ANTI-RUST AGENT (WAX) APPLICATION
D Apply the anti-chipping paint after
the top coat.
D Apply the anti-chipping paint before
the second coat.
Anti-Chipping Paint
Top Coat
Second Coat
Under coat (ED Primer)
Top Coat
Second Coat
Anti-Chipping Paint
Under coat (ED Primer)
Steel Metal
Steel Metal
ANTI-RUST TREATMENT –
General Information
AR-3
ANTI-RUST TREATMENT AFTER PAINTING PROCESS
1.
ANTI-RUST AGENT (WAX) APPLICATION
To preserve impossible to paint areas from corro-
sion, always apply sufficient anti-rust agent (wax) to
the inside of the hemming areas of the doors and
hoods, and around the hinges, or the welded sur-
faces inside the boxed cross-section structure of the
side member, body pillar, etc.
REFERENCE:
ANTI-RUST TREATMENT BY PAINTING
Painting prevents corrosion and protects the sheet metal from damage. In this section, anti-chipping paint
only for anti-corrosion purpose is described.
1.
ANTI-CHIPPING PAINT
To prevent corrosion and protect the body from damage by flying stones, etc., apply anti-chipping
paint to the rocker panel, wheel arch areas, valance panel, etc.
HINT:
Depending on the model or the application area, there are cases where the application of anti-chipping
paint is necessary before the second coat or after the top coat.
