Lexus LX600 (2023 year). Manual in english

346

4-5. Using the driving support systems



When Eco drive mode or comfort mode

is selected

●

When the four-wheel drive control

switch is in L4

●

When the Multi-terrain Select is turned

■

Customization (vehicles with Adaptive

Variable Suspension system)

The Custom mode can be changed.
(Customizable features:



P.565)

: If equipped

■

Height select switches

Higher

Lower

■

Meter display

AHC display

When the vehicle is stopped, selected
vehicle height mode is displayed. When
driving, current vehicle height mode is dis-
played.

Easy access mode indicator

AHC (Active Height Control
Suspension)

The vehicle height modes can be
selected to suit driving condition.

System components

A
B

347

4-5. Using the driving support systems

Driving

■

Front Multi Operation Panel

Vehicle height mode

Selected vehicle height mode is displayed.

AHC display

When the vehicle is stopped, selected
vehicle height mode is displayed. When
driving, current vehicle height mode is dis-
played.

Easy access mode switch

Height control OFF switch

Press the height select switch.

Selected vehicle height mode is displayed
on the AHC display and Front Multi Oper-
ation Panel. At this time, a part of the AHC
display will flash. After the vehicle height is
changed, the display will stop flashing, and
come on.

N (Normal) mode

H1 (Hi1) mode

H2 (Hi2) mode

L (Lo) mode

The vehicle height modes will change
as the following table by operating the
height select switch.

■

N mode

The standard vehicle height. This mode
is suitable for ordinary driving.

Selecting vehicle height

C
D

Vehicle height modes

Vehicle

height

modes

Height select switch

A
B
C
D

348

4-5. Using the driving support systems

■

H1 mode



Four-wheel drive control switch is in
H4

This mode is suitable for dirt roads
driving.
H1 mode is only available when the
vehicle speed is under 62 mph (100
km/h). Vehicle height is approximately
1.0 in. (25 mm) higher than N mode
height.



Four-wheel drive control switch is in
L4

This mode is suitable for extremely
rough roads driving.
H1 mode is only available when the
vehicle speed is under 50 mph (80
km/h). Vehicle height is approximately
2.2 in. (55 mm) higher than N mode
height.

■

H2 mode



Four-wheel drive control switch is in
H4

This mode is suitable for rough roads
driving.



H2 mode is only available when the
vehicle speed is under 19 mph (30
km/h). Vehicle height is approxi-
mately 3.0 in. (75 mm) higher than
N mode height.



H2 mode is only available when the
vehicle speed is 19 mph (30 km/h)
to 37 mph (60 km/h). Vehicle
height is approximately 2.2 in. (55
mm) higher than N mode height.



Four-wheel drive control switch is in
L4

This mode is suitable for extremely
rough roads driving.



H2 mode is only available when the
vehicle speed is under 9 mph (15
km/h). Vehicle height is approxi-
mately 3.3 in. (85 mm) higher than
N mode height.



H2 mode is only available when the
vehicle speed is 9 mph (15 km/h) to
31 mph (50 km/h). Vehicle height is
approximately 3.0 in. (75 mm)
higher than N mode height.

■

L mode

This mode allows easy access to the
vehicle.
L mode is only available when the vehi-
cle is traveling at 7 mph (12 km/h) or
less. Vehicle height is approximately
1.0 in. (25 mm) lower than N mode
height.

Some modes may not be selectable
depending on the vehicle speed. Refer
to the following table.

Conditions for changing the
vehicle height mode

349

4-5. Using the driving support systems

Driving



Four-wheel drive control switch is in
H4



Four-wheel drive control switch is in
L4

You can select this mode for easy
access and easy loading of the vehicle.
To turn easy access mode on, turn the
four-wheel drive control switch to H4
and press the easy access mode switch

on the Front Multi Operation Panel.

When the easy access mode is in on, the
indicator

on the switch and the easy

access mode indicator on the meter
comes on.

If the engine switch is turned off within
approximately 30 seconds after the vehi-
cle is stopped while easy access mode is
on, the vehicle height is lowered automati-
cally.
When the vehicle begins to lower, a
buzzer will sound twice. The easy access
mode indicator display will come on while
the vehicle is lowering to indicate that the
vehicle is lowering.
When the operation is complete, the easy
access mode indicator will turns off.

■

Operation conditions of the easy access

mode

●

The easy access mode is operational

when all of the following conditions are

met:

• The vehicle height mode is in N mode.

• The vehicle is stopped on a flat surface.

• The shift lever is in P.

• The side doors and back door are not

opened after the vehicle is stopped.

●

The following method will cancel the

vehicle lowering operation and raise the

Vehicle speed

Vehicle height modes

Under 7 mph

(12 km/h)

Yes Yes Yes Yes

7 mph (12 km/h)

to 37 mph (60

km/h)

No Yes Yes Yes

37 mph (60

km/h) to 62

mph (100 km/h)

No Yes Yes No

62 mph (100

km/h) or over

No Yes No

Vehicle speed

Vehicle height modes

Under 7 mph

(12 km/h)

Yes Yes Yes Yes

7 mph (12 km/h)

to 31 mph (50

km/h)

No Yes Yes Yes

31 mph (50

km/h) to 50

mph (80 km/h)

No Yes Yes No

50 mph (80

km/h) or over

No Yes No

Easy access mode

350

4-5. Using the driving support systems

vehicle again:

• Press the height select switch

■

In the following cases the easy access

mode will not operate

The easy access mode does not operate

when the suspension fluid temperature

drops below 5°F (-15°C).

Press the height control OFF switch on
the Front Multi Operation Panel while
the vehicle is stopped.

The indicator

on the switch will

come on and the OFF indicator will
display on the AHC display.
When the height control OFF indicator
is displayed, the vehicle height will not
change even if the height select switch
is operated.
Press the switch again to turn the sys-
tem back on.

■

Operating conditions of the AHC

●

The engine must be running.

●

Vehicle height control must be turned off.

●

All side doors and the back door must be

closed.

■

Vehicle height control speed

The vehicle height control speed will

change depending on the operating state of

the AHC.

■

Switching vehicle height mode while the

engine is stopped

●

If the engine is stopped while the vehicle

height is being lowered, lowering will

continue.

●

If any luggage is removed from the vehi-

cle or if any occupants leave the vehicle

within approximately 30 seconds of the

engine switch being turned off, the vehi-

cle height may be lowered by the auto

leveling function.

●

Operating the height select switch will

have no effect while the engine is

stopped.

■

Automatic change in vehicle height

modes

●

N mode is automatically selected when

all of the following conditions are met:

• The four-wheel drive control switch is

shifted to H4

• The Multi-terrain Select is turned off

●

In the following situations, H2 mode is

automatically selected.

• When the four-wheel drive control

switch is shifted to L4

• When the Multi-terrain Select is turned

: The vehicle height mode will change

depending on the selected mode.

■

Automatic change in vehicle height

when in H1 mode



Four-wheel drive control switch is in H4

●

If the vehicle speed exceeds 62 mph

(100 km/h), N mode is automatically

selected.

●

If the vehicle speed drops to 50 mph (80

km/h) or less, H1 mode is automatically

resumed.



Four-wheel drive control switch is in L4

●

If the vehicle speed exceeds 50 mph (80

km/h), the vehicle height is lowered to 1.0

Disabling the height control

351

4-5. Using the driving support systems

Driving

in. (25 mm) higher than N mode height.

