Lexus RZ (2023 year). Manual in english

121

1-6. Loading luggage

fore
driving

■

Hands Free Power Back Door operating

conditions (if equipped)

●

The Hands Free Power Back Door (kick

sensor) setting is on.

●

When an electronic key is carried within

the operation range.

■

Situations in which the Hands Free

Power Back Door may not operate

properly (if equipped)

In the following situations, the Hands Free

Power Back Door may not operate prop-

erly:

●

When a foot remains under the rear

bumper

●

If the rear bumper is strongly hit with a

foot or is touched for a while

If the rear bumper has been touched for a

while, wait for a short time before attempt-

ing to operate the back door again.

Back door operations using the
kick sensor (vehicles with Hands
Free Power Back Door)

NOTICE

The kick sensor is located behind lower

center part of the rear bumper.

Observe the following to ensure that the

power back door operates properly:

●

Keep the lower center part of the rear

bumper clean at all times.

If the lower center part of the rear

bumper is dirty or covered with snow, the

kick sensor may not operate.
In this situation, clean off the dirt or snow,

move the vehicle from the current posi-

tion and then check if the kick sensor

operates.
If it does not operate, have the vehicle

inspected by any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer.

●

Do not apply coatings that have a rain

clearing (hydrophilic) effect, or other

coatings, to the lower center part of

the rear bumper.

●

Do not park the vehicle near objects

that may move and contact the lower

center part of the rear bumper, such as

grass or trees.

If the vehicle has been parked for a while

near objects that may move and contact

the lower center part of the rear bumper,

such as grass or trees, the kick sensor

may not operate.
In this situation, move the vehicle from

the current position and then check if the

kick sensor operates.
If it does not operate, have the vehicle

inspected by any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer.

●

Do not subject the kick sensor or its

surrounding area to a strong impact.

If the kick sensor or its surrounding area

has been subjected to a strong impact,

the kick sensor may not operate prop-

erly.
If the kick sensor does not operate in the

following situations, have the vehicle

inspected by any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer.
• The kick sensor or its surrounding area

has been subjected to a strong impact.

• The lower center part of the rear

bumper is scratched or damaged.

●

Do not disassemble the rear bumper.

●

Do not attach stickers to the rear

bumper.

●

Do not paint the rear bumper.

●

If a bicycle carrier or similar heavy

object is attached to the power back

door, disable the Hands Free Power

Back Door (kick sensor).

122

1-6. Loading luggage

●

When operated while a person is too

close to the rear bumper

●

When an external radio wave source

interferes with the communication

between the vehicle and electronic key

●

When the vehicle is parked near metal, or

an external radio wave or electrical noise

source which affects the sensitivity of the

Hands Free Power Back Door, such as a

pay parking spot, gas station, electrically

heated road, fluorescent light, or metal

plate

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When mud, snow or ice is attached to the

rear bumper

●

When the vehicle has been parked for a

while near objects that may move and

contact the rear bumper, such as plants

●

When an accessory is installed to the rear

bumper

If an accessory has been installed, turn the

Hands Free Power Back Door (kick sen-

sor) operation setting off.

■

Preventing unintentional operation of

the Hands Free Power Back Door (if

equipped)

When an electronic key is in the operation

detection area, the Hands Free Power Back

Door may operate unintentionally, so be

careful in the following situations:

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When dirt is wiped off the rear bumper

●

When a small animal or small object, such

as a ball, moves under the rear bumper

●

When an object is moved from under the

rear bumper

●

If someone is swinging their legs while sit-

ting on the rear bumper

●

If the legs or another part of someone’s

body contacts the rear bumper while

passing by the vehicle

●

When the vehicle is parked near an elec-

trical noise source which affects the sen-

sitivity of the Hands Free Power Back

Door, such as a pay parking spot, gas sta-

tion, electrically heated road, or fluores-

cent light

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When the vehicle is parked in a place

where objects such as plants are near the

rear bumper

●

If luggage is set near the rear bumper

●

If accessories or a vehicle cover is

installed/removed near the rear bumper

●

When the vehicle is being towed

To prevent unintentional operation, turn the

Hands Free Power Back Door (kick sensor)

operation setting off.

While carrying an electronic key,
stand within the smart entry & start
system operation range, approxi-

Open/close the back door using the
kick sensor (vehicles with Hands
Free Power Back Door)

WARNING

Observe the following precautions when

operating the power back door.

●

Check the safety of the surrounding

area to make sure there are no obsta-

cles or anything that could cause any

of your belongings to get caught.

●

Do not operate the Hands Free Power

Back Door if there is little space under

the rear bumper.

123

1-6. Loading luggage

fore
driving

mately 50 to 70 cm (19.7 to 27.6
in.) from the rear bumper.

Kick sensor
Hands Free Power Back Door
operation detection area
Smart entry & start system opera-
tion detection area (



P.87)

Perform a kick operation by mov-
ing your foot to within approxi-
mately 10 cm (3.9 in.) of the rear
bumper, and then pulling your foot
back after the buzzer sounds.



Perform the entire kick operation
within 1 second.



The Hands Free Power Back Door
will not start operating while a foot is
detected under the rear bumper.



Operate the Hands Free Power
Back Door without contacting the
rear bumper with your foot.



If another electronic key is in the
cabin or luggage compartment, it
may take slightly longer than normal
for the operation to occur.



If the buzzer sounds twice, perform

a kick operation again.

Kick sensor
Hands Free Power Back Door
operation detection area

When the kick sensor detects that
your foot is pulled back, a buzzer
will sound and the power back door
will automatically fully open/close.

If kick operation is performed again in the

middle of back door operating, the opera-

tion will stop.

When all of the doors are locked, if a kick

operation is detected by the kick sensor, all

of the doors will unlock.

: If equipped

: This setting can be customized by any

authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

A
B

Back door operations using the
kick sensor (vehicles with Hands
Free close & lock [Walk-Away]
function)

*1, 2

NOTICE

The kick sensor is located behind lower

center part of the rear bumper.

