Driving and operating

The forward collision alert uses the

front camera in the windscreen to

detect a preceding vehicle directly

ahead, in your path.
If a vehicle directly ahead is

approached too quickly, a warning

chime and alert in the Driver

Information Centre is provided.

Warning

Forward collision alert is just a

warning system and does not

apply the brakes. When

approaching a vehicle ahead too

rapidly, there may not be enough

time to avoid a collision.
The driver accepts full

responsibility for the appropriate

following distance based on traffic,

weather and visibility conditions.
The complete attention of the

driver is always required while

driving. The driver must always be

ready to take action and apply the

brakes.

Activation

Forward collision alert detects

vehicles and operates automatically

at all speeds above 3 mph and

53 mph. The system detects

stationary vehicles if the speed does

not exceed 50 mph.

Alerting the driver

The driver is warned by following

alerts:

● Symbol

illuminates and a

warning message is displayed in

the Driver Information Centre

when the distance to the vehicle

ahead gets to small.

● Symbol

illuminates, a warning

message is displayed in the

Driver Information Centre and a

warning chime sounds, when a

collision is imminent and

immediate driver's action is

required.

Warning

Forward collision alert is just a

warning system and does not

apply the brakes. When

approaching a vehicle ahead too

rapidly, it may not provide you

enough time to avoid a collision.
The driver accepts full

responsibility for the appropriate

following distance based on traffic,

weather and visibility conditions.
The complete attention of the

driver is always required while

driving. The driver must always be

ready to take action and apply the

brakes.

Caution

The colour lighting of this control

indicator does not correspond to

local traffic laws on following

distance. The driver bears full

responsibility for maintaining safe

following distance according to

Driving and operating

199

applicable traffic rules, weather

and road conditions etc. at all

times.

Selecting the alert sensitivity

The alert sensitivity has to be set to

close, normal or distant in the vehicle

personalisation menu

83.

The chosen setting will remain until it

is changed. The alert timing will vary

based on vehicle speed. The faster

the vehicle speed, the farther away

the alert will occur. Consider traffic

and weather conditions when

selecting the alert timing.

Deactivation

The system can only be deactivated

by deactivating the active emergency

braking in the vehicle personalisation

83.

System limitations

Forward collision alert is designed to

warn on vehicles, pedestrians and

cyclists, but may react also to other

objects.

In the following cases, forward

collision alert may not detect a vehicle

ahead or sensor performance is

limited:

● driving on winding or hilly roads
● driving during nighttime
● weather limits visibility, such as

fog, rain, or snow

● the sensor in the windscreen or

the radar unit behind the front

bumper are blocked by snow, ice,

slush, mud, dirt etc.

● the windscreen is damaged or

affected by foreign objects, e.g.

stickers

● the bumper is damaged or

affected by foreign objects, e.g.

license plate support

Active emergency braking

Active emergency braking can help to

reduce the damage and injury from

crashes with vehicles, pedestrians

and obstacles directly ahead, when a

collision can no longer be avoided

either by manual braking or by

steering. Before the active

emergency braking applies, the driver

is warned by the forward collision

alert or the front pedestrian protection

alert.
Forward collision alert

197.

Front pedestrian protection

202.

Active emergency braking can be

deactivated in the personalisation

83. If deactivated,

illuminates in the instrument cluster

and a warning message is displayed

in the Driver Information Centre.
The feature uses various inputs (e.g.

camera sensor, brake pressure,

vehicle speed) to calculate the

probability of a frontal collision.

Warning

This system is not intended to

replace the driver responsibility for

driving the vehicle and looking

ahead. Its function is limited to

200

Driving and operating

supplemental use only to reduce

the vehicle speed before a

collision.
The system may not react to

animals. After a sudden lane

change, the system needs a

certain time to detect the next

preceding vehicle.
The driver must always be ready

to take action and apply the brakes

and steer to avoid collisions.

Functionality

Active emergency braking is

equipped with a front camera and

operates in forward gear in the range

between 3 mph and 53 mph. The

system detects stationary vehicles

only if the speed does not exceed

50 mph.
A precondition is that forward collision

alert with front camera system is not

deactivated in the vehicle

personalisation menu

83.

The system includes:

● emergency automatic braking
● forward looking brake assist

● forward collision alert
● front pedestrian protection

Emergency automatic braking

After activation of brake preparation

system and just before the imminent

collision, this function automatically

applies limited braking to reduce the

impact speed of the collision or

prohibit a crash. If active emergency

braking is applied,

flashes in the

instrument cluster. Depending on the

situation, the vehicle may

automatically brake moderately or

hard. This front automatic braking can

only occur if a vehicle or a pedestrian

ahead is detected.
Forward collision alert

197.

Front pedestrian protection

202.

Emergency automatic braking may

slow the vehicle to a complete stop to

try to avoid a potential crash.

Warning

Emergency automatic braking is

an emergency crash preparation

feature and is not designed to

avoid crashes. Do not rely on the

system to brake the vehicle.

Emergency automatic braking will

not brake outside of its operating

speed range and only responds to

detected vehicles and

pedestrians.

Forward looking brake assist

In addition to emergency automatic

braking, the forward looking brake

assist function makes the brake assist

more sensitive. Therefore, pressing

the brake pedal less strongly results

in immediate hard braking. This

function helps the driver brake

quicker and harder before the

imminent collision.

Driving and operating

201

Warning

Active emergency braking is not

designed to apply hard

autonomous braking or to

automatically avoid a collision. It is

designed to reduce the vehicle

speed before a collision. It may not

react to animals. After a sudden

lane change, the system needs a

certain time to detect the next

preceding vehicle.
The complete attention of the

driver is always required while

driving. The driver must always be

ready to take action and apply the

brakes and steer to avoid

collisions.

The system is designed to work with

all occupants wearing their seat belts.
Forward collision alert

197.

