Alfa Romeo Stelvio MCA (2023 year). Manual in english

271

DESCRIPTION OF CONTROLS TABLES
ON/OFF and VOLUME control (3)

Action

Function

LONG PRESS

Switching the Connect system on/off

SHORT PRESS

Radio Mode

: Activate/deactivate the Mute function

Media Mode

: Activate/deactivate play/pause

Phone Mode

: Activate/deactivate the microphone during a phone call

ROTATION

Turn clockwise to increase the volume/turn anticlockwise to decrease the volume

MOVE TO THE SIDE

Radio mode

: on the right to select next/left radio station/on the left to select previous station

(radio station search can be done by "Frequency"/"Name"/"Favourites")

Media mode

: short press on the right: select next track/short press on left select previous track

Long press on right

("Media" mode): go to next track/long press on left, go to previous track

CarManuals2.com

MULTIMEDIA

272

Rotary Pad (4)

Action

Function

ROTATION

In the Menus

: confirms selection

In Navigation mode

(where provided): zooms the maps (where provided)

SHORT PRESS

In the Menus

: confirms selection

LONG PRESS

Radio mode

: store radio station on the radio station bar/store a favourite on the preset bar

BRIEF TOUCH RIGHTWARDS (*)

In the Menus

: goes to the submenu of the selected function

In Navigation mode

(where provided), in "Browse Map": moves rightwards on the Navigation

map to move inside the navigation map (where provided)

BRIEF TOUCH LEFTWARDS (*)

In the Menus

: goes back to the previous menu ("Esc" function)

In Navigation mode

(where provided), in "Browse Map": moves leftwards on the map Navigation

to move inside the navigation map (where provided)

BRIEF TOUCH UPWARDS (*)

In the Menus

: closes the preset bar

In Navigation mode

(where provided), in "Browse Map": moves upwards on the map to move

inside the navigation map (where provided)

BRIEF TOUCH DOWNWARDS (*)

Activating radio presettings/Saving "Contacts" and "Destinations"

In the Menus

: opens the preset bar

In Navigation mode

(where provided), in "Browse Map": moves downwards on the map

Navigation to move inside the navigation map (where provided)

(*) The Rotary Pad must be tilted in the indicated direction ("tilt" function)

CarManuals2.com

273

CONTROLS ON THE STEERING

WHEEL

DESCRIPTION

The controls fig. 281 for the main system

functions are present on the steering

wheel to make control easier. The

activation of the function selected is

controlled, in some cases, by the length

of the press (short or long press) as

described below.

281

9550179

(1) (2) Volume controls (

)

Short press

: turn the volume up/down

by one step

Long press

: turn the volume up/down

by one step

(3) Screen selection / main widget /
default

Short press

: switch between the

main (or default) screen display (in the

central area of the instrument panel

display), or the widget display (inside

the tachometer on the instrument panel

display)

(4) Telephone / Voice commands
Short press (Phone Mode)

Answer / end call

Short press (Voice commands)

With voice session not active

activation of Connect system voice

controls if no phone mode is active

With voice session active

immediately close voice session in

progress

Long press (Voice commands)

With voice session active

: interrupt

voice session in progress (a new voice

command can be imparted)

With the voice session not active and

an external audio device connected (e.g.

Apple CarPlay / Android Auto)

: activate

a voice session on the connected device
NOTE Connection to the phone disables

voice command.
NOTE If Apple CarPlay and Android Auto

apps are present, Siri voice assistant

(for Apple CarPlay) or Google Assistant

(for Android Auto) will be activated. In

this case you can use "Natural language"

voice controls and not just the specific

ones preset for the Alfa Connect system.

The voice assistants of Siri (for Apple

CarPlay) or Google Assistant (for

Android Auto) will only be activated by

holding the button

pressed on the

right side of the steering wheel.

(5) Selection of items displayed on

screens/widgets (

)

Upward rotation

: select next radio

station (Radio mode) / select next track

(Media mode).

Downward rotation

: select previous

radio station (Radio mode) / select

previous track (Media mode).

Short press

: confirm the actions

suggested by the messages on the

instrument panel display.

Long press

: reset the Trip Computer

readings on the instrument panel display.

CarManuals2.com

275

WIDGETS

WIDGET INTERACTION MODES

Widgets, displayed on the Connect

system display, give access to the

various operating modes of the system.
To interact with the widgets on the Main

Menu use the touchscreen function or

the Rotary Pad located on the central

tunnel.
One of the following operations can be

performed:

open the widget

by pressing on it

(touchscreen) or by pressing the Rotary

Pad;

scroll the widgets

rightwards/leftwards using the

touchscreen function or by turning the

Rotary Pad rightwards/leftwards.

MOVING THE WIDGETS

You can move the widgets on the display

using the touchscreen function or using

the commands located on the central

tunnel.

Using the touchscreen function

Select the desired widget or press the
"Reorder"

button on the vertical

status bar and then:

Moving the widget

: hold

the desired widget pressed for a few

seconds and then move it to the right or

left of the display.

Resizing the widget

: press the

widget resize icon to be resized.

View widget content

: select the

desired widget and then scroll vertically.

When reordering the widgets (viewing

their thumbnails), it will not be possible

to view their contents.

Using the controls located on the

central tunnel

Proceed as follows:

press the

button on the central

tunnel: a horizontal bar graph fig. 282 will

appear on the upper part of the display;

turn the Rotary Pad to select the

"Settings" item;

press the Rotary Pad to confirm the

selection and then select one of the

following items:

"Widget reorder": to move the

desired widget to the right or left of

the display.

"Widget resize": to change the

size of the widget display to "1/3

view" or "2/3 view" of the display

area.

"Widget content": to view the

content of the desired widget.

282

12126V0906EM

RESIZING WIDGETS

Some widgets can occupy 1/3 or 2/3 of

the display area.

Using the touchscreen function

"1/3" view

fig. 283: icons, menu name,

main information, graphic buttons (up

to 3) (where provided) appear on the

display.

"2/3" view

fig. 284: to activate the

enlarged display of the widget, press the
"enlarge" graphic button

(where

provided) located on the top of the

widget itself. To return from the "1/3"
view, press the graphic button

CarManuals2.com

MULTIMEDIA

276

283

12126S0909EM

284

12126S0910EM

Using the controls located on the

central tunnel

Activate the "Settings" menu and then

select the item "Widget resize".
Only the resizeable widgets will be

activated (these will appear on the

display with a different colour from

those that cannot be resized and

therefore cannot be selected).
To resize the widget and switch to "2/3"

view, press the Rotary Pad.

Press the graphic button

to return to

the normal view.
NOTE It is not possible to keep two

widgets in "2/3 view" mode on the display

at the same time.

VIEWING WIDGET CONTENTS

Using the touchscreen function

To change the widget view, select it

and swipe vertically, either upwards or

downwards.

Using the controls located on the

central tunnel

Activate the "Settings" menu and then

select the "Widget content" item: only

the widgets with content will be active

and selectable on the display.
Proceed as follows to view the contents

of the widgets:

turn the Rotary Pad to select the

desired widget;

press the Rotary Pad to confirm the

selection;

turn the Rotary Pad to display the

contents of the widget;

press the Rotary Pad to keep the

display active and exit the widget.