A
B

124

1-6. Loading luggage

■

Hands Free close & lock (Walk-Away)
function

operating conditions

: If equipped

: This setting can be customized by any

authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

This function can be operated when all of

the following conditions are met:

●

Hands Free close & lock (Walk-Away)
function is enabled

●

Hands Free Power Back Door

is ena-

bled.

●

An electronic key is not detected within

the vehicle.

●

All of the doors other than the back door

are closed.

NOTICE

Observe the following to ensure that the

power back door operates properly:

●

Keep the lower center part of the rear

bumper clean at all times.

If the lower center part of the rear

bumper is dirty or covered with snow, the

kick sensor may not operate.
In this situation, clean off the dirt or snow,

move the vehicle from the current posi-

tion and then check if the kick sensor

operates.
If it does not operate, have the vehicle

inspected by any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer.

●

Do not apply coatings that have a rain

clearing (hydrophilic) effect, or other

coatings, to the lower center part of

the rear bumper.

●

Do not park the vehicle near objects

that may move and contact the lower

center part of the rear bumper, such as

grass or trees.

If the vehicle has been parked for a while

near objects that may move and contact

the lower center part of the rear bumper,

such as grass or trees, the kick sensor

may not operate.
In this situation, move the vehicle from

the current position and then check if the

kick sensor operates.
If it does not operate, have the vehicle

inspected by any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer.

●

Do not subject the kick sensor or its

surrounding area to a strong impact.

If the kick sensor or its surrounding area

has been subjected to a strong impact,

the kick sensor may not operate prop-

erly.
If the kick sensor does not operate in the

following situations, have the vehicle

inspected by any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer.
• The kick sensor or its surrounding area

has been subjected to a strong impact.

• The lower center part of the rear

bumper is scratched or damaged.

●

Do not disassemble the rear bumper.

●

Do not attach stickers to the rear

bumper.

●

Do not paint the rear bumper.

●

If a bicycle carrier or similar heavy

object is attached to the power back

door, disable the Hands Free Power

Back Door (kick sensor).

125

1-6. Loading luggage

fore
driving

●

The power switch is off.

●

The electronic key is within the effective

range (detection areas).

■

Situations in which the Hands Free close
& lock (Walk-Away) function

*1, 2

may

not operate properly

: If equipped

: This setting can be customized by any

authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

In the following situations, the function may

not operate properly:

●

When the smart entry & start system

does not operate properly.

●

When the close & lock function does not

operate properly.

●

When moving away from the back door

while the Hands Free close & lock

(Walk-Away) function is in the standby

state.

●

When the Hands Free Power Back Door
does not operate properly.

: If equipped

: This setting can be customized by any

authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

While carrying an electronic key,
stand within the smart entry & start
system operation range, approxi-

mately 50 to 70 cm (19.7 to 27.6
in.) from the rear bumper.

Kick sensor
Hands Free Power Back Door
operation detection area
Smart entry & start system opera-
tion detection area (



P.87)

Perform a kick operation by mov-
ing your foot to within approxi-
mately 10 cm (3.9 in.) of the rear
bumper, and then pulling your foot
back after the buzzer sounds.



Perform the entire kick operation
within 1 second.



The Hands Free Power Back Door
will not start operating while a foot is
detected under the rear bumper.



Operate the Hands Free Power
Back Door without contacting the
rear bumper with your foot.



If another electronic key is in the
cabin or luggage compartment, it
may take slightly longer than normal
for the operation to occur.



If the buzzer sounds twice, perform

Closing and locking the back door
after moving away from the back
door using the kick sensor (Hands
Free close & lock [Walk-Away] func-
tion)

*1, 2

A
B

126

1-6. Loading luggage

a kick operation again.

Kick sensor
Hands Free Power Back Door
operation detection area

When the kick sensor detects that
your foot is pulled back, a different
buzzer than the normal one will
sound and the Hands Free close &
lock (Walk-Away) function will go
into standby.

While the buzzer is sounding, move
away from the back door.

When the sensor detects that you are away

from the back door, the emergency flash-

ers will flash. Depending on the direction of

moving away from the back door, the loca-

tion and how to hold the electronic key or

circumstances, it may not be detected

properly.
All the doors other than the back door will

be locked, and after the back door is

closed, the back door will also be locked.

When all the doors have been closed and

locked, the emergency flashers will flash.
The standby state is canceled if you do not

move away from the back door for 30 sec-

onds. To operate the function again, per-

form the procedure again from the

beginning.
If you approach the back door carrying the

electronic key, the back door operation will

stop, all the doors will be unlocked, and the

emergency flashers will flash.

If the power back door is operated after

the back door operation has stopped, the

Hands Free close & lock (Walk-Away)

function will go into standby again.

This function reserves the locking of
the power back door when the power
back door is open.

If the following operations are per-
formed, all of the doors except the
power back door will lock and then the
power back door will lock when it is
completely closed.

Close all of the doors, except the
power back door.

Perform an automatic closing oper-
ation of the power back door and
lock the doors using the wireless
remote control (



P.118) or smart

entry & start system (



P.116) while

the power back door is closing.

Operation signals will indicate that all
the doors have been closed and
locked.



If the electronic key is placed inside
the vehicle after starting a close
operation via the door reserve lock
function, the electronic key may
become locked inside the vehicle.



If the back door does not fully close
due to the operation of the jam pro-

A
B

Back door reserve lock function
(vehicles with the power back
door)

Reserves the locking of the all the
doors

127

1-6. Loading luggage

fore
driving

tection function, etc., while the back
door is automatically closing after a
reserve lock operation is per-
formed, the reserve lock function is
canceled and all the doors will
unlock.



Before leaving the vehicle, make
sure that all the doors are closed
and locked.

The open position of the power back
door can be adjusted.

Stop the back door in the desirable
position.

Press and hold the

switch

on the lower part of the back door
for approximately 2 seconds.

When the settings are completed, the
buzzer sounds 4 times.
When opening the back door the next
time, the back door will stop at that
position.

Press and hold the

switch on

the lower part of the back door for
approximately 7 seconds.
After the buzzer sounds 4 times, it
sounds twice more.
When the power back door does the
opening operation the next time, the

door will open to the initial settings
position.

