TM 11275-15/3D

INDEX

Subject

Page No.

Numerics

120M Motorized Road Grader

2-43

20,000 Gallon Collapsible, Coated-Fabric, Fuel Tank Assembly

2-69

277C Multi-Terrain Loader

2-26

2-Inch Hose Tank Farm Interconnection Set

2-136

3,000 Gallon Collapsible, Coated-Fabric, Fuel Tank Assembly

2-68

4-Inch Discharge Hose Tank Farm Interconnection Set

2-137

4-Inch Hose Tank Farm Interconnection Set

2-135

50,000 Gallon Collapsible Coated-Fabric, Fuel Tank Assembly

2-67

500 Gallon Collapsible Coated-Fabric Potable Water Drum

2-66

600 GPM Pump Tactical Water Distribution System (TWDS)

2-153

613C Water Distributor

2-13

621B Wheeled Tractor-Scraper (WTS)

2-123

Advanced Mine Detector, AN/PSS-14

2-63

Air Compressor With Pneumatic Tools

2-57

Air Conditioner

0.75-Ton, 9,000 BTU/hr, 60 Hz

2-39

1.5-Ton, 18,000 BTU/hr

2-3

10-Ton, 120,000 BTU/hr

2-7

3-Ton, 36,000 BTU/hr

2-9

5-Ton, 60,000 BTU/hr

2-6

MCS, Horizontal, 0.75-Ton

2-1

MCS, Horizontal, 400 Hz, 1.5-Ton

2-4

MCS, Horizontal, 60 Hz, 1.5-Ton

2-2

MCS, Vertical, 400 Hz, 3-Ton

2-5

MCS, Vertical, 50/60 Or 400 Hz, 18,000 BTU

2-8

Airfield Damage Repair (ADR) Kit

2-25

All Terrain Crane (ATC)

2-24

Amphibious Assault Fuel System

2-82

Assault Breacher Vehicle (ABV)

2-52

Aviation Fuel Contamination Test Kit

2-110

Backhoe Loader (BHL)

2-160

Bag Filler Tank Farm Interconnection Set

2-134

Bath Shower Unit

2-28

Index-1

TM 11275-15/3D

INDEX - Continued

Subject

Page No.

Bridge

Erection Boat (BEB)

2-47

Erection Boat MKII Tactical Trailer

2-48

Erection Set

2-49

Bridge, Floating, IRB 80T, 100T Rafting Set, Ribbon Bridge, Construction Outfit Ramp Bay and Interior Bay Data

2-51

Bucket, Clamshell

2-53

Bucket, Concrete

2-54

Carpenter Kit

2-143

Caterpillar, Tool Kit

2-144

Clamshell, Bucket

2-53

Climber’s Set, Tree, and Pole

2-37

Cold Weather Kit

2-93

Collapsible Coated-Fabric Fuel Drum

2-65

Collapsible Fabric 3,000 Gallon Water Tank

2-132

Compressed Air Foam System-Mobile (CAFS-M)

2-77

Concrete, Bucket

2-54

Construction Shop Kit

2-124

Containerized Batch Laundry (CBL) Unit

2-36

Cooling and Refrigeration Expeditionary Kit (CREK)

2-31

D7G

Winch, Attachment, Single Drum

2-174

Demolition Equipment Set

2-61

Diesel Engine, Generator Set, Model MEP-802A

2-42

Distribution Point Tactical Water Distribution System (TWDS)

2-152

Dry Chem, Self-Contained Fire Extinguisher

2-178

Dummy Load Generator Set, 100 kW

2-70, 2-71

Electrician Lineman Tool Kit

2-146

Engineer Equipment Trailer (EET)

2-162

Equipment Description Sheet Format

1-1

Equipment Listing by TAM-Number Sequence

3-1

Index-2

TM 11275-15/3D

INDEX - Continued

Subject

Page No.

Expedient Refueling System (ERS)

2-111

Extendable Boom Forklift Truck (EBFL)

2-161

Field Wiring Harness

2-76

Fire Suppression System (FSS)

2-78

Fixed Drawbar Attachment

2-64

Floodlight Set

Self-Contained

2-79

Forklift Attachment

2-34, 2-

165

Forward Area Water Point Supply System

2-81

Full-Tracked Tractor With Multi-Purpose Bucket

2-159

Full-Tracked, Tractor With Angle Blade

2-157

General Arrangement

1-1

Generator Set

Diesel Engine, 10 kW, 400 Hz

2-86

Diesel Engine, 10 kW, 60 Hz

2-85

Diesel Engine, 100 kW, 60 Hz

2-100

Diesel Engine, 2 kW, 60 Hz

2-92

Diesel Engine, 20 kW, 60 Hz

2-87

Diesel Engine, 3 kW, 60 Hz

2-84

Diesel Engine, 30 kW, 400 Hz

2-91

Diesel Engine, 30 kW, 60 Hz

2-89

Diesel Engine, 60 kW, 400 Hz

2-95

Diesel Engine, 60 kW, 60 Hz

2-97

Generator Set, Diesel Engine, Model MEP-802A

2-42

Generator Set, Diesel Engine, Model MEP-809A

2-46

Generator Set, Diesel Engine, Model MEP-903A

2-10

Ground Expedient Refueling System (GERS)

Medium

2-22

Small

2-23

Helicopter Expedient Refueling System

2-102

High Speed, High Mobility, (HSHM) Crane

2-58

Hose Nozzle Tank Farm Interconnection Set

2-138

Index-3

TM 11275-15/3D

INDEX - Continued

Subject

Page No.