REORDER THE WIDGETS

The widgets can be reordered on the

Main Menu in two different ways:

Explicit

": by pressing the "Reorder"

graphic button located on the upper

left of the display fig. 285

Implicit

": by holding the desired

widget pressed for a few seconds.

285

12126S0919EM

Using the touchscreen function

Explicit mode

In both modes, the size of the widgets

will be reduced and displayed, up to a

maximum of 5, on the display.
NOTE When reordering the widgets

(viewing their thumbnails), it will not be

possible to view their contents.
Proceed as follows:

press the graphic button

located

in the upper left part of the display: the

first widget will be displayed;

press and hold down the desired

widget and drag it to the desired

position;

CarManuals2.com

277

release the widget: the new position of

the widget will be stored by the Connect

system.

286

12126S0922EM

Implicit mode

Proceed as follows:

hold the desired widget pressed: the

widgets will be reduced and displayed,

up to a maximum of 5, on the display. The

selected widget will remain displayed

and will be larger in size;

press and hold down the desired

widget and drag it to the desired

position;

release the widget: the new position of

the widget will be stored by the Connect

system.
To return to the Main Menu press the
graphic buttons

Using the controls located on the

central tunnel

Activate the "Settings" menu and then

select "Widget reorder": the first widget

will be displayed automatically.
Proceed as follows to reorder the

widgets:

turn the Rotary Pad and select

the desired widget: the widget will be

highlighted on the display;

press the Rotary Pad: a graphic arrow

will appear next to the widget,

indicating the direction in which you can

move the widget;

turn the Rotary Pad to move the

widget to the desired position;

press the Rotary Pad to store the new

widget location (the widget will continue

to be highlighted on the display).
To go back to the Main Menu, turn the

Rotary Pad to the left or press the button

on the central tunnel.

SHORTCUT MENU

Proceed as follows to activate the status

bar display:

Using the touchscreen function:

touch

the upper part of the display, fig. 287, and

slide your finger down.

Using the controls on the central

tunnel

: move Rotary Pad 1 fig. 288

downwards.

287

12126V2302EM

288

12126S0765EM

The "shortcut" menu can be used to:

access the "Settings" menu;
quickly access the stored radio station

"Favourites" or "Contacts" or navigation

"Destinations";

add graphic buttons to quickly access

the desired function.

CarManuals2.com

MULTIMEDIA

278

RADIO (TUNER) MODE

RADIO MODE SELECTION (TUNER)

"RADIO" mode can be activated by using

the appropriate widget in the main menu

of the Connect system.
NOTE Some "RADIO" mode functions

can be activated in addition to using the

Rotary Pad and/or the touchscreen

function, also using voice controls: for

more information, see the "AM/FM/DAB

Radio voice commands" paragraph in

the "Voice controls" chapter in this

publication.

MAIN SCREEN RADIO MODE

The following information will be

displayed after selecting the desired
radio station on the display fig. 289.

289

12126S0926EM

Sidebar fig. 289

The following graphic buttons are

displayed on the sidebar:

SRC

: can be used to select the required

frequency band;

to select the Favourites list;
to view the list of available radio

stations;

to manually seek a radio station.

Central zone of the display fig. 289

The following information is displayed in

the central area of the display:

selected frequency band (e.g. FM);
name of the current radio station;
logo of the active frequency band;
transmitted programme type;
current radio station frequency;
radio mode graphic buttons

(select previous radio station,

activate/deactivate mute function,

select next radio station);

list and name of stored radio stations.

AUDIO

(where provided)
Proceed as follows to open the "Audio"

menu:

press the “Settings”

button on the

central tunnel;

turn the Rotary Pad to select the

"Audio Settings" item.
When the function is activated, the

following parameters can be set:

"Bass" (-9; 0; +9);
"Treble" (-9; 0; +9);

"Mid" (-9; 0; +9);
"Balance/Fade";
"Volume/Speed" (OFF; +5);
“Surround Sound” (OFF/ON) (where

provided);

"AUX Volume Comp." (OFF; +20);
"Restore Settings".

MEDIA MODE

NOTE Some "MEDIA" mode functions

can be activated in addition to using the

Rotary Pad and/or the touchscreen

function, also using voice controls:

for more information, see the "Media

voice controls" paragraph in the "Voice

controls" chapter in this publication.

AUDIO SOURCE SELECTION

When the MEDIA source is active, the

following information is shown on the
display fig. 290:

SRC

: activate the list of sources

to activate Shuffle/Playback Mode
to activate Tracks Library
to activate the Playlists

Press the graphic button to activate

"MEDIA" mode

SRC

: the display shows

the available sources: AM, FM, DAB,

Bluetooth

®, USB1, USB2.

CarManuals2.com

279

290

12126S0937EM

Bluetooth® SOURCE

Bluetooth® ACTIVATION

This mode is activated by pairing a

Bluetooth

® device containing music

tracks with the system.

PAIRING A Bluetooth® AUDIO DEVICE

Proceed as follows:

activate the

Bluetooth

® function on

the device;

open the main menu by pressing

button

and select "Settings";

select "Infotainment";
select "Phone" and then "Bluetooth

Settings";

select the

Bluetooth

® fig. 291 device;

select "Add Device" ;
search for the Connect system on the

Bluetooth

® audio device (during the

pairing stage a screen will appear on

the display showing the progress of the

operation);

select the device to be paired;
when requested by the audio device,

enter the PIN code shown on the system

display or confirm on the device the PIN

displayed;

if the pairing procedure is completed

successfully, a dedicated screen will

appear.

70°F

ext.

°F

291

12126S0430EM

The

Bluetooth

® function can also be

reached by pressing the "OPTIONS"

button in the "PHONE" or "MEDIA

functions", which can be selected on the

main menu.
WARNING If the

Bluetooth

® connection

between mobile phone and system is

lost, consult the mobile phone handbook.
NOTE When modifying the name-device
in the

Bluetooth

® settings of the phone

(where provided), the Radio may change

the track being played if the device is
connected via USB after the

Bluetooth

connection. After updating the phone

software, for proper operation, it is

recommended to remove the phone from

the list of devices linked to the Connect

system, delete the previous system
pairing also from the list of

Bluetooth

devices on the phone and make a new

pairing.

USB/iPod/AUX SUPPORT

USB/iPod MODE

To activate the USB/iPod mode insert

the corresponding device (USB or iPod)

in one of the USB ports located:

under the dual zone automatic climate

control panel, (1) fig. 292;

inside the storage compartment under

the front armrest, (2) fig. 293.
NOTE The Connect system may not

support some USB keys: in this case,

it may not automatically switch from

"Radio" mode to "Media" mode. If the

device used does not play, verify its

compatibility by selecting "Media" mode:

a dedicated message will appear on the

Connect system display.
WARNING After using a USB recharging

port, we recommend disconnecting

the device (smartphone), always

removing the cable from the charging

port of the vehicle first, never from the

device. Cables left flying or connected

incorrectly could compromise correct

CarManuals2.com

MULTIMEDIA

280

recharging and/or the USB socket

condition.

