Citroen DS4 (2017 year). Manual

383

Audio and Telematics

DS4_en_Chap10c_RD5_ed01-2016

DAB (Digital Audio Broadcasting) radio

Display options:
if active but not available, the display will be
struck out.

Preset stations, buttons 1 to 6.
Short press: select the preset radio
station.
Long press: preset a radio station.

Display the name of the multiplex
service being used.

Represents the signal strength for the
band being listened to.

Display of RadioText (TXT) for the
current radio station.

Display the name of the current
station.

If the "DAB" station being listened to
is not available on "FM", "DAB FM" is
struck out.

384

Audio and Telematics

DS4_en_Chap10c_RD5_ed01-2016

Select "Multimedia

" and confirm.

Select "DAB / FM auto tracking"
and confirm

Long press: select the desired
categories of announcements from
Transport, News, Entertainment and
Flash special (availability according
to the station).

Change of station within the same
"multiplex service".

Press the "Menu

" button.

Start a search for the next "multiplex
service".

Change band (FM1, FM2, DAB, ...).

Digital radio provides a superior audio
quality and also additional categories of
traffic announcements (TA INFO).
The different "multiplex services"
offer a choice of radio stations in
alphabetical order.

Digital radio

When the radio station is displayed in
the screen, press on "OK

" to display

the contextual menu.
(Frequency hopping (RDS), DAB / FM
auto tracking, RadioText (TXT) display,
Information on the station, ...)

DAB / FM tracking

"DAB" does not have 100% coverage of
the country.
When the digital signal is weak,
"DAB / FM auto tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding analogue "FM" station
(if it exists).

If "DAB / FM auto tracking" is on, there
will be a difference of a few seconds
in the programme when the system
changes to analogue "FM" radio, with
sometimes a variation in volume.
When the strength of the digital signal
is good again, the system automatically
switches back to "DAB"

If the "DAB" station you are listening
to is not available on "FM" ("DAB/FM"
option barred), or if "DAB / FM auto
tracking" is not on, the sound will be cut
when the digital signal is too weak.

385

Audio and Telematics

DS4_en_Chap10c_RD5_ed01-2016

Press and hold one of the buttons for
fast forward or backward.

Press one of the buttons to select a
track on the CD.

Press LIST

to display the list of

tracks on the CD.

To play a disc which has already
been inserted, press the SOURCE
or SRC

button several times in

succession and select "CD".

Audio CD

Playing a CD

Insert 12 cm diameter circular compact discs
only.
Some anti-pirating systems, on original discs
or CDs copied using a personal recorder, may
cause faults which are no reflection on the
quality of the original player.
Without pressing the EJECT button, insert a
CD in the player, play begins automatically.

CD, USB

Information and advice

The audio system will only play files with
extension ".mp3" or ".wma" and a compression
rate that is constant or variable between
32 Kbps and 320 Kbps.

It is advisable to restrict file names to
20 characters without using special characters
(e.g. " ? ; ù) to avoid any playing or displaying
problems.

The playlists accepted are types .m3u and .pls.
The number of files is limited to 5 000 in
500 directories on a maximum of 8 levels.

On a single disc, the CD player can
read up to 255 MP3 files spread
over 8 directory levels. However, it
is recommended that this be kept to
2 levels so as to limit the time taken to
access and play the CD.
During play, the folder structure is not
observed.

In order to be able to play a recorded CDR or
CDRW, when recording it is preferable to select
standards ISO 9660 level 1. 2 or Joliet.
If the disc is recorded in another format, it may
not be played correctly.
It is recommended that the same recording
standard is always used for an individual disc,
with as low a speed as possible (4x maximum)
for optimum sound quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

Use only USB memory sticks formatted FAT32
(File Allocation Table).

Do not connect a hard disk or USB
device other than audio players to the
USB port. This may cause damage to
your installation.

To protect the system, do not use a
USB hub.

Media

386

Audio and Telematics

DS4_en_Chap10c_RD5_ed01-2016

Up a level in the menu.

Select a line in the list.

Press one of the buttons to select the
next or previous track.

Press and hold one of the buttons for
fast forwards or backwards.

Skip a track.

Select a track or a folder.

Press LIST

to display the menu of

folders in the compilation.

To play a disc or memory stick which
has already been inserted, press
SOURCE or SRC

several times in

succession and select "CD" or "USB".

Press one of the buttons to select the
next or previous folder in the order
chosen.

CD, USB

Playing a compilation

Insert an MP3 compilation in the CD
player or connect a memory stick to the
USB port, directly or via an extension
lead.

The system creates playlists (temporary
memory) the creation time for which can take
from a few seconds to several minutes.
The playlists are updated every time the
ignition is switched off or a USB memory stick
is connected.
Play starts automatically after a period which
depends on the capacity of the USB memory
stick.

At a first connection, the order suggested is
by folder. When connecting again, the order
previously chosen is retained.

