Hyundai i30 / Elantra Neos. Body repair manual - part 38

BT-2

BODY MODIFICATION TOOLS

Frame straightener

Port power

Body puller

Modify twisted or bent body

Push out, stretch, pull in damaged area

Stretch damaged area

BODY MODIFICATION TOOLS

MODIFICATION  TOOLS

A3EB3501

A3EB3502

A3EB3503

A3EB3504

A3EB3505

Name

Used for

Figure

BODY MODIFICATION TOOLS

BT-3

Air saw

Air chisel

Rotary cutter

Air drill

Spot cutter

Cut a panel

Cut a panel

Cut a panel

Cut and disassemble spot welded area

CUT AND DISASSEMBLY TOOLS

Name

Used for

Figure

Hand saw and

metal scissors

Cut or bend a panel, cut and

disassemble spot welded area

Fix a spot cutter or drill to cut or

disassembly spot welding area, to

finish a hole

A3EB3506

A3EB3507

A3EB3508

A3EB3509

A3EB3510

A3EB3511

BT-4

BODY MODIFICATION TOOLS

ASSEMBLY  TOOLS

Vice pliers

Air bench

Quick bench

Flanging tool

Fix a panel or area to weld

Finish a hole for plug welding

Finish contact area of flange

Name

Used for

Figure

Finish contact area of  flange and finish

a hole for plug welding

MEASUREMENT  TOOLS

Centering gauge

Tracking gauge

Measure distortion of body and frame

Measure body and frame

Name

Used for

Figure

A3EB3512

A3EB3513

A3EB3514

A3EB3515

A3EB3516

A3EB3517

BODY MODIFICATION TOOLS

BT-5

Gas welding machine

Spot welding machine

Stud welding machine

Cut a panel

Weld a panel

Weld a panel

A3EB3518

A3EB3519

A3EB3520

A3EB3521

Name

Used for

Figure

WELDING MACHINE

Carbon arc welding

machine

Stretch a panel, weld a stud bolt to fix

front window mold clip
