The chosen setting will remain until it

is changed. The alert timing will vary

based on vehicle speed. The faster

the vehicle speed, the farther away

the alert will occur. Consider traffic

and weather conditions when

selecting the alert timing.

Deactivation

The system can only be deactivated

by deactivating the active emergency

braking in the Info Display

System limitations

Forward collision alert is designed to

warn on vehicles, but may react also

to other objects.
In the following cases, forward

collision alert may not detect a vehicle

ahead or sensor performance is

limited:

● driving on winding or hilly roads
● driving during nighttime
● weather limits visibility, such as

fog, rain, or snow

Driving and operating

215

● the sensor in the windscreen or

the radar unit behind the front

bumper are blocked by snow, ice,

slush, mud, dirt etc.

● the windscreen is damaged or

affected by foreign objects, e.g.

stickers

● the bumper is damaged or

affected by foreign objects, e.g.

license plate support

Active emergency braking

Active emergency braking can help to

reduce the damage and injury from

crashes with vehicles and

pedestrians directly ahead, when the

driver does not actively take action

either by manual braking or by

steering. For vehicles equipped with

camera and radar, active emergency

braking also detects cyclists. Before

the active emergency braking

applies, the driver is warned by the

forward collision alert.
Forward collision alert

Front pedestrian protection

Active emergency braking can be

deactivated in the vehicle

personalisation

89. Depending on

version, this is only possible at a

standstill. If deactivated,

illuminates in the Driver Information

Centre and a warning message may

be displayed. When ignition is

switched on next time, system is

automatically activated.
The feature uses various inputs (e.g.

camera sensor, radar sensor, brake

pressure, vehicle speed) to calculate

the probability of a frontal collision.

Warning

This system is not intended to

replace the driver's responsibility

for driving the vehicle and looking

ahead. It warns the driver if the

vehicle is at risk of a collision with

the preceding vehicle, a

pedestrian or a cyclist. Just before

the imminent collision, it reduces

the vehicle's speed to avoid a

collision or to limit its severity.

The system may not react to

animals. After a sudden lane

change, the system needs a

certain time to detect the next

preceding vehicle.
The driver must always be ready

to take action and apply the brakes

and steer to avoid collisions.

Functionality

Depending on the vehicle

configuration and the detected

objects, there are several operational

speed ranges.
Active emergency braking operates

up to 50 mph when a pedestrian has

been detected.
On vehicles equipped with radar

sensor and front camera, the active

emergency braking operates up to

50 mph when a stationary vehicle or

a cyclist has been detected.
On vehicles equipped only with front

camera, the active emergency

braking operates from 3 mph to

50 mph or 87 mph when a moving

vehicle has been detected.

216

Driving and operating

On vehicles equipped with radar

sensor and front camera, the active

emergency braking operates from

3 mph to 87 mph when a moving

vehicle has been detected.
The system includes:

● brake preparation system
● emergency automatic braking
● smart brake assist
● forward collision alert
● front pedestrian protection

Brake preparation system

When approaching a vehicle ahead

or a pedestrian so quickly that a

collision is likely, the brake

preparation system slightly

pressurises the brakes. This reduces

the response time, when braking is

requested.
The pressurisation of the brakes may

produce a noise in the brake system.

Emergency automatic braking

After activation of brake preparation

system and just before the imminent

collision, this function automatically

applies limited braking to reduce the

impact speed of the collision or

prohibit a crash.
If active emergency braking is

applied,

flashes in the Driver

Information Centre. If active

emergency braking is finished,

flashes for a few seconds. During this

time, active emergency braking

cannot be applied if there is a risk of

a further collision.
Forward collision alert

Front pedestrian protection

Depending on version, below a speed

of 19 mph or 31 mph, emergency

automatic braking may slow down the

vehicle to a complete stop. If the

speed exceeds this limit, emergency

automatic braking reduces the speed.

However, the driver must apply the

brake to come to a complete stop.

