CORROSION PROTECTION
CP-3
1.
Heat the "antivibration pad" with a blow drier to soften
it.
2.
Align the antivibration pad layer in the position where
it is to be installed, and then press it down with a roller
or a block of wood so that it adheres well.
NOTE
An infrared lamp can also be used to heat both the
antivibration pad layer and the body panels(be sure to
wear gloves).
BMCCP6041
BMCCP6042
ATTACHMENT OF ANTIVIBRATION PADS
Antivibration pads are attached to the upper surface of the floor and at the interior side of the dash panel in order to absorb
vibrations and shut out exhaust gas heat. If these antivibration pads are peeled off in the course of replacement or repair of
a welded panel, cut and attach replacement material (in the shape shown in the figure).
BFDCP6201
F
F
84123-1H000
84127-1H000
84125-2L000
84181-1H000
84171-1H000
84115-2L000
84117-1H000
84113-1H000
84193-2L000