292

04026S0981EM

293

04026S0993EM

USB socket (battery charger)

The glove compartment underneath the

front armrest also contains a third USB

socket (3) fig. 293 for use as a "battery

charger" only.

AUX SOURCE

To activate AUX mode, insert an

appropriate device in the AUX socket(1)
fig. 294 on the car.

When a device is connected to that

socket, the system starts reproducing

the connected AUX source, if it is already

playing.

294

04026S0982EM

CLIMATE CONTROL SYSTEM

The Connect system lets you interact

with the automatic dual-zone

climate control system to adjust the

temperature inside the passenger

compartment.
NOTE The climate control widget is only

active via the touchscreen function.
The climate control widget in the Main

Menu can display two different contents:
"Air distribution" fig. 295 and "Comfort"

(present only in case of heated electric

seats and heated electric steering

wheel).

Scroll up/down on the widget

you can

change the display.

Pressing the widget

to activate the "Air

Distribution" or "Comfort" screen.

295

12126S0970EM

On the climate control system widget
is displayed a single graphic button

(activated only using the touchscreen

function) which, if pressed, allows you to

turn off the automatic dial-zone climate

control system and then turn it back on

in its last active configuration before

turning off.

"AIR DISTRIBUTION" SCREEN

The "Air Distribution" menu can be used

to adjust the air temperature on driver

and passenger side.
Graphic buttons are present on the

screen for activating the same functions

which can be selected using the buttons

on the display of the automatic dual-zone

climate control system located in the

passenger compartment (see "Climate

control system" chapter in the "Knowing

your car" section).

CarManuals2.com

281

"COMFORT" SCREEN

(where provided)
The "Comfort" screen can be used

to adjust the heating level of driver

and passenger seat and of the steering

wheel.

PHONE MODE

NOTE Some "TELEPHONE" mode

functions can be activated in addition

to using the Rotary Pad and/or the

touchscreen function, also using voice

controls: for more information, see

the "Phone voice controls" paragraph

in the "Voice controls" chapter in this

publication.

INDICATIONS ON THE DISPLAY

The “PHONE” mode widget appears on

the main menu.
The widget display vary according to the

following conditions:

Paired mobile phone
No paired mobile phone
Phone call in progress
Multiple phone call in progress
Outgoing telephone call
Phone conference in progress

Paired mobile phone

If you have already paired your mobile

phone (see the following pages), the
following three graphic buttons fig. 296

will appear on the "PHONE" widget:

Turn the microphone on/off during

a phone call (1);

End call (2);
Transfer call to device (3).

296

12126V2349EM

PAIRING A MOBILE PHONE

Pairing procedure

To pair the mobile phone, proceed as

follows:

activate the

Bluetooth

® function on

the device;

in the main menu, select the

"SETTINGS" function by turning and

pressing the Rotary Pad;

select "Infotainment";
select the

Bluetooth

® device;

select "Add Device";
search for the Connect system on the

Bluetooth

® audio device (during the

pairing stage a screen will appear on

the display showing the progress of the

operation);

select the device to be paired;
when requested by the device, enter

the PIN code shown on the system

display or confirm the PIN displayed on

the device;

if the pairing procedure is completed

successfully, a screen is displayed;

the

Bluetooth

® function can also be

activated by pressing the

"PHONE"

or "MEDIA" functions, which can be

selected from the main menu.
WARNING Perform the telephone pairing

operation only while the car is stationary

and in safe conditions. Only do this with

the car stationary and in safe conditions.

The feature is disabled when the car is

moving faster than 5 km/h.
WARNING If the

Bluetooth

® connection

between mobile phone and system is lost

consult the mobile phone handbook.

CarManuals2.com

MULTIMEDIA

282

MAKING A PHONE CALL

With the "PHONE" function on, you can

make a call in the following ways:

by selecting "Phone Book" on the

display or "Recent Calls" and then

selecting a contact from the suggested

list;
or

by selecting "Dial" item on the display.

MAIN PHONE MENU

When a mobile phone is connected to

the Connect system, various items (if

available) will appear on the main menu
fig. 297:

network signal intensity;
mobile phone battery charge;
mobile phone name.

297

12126V2500EM

The other information shown on the

display is fig. 297:

“Recent calls” (1): press this graphic

button to choose between "All Calls" and

"Missed Calls".

“Favourites” (2): press this graphic

button you can choose between "Edit

favourites", "Add favourites", "Reorder

favourites" and "Delete favourites".

“Contacts” (3): press this graphic

button on the display to show the list

of all contacts registered on the phone.

When you select a contact, the phone

number and the photo (if any) linked to

the contact appear on the right of the

display.

“SMS” (4): press this graphic

button to receive and send text

messages (if supported by the device).

The car must be stationary to read the

messages. The listening function and

the sending of default messages which

can be customised by the driver is

always possible. If an unread message is

present, it is indicated by a dot next to

the "SMS" graphic button (a maximum

of 99 unread text messages can be

present).

"Dial" (5): press this graphic button

to show the "dial number" screen on the

display which can be used to dial the

telephone.

NAVIGATION MODE

(where provided)

LEGAL/ SAFETY NOTICE

When Connect is used for the first time,

after resetting the default settings

and having changed the language,

the system will ask you to accept a

safety/legal notice, warning you about

the responsibilities involved in the

product use while navigating.
NOTE Some "NAVIGATION" mode

functions can be activated in addition

to using the Rotary Pad and/or the

touchscreen function, also using voice

controls: for more information, see the

"Navigation voice controls" paragraph

in the "Voice controls" chapter in this

publication.

NAVIGATION ACTIVATION

The “NAVIGATION” mode widget fig. 298

appears on the main menu.
NOTE The widget is only active using the

touchscreen function.
The graphic button on the widget varies

depending on whether navigation has
been activated

or is not activated .

CarManuals2.com

283

298

12126S2010EM

SETTING A DESTINATION

The following data are required to set a

destination:

"City/Post code": enter the name

or ZIP code of the city of the new

destination arrival point;

"Address": enter the street name of

the new destination;

"House Number": enter the house

number of the new destination;

"State" (where applicable/necessary):

enter the name of the state of the new

destination arrival point.

"Start Navigation": select the desired

destination using the right side of the

display. This will provide access to the

route planning screen to start navigating.
NOTE The data above can be order

entered in any order ("Free Text Search"

function).
To set a new destination, select

the graphic button

(using the

"touchscreen" function or by rotating

the Rotary Pad): the graphic keyboard

for entering the destination address will

appear on the display and the list of

"Destinations" will appear on the right

side.

Management of voice recognition for

entering navigation addresses

Pressing the button

on the right

side of the steering wheel to start the

voice recognition session and send the

necessary commands to the Connect

system to enter a navigation address.
You can enter addresses in two different

ways:

One-shot

: Say "Navigate to <City,

Address, House Number>" after pressing
the button

on the right side of the

steering wheel and starting the voice

recognition session. The Connect system

will be able to recognise the address

you inserted or display a list of possible

alternatives. Then follow the instructions

provided by the Connect system to start

route calculation.