● Automatic transmission: If the

vehicle comes to a complete

stop, automatic braking is

maintained for a certain time.

Keep the brake pedal depressed

to prevent the vehicle from

starting off again.

● Manual transmission: If the

vehicle comes to a complete

stop, the engine may stall. Keep

the brake pedal depressed to

prevent the vehicle from rolling

away.

Cruise control and adaptive cruise

control will be deactivated when an

emergency automatic braking occurs.
In some cases, the active emergency

braking system may provide an

automatic braking in situations that

seem to be unnecessary. Firmly apply

the accelerator pedal or firmly turn the

steering wheel to override the

automatic braking if the situation and

the surroundings permit.

Warning

Do not rely on the system to brake

the vehicle. Emergency automatic

braking is only applied just before

the collision and it will not brake

outside of its operating speed

Driving and operating

217

range. It only responds to detected

vehicles and pedestrians. For

vehicles equipped with camera

and radar, it also responds to

detected cyclists.

Antilock brake system

195.

Smart brake assist

If the driver brakes, but not sufficiently

to avoid a collision, this system will

supplement the braking. This

assistance will only be provided if the

driver presses the brake pedal.
Smart brake assist will automatically

disengage when the brake pedal is

released.
Forward collision alert

Front pedestrian protection

Operation conditions

Active emergency braking only works

when

● the seat belts of the front seats

and depending on version of the

rear seats are fastened

● the brake system is operational
● Electronic Stability Control and

Traction Control system are

activated

Active emergency braking is

automatically deactivated in the

following cases:

● A spare wheel with smaller

diameter is detected.

● A fault with the brake pedal

switch or with the left or right

brake light is detected.

● A fault in the active emergency

braking system, in the electronic

or in the brake system is

detected.

● A severe crash, e.g., with airbag

deployment was detected.

System limitations

The system performance may be

degraded or not available in the

following cases:

● sensor covered with snow, ice,

slush, mud or dirt

● windscreen damaged or

smeared, with blurred view or

covered with foreign items, e.g.

stickers,

● damaged or deformed front

bumper or front bumper covered

with foreign items, e.g. stickers

● radar unit is out of its regular

position resulting from an impact

of the front bumper

● front camera out of its regular

position

● automatic braking not available,

e.g. brake discs cooling going on

● brake pedal continuously used

for a long time, e.g. on a long

downhill road

● winding or hilly roads
● during initialisation of the system,

e.g. after the vehicle battery has

been disconnected

218

Driving and operating

● sun or lights shining into the front

camera lens

● adverse environmental

conditions, e.g. rain, fog, or snow

● vehicle ahead creating road

spray

After an impact or when damages are

visible have the vehicle checked by a

workshop.
The system performance may be

affected by:

● electronic stability control and

traction control system in

operation

● vehicle battery out of normal

operation voltage

● wet road reflecting lights
● close vehicles ahead
● tractors, muddy vehicles or

vehicles with a trailer

● banked roads
● poor lighting conditions
● sudden lighting changes
● vehicle modifications, e.g. tyres
● vehicle overloaded

If a sensor is covered, a message is

displayed indicating that the sensors

have to be cleaned.
If the system is temporarily affected

and no driver action is required, no

message is displayed.
Complete attention is always required

while driving, and be ready to take

action to avoid crashes.
We recommend to deactivate the

system in the vehicle personalisation

in the following cases:

● when towing a trailer or caravan
● when carrying long objects on

roof bars or a roof rack

● when the vehicle is being towed
● when performing any

maintenance with ignition on

● when the vehicle is fitted with

snow chains

● when a spare wheel is fitted that

is smaller than the other wheels

● before using an automatic car

wash

● before placing the vehicle on a

rolling road in a workshop

● if the windscreen has been

damaged close to the camera

● if the front bumper has been

damaged or deformed

● if the radar unit is out of its regular

position resulting from an impact

of the front bumper

● if the brake lights are not working

Fault

If the system has a fault,

illuminates in the Driver Information

Centre, a message is displayed and

an audible signal is given. Consult a

workshop.
If the system does not work properly

or is not available, e.g. during the

initialisation,

illuminates in the

Driver Information Centre.
If

and

illuminate in the Driver

Information Centre after the engine

has been switched off and then

restarted, consult a workshop.
Vehicle messages

88.

