7-2. Steps to take in an emergency

When trouble

 ar

ises

emergency, your vehicle may be tem-
porarily towed using cables or chains
secured to the emergency towing eye-
lets. This should only be attempted on
hard surfaced roads for short distances
at under 30 km/h (18 mph).
A driver must be in the vehicle to steer
and operate the brakes. The vehicle’s
wheels, drive train, axles, steering and
brakes must be in good condition.

To have your vehicle towed by another
vehicle, the towing eyelet must be
installed to your vehicle. Install the tow-
ing eyelet using the following proce-
dure.

1

Except F SPORT models: Take out
the towing eyelet. (



P.570, 580)

F SPORT models: Take out the
flathead screwdriver and towing
eyelet. (



P.570, 580)

2

Except F SPORT models: Remove
the eyelet cover.
F SPORT models: Remove the eye-
let cover using a flathead screw-
driver.

To protect the bodywork, place a rag

between the screwdriver and the vehicle

body as shown in the illustration.



Except F SPORT models



F SPORT models

3

Insert the towing eyelet into the
hole and tighten partially by hand.

Emergency towing procedure

542

7-2. Steps to take in an emergency

4

Tighten down the towing eyelet
securely using a wheel bolt wrench
or hard metal bar.

5

Securely attach cables or chains to
the towing eyelet.

Take care not to damage the vehicle body.

6

Enter the vehicle being towed and
start the hybrid system.

If the hybrid system does not start, turn the

power switch to ON.

7

Shift the shift position to N and
release the parking brake.

Turn automatic mode off. (



P.246)

■

While towing

If the hybrid system is off, the power assist

for the brakes and steering will not function,

making steering and braking more difficult.

■

Wheel bolt wrench

Vehicles with a spare tire: Wheel bolt

wrench is installed in luggage compart-

ment. (



P.580)

Vehicles with an emergency tire puncture

repair kit: Wheel bolt wrench can be pur-

chased at any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer.

WARNING

Observe the following precautions. Fail-

ure to do so may result in death or seri-

ous injury.

■

While towing

●

When towing using cables or chains,

avoid sudden starts, etc. which place

excessive stress on the towing eyelets,

cables or chains. The towing eyelets,

cables or chains may become dam-

aged, broken debris may hit people,

and cause serious damage.

●

Do not perform any of the following as

doing so may cause the parking lock

mechanism to engage, locking the

front wheels and possibly leading to an

accident resulting in death or serious

injury:

• Unfasten the driver’s seat belt and

open the driver’s door.

• Turn the power switch off.

■

Installing towing eyelets to the vehi-

cle

Make sure that towing eyelets are

installed securely. If not securely

installed, towing eyelets may come loose

during towing.

NOTICE

■

To prevent damage to the vehicle dur-

ing emergency towing

Do not secure cables or chains to the

suspension components.

543

7

7-2. Steps to take in an emergency

When trouble

 ar

ises



Fluid leaks under the vehicle
(Water dripping from the air condi-
tioning after use is normal.)



Flat-looking tires or uneven tire
wear



Engine coolant temperature gauge
continually points higher than nor-
mal



Changes in exhaust sound



Excessive tire squeal when corner-
ing



Strange noises related to the sus-
pension system



Pinging or other noises related to
the hybrid system



Engine missing, stumbling or run-
ning roughly



Appreciable loss of power



Vehicle pulls heavily to one side
when braking



Vehicle pulls heavily to one side
when driving on a level road



Loss of brake effectiveness, spongy
feeling, pedal almost touches the
floor

If you think something is
wrong

If you notice any of the following
symptoms, your vehicle probably
needs adjustment or repair. Con-
tact any authorized Lexus retailer
or Lexus authorized repairer, or any
reliable repairer as soon as possi-
ble.

Visible symptoms

Audible symptoms

Operational symptoms

544

7-2. Steps to take in an emergency

■

Brake system warning light (warning buzzer)

■

Brake system warning light (warning buzzer)

■

High coolant temperature warning light

*

 (warning buzzer)

*

: This light illuminates on the multi-information display.

If a warning light turns on or a warning buzzer sounds

Calmly perform the following actions if any of the warning lights comes on or
flashes. If a light comes on or flashes, but then goes off, this does not necessar-
ily indicate a malfunction in the system. However, if this continues to occur,
have the vehicle inspected by any authorized Lexus retailer or Lexus author-
ized repairer, or any reliable repairer.

Actions to the warning lights or warning buzzers

Warning light

Details/Actions

(red)

Indicates that:



The brake fluid level is low; or



The brake system is malfunctioning



Immediately stop the vehicle in a safe place and contact any
authorized Lexus retailer or Lexus authorized repairer, or any reli-
able repairer. Continuing to drive the vehicle may be dangerous.

Warning light

Details/Actions

(yellow)

Indicates a malfunction in:



The regenerative braking system;



The electronically controlled brake system; or



The parking brake system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

Warning light

Details/Actions

Indicates that the engine coolant temperature is too high



Immediately stop the vehicle in a safe place.
Handling method (



P.602)

545

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

■

Hybrid system overheat warning light

*

(warning buzzer)

*

: This light illuminates on the multi-information display.