Front pedestrian protection

202.

System limitations

The system performance may be

degraded or not available in the

following cases:

● sensor covered with snow, ice,

slush, mud or dirt

● windscreen damaged or

smeared, with blurred view or

covered with foreign items, e.g.

stickers,

● damaged or deformed front

bumper or front bumper covered

with foreign items, e.g. stickers

● radar unit is out of its regular

position resulting from an impact

of the front bumper

● front camera out of its regular

position

● automatic braking not available,

e.g. brake discs cooling going on

● brake pedal continuously used

for a long time, e.g. on a long

downhill road

● winding or hilly roads
● during initialisation of the system,

e.g. after the vehicle battery has

been disconnected

● sun or lights shining into the front

camera lens

● adverse environmental

conditions, e.g. rain, fog, or snow

● vehicle ahead creating road

spray

After an impact or when damages are

visible have the vehicle checked by a

workshop.
The system performance may be

affected by:

● electronic stability control and

traction control system in

operation

● vehicle battery out of normal

operation voltage

● wet road reflecting lights
● close vehicles ahead
● tractors, muddy vehicles or

vehicles with a trailer

● banked roads
● poor lighting conditions
● sudden lighting changes
● vehicle modifications, e.g. tyres
● vehicle overloaded

202

Driving and operating

If the system is temporarily affected

and no driver action is required, no

message is displayed.
Complete attention is always required

while driving, and be ready to take

action to avoid crashes.
We recommend to deactivate the

system in the vehicle personalisation

in the following cases:

● when towing a trailer or caravan
● when carrying long objects on

roof bars or a roof rack

● when the vehicle is being towed
● when performing any

maintenance with ignition on

● when the vehicle is fitted with

snow chains

● when a spare wheel is fitted that

is smaller than the other wheels

● before using an automatic car

wash

● before placing the vehicle on a

rolling road in a workshop

● if the windscreen has been

damaged close to the camera

● if the front bumper has been

damaged or deformed

● if the radar unit is out of its regular

position resulting from an impact

of the front bumper

● if the brake lights are not working

Fault

In case the system requires a service,

a message is displayed in the Driver

Information Centre.
If the system does not work as it

should do, vehicle messages are

displayed in the Driver Information

Centre.
Vehicle messages

82.

Front pedestrian protection

Front pedestrian protection may help

to avoid or reduce the harm caused

by front-end crashes with pedestrians

when driving forward.
The system uses the front camera in

the windscreen to detect a pedestrian

directly ahead in your path.
Front pedestrian protection can

detect and alert to pedestrians in a

forward gear at speeds between

3 mph and 37 mph.

During nighttime driving, system

performance is limited.

Danger

Front pedestrian braking does not

provide an alert or automatically

brake the vehicle, unless it detects

a pedestrian.
The system may not detect

pedestrians, including children,

when the pedestrian is not directly

ahead, not fully visible, not

standing upright, or when part of a

group.

Front pedestrian protection includes:

● detecting front pedestrian ahead
● front pedestrian alert

Front pedestrian protection is

activated together with forward

collision alert.
Forward collision alert

197.

Detecting front pedestrian ahead

A pedestrian ahead up to a distance

of approx. 40 m is indicated by a

symbol in the instrument cluster.

Driving and operating

203

Front pedestrian alert

When approaching a detected

pedestrian too quickly, a warning

message is displayed in the Driver

Information Centre. A warning chime

is provided.
Cruise control or adaptive cruise

control may be disengaged when the

front pedestrian alert occurs.

System limitations

In the following cases, front

pedestrian protection may not detect

a pedestrian ahead or sensor

performance is limited:

● driving on winding or hilly roads
● driving in the dark
● weather limits visibility, such as

fog, rain, or snow

● the sensor in the windscreen or

the radar unit behind the front

bumper is blocked by snow, ice,

slush, mud, dirt or by foreign

objects, e.g. stickers

● the windscreen is damaged
● the bumper is damaged

Parking assist

General information

When attaching a trailer or bicycle

carrier to the trailer hitch, the parking

assist is deactivated.

Warning

The driver bears full responsibility

for the parking manoeuvre.
Always check the surrounding

area when driving backwards or

forwards while using parking

assist system.

The parking assist makes parking

easier by measuring the distance

between the vehicle and obstacles. It

informs and warns the driver by giving

acoustic signals and display

indication.
Acoustic signals are given on the side

on which the vehicle is closer to an

obstacle. The interval between the

sounds becomes shorter as the

vehicle gets closer to that obstacle.

When the distance is less than

approx. 30 cm, the sound is

continuous.

Rear parking assist

The system operates with ultrasonic

parking sensors in the rear bumper.

Activation

The rear parking assist is activated

when reverse gear is engaged.
The system is ready to operate when

the LED in the parking assist button

is not illuminated.

204

Driving and operating

Indication

The system warns the driver with

audible signals against potentially

hazardous obstacles behind the

vehicle in a distance range up to

50 cm.

Additionally, the distance to rear

obstacles is displayed by changing

distance lines in the Info Display

79. When the obstacle is very close,

for danger is displayed in the

screen.

Deactivation

The system is switched off when

reverse gear is disengaged. Press

to deactivate the system manually.

The LED in the button illuminates

when the system is deactivated. If the

system has been deactivated

manually, it is not reactivated

automatically the next time the

ignition is switched on.

Front-rear parking assist

It uses two different acoustic warning

signals for the front and rear

monitoring areas, each with a

different tone frequency.

The system operates with ultrasonic

parking sensors in the rear and front

bumper.

Activation

The rear parking assist is activated

when reverse gear is engaged.
In addition to the rear parking assist,

the front parking assist is triggered

when an obstacle is detected in front

and the speed of the vehicle is still

below 6 mph.
The system is ready to operate when

the LED in the parking assist button

is not illuminated.