Driving and operating

219

Front pedestrian protection

Front pedestrian protection may help

to avoid or reduce the harm caused

by front-end crashes with pedestrians

when driving forward.
The system uses the front camera in

the windscreen and a radar unit in the

front bumper to detect a pedestrian

directly ahead in your path.
Front pedestrian protection can

detect and alert to pedestrians in a

forward gear at speeds between

3 mph and 37 mph. Additionally front

pedestrian protection can provide a

boost to braking or automatically

brake the vehicle.
During nighttime driving, system

performance is limited.

Danger

Front pedestrian braking does not

provide an alert or automatically

brake the vehicle, unless it detects

a pedestrian.

The system may not detect

pedestrians, including children, if

the pedestrian is not directly

ahead, not fully visible, or not

standing upright.

Front pedestrian protection includes:

● detecting front pedestrian ahead
● front pedestrian alert

Front pedestrian protection is

activated together with forward

collision alert.
Forward collision alert

Front pedestrian alert

When approaching a detected

pedestrian too quickly, a warning

message is displayed in the Driver

Information Centre. A warning chime

is provided.
Cruise control or adaptive cruise

control may be disengaged when the

front pedestrian alert occurs.

System limitations

In the following cases, front

pedestrian protection may not detect

a pedestrian ahead or sensor

performance is limited:

● vehicle speed is out of range from

3 mph to 37 mph in forward gear

● driving on winding or hilly roads
● driving during nighttime
● weather limits visibility, such as

fog, rain, or snow

● the sensor in the windscreen or

the radar unit behind the front

bumper is blocked by snow, ice,

slush, mud, dirt or by foreign

objects, e.g. stickers

● the windscreen is damaged
● the bumper is damaged

Parking assist

General information

The rear system is deactivated when

a plug is connected to the power

outlet of the trailer hitch.

220

Driving and operating

Warning

The driver bears full responsibility

for the parking manoeuvre.
Always check the surrounding

area when driving backwards or

forwards while using parking

assist system.

Front-rear parking assist

The front-rear parking assist

measures the distance between the

vehicle and obstacles in front and

behind the vehicle. It informs and

warns the driver by giving audible

signals and display indication.
It uses two different audible signals

for the front and rear monitoring

areas, each with a different tone

frequency.

The system operates with ultrasonic

parking sensors in the rear and front

bumper.

Activation

When a forward gear has been

engaged, the front parking assist is

triggered, as soon as an obstacle is

detected in the front and the speed of

the vehicle is below 6 mph.
When the reverse gear has been

engaged, the front parking assist is

triggered additionally to the rear

parking assist.
After engaging the reverse gear, an

audible signal is given from the rear

speakers and a display indication will

be shown. If no audible signal is

given, the display indication is not

shown or a warning message

appears, the system has a failure.

Depending on version the system is

ready to operate when the LED in the

parking assist button

is not

illuminated. The state of the system is

memorised when the ignition is

switched off.

Deactivation

The system is switched off

automically when reverse gear is

disengaged or when the vehicle

speed exceeds 6 mph.

Driving and operating

221

Press

or apply the electric parking

brake to deactivate the system

manually. When the system is

deactivated manually, the LED in the

button illuminates. If the system has

been deactivated manually, it is not

reactivated automatically the next

time the ignition is switched on.

Indication

As soon as an obstacle gets closer to

the vehicle, an audible signal is given

and the symbol

may flash. The

interval between the sounds

becomes shorter as the vehicle gets

closer to that obstacle. When the

distance is less than approx. 30 cm,

the sound is continuous.
Audible signals are given via front or

rear loudspeakers depending on

which detected obstacle is nearest to

the vehicle.
If the vehicle stops for more than

three seconds, if the automatic

transmission is in P position, or if no

further obstacles are detected, no

audible signals are given.