●

If the vehicle speed drops to 37 mph (60

km/h) or less, H1 mode is automatically

resumed.

■

Automatic change in vehicle height

when in H2 mode



Four-wheel drive control switch is in H4

●

If the vehicle speed exceeds 19 mph (30

km/h), the vehicle height is lowered to

2.2 in. (55 mm) higher than N mode

height.

●

If the vehicle speed exceeds 37 mph (60

km/h), H1 mode is automatically

selected.

●

If the vehicle speed exceeds 62 mph

(100 km/h), N mode is automatically

selected.

●

If the vehicle speed drops to 50 mph (80

km/h) or less, H1 mode is automatically

resumed.

●

If the vehicle speed drops to 25 mph (40

km/h) or less, the vehicle height is auto-

matically set to 2.2 in. (55 mm) higher

than the N mode height.

●

If the vehicle speed drops to 6 mph (10

km/h) or less, the vehicle height is auto-

matically set to 3.0 in. (75 mm) higher

than the N mode height.



Four-wheel drive control switch is in L4

●

If the vehicle speed exceeds 9 mph (15

km/h), the vehicle height is lowered to

3.0 in. (75 mm) higher than N mode

height.

●

If the vehicle speed exceeds 31 mph (50

km/h), H1 mode is automatically

selected.

●

If the vehicle speed exceeds 50 mph (80

km/h), the vehicle height is lowered to 1.0

in. (25 mm) higher than N mode height.

●

If the vehicle speed drops to 37 mph (60

km/h) or less, H1 mode is automatically

resumed.

●

If the vehicle speed drops to 19 mph (30

km/h) or less, the vehicle height is auto-

matically set to 3.0 in. (75 mm) higher

than the N mode height.

●

If the vehicle speed drops to 3 mph (5

km/h) or less, the vehicle height is auto-

matically set to 3.3 in. (85 mm) higher

than the N mode height.

■

Automatic change in vehicle height

when in L mode

If the vehicle speed drops to 7 mph (12

km/h) or less, N mode is automatically

resumed.

■

Extra high mode

If the vehicle becomes stuck, extra high

mode may be automatically selected when

the vehicle height is in H2 mode with the

four-wheel drive control switch in the L4

position.
The vehicle height is raised to 0.8 in. (20

mm) higher than the H2 mode height, or

slightly higher.

●

Extra high mode will change back to H2

mode when:

• The vehicle speed exceeds 6 mph (10

km/h)

• The four-wheel drive control switch is

shifted to H4.

●

If you press the height select switch

when in extra high mode, H1 mode

is selected.

●

Extra high mode cannot be manually

selected.

■

Turning off the height control

●

The system will remain off until the height

control OFF switch is pressed again,

even if the engine switch is turned off.

●

Even if the system is turned off, the sys-

tem will intervene automatically if the

vehicle speed exceeds the following.

• 18 mph (30 km/h) with H2 or L mode

• 62 mph (100 km/h) with N or H1 mode

■

Automatic leveling function

The vehicle is adjusted to a fixed height for

each mode, regardless of the number of

occupants and the luggage load.

■

When the vehicle is stopped during

driving

The activation of the automatic leveling

function may cause the vehicle height to

change. This is not a malfunction.

352

4-5. Using the driving support systems

■

If the vehicle height does not change

If the vehicle is loaded too heavily, or the

undercarriage has come into contact with

the road surface, the vehicle height cannot

be raised/lowered.
In the following situations, the vehicle is

loaded too heavily. Take extra care when

driving in this condition.

• If the vehicle height cannot be raised

when in N mode, and “L” appears on the

multi-information display

• If the vehicle height cannot be raised

when in H1 mode, and “L” or “N” appears

on the multi-information display

• If the vehicle height cannot be raised

when in H2 mode, and “L” or “N” or “H1”

appears on the multi-information display

If the vehicle height cannot be raised even
after unloading the vehicle, press the height
select switch

then press to

■

In the following cases the AHC will not

operate

●

The AHC display on the meter will flash.

●

Vehicle height control has not been fre-

quently used.

●

The suspension fluid temperature is

lower than -22°F (-30°C).

●

There is ice on the suspension.

●

Driving on bumpy roads which may

cause the suspension to fully elongate.

●

If the steering wheel is abruptly turned

more than 3/4 of a revolution with the

center differential lock system activated

(



P.354).

■

Cold weather operation

●

It may take longer for the vehicle height

to change if the suspension fluid tem-

perature drops below 5°F (-15°C).

●

The AHC does not operate when the

suspension fluid temperature drops

below -22°F (-30°C). In this case, even if

the height select switch is pressed, the

vehicle height will not change. Once the

vehicle has been driven for a short time

and the suspension fluid has been

warmed to within normal operating limits,

the AHC will begin operating and the

vehicle height will automatically change

to the selected mode.

■

Parking and stopping tips

●

If you immediately stop the engine after

off-road driving, the vehicle height may

gradually lower. When parking, make

sure there is nothing under the vehicle

that may come in contact with the under-

body. The vehicle will return to the set

height when the engine is started.

●

The vehicle height may change as the

temperature changes when the engine is

stopped. The vehicle will return to the set

height when the engine is started.

■

Propeller shaft noise

If the vehicle height is adjusted on a slope,

or with the shift lever in a position other than

P or N while the vehicle is stopped, you may

hear a sound caused by the expansion and

contraction of the propeller shaft. This does

not indicate a malfunction.

■

AHC failure warning

●

If a malfunction occurs in the AHC, N

mode is automatically selected. How-

ever, the system may not switch to N

mode depending on the location of the

malfunction. The warning message is dis-

played on the multi-information display,

and the AHC cannot be activated until

the malfunction is corrected.

●

Stop the engine and start it again. If the

warning message turns off, the system is

operating correctly. If the warning mes-

sage continues to be displayed, have the

vehicle checked at your Lexus dealer as

soon as possible.

WARNING

■

When switching the vehicle height

mode

Before lowering the vehicle height,

check that there are no people under or

around the vehicle, and check for obsta-

cles.
If you do not do this, body parts may be

caught in the vehicle, possibly leading to

an accident.

353

4-5. Using the driving support systems

Driving

WARNING

■

Using H2 mode

H2 mode should only be used when driv-

ing on rough roads, for example when

driving off-road. Because the vehicle’s

center of gravity will become higher

when in the mode, the vehicle may

become unstable when turning abruptly,

resulting in an accident.

■

When jacking up the vehicle or

installing tire chains

Turn off the height control and stop the

engine, otherwise the vehicle height may

change due to the automatic leveling

function and you may catch part of your

body in the vehicle, resulting in an acci-

dent.

■

When crossing rivers

Select H2 mode and turn off the height

control. Drive at 18 mph (30 km/h) or

lower. Otherwise the vehicle height may

change due to the automatic leveling

function, resulting in an accident.

■

If your vehicle must be towed

Put the vehicle height in N mode and

turn off the height control, otherwise the

vehicle height may change due to the

automatic leveling function and you may

catch part of your body in the vehicle,

resulting in an accident.

■

If your vehicle becomes stuck in a

ditch

Turn off the height control, otherwise the

vehicle height may change due to the

automatic leveling function, resulting in

an accident.

