CG958H Wheel Loader. Manual - part 3

14

20. Rise and down of lift arm















21. Power off prompt sign





22. Burn prevention symbol















23. Binding symbol





24. Symbol of escape exit from the cab













25. Symbol of lift arm support













26. Housing rollover switch symbol













27. Master switch symbol

















 Safety rules

Ⅱ



2.1  EU Safety Requirements

1． Noise limit requirement

Complying with the 2000/14/EC directive, this machine meets the following requirements:

L

PA

：

≤85dB (A)

L

WA

：

≤106.36 dB (A)

See the attached table

DECLARED SINGLE-NUMBER NOISE EMISSION VALUES for the noise

test of the model machine.



2． The vibration value of the seat of cab of this machine meets the requirements of ISO

7096-2000. See the attached table

DECLARED VIBRATION EMISSION VALUES OF A SINGLE

MACHINE for vibration test of the model machine.



3． Electromagnetic compatibility

The electromagnetic compatibility of this machine complies with the relevant requirements of

ISO13766 EN 13309 Standard. The machines can maintain its normal functions in certain

electromagnetic environments and the electromagnetism generated during the operation does not

cause damages to surrounding environment.

4．  The cab of this machine has ROPS – rollover protective structure and FOPS – falling

object protective structure.

2.2  Safety of Operator

Pay attention to location of all safety and warning symbols on the machine and comprehend their

meanings. The symbols and warnings that are obscure or damaged during use shall be replaced by

new ones.

When the operator is in one of the following status, he shall not operate the machine:

z  When the operator is exhausted, he shall not operate

the machine.

z  When the operator has taken medicines that may cause

sleepiness, he shall not operate the machine.

z  The operator shall not operate the machine after

drinking alcohol.

z  The operator shall wear work clothes, work cap and work gloves for the servicing of the

-  -

16

machine. The operator shall not wear clothes or ornamental articles that may either hook or

entangle the machine, or cause combustion or sparkles in contact with electrical devices.

z  Personnel who is not approved or certificated (operation qualification certificate) is not allowed

to conduct operation, repair, or maintenance of the machine.

z  Be familiar with the command signs and only follow the command signs of one person.

z  Before starting the machine, be clear of:

Location of fire extinguisher

Location of toolkit

Fire alarm telephone number

Emergency telephone number

Walk around the machine to ensure nobody is working around the machine and nobody is working

lying underneath the machine.

2.3 Safety Protective Appliances

z  When servicing the machine, determine the needed

individual protective appliances according to the

specific work environment.

z  Do not wear clothes or ornamental articles that may

either hook or entangle the machine.

z  Do not wear clothes or ornamental articles that may

cause combustion or sparkles in contact with electrical devices.

z  All protective appliances shall be checked prior to use for their usability.

2.4 Safety Device



Ensure that all protective devices and housing are in their proper position. Any damaged one shall be

repaired in time.

z  Properly use the safety device;

z  Do not dismantle the safety device and keep it under good conditions.

z  Improper use of the safety device will possibly cause personnel casualty.







-  -

17

III Operation of the Machine

Safety issues

In this section, relevant safety warnings and some accident threats are explained. Please assign

some time to get familiar with these safety issues before starting the machine.

Warning contents

Warning

Unless you have already read and comprehended the servicing instructions and safety issues,

do not work on this machine. Failure to follow the instructions or ignorance of warnings may

cause injuries. Be prudent is your responsibility.

Warning

This cab is integrated with the ROPS. Structural damages, rollover, modifications,

replacements or improper repair may detrimentally affect the protective performance of

ROPS and thus fail the standard that has been met previously. Please consult Sichuan

Chengdu Chenggong Construction Machinery Co., Ltd for the limit of failure of the ROPS.

Warning

Improper external power supply may cause explosion and injuries. Tandem storage battery

shall be contained in a separate storage battery box. When using an external power supply,

the (+) pole of the wire shall be connected to the positive (+) pole of the storage battery that

connects the starter coil, and the negative (-) pole of the wire of external power supply shall be

connected to the negative pole of the starter. (If there is no negative pole of starter, connect to

the body of engine.)

Warning

During the operation of the machine, the space between the front and rear frames is not

allowed to be entered. When the machine is hoisted and loaded on other machines, or when

servicing at the middle of the machine, the lock rod shall be installed between the front and

rear frames to keep the machine in a straight position. When the machine is hoisted and

loaded on other machines, or when servicing at the middle of the machine, the lock rod shall

be installed between the front and rear frames to keep the machine in a straight position.

Warning