Notice

An audible signal is not given if the

sound has been muted or if the

display of the rear view camera

indicated on the Info Display has

been switched off.

Additionally, the distance to rear and

front obstacles is displayed by

changing distance lines in the Info

Display

85.

Muting the sound / closing the display

indication

If the audible signal is muted or the

display of the rear view camera is

closed and an obstacle gets closer,

only the

flashes.

When engaging the forward gear and

driving more than 6 mph the sound

and the display are automatically

resumed.

System limitations

In the event of a fault or if the system

does not work temporarily, e.g.

because of high external noise level

or other interference factors,

illuminates in the Driver Information

Centre. A message is displayed in the

Driver Information Centre and a

warning chime sounds.
In the case of a permanent fault, seek

the assistance of a workshop.

Warning

Under certain circumstances,

various reflective surfaces on

objects or clothing as well as

external noise sources may cause

the system to fail to detect

obstacles.
Special attention must be paid to

low obstacles which can damage

the lower part of the bumper.

222

Driving and operating

Caution

In the case of a severe failure of

the vehicle with the need to stop

the vehicle, the system is

deactivated.
In the case of a gearbox failure,

the parking assist system is not

active, when reverse gear is

engaged.
In the case of a loudspeaker

failure, the audible signals may not

be given.
Performance of the system can be

reduced when sensors are

covered, e.g. by ice or snow.
If a sensor is covered, a message

is displayed indicating that the

sensors have to be cleaned.
Performance of the parking assist

system may be limited or the

functionality may not be available

at all if

illuminates or if the

image shown on the Info Display

is frozen or if the screen is black.

Performance of the parking assist

system can be reduced due to

heavy loading.
Special conditions apply if there

are taller vehicles in the vicinity

(e.g. off-road vehicles, mini vans,

vans). Object identification and

correct distance indication in the

upper part of these vehicles

cannot be guaranteed.
Objects with a very small reflection

cross-section, e.g. objects of

narrow size or soft materials, may

not be detected by the system.
Parking assist systems do not

detect objects outside the

detection range, e.g. below the

bumper or underneath the vehicle.
During a reverse parking

manoeuvre, the system does not

consider a mounted coupling ball

bar. The driver has to consider this

additional length.

Notice

It is possible that the sensor detects

a non-existing object caused by

echo disturbance from external

acoustic noise or mechanical

misalignments (sporadic false

warnings may occur).
Make sure that the front number

plate is properly mounted (not bent

and no gaps to the bumper on the left

or right side) and the sensors are

firmly in place. The performance of

the parking assist may be reduced if

the license plate is bent or a license

plate support is used.
Low curbs and surface irregularities,

e.g. on construction zones, are not

detected by the system. The driver

accepts responsibility.

Advanced parking assist

Warning

The driver bears full responsibility

for accepting the parking slot

suggested by the system and the

parking manoeuvre.
Always check the surrounding

area in all directions when using

the advanced parking assist.

Driving and operating

223

The advanced parking assist is an

enhancement of the front-rear

parking assist. All system limitations

of the parking assist also apply for this

system.
Parking assist

The advanced parking assist

measures a suitable parking slot

while passing, calculates the

trajectory and automatically steers

the vehicle while parking.
Advanced parking assist provides

assistance for the following

manoeuvres:

● entry into a parallel parking slot
● entry into a perpendicular parking

slot

● exit from a parallel parking slot

The driver must control acceleration,

braking and gear shifting, while

steering is done automatically. The

driver can take control at any time by

gripping the steering wheel.
It may be necessary to move forwards

and backwards more than once.
Instructions are given in the Info

Display

Advanced parking assist can only be

activated when driving forwards.