Hose Reel System

2-103

Hypochlorination Unit, Purification, 2-350

2-104

IM Tram, Tool Kit

2-145

Improved Ribbon Bridge Raft Set Ramp Bay

2-117

Integrated Trailer-ECU-Generator (ITEG)

2-12

Joint Assault Bridge (JAB)

2-29

Kit, Armor Tractor, Rubber Tire, Articulated Steering, Multi-Purpose

2-180

Kit, Armor, Medium Crawler Tractor

2-181

Kit, Tool, Caterpillar

2-144

Kit, Tool, IM Tram

2-145

Kit, Tool, M9 ACE, 2nd OEM

2-155

Kit, Tool, M9 ACE, 3rd/4th OEM

2-156

Large Field Refrigeration System (LFRS)

2-27

Laserplane, Level System

2-179

Level System, Laserplane

2-179

Light Capacity Rough Terrain Truck Forklift (LRTF)

2-163

Lightweight Water Purification System (LWPS)

2-38

Lineman’s Tool Kit

2-32

List of Abbreviations/Acronyms

1-2

M9 ACE Armored Combat Earthmover

2-72

M9 ACE, 2nd OEM, Tool Kit

2-155

M9 ACE, 3rd/4th OEM, Tool Kit

2-156

Maintenance Platform, Air Mobile Crane

2-107

Marine Corps Tactical Welding Shop (MCTWS)

2-171

Armor Welding Kit

2-172

Titanium Kit

2-173

Mason and Concrete Finishers Kit

2-149

Medium Crawler Tractor (MCT)

2-30

Index-4

TM 11275-15/3D

INDEX - Continued

Subject

Page No.

Medium Girder Bridge (MGB)

2-50

Medium, Full-Tracked Tractor

2-158

MEPDIS-Replacement, Power Distribution Box

100 kW

2-20

15 kW

2-18

30 kW

2-19

300 kW

2-21

Indoor Model, 5 kW, GFCI Protected

2-16

Outdoor Model, 5 kW, Non-GFCI Protected

2-17

Mine Detector, AN/PSS-12

2-62

Minefield Marking Set

2-109

MK 1 MOD Mine Clearance System

2-108

MK 2 MOD 0 Mine Clearance System Trailer Mounted

2-106

Mobile Electric Power Distribution, 100 kW Panel

2-75

Mobile Electric Power Distribution, 15 KW Panel

2-73

Mobile Electric Power Distribution, 30 kW Panel

2-74

Motorized Road Grader

2-101

Multi-Purpose Bucket

2-35, 2-

166

Multi-Terrain Loaded Work Tool

2-41

Obsolete Equipment List

4-1

Pioneer Platoon Kit

2-147

Pioneer Squad Kit

2-148

Power Distribution System, FFSS Bus Duct

2-177

Pump

Fuel, 600 GPM

2-115

Water, 350 GPM

2-114

Pump Module

Fuel Six Container (Sixcon)

2-112

Water Six Container (Sixcon)

2-113

Pump Set, 65 GPM, 50 ft Head

2-116

Pump Station, Tactical Water Distribution System (TWDS)

2-150

Refrigeration Unit, Enhance

2-118

Index-5

TM 11275-15/3D

INDEX - Continued

Subject

Page No.

Refrigerator, Rigid Box

2-119

Reinforcement Set, Medium Girder Bridge (MGB)

2-120

Ripper Attachment, 3-Shank, Rear MTG F/Tractor

2-44

Roller, Compactor, Vibratory, Self-Propelled

2-122

Rough Terrain Air Mobile Crane (AMC)

2-59

Rough Terrain Container Handler (RTCH)

Kalmar

2-56

Vehicle

2-55

Rubber-Tired, Articulated Steering, Multi-Purpose Tractor (TRAM)

2-164

Scope

1-1

Shop Equipment, General Purpose, Set No. 1

2-125

SIXCON, Fuel Storage Tank Module

2-128

Skid-Mounted Hydroseeder

2-15

Skid-Mounting Assembly, Large, Remote Air Conditioner

2-127

Skid-Mounting Assembly, Small, Remote, Air Conditioner

2-126

Small Field Refrigeration System (SFRS)

2-40

Squad Demolition Kit (SDK)

2-60

Storage Assembly, Tactical Water Distribution System (TWDS)

2-151

Survey Set General Purpose

2-130

Sweeper, Rotary, Vehicle Mounting

2-131

Synchronizer Box, Generator, 20 kW, 60 Hz

2-183

Tactical Airfield Fuel Dispensing System (TAFDS)

2-80

Tactical Petroleum Laboratory, Medium

2-83

Tactical Water Purification System (TWPS)

2-167

Tank Farm Interconnection Set

125 GPM Pump

2-141

350 GPM Pump

2-140

Accessory Kit

2-139

Dual Tank

2-133

Tank, Fabric, Collapsible, Potable Water, 20,000 Gallon

2-170

Tank, Fabric, Collapsible, Potable Water, 50,000 Gallon

2-169

Test Set, Soil

2-142

Index-6

TM 11275-15/3D

INDEX - Continued

Subject

Page

Three Shank, Rear Mounting Ripper Attachment

2-121

Tool Kit, IM, F/Tractor, Ft, W/Angle Blade

2-105

Tool Kit, Intermediate Level Electricians (L-Level Tool Kit)

2-176

Towing And Lifting Yoke

2-175

Tractor, Rubber-Tired, Articulated Steering, Multi-Purpose (TRAM)

2-33

Trailer-Mounted Hydroseeder

2-14

Tram Armored Cab

2-182

TWDS 5 Mile Hose Segment Kit

2-154

Water Six Container (SIXCON) Storage Tank Module

2-129

Winch Attachment, Single Drum

2-45

WQAS-P

2-168

Index-7/(Index-8 blank)