NOTICE

■

When parking in areas with limited

overhead height

After leaving the vehicle or unloading the

luggage, the vehicle height may be

slightly higher than normal. Take care

when overhead height is limited.

■

To avoid damage to the vehicle

●

N mode will be switched to automati-

cally even if the vehicle is started off in

L mode. Take care when overhead

height is limited.

●

Do not select L mode when driving on

bumpy roads, as the underbody of the

vehicle may contact the road surface.

●

When traveling on bumpy roads or

through water, or when towing, turn off

easy access mode.

■

Avoid rapid changes to the vehicle

height

As the pump may overheat. Leave a few

seconds between selections when

changing the vehicle height mode.

354

4-5. Using the driving support systems

H4 (high speed position)

Normal driving on all types of roads.

L4 (low speed position)

Driving requiring maximum power and
traction such as climbing or descending
steep hills, off-road driving, and hard pull-
ing in sand or mud, etc.
The low speed four-wheel drive indicator
will come on.

■

Shifting from H4 to L4

Stop the vehicle completely.

Shift the shift lever to N.

Push and turn the four-wheel drive
control switch counterclockwise.

Maintain this condition until the low speed

four-wheel drive indicator turns on.

■

Shifting from L4 to H4

Stop the vehicle completely.

Shift the shift lever to N.

Push and turn the four-wheel drive
control switch clockwise.

Maintain this condition until the low speed

four-wheel drive indicator turns off.

Lock the center differential when your
vehicle’s wheels get stuck in a ditch or
when driving on a slippery or bumpy
surface.

The center differential lock indicator will
come on.
To unlock the center differential, push the
switch again.
Unlock the center differential after the
wheels have been freed, or after moving to
a flat, non-slippery surface.

■

The four-wheel drive control switch can

be operated when

●

The engine switch is in ON.

●

The shift lever is in N.

●

The vehicle is stopped completely.

■

The low speed four-wheel drive indica-

tor light

The indicator light blinks while shifting

Four-wheel drive system

Use the four-wheel drive control
switch and center differential lock
switch to select the following trans-
fer and center differential modes.

Four-wheel drive control switch

Shifting between H4 and L4

Center differential lock switch

355

4-5. Using the driving support systems

Driving

between “H4” and “L4”.

■

Advice for driving on slippery roads

●

If you shift the four-wheel drive control

switch to L4 and the shift lever to the 2

range of M while driving in steep off-road

areas, the output of the brake can be

controlled effectively by the Active

TRAC, which assists the driver to control

the driving power of 4 wheels.

●

Use the 1 range of M for maximum power

and traction when your wheels get stuck

or when driving down a steep incline.

■

The center differential lock indicator

The indicator blinks while locking/unlock-

ing the center differential.

■

The center differential lock switch can

be operated when

●

The engine switch is in ON.

●

The vehicle speed is less than 62 mph

(100 km/h).

■

Locking/unlocking the center differen-

tial

●

When the four-wheel drive control

switch is in L4 with the center differential

locked, VSC is automatically turned off.

(The center differential lock and VSC

OFF indicator lights come on.)

●

If the operation is not completed, the

center differential lock indicator blinks. If

the indicator light does not turn off when

unlocking the center differential, drive

straight ahead while accelerating or

decelerating, or drive in reverse.

●

If the center differential lock/unlock is not

completed within 5 seconds while the

cruise control system is on, cancel the

cruise control system.

■

If the low speed four-wheel drive indica-

tor light or the center differential lock

indicator blinks

●

If the low speed four-wheel drive indica-

tor light continues to blink when using the

four-wheel drive control switch, stop the

vehicle completely, move the shift lever

to N and then operate the switch again.

●

If the shift lever is moved before the low

speed four-wheel drive indicator turns

on/off, the transfer mode may not be

shifted completely. The transfer mode

disengages both the front and rear drive-

shafts from the powertrain and allows the

vehicle to move regardless of the shift

position. (At this time, the indicator blinks

and the buzzer sounds.)

Therefore, the vehicle is free to roll even if
the shift lever is in P. You or someone else
could be seriously injured. You must com-
plete the shifting of the transfer mode.
To complete the shifting, stop the vehicle
completely, return the shift lever to N, and
confirm that the shift was completed (the
indicator turns on/off).

●

If the engine coolant temperature is too

low, the four-wheel drive control system

may not be able to shift. When the engine

is warmer operate the switch again.

If the low speed four-wheel drive indicator
light or the center differential lock indicator
continues to blink even after attempting the
above, there may be a malfunction in the
engine, the brake system or the four-wheel
drive system. In this case, you may not be
able to shift between H4 and L4, and the
center differential lock may not be opera-
ble. Have the vehicle inspected by your
Lexus dealer immediately.

WARNING

■

While driving

Never move the four-wheel drive control

switch if the wheels have lost traction.

Doing so may cause an accident result-

ing in death or serious injury.

356

4-5. Using the driving support systems

WARNING

■

When the vehicle is parked

If the shift lever is moved before the low

speed four-wheel drive indicator turns

on/off, the transfer mode may not be

shifted completely. The transfer mode

disengages both the front and rear drive-

shafts from the powertrain and allows the

vehicle to move regardless of the shift

position. (At this time, the indicator blinks

and the buzzer sounds.)
Therefore, the vehicle is free to roll even

if the shift lever is in P. You or someone

else could be seriously injured. You must

complete the shifting of the transfer

mode.

NOTICE

■

To prevent damage to the center dif-

ferential

●

For normal driving on dry and hard

surface roads, unlock the center differ-

ential.

●

Unlock the center differential after the

wheels are out of the ditch or off the

slippery or bumpy surface.

●

Do not push the center differential

lock switch when the vehicle is turning

or when its wheels are spinning freely

off the ground.

Crawl Control (with Turn
Assist function)

Allows travel on extremely rough
off-road surfaces at a fixed low
speed without pressing the accel-
erator or brake pedal. Minimizes
loss of traction or vehicle slip when
driving on slippery road surfaces,
allowing for stable driving.

WARNING

■

When using Crawl Control (with Turn

Assist function)

Do not rely solely on the Crawl Control

(with Turn Assist function). This function

does not extend the vehicle’s perfor-

mance limitations. Always thoroughly

check the road conditions, and drive

safely.

■

These conditions may cause the sys-

tem not to operate properly

When driving on the following surfaces,

the system may not be able to maintain a

fixed low speed, which may result in an

accident:

●

Extremely steep inclines.

●

Extremely uneven surfaces.

●

Snow-covered roads, or other slippery

surfaces.

NOTICE

■

When using Turn Assist function

The Turn Assist function is a function to

assist turning performance when driving

off-road. The function may be less effec-

tive on paved road surfaces.

357

4-5. Using the driving support systems

Driving

Meter (



P.72, 81)

Front Multi Operation Panel
(



P.378)

MODE SELECT switch

DAC/CRAWL switch

Press the DAC/CRAWL switch.

The indicator light

and the Crawl Con-

trol indicator on the meter will come on,

and the slip indicator light will flash.

Turn the MODE SELECT switch
left or right to select a mode on the
meter.

A mode which matches the road con-
ditions can be selected from among
the following 5 modes.