Manual entry

: The Connect system will

help you entry individual fields through

a guided procedure, with the possibility

of using the "City", "Address" and "House

Number" voice commands. To activate

this mode, press the button

located on

the right side of the steering wheel and

starting the voice recognition session,

send the first command to enter the city

and continue following the instructions

provided by the Connect system.
If a language change is made on the

Connect system, using the dedicated

menu in the "Settings" on the display, a

pop-up screen will appear informing the

driver of the limited availability of the

voice recognition functions.
If you choose the English language on a

car sold in Italy the following message

will appear on the display of the Connect

system: "When the vocal system is set

to English you can input addresses

in the United Kingdom, Ireland, Malta

and Gibraltar. You can also insert all

destinations manually.".
WARNING The above message is located

according to the country of destination

of the vehicle. Only the countries shown

on this pop-up screen will be available

with voice recognition functions for

address and destination selection. The

available countries will change according

to the language type selected by the

driver.
NOTE The "one-shot" address entry

mode will not be available if the driver

chooses a language other than the one

used in the country in which the car was

marketed. In this case, in order to access

the voice recognition functions and enter

a valid address, i.e. recognisable by the

Connect system, you will need to send to

CarManuals2.com

MULTIMEDIA

284

the Connect system a voice command to

change country in advance (for each use

of the car). For example, if you choose

English language on a car sold in Italy,

you will need to use the voice command

"Change country" to start the address

entry procedure.

STOPPING NAVIGATION

After starting the navigation, it can be

stopped at any moment by pressing the
graphic button
A dedicated message will appear on the

display: select “Confirm” to confirm your

choice and display the main navigation

screen again, or “Cancel” to cancel the

operation.

Tom Tom® ONLINE SERVICES

(where provided)
Tom Tom® "Online Services" (where

provided) allow you to receive the

following information and view on the

Connect system display:

"Live Traffic"/"Speed Cameras";
"Send Destination to car";
"Search for a point of interest (POI)

online"

"Last Mile Navigation".

NOTE Tom Tom® online services are

available if Connected Services - Alfa

Connect Services is activated and for the

entire duration, plus any renewals, of the

"My Navigation" package.

LIVE TRAFFIC / SPEED CAMERAS

(where provided)
With this service you can view the

relevant information on the display of

the Connect system:

traffic (conditions updated in real-

time);

the presence of speed cameras (if any).

Live Traffic

With this service, you can monitor, the

traffic conditions in real-time on the

display of the Connect system. The

information is displayed by means of

special icons with the following colours
fig. 299:

GREEN

: Roads where the average

traffic speed corresponds to the

expected free flow speed;

YELLOW

: Roads where the average

speed is below the indicated road speed

limit;

RED

: Roads where the average speed

is close to blocked traffic conditions;

RED + DANGER SIGN

: Roads blocked,

due to the presence of construction

sites, accidents, etc.

299

12126S2300EM

Speed Cameras

(where provided)
With this service, you can see on the

display the type (fixed or mobile) and

location of the speed cameras.
The display shows a speed camera icon

on the right-hand side.
If you press on the icon on the display

you will see a screen with the following

information about the speed cameras
fig. 300:

"Position" (e.g. "Both sides");

CarManuals2.com

285

"Report Now."

300

12126S2132EM

Send Destination to car

Using this service, you can navigate to a

second destination sent to Connect via

your smartphone.
The new destination will appear in

the lower area of the display; to start

navigation, press the "Start Navigation"
graphic button fig. 301:

with destination NOT set

: the new

destination will be displayed in the

"Recent Destinations" menu;

with destination set

: the new

destination will be displayed in the

"Manage Route" menu. To access the

new destination press the "Add New

Destination" graphic button.

301

12126S2135EM

SEARCH FOR A POINT OF INTEREST

(POI) ONLINE

Using this service, you can enter a

destination (by entering the name,

address or a POI) and a list of POIs that

match your search will appear on the

display.
NOTE A subscription and authorisation is

needed to use this service.

LAST MILE NAVIGATION

With this service you can transfer

navigation from the Connect system to

your smartphone.
When navigation is active, the Connect

system will transfer navigation to your

smartphone as follows:

automatically

by activating the

"Automatic sending Last Mile to mobile"

option in the "Settings" menu;

at the driver's request

by activating

the "Send Last Mile Navigation" option

in the "Manage Route" menu or in the

"Settings" menu;

at the driver's request

if, during

navigation, you touch a point on the Map

and then select the "Send Last Mile

Navigation" option on the pop-up menu

that appears on the display.

Transferring Navigation to your

smartphone

With active navigation, proceed as

follows:

press the graphic button

("Manage

Route"): the "Manage Route" menu will

appear on the display;

select the "Last Mile Navigation" item;
select the "Send Now Last Mile

Navigation" item: the display will show a

dedicated message indicating that the

navigation will be transferred to the

smartphone. Then press the "OK" graphic

button to confirm the selection.
NOTE The final destination will be sent

to the smartphone even if the car is not

in a 1 kilometre (or 1 mile) radius from the

final destination.
NOTE The transfer to the smartphone

will take place even if you have not

enabled the "Automatic sending Last

Mile to mobile" feature in the "Settings"

menu (the navigation will be transferred

by selecting the "Send Last Mile

Navigation" option ).

CarManuals2.com

MULTIMEDIA

286

SETTINGS

ACTIVATING THE SETTINGS MENU

The "Settings" menu can be activated by

using the appropriate widget on the main
menu fig. 302.
Indicatively, the following items are

available in the menu:

"Lights"
"Units & Language"
"Clock and Date"
"Passive Safety"
"Convenience & Comfort"
"Doors & Locks"
"Instrument panel"
"Infotainment"
"System"

302

12126V2305EM

Lights

The following settings can be modified

when this mode is selected:

"Headlight Sensor"

"Follow Me"
"Cornering Lights"
"Flash Lights with Lock"
"Adaptive front lights” (AFS)
"Daytime Running Lights"
"Courtesy Lights"
"Interior Ambient Lighting"
"Restore Settings"

Units & Language

The following settings can be modified

when this mode is selected:

"Units"
"Language"
"Restore Settings"

Clock & date

The following settings can be modified

when this mode is selected:

"Sync with Gps Time"
"Set Time"
"Set Date"
"Time Format"
"Restore Clock and Date Settings"

Passive safety

The following settings can be modified

when this mode is selected:

"Passenger airbag": this is used to

activate/deactivate the front passenger

airbag function.
When the function is accessed:

the system will detect the

activation/deactivation status of the

airbags and confirm change of status.

Press the Rotary Pad to continue. The

airbag status is visible through the LEDs

next to the status icon on the dashboard.

Passenger protection activated

the ON LED switches on with a

steady light.

Passenger protection

deactivated

: the OFF LED switches

on with a steady light.

“Auto Park Brake" (where provided):

allows you to activate/deactivate the

electric parking brake engagement when

the engine is stopped.

"Brake service" (where provided):

this can be used to activate ("Yes") or

deactivate ("No") the procedure to effect

brake system maintenance.

"Seat Belt Reminder": this is used to

enable ("OK") or disable ("Cancel") the

acoustic signal for the SBA (Seat Belt

Alert) system.