Driving and operating

205

Indication

The system warns the driver with

audible signals against potentially

hazardous obstacles in front of the

vehicle and behind the vehicle by

using the respective loudspeakers.

Additionally, the distance to rear and

front obstacles is displayed by

changing distance lines in the Info

Display

79.

Deactivation

The system is deactivated

automatically when vehicle speed

exceeds 6 mph or if the vehicle stops

for more than three seconds in a

forward gear or if no further obstacles

are detected.
When the system is deactivated

manually, the LED in the button

illuminates.
If the system has been deactivated

manually, it is not reactivated

automatically the next time the

ignition is switched on.

System limitations

In the event of a fault or if the system

does not work temporarily, e.g.

because of high external noise level

or other interference factors,

illuminates in the Driver Information

Centre. A message is displayed in the

Driver Information Centre and a

warning chime sounds.
In the case of a permanent fault, seek

the assistance of a workshop.

Warning

Under certain circumstances,

various reflective surfaces on

objects or clothing as well as

external noise sources may cause

the system to fail to detect

obstacles.
Special attention must be paid to

low obstacles which can damage

the lower part of the bumper.

206

Driving and operating

Caution

In the case of a severe failure of

the vehicle with the need to stop

the vehicle, the system is

deactivated.
In the case of a gearbox failure,

the parking assist system is not

active, when reverse gear is

engaged.
In the case of a loudspeaker

failure, the audible signals may not

be given.
Performance of the system can be

reduced when sensors are

covered, e.g. by ice or snow.
If a sensor is covered, a message

is displayed indicating that the

sensors have to be cleaned.
Performance of the parking assist

system may be limited or the

functionality may not be available

at all if

illuminates or if the

image shown on the Info Display

is frozen or if the screen is black.

Performance of the parking assist

system can be reduced due to

heavy loading.
Special conditions apply if there

are taller vehicles in the vicinity

(e.g. off-road vehicles, mini vans,

vans). Object identification and

correct distance indication in the

upper part of these vehicles

cannot be guaranteed.
Objects with a very small reflection

cross-section, e.g. objects of

narrow size or soft materials, may

not be detected by the system.
Parking assist systems do not

detect objects outside the

detection range, e.g. below the

bumper or underneath the vehicle.
During a reverse parking

manoeuvre, the system does not

consider a mounted coupling ball

bar. The driver has to consider this

additional length.

Notice

It is possible that the sensor detects

a non-existing object caused by

echo disturbance from external

acoustic noise or mechanical

misalignments (sporadic false

warnings may occur).
Make sure that the front number

plate is properly mounted (not bent

and no gaps to the bumper on the left

or right side) and the sensors are

firmly in place. The performance of

the parking assist may be reduced if

the license plate is bent or a license

plate support is used.
Low curbs and surface irregularities,

e.g. on construction zones, are not

detected by the system. The driver

accepts responsibility.

Advanced parking assist

Warning

The driver bears full responsibility

for accepting the parking slot

suggested by the system and the

parking manoeuvre.
Always check the surrounding

area in all directions when using

the advanced parking assist.

Driving and operating

207

The advanced parking assist

measures a suitable parking slot

while passing, calculates the

trajectory and automatically steers

the vehicle while parking.
Advanced parking assist provides

assistance for the following

manoeuvres:

● entry into a parallel parking slot
● entry into a perpendicular parking

slot

● exit from a parallel parking slot

The driver must control acceleration,

braking and gear shifting, while

steering is done automatically. The

driver can take control at any time by

gripping the steering wheel.
It may be necessary to move forwards

and backwards more than once.
Instructions are given in the Info

Display

79.

Advanced parking assist can only be

activated when driving forwards.

Advanced parking assist is always

combined with front-rear parking

assist.
The system has six ultrasonic parking

sensors each in both the rear and

front bumper.

Entry into a parallel parking slot

Activation

7'' Colour Info Display: to search for a

parking slot, activate the system by

selecting Park Assist on the

homepage of the touch screen. Then

select Enter parallel parking space.

8'' Colour Info Display: to search for a

parking slot, activate the system by

pressing

. Select Driving functions

on the touch screen and then Park

Assist. Select Enter parallel parking

space.

illuminates in the instrument cluster

to confirm the function.
Slow down the vehicle speed below

12 mph.
Select parking side by switching on

the turn light on the respective side.
The allowed parallel distance

between the vehicle and a row of

parked cars is between 0.5 m and

1.5 m.
The system will not identify slots that

are clearly smaller or larger than the

vehicle.

208

Driving and operating

When a free slot is detected, a visual

feedback on the Colour Info Display

and a first acoustic signal are given.

Drive slowly forwards. When the

second acoustic signal is given, stop

the vehicle, select reverse gear,

release the steering wheel and start

moving without exceeding 4 mph.

Move forwards and backwards while

observing the warnings of the parking

assist until the end of manoeuvre is

indicated. When finished,

extinguishes in the instrument cluster.

Entry into a perpendicular parking

slot

Activation

7'' Colour Info Display: to search for a

parking slot, activate the system by

selecting Park Assist on the

homepage of the touch screen. Then

select Enter perpendicular parking

space.

8'' Colour Info Display: when search

for a parking slot, activate the system

by pressing

. Select Driving

functions on the touch screen and

then Park Assist. Select Enter bay

parking space.

illuminates in the instrument cluster

to confirm the function.
Slow down the vehicle speed below

12 mph.
Select parking side by switching on

the turn light on the respective side.
The allowed parallel distance

between the vehicle and a row of

parked cars is between 0.5 m and

1.5 m.
When several successive slots are

found, the vehicle will be directed

towards the last one.

Driving and operating

209

When a free slot is detected, a visual

feedback on the Colour Info Display

and an acoustic signal are given. Stop

the vehicle, select reverse gear,

release the steering wheel and start

moving without exceeding 4 mph.