THE METRIC SYSTEM AND EQUIVALENTS

Linear Measure

Square Measure

1 Centimeter = 10 Millimeters = 0.01 Meters = 0.3937 Inches

1 Sq Centimeter = 100 Sq Millimeters = 0.155 Sq Inches

1 Meter = 100 Centimeters = 1000 Millimeters = 39.37 Inches

1 Sq Meter = 10,000 Sq Centimeters = 10.76 Sq Feet

1 Kilometer = 1000 Meters = 0.621 Miles

1 Sq Kilometer = 1,000,000 Sq Meters = 0.0386 Sq Miles

Weights

Cubic Measure

1 Gram = 0.001 Kilograms = 1000 Milligrams = 0.035 Ounces

1 Cu Centimeter = 1,000 Cu Millimeters = 0.06 Cu Inches

1 Kilogram = 1000 Grams = 2.2 Pounds

1 Cu Meter = 1,000,000 Cu Centimeters = 35.31 Cu Feet

1 Metric Ton = 1000 Kilograms = 1 Megagram = 1.1 Short Tons

Temperature

Liquid Measure

5/9 (°F - 32) = °C

1 Milliliter = 0.001 Liters = 0.0338 Fluid Ounces

212° Fahrenheit is equivalent to 100° Celsius

1 Liter = 1000 Milliliters = 33.82 Fluid Ounces

90° Fahrenheit is equivalent to 32.2° Celsius

32° Fahrenheit is equivalent to 0° Celsius

9/5 C° +32 = F°

APPROXIMATE CONVERSION FACTORS

To Change

Multiply By

To Change

Multiply By

Inches

Centimeters

2.540

Centimeters

Inches

0.394

Feet

Meters

0.305

Meters

Feet

3.280

Yards

Meters

0.914

Meters

Yards

1.094

Miles

Kilometers

1.609

Kilometers

Miles

0.621

Sq Inches

Sq Centimeters

6.451

Sq Centimeters

Sq Inches

0.155

Sq Feet

Sq Meters

0.093

Sq Meters

Sq Feet

10.764

Sq Yards

Sq Meters

0.836

Sq Meters

Sq Yards

1.196

Sq Miles

Sq Kilometers

2.590

Sq Kilometers

Sq Miles

0.386

Acres

Sq Hectometers

0.405

Sq Hectometers

Acres

2.471

Cubic Feet

Cubic Meters

0.028

Cubic Meters

Cubic Feet

35.315

Cubic Yards

Cubic Meters

0.765

Cubic Meters

Cubic Yards

1.308

Fluid Ounces

Milliliters

29.573

Milliliters

Fluid Ounces

0.034

Pints

Liters

0.473

Liters

Pints

2.113

Quarts

Liters

0.946

Liters

Quarts

1.057

Gallons

Liters

3.785

Liters

Gallons

0.264

Ounces

Grams

28.349

Grams

Ounces

0.035

Pounds

Kilograms

0.454

Kilograms

Pounds

2.205

Short Tons

Metric Tons

0.907

Metric Tons

Short Tons

1.102

Pound-Feet

Newton-Meters

1.356

Newton-Meters

Pound-Feet

0.738

Pounds per Sq

Kilopascals

6.895

Kilopascals

Pounds per Sq

0.145

Inch

Miles per Gallon

Kilometers per Liter

0.425

Kilometers per Liter

Miles per Gallon

2.354

Miles per Hour

Kilometers per Hour

1.609

Kilometers per Hour

Miles per Hour

0.621

TM 8000-10/1D

U.S. MARINE CORPS TECHNICAL MANUAL

PRINCIPAL TECHNICAL CHARACTERISTICS

U.S. MARINE CORPS

ORDNANCE EQUIPMENT

MARINE CORPS SYSTEM COMMAND

QUANTICO, VA 22134-6050

DISTRIBUTION STATEMENT: DISTRIBUTION AUTHORIZED TO U.S. GOVERNMENT AGENCIES AND THEIR

CONTRACTORS. THIS PUBLICATION IS REQUIRED FOR ADMINISTRATION AND OPERATIONAL PURPOSES.

OTHER REQUESTS FOR THIS DOCUMENT MUST BE REFERRED TO COMMANDER, MARINE CORPS SYSTEMS

COMMAND (PG-13 PM IW), QUANTICO, VA 22134-6050.

DESTRUCTION NOTICE: DESTROY BY ANY METHOD THAT WILL PREVENT DISCLOSURE OF CONTENTS OR

RECONSTRUCTION OF THE DOCUMENTS.

FOR OFFICIAL USE ONLY

APRIL 2010

PCN 180 002400 00

DEPARTMENT OF THE NAVY

Headquarters, U.S. Marine Corps

Washington, DC 20380-0001

30 April 2010

1. This Technical Manual (TM), authenticated for Marine Corps use and effective upon receipt, provides

the Principal Technical Characteristics of U.S. Marine Corps Ordnance Equipment.

2. Submit notice of discrepancies or suggested changes on a NAVMC 10772. The NAVMC may be

submitted via the Internet using website https://pubs.ala.usmc.mil/front.htm , scrolling down to the

NAVMC 10772 Tracking Program and following instructions provided. It may also be submitted by

electronic mail to smb.log.tech.pubs.fct@usmc.mil or by mailing paper copy NAVMC 10772 in an

envelope addressed to Commander, Marine Corps Systems Command, Attn: Assistant Commander

Acquisition and Logistics (LOG/TP), 814 Radford Blvd, Suite 20343, Albany, Georgia 31704-0343.