Suitable for driving on rocky roads or
decline

Lo-Mid

Suitable for driving on rocky roads, decline
or bumpy incline

System components

Turning Crawl Control on

A
B

C
D

Selectable modes

358

4-5. Using the driving support systems

Mid

Suitable for driving on bumpy inclines

Mid-Hi

Suitable for driving on bumpy inclines,
debris roads, snow-covered roads, muddy
roads, gravel roads and grass roads



When the DAC/CRAWL switch
indicator illuminates

Press the DAC/CRAWL switch again.



When the DAC/CRAWL switch
indicator does not illuminate

Press the DAC/CRAWL switch to
turn the indicator on. Press the
DAC/CRAWL switch again with the
indicator turned on.

If Crawl Control is turned off, the Crawl
Control indicator, slip indicator light and
the Turn Assist indicator (when the Turn
Assist function is in use) will go off and a
message stating that Crawl Control has
been turned off will be displayed on the
multi-information display for several sec-
onds.

When turning off Crawl Control while
driving, drive extremely carefully.

■

Operation conditions of the Crawl

Control

●

The engine is running.

●

The shift lever is in any gear other than P

or N.

●

The four-wheel drive control switch is in

L4.

●

The driver’s door is closed.

■

Automatic system cancelation of Crawl

Control

In the following situations, the buzzer will

sound intermittently and Crawl Control will

be canceled automatically. In this event, the

Crawl Control indicator will flash and then

go off, the Turn Assist indicator will go off (if

the Turn Assist function is in use), and a

message stating that Crawl Control has

been turned off will be displayed on the

multi-information display for several sec-

onds.

●

When the shift lever is moved to P or N.

●

When the four-wheel drive control

switch is in H4.

●

When the driver’s door is opened.

■

Function limitations of Crawl Control

●

In the following situations, brake control

can be used to drive downhill at a con-

stant speed. However, engine control is

not available when driving uphill at a con-

stant speed.

• When the vehicle speed exceeds

approximately 6 mph (10 km/h).

●

In the following situation, engine control

and brake control will stop temporarily. In

this event, the Crawl Control indicator

will flash.

• When the vehicle speed exceeds

approximately 15 mph (25 km/h).

■

When the Crawl Control system is

operated continuously

●

If Crawl Control is used continuously for

a long time, the brake system may over-

heat. In this case, a buzzer will sound, a

message stating a malfunction will be dis-

played on the multi-information display,

and the Crawl Control indicator will flash

and then go off. In this event, as Crawl

Control will be temporarily inoperable,

stop the vehicle immediately in a safe

place, and allow the brake system to cool

down sufficiently until the message goes

off. (In the meantime, normal driving is

possible.)

●

If Crawl Control is used continuously for

a long time, the automatic transmission

may overheat. In this case, a buzzer will

Turning Crawl Control off

359

4-5. Using the driving support systems

Driving

sound, the system will be temporarily

canceled, and a message stating a mal-

function may be displayed on the multi-

information display. In this event, stop the

vehicle in a safe place until the message

goes off.

■

Sounds and vibrations caused by the

Crawl Control system

●

A sound may be heard from the engine

compartment when the engine is started

or just after the vehicle begins to move.

This sound does not indicate that a mal-

function has occurred in Crawl Control

system.

●

Either of the following conditions may

occur when the Crawl Control system is

operating. None of these are indicators

that a malfunction has occurred.

• Vibrations may be felt through the vehi-

cle body and steering.

• A motor sound may be heard after the

vehicle comes to a stop.

■

When there is a malfunction in the sys-

tem

Warning lights and/or warning messages

will turn on. (



P.501, 506)

This function assists cornering perfor-
mance in accordance with steering
operation when driving through a tight
corner. It maintains vehicle speed
while driving and implements control
that improves turning performance
according to the driver’s steering
wheel operation, to reduce the number
of turns.

While Crawl Control is operating,
press the

on Front Multi Oper-

ation Panel to display the off-road

driving information display screen.
(



P.378)

Press the Turn Assist switch

The indicator light

and Turn Assist

indicator on the meter will come on.
To turn the system off, press the switch

again.

While the Turn Assist function is
operating, press the

on Front

Multi Operation Panel to display
the off-road driving information dis-
play screen. (



P.378)

Press the Turn Assist switch

The indicator light on the Turn Assist

switch and Turn Assist indicator on the

meter will go off, and a message stating

that the Turn Assist function has been

turned off will be displayed on the multi-

information display for several seconds.

■

Operation conditions of the Turn Assist

function

●

The vehicle speed is approximately 6

mph (10 km/h) or less.

●

Crawl Control is operating.

Turn Assist function

Turning the Turn Assist function
on

Turning the Turn Assist function
off

360

4-5. Using the driving support systems

●

The brake pedal is not depressed

●

The shift lever is in any gear other than P,

R or N.

●

The steering wheel is turned very far.

■

Function limitations of the Turn Assist

function

In the following situations, the Turn Assist

function will stop temporarily. In this event,

the Turn Assist indicator will flash.

●

When the vehicle speed exceeds

approximately 6 mph (10 km/h).

●

When the shift lever is moved to R.

■

When the battery is disconnected

The Turn Assist indicator will flash and the

system needs to be initialized. Drive the

vehicle straight ahead for a while at a speed

of approximately 22 mph (35 km/h) or

more. If the Turn Assist indicator still flashes

even after initializing the system, have the

vehicle inspected by your Lexus dealer.

Multi-terrain Select

Multi-terrain Select is a system that
improves drivability in off-road situ-
ations.

Select a mode that most closely
matches the type of terrain on which
you are driving from several modes.
Brake control, drive force control
and suspension control can be opti-
mized in accordance with the
selected mode.

When AUTO mode is selected,
brake control, drive force control
and suspension control are opti-
mized automatically according to
the road conditions.

WARNING

■

When using the Multi-terrain Select

Observe the following precautions to

avoid an accident that could result in

death or serious injuries:

●

Check that the selected mode indica-

tors are illuminated before driving.

Multi-terrain Select will not operate

when the indicators are off.

●

The road conditions listed (



P.361)

are for reference only. There is a

chance that the function may not be

the most appropriate in terms of road

conditions such as pitch, slipperiness,

undulation, etc. Thoroughly check the

road conditions before driving.

●

Multi-terrain Select is not intended to

expand the limits of the vehicle. Check

the road conditions thoroughly

beforehand, and drive safely and care-

fully.

361

4-5. Using the driving support systems

Driving

MTS switch

MODE SELECT switch

Multi-information display

Selected mode is displayed.

Press the MTS switch.

The indicator

on the switch will turn on.

Select the driving modes on the
multi-information display while
turning the MODE SELECT switch
left and right.

Depending on the positions of the four-

wheel drive control switch, a mode can be

selected from among the following modes.



Four-wheel drive control switch is in
L4

If the brake control has activated, the slip
indicator light will flash.



Four-wheel drive control switch is in
H4

NOTICE

■

Precaution for use

The Multi-terrain Select is intended for

use during off-road driving. Do not use

the system at any other time.

System components

Switching modes

Mode

Road Conditions

AUTO

Suitable for the road
conditions

SAND Suitable for sandy roads

MUD

Suitable for muddy
roads

ROCK

Suitable for rocky ter-
rain

Mode

Road Conditions

AUTO

Suitable for the road
conditions

DIRT

Suitable for dirt roads

SAND Suitable for sandy roads

362

4-5. Using the driving support systems

If the brake control has activated, the slip
indicator light will flash.
When the vehicle is in SAND, MUD or
DEEP SNOW mode, VSC is automatically
turned off. (VSC OFF indicator light come
on.)