Move forwards and backwards as

instructed by observing the warnings

of the parking assist and paying

attention to the acoustic signals until

the end of manoeuvre is indicated.

When finished,

extinguishes in the

instrument cluster.
During the parking manoeuvre, the

system is automatically deactivated

once the rear of the vehicle is within

50 cm of an obstacle.

Exiting a parallel parking slot

Activation

7'' Colour Info Display: when exiting a

parallel parking slot, activate the

system by selecting Park Assist on

the homepage of the touch screen.

Then select Exit parallel parking

space.
8'' Colour Info Display: when exiting a

parallel parking slot, activate the

system by pressing

. Select Driving

functions on the touch screen and

then Park Assist. Select Exit parallel

parking space.
Select exit side by switching on the

respective turn light.
Engage reverse or forward gear,

release the steering wheel and start

moving without exceeding 3 mph.

210

Driving and operating

Move forwards and backwards while

observing the warnings of the parking

assist until the end of manoeuvre is

indicated. The manoeuvre is

complete when the vehicle's front

wheels are out of the parking slot and

extinguishes in the instrument

cluster.
After deactivation ensure to take

control over the vehicle.

Display indication

The instructions on the display show:

● general hints and warning

messages

● the demand to stop the vehicle,

when a parking slot is detected

● the direction of driving during the

parking manoeuvre

● the demand to shift into reverse

or first gear

● the demand to stop or to drive

slowly

● the successful completion of the

parking manoeuvre indicated by

a pop-up symbol and a chime

● the cancelling of a parking

manoeuvre

Deactivation

Do not use the advanced parking

assist when a temporary spare wheel

is mounted. The rear view camera

may not work properly.
The current park assist manoeuvre is

cancelled via the button to return to

the previous screen in the Colour Info

Display. To deactivate the system

completely, press

Off in the

centre console.
The system is deactivated

automatically:

● if the ignition is switched off
● if stalling the engine
● if no manoeuvre is started within

5 minutes of selection of the type

of manoeuvre

● after a prolonged stop of the

vehicle during a manoeuvre

● if the electronic stability control is

triggered

● if the speed of the vehicle

exceeds the stated limit

● when the driver interrupts

movement of the steering wheel

● after four manoeuvre cycles
● on opening the driver's door
● if one of the front wheels

encounters an obstacle

● parking manoeuvre successfully

ended

Driving and operating

211

Deactivation by the driver or by the

system during manoeuvring will be

indicated on the display. Additionally,

an acoustic signal sounds.
The system is deactivated when a

plug is connected to the power outlet

of the trailer hitch.
Contact your dealer to switch off the

system for a prolonged period.

Fault

In the event of a fault,

flashes for a

few seconds, accompanied by an

acoustic signal. If the fault occurs

during the use of the system,

extinguishes.
In the event of a fault in the power

steering,

flashes in the instrument

panel, accompanied by a message.

Notice

Advanced parking assist system

may not respond to changes in the

available parking space after

initiating a parking manoeuvre. The

system may recognize an entry, a

gateway, a courtyard or even a

crossing as a parking slot. Take care

regarding the availability of the

suggested parking slot.

Side blind spot alert

The side blind spot alert system

detects and reports objects on either

side of the vehicle, within a specified

blind spot zone. The system displays

a visual alert in each exterior mirror,

when detecting objects that may not

be visible in the interior and exterior

mirrors.
Side blind spot alert uses some of the

advanced parking assist sensors

which are located in the front and rear

bumper on both sides of the vehicle.

Warning

Side blind spot alert does not

replace driver vision.
The system does not detect:

● vehicles outside the side blind

zones which may be rapidly

approaching

● pedestrians, cyclists or animals

Before changing a lane, always

check all mirrors, look over the

shoulder and use the turn light.

Activation

7'' Colour Info Display: select Blind

spot monitoring on the Info Display

and activate the function.
8'' Colour Info Display: press

Select Driving functions on the Info

Display and then Blind spot

monitoring. Activate the function.

illuminates continously green in the

instrument cluster to confirm the

function.

212

Driving and operating

Functionality

When the system detects a vehicle in

the side blind zone while driving

forwards, an LED will illuminate in the

relevant exterior mirror.
The LED comes on immediately when

being passed.
The LED comes on after a delay when

passing another vehicle slowly.

Operation conditions

The following conditions must be

fulfilled for proper operation:

● all vehicles are moving in the

same direction and in adjacent

lanes

● the vehicle speed is between 7

and 87 mph

● passing a vehicle with a speed

difference of less than 6 mph

● another vehicle is passing with a

speed difference of less than

15 mph

● the traffic flow is normal
● driving on a straight or slightly

curved road

No alert will be given in the following

situations:

● in the presence of non-moving

objects, e.g. parked vehicles,

barriers, street lamps, road signs

● in very dense traffic, when

moving vehicles might be

confused with a stationary object

● with vehicles moving in the

opposite direction

● driving on a winding road or a

sharp corner

● when passing or being passed by

a very long vehicle, e.g. lorry,

coach, which is at the same time

detected at the rear in the blind

spot angle and present in the

driver's forward field of vision

● when passing too quickly

Deactivation

The system is deactivated in the

vehicle personalisation

83.

extinguishes in the instrument cluster.

Additionally, an acoustic signal

sounds.
The state of the system is stored

when switching off the ignition.
The system is switched off

automatically when attaching a trailer

or bike carrier to the trailer hitch.
Due to adverse weather conditions

such as heavy rain, false detections

may occur.

Driving and operating

213

Fault

In the event of a fault,

flashes for a

few moments in the instrument

cluster, accompanied by

and a

display message. Seek the

assistance of a workshop.

Panoramic view system

This system allows views of the

vehicle's surroundings to be

displayed as a nearly 180° picture in

the Info Display, like a bird's eye view.

