Citroen C4 Dag (2013 year). Manual

239

For the details of the menus, refer to the "Screen menu map"

section.

For cleaning the screen, the use of a soft, non-abrasive cloth

(spectacles cloth) is recommended, with no additional product.

" TRIP COMPUTER "
(Permanent display)

" RADIO "

SETUP : PARAMETERS date and time, display

confi guration, sound, vehicle settings.

  Changing the audio source:
RADIO :   RADIO broadcasts.
  MUSIC : playing MUSIC.

Press the MODE button several times in succession for access to the following displays:

GENERAL OPERATION

" FULL SCREEN MAP "

" MAP IN WINDOW "
(If navigation guidance in

progress)

240

A press on the knob gives access

to short-cut menus according to the

display in the screen.

GENERAL OPERATION

Display according to context

RADIO:

Activate / Deactivate TA
Activate / Deactivate RDS

MUSIC MEDIA PLAYERS,

CD or USB (according to

media):

Play modes:

Normal
Random
Random on all media
Repetition

TELEPHONE (call in

progress):

Private mode

FULL SCREEN MAP OR

IN A NEW WINDOW:

Stop / Restore guidance

Select destination

Enter an address

Directory

GPS coordinates

Divert route

Move the map

Info. on location

Select as destination

Select as stage

Save this place (contacts)

Quit map mode

Guidance criteria

Put call on hold

DTMF ring tones
Hang up

Change waveband

241

List of recent destinations.

" Navigation - guidance "

To delete the list of recent destinations, select " Guidance

options " in the navigation menu then select " Delete last

destinations " and confi rm. Select " Yes " then confi rm.
Deleting just one destination is not possible.

Go from the list to the menu (left/right).

" Select destination "
" Journey leg and route "
" Guidance options "
" Map management "
" Stop / Restore guidance "

NAVIGATION - GUIDANCE

Access to the "Navigation" menu

Press NAV .

To make full use of all of the

functions of your navigation

system, update the mapping

regularly. Contact a

CITROËN dealer or order

your mapping update at

http://citroen.navigation.com

A short press on the end of the

lighting control stalk repeats

the last navigation message.

242

Press NAV to display the

" Navigation - guidance " menu.

Towards a new destination

NAVIGATION - GUIDANCE

Selecting a destination

Select " Select destination " and

confi rm, then select " Enter an address "

and confi rm.

Select the " Country " function then

confi rm.

Select the " Town " or " Post code "

function then confi rm.

Select the letters in the name of the

town or the characters in a post code

one at a time, confi rming each one with

the knob.

Selection the town from the list offered,

then confi rm
A pre-set list (by entering the fi rst few

letters) of the towns in the country

selected can be accessed directly by

selecting and confi rming " List " in the

screen.

If possible, enter the " Road " and " N°/X "

information in the same way.

Select " Archive " to save the address entered in a contact fi le.
The system allows up to 400 contact fi les to be recorded.

Confi rm " OK " to start guidance.

Select the guidance criteria: " Fastest

route ", " Shortest route " or optimised

" Distance/Time ", then select the

desired restriction criteria: " With tolls ",

" With Ferry ", or " Traffi c info " then

confi rm " OK ".

243

Towards a recent destination

Press NAV to display the

" Navigation - guidance " menu.

Select the desired destination and

confi rm to start guidance.

Towards a contact in the contacts directory

Select " Select destination " and

confi rm, then select " Directory " and

confi rm.

Selection the desired destination from

your contacts and confi rm " OK " to start

the guidance.

Press NAV to display the

" Navigation - guidance " menu.

Navigation towards a contact is only possible if it has an address

entered in the audio navigation system.

Delete recent destinations

Press NAV to display the

" Navigation - guidance " menu.

Select " Options " and confi rm and then

" Delete recent destinations " and

confi rm.

NAVIGATION - GUIDANCE

244

Select " Select destination " and

confi rm, then select " GPS coordinates "

and confi rm.

Enter the GPS coordinates and confi rm

" OK " to start the guidance.

Press NAV to display the

" Navigation - guidance " menu.

NAVIGATION - GUIDANCE

Towards GPS coordinates

Towards a point on the map

With the map displayed, press OK to

display the contextual menu. Select

" Move the map " and confi rm.

Press OK to display the contextual

menu for " Move the map " mode.

Select " Select as destination " or

" Select as stage " and confi rm.

Move the cursor using the control to

identify the desired destination.

245

Towards points of interest (POI)

NAVIGATION - GUIDANCE

The points of interest (POI) indicate all of the service locations in the vicinity

(hotels, various businesses, airports…).

Select the " Enter an address " function

and confi rm, then select Select

destination and confi rm.

To select a POI close to your current

location, select " POI " and confi rm, then

select " Around the current place " and

confi rm.
To select a POI as a stage on the route,

select " POI " and confi rm, then select " On

the route " and confi rm.
To select a POI as a destination, fi rst

enter the country and town (see "Towards

a new destination"), select " POI " and

confi rm, fi nally select " Near " and confi rm.

Search for POIs in the categories

suggested in the following pages.

Select " Search by Name " to search for POIs by name and not by

proximity.

Select the POI and confi rm " OK " to start

the guidance.