■

Multi-terrain Select

Multi-terrain Select controls the vehicle so

that it can maximize the drive force and

improve drivability on rough roads. As a

result, fuel efficiency may diminish when

compared to driving in normal mode.

■

Automatic system cancelation

In the following situations, Multi-terrain

Select will be canceled automatically.

●

When the DRIVE MODE switch is

pressed while the four-wheel drive con-

trol switch is in H4.

●

When the engine switch is turned off

■

AUTO mode

Estimates the road conditions where the

vehicle is being driven and optimizes brake

control, drive force control and suspension

control.

The capability to estimate the road condi-

tions is limited and there is a chance that the

Multi-terrain Select may not be the most

appropriate for road conditions such as

pitch, slipperiness, undulation, etc.

In these cases, select the mode that

matches the road conditions before driving.

■

Turning off Multi-terrain Select

Performing the following turns Multi-terrain

Select off, and then the display on the multi-

information display will disappear.



When the MTS switch indicator is illumi-

nated

Press the MTS switch while the system is in
operation.



When the MTS switch indicator is not illu-

minated

Press the MTS switch to turn the indicator
on.
Press the MTS switch again with the Multi-
terrain Select indicator illuminated.

■

When the vehicle is stuck

Switching the transfer and differential

For the operation of the following functions,

refer to the following pages.

●

Four-wheel drive system (



P.354)

●

Center differential lock (



P.354)

■

Driving in Multi-terrain Select

The following types of situations may occur,

but they are not malfunctions.

●

Vibrations may be felt throughout the

vehicle or steering wheel.

●

Operating noise may be heard from the

engine compartment.

■

When an inspection at your Lexus

dealer is necessary

In the following situations, the system may

be malfunctioning. Have the vehicle

inspected by your Lexus dealer immedi-

ately.

●

When the slip indicator light illuminates.

●

When the indicator for each mode does

not illuminate on the multi-information

display even though Multi-terrain Select

is selected.

MUD

Suitable for muddy
roads

DEEP
SNO
W

Suitable for deep snow
roads

Mode

Road Conditions

363

4-5. Using the driving support systems

Driving

Press the DAC/CRAWL switch.

The downhill assist control system indica-
tor will come on and the system will oper-
ate.
When the system is in operation, the slip
indicator light will flash, and the stop
lights/high mounted stop lights will be lit. A
sound may also occur during the opera-
tion. This does not indicate a malfunction.

Turn the MODE SELECT switch to set
the desired speed (approx. 2 to 18
mph [4 to 30 km/h]). The set speed is
displayed on the multi-information dis-
play.

Increases the speed

Decreases the speed



When the DAC/CRAWL switch
indicator illuminates

Press the DAC/CRAWL switch again.



When the DAC/CRAWL switch
indicator does not illuminate

Press the DAC/CRAWL switch to
turn the indicator on. Press the
DAC/CRAWL switch again with the
indicator turned on.

The downhill assist control system indica-
tor will flash as the system gradually ceases
operation, and will turn off when the system
is fully off.
Press the DAC/CRAWL switch while the
downhill assist control system indicator is
flashing to start the system again.

Downhill assist control sys-
tem

The downhill assist control system
helps to prevent excessive speed
on steep downhill slopes. The sys-
tem will operate when the vehicle is
traveling under 18 mph (30 km/h)
and transfer mode is in H4.

WARNING

■

When using downhill assist control

system

Do not rely overmuch on the downhill

assist control system. This function does

not extend the vehicle’s performance

limitations. Always thoroughly check the

road conditions, and drive safely.

System operation

Setting the speed of the downhill
assist control system

Turning off the system

364

4-5. Using the driving support systems

■

Operating tips

The system will operate when the shift lever

is in a position other than P, however to

make effective use of the system it is recom-

mended to select a lower shift range.

■

If the downhill assist control system indi-

cator flashes

●

In the following situations, the indicator

flashes and the system will not operate:

• The four-wheel drive control switch is

changed to a position other than H4.

• The shift lever is in P.

• The vehicle speed exceeds approxi-

mately 18 mph (30 km/h).

• The brake system overheats.

●

In the following situations, the indicator

flashes to alert the driver, but the system

will operate:

• The shift lever is in N.

• The DAC/CRAWL sw

itch is pressed

while the DAC/CRAWL switch indica-

tor illuminates.

The system will gradually ceases operation.
The indicator will flash during operation,
and then go off when the system is fully off.

■

When the downhill assist control system

is operated continuously

If the downhill assist control system is oper-

ated for a long period of time, the brake sys-

tem may abnormally overheat. To prevent

that, a buzzer will sound and the function is

temporarily stopped.
In this case, the downhill assist control sys-

tem indicator will flash and “Traction Con-

trol Turned Off” will be shown on the multi-

information display. (The vehicle can be

driven normally during this time)
When the downhill assist control system

indicator switches to steadily illuminated

after a short while and the “Traction Con-

trol Turned Off” disappears, the system will

become available.

■

Sounds and vibrations caused by the

downhill assist control system

●

A sound may be heard from the engine

compartment when the engine is started

or just after the vehicle begins to move.

This sound does not indicate that a mal-

function has occurred in downhill assist

control system.

●

Either of the following conditions may

occur when the downhill assist control

system is operating. None of these are

indicators that a malfunction has

occurred.

• Vibrations may be felt through the vehi-

cle body and steering.

• A motor sound may be heard after the

vehicle comes to a stop.

■

System malfunction

In the following cases, have your vehicle

checked by your Lexus dealer.

●

The downhill assist control system indica-

tor does not come on when the

DAC/CRAWL switch is pressed.

●

The slip indicator light comes on.

WARNING

■

The system may not operate on the

following surfaces, which may lead to

an accident causing death or serious

injury

On the following surfaces, the vehicle

may be unable to maintain a constant low

speed especially when the grip perfor-

mance limit of the tires is exceeded or if

the tires do not make sufficient contact

with the ground. This could result in seri-

ous injury, or even death.

●

Slippery surfaces such as wet or

muddy roads

●

Icy surface

●

Very bumpy and rough roads

365

4-5. Using the driving support systems

Driving

■

ECB (Electronically Controlled
Brake System)

The electronically controlled system
generates braking force correspond-
ing to the brake operation

■

Multi Terrain ABS (Anti-lock
Brake System)

Helps to prevent wheel lock when the
brakes are applied suddenly, or if the
brakes are applied while driving on a
slippery road surface, or in off-road
conditions (such as rough roads, sand
and mud)
The Multi Terrain ABS operates in syn-
chronization with the Multi-terrain
Select

■

Brake assist

Generates an increased level of brak-
ing force after the brake pedal is
depressed when the system detects a
panic stop situation

■

VSC (Vehicle Stability Control)

Helps the driver to control skidding

when swerving suddenly or turning on
slippery road surfaces.

■

Enhanced VSC (Enhanced Vehi-
cle Stability Control)

Provides cooperative control of the
Multi Terrain ABS, Active TRAC, VSC
and EPS.
Helps to maintain directional stability
when swerving on slippery road sur-
faces by controlling steering perfor-
mance.

■

Trailer Sway Control

Helps the driver to control trailer sway
by selectively applying brake pressure
for individual wheels and reducing
driving torque when trailer sway is
detected.