Warning

The panoramic view system does

not replace driver vision. It will not

display children, pedestrians,

cyclists, crossing traffic, animals,

or any other objects outside of the

camera view area, e. g. below the

bumper, or underneath the

vehicle.
Do not drive or park the vehicle

using only the panoramic view

system.

Always check the surrounding of

the vehicle before and during

driving.
Displayed images may be further

or closer than they appear. The

area displayed is limited and

objects that are close to either

edge of the bumper or under the

bumper are not displayed on the

screen.
Depending on the load of the

vehicle, the inclination of the

vehicle may be changed including

the view of the camera.

The system may use:

● rear camera, installed in the

tailgate

● ultrasonic parking sensors in the

rear bumper

The screen is divided into two parts:

on the right there is a view from above

the vehicle, and on the left there are

different views displayed.

Activation

Panoramic view system is activated

by:

● engaging reverse gear
● driving up to 6 mph

Functionality

Different views can be selected in the

left part of the display. Change the

type of view by pressing the touch

field in the left lower zone of the

display:

● Rear view
● Auto mode

214

Driving and operating

● Zoom view
● 180° view

Auto mode is activated by default. In

this mode, the system selects the

best view, standard or zoom, to

display according to the information

from the ultrasonic parking sensors.
The state of the system is not kept in

memory when the ignition is switched

off.

Rear view

The area behind the vehicle is

displayed in the screen. The vertical

lines represent the width of the

vehicle with mirrors unfolded. The

direction of the lines changes with the

steering angle.
The horizontal lines represent a

distance of about 30 cm, 1m and 2 m

beyond the rear bumper.
This view is available in auto mode or

in the view selection menu.

Auto mode

This mode is activated by default. If

the vehicle is equipped with ultrasonic

parking sensors, the automatic view

changes from rear view or front view

to a view from above, as an obstacle

is approached during a manoeuvre.
If the vehicle is not equipped with

ultrasonic parking sensors, the view

needs to be changed manually in the

Info Display.

Zoom view

The camera records the vehicle's

surroundings during the manoeuvre

in order to reconstruct a view from

above the rear of the vehicle in its

near surroundings, allowing the

vehicle to be manoeuvred around

obstacles nearby. This view is

available with auto mode or in the

view selection menu.

Driving and operating

215

180° view

The 180° view facilitates reversing

out of a parking bay, making it

possible to see the approach of

vehicles, pedestrians and cyclists.

This view is not recommended for

carrying out a complete manoeuvre.

It is made up of three areas: left 1,

centre 2 and right 3. This view is

available from the view selection

menu only.

Deactivation

Panoramic view system is

deactivated when:

● driving faster than 6 mph
● seven seconds after disengaging

reverse gear

● by pressing the icon

in the left

upper corner of the touch screen

● opening the tailgate

System limitations

Caution

For optimal operation of the

system, it is important to keep the

lenses of all cameras always

clean. For the rear view camera,

there is a washer nozzle which will

be activated when the rear window

washer is operating.
If manually cleaning the lenses of

the cameras, rinse the lenses with

water and wipe with a soft cloth.
Do not clean the lenses with a

steam-jet or high-pressure jet

cleaner.

The panoramic view system may not

operate properly when:

● The surrounding is dark.
● The sun or the beam of

headlights is shining directly into

the camera lenses.

● Weather limits visibility, such as

fog, rain, or snow.

● The camera lenses are blocked

by snow, ice, slush, mud, dirt.

● The vehicle is towing an

electrically connected trailer,

bicycle carrier, etc.

● The vehicle had an accident.

Contact a workshop.

● There are extreme temperature

changes.

Caution

It is very important that any repair

to the panoramic view system is

performed accurately according to

Vauxhall specifications.

Otherwise, the system may not

216

Driving and operating

work properly and there is a risk of

unexpected behaviour and / or

messages from the system.

Rear view camera

The rear view camera assists the

driver when reversing by displaying a

view of the area behind the vehicle.
The view of the camera is displayed

in the Info Display.

Warning

The rear view camera does not

replace driver vision. Note that

objects that are outside the

camera's field of view and the

parking assist sensors, e.g. below

the bumper or underneath the

vehicle, are not displayed.
Do not reverse or park the vehicle

using only the rear view camera.
Always check the surrounding of

the vehicle before and during

driving.

Switching on

Rear view camera is automatically

activated when reverse gear is

engaged.

Functionality

The area displayed by the camera is

limited. The distance of the image that

appears on the display differs from

the actual distance.

Guidelines

The vertical lines represent the width

of the vehicle without mirrors and the

general direction of the vehicle. The

horizontal lines represent a distance

of about 30 cm, 1m and 2 m beyond

the rear bumper. The crossing curves

represent the maximum turning circle.

Deactivation of guidelines

Guidelines can be deactivated in the

Info Display. Select Settings

Vehicle

Collision detection

Rear view

camera guide lines

Info Display

79.

Vehicle personalisation

83.

Driving and operating

217

Switching off

The camera is switched off when a

certain forward speed is exceeded or

if reverse gear is disengaged for

approx. 10 seconds.

System limitations

The rear view camera may not

operate properly when:

● The surrounding is dark.
● The beam of headlights is shining

directly into the camera lenses.

● During nighttime driving.
● Weather limits visibility, such as

fog, rain, or snow.

● The camera lenses are blocked

by snow, ice, slush, mud, dirt.

Clean the lense, rinse with water,

and wipe with a soft cloth.

● The tailgate will be opened.
● A trailer or bike carrier is attached

to the trailer hitch.

● The vehicle had a rear end

accident.

● There are extreme temperature

changes.

Traffic sign assistant

Warning

The actual traffic sign always

takes priority over the traffic sign

displayed in the Driver Information

Centre.