3. TM 8000-10/1C, dated December 1993, is hereby superseded for Marine Corps use.

BY DIRECTION OF THE COMMANDANT OF THE MARINE CORPS

OFFICIAL:

MARK T. BRINKMAN

Program Manager, IW, PG-13

Marine Corps Systems Command

DISTRIBUTION: EDO

TM 8000-10/1D

TECHNICAL MANUAL

MARINE CORPS SYSTEMS COMMAND

TM 8000-10/1D

Quantico, VA, April 2010

U.S. MARINE CORPS TECHNICAL MANUAL

PRINCIPAL TECHNICAL CHARACTERISTICS

OF U.S. MARINE CORPS

ORDNANCE EQUIPMENT

DISTRIBUTION STATEMENT: DISTRIBUTION AUTHORIZED TO U.S. GOVERNMENT AGENCIES AND THEIR

CONTRACTORS. THIS PUBLICATION IS REQUIRED FOR ADMINISTRATION AND OPERATIONAL PURPOSES.

OTHER REQUESTS FOR THIS DOCUMENT MUST BE REFERRED TO COMMANDER, MARINE CORPS SYSTEMS

COMMAND (PG-13 PM IW), QUANTICO, VA 22134-6050.

DESTRUCTION NOTICE: DESTROY BY ANY METHOD THAT WILL PREVENT DISCLOSURE OF CONTENTS OR

RECONSTRUCTION OF THE DOCUMENTS.

Table of Contents

Page

Number

Introduction

Equipment Listing by Functional Category

List of Abbreviations/Acronyms

CHAPTER 1 INFANTRY WEAPONS

Carbine, 5.56 mm, M4

1-1

Carbine, 5.56 mm, M4A1 Close Quarters Battle Weapon (CQBW)

1-3

Guided Missile System, TOW 2 Weapon System, M220E4

1-5

Launcher System, Saber, M41 (ITAS)

1-7

Javelin Weapons System, Command Launch Unit (CLU), M98A1

1-9

Launcher, Assault, Rocket, 83 mm (SMAW), MK 153

1-10

Launcher, Grenade, 40 mm, M203

1-12

Launcher, Grenade, 40 mm, M203A1

1-13

Launcher, Grenade, Multi-Shot, 40 mm, M32

1-14

Machine Gun, 7.62 mm, M240

1-15

Machine Gun, 7.62 mm, M240E1

1-16

Machine Gun, 7.6 mm, M240B

1-17

Machine Gun, 40 mm, MK 19 w/BKT

1-18

Machine Gun, Caliber .50, Browning, M2, Heavy Barrel, Flexible

1-19

Machine Gun, Caliber .50, M2, Heavy Barrel, Flexible, M48 Turret Type

1-20

TM 8000-10/1D

Table of Contents - Continued

Page

Number

Machine Gun, Light, Squad, 5.56 mm, M249

1-21

Mortar, 60 mm, Lightweight, Company, M224

1-22

Mortar, Medium, Extended Range, 81 mm, M252

1-23

Mount, Machine Gun, MK64 MOD 5

1-24

Mount, Vehicle, Medium Machine Gun, M35 (MMGVM)

1-25

Mount, Machine Gun, MK93

1-27

Mount, Tripod, Machine Gun, 7.62 mm, M122

1-28

Mount, Tripod, Machine Gun, Caliber .50, M3

1-29

Pistol, M45 Close Quarters Battle Pistol (CQBP) .45 Caliber

1-30

Pistol, Semi-Automatic, 9 mm, M9 and M9A1

1-31

Rifle, 7.62 mm, M14, Enhanced Marksman Rifle (EMR)

1-32

Rifle, 5.56 mm, M16A2

1-33

Rifle, 5.56 mm, M16A4

1-34

Rifle, Scoped, Long Range, .50 Caliber, M107

1-35

Rifle, Sniper, 7.62 mm, M40A3/A5

1-36

Shotgun, 12 Gage, M1014, Joint Service Combat Shotgun (JSCS)

1-37

Shotgun, 12 Gage, Mossberg 500A2

1-38

CHAPTER 2 TOWED ARTILLERY WEAPONS

Howitzer, Medium, Towed, 155 mm, M198

2-1

Howitzer, M777A2

2-3

CHAPTER 3 TRACKED AND WHEELED COMBAT VEHICLES

Assault Amphibian Vehicle, Personnel Carrier (AAVP7A1)

3-1

Assault Amphibian Vehicle, Personnel Carrier, Model 7A1, (AAVP7A1),

Upgunned Weapons Station (UGWS)

3-3

Assault Amphibian Vehicle, Command (AAVC7A1)

3-5

Assault Amphibian Vehicle, Recovery (AAVR7A1)

3-8

Blade, Mine Clearing, M1A1

3-12

Bridge, Armored Vehicle Launched

3-13

Gun, Automatic, 25 mm, M242

3-14

M142 High Mobility Artillery Rocket System (HIMARS)

3-15

Light Armored Vehicle (LAV) - Anti-Tank (LAV-AT)

3-17

Light Armored Vehicle (LAV) - Command and Control (LAV-C²A1)

3-18

Light Armored Vehicle (LAV) - Light Assault (LAV-25A1)

3-19

Light Armored Vehicle (LAV) - Logistics (LAV-L)

3-20

Light Armored Vehicle (LAV) - Maintenance/Recovery (LAV-RA1)

3-21

Light Armored Vehicle (LAV) - Mortar (LAV-M)

3-22

Recovery Vehicle, Heavy, Full-Tracked, M88A2

3-23

Tank, Combat, Full-Tracked, 120 mm Gun, M1A1

3-25

TM 8000-10/1D

Table of Contents - Continued

Page

Number

CHAPTER 4 OPTICAL AND MISCELLANEOUS EQUIPMENT

Mini Thermal Imager (MTI)

4-1

Weapon Thermal Sight, AN/PAS-13B, (V)2 Medium (MWTS)

and AN/PAS-13B, (V)3 Heavy (HWTS)