■

Charging system warning light

*

(warning buzzer)

*

: This light illuminates on the multi-information display.

■

Low engine oil pressure warning light

*

 (warning buzzer)

*

: This light illuminates on the multi-information display.

■

Malfunction indicator lamp

*

: If  equipped

Warning light

Details/Actions

Indicates the hybrid system has overheated



Stop the vehicle in a safe place.
Handling method (



P.605)

Warning light

Details/Actions

Indicates a malfunction in the vehicle’s charging system



Immediately stop the vehicle in a safe place and contact any
authorized Lexus retailer or Lexus authorized repairer, or any reli-
able repairer.

Warning light

Details/Actions

Indicates that the engine oil pressure is too low



Immediately stop the vehicle in a safe place and contact any
authorized Lexus retailer or Lexus authorized repairer, or any reli-
able repairer.

Warning light

Details/Actions

Indicates a malfunction in:



The emission control system (on some models);



The hybrid system;



The electronic engine control system;



The GPF (Gasoline Particulate Filter) system

*

;



The electronic throttle control system; or



RX500h: The electronic transmission control system



Immediately stop the vehicle in a safe place and contact any
authorized Lexus retailer or Lexus authorized repairer, or any reli-
able repairer.

546

7-2. Steps to take in an emergency

■

SRS warning light (warning buzzer)

■

ABS warning light (warning buzzer)

■

Inappropriate pedal operation warning light

*

 (warning buzzer)

*

: This light illuminates on the multi-information display.

Warning light

Details/Actions

Indicates a malfunction in:



The SRS airbag system; or



The seat belt pretensioner system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

Warning light

Details/Actions

Indicates a malfunction in:



The ABS; or



The brake assist system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

Warning light

Details/Actions

When a buzzer sounds:



Brake Override System is malfunctioning



Drive-Start Control is malfunctioning



Drive-Start Control is operating



PKSB (Parking Support Brake) (if equipped) is operating



Follow the instructions displayed on the multi-information display.

When a buzzer does not sound:
Brake Override System is operating



Release the accelerator pedal and depress the brake pedal.

547

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

■

Electric power steering system warning light (warning buzzer)

■

Low fuel level warning light

■

Driver’s and front passenger’s seat belt reminder light (warning buzzer)

*

*

: Driver’s and front passenger’s seat belt warning buzzer:

The driver’s and front passenger’s seat belt warning buzzer sounds to alert the driver and
front passenger that his or her seat belt is not fastened. If the seat belt is unfastened, the
buzzer sounds intermittently for a certain period of time after the vehicle reaches a certain
speed.

Warning light

Details/Actions

(red)

or

(yellow)

Indicates a malfunction in the EPS (Electric Power Steering) system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

Warning light

Details/Actions

Indicates that remaining fuel is approximately 10.0 L (2.6 gal., 2.2 Imp.
gal.) or less



Refuel the vehicle.

Warning light

Details/Actions

Warns the driver and/or front passenger to fasten their seat belts



Fasten the seat belt.
If the front passenger’s seat is occupied, the front passenger’s seat
belt also needs to be fastened to make the warning light (warning
buzzer) turn off.

548

7-2. Steps to take in an emergency

■

Rear passengers’ seat belt reminder light (warning buzzer)

*

*

: Rear passengers’ seat belt warning buzzer:

The rear passengers’ seat belt warning buzzer sounds to alert the rear passenger that his or
her seat belt is not fastened. If the seat belt is unfastened, the buzzer sounds intermittently
for a certain period of time after the vehicle reaches a certain speed.

■

Tire pressure warning light (warning buzzer)

Warning light

Details/Actions

(Vehicles without a

head-up display)

(Vehicles with a

head-up display)

Warns the rear passengers to fasten their seat belts



Fasten the seat belt.

Warning light

Details/Actions

When the light comes on (a buzzer sounds):



Low tire inflation pressure from natural causes



After the temperature of the tires has lowered sufficiently, check
the inflation pressure of each tire and adjust them to the specified
level.



Low tire inflation pressure from flat tire



Immediately stop the vehicle in a safe place and perform the nec-
essary actions.

When the light comes on after blinking for approximately 1 minute (a
buzzer does not sounds):
Malfunction in the tire pressure warning system



Have the system checked by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer.

549

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

■

Lexus parking assist-sensor OFF indicator (warning buzzer)

■

PCS warning light (warning buzzer)

■

LTA indicator (warning buzzer)

■

LDA indicator (warning buzzer)

■

PDA indicator (warning buzzer)

Warning light

Details/Actions

Indicates a malfunction in the Lexus parking assist-sensor function



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

Indicates that the system is temporarily unavailable, possibly due to a
sensor being dirty or covered with ice, etc.



Follow the instructions displayed on the multi-information display.
(



P.359)

Warning light

Details/Actions

Indicates a malfunction in the PCS (Pre-Collision System).



Follow the instructions displayed on the multi-information display.

If the PCS (Pre-Collision System) or VSC (Vehicle Stability Control)
system is disabled, the PCS warning light will illuminate.

Warning light

Details/Actions

(orange)

Indicates a malfunction in the LTA (Lane Tracing Assist).



Follow the instructions displayed on the multi-information display.

Warning light

Details/Actions

(orange)

Indicates a malfunction in the LDA (Lane Departure Alert).