Folding the seat backs can be done
with the lever operations.

Adjusting the open position of the
back door (vehicles with the
power back door)

Canceling the adjusted open posi-
tion of the back door

Rear seat seatbacks

WARNING

■

When operating the rear seatback

Observe the following precautions.

●

Do not operate the rear seat if it is

occupied.

●

After adjusting the seat, make sure that

the seat is locked in position. If the

seatback is not securely locked, the

red marking will be visible. Make sure

that the red marking is not visible.

■

When a rear seatback is folded

Observe the following precautions.

●

Do not fold down the rear seatbacks

while driving.

●

Stop the vehicle on level ground, apply

the parking brake and change the shift

position to P.

●

Do not allow anyone to sit on a folded

rear seatback or in the luggage com-

partment while driving.

●

Do not allow children to enter the lug-

gage compartment.

128

1-6. Loading luggage

Stow the rear center seat belt, seat
belt buckles and armrest.

Lower the head restraint of the rear
seat.

Pull the seatback angle adjustment
lever and fold down the seatback.

Raise the rear seatback until it
locks.

Check that the plate for each seat
belt is on the front side of the seat.

WARNING

■

After adjusting the rear seats

Observe the following precautions.

●

Make sure that the rear seatback is

securely locked in position by lightly

pushing it back and forth.

If the seatback is not securely locked, the

red marking will be visible. Make sure

that the red marking is not visible.

●

Check that the seat belts are not

twisted or caught between or behind

in the rear seatback.

NOTICE

The seat belt for the rear center seat, seat

belt buckles and armrest must be stowed

before you fold down the rear seatbacks.

Fold the rear seatbacks

Return the rear seatbacks

129

1-7. Obtaining the correct driving posture

fore
driving

1-7.Obtaining the correct driving posture

Adjust the seat forward/backward and
up/down as necessary to obtain a cor-
rect posture.



Adjust the angle of the seatback so
that you are sitting straight up and so
that you do not have to lean forward
to steer.



Adjust the seat so that you can
depress the pedals fully and so that
your arms bend slightly at the elbow
when gripping the steering wheel.



Power seat

Seat position adjustment switch
Seat cushion (front) angle adjust-
ment switch
Seatback angle adjustment switch
Vertical height adjustment switch
Lumbar support firmness adjust-
ment switch (for driver’s side)



Manual seat

Seat position adjustment lever
Seatback angle adjustment lever
Vertical height adjustment lever

■

When adjusting the seats

Take care so that a head restraint does not

contact the ceiling or a sun visor.

Adjusting the seats

Adjusting the front seats

A
B

C
D

WARNING

Observe the following when adjusting

the seats.

●

Do not adjust the position of the

driver’s seat while driving.

Doing so could cause the driver to lose

control of the vehicle.

●

Be careful so that the seat does not

contact and injure a passenger.

●

Do not place anything under the front

seats.

Objects placed under the front seats

may become jammed in the seat tracks

and stop the seat from locking in place.

This may lead to an accident and the

adjustment mechanism may also be

damaged.

●

Do not put your hands under the seat

or near the moving parts to avoid

injury.

Fingers or hands may become jammed in

the seat mechanism.

A
B
C

130

1-7. Obtaining the correct driving posture

Reclining adjustments and folding the
seat backs can be done with the levers.

Reclining adjustment

Head restraints are provided for all
seats.

WARNING

●

Manual seat: After adjusting the seat,

make sure that the seat is locked in

position.

●

To reduce the risk of sliding under the

lap belt during a collision, do not

recline the seat more than necessary.

If the seat is reclined excessively, in a col-

lision, one may slide under the lap belt

and it may apply restraint forces directly

to the abdomen, etc., or their neck may

contact the shoulder belt.

●

Do not place a cushion between the

driver or passenger and the seatback.

A cushion may prevent correct posture

from being achieved, and reduce the

effectiveness of the seat belt and head

restraint.

Adjusting the rear seats

WARNING

Observe the following when adjusting

the seatbacks.

●

Keep other passengers from being hit

with the seatback.

●

Do not bring your hands close to the

moving parts or between the seats, as

well as do not let any part of your body

get caught.

●

To reduce the risk of sliding under the

lap belt during a collision, do not

recline the seat more than necessary.

If the seat is reclined excessively, in a col-

lision, one may slide under the lap belt

and it may apply restraint forces directly

to the abdomen, etc., or their neck may

contact the shoulder belt.

Adjusting the head restraints

WARNING

Observe the following precautions

regarding the head restraints. Failure to

do so may result in death or serious

injury.

●

Use the head restraints designed for

each respective seat.

●

Adjust the head restraints to the cor-

rect position at all times.

●

After adjusting the head restraints,

push down on them and make sure

they are locked in position.

●

Do not drive with the head restraints

removed.

131

1-7. Obtaining the correct driving posture

fore
driving

■

Adjusting the front seat head
restraints vertically

Pull the head restraints up.

Down

Push the head restraint down while press-
ing the lock release button

■

Adjusting the rear seat head
restraints vertically

Pull the head restraints up.

Down

Push the head restraint down while press-
ing the lock release button

■

Adjusting the height of the head

restraints

Make sure that the head restraints are

adjusted so that the center of the head

restraint is closest to the top of your ears

■

Adjusting the height of the head

restraints

When the rear seat is to be used, make sure

the head restraint is at least one step above

the storage position.



Front seats

Pull the head restraint up while press-
ing the lock release button .
If the head restraint touches the ceiling,
making the removal difficult, change
the seat height or angle.

Removing the head restraints

133

1-7. Obtaining the correct driving posture

fore
driving



Extend the shoulder belt so that it
comes fully over the shoulder, but
does not come into contact with the
neck or slide off the shoulder.



Position the lap belt as low as possi-
ble over the hips.



Adjust the position of the seatback.
Sit up straight and well back in the
seat.



Do not twist the seat belt.

Using the seat belts

Make sure that all occupants are
wearing their seat belts before driv-
ing the vehicle.

WARNING

Observe the following precautions to

reduce the risk of injury in the event of

sudden braking, sudden swerving or an

accident. Failing to do so may cause

death or serious injury.