4-2

Weapon Thermal Sight, AN/PAS-13D, (V)2 Medium (MWTS)

and AN/PAS-13D, (V)3 Heavy (HWTS)

4-3

Laser Borelight System (LBS), AN/PEM-1

4-4

Target Pointer Illuminator/Aiming Light (TPIAL), AN/PEQ-2A

4-5

Medium Power Laser Illuminator (MPLI), AN/PEQ-4

4-6

Light Module, Integrated Laser (ILLM), AN/PEQ-6A

4-7

Grenade Launcher Day Night Sight Mount (GLDNSM), AN/PSQ-18A

4-8

Night Vision Goggles, Individual, AN/PVS-7B and -7D

4-9

Monocular Night Vision Device (MNVD), AN/PVS-14

4-10

Sight, Miniature Night (MNS), AN/PVS-17B and -17C

4-11

Sight, Night Vision, Crew-Served, AN/TVS-5A

4-12

Eotech Holographic Diffraction Sight (HDS)

4-13

Laser Boresight System (LBS)

4-14

Scout Sniper Periscope (SSP)

4-15

AN/PAS-22 Long-Range Thermal Imager (LRTI)

4-16

M49 Telescope, Straight

4-17

Rifle Combat Optics (RCO), AN/PVQ-31A (A4) and AN/PVQ-31B (M4)

4-18

Scout Sniper Day Scope (SSDS)

4-19

Visible Light Illuminator Replacement (VLIR), AN/PVS-29

4-20

Infrared Zoom Laser Illuminator Designator (IZLID) 1000P-A1

4-21

Non-Lethal Visual Hailing Device (GBD-IIIC), LA-9/P

4-22

AN/PEQ-15 Advanced Target Pointer Illuminator Aiming Light (ATPIAL)

4-23

AN/PEQ-16 Integrated Pointer/Illuminator Module (IPIM)

4-24

AN/PVS-27 Scout Sniper Medium Range Night Sight (SSMRNS)

4-25

Electro-Optical Maintenance Shelter Complex (EOMSC)

4-26

Medium Range Thermal Bi-Ocular (MRTB)

4-28

Individual Weapon Night Sight-Thermal (IWNS-T), AN/PAS-27

4-29

AN/PVS-21 Low Profile Night Vision Goggles (LP-NVG)

4-30

AN/PVS-24A Individual Weapon Night Sight I² (IWNS-I²)

4-31

AN/PEQ-16A Mini-Integrated Pointer/Illuminator Module (MIPIM)

4-32

AN/PEQ-14 Integrated Laser White Light Pointer (ILWLP)

4-33

Scout Sniper Observation Telescope (SSOT)

4-34

Sound Commander 3600 (SC3600)

4-35

Non-Lethal/Tube Launched Munition System (NL/TLMS)

4-36

Mission Payload Module - Non-Lethal Weapons Systems

4-37

Nitrogen Generator

4-38

Shop Equipment Contact Maintenance Vehicle (SECMV)

4-39

iii

TM 8000-10/1D

Table of Contents - Continued

Page

Number

Tool Kit, Electro-Optical (EOTK)

4-40

Infantry Binoculars - Tactical Cots

4-41

SU-260P Machine Gun Day Optic (MDO)

4-42

SU-258/PVQ Squad Day Optic (SDO)

4-43

CHAPTER 5 ANCILLARY EQUIPMENT

Compass, Magnetic, M2

5-1

Quadrant, Fire Control, Gunner’s, M1A2

5-2

Sight, Bore, Optical, M45/M45A1

5-3

Sight Unit, M64A1

5-4

CHAPTER 6 EQUIPMENT LISTING BY TAM-NUMBER SEQUENCE

Equipment Listing by TAM-Number Sequence

6-1

CHAPTER 7 GLOSSARY

Glossary

7-1

Index

Index-1

TM 8000-10/1D

INTRODUCTION

1-1.

SCOPE

This manual provides easy-to-use reference data for the more common items of Marine Corps ordnance

equipment. The equipment description sheets, which make up the bulk of the manual, provide a description,

function, and technical characteristics of the equipment, including, when applicable, fuel and power requirements,

power outputs, major components, and associated components. If available, photographs or drawings of the

equipment are provided. For complete data on any item, refer to the appropriate technical manual or Stock List

(SL-3 or SL-4). Stock Lists can be accessed on the internet through the MATCOM website

http://mcsd4.ala.usmc.mil/MCSD/SL/. For additional assistance contact Action Officer at PG 13, PM IW,

phone number: 703-432-4942.

1-2.

CONTENTS OF THIS MANUAL

a. Introduction. Contains general information about the publication and its use.

b. Equipment Description Sheets. Equipment description sheets provide key characteristics of the

equipment and include illustrations or drawings as appropriate. Some equipment items have multiple operating

configurations. Those are marked as “varies” under Operating Data.

c. Equipment Listing by Functional Category. The equipment is listed by groupings of functionally

similar items of equipment.

d. Equipment Listing by TAM-Number Sequence. This section is a listing arranged in alphanumeric

TAMCN sequence of each functional category. The listing provides Table of Authorized Materiel Control Number

(TAMCN), equipment Item Designator (ID) number, National Stock Number (NSN), item description, model

number, and a page number reference to the equipment description sheets. It should be noted that some TAMCN

are common to more than one piece of equipment.

1-3.

LOCATING EQUIPMENT DATA

Equipment data may be located by either TAMCN or by Functional Category.

Functional Category. If the functional category is known, e.g., floodlight, find the functional

category, then refer to the desired sublist item. If more detailed information is required than is presented, refer to

the appropriate page in the equipment description sheets section.

