SPECIFICATIONS

6LPA Series Operation Manual

79

12/05

Marine Drive Specifications (Optional)

Model

Hurth

Kanzaki

Mercruiser

ZF63A1

KMH50A

KMH50V

ZT370

Bravo X-1 Bravo X-2 Bravo X-3

Type

8° down Hydraulic

12° down
Hydraulic

Stern Drive

Applicable
engine

6LPA-STP2

6LPA-STZP2

Reduction ratio
ZF63A1:
Ahead / Astern
Bravo X-1, 2, 3:
Both Ahead /
Astern

1.22 / 1.21 1.67 / 1.67 1.22 / 1.22

1.65

1.36

1.50

1.36

1.56 / 1.58 2.13 / 2.13 1.58 / 1.58

1.78

1.50

1.65

1.50

2.04 / 2.10 2.43 / 2.43 2.08 / 2.08

-

-

1.81

1.65

2.52 / 2.53

-

2.47 / 2.47

-

-

2.00

1.81

See manufacturer’s documentation for additional information.

SPECIFICATIONS

80

6LPA Series Operation Manual

This Page Intentionally Left Blank

6LPA Series Operation Manual

81



SYSTEM DIAGRAMS

PIPING DIAGRAMS

Note: Fuel rubber pipes (marked *) satisfy EN / ISO7840.

Notation

Description

Screw Joint (Union)

Flange Joint

Eye Joint

Insertion Joint

Drilled Hole

Coolant Piping

Cooling Seawater Piping

Lubricating Oil Piping

Diesel Fuel Piping

SYSTEM DIAGRAMS

82

6LPA Series Operation Manual

 Figure 1

6LPA-STP2

Figure 1

(12)

(11)

(14)

(1

3

)

(16)

(15)

(1

8

)

(21)

(2

3

)

(25)

(17)

(19)

(20)

(22)

(24)

(26)

(8

)

(6)

(5)

(4)

(3

)

(2)

(1)

(9)

(10)

(7)