●

Ensure that all passengers wear a seat

belt.

●

Always wear a seat belt properly.

●

Each seat belt should be used by one

person only.

Do not use a seat belt for more than one

person at once, including children.

●

Lexus recommends that children be

seated in the rear seat and always use

a seat belt and/or an appropriate child

restraint system.

●

To achieve a proper seating position,

do not recline the seat more than nec-

essary. The seat belt is most effective

when the occupants are sitting up

straight and well back in the seats.

●

Do not wear the shoulder belt under

your arm.

●

Always wear your seat belt low and

snug across your hips.

●

Women who are pregnant should con-

sult their doctor for any precautions

for wearing the seat belt correctly.

Position the lap belt as low as possible

over the hips in the same manner as

other occupants, extending the shoulder

belt completely over the shoulder and

avoiding belt contact with the rounding

of the abdominal area.

If the seat belt is not worn properly, not

only the pregnant woman, but also the

fetus could suffer death or serious injury

as a result of sudden braking or a colli-

sion.

134

1-7. Obtaining the correct driving posture

■

Child seat belt usage

The seat belts of your vehicle were princi-

pally designed for persons of adult size.

●

Use a child restraint system appropriate

for the child, until the child becomes large

enough to properly wear the vehicle’s

seat belt.

●

When the child becomes large enough to

properly wear the vehicle’s seat belt, fol-

low the instructions regarding seat belt

usage.

■

Seat belt regulations

If seat belt regulations exist in the country

where you reside, please contact any

authorized Lexus retailer or Lexus author-

ized repairer, or any reliable repairer for

seat belt replacement or installation.

To fasten the seat belt, push the
plate into the buckle until a click
sound is heard.

To release the seat belt, press the
release button .

■

Emergency locking retractor (ELR)

The retractor will lock the belt during a sud-

den stop or on impact. It may also lock if you

lean forward too quickly. When the seat belt

locks, pull the belt strongly and then release

the belt, then a slow and easy pulling will

allow the belt to extend.

WARNING

●

Persons with a medical condition

should consult their doctor for any

precautions for wearing the seat belt

correctly.

●

Inspect the seat belt system periodi-

cally. Check for cuts, fraying, and loose

parts. Do not use a damaged seat belt

until it is replaced. Damaged seat belts

cannot protect an occupant from

death or serious injury.

●

Replace the seat assembly, including

the belts, if your vehicle has been

involved in a serious accident, even if

there’s no obvious damage.

●

Do not attempt to install, remove,

modify, disassemble or dispose of the

seat belts. Have any necessary repairs

carried out by any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer. Inappropriate

handling may lead to incorrect opera-

tion.

●

Do not allow children to play with the

seat belt.

If the seat belt becomes twisted around a

child's neck, it may lead to choking or

other serious injuries that could result in

death.
If this occurs and the buckle cannot be

unfastened, scissors should be used to

cut the belt.

Fastening and releasing the seat
belts

WARNING

●

Do not damage the seat belts by allow-

ing the belt, plate, or buckle to be

jammed in the door.

●

Ensure that the belt and plate are

locked and the belt is not twisted.

If the seat belt does not function cor-

rectly, immediately contact any author-

ized Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

135

1-7. Obtaining the correct driving posture

fore
driving

Push the seat belt shoulder anchor
down while pressing the release
button .

Push the seat belt shoulder anchor
up.

Move the height adjuster up and down as
needed until you hear a click.

Hold the steering wheel and push
the lever down.

Adjust to the ideal position by mov-
ing the steering wheel horizontally
and vertically.

After adjustment, pull the lever up to

secure the steering wheel.

■

After adjusting the steering wheel

Make sure that the steering wheel is

securely locked.

Adjusting the height of the front
seat belts

WARNING

■

Adjustable shoulder anchor

Always make sure the shoulder belt is

positioned across the center of your

shoulder. The belt should be kept away

from your neck, but not falling off your

shoulder. Failure to do so could reduce

the amount of protection in an accident

and cause death or serious injuries in the

event of a sudden stop, sudden swerve or

accident.

Adjusting the position of the
steering wheel and mirrors

Adjusting the position of the
steering wheel horizontally/ver-
tically (Manual type)

WARNING

Do not adjust the steering wheel while

driving.

136

1-7. Obtaining the correct driving posture

The horn may not sound if the steering

wheel is not securely locked.

Operating the switch moves the steer-
ing wheel in the following directions:

Down

Toward the driver

Away from the driver

■

The steering wheel can be adjusted

when

The power switch is in ACC or ON.

: If the driver’s seat belt is fastened, the

steering wheel can be adjusted regard-
less of power switch mode.

■

Automatic adjustment of the steering

position

A desired steering position can be entered

to memory and recalled automatically by

the driving position memory system.

■

Power easy access system (if equipped)

The steering wheel and driver’s seat move

in accordance with power switch mode and

the driver’s seat belt condition.

Adjust the position of the inside rear
view mirror so that the correct driving
posture can be achieved.

Adjust the inside rear view mirror verti-
cally by grasping and moving it.

The Digital Rear-view Mirror is a sys-
tem that uses the camera on the rear of
the vehicle and displays its image on
the display of the Digital Rear-view
Mirror.

WARNING

After adjusting the steering wheel, make

sure that the steering wheel is securely

locked.

Otherwise, the steering wheel may move

suddenly.

Adjusting the position of the
steering wheel horizontally/ver-
tically (Power type)

WARNING

Do not adjust the steering wheel while

driving.

Adjusting the position of the
inside rear view mirror

WARNING

Do not adjust the position of the mirror

while driving.

Digital Rear-view mirror effort
and caution (if equipped)

137

1-7. Obtaining the correct driving posture

fore
driving

The Digital Rear-view Mirror can be
changed between optical mirror mode
and digital mirror mode by operating
the lever.
The Digital Rear-view Mirror allows the
driver to see the rear view despite
obstructions, such as the head
restraints or luggage, ensuring rear vis-
ibility. Also, the rear seats are not dis-
played and privacy of the passengers is
enhanced.