TAMCN. If the TAMCN is known, refer to the alphanumeric listing in the Equipment Listing by

TAM-number sequence to find the equipment. If more detailed information is required than is presented, refer to

the appropriate page in the equipment description sheets.

1-4.

EQUIPMENT DESCRIPTION SHEET FORMAT

Each end item is given a separate page. Data provided are self-explanatory.

a/(b blank)

TM 8000-10/1D

EQUIPMENT LISTING BY FUNCTIONAL CATEGORY

TAMCN

ITEM DESCRIPTION

MODEL

INFANTRY WEAPONS

E01957M

Carbine, 5.56 mm, M4

E01907M

Carbine, 5.56 mm, M4A1 Close Quarters Battle Weapon (CQBW)

M4A1 CQBW

E09357B

Guided Missile System, Tow 2 Weapon System

M220E4

E02077B

Javelin Weapons System, Command Launch Unit (CLU)

M98A1

E09157M

Launcher, Assault, Rocket, 83 mm (SMAW)

MK 153

E08927M

Launcher, Grenade, 40 mm

M203

E08927M

Launcher, Grenade, 40 mm

M203A1

E00252M

Launcher, Grenade, Multi-Shot, 40 mm

M32

E0055

Launcher System, Saber (ITAS)

M41

E09987M

Machine Gun, 7.62 mm

M240

E0961

Machine Gun, 7.62 mm

M240E1

E09897M

Machine Gun, 7.62 mm

M240B

E09947M

Machine Gun, 40 mm, MK 19 w/BKT

MOD 3

E09807M

Machine Gun, Caliber .50, Browning, M2, Heavy Barrel, Flexible

E0984

Machine Gun, Caliber .50, M2, Heavy Barrel, Flexible, M48 Turret Type

M2 - M48 Type

E09607M

Machine Gun, Light, Squad, 5.56 mm

M249

E10657M

Mortar, 60 mm, Lightweight, Company

M224

E10957M

Mortar, Medium, Extended Range, 81 mm

M252

E11232B

Mount, Machine Gun, MK93

MK93

E00817

Mount, Vehicle, Medium Machine Gun, M35 (MMGVM)

M35

E11232B

Mount, Machine Gun, MK64

MOD 5

E11202M

Mount, Tripod, Machine Gun, 7.62 mm

M122

E11262B

Mount, Tripod, Machine Gun, Caliber .50

E12512M

Pistol, M45 Close Quarters Battle Pistol (CQBP) .45 Caliber

M1911A1

E12502M

Pistol, Semi-Automatic, 9 mm

M9 and M9A1

E12452M

E03117M

Rifle, 7.62 mm, M14, Enhanced Marksman Rifle (EMR)

EMR

E14412M

Rifle, 5.56 mm, M16A2

M16A2

E14412M

Rifle, 5.56 mm, M16A4

M16A4

E14752M

Rifle, Scoped, Long Range, Caliber .50

M107

E14602M

Rifle, Sniper, 7.62 mm

M40A3/A5

E17612M

Shotgun, 12 Gage, M1014, Joint Service Combat Shotgun (JSCS)

M1014

E17622M

Shotgun, 12 Gage, Mossberg

500A2

TOWED ARTILLERY WEAPONS

E06657M

Howitzer, Medium, Towed, 155 mm

M198

E06717M

Howitzer

M777A2

TM 8000-10/1D

EQUIPMENT LISTING BY FUNCTIONAL CATEGORY - CONTINUED

TAMCN

ITEM DESCRIPTION

MODEL

TRACKED AND WHEELED COMBAT VEHICLES

E08467K

Assault Amphibian Vehicle, Personnel Carrier

AAVP7A1

E3201

Assault Amphibian Vehicle, Personnel Carrier, Model 7A1, Upgunned

AAVP7A1 UGWS

Weapons Station (UGWS)

E07967K

Assault Amphibian Vehicle, Command

AAVC7A1

E08567K

Assault Amphibian Vehicle, Recovery

AAVR7A1

E09967M

Blade, Mine Clearing

M1A1

E01507B

Bridge, Armored Vehicle Launched

E0947

Gun, Automatic, 25 mm

M242

E1500

M142 High Mobility Artillery Rocket System (HIMARS)

M142

E09427M

Light Armored Vehicle (LAV) - Anti-Tank

LAV-AT

E09467B

Light Armored Vehicle (LAV) - Command and Control

LAV-C²A1

E09477M

Light Armored Vehicle (LAV) - Light Assault

LAV-25A1

E09487B

Light Armored Vehicle (LAV) - Logistics

LAV-L

E09507B

Light Armored Vehicle (LAV) - Maintenance/Recovery

LAV-RA1

E09497M

Light Armored Vehicle (LAV) - Mortar

LAV-M

E13787K

Recovery Vehicle, Heavy, Full-Tracked

M88A2

E18887M

Tank, Combat, Full-Tracked, 120 mm Gun

M1A1

OPTICAL AND MISCELLANEOUS EQUIPMENT

E00637G

Mini Thermal Imager (MTI)

E19757G

Weapon Thermal Sight, Medium (MWTS) and HEAVY (HWTS)

AN/PAS-13B (V)2

AN/PAS-13B (V)3

E19767G

E1975

Weapon Thermal Sight, Medium (MWTS) and HEAVY (HWTS)

AN/PAS-13D (V)2

AN/PAS-13D (V)3

E1976

E09567B

Laser Borelight System (LBS)

AN/PEM-1

E17987G

Target Pointer Illuminator/Aiming Light (TPIAL)

AN/PEQ-2A

E17997G

Medium Power Laser Illuminator (MPLI)

AN/PEQ-4

E09577B

Light Module, Integrated Laser (ILLM)

AN/PEQ-6A

E17797B

Grenade Launcher Day Night Sight Mount (GLDNSM)

