Lexus RX300 (MCU15). Service manual - part 482

PP052–04

PP–48

–

PREPARATION

SUSPENSION AND AXLE

LEXUS RX300   (RM785E)

LUBRICANT

Item

Capacity

Classification

Front drive shaft

Outboard joint grease

Color=Yellow

Inboard joint grease

Color=Gray

115 – 135 g (4.1 – 4.8 oz.)

95 – 115 g (3.4 – 4.1 oz.)

Rear drive shaft

Outboard joint grease

Color=Gray

Inboard joint grease

Color=Yellow

107 – 117 g (3.77 – 4.13 oz.)

180 – 190 g (6.35 – 6.70 oz.)

Differential oil

0.9

± 0.05 liters

(0.95

± 0.05 US qts, 0.79 ± 0.04 lmp.qts)

Hypoid gear oil API GL–5

Above –18

°C (0°F)

SAE90

Below –18

°C (0°F)

SAE 80W or 80W–90

PP3DL–01

–

PREPARATION

SUSPENSION AND AXLE

PP–49

LEXUS RX300   (RM785E)

SSM (Special Service Materials)

08826–00090

Seal Packing 1281,

THREE BOND 1281 or equivalent

(FIPG)

Rear Differential

PP3DP–01

PP–50

–

PREPARATION

BRAKE

LEXUS RX300   (RM785E)

BRAKE

SST (Special Service Tools)

09992–00242

Turbocharger  Pressure Gauge

09992–00350

Brake Reservoir Pressure Adapter

09737–00011

Brake Booster Push Rod Gauge

09737–00010

Brake Booster Push Rod Gauge

09751–36011

Brake Line Union Nut 10 x 12 mm

Wrench

09737–00020

Brake Booster Push Rod Wrench

09709–29018

LSPV Gauge Set

09843–18020

Diagnosis Check Wire

09843–18040

Diagnosis Check Wire No.2

PP1E3–02

–

PREPARATION

BRAKE

PP–51

LEXUS RX300   (RM785E)

RECOMMENDED TOOLS

09082–00040

TOYOTA Electrical Tester.

09905–00013

Snap Ring Pliers .