Entry into a parallel parking slot

Activation

Slow down the vehicle speed below

12 mph.
To search for a parking slot, activate

the system in the Info Display

Select the parallel parking slot menu.
Select parking side by switching on

the turn light on the respective side.
The allowed parallel distance

between the vehicle and a row of

parked cars is between 0.5 m and

1.5 m.
The system will not identify slots that

are clearly smaller or larger than the

vehicle.

When a free slot is detected, a visual

feedback on the Info Display and a

first acoustic signal are given. Drive

slowly forwards. When the second

acoustic signal is given, stop the

vehicle, select reverse gear, release

the steering wheel and start moving

slowly. A visual feedback is given on

the Info Display.

224

Driving and operating

Move forwards and backwards while

observing the warnings of the parking

assist until the end of manoeuvre is

indicated.

Entry into a perpendicular parking

slot

Activation

Slow down the vehicle speed below

12 mph.
To search for a parking slot, activate

the system in the Info Display

Select the perpendicular parking slot

menu.
Select parking side by switching on

the turn light on the respective side.

The allowed parallel distance

between the vehicle and a row of

parked cars is between 0.5 m and

1.5 m.
When several successive slots are

found, the vehicle will be directed

towards the last one.

When a free slot is detected, a visual

feedback on the Info Display and an

acoustic signal are given. Stop the

vehicle, select reverse gear, release

the steering wheel and start moving

without exceeding 4 mph.

Move forwards and backwards as

instructed by observing the warnings

of the parking assist and paying

attention to the acoustic signals until

the end of manoeuvre is indicated.
During the parking manoeuvre, the

system is automatically deactivated

once the rear of the vehicle is within

50 cm of an obstacle.

Exiting a parallel parking slot

Activation

When exiting a parallel parking slot,

activate the system in the Info Display

Driving and operating

225

Select the exiting a parallel parking

slot menu.
Select exit side by switching on the

respective turn light.
Engage reverse or forward gear,

release the steering wheel and start

moving without exceeding 3 mph.

Move forwards and backwards while

observing the warnings of the parking

assist until the end of manoeuvre is

indicated. The manoeuvre is

complete when the vehicle's front

wheels are out of the parking slot.
After deactivation ensure to take

control over the vehicle.

Display indication

The instructions on the display show:

● general hints and warning

messages

● the demand to stop the vehicle,

when a parking slot is detected

● the direction of driving during the

parking manoeuvre

● the demand to shift into reverse

or first gear

● the demand to stop or to drive

slowly

● the successful completion of the

parking manoeuvre indicated by

a pop-up symbol and a chime

● the cancelling of a parking

manoeuvre

Deactivation

Do not use the advanced parking

assist when a temporary spare wheel

is mounted. The rear view camera

may not work properly.
The current park assist manoeuvre is

cancelled via the button to return to

the previous screen in the Info

Display. To deactivate the system

completely, press

in the centre

console.
The system is deactivated

automatically:

● if the ignition is switched off
● if stalling the engine
● if no manoeuvre is started within

five minutes of selection of the

type of manoeuvre

● after a prolonged stop of the

vehicle during a manoeuvre

● if the electronic stability control is

triggered

● if the speed of the vehicle

exceeds the stated limit

● when the driver interrupts

movement of the steering wheel

● after four manoeuvre cycles (a

manoeuvre cycle consists of one

rear move and one forward

move)

● on opening the driver's door

226

Driving and operating

● if one of the front wheels

encounters an obstacle

● parking manoeuvre successfully

ended

Deactivation by the driver or by the

system during manoeuvring will be

indicated on the display. Additionally,

an acoustic signal sounds.
The system is deactivated when a

plug is connected to the power outlet

of the trailer hitch.
Contact your dealer to switch off the

system for a prolonged period.

Fault

In the event of a fault, a message is

displayed in the Info Display,

accompanied by an acoustic signal.
In the event of a fault in the power

steering,

illuminates and a

message is displayed in the Driver

Information Centre.