Camera indicator

Indicates that the camera is operating nor-
mally.

Icon display area

Displays icons, adjusting gauge, etc.

Select/adjust button

Press to change the setting of the item you
want to adjust. (



P.139)

Menu button

Press to display the icon display area and
select the item you want to adjust.

Lever

Operate to change between digital mirror
mode and optical mirror mode.

Digital mirror anti-glare function
indicator

Displayed in digital mirror mode when the
anti-glare function of the digital mirror is
enabled. (



P.139)

Operate the lever to change between
digital mirror mode and optical mirror
mode.

WARNING

■

Before using the Digital Rear-view

Mirror

Observe the following precautions. Fail-

ure to do so may result in death or seri-

ous injury.

●

Make sure to adjust the mirror before

driving.

• Change to optical mirror mode and

adjust the position of the Digital

Rear-view Mirror so that the area

behind your vehicle can be viewed

properly.

• Change to digital mirror mode and

adjust the display settings.

●

As the range of the image displayed by

the Digital Rear-view Mirror is differ-

ent from that of the optical mirror,

make sure to check this difference

before driving.

System components of the Digi-
tal Rear-view Mirror

Changing modes of the Digital
Rear-view Mirror

138

1-7. Obtaining the correct driving posture

Digital mirror mode

Displays an image of the area behind the
vehicle.

will illuminate in this mode.

Optical mirror mode

Turns off the display of the Digital Rearview
Mirror allows it to be used as an optical
mirror.

The power switch is turned to ON.
When the power switch is changed
from ON to OFF or ACC, the image
will disappear after several seconds.

If it is difficult to see the Digital
Rear-view Mirror image because
water, snow, mud, etc. is stuck to the
camera lens, operate the rear window
washer (



P.183) or change to optical

mirror mode.



When the back door is open, the
Digital Rear-view Mirror image may
not display properly. Before driving,
make sure the back door is closed.



If the display is difficult to see due to
reflected light, in this case, change
to optical mirror mode.



Any of the following conditions may
occur when driving in the dark, such
as at night. None of them indicates
that a malfunction has occurred.

• Colors of objects in the displayed image

may differ from their actual color.

• Depending on the height of the lights of

the vehicle behind, the area around the
vehicle may appear white and blurry.

• Automatic image adjustment for

brighter surrounding image may cause
flickering.

If it is difficult to see the displayed image or
flickering bothers you, change to optical
mirror mode.



The Digital Rear-view Mirror may
become hot while it is in digital mir-
ror mode. This is not a malfunction.



Depending on your physical condi-
tion or age, it may take longer than
usual to focus on the displayed
image. In this case, change to opti-
cal mirror mode.



Do not let passengers stare at the
displayed image when the vehicle is
being driven, as doing so may cause
motion sickness.

■

When the system malfunctions

If the symbol shown in the illustration is
displayed when using the Digital
Rear-view Mirror in digital mirror
mode, the system may be malfunction-
ing. The symbol will disappear in a few
seconds.

Digital mirror mode operating
condition

Precautions about digital mirror
mode

139

1-7. Obtaining the correct driving posture

fore
driving

Operate the lever, change to optical
mirror mode and have the vehicle
inspected by any authorized Lexus
retailer or Lexus authorized repairer,
or any reliable repairer.

Settings of the display in the digital mir-
ror mode, on/off operation of the auto-
matic anti-glare function, etc. can be
changed.

Press the menu button.

The icons will be displayed.

Press the menu button repeatedly
and select the item you want to
adjust.

Press

change the setting.

The icons will disappear if a button is not

operated for approximately 5 seconds or

more.

Adjusting the Digital Rear-view
Mirror

Icons

Settings

Select to adjust the

brightness of the dis-

play.

Select to adjust the

area displayed

up/down.

Select to adjust the

area displayed to the

left/right.

Select to adjust the

angle of the dis-

played image.

Select to zoom

in/out the displayed

image.

140

1-7. Obtaining the correct driving posture

: This is a function for the optical mirror

mode, however, the setting can also be
changed while using the digital mirror
mode.

■

Display settings (digital mirror
mode)



The icons will disappear if a button is

not operated for approximately 5
seconds or more.



If the displayed image is adjusted, it
may appear distorted. This is not a
malfunction.



If the brightness of the Digital
Rear-view Mirror is set too high, it
may cause eye strain. Adjust the
Digital Rear-view Mirror to an
appropriate brightness. If your eyes
become tired, change to optical
mirror mode.



The brightness of the Digital
Rear-view Mirror will change auto-
matically according to the bright-
ness of the area in front of your
vehicle.



The anti-glare function of the digital
mirror is operational only when the
surrounding area of the vehicle is
dark enough. Depending on the
brightness conditions of the sur-
rounding area, the brightness of the
displayed image on the digital mir-
ror may not be reduced, not ena-
bling to reduce the headlight glare
of the following vehicle.

■

To prevent the light sensors from
malfunctioning

To prevent the light sensors from mal-
functioning, do not touch or cover
them.

Select to enable/dis-

able the automatic

anti-glare function.

Responding to the

brightness of the

headlights of vehi-

cles behind, the

reflected light is

automatically

adjusted.

The automatic

anti-glare function is

enabled each time

the power switch is

changed to ON.

The anti-glare func-

tion of the digital

mirror can be ena-

bled/disabled.

When enabled,

image on the digital

mirror at nighttime

will be displayed at a

reduced brightness

level, reducing the

headlight glare of

the following vehi-

cle.

Precautions when adjusting the
Digital Rear-view Mirror

Icons

Settings

141

1-7. Obtaining the correct driving posture

fore
driving

■

Cleaning the mirror surface

If the mirror surface is dirty, the image
on the display may be difficult to see.
Wipe the mirror surface gently using a
soft dry cloth.

■

Cleaning the camera

If it is difficult to see the Digital
Rear-view Mirror image because
water, snow, mud, etc. is stuck to the
camera lens, operate the rear window
washer or change to optical mirror
mode. (



P.137)

■

The camera

The camera for the Digital Rear-view Mir-

ror is located as shown.

