PERIODIC MAINTENANCE

58

LV Operation Manual

A

 WARNING

SHOCK HAZARD!

• Turn off the battery switch (if

equipped) or disconnect the negative
battery cable before servicing the
electrical system.

• Check the electrical harnesses for

cracks, abrasions, and damaged or
corroded connectors. ALWAYS keep
the connectors and terminals clean.

• Failure to comply could result in death

or serious injury.

0000009en

A

 WARNING

SEVER HAZARD!

• Stop the engine before you begin to

service it.

• NEVER leave the key in the key switch

when you are servicing the engine.
Someone may accidentally start the
engine and not realize you are
servicing it. This could result in a
serious injury.

• If you must service the engine while it

is operating, remove all jewelry, tie
long hair back, and keep your hands,
other body parts and clothing away
from moving / rotating parts.

• Failure to comply could result in death

or serious injury.

0000010en

A

 WARNING

BURN HAZARD!

• If you must drain the engine oil while it

is still hot, stay clear of the hot engine
oil to avoid being scalded. Make sure
you wear eye protection.

• Failure to comply could result in death

or serious injury.

0000011en

A

 CAUTION

FLYING OBJECT HAZARD!

• ALWAYS wear eye protection when

servicing the engine and when using
compressed air or high-pressure
water. Dust, flying debris, compressed
air, pressurized water or steam may
injure your eyes.

• Failure to comply may result in minor

or moderate injury.

0000003en

PERIODIC MAINTENANCE

LV Operation Manual

59

CAUTION

• Only use diesel fuels recommended by

Yanmar for the best engine
performance, to prevent engine
damage and to comply with EPA / ARB
warranty requirements.

• Only use clean diesel fuel.

• NEVER remove inlet fuel screen from

the filler port. If removed, dirt and
debris could get into the fuel system
causing it to clog.

0000004enLV

CAUTION

• Only use the engine oil specified.

Other engine oils may affect warranty
coverage, cause internal engine
components to seize, or shorten
engine life.

• Prevent dirt and debris from

contaminating the engine oil. Carefully
clean the oil cap / dipstick and the
surrounding area before you remove
the cap.

• NEVER mix different types of engine

oil. This may adversely affect the
lubricating properties of the engine oil.

• NEVER overfill. Overfilling may result

in white exhaust smoke, engine
overspeed or internal damage.

0000005en

CAUTION

• NEVER attempt to modify the engine’s

design or safety features such as
defeating the engine speed limit
control or the fuel injection quantity
control.

• Failure to comply may impair the

engine’s safety and performance
characteristics and shorten the
engine’s life. Any alterations to this
engine may affect the warranty
coverage of your engine. See Yanmar
Limited Warranty on page vii.

0000044enLVOM

CAUTION

Observe the following environmental
operating conditions to maintain engine
performance and avoid premature
engine wear:

• Avoid operating in extremely dusty

conditions.

• Avoid operating in the presence of

chemical gases or fumes.

• Avoid operating in a corrosive

atmosphere such as salt water spray.

• NEVER install the engine in a

floodplain unless proper precautions
are taken to avoid being subject to a
flood.

• NEVER expose the engine to the rain.

0000003en

PERIODIC MAINTENANCE

60

LV Operation Manual

CAUTION

Observe the following environmental
operating conditions to maintain engine
performance and avoid premature
engine wear:

• NEVER run the engine if the ambient

temperature is above +104°F (+40°C)
or below +14°F (-10°C)

◆

If the ambient temperature exceeds
+104°F (+40°C) the engine may
overheat and cause the engine oil to
break down.

◆

If the ambient temperature falls
below +14°F (-10°C) rubber
components such as gaskets and
seals will harden causing premature
engine wear and damage.

◆

Contact your authorized Yanmar
industrial engine dealer or
distributor if the engine will be
operated in either temperature
extreme.

• Contact your authorized Yanmar

industrial engine dealer or distributor
if you need to operate the engine at
high altitudes. At high altitudes the
engine will lose power, run rough, and
produce exhaust gases that exceed
the design specifications.

0000065enLV

CAUTION

NEVER hold the key in the START
position for longer than 15 seconds or
the starter motor will overheat.

0000007en

CAUTION

For maximum engine life, Yanmar



recommends that when shutting the
engine down, you allow the engine to
idle, without load, for 5 minutes. This
will allow the engine components that
operate at high temperatures, such as
the turbocharger (if equipped) and
exhaust system, to cool slightly before
the engine itself is shut down.

0000008en

CAUTION

NEVER use an engine starting aid such
as ether. Engine damage will result.

0000009en

CAUTION

Make sure the engine is installed on a
level surface. If a continuously running
engine is installed at an angle greater
than 20° (in any direction) or if an engine
runs for short periods of time (less than
3 minutes) at an angle greater than 25°
in any direction, engine oil may enter the
combustion chamber causing exessive
engine speed and generate white
smoke. This may cause serious engine
damage.

0000010enTNE

CAUTION

• NEVER overfill the engine with engine

oil.

• ALWAYS keep the oil level between the

upper and lower lines on the oil
cap / dipstick.

0000015en

PERIODIC MAINTENANCE

LV Operation Manual

61

CAUTION

It is important to perform daily checks.
See Daily Checks on page 34.

Periodic maintenance prevents
unexpected downtime, reduces the
number of accidents due to poor
machine performance and helps extend
the life of the engine.

0000060enLVOM

CAUTION

NEVER engage the starter motor while
the engine is running. This may damage
the starter motor pinion and / or ring
gear.

0000012en

CAUTION

Protect the air cleaner, turbocharger (if
equipped) and electric components
from damage when you use steam or
use high-pressure water to clean the
engine.

0000014en

CAUTION

Be environmentally responsible. Follow
these procedures for hazardous waste
disposal. Failure to follow these
procedures may seriously harm the
environment.

• Follow the guidelines of the EPA or

other governmental agency for the
proper disposal of hazardous
materials such as engine oil, diesel
fuel and engine coolant. Consult the
local authorities or reclamation facility.

• NEVER dispose of hazardous

materials irresponsibly by dumping
them into a sewer, on the ground or
into ground water or waterways.

0000013en

CAUTION

Establish a periodic maintenance plan
according to the engine application and
make sure you perform the required
periodic maintenance at intervals
indicated. Failure to follow these
guidelines will impair the engine’s safety
and performance characteristics,
shorten the engine’s life and may affect
the warranty coverage on your engine.
See Yanmar Limited Warranty on
page vii.

Consult your authorized Yanmar
industrial engine dealer or distributor for
assistance when checking items marked
with a  .

0000024enLVOM
