ... 484
Vehicle-equipped jack...........................488

Jack handle....................................................488
Jam protection function..............................108

Power back door.......................................... 112

K

Key

If a key has been lost .................................551
Keyless entry ...................................................87

Keyless entry

Smart entry & start system .......................87

Keys ......................................................................84

Electronic key .................................................84
If the electronic key does not operate

properly............................................532, 551

Knee airbags................................................. 428

L

Lane Change Assist.....................................301
Lane change Assist (LCA)........................301
Lane Departure Alert (LDA)................. 305
Lane Tracing Assist.....................................296
LCA....................................................................301
LCA (Lane change Assist)........................301
LDA (Lane Departure Alert)................. 305
Lever

Auxiliary catch lever .................................. 461
Hood lock release lever.......................... 461
Wiper lever......................................................181

Lexus Climate Concierge.......................208
Lexus parking assist-sensor

Function ........................................................... 361

631

Alphabetical Index

Lexus parking assist-sensor OFF indica-

tor ..................................................................508

Warning message.....................................362

Lexus Safety System + ...............................275

Driver monitor.............................................283
Dynamic radar cruise control ...321, 336
FCTA (Front Crossing Traffic Alert) 315
LCA (Lane change Assist).................... 301
LDA (Lane Departure Alert).............. 305
LTA (Lane Tracing Assist)....................296
PCS (Pre-Collision System)................285
PDA (Proactive driving assist)............. 310
RSA (Road Sign Assist)........................... 318
Speed limiter ................................................342

Lexus Teammate Advanced Park ........387
License plate lights

Headlight switch...........................................170
Replacing light bulbs............................... 590

Light bulbs

Replacing...................................................... 590

Lights

Emergency flashers..................................497
Fog light............................................................192
Headlight switch...........................................170

Linked mirror function when reversing144
Lock

Smart entry & start system.......................87
Window lock switch....................................110

Locking and unlocking the AC charging

connector........................................................42

LTA ....................................................................296

M

Maintenance

Do-it-yourself maintenance .................459
Maintenance data......................................594
Maintenance requirements ..................457

Max cool...........................................................213
Max heat........................................................... 212
Memory recall function............................ 205

Meter

Changing the instrument panel light

brightness...................................................264

Displayed content......................................257
Head-up display........................................ 255
Indicators........................................................246
Multi-information display ...........252, 253
Warning lights.............................................244

Mirror

Digital Rear-view Mirror ......................... 136
Inside rear view mirror............................. 136

Mirrors

Outside rear view mirrors...................... 144

Moter compartment

Steam comes out from under the hood

.........................................................................586

Multi Weather Lights

Switch..................................................................191

Multi-information display

Charging.........................................46, 63, 64
Dynamic radar cruise control..............324
Operating......................................................257
Warning messages....................................510

My Room Mode ..............................................64

Starting My Room Mode..........................64

My Settings.................................................... 202

N

nanoe™ X ........................................................ 214

O

Odometer

Changing/resetting................................... 251
Function ..........................................................247

Opener

Hood................................................................. 461

Outer foot lights ...........................................222
Outside rear view mirrors.........................144

Adjustment..................................................... 144
Folding/extending...................................... 145

632

Alphabetical Index

Heaters ............................................................ 186
RCTA function............................................369

Outside temperature .................................247
Overheating.................................................. 586

P

Paddle shift switches......................................161
Panic mode........................................................94
Parking assist sensors (Lexus parking

assist-sensor)...............................................361

Parking brake .................................................165

Parking brake engaged warning buzzer

.......................................................................... 165

Parking brake indicator......................... 509

Parking lights

Light switch.....................................................170

Parking Support Brake function (for

rear-crossing vehicles).......................... 384

Function..........................................................384

Parking Support Brake function (rear

pedestrians)................................................ 385

Function......................................................... 385

Parking Support Brake function (static

objects)......................................................... 382

Function..........................................................382

PCS (Pre-Collision System)

Function..........................................................285
PCS warning light .................................... 506

PDA (Proactive driving assist) ................310
Personal lights ...............................................224
PKSB (Parking Support Brake) .............378
Power (ignition) switch

Changing the power switch modes ..149
How to start the EV system .................. 148

Power back door.............................................112

Adjusting the open position of the back

door.................................................................127

Hands Free Power Back Door ............122
Jam protection function..............................112

Power control unit coolant

Capacity ............................................597, 598
Checking........................................................463
Preparing and checking before winter

........................................................................... 187

Radiator...........................................................464

Power outlets...................................... 230, 231
Power steering (Electric power steering

system) ......................................................... 268

Power switch

Stopping the vehicle in an emergency

..........................................................................497

Power windows

Door lock linked window operation.109
Jam protection function...........................108
Operation.......................................................109
Window lock switch....................................110

Pre-Collision System (PCS)

Function ......................................................... 285

R

Radar cruise control (dynamic radar cruise

control)...........................................................321

Radiant heaters.............................................. 217
Radiator

Overheating................................................586

Rain-sensing windshield wipers............... 181
RCD (Rear Camera Detection)

Function ..........................................................374

RCTA function............................................. 369
Rear doors

If the rear doors cannot be opened from

the inside......................................................561

Rear fog lights.................................................192

Replacing light bulbs...............................590

Rear passengers’ seat belt reminder light

......................................................................... 504

Rear seats.........................................................130

Head restraints.............................................130