387

Audio and Telematics

DS4_en_Chap10c_RD5_ed01-2016

Having selected the desired sorting
("By folders", "By artists", "By
genres", "By playlists") press OK

Then confirm OK to save the
modifications.
-

By folders

: all folders containing

audio files recognised on the
peripheral device, in alphabetical
order without following the folder
structure.

By artists

: all of the artist names

defined in the ID3 Tags, in
alphabetical order.

By genres

: all of the genres

defined in the ID3 Tags.

By playlists

: if playlists have

been saved.

Make a long press on LIST or press
MENU, select "Multimedia", then
"Media parameters

" and finally

"Choice of track listing

" to display

the different types of sorting.

USB memory stick - File

sorting

* Check your player's manual.

USB port

The audio files on a Mass Storage portable
player* can be heard through the vehicle's
speakers by connecting it to the USB port
(cable not supplied).

To protect the system, do not use a
USB hub.

Management of the device is via the
audio system controls.

If the portable player is not recognised by
the USB port, connect it to the auxiliary Jack
socket.
The Apple

player must be updated regularly

for the best connection.

The playlists are those defined in the
Apple

player.

The Apple

player must be generation 5 or

later.

388

Audio and Telematics

DS4_en_Chap10c_RD5_ed01-2016

Activate the streaming source by
pressing SOURCE or SRC. Control
of playback is via the audio system.
The contextual information can be
displayed in the screen.

Then adjust the volume of the audio
system.

Pair/connect the telephone: see the
"USING THE TELEPHONE" section.

Press the SOURCE or SRC button
several times in succession and
select "AUX

Auxiliary socket (AUX)

The auxiliary Jack socket permits the
connection of a portable non-mass storage
device or an Apple

player if not recognised by

the USB port.

Do not connect a device to the USB
port and to the auxiliary Jack socket at
the same time.

Connect the portable device to the auxiliary
Jack socket using a suitable cable (not
supplied).

First adjust the volume on your portable device.

The display and management of controls is on
the portable device.

Depending on the compatibility of the phone

Streaming - Playing audio

files via Bluetooth

Streaming allows music files on a telephone to
be heard via the vehicle's speakers.
The telephone must support the appropriate
Bluetooth profiles (Profiles A2DP / AVRCP).

In certain cases, playing of the
audio files must be initiated from the
telephone.

The audio quality depends on the quality of the
transmission from the telephone.

389

Audio and Telematics

DS4_en_Chap10c_RD5_ed01-2016

Select "Multimedia

" and confirm.

Select "Media parameters

" and

confirm.

Select "Read mode

" and confirm.

Select the desired play mode and
confirm OK to save the modifications.

Press OK for access to the
contextual menu.
or
Press MENU

Play mode

The play modes available are:
- Normal: the tracks are played

in order, depending on the
classification of the selected files.

- Random: the tracks in an album

or folder are played in a random
order.

- Random all: all of the tracks saved

in the media are played in random
order.

- Repeat: the tracks played are only

those from the current album or
folder.

390

Audio and Telematics

DS4_en_Chap10c_RD5_ed01-2016

A message is displayed on the screen of the
telephone: enter the same code and confirm.

Select "Bluetooth connection

" and

confirm.

A virtual keypad is displayed on the
screen: enter a code with at least
4 digits and conform with OK.

Select "Search for a device

Select the telephone to be connected
from the list. Only one telephone can
be connected at a time.

A window is displayed "Search in progress…".

In some cases, the reference number of the
telephone or the Bluetooth address may appear
instead of the name of the telephone.

If pairing fails, try again; the number of attempts is not limited.

Accept the connection to the telephone.

A message appears in the screen to confirm
successful connection.

Pairing can also be initiated from the
telephone by searching for detected
Bluetooth devices.
The directory and the calls list can be
accessed after the synchronisation
period (if the telephone is compatible).
Automatic connection must be
configured in the telephone to allow
the connection each time the vehicle
is started.

Press MENU

Telephone

Pairing a telephone
First connection

The services offered depend on the network,
the SIM card and the compatibility of the
Bluetooth telephone used.
Consult your telephone's manual and your
operator to find out which services are
available to you.

As a safety measure and because they
require prolonged attention on the part
of the driver, the operations for pairing
of the Bluetooth mobile telephone with
the Bluetooth hands-free system of
your audio system must be carried out
with the vehicle stationary

and the

ignition on.
Visit www.citroen.co.uk for more
information (compatibility, additional
help, ...).

Activate the telephone's Bluetooth function
and ensure that it is "visible to all" (refer to the
telephone user guide).

391

Audio and Telematics

DS4_en_Chap10c_RD5_ed01-2016

Streaming - Playing audio

files via Bluetooth

Pair/connect the telephone then play the files:
see the "Pairing" section.

