Hyundai i30 / Elantra Neos. Body repair manual - part 39

BT-6

BODY MODIFICATION TOOLS

Disk grinder

Disk sander

Belt sander

Small sized grinder

Double action sander

Orbital sander(short)

Buff

Buff

Buff paints

Buff paints or smooth finishing

BUFFING AND GRINDING  TOOLS

Name

Used for

Figure

Grind rough area of puttee assembled

area

A3EB3522

A3EB3523

A3EB3524

A3EB3525

A3EB3526

A3EB3527

Grind rough area of puttee assembled

area

BODY MODIFICATION TOOLS

BT-7

Orbital sander(long)

Flexible file

Surform tool

Hand file

Used for puttee grinding of wide area

Buff rough area of puttee area

Grind body puttee, pulley, finish puttee

Name

Used for

Figure

A3EB3528

A3EB3529

A3EB3506

A3EB3530

A3EB3531

Grind touch up area, uneven area of a

panel

BT-8

BODY MODIFICATION TOOLS

Body hammer and dolly

Center punch

Plane chisel

Weight hammer

Bowl pin hammer

Spoon

-

Cut and disassemble a panel

Used when greater force is required

Used when smaller force is required

HANDHELD TOOLS

Name

Used for

Figure

Punch a hole in the middle of a spot

welding area

A3EB3532

A3EB3533

A3EB3534

A3EB3535

A3EB3536

A3EB3537

Used for an area where not reached by

hand

BODY MODIFICATION TOOLS

BT-9

Body chisel

Wire brush

Name

Used for

Figure

A3EB3538

A3EB3539

Remove paints, rust, slag on welded

area which are hard to recognize

Window tool set

Repair window collar

Repair plastic parts

Name

Used for

Figure

A3EB3540

A3EB3541

Bend rough body line damaged or sheet

metal etc.

REPAIR TOOLS  SET

Repair tool set for

plastics