■

Cleaning the camera with washer fluid

●

When cleaning the camera, it may be dif-

ficult to see the image due to the washer

fluid. Therefore, take care in the sur-

rounding area while driving.

●

If washer fluid remains on the camera

lens surface after cleaning, the image

may be difficult to see at night due to the

height or inclination of the headlights of

the vehicle behind. In this case, change to

optical mirror mode.

●

Some dirts may not be removed com-

pletely after cleaning. In this case, rinse

the camera lens with a large quantity of

water and then wipe it clean with a soft

cloth dampened with water.

●

Washer fluid is sprayed onto the camera

lens surface. Therefore, the ice, snow, etc.

adhering around the camera cannot be

removed.

WARNING

■

While driving

Observe the following precautions. Fail-

ure to do so may result in death or seri-

ous injury.

●

Do not adjust the position of the Digital

Rear-view Mirror or adjust the display

settings while driving.

Stop the vehicle and operate the Digital

Rear-view Mirror control switches. Fail-

ure to do so may cause a steering wheel

operation error, resulting in an unex-

pected accident.

●

Always pay attention to the vehicle’s

surroundings.

The size of the vehicles and other objects

may look different when in digital mirror

mode and optical mirror mode. When

backing up, make sure to directly check

the safety of the area around your vehi-

cle, especially behind the vehicle. Addi-

tionally, if a vehicle approaches from the

rear in the dark, such as at night, the sur-

rounding area may appear dim.

Cleaning the Digital Rear-view
Mirror

142

1-7. Obtaining the correct driving posture

If you notice any of the following symptoms, refer to the following table for the likely
cause and the solution.
If the symptom is not resolved by the solution, have the vehicle inspected by any
authorized Lexus retailer or Lexus authorized repairer, or any reliable repairer.

NOTICE

■

To prevent the camera from malfunc-

tioning

●

Observe the following precautions,

otherwise the Digital Rear-view Mirror

may not operate properly.

• Do not strike or hit the camera or sub-

ject it to a strong impact, as the camera

installation position and angle may be

changed.

• Do not remove, disassemble or modify

the camera.

• When washing the camera, rinse it

with a large quantity of water and then

wipe it clean with a soft cloth damp-

ened with water. Do not strongly rub

the camera lens, as it may be

scratched and will not be able to trans-

mit a clear image.

• Do not allow organic solvent, car wax,

window cleaner or glass coat to

adhere to the camera cover. If this hap-

pens, wipe it off as soon as possible.

• Do not apply hot water to the camera

in cold weather, as the sudden change

of temperature may cause the camera

to not operate properly.

• When using a high pressure washer to

wash the vehicle, do not directly spray

the camera and its surrounding area,

as doing so may cause the camera to

not operate properly.

●

Do not subject the camera to a strong

impact as this could cause a malfunc-

tion. If this happens, have the vehicle

inspected by any authorized Lexus

retailer or Lexus authorized repairer,

or any reliable repairer as soon as pos-

sible.

●

Do not block the vent holes of the mir-

ror. Otherwise, the mirror may be hot,

leading to a malfunction or a fire.

If you notice any symptoms about the Digital Rear-view Mirror

143

1-7. Obtaining the correct driving posture

fore
driving

Symptom

Likely cause

Solution

The image is
difficult to see.

The mirror surface is dirty.

Clean the mirror surface gently, using a
soft dry cloth.

Sunlight or headlights are shin-
ing directly into the Digital
Rear-view Mirror.

Change to optical mirror mode.



The vehicle is in a dark area.



The vehicle is near a TV
tower, broadcasting station,
electric power plant, or other
location where strong radio
waves or electrical noise may
be present.



The temperature around the
camera is extremely high/low.



The ambient temperature is
extremely low.



It is raining or humid.



Sunlight or headlights are
shining directly into the cam-
era lens.



The vehicle is under fluores-
cent lights, sodium lights,
mercury lights, etc.

Change to optical mirror mode. (Change
back to digital mirror mode when the
conditions have improved.)

Foreign matters such as water
droplets or dust is on the cam-
era lens.



Operate the dedicated camera clean-
ing washer and clean the camera
lens.(



P.183)



Change to optical mirror mode.

The image is
out of align-
ment.

The back door is not fully
closed.

Fully close the back door.

The camera or its surrounding
area has received a strong
impact.

Change to optical mirror mode and have
the vehicle inspected by any authorized
Lexus retailer or Lexus authorized
repairer, or any reliable repairer.

The display is
dim and

is displayed.

The system may be malfunction-
ing.

Change to optical mirror mode and have
the vehicle inspected by any authorized
Lexus retailer or Lexus authorized
repairer, or any reliable repairer.

goes off.

144

1-7. Obtaining the correct driving posture

To select a mirror to adjust, press
the switch.

Select the left mirror
Select the right mirror

To adjust the mirror, press the
switch.

Adjust the mirror surface up
Adjust the mirror surface right
Adjust the mirror surface down
Adjust the mirror surface left

■

Mirror angle can be adjusted when

The power switch is in ACC or ON.

is dis-

played.

The Digital Rear-view Mirror is
extremely hot. (The display will
gradually become more dim. If
the temperature continues to
increase, the Digital Rear-view
Mirror will turn off.)

Reducing the cabin temperature is rec-
ommended to reduce the temperature of
the mirror. (

will disappear when the

mirror becomes cool.)

does not disappear even though

the mirror is cool, have the vehicle
inspected by any authorized Lexus
retailer or Lexus authorized repairer, or
any reliable repairer.

The lever can-
not be oper-
ated properly.

The lever may be malfunction-
ing.

Change to optical mirror mode and have
the vehicle inspected by any authorized
Lexus retailer or Lexus authorized
repairer, or any reliable repairer.
To change to optical mirror mode, press
and hold the menu button for approxi-
mately 10 seconds.

Symptom

Likely cause

Solution

Adjusting the angle of the out-
side rear view mirrors

WARNING

Do not adjust the position of the mirror

while driving.

A
B

A
B
C
D

145

1-7. Obtaining the correct driving posture

fore
driving

■

Automatic adjustment of the mirror

angle (vehicles with driving position

memory)

A desired mirror face angle can be entered

to memory and recalled automatically by

the driving position memory.