Follow the instructions displayed on the multi-information display.

Warning light

Details/Actions

(orange)

(if equipped)

Indicates a malfunction in the PDA (Proactive Driving Assist).



Follow the instructions displayed on the multi-information display.

550

7-2. Steps to take in an emergency

■

Dynamic radar cruise control indicator (warning buzzer)

■

Cruise control indicator (warning buzzer)

■

Speed limiter indicator (warning buzzer)

■

Driving assist information indicator

*

: If  equipped

Warning light

Details/Actions

(orange)

Indicates a malfunction in the dynamic radar cruise control.



Follow the instructions displayed on the multi-information display.

Warning light

Details/Actions

(orange)

Indicates a malfunction in the cruise control.



Follow the instructions displayed on the multi-information display.

Warning light

Details/Actions

(orange)

(if equipped)

Indicates a malfunction in the speed limiter.



Follow the instructions displayed on the multi-information display.

Warning light

Details/Actions

Indicates either of the following systems may be malfunctioning.



PCS (Pre-Collision System)



LDA (Lane Departure Alert)



Automatic Rear Flashing Hazard Lights

*



Secondary Collision Brake (Rear Impacts while Stopped)

*



Follow the instructions displayed on the multi-information display.

Indicates one of the following systems is malfunctioning or disabled.



PKSB (Parking Support Brake)

*



RCD (Rear Camera Detection)

*



BSM (Blind Spot Monitor)

*



RCTA (Rear crossing traffic alert)

*



Safe Exit Assist

*



Follow the instructions displayed on the multi-information display.

551

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

■

Slip indicator

■

Parking brake indicator (warning buzzer)

■

Brake hold operated indicator (warning buzzer)

■

Warning buzzer

In some cases, the buzzer may not be heard

due to being in a noisy location or audio

sound.

■

Front passenger detection sensor, seat

belt reminder and warning buzzer

●

If luggage is placed on the front passen-

ger seat, the front passenger detection

sensor may cause the warning light to

flash and the warning buzzer to sound

even if a passenger is not sitting in the

seat.

●

If a cushion is placed on the seat, the sen-

sor may not detect a passenger, and the

warning light may not operate properly.

■

If the malfunction indicator lamp comes

on while driving

For some models, the malfunction indicator

lamp will come on if the fuel tank becomes

completely empty. If the fuel tank is empty,

refuel the vehicle immediately. The malfunc-

tion indicator lamp will go off after several

trips.
If the malfunction indicator lamp does not

Warning light

Details/Actions

(illuminates)

Indicates a malfunction in:



The VSC system;



The TRC system;



The Trailer Sway Control;



The Trail Mode function; or



The hill-start assist control system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

Warning light

Details/Actions

(flashes)

It is possible that the parking brake is not fully engaged or released



Operate the parking brake switch once again.

This light comes on the parking brake is not released. If the light turns off
after the parking brakes is fully released, the system is operating nor-
mally.
Indicates a malfunction in the parking brake system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

Warning light

Details/Actions

(flashes)

Indicates a malfunction in the brake hold system



Have the vehicle inspected by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable repairer immediately.

552

7-2. Steps to take in an emergency

go off, contact any authorized Lexus retailer

or Lexus authorized repairer, or any reliable

repairer as soon as possible.

■

Electric power steering system warning

light (warning buzzer)

When the 12-volt battery charge becomes

insufficient or the voltage temporarily

drops, the electric power steering system

warning light may come on and the warning

buzzer may sound.

■

When the tire pressure warning light

comes on

Inspect the tires to check if a tire is punc-

tured.
If a tire is punctured:



P.569, 579

If none of the tires are punctured:

Turn the power switch off then turn it to ON.

Check if the tire pressure warning light

comes on or blinks.



If the tire pressure warning light blinks for

approximately 1 minute then stays on

There may be a malfunction in the tire

pressure warning system. Have the vehicle

inspected by any authorized Lexus retailer

or Lexus authorized repairer, or any relia-

ble repairer immediately.



If the tire pressure warning light comes

on

After the temperature of the tires has low-

ered sufficiently, check the inflation pres-

sure of each tire and adjust them to the

specified level.
If the warning light does not turn off even

after several minutes have elapsed, check

that the inflation pressure of each tire is at

the specified level and perform the tire

inflation pressure setting procedure.

(



P.514)

If the warning light does not turn off even

after several minutes have elapsed since

performing the tire inflation pressure set-

ting procedure, have the vehicle inspected

by any authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer as soon as possible.

■

The tire pressure warning light may

come on due to natural causes

The tire pressure warning light may come

on due to natural causes such as natural air

leaks and tire inflation pressure changes

caused by temperature. In this case, adjust-

ing the tire inflation pressure will turn off the

warning light (after a few minutes).

■

When a tire is replaced with a spare tire

(vehicles with a spare tire)

The spare tire is not equipped with a tire

pressure warning valve and transmitter. If a

tire goes flat, the tire pressure warning light

will not turn off even though the flat tire has

been replaced with the spare tire. Replace

the spare tire with the repaired tire and

adjust the tire inflation pressure. The tire

pressure warning light will go off after a few

minutes.

