PERIODIC MAINTENANCE

62

LV Operation Manual

CAUTION

• When the engine is operated in dusty

conditions, clean the air cleaner
element more frequently.

• NEVER operate the engine with the air

cleaner or element(s) removed.  This
may cause foreign material to enter the
engine and damage it.

0000026en

CAUTION

The maximum air intake restriction shall
be:

• L48V: 0.10 psi (0.69 kPa; 70 mm Aq) or

less

• L70V: 0.20 psi (1.37 kPa; 140 mm Aq)

or less

• L100V: 0.21 psi (1.47 kPa; 150 mm Aq)

or less.

Clean or replace the air cleaner element
if the air intake restriction exceeds the
above mentioned value.

0000046enLV

CAUTION

The tightening torque in the Standard
Torque Chart (page 64) should be
carefully observed.

• Apply 60% torque to bolts that are not

listed.

• Apply 80% torque when tightened to

aluminum alloy.

0000023enLVOM

PERIODIC MAINTENANCE

LV Operation Manual

63

PRECAUTIONS

The Importance of Periodic
Maintenance

Engine deterioration and wear occurs in
proportion to length of time the engine has been
in service and the conditions the engine is subject
to during operation. Periodic maintenance
prevents unexpected downtime, reduces the
number of accidents due to poor machine
performance and helps extend the life of the
engine.

Performing Periodic Maintenance

Perform periodic maintenance procedures in an
open, level area free from traffic. If possible,
perform the procedures indoors to prevent
environmental conditions, such as rain, wind, or
snow, from damaging the machine.

The Importance of Daily Checks

Periodic Maintenance Schedules assume that the
daily checks are performed on a regular basis.
Make it a habit of performing daily checks before
the start of each shift. See Daily Checks on
page 34.

Keep a Log of Engine Hours and
Daily Checks

Keep a log of the number of hours the engine is
run each day and a log of the daily checks
performed. Also note the date, type of repair
(e.g., replaced alternator), and parts needed for
any service needed between the periodic
maintenance intervals. Periodic maintenance
intervals are every 50, 200, 400, 1000, 1500 and
2000 engine hours. Failure to perform periodic
maintenance will shorten the life of the engine.

Yanmar Replacement Parts

Yanmar recommends that you use genuine
Yanmar parts when replacement parts are
needed. Genuine replacement parts help ensure
long engine life.

Tools Required

Before you start any periodic maintenance
procedure make sure you have the tools you
need to perform all of the required tasks.

Ask Your Authorized Yanmar
Industrial Engine Dealer or
Distributor For Help

Our professional service technicians have the
expertise and skills to help you with any
maintenance or service related procedures you
need help with.

A

 WARNING

EXHAUST HAZARD!

• NEVER operate the engine in an

enclosed area such as a garage,
tunnel, underground room, manhole or
ship’s hold without proper ventilation.

• NEVER block windows, vents, or other

means of ventilation if the engine is
operating in an enclosed area. All
internal combustion engines create
carbon monoxide gas during
operation. Accumulation of this gas
within an enclosure could cause
illness or even death.

• Make sure that all connections are

tightened to specifications after repair
is made to the exhaust system.

• Failure to comply could result in death

or serious injury.

0000003en

PERIODIC MAINTENANCE

64

LV Operation Manual

Required EPA / ARB Maintenance -
USA Only

To maintain optimum engine performance and
compliance with the Environmental Protection
Agency (EPA) Regulations Non-road Engines
and the California Air Resources Board (ARB,
California), it is essential that you follow the
Periodic Maintenance Schedule on page 65 and
Periodic Maintenance Procedures which start on
page 67.

EPA / ARB Installation
Requirements - USA Only

The following are the installation requirements for
the EPA / ARB. Unless these requirements are
met, the exhaust gas emissions will not be within
the limits specified by the EPA and ARB.

Maximum Exhaust Gas Restriction shall be:

• L48V: 0.53 psi (3.628 kPa; 370 mm Aq) or Iess

• L70V: 0.54 psi (3.727 kPa; 380 mm Aq) or Iess

• L100V: 0.63 psi (4.315 kPa; 440 mm Aq) or Iess

Maximum Exhaust Gas Restriction shall be:

• L48V: 0.10 psi (0.69 kPa; 70 mm Aq) or Iess

• L70V: 0.20 psi (1.37 kPa; 140 mm Aq) or Iess

• L100V: 0.21 psi (1.47 kPa; 150 mm Aq) or Iess

Clean or replace the air cleaner element if the air
intake restriction exceeds the above mentioned
value.

Tightening Fasteners

Use the correct amount of torque when you
tighten fasteners on the machine. Applying
excessive torque may damage the fastener or
component and not enough torque may cause a
leak or component failure.

STANDARD TORQUE CHART

CAUTION

The tightening torque in the Standard
Torque Chart (page 64) should be
carefully observed.

• Apply 60% torque to bolts that are not

listed.

• Apply 80% torque when tightened to

aluminum alloy.

0000023enLVOM

Thread size × Pitch mm

M6×1.0

M8×1.25

M10×1.5

M12×1.75

M14×1.5

M16×1.5

Tightening
Torque

in  lbs

96.0  ±  9.0

-

-

-

-

-

ft lbs

-

19.0 ± 2.0

36.0 ± 4.0

65.0 ± 7.0

101.0 ± 7.0

167.0 ± 7.0

N·m

10.8 ± 1.0

25.5 ± 2.9

49.0 ± 4.9

88.3 ± 9.8

137.0 ± 9.8

226.0 ± 9.8

kgf·m

1.1 ± 0.1

2.6 ± 0.3

5.0 ± 0.5

9.0 ± 1.0

14.0 ± 1.5

23.0 ± 2.0

PERIODIC MAINTENANCE

LV Operation Manual

65

PERIODIC MAINTENANCE
SCHEDULE

Daily and periodic maintenance is important to
keep the engine in good operating condition. The
following is a summary of maintenance items by
periodic maintenance intervals. Periodic
maintenance intervals vary depending on engine
application, loads, diesel fuel and engine oil used
and are hard to establish definitively. The
following should be treated only as a general
guideline.

CAUTION

Establish a periodic maintenance plan
according to the engine application and
make sure you perform the required
periodic maintenance at intervals
indicated. Failure to follow these
guidelines will impair the engine’s safety
and performance characteristics,
shorten the engine’s life and may affect
the warranty coverage on your engine.
See Yanmar Limited Warranty on
page vii.

Consult your authorized Yanmar
industrial engine dealer or distributor for
assistance when checking items marked
with a  .

0000024enLVOM