Speed limit

Using the camera at the top of the

windscreen and the vehicle's

integrated navigation system, this

system provides speed limits and end

of speed limits in the Driver

Information Centre.
The system can be activated or

deactivated in the vehicle

personalisation

83.

If the system is activated but does not

detect a speed limit sign, the following

sign is displayed:

If the vehicle exceeds the speed limit

by at least 3 mph, the speed limit

displayed flashes about ten seconds.
Speed limiter

195.

Cruise control

192.

Updating navigation map data

To maintain the performance of the

system, the navigation map should be

updated in periodical intervals. A

navigation map update is available

twice per year.
Further information is avaialble in the

Infotainment system section.

Other traffic signs

The system detects traffic signs and

displays them in specific page of the

Driver Information Centre.

This system can be activated or

deactivated in the vehicle

personalisation

83.

218

Driving and operating

Driver Information Centre

76.

System limitations

Traffic sign assistant may not operate

properly when:

● Driving on winding or hilly roads.
● Driving during nighttime.
● Driving with snow chains.
● Driving with a trailer.
● The area of the windscreen,

where the front camera is

located, is not clean or affected

by foreign items, e.g. stickers.

● The visibility is limited because of

the weather, such as fog, rain, or

snow.

● The sun is shining directly into

the camera lens.

● Traffic signs are completely or

partially covered or difficult to

discern.

● Traffic signs are incorrectly

mounted or damaged.

● Traffic signs do not comply with

the Vienna Convention on Road

Signs and Signals.

● The navigation map data is

outdated.

Caution

The system is intended to help the

driver within a defined speed

range to recognise certain traffic

signs. Do not ignore traffic signs

which are not displayed by the

system.
Do not let this special feature

tempt you into taking risks when

driving.
Always adapt speed regarding

road, traffic and weather

conditions.
The driver assistance systems do

not relieve the driver from full

responsibility for vehicle

operation.

When driving abroad make sure

the vehicle uses the speed unit of

the respective country. If

necessary, select the correct units

in the Info Display.

Lane departure warning

The lane departure warning system

supports the driver to avoid

unintended leaving of the lane. The

front camera observes road edges,

as well as the lane markings between

which the vehicle is driving. If the

vehicle approaches a road edge or a

lane marking, the system warns the

driver.
Unintended lane departure is not

assumed by the system when the turn

lights are operated and during few

seconds after turn lights have been

switched off.
No warning will be issued with a

dynamic driving, i.e. pressure on the

brake or accelerator pedal.

Driving and operating

219

When the system recognises an

unintended lane departure, the

control indicator

)

flashes yellow.

Simultaneously a chime sound is

activated.

Warning

This system is a driving aid that

cannot, in any circumstances,

replace the need for vigilance on

the part of the driver.

Activation

The lane departure warning system is

activated by pressing

. The system

is switched on if the LED in the button

is not illuminated.
The system is only operable at

vehicle speeds above 40 mph.

Deactivation

To deactivate the system, press

until LED in the button is illuminated.

Fault

In the event of a fault,

appears in

the Driver Information Centre,

accompanied by a display message.

Seek the assistance of a workshop.

System limitations

The system performance may be

affected by:

● covered camera by snow, ice,

slush, mud, dirt, or affected by

windscreen damage or foreign

items, e.g. stickers

● close vehicles ahead
● banked roads
● winding or hilly roads
● poor lighting conditions
● sudden lighting changes
● shining sun directly into the

camera lens

● adverse environmental

conditions, e.g. heavy rain, fog,

or snow

● vehicle modifications, e.g. tyres
● roads with poor lane markings

220

Driving and operating

Driver alert

The driver alert system monitores the

driving time and the vigilance of the

driver. Monitoring the vigilance of the

driver is based on the trajectory

variations of the vehicle compared to

the lane markings.
The system cannot replace the need

for vigilance on the part of the driver.

Taking a break is recommended as

soon as feeling tired or at least every

two hours. Do not drive when feeling

tired.

Activation or Deactivation

The system can be activated or

deactivated in the vehicle

personalisation

83.

The state of the system stays in

memory when the ignition is switched

off.

Driving time alert

The driver gets notified by a pop-up

reminder symbol

€

in the Driver

Information Centre simultaneously

with an acoustic alert if the driver has

not taken a break after two hours of

driving at a speed above 40 mph. The

alert is repeated hourly until the

vehicle is stopped, no matter how

vehicle speed evolves.
The counting of driving time alert is

reset when the ignition has been

switched off for a few minutes.

Driver drowsiness detection

The system monitors the driver's level

of vigilance. A camera in the

windscreen detects variations in

trajectory compared to the lane

markings. This system is particularly

suited to fast roads (speed higher

than 40 mph).
If the trajectory of the vehicle

suggests a certain level of

drowsiness or inattention by the

driver, the system triggers the first

level of alert. The driver is notified by

a message and an audible signal is

given.
After three first level alerts, the

system triggers a new alert with a

message, accompanied by a more

pronounced audible signal.

In certain driving conditions (poor

road surface or strong winds), the

system may give alerts independent

of the driver's level of vigilance.
The driver drowsiness detection is

reinitialised when the ignition has

been switched off for a few minutes or

the speed remains below 40 mph for

a few minutes.

System limitations

In the following situations, the system

may not operate properly or even not

operate at all:

● poor visibility caused by

inadequate lighting of the

roadway, falling snow, heavy

rain, dense fog etc.

● dazzle caused by headlamps of

oncoming vehicles, low sun,

reflections on damp roads,

leaving a tunnel, alternating

shade and light etc.

● no lane markings detected or

multiple lane markings due to

roadworks

● close vehicles ahead
● winding roads or narrow roads

Driving and operating

221

● advanced lane keep assist is

active

● covered camera by snow, ice,

slush, mud, dirt, or affected by

windscreen damage or foreign

items, e.g. stickers

Fuel

Fuel for petrol engines

Only use unleaded fuel that complies

with European standard EN 228 or

E DIN 51626-1 or equivalent.
The engine is capable of running with

fuel that contains up to 10% ethanol

(e.g. named E10).
Use fuel with the recommended

octane rating. A lower octane rating

can reduce engine power and torque

and slightly increases fuel

consumption.