■

Conditions that the tire pressure warn-

ing system may not function properly



P.511

WARNING

■

If both the ABS and the brake system

warning lights remain on

Stop your vehicle in a safe place immedi-

ately and contact any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer.

The vehicle will become extremely

unstable during braking, and the ABS

system may fail, which could cause an

accident resulting in death or serious

injury.

553

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

WARNING

■

When the electric power steering

system warning light comes on

When the light comes on yellow, the

assist to the power steering is restricted.

When the light comes on red, the assist

to the power steering is lost and handling

operations of the steering wheel become

extremely heavy.

When steering wheel operations are

heavier than usual, grip the steering

wheel firmly and operate it using more

force than usual.

■

If the tire pressure warning light

comes on

Be sure to observe the following precau-

tions.

Failure to do so could cause a loss of

vehicle control and result in death or

serious injury.

●

Stop your vehicle in a safe place as

soon as possible. Adjust the tire infla-

tion pressure immediately.

●

Vehicles with a spare tire: If the tire

pressure warning light comes on even

after tire inflation pressure adjustment,

it is probable that you have a flat tire.

Check the tires. If a tire is flat, change it

with the spare tire and have the flat tire

repaired by the nearest any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer.

●

Vehicles with an emergency tire punc-

ture repair kit: If the tire pressure warn-

ing light comes on even after tire

inflation pressure adjustment, it is

probable that you have a flat tire.

Check the tires. If a tire is flat, repair

the flat tire by using emergency tire

puncture repair kit.

●

Avoid abrupt maneuvering and brak-

ing.

If the vehicle tires deteriorate, you

could lose control of the steering

wheel or the brakes.

■

If a blowout or sudden air leakage

should occur

The tire pressure warning system may

not activate immediately.

NOTICE

■

To ensure the tire pressure warning

system operates properly

Do not install tires with different specifi-

cations or makers, as the tire pressure

warning system may not operate prop-

erly.

554

7-2. Steps to take in an emergency

■

Warning messages

The warning messages explained below

may differ from the actual messages

according to operation conditions and vehi-

cle specifications.

■

Warning buzzer

In some cases, the buzzer may not be heard

due to being in a noisy location or audio

sound.

If a warning message is dis-
played

The multi-information display
shows warnings for system malfunc-
tions and incorrectly performed
operations, and messages that indi-
cate a need for maintenance.
When a message is displayed, per-
form the appropriate corrective
action for the message.

If a warning message is displayed
again after the appropriate actions
have been performed, contact any
authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

Additionally, if a warning light
comes on or flashes at the same
time that a warning message is dis-
played, take the appropriate cor-
rective action for the warning light.
(



P.544)

555

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

■

If “Engine Oil Level Low Add or Replace” is displayed

■

If “Hybrid System Stopped Steering Power Low” is displayed

■

If “Auto Power OFF to Conserve Battery” is displayed

■

If “Shift Out of N Release Accelerator Before Shifting” is displayed

■

If “Press Brake when vehicle is stopped Hybrid system may overheat” is dis-
played

Messages and warnings

Cause

Actions

The engine oil level may be low.

Check the level of the engine oil, and add engine oil
if necessary. (



P.502)

This message may be displayed if the vehicle is
stopped on a slope. Move the vehicle to a level sur-
face and check if the message disappears.

Cause

Actions

This message is displayed if the
hybrid system is stopped while driv-
ing.

When steering wheel operations are heavier than
usual, grip the steering wheel firmly and operate it
using more force than usual.

Cause

Actions

Power was turned off due to the
automatic power off function.

Next time when starting the hybrid system, operate
the hybrid system for approximately 5 minutes to
recharge the 12-volt battery.

Cause

Actions

The accelerator pedal has been
depressed when the shift position is
in N.

Release the accelerator pedal and change the shift
position to D or R.

Cause

Actions

The message may be displayed
when the accelerator pedal is
depressed to hold the vehicle while
the vehicle is stopped on an incline,
etc.

The hybrid system may overheat. Release the accel-
erator pedal and depress the brake pedal.

556

7-2. Steps to take in an emergency

■

If “12-Volt Battery Charging System Malfunction Stop in a Safe Place See
Owner’s Manual” is displayed

■

If “Protect traction battery Shift to P” is displayed (RX350h)

■

If “Protect traction battery No N position.” is displayed (RX350h)

■

If “Hybrid System Overheated Output Power Reduced” is displayed

■

If “Tyre Set Switching Incomplete Retry Tyre Set Registration See Owner’s
Manual” is displayed

Cause

Actions

It may indicate a malfunction.

Immediately stop the vehicle and contact any
authorized Lexus retailer or Lexus authorized
repairer, or any reliable repairer. Continuing to drive
the vehicle may be dangerous.

Cause

Actions

This message is displayed when the
hybrid battery (traction battery)
charge has become extremely low
because the vehicle has been left
with the N shift position selected for
a certain amount of time.

When operating the vehicle, shift to P and restart the
hybrid system.

Cause

Actions

This message may be displayed
when the shift position is in N.

As the hybrid battery (traction battery) cannot be
charged when the shift position is in N, shift the shift
position to P when the vehicle is stopped.

Cause

Actions

This message may be displayed
when driving under severe operating
conditions. (For example, when driv-
ing up a long steep hill.)