Press NAV to display the

" Navigation - guidance " menu.

246

NAVIGATION - GUIDANCE

This icon appears when several POIs are grouped

together in the same area. Zooming in on this icon

shows details of the POIs.

Service station

Garage

CITROËN

Covered car park

Car park

Rest area

Hotel

Restaurant

Cafeteria

Bed and breakfast

Railway station

Bus station

Port

Industrial estate

Supermarket

Vending machine

Sports complex, sports centre,

sports ground

Swimming pool

Winter sports resort

Airport

Theme parks

Hospital, Chemist, Vet

Police station

Town hall

Post offi ce

Museum, Culture, Theatre,

Historic monument

Tourist information, Tourist

attraction

Risk areas / Danger areas *

List of principal points of interest (POI)

* According to availability in the country.

School

           An annual mapping update allows new points of interest to be presented to you.
You can also update the Risk areas / Danger areas every month.
The detailed procedure is available on:
http://citroen.navigation.com.

Cinema

247

NAVIGATION - GUIDANCE

Select:
- "Visual

alert"

- "Audible

alert"

"Alert only in guidance"

"Overspeed alarm only".

The choice of time of notifi cation defi nes

how long in advance that Risk area

warnings are given.
Select " OK " to confi rm the screen.

Select " Guidance options " and confi rm,

then select " Set parameters for risk

areas " and confi rm.

Press NAV to display the " Navigation -

guidance " menu.

These functions are only available if risk areas have been

downloaded and installed on the system.
The detailed procedure for updating risk area POIs can be found at

http://citroen.navigation.com.

Settings for risk area / danger area alerts

248

NAVIGATION - GUIDANCE

Adding a stage

Press NAV to display the

" Navigation - guidance " menu.

Select " Journey leg and route " then

confi rm.

Select " Close to " a route passing

close to the stage or " Strict " for a route

passing through the stage.
Confi rm " OK " to start the guidance, and

give a general indication of the guidance

route.

Select " Add a stage " then confi rm .
The address of the stage is entered as

a destination, by " Enter an address ",

a contact in " Directory ", or " Previous

destinations ".

Organising stages

To organise stages, carry out operations 1

to 2 again, then select " Order/delete

journey legs " and confi rm.

Select and confi rm to save the

modifi cations.

Select the stage that you want to move

in the order.

Select " Delete " to delete the stage.

249

NAVIGATION - GUIDANCE

Route options

Calculation criteria

Select " Guidance options " and confi rm.

Select " OK " and confi rm to save the

modifi cations.

Select " Defi ne calculation criteria " and

confi rm.
This function allows modifi cation of:
-

the guidance criteria: (" Fastest

route ", " Shortest route ",

" Distance/Time "),

the exclusion criteria: (" With tolls "

or " With Ferry "),

- traffi c avoidance: (" Traffi c info ").

Press NAV to display the

" Navigation - guidance " menu.

If traffi c avoidance (Traffi c info) is selected, the system suggests

an alternative route if there is a delay on the guidance route.

250

NAVIGATION - GUIDANCE

Press NAV to display the

" Navigation - guidance " menu.

Map management

Selecting the points of interest displayed on the map

Select " Map management " and confi rm.

Select from the various categories the

ones that you want to display on the

screen.

Select " Map details " and confi rm.

Select " Default " to have only " Filling stations, garages " and

" Risk areas " appear on the map (if installed in the system).

Select " OK " then confi rm and select

" OK " again then confi rm to save the

modifi cations.

251

NAVIGATION - GUIDANCE

Select " Map management " and confi rm.

Select:
- "

Vehicle direction " to have the map

follow the direction of travel,

- "

North direction " to keep the map

always North up,

- "

Perspective view " to display a

perspective view.

Select " Map orientation " and confi rm.

The colour of the map, different from the day and night mode, is

confi gured in the " SETUP " menu.

Map orientation

Press NAV to display the

" Navigation - guidance " menu.

Street names are visible on the map from the 100 m scale.

252

NAVIGATION - GUIDANCE

Press NAV to display the

" Navigation - guidance " menu.

Navigation voice synthesis

Select " Guidance options " and confi rm.

Adjusting the volume / Deactivation

Select " Set speech synthesis " and

confi rm.

Select the volume graph and confi rm.

Select " Deactivate " to deactivate voice messages.

Select " OK " and press the dial to

confi rm.

Adjust the volume to the desired level

and confi rm.

The volume of messages can be adjusted during the transmission

of the message using the volume adjustment control.

The volume setting of guidance messages is also accessible via

the " SETUP " / " Voice synthesis " menu.

253

NAVIGATION - GUIDANCE

Male voice / Female voice

Press SETUP to display the

confi guration menu.

Select " Select male voice " or " Select

female voice " then confi rm " Yes " to

activate a male or female voice. The

system restarts.

Select " Voice synthesis " and confi rm.

254

TRAFFIC INFORMATION

Access to the "Traffic information" menu

List of TMC messages in order

of distance from the vehicle.

Go from the list to the menu (left/right).

" Traffi c information "

" Geographic fi lter "
" Select TMC station "

(automatic, manual)
" Display/Do not display

messages "

Press " TRAFFIC ".

Citroen C4 Dag (2013 year). Manual - part 16