■

Active TRAC (Traction Control)

Helps to maintain drive power and
prevent the drive wheels from spinning
when starting the vehicle or accelerat-
ing on slippery roads

■

Hill-start assist control

Helps to reduce the backward move-
ment of the vehicle when starting on an
uphill

■

EPS (Electric Power Steering)

Employs an electric motor to reduce
the amount of effort needed to turn the
steering wheel

■

VDIM (Vehicle Dynamics Inte-
grated Management)

Provides integrated control of the
Multi Terrain ABS, brake assist, Active
TRAC, VSC, hill-start assist control
and EPS systems. Helps to maintain

Driving assist systems

To keep driving safety and perfor-
mance, the following systems oper-
ate automatically in response to
various driving situations. Be
aware, however, that these systems
are supplementary and should not
be relied upon too heavily when
operating the vehicle.

Summary of the driving assist
systems

366

4-5. Using the driving support systems

vehicle stability when swerving on slip-
pery road surfaces by controlling the
brakes, engine output and steering
assist.

■

Adaptive Variable Suspension Sys-
tem (if equipped)

The damping force of the shock
absorbers are independently con-
trolled for the 4 wheels according to
factors including the road surface con-
ditions and driving operation, contrib-
uting toward enhancing smooth
driving comfort and superior stability,
and helping to maintain vehicle pos-
ture.
In addition, the damping force can be
changed by selecting the drive mode
with the driving mode select
(



P.344), and driving comfort can be

ensured during off-road driving by set-
ting the four-wheel drive control switch
to L4. (



P.354)

■

Secondary Collision Brake

When the SRS airbag sensor detects a
collision and the system operates, the
brakes and brake lights are automati-
cally controlled to reduce the vehicle
speed and help reduce the possibility
of further damage due to a secondary
collision.

■

When the Active TRAC/VSC/Multi

Terrain ABS/Trailer Sway Control sys-

tems are operating

The slip indicator light will flash while the

Active TRAC/VSC/Multi Terrain

ABS/Trailer Sway Control systems are

operating.

■

Disabling the Active TRAC system

If the vehicle gets stuck in mud, dirt or snow,

the Active TRAC system may reduce

power from the engine to the wheels.

Pressing

to turn the system off may

make it easier for you to rock the vehicle in
order to free it.
To turn the Active TRAC system off, quickly
press and release

“Traction Control Turned Off” will be

shown on the multi-information display.

Press

again to turn the system back on.

■

Turning off the Active

TRAC/VSC/Trailer Sway Control sys-

tems

To turn the Active TRAC/VSC/Trailer
Sway Control systems off, press and hold

for more than 3 seconds while the vehi-

cle is stopped.
The VSC OFF indicator light will come on

and the “Traction Control Turned Off” will
be shown on the multi-information display.

Press

again to turn the systems back

on.

: PCS will also be disabled (only Pre-Colli-

sion warning is available). The PCS warn-

367

4-5. Using the driving support systems

Driving

ing light will come on and a message will
be displayed on the multi-information dis-
play. (



P.229)

■

When the message is displayed on the
multi-information display showing that
Active TRAC has been disabled even if

has not been pressed

Active TRAC is temporary deactivated. If

the information continues to show, contact

your Lexus dealer.

■

Operating conditions of hill-start assist

control

When all of the following four conditions

are met, the hill-start assist control will

operate:

●

The shift lever is in a position other than P

or N (when starting off forward/back-

ward on an upward incline).

●

The vehicle is stopped.

●

The accelerator pedal is not depressed.

●

The parking brake is not engaged.

●

The engine switch is in ON

■

Automatic system cancelation of hill-

start assist control

The hill-start assist control will turn off in any

of the following situations:

●

The shift lever is shifted to P or N.

●

The accelerator pedal is depressed.

●

The brake pedal is depressed and the

parking brake is engaged.

●

A maximum of 2 seconds have elapsed

after the brake pedal is released.

●

The engine switch is turned to OFF.

■

Sounds and vibrations caused by the

Multi Terrain ABS, brake assist, VSC,

Trailer Sway Control, Active TRAC and

hill-start assist control systems

●

A sound may be heard from the engine

compartment when the brake pedal is

depressed repeatedly, when the engine is

started or just after the vehicle begins to

move. This sound does not indicate that a

malfunction has occurred in any of these

systems.

●

Any of the following conditions may

occur when the above systems are oper-

ating. None of these indicates that a mal-

function has occurred.

• Vibrations may be felt through the vehi-

cle body and steering.

• A motor sound may be heard also after

the vehicle comes to a stop.

■

ECB operating sound

ECB operating sound may be heard in the

following cases, but it does not indicate that

a malfunction has occurred.

●

Operating sound heard from the engine

compartment when the brake pedal is

operated.

●

Motor sound of the brake system heard

from the front part of the vehicle when

the driver’s door is opened.

●

Operating sound heard from the engine

compartment when one or two minutes

passed after the stop of the engine.

■

EPS operation sound

When the steering wheel is operated, a

motor sound (whirring sound) may be

heard. This does not indicate a malfunction.

■

Automatic reactivation of Active

TRAC, Trailer Sway Control and VSC

systems

After turning the Active TRAC, Trailer

Sway Control and VSC systems off, the sys-

tems will be automatically re-enabled in the

following situations:

●

When the engine switch is turned off.

●

If only the Active TRAC system is turned

off, the Active TRAC will turn on when

vehicle speed increases.

If both the Active TRAC and VSC sys-

tems are turned off, automatic re-

enabling will not occur when vehicle

speed increases.

■

Reduced effectiveness of the EPS sys-

tem

The effectiveness of the EPS system is

reduced to prevent the system from over-

heating when there is frequent steering

input over an extended period of time. The

steering wheel may feel heavy as a result.

Should this occur, refrain from excessive

368

4-5. Using the driving support systems

steering input or stop the vehicle and turn

the engine off. The EPS system should

return to normal within 10 minutes.

■

If the brake system overheats

The brake system may overheat. In this

case, a buzzer will sound, “Traction Control

Turned Off” is displayed on the multi-infor-

mation display, and Active TRAC and hill-

start assist control will be temporarily inop-

erable. In this event, stop the vehicle imme-

diately in a safe place, and allow the brake

system to cool down sufficiently. (There is

no problem with continuing normal driving.)

After a short time, the display message on

the multi-information display turns off, and

you will be able to use Active TRAC and

hill-start assist control.

■

Secondary Collision Brake operating

conditions

The system operates when the SRS airbag

sensor detects a collision while the vehicle

is in motion. However, the system does not

operate when the components are dam-

aged.

■

Secondary Collision Brake automatic

cancellation

The system is automatically canceled in any

of the following situations.

●

The vehicle speed drops to approxi-

mately 0 mph (0 km/h).

●

A certain amount of time elapses during

operation

●

The accelerator pedal is depressed a

large amount

WARNING

■

The Multi Terrain ABS does not oper-

ate effectively when

●

The limits of tire gripping performance

have been exceeded (such as exces-

sively worn tires on a snow covered

road).

●

The vehicle hydroplanes while driving

at high speed on wet or slick roads.

■

Stopping distance when the Multi

Terrain ABS is operating may exceed

that of normal conditions

The Multi Terrain ABS is not designed to

shorten the vehicle’s stopping distance.