P.602

Cause

Actions

The wheel set change could not be
completed.

Check which wheel set is installed and perform the
change procedure again from the beginning.

557

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

■

If “Headlight System Malfunction Visit Your Dealer” is displayed

*

: If  equipped

■

If “Engine Coolant Temp High Stop in a Safe Place See Owner’s Manual” is
displayed

■

If “Exhaust Filter Clogged See Owner’s Manual” is displayed (on some mod-
els)

■

If “Smart Entry & Start System Malfunction See Owner’s Manual” is dis-
played

■

If “Braking Power Low Stop in a Safe Place See Manual” is displayed

Cause

Actions

The following systems may be malfunctioning.



The LED headlight system



The automatic headlight leveling system



AHB (Automatic High Beam)

*



AHS (Adaptive High-beam System)

*

Have the vehicle inspected by any
authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer immediately.

Actions



P.602

Actions



P.425

Cause

Actions

It may indicate a malfunction.

Have the vehicle checked by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer immediately.

Cause

Actions

It may indicate a malfunction.

Immediately stop the vehicle in a safe place and con-
tact any authorized Lexus retailer or Lexus author-
ized repairer, or any reliable repairer. Continuing to
drive the vehicle may be dangerous.

558

7-2. Steps to take in an emergency

■

If “Oil Pressure Low Stop in a Safe Place See Owner’s Manual” is displayed

■

If “High Power Consumption Power to Climate Temporarily Limited” is dis-
played

■

If a message that indicates the need for visiting your Lexus dealer is displayed

■

If “Maintenance Required for Traction Battery Cooling Parts See Owner’s
Manual” is displayed

Cause

Actions

It may indicate a malfunction.

Immediately stop the vehicle in a safe place and con-
tact any authorized Lexus retailer or Lexus author-
ized repairer, or any reliable repairer. Continuing to
drive the vehicle may be dangerous.

Cause

Actions

If this message is displayed fre-
quently, there is a possible malfunc-
tion relating to the charging system
or the 12-volt battery may be deteri-
orating.

Have the vehicle checked by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer.

Cause

Actions

The system or part shown on the
multi-information display is malfunc-
tioning.

Have the vehicle inspected by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer immediately.

Cause

Actions

The air intake vent or filter of the
hybrid battery (traction battery) may
be clogged, the air intake vent may
be blocked, or there may be a gap in
the duct.



If the air intake vent or filter of the hybrid battery
(traction battery) is dirty, clean them.



If the warning message is shown when the air
intake vent and filter of the hybrid battery (traction
battery) are not dirty, have the vehicle inspected
by any authorized Lexus retailer or Lexus author-
ized repairer, or any reliable repairer.

559

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

■

If “Shift System Malfunction Shifting Unavailable Drive to a Safe Place and
Stop” is displayed

■

If “Shift System Malfunction Driving Unavailable” is displayed

■

If a message that indicates the need for the shift lever operation is displayed

■

If “Shift System Malfunction Apply Parking Brake Securely When Parking
See Owner’s Manual” is displayed

■

If “P Switch Malfunction Apply Parking Brake Securely When Parking See
Owner’s Manual” is displayed

Cause

Actions

There is a malfunction in the shift
control system.

Have the vehicle inspected by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer immediately.

Cause

Actions

There is a malfunction in the shift
control system.

Have the vehicle inspected by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer immediately.

Cause

Actions

To prevent the shift lever from being operated incor-
rectly or the vehicle from moving unexpectedly, a
message that requires shifting the shift position may
be displayed on the multi-information display.

Follow the instruction of the message
and shift the shift position.

Cause

Actions

It may indicate a malfunction.

Have the vehicle inspected by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer immediately.

Cause

Actions

It may indicate a malfunction.

Have the vehicle inspected by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer immediately.

560

7-2. Steps to take in an emergency

■

If “Shift System Unavailable Apply Parking Brake Securely When Parking See
Owner’s Manual” is displayed

■

If “Shift System Malfunction See Owner’s Manual” is displayed

■

If “Shift System Malfunction Stop in a Safe Place See Owner’s Manual” is dis-
played

■

If “Battery Low Shifting Unavailable See Owner’s Manual” is displayed

Cause

Actions

It may indicate a malfunction.

Have the vehicle inspected by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer immediately.

Cause

Actions

It may indicate a malfunction.

Have the vehicle inspected by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer immediately.

Cause

Actions

It may indicate a malfunction.

Have the vehicle inspected by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer immediately.

Cause

Actions

It may indicate a malfunction.

Have the vehicle inspected by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer immediately.

561

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

■

If “System Malfunction Visit Your Dealer” is displayed

*

: If  equipped

Cause

Actions

Indicates one of the following systems is disabled.



PCS (Pre-Collision System)



LDA (Lane Departure Alert)



LTA (Lane Tracing Assist)



 LCA (Lane Change Assist)

*



AHB (Automatic High Beam)

*



AHS (Adaptive High-beam System)

*



Dynamic radar cruise control system



Speed limiter system

*



 RSA (Road Sign Assist)

*



PDA (Proactive Driving Assist)

*



 BSM (Blind Spot Monitor)

*



 RCTA (Rear crossing traffic alert)

*



 Secondary Collision Brake (Rear Impacts

while Stopped)

*



 Automatic Rear Flashing Hazard Lights

*



 Safe Exit Assist

*



Lexus parking assist-sensor



 PKSB (Parking Support Brake)

*



 RCD (Rear camera detection)

*

Have the vehicle inspected by any
authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer immediately.

