Hyundai i30 / Elantra Neos. Body repair manual - part 36

CORROSION PROTECTION

CP-7

UNDER  BODY & SIDE BODY COAT

In order to provide corrosion, stone chipping and vibration resistance, under body coat is applied to the under sides of the
floor  and wheel house.
Therefore, when such  panel is replaced or repaired, apply under body coat to that part.

BFDCP6002

C

C

B

B

E

E

A

A

D

D

F

F

X

Y

Under body coating  (Thickness             : 1.0 mm ,             :1.5 mm ,             : 2.0mm)

CP-8

CORROSION PROTECTION

BFDCP6105

BFDCP6103

BFDCP6107

BFDCP6106

BFDCP6104

B - B

D - D

A - A

C - C

G

G

[ Wagon ]

Fender apron upper inner panel

Shock absorber

housing lower

panel

Front side

inner member

Side outer rear extension

Side frame
mounting rear support

Side frame mounting
rear reinforcement

Fender apron
upper outer
panel

Shock absorber
housing cover

Front side outer member

Tie down front reinforcement

Center floor

side member

Side sill inner panel

Side outer

panel

Side frame

mounting rear

 bracket

CORROSION PROTECTION

CP-9

BFDCP6111

BFDCP6110

BFDCP6112

BFDCP6109

BFDCP6108

E - E

Y

F - F

X

G - G

Rear floor rear panel

Rear floor

center cross

member

[ 5Door ]

20mm

50mm

50mm

Rear suspension
mounting bracket

Wheel house

inner panel

Outer inner uper panel

Side outer panel

Rear floor rear panel

Rear floor center

cross member

Back panel

[ Wagon ]

20mm

50mm

50mm

CP-10

CORROSION PROTECTION

SIDE BODY

CAVITY WAX INJECTION

In order to provide greater corrosion resistance, cavity wax injection has been performed for the lower areas of the vehicle,
such as the side member, the side sill and the inside of other panels which have a hollow construction.
When replacing these parts, be sure to apply cavity wax to the appropriate areas of the new parts.

BFDCP6213

BFDCP6212

A - A

40mm

Wax injection hole

Side sill inner panel

Side outer panel

Side sill inner front extension

Side sill outer
reinforcement

25

16

A

A
