SANY DUMPER Truck SYZ318C-8R. Technical Specifications & Load Chart
SANY DUMPER
SYZ318C-8R
Quality
Security
Efficient Braking System
More Reliable
◆◆
Through the combination of engine exhaust brake and tyre
◆◆
Digital simulation
brake system, braking distance could be ≤10m(v=30km/h)
◆◆
Structure test
when full load. Security risk was dramatically reduced.
◆◆
Experienced 300,000KM road test.
Lower Gravity
More Energy-efficient
◆◆
Height of gravitational center is 1315mm, move safe and
◆◆
Superior Engine & Gearbox Combination
stable.
◆◆
Equipped with Euro
diesel engine, 10 AT wide speed
gearbox and double reduction axles with high speed ratio.
High-strength Structure
Fuel consumption is less than 45L/100KM when full load at
the speed of 50KM/H.
Quality Changes the World
SANY Industry Town, Changsha Economic and Technological Development Zone,
Hunan Province, China
Service Line: +86 4006 098 318
E-mail: crd@sany.com.cn
SYZ318 Specification
No.
Model
SYZ318C-8R
1
Dimension (L×H×W)
8350 mm × 2550 mm × 3550 mm
2
Gross Weight
14000 kg
3
Max. Full Load Weight
43000 kg
4
Min. Turning Diameter
18 m
5
Max. Gradability
≥30%
6
Max. Speed
85 km/h
7
Steering Wheel
Left-mounted
8
Cargo Capacity
18 m³
9
Cargo Empty
5400 mm × 2300 mm × 1500 mm
10
Lifting Angle
48°
11
Lifting Mode
Front Lifting
12
Manufacturer
SANY
13
Engine
J08E-UP (HINO)
14
Power
222 kW
15
Emission Standard
Euro
16
Axles Quantity
3
17
Wheel Base
3775+1400 mm
18
Gear Box
FAST 10JSD120B
19
Front Axle
7.5 T
20
Rear Axle
2×16 T
21
Tyre
315/80 R22.5
22
Cab
SANY CB318
23
Fuel Tank
300 L