Caution

Do not use fuel or fuel additives

that contain metallic compounds

such as manganese-based

additives. This may cause engine

damage.

Caution

Use of fuel with a lower octane

rating than the lowest possible

rating could lead to uncontrolled

combustion and engine damage.

The engine specific requirements

regarding octane rating are given in

the engine data overview

278. A

country-specific label at the fuel filler

flap can supersede the requirement.

In certain countries, the use of a

particular fuel, e.g. a specific octane

rating, may be required to ensure

proper engine operation.

222

Driving and operating

Fuel for diesel engines

The diesel engines are compatible

with bio-fuels that conform to current

and future European standards and

can be obtained from filling stations:

Diesel fuel that meets standard

EN590 mixed with a biofuel that

meets standard EN14214 (possibly

containing up to 7% Fatty Acid Methyl

Ester).

Diesel fuel that meets standard

EN16734 mixed with a biofuel that

meets standard EN14214 (possibly

containing up to 10% Fatty Acid

Methyl Ester).

Paraffinic diesel fuel that meets

standard EN15940 mixed with a

biofuel that meets standard

EN14214 (possibly containing up to

7% Fatty Acid Methyl Ester).

The use of B20 or B30 fuel meeting

standard EN16709 is possible.

However, this use, even occasional,

requires strict application of the

special servicing conditions referred

to as "Arduous conditions".
For further information, contact a

workshop.

Caution

The use of any other type of (bio)

fuel (vegetable or animal oils, pure

or diluted, domestic fuel etc.) is

strictly prohibited (risk of damage

to the engine and fuel system).

Notice

The only diesel additives authorised

for use are those that meet the

B715000 standard.

Low temperature operation

At temperatures below 0 °C, some

diesel products with biodiesel blends

may clog, freeze or gel, which may

affect the fuel supply system. Starting

and engine operation may not work

properly. Make sure to fill winter

grade diesel fuel at ambient

temperatures below 0 °C.
Arctic grade diesel fuel can be used

at extremely low temperatures below

-20 °C. Using this fuel grade in warm

or hot climates is not recommended

and may cause engine stalling, poor

starting or damage on the fuel

injection system.

Driving and operating

223

Refuelling

Danger

Before refuelling, switch off

ignition and any external heaters

with combustion chambers.
Follow the operating and safety

instructions of the filling station

when refuelling.

Danger

Fuel is flammable and explosive.

No smoking. No naked flames or

sparks.
If you can smell fuel in your

vehicle, have the cause of this

remedied immediately by a

workshop.

A label with symbols at the fuel filler

flap is indicating the allowed fuel

types. In Europe the pump nozzles of

the filling stations are marked with

these symbols. Refuel only the

allowed fuel type.

Caution

In case of misfuelling, do not

switch on ignition.

Fuel filler flap is located at left rear

side of vehicle.

The fuel filler flap can only be opened

if the vehicle is unlocked. Open the

fuel filler flap by pushing the flap.

Petrol and diesel refuelling

To open, turn the cap slowly

anticlockwise.

224

Driving and operating

The fuel filler cap can be attached to

the hook on the fuel filler flap.
Place the nozzle in straight position to

the filler neck and press with slight

force to insert.
To refuel, switch on pump nozzle.
After the automatic cut-off, the tank

can be topped up by operating the

pump nozzle a maximum of two more

times.

Caution

Wipe off any overflowing fuel

immediately.

To close, turn the fuel filler cap

clockwise.
Close the flap and allow it to engage.

Fuel filler cap

Only use genuine fuel filler caps.
Diesel-engined vehicles have special

fuel filler caps.

Trailer hitch

General information

Only use towing equipment that has

been approved for your vehicle. If

using non-factory fitted towing

equipment, deactivation of the hands-

free tailgate operation may be

required

15.

Entrust retrofitting of towing

equipment to a workshop. It may be

necessary to make changes that

affect the cooling system, heat

shields or other equipment.
The bulb outage detection function for

trailer or bike carrier brake light

cannot detect a partial bulb outage.

E.g. in case of four bulbs with a power

of 5 W each, the function only detects

light outage when only a single 5 W

light remains or none remain.
LED lights are not suitable for the

wiring harness of this trailer hitch.
Fitting of towing equipment could

cover the opening of the towing eye.

If this is the case use the coupling ball

Driving and operating

225

bar for towing. Always keep the

coupling ball bar in the vehicle to have

it on hand if needed.

Driving characteristics and

towing tips

Before attaching a trailer, lubricate

the coupling ball. However, do not do

so if a stabiliser, which acts on the

coupling ball, is being used to reduce

snaking movements.
During trailer towing do not exceed a

speed of 50 mph. A maximum speed

of 60 mph is only appropriate if an

oscillation damper is used and the

permissible gross trailer weight does

not exceed the vehicle's curb weight.
For trailers with low driving stability

and caravan trailers, the use of an

oscillation damper is strongly

recommended.
If the trailer starts snaking, drive more

slowly, do not attempt to correct the

steering and brake sharply if

necessary.
When driving downhill, drive in the

same gear as if driving uphill and

drive at a similar speed.

Adjust tyre pressure to the value

specified for full load

283.