562

7-2. Steps to take in an emergency

■

If “System Stopped See Owner’s Manual” is displayed

Cause

Actions

Indicates one of the following systems is disabled.



PCS (Pre-Collision System)



LDA (Lane Departure Alert)



LTA (Lane Tracing Assist)



 LCA (Lane Change Assist)

*



AHB (Automatic High Beam)

*



AHS (Adaptive High-beam System)

*



Dynamic radar cruise control system



Speed limiter system

*



 RSA (Road Sign Assist)

*



PDA (Proactive Driving Assist)

*



 BSM (Blind Spot Monitor)

*



 RCTA (Rear crossing traffic alert)

*



 Secondary Collision Brake (Rear Impacts

while Stopped)

*



 Automatic Rear Flashing Hazard Lights

*



 Safe Exit Assist

*



Lexus parking assist-sensor



 PKSB (Parking Support Brake)

*



 RCD (Rear camera detection)

*

Follow the following correction
methods.



Check the voltage of the 12-volt
battery



Check the sensors that the Lexus
Safety System+ uses for foreign
matter covering them. Remove
them if any. (



P.271)



Vehicles with RCD: Check if the
back door is open.

563

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

*

: If  equipped

■

If “System Stopped Front Camera Low Visibility See Owner’s Manual” is dis-
played

*

: If  equipped

Indicates the sensors may not be operating properly.
(



P.275, 347, 349, 351, 356, 359, 369, 373,

382, 383, 385, 387)



Check the rear bumper around
the sensors used by the BSM

*

,

RCTA

*

, Secondary Collision

Brake (Rear Impacts while
Stopped)

*

, Automatic Rear Flash-

ing Hazard Lights

*

, or Safe Exit

Assist

*

 for foreign matter covering

them. Remove them if any.
(



P.344, 354)



Check the sensors including cam-
era sensors used by the LEXUS
parking assist-sensor, PKSB

*

, or

RCD

*

 for foreign matter covering

them. Remove them if any.
(



P.357)



When problems are solved and
the sensors are operational, this
indication may disappear by itself.

Cause

Actions

Indicates one of the following systems is disabled.



PCS (Pre-Collision System)



LDA (Lane Departure Alert)



LTA (Lane Tracing Assist)



 LCA (Lane Change Assist)

*



AHB (Automatic High Beam)

*



AHS (Adaptive High-beam System)

*



Dynamic radar cruise control system



Speed limiter system

*



 RSA (Road Sign Assist)

*



PDA (Proactive Driving Assist)

*

Follow the following correction
methods.



Using the windshield wipers,
remove the dirt or foreign matter
from the windshield.



Using the air conditioning system,
defog the windshield.



Close the hood, remove any stick-
ers, etc. to clear the obstruction in
front of the front camera.

Cause

Actions

564

7-2. Steps to take in an emergency

■

If “System Stopped Front Camera Out of Temp. Range Wait until Normal
Temperature” is displayed

*

: If  equipped

Cause

Actions

Indicates one of the following systems is disabled.



PCS (Pre-Collision System)



LDA (Lane Departure Alert)



LTA (Lane Tracing Assist)



 LCA (Lane Change Assist)

*



AHB (Automatic High Beam)

*



AHS (Adaptive High-beam System)

*



Dynamic radar cruise control system



Speed limiter system

*



 RSA (Road Sign Assist)

*



PDA (Proactive Driving Assist)

*

Follow the following correction
methods.



If the front camera is hot, such as
after the vehicle is parked in the
sun, use the air conditioning sys-
tem to decrease the temperature
around the front camera



If a sunshade was used when the
vehicle was parked, depending on
its type, the sunlight reflected from
the surface of the sunshade may
cause the temperature of the front
camera to become excessively
high



If the front camera is cold, such
after the vehicle is parked in an
extremely cold environment, use
the air conditioning system to
increase the temperature around
the front camera

565

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

■

If “System Stopped Front Radar Sensor Blocked Clean Radar Sensor” is dis-
played

*

: If  equipped

■

If “System Stopped Front Radar Sensor Out of Temp. Range Wait until Nor-
mal Temperature” is displayed

*

: If  equipped

Cause

Actions

Indicates one of the following systems is disabled.



PCS (Pre-Collision System)



LDA (Lane Departure Alert)



LTA (Lane Tracing Assist)



 LCA (Lane Change Assist)

*



AHB (Automatic High Beam)

*



AHS (Adaptive High-beam System)

*



Dynamic radar cruise control system



Speed limiter system

*



PDA (Proactive Driving Assist)

*

Follow the following correction
methods.



Check if there is any foreign mat-
ter attached to the radar sensor or
radar sensor cover and clean
them if necessary. (



P.272)



This message may be displayed
when driving in an open area with
few nearby vehicles or structures,
such as a desert, grasslands, sub-
urbs, etc.

