PP1E4–02

PP–52

–

PREPARATION

BRAKE

LEXUS RX300   (RM785E)

EQUIPMENT

Torque wrench

Micrometer

Brake disc

Dial indicator

Brake disc

Brake drum gauge

Brake disc

PP1E5–02

–

PREPARATION

BRAKE

PP–53

LEXUS RX300   (RM785E)

LUBRICANT

Item

Capacity

Classification

Brake fluid

–

SAE J1703 or FMVSS No. 116 DOT3

PP1DK–03

PP–54

–

PREPARATION

STEERING

LEXUS RX300   (RM785E)

STEERING

SST (Special Service Tools)

09023–38200

Union Nut Wrench  12mm

PS gear

09023–38400

Union Nut Wrench 14mm

PS gear

09249–63010

Torque Wrench Adaptor

PS vane pump

09521–24010

Drive Shaft Boot Clamping Tool

PS gear

09527–20011

Rear Axle Shaft Bearing Remover

PS gear

09612–00012

Rack & Pinion Steering Rack

Housing Stand

PS gear

09612–22011

Tilt Handle Bearing Replacer

PS gear

09612–24014

Steering Gear Housing Overhaul

Tool Set

(09613–22011)

Steering Rack Shaft Bushing

Puller

PS gear

09616–00011

Steering Worm Bearing Adjusting

Socket

PS gear

09631–10021

Rack Stopper Wrench

PS gear

09631–12071

Steering Rack Oil Seal Test Tool

PS gear

–

PREPARATION

STEERING

PP–55

LEXUS RX300   (RM785E)

09631–20081

Seal Ring Tool

PS gear

09631–33010

Steering Rack Cover ”I”

PS gear

09640–10010

Power Steering Pressure Gauge

Set

(09641–01010)

Gauge Assy

Power steering fluid

(09641–01020)

Attachment A

Power steering fluid

(09641–01030)

Attachment B

Power steering fluid

09922–10010

Variable Open Wrench

PS gear

09950–50012

Puller C Set

(09951–05010)

Hanger 150

Tilt steering column

(09952–05010)

Slide Arm

Tilt steering column

(09953–05020)

Center Bolt 150

Tilt steering column

(09954–05020)

Claw No.2

Tilt steering column

09950–60010

Replacer Set