Always maintain a safe distance from the

vehicle in front of you, especially in the

following situations:

●

When driving on dirt, gravel or snow-

covered roads

●

When driving with tire chains

●

When driving over bumps in the road

●

When driving over roads with pot-

holes or uneven surfaces

■

Active TRAC/VSC may not operate

effectively when

Directional control and power may not

be achievable while driving on slippery

road surfaces, even if the Active

TRAC/VSC system is operating.

Drive the vehicle carefully in conditions

where stability and power may be lost.

■

Hill-start assist control does not oper-

ate effectively when

●

Do not overly rely on hill-start assist

control. Hill-start assist control may

not operate effectively on steep

inclines and roads covered with ice.

●

Unlike the parking brake, hill-start

assist control is not intended to hold

the vehicle stationary for an extended

period of time. Do not attempt to use

hill-start assist control to hold the vehi-

cle on an incline, as doing so may lead

to an accident.

■

When the Active

TRAC/VSC/Trailer Sway Control is

activated

The slip indicator light flashes. Always

drive carefully. Reckless driving may

cause an accident. Exercise particular

care when the indicator light flashes.

369

4-5. Using the driving support systems

Driving

WARNING

■

When the Active

TRAC/VSC/Trailer Sway Control

systems are turned off

Be especially careful and drive at a

speed appropriate to the road condi-

tions. As these are the systems to help

enhance vehicle stability and driving

force, do not turn the Active

TRAC/VSC/Trailer Sway Control sys-

tems off unless necessary.
Trailer Sway Control is part of the VSC

system and will not operate if VSC is

turned off or experiences a malfunction.

■

Replacing tires

Make sure that all tires are of the speci-

fied size, brand, tread pattern and total

load capacity. In addition, make sure that

the tires are inflated to the recom-

mended tire inflation pressure level.

The Multi Terrain ABS, Active TRAC,

Trailer Sway Control and VSC systems

will not function correctly if different tires

are installed on the vehicle.

Contact your Lexus dealer for further

information when replacing tires or

wheels.

■

Handling of tires and the suspension

Using tires with any kind of problem or

modifying the suspension will affect the

driving assist systems, and may cause a

system to malfunction.

■

Trailer Sway Control precaution

The Trailer Sway Control system is not

able to reduce trailer sway in all situa-

tions. Depending on many factors such

as the conditions of the vehicle, trailer,

road surface and driving environment,

the Trailer Sway Control system may not

be effective. Refer to your trailer owner’s

manual for information on how to tow

your trailer properly.

■

If trailer sway occurs

Observe the following precautions.

Failing to do so may cause death or seri-

ous injury.

●

Firmly grip the steering wheel. Steer

straight ahead. Do not try to control

trailer swaying by turning the steering

wheel.

●

Begin releasing the accelerator pedal

immediately but very gradually to

reduce speed.

Do not increase speed. Do not apply

vehicle brakes.

If you make no extreme correction with
the steering or brakes, your vehicle and
trailer should stabilize. (



P.175)

■

Secondary Collision Brake

Do not rely solely upon the Secondary

Collision Brake. This system is designed

to help reduce the possibility of further

damage due to a secondary collision,

however, that effect changes according

to various conditions. Overly relying on

the system may result in death or serious

injury.

370

4-6. Driving tips

4-6.Driving tips



Specific design characteristics give
it a higher center of gravity than
ordinary passenger cars. This vehi-
cle design feature causes this type
of vehicle to be more likely to roll-
over. And, utility vehicles have a sig-
nificantly higher rollover rate than
other types of vehicles.



An advantage of the higher ground
clearance is a better view of the
road allowing you to anticipate
problems.



It is not designed for cornering at
the same speeds as ordinary pas-
senger cars any more than low-
slung sports cars are designed to
perform satisfactorily under off-
road conditions. Therefore, sharp
turns at excessive speeds may
cause the vehicle to rollover.

When driving your vehicle off-road,
please observe the following precau-
tions to ensure your driving enjoyment
and to help prevent the closure of
areas to off-road vehicles:



Drive your vehicle only in areas

Off-road precautions

This vehicle belongs to the utility
vehicle class, which has higher
ground clearance and narrower
tread in relation to the height of its
center of gravity to make it capable
of performing in a wide variety of
off-road applications.

Off-road vehicle features

WARNING

■

Off-road vehicle precautions

Always observe the following precau-

tions to minimize the risk of death, seri-

ous injury or damage to your vehicle:

●

In a rollover crash, an unbelted person

is significantly more likely to die than a

person wearing a seat belt. Therefore,

the driver and all passengers should

always fasten their seat belts.

●

Avoid sharp turns or abrupt maneu-

vers, if at all possible.

Failure to operate this vehicle cor-

rectly may result in loss of control or

vehicle rollover causing death or seri-

ous injury.

●

Loading cargo on the roof luggage

carrier will make the center of the

vehicle gravity higher. Avoid high

speeds, sudden starts, sharp turns,

sudden braking or abrupt maneuvers,

otherwise it may result in loss of con-

trol or vehicle rollover due to failure to

operate this vehicle correctly.

●

Always slow down in gusty crosswinds.

Because of its profile and higher cen-

ter of gravity, your vehicle is more sen-

sitive to side winds than an ordinary

passenger car. Slowing down will

allow you to have better control.

●

Do not drive horizontally across steep

slopes. Driving straight up or straight

down is preferred. Your vehicle (or

any similar off-road vehicle) can tip

over sideways much more easily than

forward or backward.

Off-road driving

371

4-6. Driving tips

Driving

where off-road vehicles are permit-
ted to travel.



Respect private property. Get
owner’s permission before entering
private property.



Do not enter areas that are closed.
Honor gates, barriers and signs that
restrict travel.



Stay on established roads. When
conditions are wet, driving tech-
niques should be changed or travel
delayed to prevent damage to
roads.

■

Additional information for off-road driv-

ing



For owners in U.S. mainland, Hawaii and

Puerto Rico:

To obtain additional information pertaining

to driving your vehicle off-road, consult the

following organizations.

●

State and Local Parks and Recreation

Departments

●

State Motor Vehicle Bureau

●

Recreational Vehicle Clubs

●

U.S. Forest Service and Bureau of Land

Management

WARNING

■

Off-road driving precautions

Always observe the following precau-

tions to minimize the risk of death, seri-

ous injury or damage to your vehicle:

●

Drive carefully when off the road. Do

not take unnecessary risks by driving

in dangerous places.

●

Do not grip the steering wheel spokes

when driving off-road. A bad bump

could jerk the wheel and injure your

hands. Keep both hands and especially

your thumbs on the outside of the rim.

●

Always check your brakes for effec-

tiveness immediately after driving in

sand, mud, water or snow.

●

After driving through tall grass, mud,

rock, sand, rivers, etc., check that there

is no grass, bush, paper, rags, stone,

sand, etc. adhering or trapped on the

underbody. Clear off any such matter

from the underbody. If the vehicle is

used with these materials trapped or

adhering to the underbody, a break-

down or fire could occur.

●

When driving off-road or in rugged

terrain, do not drive at excessive

speeds, jump, make sharp turns, strike

objects, etc. This may cause loss of

control or vehicle rollover causing

death or serious injury. You are also

risking expensive damage to your

vehicle’s suspension and chassis.