The telephone connection
automatically includes hands free
operation and audio streaming.
The ability of the system to connect
to just one profile depends on the
telephone. Both profiles may connect
by default.

Indicates that a device is connected.

Indicates connection of the audio
steaming profile.

Indicates connection of the hands-
free profile.

Press MENU

Managing connections

Select "Bluetooth connection

" and

confirm.

Select "Connections management"
and confirm. The list of paired
telephones is displayed.

Select a telephone and confirm.

392

Audio and Telematics

DS4_en_Chap10c_RD5_ed01-2016

To display the "TELEPHONE" menu:
- Make along press on SOURCE

or SRC

- Or, press OK to display the

contextual menu. Select "Call"
and confirm.

- Or, press MENU, select

"Telephone

" and confirm.

Select "Call

" and confirm.

Select "Dial

" to enter a number and

confirm.

Select OK

and confirm to start the

call.

Select numbers one at a time using
the 7

and 8 buttons and confirm.

Making a call - Dialling

Correction allows numbers to be deleted one
at a time.

Then select and confirm:
- "Connect telephone

" /

"Disconnect telephone

to connect / disconnect the
telephone or the hands-free
connection only.

- "Connect media player

" /

"Disconnect media player

to connect / disconnect only
streaming.

- "Connect telephone +

media player

" / "Disconnect

telephone + media player

to connect / disconnect the
telephone (hands-free and
streaming).

- "Delete connection

": to delete

the pairing.

393

Audio and Telematics

DS4_en_Chap10c_RD5_ed01-2016

To display the "TELEPHONE" menu:
- Make a long press on SRC/TEL.
- Or, press the dial to display the

contextual menu. Select "Call"
and confirm.

- Or, press MENU, select

"Telephone

" and confirm.

Select "Call

" and confirm.

To display the "TELEPHONE" menu:
- Make a long press on SRC/TEL.
- Or, press the dial to display the

contextual menu. Select "Call"
and confirm.

- Or, press MENU, select

"Telephone

" and confirm. Select

"Call

" and confirm.

Select "Calls list

" and confirm.

Select "Directory

" and confirm.

Select the number and confirm to
start the call.

Making a call - Recently called

numbers*

Making a call - From the

directory of contacts

The calls list includes calls sent
and received in the vehicle using
the connected telephone.

It is possible to make a call directly
from the telephone; park the vehicle
first as a safety measure.

* Depending on the compatibility of the

telephone.

394

Audio and Telematics

DS4_en_Chap10c_RD5_ed01-2016

During a call, press OK to display the
contextual menu.

A long press on ESC or on TEL,
SOURCE or SRC

also rejects an

incoming call.

Select a contact then confirm.

Select the number and confirm.

"YES

" to accept the call is selected

by default.
Press OK

to accept the call.

Select "NO

" and confirm to reject

the call.
or
Press one of these buttons to accept
the call.

In the contextual menu, select
"Hang up

" to end the call.

A long press on one of these buttons
also ends the call.

Home

Receiving a call

An incoming call is announced by a ring and
a superimposed display in the multifunction
screen.

Business

Mobile
(depending on the information
available in the contact
records of the telephone
connected).

Managing calls

Hang up

395

Audio and Telematics

DS4_en_Chap10c_RD5_ed01-2016

(so that the caller cannot hear)

In the contextual menu:
-

select "Micro OFF" to switch off
the microphone.

- deselect "Micro OFF" to switch

the microphone on.

In the contextual menu:
-

select "Telephone mode" to
transfer the call to the telephone.

- deselect "Telephone mode" to

transfer the call to the vehicle.

From the contextual menu, select
"DTMF tones

" and confirm to use

the digital keypad to navigate in the
interactive voice response menu.

From the contextual menu, select
"Switch

" and conform to return to a

call left on hold.

Secret - Mute

Combined mode

Interactive voice response

Consultation call

In certain cases, the combined mode has to
activated from the telephone.
If the contact has been cut off, when you
reconnect on returning to the vehicle,
the Bluetooth connection will be restored
automatically (depending on the compatibility of
the telephone).

(to leave the vehicle without ending the call)

396

Audio and Telematics

DS4_en_Chap10c_RD5_ed01-2016

To modify the contacts saved in the
system, press MENU then select
"Telephone

" and confirm.

Select "Directory management"
and confirm.
You can:
- "Consult an entry",
- "Delete an entry",
- "Delete all entries

Make a long press on SOURCE or
SRC

for access to the directory

or press OK

, and

select "Call

" and confirm.

The system accesses the telephone's
contacts directory, depending on
its compatibility, and while it is
connected by Bluetooth

With certain telephones connected
by Bluetooth

you can send a contact

to the directory of the audio system.
Contacts imported in this way are
saved in a permanent directory
visible to all, whatever the telephone
connected.
The menu for the directory is not
accessible if it is empty.

Select "Directory" to see the list of
contacts.

Citroen DS4 (2017 year). Manual - part 25