AN/PSQ-18A

E11522B

Night Vision Goggles, Individual

AN/PVS-7B and 7D

E11522BA

E11542B

Monocular Night Vision Device (MNVD)

AN/PVS-14

E11627G

Sight, Miniature Night (MNS)

AN/PVS-17B and

17C

E11607G

E11592B

Sight, Night Vision, Crew-Served

AN/TVS-5A

N/A

EOTECH Holographic Diffraction Sight (HDS)

E09567B

Laser Boresight System (LBS)

AN/PEM-1

E00957B

Scout Sniper Periscope (SSP)

TM 8000-10/1D

EQUIPMENT LISTING BY FUNCTIONAL CATEGORY - CONTINUED

TAMCN

ITEM DESCRIPTION

MODEL

OPTICAL AND MISCELLANEOUS EQUIPMENT - Continued

E19787G

Long-Range Thermal Imager (LRTI) AN/PAS-22

AN/PAS-22

E19007B

M49 Telescope, Straight

M49

E17107G (A4)

Rifle Combat Optics (RCO), AN/PVQ-31A (A4) and AN/PVQ-31B (M4)

AN/PVQ-31A

AV/PVQ-31B

E00177M (M4)

N/A

Scout Sniper Day Scope (SSDS)

E00387B

Visible Light Illuminator Replacement (VLIR)

AN/PVS-29

E00067B

Infrared Zoom Laser Illuminator Designator (IZLID)

1000P-A1

E00537B

Non-Lethal Visual Hailing Device, LA-9/P

GBD-IIIC

E17987G

Advanced Target Pointer Illuminator Aiming Light (ATPIAL)

AN/PEQ-15

E00587G

Integrated Pointer/Illuminator Module (IPIM)

AN/PEQ-16

E00207B

Scout Sniper Medium Range Night Sight (SSMRNS)

AN/PVS-27

E00677B

Electro-Optical Maintenance Shelter Complex (EOMSC)

E00127G

Medium Range Thermal Bi-Ocular (MRTB)

E00627G

Individual Weapon Night Sight-Thermal (IWNS-T)

AN/PAS-27

E00617B

Low Profile Night Vision Goggles (LP-NVG)

AN/PVS-21

E00087G

Individual Weapon Night Sight I² (IWNS-I²)

AN/PVS-24

E00587G

Mini-Integrated Pointer/Illuminator Module (MIPIM)

AN/PEQ-16A

E09577B

Integrated Laser White Light Pointer (ILWLP)

AN/PEQ-14

E00167B

Scout Sniper Observation Telescope (SSOT)

A02507G

Sound Commander 3660

SC3600

C00247B

Non-Lethal/Tube Launched Munition System (NL/TLMS)

E00327M

Mission Payload Module - Non-Lethal Weapons Systems

E00807B

Nitrogen Generator

N2-GEN™

C70077B

Shop Equipment Contact Maintenance Vehicle (SECMV)

E22082B

Tool Kit, Electro-Optical (EOTK)

E00847B

Infantry Binoculars - Tactical COTS

E00887B

SU-260P Machine Gun Day Optic (MDO)

E00827B

SU-258/PVQ Squad Day Optic (SDO)

ANCILLARY EQUIPMENT

E02102E

Compass, Magnetic

E12607B

Quadrant, Fire Control, Gunner's

M1A2

E17802E

Sight, Bore, Optical

M45/M45A1

TBD

Sight, Unit

M64A1

e/(f Blank)

TM 8000-10/1D

LIST OF ABBREVIATIONS/ACRONYMS

Abbreviation/Acronym

Definition

approx

Approximately

APU

Auxiliary Power Unit

BAD

Blast Attenuator Device

Celsius; Centigrade

CFM

Cubic Feet per Minute

Centimeter

cu ft

Cubic Feet

cu m

Cubic Meters

Direct Current

deg

Degrees

dia

Diameter

elev

Elevation

Fahrenheit

ft/sec

Feet per Second

Feet

ft-Ib

Foot-Pound

ft³

Cubic Feet

Gram

gal

Gallon

gpm

Gallons per Minute

Grains

HEDP

High-Explosive, Dual Purpose

Identification Number

Inch

in.-lb

Inch-Pound

Incl

Including

Joules

Kilogram

Kilopascal

Kilowatt

Liter

LAV

Light Armored Vehicle

Pound

Meter

m-ton

Metric Ton

m³

Cubic Meters

mag

Magazine

Max

Maximum

Millimeter

mps

Meters per Second

TM 8000-10/1D

LIST OF ABBREVIATIONS/ACRONYMS - CONTINUED

Abbreviation/Acronym

Definition

NATO

North Atlantic Treaty Organization

Newton meters

NSN

National Stock Number

Ounce

PSI

Pounds per Square Inch

PSIG

Pounds per Square Inch, Gage

pwr

Power

Quart

R.H

Right Hand

Rounds/min

Rounds per Minute

RPM

Revolutions per Minute

sec

Second

sq ft

Square Feet

TAM

Table of Authorized Materiels

Technical Manual

VDC

Volts Direct Current

With

w/o

Without

W/E

With Equipment

Yard

TM 8000-10/1D

CARBINE, 5.56 MM, M4

TAMCN E01957M

NSN 1005-01-231-0973

ID 10012A

TM8K-001

DESCRIPTION AND FUNCTION

Carbine, 5.56 mm, M4 is a lightweight, air-cooled, gas-operated, magazine-fed, shoulder-fired weapon

designed for burst (three-round burst) or semi-automatic (single shots) fire by using the selector lever. The

weapon has a fully adjustable rear sight and is configured with a flat-top upper receiver and barrel assembly with

a detachable carrying handle, integral rear aperture sight, and a compensator that keeps the muzzle down during

firing. The M4 Carbine’s buttstock has four positions: closed, 1/2 open, 3/4 open, and full open.