"Automatic mirror folding"

(where provided): This function

activates/deactivates automatic folding

of the mirrors when the doors are

locked/unlocked. The default setting is

"Off".

“Restore Settings”: allows you to

delete the previously settings from this

menu and restore the default settings.

CarManuals2.com

287

Convenience & Comfort

The following settings can be modified

when this mode is selected:

“Passive Entry": this allows you to

activate ("On") or deactivate ("Off") the

automatic door closing

“Restore Settings”: allows you to

delete the previously settings from this

menu and restore the default settings.

Doors & Locks

The following settings can be modified

when this mode is selected:

"Door lock in motion"
"Unlock all doors on exit"
"Door unlock on entry" (where

provided)

"Sound Horn with Remote Start"

(where provided)

"Sound Horn with lock" (where

provided)

"Auto Relock" (where provided)
"Electric tailgate"
"Automatic tailgate opening"
"Convenience & Comfort"
"Restore Settings"

Instrument panel

The following settings can be modified

when this mode is selected:

"Buzzer volume"
"Trip B"

"Show Phone Info"
"Show Audio Info"
"Show Nav Info"
"Digital speed on all screens"
"Consumption bar"
"Performance pages"
"Custom areas"
"Restore Settings"

Infotainment

The following settings can be modified

when this mode is selected:

"Screen Off"
"Display brightness"
"Audio"
"Home Page"
"Bluetooth®"
"Device Manager"
"Entertainment"
"Phone"
"Projection mode"
"Navigation "(where provided)
"Performance Pages"
"Android Auto"
"Connected Services" (where

provided)

"Driver Assistance"

System

The following settings can be modified

when this mode is selected:

"Auto-On Radio"

"Cam Delay"
"Software Update"
"Map Update"
"Restore All Settings"

MAP UPDATE

(where provided)
To ensure optimal performance (where

provided), the navigation system must be

updated periodically.
For this, the

Mopar® Map Care

service

offers a new map update every three

months.
The updates can be downloaded from the

maps.mopar.eu website and installed

directly on the Connect system. All

updates are free of charge for 3 years

from the start of the warranty on the car.
The navigation system can also be

updated at the Alfa Romeo Dealership.
NOTE The dealer may charge for

updating the navigation system.

Map update procedure

Proceed as follows to update the

navigation maps:

start the engine;
with the car stationary, insert the USB

key, containing the updated maps, into

one of the USB ports located on the

central tunnel;

CarManuals2.com

MULTIMEDIA

288

select the "Update Map" option from

within the "Map Update" function. The

display will show a screen with the

version and the duration of the whole

procedure in minutes;

select the "Update" function. The

display will show a screen with the

instructions to be followed and a request

for confirmation;

confirm to start the process.

During the update, the instructions to be

followed will continue to be displayed

together with the process progress. You

can move the car during this phase.

PERFORMANCE

The "Performance pages" can be

activated by using the appropriate
widget on the main menu fig. 303.
The following information is shown on

the main screen of the "Performance

pages":

"Technical gauges"
"Consumption history"
"Efficient Drive"
"Engine torque"
"Temperatures" (Quadrifoglio version

only)

"Drag Race" (Quadrifoglio version only)
"Performance content" (where

provided)
Turn the Rotary Pad to select the desired

item and then press the Rotary Pad to

confirm the selection and access the

menu or, using the touchscreen function,

touch the display to select the desired

item.

303

12126S0400EM

CAR INFORMATION

The "Vehicle Information" function can

be activated by using the appropriate
widget on the Main Menu fig. 304.
The main screen shows information

about:

Service (scheduled servicing)
TPMS (Tyre Pressure Monitoring

System)

Engine oil level
AdBlue® level (only Diesel versions)

(where provided)

Alfa DNA™ system

To view the contents of one of the

information on the display, press on the

display (touchscreen function) or turn the

Rotary Pad, select the desired item and

then press the Rotary Pad to confirm

your selection.

304

12126V2305EM

DRIVER ASSISTANCE

The "Driver Assistance" widget fig. 305 is

located on the main menu of the Connect

system.
The following menus are available in the

"Driver Assistance" widget:

"Safety"
"Comfort"

Select the two menus by sliding on the

widget upwards or downwards with a

finger.

CarManuals2.com

289

305

12126S0431EM

"SAFETY" MENU

The "Safety" menu displays information

on the following driver assistance

systems:

FCW (Forward Collision Warning)

System

LKA (Lane Keeping Assist) or LDW

(Lane Departure Warning)

ABSA (Active Blind Spot Assist) or

BSM (Blind Spot Monitoring)

DAA (Driver Attention Assist) System

Indications on the display

The driver assistance system status

(activated or deactivated) is shown on

the display by a graphic "shield" next to

the outline of the car.
When ALL driver assistance systems are

ACTIVATED

, the following screen will

appear on the display fig. 306.
When ALL driver assistance systems are

DEACTIVATED

, the following screen will

appear on the display, fig. 305.

306

12126S0438EM

"COMFORT" MENU

The "Comfort" submenu fig. 307 displays

information on the following driver

assistance systems:

ISC (Intelligent Speed Control) System
TSR (Traffic Sign Recognition) System
Speed Limiter
Park Sensors System
Rear View Camera
AHB (Automatic High Beam)

ext.

307

07076S0709EM

Indications on the display

Each driver assistance system is

represented by a corresponding icon on

the display.
The status of the function is displayed

next to the icon: "On" = system activated

/ "Off" = system deactivated.
Settings are possible on some systems

(if activated), (e.g. the speed limit value

can be adjusted on the Speed Limiter

function).

SYSTEM SETTINGS

After viewing the "Driver Assistance"

menu in full screen mode, a list of all

settings that can be made for driver

assistance systems will appear on the

display.
The information shown on the display is

as follows:

system identification icon;
system name;
graphic button 1 fig. 308 for activating

("ON") and deactivating ("Off"") the

system;

indication of the function status;
graphic display area of the system;
default system setting (modifiable by

the driver).
The following active driver

assistance/safety systems will not be

available if you have selected the "Race”

driving mode (where provided). In this

CarManuals2.com

MULTIMEDIA

290

case, a dedicated pop-up screen will

appear on the Connect system display.

308

12126V2096EM

SYSTEM ACTIVATION/DEACTIVATION

Using the touchscreen function

Proceed as follows:

press the display to select the desired

item;

to activate the system, press the

graphic button 1 fig. 308 rightwards: "ON"

will appear on the display

to deactivate the system, press the

graphic button 1 fig. 308 leftwards: "OFF"

will appear on the display.

Using the controls located on the

central tunnel

Proceed as follows:

turn the Rotary Pad and select the

desired item;

press on Rotary Pad to confirm

the choice and activate the system:

the selected item will be activated

automatically. When the system is

activated, press the Rotary Pad to

deactivate it.