The message may be cleared by
driving the vehicle in an area with
structures, vehicles, etc. nearby.

Cause

Actions

Indicates one of the following systems is disabled.



PCS (Pre-Collision System)



LDA (Lane Departure Alert)



LTA (Lane Tracing Assist)



 LCA (Lane Change Assist)

*



AHB (Automatic High Beam)

*



AHS (Adaptive High-beam System)

*



Dynamic radar cruise control system



Speed limiter system

*



PDA (Proactive Driving Assist)

*

The temperature of the radar sensor
is outside of the operating range.
Wait for the temperature to become
appropriate.

566

7-2. Steps to take in an emergency

■

If “System Stopped Front Radar In Self Calibration See Owner’s Manual” is
displayed

*

: If  equipped

■

If “Driver Monitor Out of Temperature Range Wait until Normal Tempera-
ture” is displayed (on some models)

■

If “Unavailable Activ. Cond.not Satisfied See Owner’s Manual” is displayed
(on some models)

Cause

Actions

Indicates one of the following systems is disabled.



PCS (Pre-Collision System)



LDA (Lane Departure Alert)



LTA (Lane Tracing Assist)



 LCA (Lane Change Assist)

*



AHB (Automatic High Beam)

*



AHS (Adaptive High-beam System)

*



Dynamic radar cruise control system



Speed limiter system

*



PDA (Proactive Driving Assist)

*

Follow the following correction
methods.



Check if there is any foreign mat-
ter attached to the radar sensor or
radar sensor cover and clean
them if necessary. (



P.272)



The radar sensor may be mis-
aligned and will be adjusted auto-
matically while driving. Continue
driving for a while.

Cause

Actions

Indicates one of the following sys-
tems is disabled.



Driver monitor

The temperature of the driver monitor camera is
outside of the operating range. Wait for the temper-
ature to become appropriate.

Cause

Actions

 The LCA function cannot be

used as the operating conditions
have not been met. (P.297)

Operate the turn signal lever again after all of the
operating conditions are met.

567

7

7-2. Steps to take in an emergency

When trouble

 ar

ises

■

If “Cruise Control Unavailable See Owner’s Manual” is displayed

■

If “Speed Limiter Unavailable See Owner’s Manual” is displayed (on some
models)

■

If “Driver Monitor Unavailable See Owner’s Manual” is displayed (on some
models)

■

If “Parking Assist Unavailable Low Visibility See Owner’s Manual” is dis-
played

*

: If  equipped

Cause

Actions

Indicates one of the following sys-
tems is disabled.



Dynamic radar cruise control



Cruise control

A message is displayed when the
driving assist switch is pushed
repeatedly.

Press the driving assist switch quickly and firmly.

Cause

Actions

This message may be displayed
when the shift position is in R.

Shift the shift position to D.

A message is displayed when the
driving assist switch is pushed
repeatedly.

Press the driving assist switch quickly and firmly.

Cause

Actions

The lens of the driver monitor cam-
era may be dirty.

When there is dirt on the camera lens, clean it with a
dry, soft cloth so as to not damage it.

Cause

Actions

Indicates one of the following sys-
tems is disabled.



 PKSB (Parking Support

Brake)

*



 RCD (Rear camera detec-

tion)

*

Remove any dirt or foreign matter from the rear
cameras.

568

7-2. Steps to take in an emergency

■

If “Check Engine” is displayed

■

If “Hybrid System Malfunction” is displayed

■

If “Accelerator System Malfunction” is displayed

■

If “Traction battery system malfunction” is displayed

■

If “Hybrid System Stopped” is displayed

■

If “Engine stopped No Fuel” is displayed

Cause

Actions

It may indicate a malfunction.

Have the vehicle inspected by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer immediately.

Cause

Actions

It may indicate a malfunction.

Have the vehicle inspected by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer immediately.

Cause

Actions

It may indicate a malfunction.

Have the vehicle inspected by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer immediately.

Cause

Actions

It may indicate a malfunction.

Have the vehicle inspected by any authorized Lexus
retailer or Lexus authorized repairer, or any reliable
repairer immediately.

Cause

Actions

The vehicle may have run out of fuel.

Stop the vehicle in a safe place and, if the fuel level is
low, refuel the vehicle.

Cause

Actions

The vehicle may have run out of fuel.

Stop the vehicle in a safe place and, if the fuel level is
low, refuel the vehicle.

569

7

7-2. Steps to take in an emergency

When trouble

 ar

ises



Stop the vehicle in a safe place on a
hard, flat surface.



Set the parking brake.



Shift the shift position to P.



Stop the hybrid system.



Turn on the emergency flashers.
(



P.536)



Check the degree of the tire dam-
age.

A tire should only be repaired with the
emergency tire puncture repair kit if
the damage is caused by a nail or
screw passing through the tire tread.
• Do not remove the nail or screw

from the tire. Removing the object
may widen the opening and
disenable emergency repair with
the kit.

• To avoid sealant leakage, move the

vehicle until the area of the punc-
ture, if known, is positioned at the
top of the tire.

■

A flat tire that cannot be repaired with

the emergency tire puncture repair kit

In the following cases, the tire cannot be

repaired with the emergency tire puncture

repair kit. Contact any authorized Lexus

retailer or Lexus authorized repairer, or any

reliable repairer.