Notice

Advanced parking assist system

may not respond to changes in the

available parking space after

initiating a parking manoeuvre. The

system may recognize an entry, a

gateway, a courtyard or even a

crossing as a parking slot. Take care

regarding the availability of the

suggested parking slot.

Side blind spot alert

The side blind spot alert system

detects and reports objects on either

side of the vehicle, within a specified

blind spot zone. The system displays

a visual alert in each exterior mirror,

when detecting objects that may not

be visible in the interior and exterior

mirrors.
Side blind spot alert uses some of the

advanced parking assist sensors

which are located in the front and rear

bumper on both sides of the vehicle.

Warning

Side blind spot alert does not

replace driver vision.
The system does not detect:

● vehicles outside the side blind

zones which may be rapidly

approaching

● pedestrians, cyclists or animals

Before changing a lane, always

check all mirrors, look over the

shoulder and use the turn light.

Activation

Activate the side blind spot alert in the

Info Display

Functionality

When the system detects a vehicle in

the side blind zone while driving

forwards, an LED will illuminate in the

relevant exterior mirror.
The LED comes on immediately when

being passed.

Driving and operating

227

The LED comes on after a delay when

passing another vehicle slowly.

Operation conditions

The following conditions must be

fulfilled for proper operation:

● all vehicles are moving in the

same direction and in adjacent

lanes

● the speed of your vehicle is

between 7 and 87 mph

● passing a vehicle with a speed

difference of less than 6 mph

● another vehicle is passing with a

speed difference of less than

15 mph

● the traffic flow is normal
● driving on a straight or slightly

curved road

● the vehicle is not pulling a trailer

No alert will be given in the following

situations:

● in the presence of non-moving

objects, e.g. parked vehicles,

barriers, street lamps, road signs

● in very dense traffic, when

moving vehicles might be

confused with a stationary object

● with vehicles moving in the

opposite direction

● driving on a winding road or a

sharp corner

● when passing or being passed by

a very long vehicle, e.g. lorry,

coach, which is at the same time

detected at the rear in the blind

spot angle and present in the

driver's forward field of vision

● when passing too quickly

Deactivation

The system is deactivated in the Info

Display

The state of the system is stored

when switching off the ignition.

The system is automatically

deactivated when towing an

electrically connected trailer.
Due to adverse weather conditions

such as heavy rain, false detections

may occur.

Fault

In the event of a fault,

flashes for a

few moments in the Driver

Information Centre, accompanied by

and the display of a message.

Contact a dealer or a qualified

workshop to have the system

checked.

Night vision

Night vision warns the driver about

pedestrians and animals in his visual

field during the night. The system

uses an infrared camera below the

bonnet.

228

Driving and operating

Activation

Night vision is activated in the Info

Display

85. If the operation

conditions are met,

illuminates in

green. The system is active.
To display the image provided by the

camera in the Driver Information

Centre, select night vision using the

adjuster wheel of the indicator lever.

Functionality

Detected pedestrians or animals are

displayed within a yellow frame. The

warmer the temperature of the object

the brighter the colour in which it is

displayed.

If a collision is imminent, the object

detected is displayed in a red frame

and an alert symbol is triggered.

If night vision is activated but its

permanent display is not selected, a

temporary window including the alert

symbol is displayed in case of an

imminent collision.

Operation conditions

The following conditions must be

fulfilled for proper operation:

● light conditions are poor
● low beam is activated
● outside temperature is between

-30 °C and 30 °C

● vehicle speed must be below 99

mph

● distance to the object to be

detected is between 15 m (for

pedestrians) and 200 m

depending on light conditions

● animals and pedestrians taller

than 0.5 m

System limits

In the following cases, night vision

may not work:

● weather limits visibility such as

fog, rain or snow

● camera covered by snow, mud,

dirt etc.

● driving on winding or hilly roads
● driving through a bend

Driving and operating

229

Warning

In the event of a front impact, the

infrared camera may be affected

and not work properly. After an

accident, consult a workshop to

verify and adjust the position of the

infrared camera.

Deactivation

The system is deactivated in the Info

Display