Trailer towing

Trailer loads

The permissible trailer loads are

vehicle and engine-dependent

maximum values which must not be

exceeded. The actual trailer load is

the difference between the actual

gross weight of the trailer and the

actual coupling socket load with the

trailer coupled.
The permissible trailer loads are

specified in the vehicle documents. In

general, they are valid for inclines up

to 12%.
The permissible trailer load applies

up to the specified incline and at sea

level. Since engine power decreases

as altitude increases due to the air

becoming thinner, therefore reducing

climbing ability, the permissible gross

train weight also decreases by 10%

for every 1000 m of altitude. The

gross train weight does not have to be

reduced when driving on roads with

slight inclines (less than 8%, e.g.

motorways).
The permissible gross train weight

must not be exceeded. This weight is

specified on the identification plate

275.

Vertical coupling load

The vertical coupling load is the load

exerted by the trailer on the coupling

ball. It can be varied by changing the

weight distribution when loading the

trailer.
The maximum permissible vertical

coupling load of 65 kg is specified on

the towing equipment identification

plate and in the vehicle documents.

For vehicles with engine DV5RC and

automatic transmission, the

maximum permissible vertical

coupling load is 55 kg. Always aim for

the maximum load, especially in the

case of heavy trailers. The vertical

coupling load should never fall below

25 kg.

226

Driving and operating

Rear axle load

When the trailer is coupled and the

towing vehicle fully loaded, the

permissible rear axle load (see

identification plate or vehicle

documents) may be exceeded by

60 kg, the gross vehicle weight rating

must not be exceeded. If the

permissible rear axle load is

exceeded, a maximum speed of

60 mph applies.

Towing equipment

Caution

When operating without a trailer,

remove the coupling ball bar.

Stowage of coupling ball bar

The bag with the coupling ball bar is

stowed on the rear floor cover in the

load compartment.

Place the strap through the rear right

lashing eye, wrap around twice and

tighten the strap to secure the bag.

Fitting the coupling ball bar

Swivel the connecting socket

downwards. Remove the sealing plug

from the opening for the coupling ball

bar and stow it.

Checking the tensioning of the

coupling ball bar

● Red marking on rotary knob must

point towards green marking on

coupling ball bar.

● The gap between the rotary knob

and the coupling ball bar must be

approx. 6 mm.

● The key must be in position

Otherwise, the coupling ball bar must

be tensioned before being inserted:

Driving and operating

227

● Unlock coupling ball bar by

turning key to position

● Pull out rotary knob and turn

clockwise as far as it will go.

Inserting the coupling ball bar

Insert the tensioned coupling ball bar

in the opening and push firmly

upwards until it audibly engages.
The rotary handle snaps back into its

original position resting against the

coupling ball bar without a gap.

Warning

Do not touch rotary handle during

insertion.

Lock the coupling ball bar by turning

the key to position

. Remove the key

and close the protective flap.

Eye for break-away stopping cable

Attach breakaway stopping cable to

eye.

Checking the correct installation of

the coupling ball bar

● Green marking on rotary knob

must point towards green

marking on coupling ball bar.

● There must be no gap between

the rotary handle and the

coupling ball bar.

● The coupling ball bar must be

firmly engaged in the opening.

● The coupling ball bar must be

locked and the key removed.

228

Driving and operating

Warning

Towing a trailer is permitted only

when a coupling ball bar is fitted

correctly. If the coupling ball bar

does not engage correctly, seek

the assistance of a workshop.

Dismounting the coupling ball bar

Open the protective flap and turn the

key to position

to unlock the

coupling ball bar.
Pull out rotary handle and turn

clockwise as far as it will go. Pull out

coupling ball bar downwards.
Insert sealing plug in opening.

Swivel the connecting socket

upwards.
Stow the coupling ball bar in the bag

and secure by fixing the strap through

the rear right lashing eye. Wrap

around twice and tighten the strap to

secure the bag.

Vehicle care

229

Vehicle care

General Information ................... 229

Accessories and vehicle

modifications .......................... 229

Vehicle storage ........................ 232

End-of-life vehicle recovery ..... 233

Vehicle checks ........................... 233

Performing work ...................... 233

Bonnet ..................................... 234

Engine oil ................................. 234

Engine coolant ......................... 235

Washer fluid ............................ 236

Brakes ..................................... 236

Brake fluid ............................... 236

Vehicle battery ......................... 237

Diesel fuel system bleeding ..... 239

Wiper blade replacement ........ 239

Bulb replacement ....................... 240

Halogen headlights .................. 240

LED headlights ........................ 242

Front fog lights ......................... 243

Tail lights ................................. 243

Side turn lights ......................... 247

Number plate light ................... 248

Interior lights ............................ 248

Electrical system ........................ 248

Fuses ....................................... 248

Vehicle tools .............................. 248

Tools ........................................ 248

Wheels and tyres ....................... 249

Winter tyres ............................. 249

Tyre designations .................... 249

Tyre pressure .......................... 250

Tyre deflation detection

system .................................... 251

Tread depth ............................. 251

Changing tyre and wheel size . 252

Wheel covers ........................... 252

Tyre chains .............................. 253

Tyre repair kit .......................... 253

Wheel changing ....................... 256

Spare wheel ............................ 258

Jump starting ............................. 263
Towing ....................................... 264

Towing the vehicle ................... 264

Towing another vehicle ........... 265

Appearance care ....................... 266

Exterior care ............................ 266

Interior care ............................. 268

Floor mats ............................... 268

General Information

Accessories and vehicle

modifications

We recommend the use of genuine

parts and accessories and factory

approved parts specific for this

vehicle type. We cannot assess or

guarantee reliability of other products

- even if they have a regulatory or

otherwise granted approval.
Any modification, conversion or other

changes made to standard vehicle

specifications (including, without

limitation, software modifications,

modifications of the electronic control

units) may invalidate the warranty

offered by Vauxhall.
Furthermore, such changes may

affect driver assistance systems, may

impact fuel consumption, CO

emissions and other emissions of the

vehicle and cause the vehicle to no

longer conform to the operating

permit, impacting the validity of your

vehicle registration.

Vauxhall Crossland X (2023 year). Manual in english - page 7