NOTICE

■

To prevent the water damage

Take all necessary safety measures to

ensure that water damage to the engine

or other components does not occur.

●

Water entering the engine air intake

will cause severe engine damage.

●

Water entering the automatic trans-

mission will cause deterioration in shift

quality, locking up of your transmission

accompanied by vibration, and ulti-

mately damage.

●

Water can wash the grease from

wheel bearings, causing rusting and

premature failure, and may also enter

the differentials, transmission and

transfer case, reducing the gear oil’s

lubricating qualities.

■

When you drive through water

If driving through water, such as when

crossing shallow streams, first check the

depth of the water and the bottom of the

riverbed for firmness. Drive slowly and

avoid deep water.

372

4-6. Driving tips



Use fluids that are appropriate to
the prevailing outside temperatures.

• Engine oil
• Engine coolant
• Intercooler coolant
• Washer fluid



Have a service technician inspect
the condition of the battery.



Have the vehicle fitted with four
snow tires or purchase a set of tire
chains for the rear tires

Ensure that all tires are the same size and
brand, and that chains match the size of the
tires.

: Tire chains cannot be mounted on vehi-

cles with 22-inch tires

NOTICE

■

Inspection after off-road driving

●

Sand and mud that has accumulated in

brake drums and around brake discs

may affect braking efficiency and may

damage brake system components.

●

Always perform a maintenance

inspection after each day of off-road

driving that has taken you through

rough terrain, sand, mud, or water. For

scheduled maintenance information,

refer to the “Warranty and Services

Guide”, “Owner’s Manual Supple-

ment” or “Scheduled Maintenance”.

Winter driving tips

Carry out the necessary prepara-
tions and inspections before driving
the vehicle in winter. Always drive
the vehicle in a manner appropriate
to the prevailing weather condi-
tions.

Pre-winter preparations

WARNING

■

Driving with snow tires

Observe the following precautions to

reduce the risk of accidents.

Failure to do so may result in a loss of

vehicle control and cause death or seri-

ous injury.

●

Use tires of the specified size.

●

Maintain the recommended level of air

pressure.

373

4-6. Driving tips

Driving

Perform the following according to the
driving conditions:



Do not try to forcibly open a window
or move a wiper that is frozen. Pour
warm water over the frozen area to
melt the ice. Wipe away the water
immediately to prevent it from
freezing.



To ensure proper operation of the
climate control system fan, remove
any snow that has accumulated on
the air inlet vents in front of the
windshield.



Check for and remove any excess
ice or snow that may have accumu-
lated on the exterior lights, outside
rear view mirrors, side windows,
vehicle’s roof, chassis, around the
tires or on the brakes.



Remove any snow or mud from the
bottom of your shoes before getting
in the vehicle.

Accelerate the vehicle slowly, keep a
safe distance between you and the
vehicle ahead, and drive at a reduced

WARNING

●

Do not drive in excess of 75 mph (120

km/h), regardless of the type of snow

tires being used.

●

Use snow tires on all, not just some

wheels.

■

When installing tire chains (vehicles

without 22-inch tires)

Turn off the AHC (if equipped).
The vehicle height may change due to

the automatic leveling function and you

may catch part of your body in the vehi-

cle, resulting in an accident. (



P.346)

■

Driving with tire chains (vehicles

without 22-inch tires)

Observe the following precautions to

reduce the risk of accidents.

Failure to do so may result in the vehicle

being unable to be driven safely, and may

cause death or serious injury.

●

Do not drive in excess of the speed

limit specified for the tire chains being

used, or 30 mph (50 km/h), which-

ever is lower.

●

Avoid driving on bumpy road surfaces

or over potholes.

●

Avoid sudden acceleration, abrupt

steering, sudden braking and shifting

operations that cause sudden engine

braking.

●

Slow down sufficiently before entering

a curve to ensure that vehicle control

is maintained.

●

Do not use LTA (Lane Tracing Assist)

system.

NOTICE

■

Repairing or replacing snow tires

Request repairs or replacement of snow

tires from your Lexus dealer or legiti-

mate tire retailers.

This is because the removal and attach-

ment of snow tires affects the operation

of the tire pressure warning valves and

transmitters.

Before driving the vehicle

When driving the vehicle

374

4-6. Driving tips

speed suitable to road conditions.



Park the vehicle and move the shift
lever to P without setting the park-
ing brake. The parking brake may
freeze up, preventing it from being
released. If the vehicle is parked
without setting the parking brake,
make sure to block the wheels.
Failure to do so may be dangerous
because it may cause the vehicle to
move unexpectedly, possibly lead-
ing to an accident.

When the parking brake is in automatic
mode, release the parking brake after shift-
ing the shift lever to P. (



P.193)



If the vehicle is parked without set-
ting the parking brake, confirm that
the shift lever cannot be moved out
of P

: The shift lever will be locked if it is

attempted to be shifted from P to any
other position without depressing the
brake pedal. If the shift lever can be
shifted from P, there may be a problem
with the shift lock system. Have the vehi-
cle inspected by your Lexus dealer
immediately.



Vehicles without 22-inch tires

Use the correct tire chain size when
mounting the snow chains. Chain size
is regulated for each tire size.

Side chain:

0.20 in. (5 mm) in diameter

0.71 in. (18 mm) in width

1.81 in. (46 mm) in length

Cross chain:

0.25 in. (6.3 mm) in diameter

0.89 in. (22.6 mm) in width

1.50 in. (38.1 mm) in length



Vehicles with 22-inch tires

Tire chains cannot be mounted.

Snow tires should be used instead.

Regulations regarding the use of tire
chains vary depending on location and
type of road. Always check local regu-
lations before installing chains.

When parking the vehicle

WARNING

■

When parking the vehicle

When parking the vehicle without apply-

ing the parking brake, make sure to

chock the wheels. If you do not chock the

wheels, the vehicle may move unexpect-

edly, possibly resulting in an accident.

Selecting tire chains

Regulations on the use of tire
chains

375

4-6. Driving tips

Driving

■

Tire chain installation (vehicles without

22-inch tires)

Observe the following precautions when

installing and removing chains:

●

Install and remove tire chains in a safe

location.

●

Install tire chains on the rear tires only.

Do not install tire chains on the front tires.

●

Install tire chains on rear tires as tightly as

possible. Retighten chains after driving

1/4 - 1/2 mile (0.5 - 1.0 km).

●

Install tire chains following the instruc-

tions provided with the tire chains.

NOTICE

■

Fitting tire chains (vehicles without

22-inch tires)

The tire pressure warning valves and

transmitters may not function correctly

when tire chains are fitted.

377

Interio

r fe

atures

Interior features

5-1. Display

Front Multi Operation Panel

378

Rear Multi Operation Panel (4-

passenger models).................

381

5-2. Lexus Climate Concierge

Lexus Climate Concierge.....

385

5-3. Using the air conditioning system

and defogger

Front automatic air conditioning

system .........................................

386

Rear air conditioning system

394

Heated steering wheel/seat heat-

ers/seat ventilators................

398

5-4. Using the interior lights

Interior lights list.........................

402

5-5. Using the storage features

List of storage features............

407

Luggage compartment features

.........................................................

414

5-6. Using the other interior features

Other interior features ............

418

Garage door opener...............

433

Lexus LX600 (2023 year). Manual in english - page 11