Apple CarPlay and Android Auto

(where provided)
The Apple CarPlay and Android Auto

applications allow you to use your

smartphone in the car safely and

intuitively.
To activate them, simply connect a

compatible smartphone to the USB

port and the contents of the phone will

automatically appear on the display

of the Connect system after having

selected the default action the first time

you connect an Android and/or an iOS

device. Use the "Device Manager" menu

to change the choice previously made.
To check the compatibility

of your smartphone, see the

indications on the websites:

https://www.android.com/intl/it_it/auto/

and http://www.apple.com/it/ios/carplay/.
The first time a device is connected, a

pop-up screen appears on the Connect

system display, allowing you to choose

which profile to use it with during

subsequent connections. The possible

options are: “Charge Only”, “Media/iPod”,

“Projection mode”. The options can be

modified by using the "Device Manager"

menu.
If your smartphone is properly connected

to the car via the USB port, an additional

widget and its graphic icon will be

displayed on the Connect System Main

Menu on the left hand side of the status

bar.
To use Apple CarPlay, connect your

iPhone to the car using a MFI (made for

iPhone) certified USB cable.
To use Android Auto, connect your

smartphone to the car using a USB for

Android phones having appropriate

features. Using unsuitable cables may

prevent correct system operation.
NOTE Interaction with the smartphone

may be needed to enable Apple

Carplay/Android Auto and some other

functions. Complete the action on your

device (smartphone) as needed.

APP CONFIGURATION (Apple CarPlay)

Apple CarPlay is compatible with the

iPhone 5 or more recent models, with

the iOS 7.1 operating system or later

versions.
In order to use Siri in Apple CarPlay, you

must activate the function from your

smartphone settings.
To use Apple CarPlay, the smartphone

must be connected to the car by means

of a USB cable.

INTERACTION

After the configuration procedure, when

you connect your smartphone to the

USB port on the car, after displaying the

pop-up screen and according to the last

CarManuals2.com

291

setting made on the "Device Manager"

menu, the application will automatically

start on the Connect system.
The Rotary Pad can be used to select

and confirm the available smartphone

functions.
Multimedia contents on the smartphone

can be accessed directly via "MEDIA"

mode of Connect.

Interaction with voice controls

You can interact with the voice

assistants of Apple CarPlay and Android
Auto using the button

located on the

right side of the steering wheel:

long pressure

will activate interaction

with the voice assistant of Apple (Siri) or

Android (Google Assistant);

short pressure

will initiate interaction

with the native voice system. When

the voice assistant of the phone is

activated, the interface will but that of

the associated telephone not that of the

car. A short press will interrupt both the

native voice session and that of Siri or

Google Assistant.
WARNING If Apple CarPlay and

Android Auto apps are present, Siri

voice assistant (for Apple CarPlay) or

Google Assistant (for Android Auto) will

be activated. In this case you can use

"Natural language" voice controls and

not just the specific ones preset for the

Connect system. The voice assistants

of Siri (for Apple CarPlay) or Google

Assistant (for Android Auto) will only
be activated by holding the button

pressed on the right side of the steering

wheel.

Active Media or Phone mode

The following will be activated according
to how you press the button

on the

right side of the steering wheel:

short

press of the button

will

activate the voice commands related to

the Connect system;

long

press of the button

will

activate the voice commands for the

phone in "Projection" mode.

Active Tuner (Radio) or Navigation

mode

Briefly pressing the button on the

right side of the steering wheel on the

Connect system display to activates

the voice control for "Tuner (Radio)" or

"Navigation" mode, also when Apple

CarPlay or Android Auto apps are

activated.

NAVIGATION

With the Apple CarPlay and Android Auto

applications, you can choose to use the

navigation system on your smartphone.
The controls can be imparted directly on

the Connect system.
The user can choose to change their

selection at any time by accessing the

navigation system that they want to use

and setting a new destination.

EXITING FROM THE Apple CarPlay AND

Android Auto APPS

To end the Apple CarPlay or Android

Auto session, physically disconnect the

smartphone from the USB port on the

car.
NOTE The date and time shown on

Connect system display must match

the actual date and time, even after

disconnecting the of the battery.

Adjust it from the "Settings" menu of

Connect system. Any discrepancy

between the date and time on the display

and the actual date and time may be

due to on the malfunction in Apple

CarPlay/Android Auto.

CarManuals2.com

MULTIMEDIA

292

VOICE COMMANDS

221)

WARNING Voice commands are not

available for languages not supported by

the system.
NOTE Voice controls activation is only

possible with the ignition device at ON.

Voice controls will not be active when

the starter is in the OFF position and the

Connect system is on.
NOTE If Apple CarPlay and Android Auto

apps are present, Siri voice assistant

(for Apple CarPlay) or Google Assistant

(for Android Auto) will be activated. In

this case you can use "Natural language"

voice controls and not just the specific

ones preset for the Connect system.

The voice assistants of Siri (for Apple

CarPlay) or Google Assistant (for

Android Auto) will only be activated by
holding the button

pressed on the

right side of the steering wheel.

STARTING A VOICE SESSION

Briefly press

the button

on the

steering wheel once.

INTERRUPTING A VOICE SESSION

At any time during a voice session

(dialogue), you can press and hold the

button to stop and restart the voice

session from scratch and impart a new

command, regardless of the previous

conversation.

For example, if the system is uttering

a voice help message and recognises

the desired command, it may be useful

to stop the help by pressing the button

on the steering wheel and give the

command, so you don't have to wait for

the help messages to end.

DEACTIVATING A VOICE SESSION

With the voice session active,

briefly

press

the button

on steering wheel.

The voice session will automatically

close when a command has been

recognised and no further actions are

required by the driver.
A phone call will also interrupt the voice

session, in order to allow you to answer

and speak normally using the hands-free

function.

RADIO AM/FM/DAB VOICE CONTROLS

The

button activates the following

functions:

Tune to station <XXX>
Tune to station < XXX>
Tune to frequency < XXX>
Tune to frequency < XXX>
Add to favourites
Show available stations
Show the list of available stations

(where provided)

Shows favourite stations (where

provided)

Show the list of favourite stations

(where provided)

FM
AM (where provided)
DAB (where provided)
Radio controls ("Go to radio")

MEDIA VOICE COMMANDS

The

button activates the following

functions:

Play (or say View) Album
Play (or say View) Artist
Play (or say View) Composer
Play (or say View) Genre
Play (or say View) Playlists
Play (or say View) Song
Play (or say View) All
Shuffle on
Shuffle off
Play Song (or Track)
Play All (or say View All) Albums
Play All (or say View All) Artists
Play All (or say View All) Composers
Play All (or say View All) Genres
Play All (or say View All) Playlists
Change to AUX
Pass to USB 1
Pass to USB 2
Pass to USB 3
Change to AUX
Change Bluetooth®

CarManuals2.com

293

NOTE These controls are valid on

devices connected to the system via USB
ports and not through the

Bluetooth®

system.

PHONE VOICE COMMANDS

The

button activates the following

functions:

Dial number <XXXXXX>
Call <XXXXXX>
Go (or say Change to phone)
Phone commands
Search contact
Search
Call back
Show missed calls
All Calls
Show contacts
View contacts
Show all messages
Send a message
Send a message to
Read last (or say Read the last)

message
NOTE On some mobile phones, in order

to have the text message voice reading

function available, you need to enable the

text messages option on the phone.