●

When the tire is damaged due to driving

without sufficient air pressure

●

When the tire lost air pressure due to a

If you have a flat tire (vehi-
cles with an emergency tire
puncture repair kit)

Your vehicle is not equipped with a
spare tire, but instead is equipped
with an emergency tire puncture
repair kit.

A puncture caused by a nail or
screw passing through the tire
tread can be repaired temporarily
with the emergency tire puncture
repair kit. (The kit contains a bottle
of sealant. The sealant can be used
only once to temporarily repair one
tire without removing the nail or
screw from the tire.)

After temporarily repairing the tire
with the kit, have the tire repaired
or replaced by any authorized
Lexus retailer or Lexus authorized
repairer, or any reliable repairer.

WARNING

■

If you have a flat tire

Do not continue driving with a flat tire.

Driving even a short distance with a flat

tire can damage the tire and the wheel

beyond repair.

Driving with a flat tire may cause a cir-

cumferential groove on the side wall. In

such a case, the tire may explode when

using the emergency tire puncture repair

kit, resulting in death or serious injury.

Before repairing the vehicle

570

7-2. Steps to take in an emergency

crack or damage in the tire sidewall

●

When the tire is visibly separated from

the wheel

●

When the cut or damage to the tread is 4

mm (0.16 in.) long or more

●

When the wheel is damaged

●

When two or more tires have been punc-

tured

●

When there is more than one hole or cut

in the damaged tire

●

When the sealant has expired

Towing eyelet
Emergency tire puncture repair kit
Screwdriver

■

Jack and tools

As your vehicle is equipped with an emer-

gency tire puncture repair kit, the following

tools for replacing a tire are not included

with your vehicle. They can be purchased at

any authorized Lexus retailer or Lexus

authorized repairer, or any reliable repairer.

●

Jack

●

Jack handle

●

Wheel bolt socket

●

Guide pin

●

Wheel bolt wrench

Location of the emergency tire puncture repair kit and tools

A
B
C

WARNING

■

Using the tire jack



P.580

571

7

7-2. Steps to take in an emergency

When trouble

 ar

ises



Bottle

Sticker



Compressor

Air pressure gauge
Compressor switch
Power plug
Hose
Air release cap

■

Emergency tire puncture repair kit

●

The sealant stored in the emergency tire

puncture repair kit can be used only once

to temporarily repair a single tire. If the

sealant in the bottle and other parts of the

kit have been used and need to be

replaced, contact any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer.

●

The compressor can be used repeatedly.

●

The sealant can be used when the outside

temperature is from -30°C (-22°F) to

60°C (140°F).

●

The kit is exclusively designed for size

and type of tires originally installed on

your vehicle. Do not use it for tires that a

different size than the original ones, or for

any other purposes.

●

If the sealant gets on your clothes, it may

stain.

●

If the sealant adheres to a wheel or the

surface of the vehicle body, the stain may

not be removable if it is not cleaned at

once. Immediately wipe away the sealant

with a wet cloth.

●

During operation of the kit, a loud opera-

tion noise is produced. This does not indi-

cate a malfunction.

●

Do not use the emergency tire puncture

repair kit to check or adjust the tire infla-

tion pressure.

■

Note for checking the emergency tire

puncture repair kit

●

Check the sealant expiry date occasion-

ally. The expiry date is shown on the bot-

tle.

●

Do not use sealant whose expiry date has

already passed. Otherwise, repairs con-

ducted using the emergency tire punc-

ture repair kit may not be performed

properly.

●

Replace the liquid sealant bottle of the

emergency tire puncture repair kit before

it’s expiration date. For information on

replacement, contact any authorized

Lexus retailer or Lexus authorized

repairer, or any reliable repairer for

Emergency tire puncture repair
kit components

A

A
B
C
D

E

572

7-2. Steps to take in an emergency

replacement.

1

Secure the deck board using the
hook. (



P.466)

2

Take out the emergency tire punc-
ture repair kit.

1

Remove the emergency tire punc-
ture repair kit from the plastic bag.

The sticker enclosed with the bottle will be

attached at a specified location. (See step

10

.)

2

Pull out the hose and power plug
from the compressor.

3

Connect the bottle to the compres-
sor.

Insert the bottle straight into the compres-

sor to connect it, and make sure that the

claws are securely engaged to the com-

pressor as shown in the illustration.

4

Connect the hose to the bottle.

Make sure that the hose is securely con-

nected to the bottle, as shown in the illus-

WARNING

■

Caution while driving

Observe the following precautions.

Failure to do so may cause an accident.

●

The emergency tire puncture repair kit

is made exclusively for your vehicle.

Do not use it on other vehicles.

●

Do not use the emergency tire punc-

ture repair kit for tires that are a differ-

ent size than the specified ones or for

any other purpose. Doing so may

cause the tires to not be repaired

properly.

■

Precautions for use of the sealant

●

Ingesting the sealant is hazardous to

your health. If you ingest sealant, con-

sume as much water as possible, then

immediately consult a doctor.

●

If sealant gets in eyes or adheres to

skin, immediately wash it off with water.

If discomfort persists, consult a doctor.

Taking out the emergency tire
puncture repair kit

Emergency repair method