■

Linked mirror function when reversing

When the mirror select switch is in the “L” or

“R” position, the outside rear view mirrors

will automatically angle downwards when

the vehicle is reversing in order to give a

better view of the ground.
To disable this function, move the mirror

select switch to the neutral position

(between “L” and “R”)
With the shift position in R, adjust the mirror

angle at a desired position to set the mirror

angle used when the vehicle is reversing.
The adjusted angle will be memorized and

the mirror will automatically tilt to the mem-

orized angle whenever the shift position is

shifted to R from next time.
The memorized downward tilt position of

the mirror is linked to the normal position

(angle adjusted with the shift position in

other than R). Therefore, if the normal posi-

tion is changed after adjustment, the tilt

position will also change.
When the normal position is changed, read-

just the angle in reversing.

■

Using the reverse-linked function when

it is cold

When reverse-linked function used in cold

weather, the door mirror could be frozen

and may not automatically point the mirror

surface downward. In this event, remove

any ice and snow from the mirror surface.



Using the switch

Press the switch to fold the mirrors.
Press it again to extend them to the
original position.



Setting automatic mode

Automatic mode allows the folding or
extending of the mirrors to be linked to
locking/unlocking of the doors.
Press the switch to set automatic
mode.

The indicator will come on.
Pressing the switch once more will
return to manual mode.

■

When using the outside rear view mir-

rors in a cold weather

When it is cold and the outside rear view

Folding/extending the outside
rear view mirrors

146

1-7. Obtaining the correct driving posture

mirrors are frozen, it may not be possible to

fold/extend them or adjust the mirror sur-

face. Remove the ice, snow, etc. covering

the outside rear view mirrors.

■

Customization

Some functions can be customized.

(



P.608)

WARNING

Observe the following precautions.

●

Do not drive with the mirrors folded.

●

Do not touch an outside rear view mir-

ror when it is moving. Failure to do so

may lead to your finger being pinched

or the mirror being damaged.

●

As the mirror surface will be hot, do

not touch an outside rear view mirror

when the mirror heater is operating.

●

Both the driver and passenger side

mirrors must be extended and prop-

erly adjusted before driving.

147

Driving the vehicle

2-1. Starting and stopping the EV sys-

tem

Starting the EV system.............

148

Stopping the EV system...........

151

2-2. Driving procedures

Driving procedure.....................

152

Breaking in your new Lexus ..

154

Intended use of each shift position

.........................................................

155

Changing the shift position ....

156

Starting off.....................................

159

Informing the driver of the vehi-

cle’s dynamic conditions through
sounds..........................................

160

Operations when turning left or

right or changing lanes .........

160

Changing the regenerative brak-

ing power.....................................

161

2-3. Parking the vehicle

When parking the vehicle ......

163

Stopping.........................................

164

Parking the vehicle....................

165

148

2-1. Starting and stopping the EV system

2-1.Starting and stopping the EV system

Performing the following operations
when carrying the electronic key on
your person starts the EV system or
changes power switch modes.

Check that the charging cable is
disconnected.

Pull the parking brake switch to
check that the parking brake is set.
(



P.167)

The parking brake indicator will come on.

Firmly depress the brake pedal.

and a message will be displayed on

the multi-information display. If it is not dis-

played, the EV system cannot be started.
When the shift position is N, the EV system

cannot start. Shift the shift position to P

when starting the EV system. (



P.148)

Press the power switch shortly and
firmly.

When operating the power switch, one

short, firm press is enough. It is not neces-

sary to press and hold the switch.
If the “READY” indicator turns on, the EV

system will operate normally.
Continue depressing the brake pedal until

the “READY” indicator is illuminated.
The EV system can be started from any

power switch mode.

Check that the “READY” indicator
is illuminated.

The vehicle will not move when the

“READY” indicator is off.

■

Power switch illumination

According to the situation, the power

Starting the EV system

Starting the EV system

WARNING

■

When starting the EV system

Always start the EV system while sitting

in the driver’s seat. Do not depress the

accelerator pedal while starting the EV

system under any circumstances.

■

Caution while driving

If EV system failure occurs while the

vehicle is moving, do not lock or open the

doors until the vehicle reaches a safe and

complete stop. Otherwise, the steering

lock function (if equipped) will activate

and this may lead to an accident, result-

ing in death or serious injury.

NOTICE

■

When starting the EV system

If the EV system becomes difficult to

start, have your vehicle checked by any

authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer immediately.

■

Operation of the power switch

If the power switch seems to be operat-

ing somewhat differently than usual, such

as the switch sticking slightly, there may

be a malfunction. Contact any author-

ized Lexus retailer or Lexus authorized

repairer, or any reliable repairer immedi-

ately.

149

2-1. Starting and stopping the EV system

Driving the vehicle

switch illumination operates as follows.

●

If a door is open or the power switch is

turned from ACC or ON to OFF, the

power switch light will illuminate dimly.

●

If the brake pedal is depressed while car-

rying an electronic key, the power switch

light will illuminate brightly.

●

When the power switch is in ACC or

ON, the power switch illumination illumi-

nates.

■

If the EV system does not start

●

The immobilizer system may not have

been deactivated. Contact any author-

ized Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

●

The charging cable may be connected to

the vehicle.

●

If a message related to start-up is shown

on the multi-information display, read the

message and follow the instructions.

●

If the door is unlocked with the mechani-

cal key, the EV system cannot be started

using the smart entry & start system.

Refer to P.532to start the EV system.

However, if the electronic key is carried

inside the vehicle and the doors are

locked (



P.93), the EV system can be

started.

■

When the ambient temperature is low,

such as during winter driving conditions

●

When starting the EV system, the flashing

time of the “READY” indicator may be

long. Leave the vehicle as it is until the

“READY” indicator is steady on, as

steady means the vehicle is able to move.

●

When the EV battery (traction battery) is

extremely cold (below approximately

-30°C [-22°F]) under the influence of

the outside temperature, it may not be

possible to start the EV system. In this

case, try to start the EV system again

after the temperature of the EV battery

increases due to the outside temperature

increase etc.