NAVIGATION COMMANDS

(where provided)
The

button activates the following

functions:

Go (or say Drive) Home

Favourite <favourite name>
Navigation commands
Go (or say Change) to Navigation
Set 2D map
Set detailed 3D map
Set overhead view
Add destination
Destination
Stop Navigation
Repeat instructions
Show map
Enter city
Enter nation
Enter country
Enter street
Enter house number
Route preview
Find the closest <point of interest>

NOTE Voice entry of addresses is only

supported in the country in which you are

located and provided that the system

language matches the local language.

For example, if the car is located in

Italy, it will be possible to enter Italian

addresses only if the system language is

set to "Italian".

WARNING

221)

Voice controls must always be given in

safe driving conditions, in compliance with

the laws in force in the country where you

are driving.

CONNECTED SERVICES - ALFA

CONNECT SERVICES

(for versions/markets where provided)

222)

Alfa Connect Services enrich the

experience of use of the car by

connecting it to the network.
The services (where provided) allow

you to receive timely assistance in

case of need and emergency, to obtain

information about the status of your car,

its location, control it remotely and

to improve the navigation experience

(where provided) thanks to real-time

updates.
You can access the Alfa Connect

Services using a Alfa Connect mobile app

for smartphone, smart watch, web portal

or the Connect system of your car.
The availability of services is subject to a

Alfa Connect Services subscription.
More information on Alfa

Connect Services (applicability,

availability, compatibility,

packages and specifications)

CarManuals2.com

MULTIMEDIA

294

can be found on the website:

https://myalfaconnect.alfaromeo.com/

GENERAL DISCLAIMER

Personal data & customization

FCA collects, processes and

uses the personal data of the car in

accordance with legal requirements.

More information can be found in the

general conditions of service and on data

protection policies on the Alfa Romeo

official website.

The Customer is solely responsible

for using the services in the vehicle, even

if by other people, and shall inform all

users and occupants of the car about the

services and the operations and limits of

the system.

If the SOS emergency service is

activated, the call will be automatically

routed to a private FCA Call Centre. We

hereby specify that, whenever the SOS

call is referred to the text, it is to be

considered managed by private service

providers

Operating prerequisites

Registration and activation are

required to use some of the Alfa Connect

Services. Go to the portal, accessible

through the official Alfa Romeo website,

or use the My Alfa Connect mobile

application to do so and login on with

your devices.

Alfa Connect Services is not

available in all countries and is subject

to limitations depending on Connect

system type, location and duration of the

services.

The full operation of the Alfa Connect

Services, including SOS calls and

roadside assistance calls (ASSIST), is

subject to mobile network and GPS

geolocation coverage, without which

the proper provision of services is

not guaranteed. Coverage may not be

guaranteed in places such as tunnels,

garages, multi-story parking garages,

mountains.

The services may be unavailable in

the event of mobile network overload

or problems related to the car power

source (e.g. low battery).

When using the services, customers

shall keep their passwords secret for

strictly personal use and not disclose

them to third parties.

SERVICES

WARNING Some of the services listed

below may not be available if the car is

left with the engine off for more than

20 days. Start the engine to reactivate

these services.
According on the equipment of the car

and of the country, different services

may be available for different durations.

For further information about your car,

go to the personal page on the official

Alfa Romeo website.
Some of the packages made available to

the customer are:

My Assistant

: Customer assistance

and safety warning service, which

includes:

"SOS emergency call and ASSIST

roadside assistance" (see the "In an

emergency" section).

"Vehicle condition report":

information on the status and

condition of the car, notifying

potential maintenance needs to the

customer via periodic e-mails. This

service is provided on condition

that the Customer has previously

provided the FCA network with a

valid e-mail address.

"In-Vehicle Alerts (Basic)": to

receive messages and/or alerts

regarding recall campaigns or

other important messages on the

Connect system display. You can

contact FCA Customer Service for

further information regarding the

messages received.

My Car

: vehicle status monitoring

service.

"Driving Warnings": to set alerts

when user-defined parameters

such as speed, time and area are

CarManuals2.com

295

exceeded, as well as the Valet

Mode feature.

"At-Home Digital Assistant": to

run the main remote commands

from a voice assistant as well as

mobile apps and smartwatches.

My Remote

: this can be used to

manage remote operations (switching

on lights, door lock/unlock, find vehicle,

etc.) from the mobile app and through

compatible voice assistants. It also

allows you to set up Driving Warnings

with notifications, for example, when you

exceed the set area or time.

My Navigation

: connected navigation

service (subject to availability according

to version/market).

My Wi-Fi

: Optional Wi-Fi Hotspot

service. This service provides Internet

access from the car to all devices with

Wi-Fi connection (smartphones, tablets,

laptops) (supported technologies: 3G –

4G). This creates a private Wi-Fi internet

access point in the car. The function,

available only with the ignition device in

ON position or with the engine started

allows the connection of up to eight

devices simultaneously, but not the

direct communication between devices.

The quality of the service offered by the

integrated Wi-Fi Hotspot depends on

the coverage of the mobile operator's

network.

NOTE The hotspot name and password

can only be changed with the ignition

device in the ON position.

My Alert:

optional service with

app and web notifications in case of

suspected theft attempts and assistance

in case of theft.
You can enrich Alfa Connect Services

experience by purchasing optional

services for which a subscription is

required.
The services can be subscribed to

independently by the customer

from the catalogue of services

available for the car, directly on the

https://myalfaconnect.alfaromeo.com/

website.
NOTE The date and time shown on

Connect system display must match

the actual date and time, even after

disconnecting the of the battery. Adjust

it from the "Settings" menu of Connect

system. Any discrepancy between the

date and time on the display and the

actual date and time may be due to

on the malfunction in the Connected

Services.

DEACTIVATION OF GEOLOCATION

MODE

(for versions/markets where provided)
If you wish to deactivate geolocation

mode, simply do so from the Connect

system fig. 309 (see the "Settings" menu

of the Connect system for more details).
When geolocation mode is deactivated

some of the services on mobile apps and

web that use the location of the car will

not be available.
WARNING The

icon is shown at the

bottom left of the Connect system

display when the geolocation function

is active (ON). When geolocation is on,

the vehicle position is tracked to enable

the functions that require it. When

geolocation is off, the vehicle position is

only tracked by the navigation, safety,

insurance and driver assistance systems

(where provided). See the Connect

system "Settings" chapter to deactivate

the function.

309

12126S2094EM

UPDATING THE SYSTEM

Alfa Connect Services and the Connect

system application software are

updated remotely in order to provide

the customer with newer software

CarManuals2.com

MULTIMEDIA

296

versions that include new features or

enhancements/enrichments of features

already offered.
Updates are made at the discretion of

FCA.
Some system updates will be

managed automatically, others will be

communicated to the Customer through

messages on the Connect system

display, allowing the customer to confirm

or postpone the update.
The customer will be notified by

the Connect system if the system is

unavailable.
To obtain more information about

services, features, specifications,

availability and any updates please

always refer to the content included in

the official website of Alfa Romeo.

