ENGINE
DIESEL PARTICULATE FILTER HANDLING MANUAL, WSM
1-S17
[7] PACKING, DELIVERING, AND HANDLING STANDARD OF DPF
FILTER COMPLETE
Follow the below procedures to pack the separated DPF filter complete and to send it to a cleaning contractor.
[Packing and delivering]
(1) Refer to the example of packaging, cover and seal the DPF filter complete with a plastic bag so that soot and ash
are not scattered in the air, and pack it in a cardboard box having cushioning material in it.
(2) Put "FRAGILE" sticker on the package.
(3) Make sure not to drop DPF filter complete when handling and carrying.
Packing and Delivering of DPF Filter Complete (Example)
1. Seal the removed DPF filter complete with a plastic bag as
shown in the photograph [A].
2. Put a cushioning material in the bottom of the prepared
cardboard box.
3. Put the DPF filter complete with the sealed plastic bag on a
cushioning material.
4. Put a cushioning material in around the DPF filter complete as
shown in the photograph [B].
5. Put a cushioning material over the DPF filter complete as shown
in the photograph [C].
6. Enclose the completed DPF Cleaning Order Form in the
cardboard box and close it.
7. Put "FRAGILE" sticker on the cardboard box.
8. Write the address and send it to a cleaning contractor.
[Cautions for handling]
(1) Workers should wear a mask and goggles, and other required protective equipments according to local relevant
regulations whenever cleaning DPF.
(2) The removed soot and ash should be collected on a filter etc. and safely disposed by an industrial waste disposer
according to local relevant regulations.
[Disposal standard of DPF]
(1) DPF should be disposed by an industrial waste disposer according to local relevant regulations.