■

Steering lock function

After turning the power switch off and

opening and closing the doors, the steering

wheel will be locked due to the steering

lock function. Operating the power switch

again automatically cancels the steering

lock.

■

If the “READY” indicator does not come

In the event that the “READY” indicator

does not come on even after performing

the proper procedures for starting the vehi-

cle, contact any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer immediately.

■

Operation of the power switch

●

If the switch is not pressed shortly and

firmly, the power switch mode may not

change or the EV system may not start.

●

If attempting to restart the EV system

immediately after turning the power

switch off, the EV system may not start in

some cases. After turning the power

switch off, please wait a few seconds

before restarting the EV system.

Modes can be changed by pressing
the power switch with brake pedal
released. (The mode changes each
time the switch is pressed.)

Changing the power switch
mode

150

2-1. Starting and stopping the EV system

OFF

The emergency flashers can be used.

ACC

Some electrical components such as the
audio system can be used. “ACCESSORY”
will be displayed on the meter.

All electrical components can be used.
“POWER ON” will be displayed on the
meter.

: ACC mode can be enabled/disabled on

the customize menu. (



P.618)

■

When ACC customization is in off

●

With the power switch is turned off, the

center display can still be used for a cer-

tain time until the battery saving function

starts operating.

●

When the safe exit assist is operating, a

buzzer will sound and a voice guidance

will be given.

■

Auto power off function

●

If the vehicle is left in ACC or ON (the

EV system is not operating) for more than

20 minutes with the shift position in P, the

power switch will automatically turn to

OFF.

●

If the 12-volt battery is low with the shift

position is in P and the power switch is in

ACC or ON (the EV system is not oper-

ating). The power switch is automatically

turn to OFF.

However, this function cannot entirely pre-

vent the 12-volt battery discharge. Do not

leave the vehicle with the power switch in

ACC or ON for long periods of time when

the EV system is not operating.

■

When the shift control system malfunc-

tions

When attempting to turn the power switch

off while there is a malfunction in the shift

control system, the power switch mode may

change to ACC. In this case, ACC may be

turned off by applying the parking brake

and pressing the power switch again.
If there is a malfunction in the system, have

the vehicle inspected by any authorized

Lexus retailer or Lexus authorized repairer,

or any reliable repairer. immediately.

NOTICE

Do not leave the vehicle with the power

switch in ACC or ON for long periods of

time when the EV system is not operat-

ing.

If “ACCESSORY” or “POWER ON” is

displayed on the meters while the EV

system is not operating, the power switch

is not off. Exit the vehicle after turning the

power switch off.

151

2-1. Starting and stopping the EV system

Driving the vehicle

Stop the vehicle completely.

Set the parking brake. (



P.165)

Check the parking brake indicator is illumi-

nated.

Press the P position switch.
(



P.156)

Check that the shift position indicator

shows P and the parking brake indicator is

illuminated.

Press the power switch shortly and
firmly.

The EV system will stop, and the meter dis-

play will be extinguished (the shift position

indicator will be extinguished a few sec-

onds after the meter display).

Release the brake pedal and check
that “ACCESSORY” or “POWER
ON” is not shown on the meter.

Stopping the EV system

Stopping the EV system

WARNING

If you want to stop the EV system in an

emergency while driving the vehicle,

press and hold the power switch for more

than 2 seconds, or press it briefly 3 times

or more in succession.

However, do not touch the power switch

while driving, except in an emergency.

Turning the EV system off while driving

will not cause loss of steering or braking

control, however power assist to the

steering will be lost. This will make it

more difficult to steer. Pull over and stop

the vehicle as soon as it is safe to do so.

152

2-2. Driving procedures

2-2.Driving procedures

Driving procedure

WARNING

■

When driving the vehicle

●

If the vehicle is coasting due to the EV

system being stopped, etc., do not

operate the door locks or open a door

until the vehicle has been safely

stopped. Doing so may cause the

steering lock function (if equipped) to

operate, possibly leading to an acci-

dent.

●

When backing up, you may twist your

body around, leading to difficulty in

operating the pedals.

Make sure to operate the pedals prop-
erly.

●

Make sure to keep a correct driving

posture even when moving the vehicle

only slightly. This allows you to depress

the brake and accelerator pedals

properly.

●

Depress the brake pedal using your

right foot.

Depressing the brake pedal using your
left foot may delay response in an emer-
gency, resulting in an accident.

●

The driver should pay extra attention

to pedestrians. As there is no engine

noise, the pedestrians may misjudge

the vehicle’s movement. Even though

the vehicle is equipped with the

Acoustic Vehicle Alerting System,

drive with care as pedestrians in the

vicinity may still not notice the vehicle if

the surrounding area is noisy.

●

Never turn the power switch off during

normal driving. If the EV system is

stopped while driving, steering and

brake operations will still be possible,

however, power assist will no longer be

provided and the steering wheel will

become difficult to operate. After

checking the safety of the area around

your vehicle, stop the vehicle on the

side of the road. In an emergency, if the

vehicle cannot be stopped normally,

perform an emergency stop.

●

Use regenerative braking to maintain

a safe speed when driving down a

steep hill. Using the brakes continu-

ously may cause the brakes to over-

heat and lose effectiveness.

●

If “Regenerative Braking Limited Press

Brake to Decelerate” appears on the

multi-information display, firmly

depress the brake pedal to decelerate

the vehicle. (



P.530)

●

Do not adjust the positions of the

steering wheel, the seat, or the inside

or outside rear view mirrors while driv-

ing. Doing so may result in a loss of

vehicle control.

●

Always check that all passengers’

arms, heads or other parts of their

body are not outside the vehicle.

●

This vehicle is not designed for

extreme off-roading.

• When driving in sand or mud is una-

voidable, drive carefully and avoid

continuous driving on sand or mud.

• Do not drive on extremely rocky roads

or extremely uneven roads.

●

Do not drive across a river or through

other bodies of water. This may cause

electric/electronic components to

short circuit, damage the EV system or

cause other serious damage to the

vehicle.

Lexus RZ (2023 year). Manual in english - page 4