“AOTA” ("Updates Over The Air”)

OPERATION

(where provided)
This feature allows you to manually

update the Connected Services - Alfa

Connect Services present in the car.
If a Connected Services - Alfa Connect

Services update is available, it will only

be started when the ignition device is set

to AVV.
If the ignition device is turned to STOP

during the Connected Services - Alfa

Connect Services update phase, the

update will continue until this phase. The

update will be completed the next time

the ignition device is set to AVV.
When update availability messages

appear on the Connect system display:

if you do not accept

the suggestion

to update

and the update is mandatory

the message will continue to appear on

the display the next time the Connect

system is turned on;

if you do not accept

the update

suggestion

and the update is not

mandatory

, you can access the feature

and see feedback on the Connect system

display of the available update. Click on

the graphic button on the display to

continue the update.

IN-VEHICLE MESSAGING

(where provided)
This feature allows you to view pop-up

messages on the Connect system display

about:

"Urgent Safety Recall";
"Service Notification" ("Service Oil

Soon" / "Low tyre pressure");

"Subscription Expiring."

NOTE The pop-up messages can only be

displayed when the ignition device is in

the ON or AVV position. The messages

will remain on the display for about 15

seconds and will disappear when the car

starts to move.

Display of messages

Proceed as follows to display the

messages:

press the "Connected Services" widget

shown on the display;

select "In-Vehicle Messaging";
a dedicated screen will appear on the

display after selecting the desired item:

press the "ASSIST" graphic

button to activate a Roadside

Assistance - ASSIST call, the

message shown on the display will

be marked as "read" and stored by

the Connect system (for countries

where the service is provided);

press the "Delete" graphic

button, a message will appear on

the display to delete the message;

select "Yes" if you want to delete

the message or "No" if you do not

want to delete it.

IN-VEHICLE ACTIVATION

(Connected Services – Alfa Connect

Services activation)

(where provided)
This feature allows the driver to

manually activate the Connected

Services - Alfa Connect Services.
NOTE A manual "SOS Call" or a

"Roadside Assistance Call - ASSIST"

always has priority over the "In-Vehicle

Activation" functions.

CarManuals2.com

297

Manual function activation

Depending on the country in which the

car is sold, the "Activate Services"

function may be activated:

by pressing the Connected Services

widget;

by selecting the "Activate Services"

item shown on the display. This item

will be shown on the display when the

car is purchased only after receiving all

the credentials from the Dealer (basic

services will be active at the end of the

production process). The "SOS Call" and

"ASSIST Call" will be active when the

process is complete.
In both cases, a screen with the following

options will appear on the display after

the operations described above:

"Activate Now" (default option);
"Learn More";
"Postpone"

Entering your personal data

After pressing the "Activate Now"

graphic button, the "Enter your data"
screen will appear on the display fig. 310,

in which the following options will

appear:

"First Name";
"Last Name";
"E-mail Address";
"Confirm".

Fill in your name, surname and e-mail

address.
NOTE The "Confirm" graphic button will

only be active after you have entered a

valid e-mail address.

310

12126S2119EM

On the screen there is also the graphic
button 1 fig. 310. Pressing it to be put in

contact with an operator who will help

you complete the registration procedure.

Successful activation

If the activation is successful, you will

receive a link (sent by the dealer) to click

on at their e-mail address.
If the activation phase was not

completed, a screen on which you can

make two different choices will appear

on the display:

complete the activation procedure by

clicking on the link;
or

activate using another account.

The "OK" and "CREATE NEW" graphic

buttons will appear on the display:

press the "OK" graphic button to end

the activation procedure;

press the "CREATE NEW" graphic

button on the display to open a screen in

which you can enter your personal data

to receive the new link from the dealer.

DEACTIVATION OF ALFA CONNECT

SERVICES

If you sell your car on which the Alfa

Connect Services are still active, you

will be responsible for logging off your

profile from the services on the page

on the official Alfa Romeo website, by

contacting the Customer Care or by

going to an Alfa Romeo dealership.
The customer is also responsible for

informing the new owner of any services

not yet expired associated with a new

Alfa Connect Services account.

WARNING

222)

Always follow the highway code of

the country in which you are driving, and

concentrate on the road. Always drive

safely with your hands on the steering

wheel. Only use Connect system functions

when you are sure that it is safe to do

so. The customer is liable for all risks

associated with using the functions and

CarManuals2.com

MULTIMEDIA

298

applications of the car. Failure to follow

these rules may cause serious accidents

and/or death.

WIRELESS CHARGING

SYSTEM– WCPM (Wireless

Charge Pad Module)

(where provided)

OPERATION

The wireless charger system is activated

automatically when a mobile phone Qi®

standard compatible is placed in the
appropriate housing, fig. 311, if the mobile

phone is compatible with the standard.
If the mobile phone is removed from the

housing during the wireless charging

phase, this will automatically be

interrupted.

311

11116S0999EM

The wireless charger system enables

charging when all doors are closed

properly and the engine has been

started.
Interacting with the wireless charging

system, positioning the mobile phone in

the appropriate housing, the following

messages are shown on the Connect

system display (with specific icons and

widgets), to inform the driver about the

wireless charging system status:

"Your phone is being charged", fig. 312

and fig. 313: is displayed when the mobile

phone is positioned correctly in the

wireless charging compartment and the

system is activated correctly;

"Phone fully charged", fig. 314: is

displayed when the phone has completed

charging its battery;

"Object not allowed", fig. 315: is

displayed when a phone that is not

enabled for wireless charging or an

object that is not permitted (e.g. the

ignition key) is placed;

"Unavailable system", fig. 315: appears

when there is a malfunction in the

wireless charger system.

312

12126S2085EM

313

12126S2088EM

314

12126S2086EM

CarManuals2.com

299

315

12126S2087EM

The driver can deactivate the display

of messages relating to the operating

status of the wireless charging system

the relevant Connect system menu.
NOTE The use of multiple wireless

functions on the smartphone at the same

time (Apple CarPlay/Android Auto and

wireless charging), as indicated by the

smartphone manufacturers, could cause

it to overheat, resulting in a limitation of

the active functions or its turning off. In

this case, it is recommended to connect

the system using the USB socket.

OFFICIAL TYPE APPROVALS

RADIO DEVICES

All radio equipment provided with the car

complies with the 2014/53/EU directive,

UA.RED.TR, the French SAR Decree

Law dated 15/11/2019 and the UKCA (UK

Conformity Assessed) Certification

dated 01/01/2023 in force in the United

Kingdom.
For more information go to

www.mopar.eu/owner or

http://aftersales.fiat.com/elum/

RADIO FREQUENCY DEVICES

All radio frequency devices comply with

the regulations in force in the countries

in which they are sold.
For more information go to

www.mopar.eu/owner or

http://aftersales.fiat.com/elum/

CONNECT SYSTEM

The Connect system installed on the car

complies with the 2014/53/EU directive,

UA.RED.TR, the French SAR Decree

Law dated 15/11/2019 and the UKCA (UK

Conformity Assessed) Certification

dated 01/01/2023 in force in the United

Kingdom.

CarManuals2.com

Alfa Romeo Stelvio MCA (2023 year). Manual in english - page 9