TECHNICAL CHARACTERISTICS

Weight:

Rate of Fire:

w/o Mag and Sling

6.25 lb (2.33 kg)

Maximum

Approx 700 to 900 RPM

Loaded 30-rd Mag and Sling

7.5 lb (2.8 kg)

Semi

45 RPM

Length:

Burst

90 RPM

Buttstock Closed

29.75 in. (75.57 cm)

Sustained

12 to 15 RPM

Buttstock Opened

33.0 in. (84 cm)

Max Effective Range

1,640 ft (500 m)

Fire Selector

SAFE-SEMI-BURST

(individual/pt targets)

Muzzle Velocity (Max)

2,970 ft/sec

1,968 ft (600 m)

(area targets)

MAJOR COMPONENTS

Qty

Item

Qty

Item

Bolt Carrier Assembly

Upper Receiver and Barrel Assembly

Carrying Handle

Lower Receiver and Buttstock Assembly

1-1

TM 8000-10/1D

CARBINE, 5.56 MM, M4 - CONTINUED

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

E0892

07700B

Launcher, Grenade, 40 mm, M203A1

N/A

10090A

Thermal Sight

AN/PVS-13(V)1

N/A

11059A

Holographic Sight

552.65A

N/A

8I015B

Conversion Kit

5304650

E00502E

05576C

OKC3S Bayonet

E00177M

11064B

AN/PVQ-13B (M4/M4A1)

E00627G

TBD

IWNS-T

E11542B

10271A

AN/PVS-14 (MNVD)

E11607G

10796C

AN/PVS-17C (MNS)

E11587G

05975D

AN/PVS-4*

E00087G

TBD

AN/PVS-24

N60305EP

10012B

VLI

E00387B

11452A

VLI Replacement**

The AN/PVS-4 is being replaced by the AN/PVS-17.

The 11452A is replacing the 10012B.

REFERENCES

• TM 05538/10012-10A/1; Operator’s Manual, Rifles 5.56 mm, M16A2, M16A4, and Carbines 5.56 mm, M4,

and M4A1.

• TM 05538/10012-23&P; Maintenance Manual, Rifles 5.56 mm, M16A2, M16A3, M16A4, and Carbines

5.56 mm, M4 and M4A1.

1-2

TM 8000-10/1D

CARBINE, 5.56 MM, M4A1 CLOSE QUARTERS BATTLE WEAPON (CQBW)

TAMCN E01907M

NSN 1005-01-382-0953

ID 10012B

TM8K-002

DESCRIPTION AND FUNCTION

Carbine, 5.56 mm, M4A1 is a lightweight, air-cooled, gas-operated, magazine-fed, shoulder-fired weapon

designed for automatic or semi-automatic (single shots) fire by using the selector lever. The weapon has a fully

adjustable rear sight and is configured with a flat-top upper receiver and barrel assembly with a detachable carry-

ing handle, integral rear aperture sight, and a modified compensator that allows attachment of a sound suppres-

sor. The M4A1 Carbine’s buttstock has four positions: closed, 1/2 open, 3/4 open, and full open.

TECHNICAL CHARACTERISTICS

Weight:

Rate of Fire:

w/o Mag and Sling

6.25 lb (2.33 kg)

Maximum

Approx 700 to 900 RPM

Loaded 30-rd Mag and Sling

7.5 lb (2.88 kg)

Semi

45 RPM

Length:

Burst

90 RPM

Buttstock Closed

29.75 in. (75.57 cm)

Sustained

12 to 15 RPM

Buttstock Opened

33.0 in. (84 cm)

Max Effective Range

1,640 ft (500 m)

Fire Selector

SAFE-SEMI-AUTO

(individual/pt targets)

Muzzle Velocity (Max)

2,970 ft/sec

1,968 ft (600 m)

(area targets)

MAJOR COMPONENTS

Qty

Item

Qty

Item

Bolt Carrier Assembly

Upper Receiver and Barrel Assembly

Carrying Handle

Lower Receiver and Buttstock Assembly

1-3

TM 8000-10/1D

CARBINE, 5.56 MM, M4A1 CLOSE QUARTERS BATTLE WEAPON (CQBW) - CONTINUED

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

E0892

07700B

Launcher, Grenade, 40 mm, M203A1

E00502E

05576C

OKC3S Bayonet Suppressor MK3

E00177M

11064B

AN/PVQ-13B (RCO M4/M4A1)

E00627G

TBD

IWNS-T

E11542B

10271A

AN/PVS-14 (MNVD)

E11607G

10796C

AN/PVS-17C (MNS)

E11587G

05975D

AN/PVS-4*

E00087G

TBD

AN/PVS-24

N60302EP

10012B

VLI

E00387B

11452A

VLI Replacement**

The AN/PVS-4 is being replaced by the AN/PVS-17.

The 11452A is replacing the 10012B.

REFERENCES

• TM 05538/10012-10A/1; Operator’s Manual, Rifles 5.56 mm, M16A2, M16A4, and Carbines 5.56 mm,

M4, and M4A1.

• TM 05538/10012-23&P; Maintenance Manual, Rifles 5.56 mm, M16A2, M16A3, M16A4, and Carbines

5.56 mm, M4 and M4A1.

1-4

TM 8000-10/1D

GUIDED MISSILE SYSTEM, TOW 2 WEAPON SYSTEM, M220E4

TAMCM E09357B

NSN 1440-01-104-9834

ID 07722B

TM8K-003

DESCRIPTION AND FUNCTION

Guided Missile System, TOW 2 Weapon System, M220E4 is a portable wire guided, heavy anti-tank

weapon designed to defeat armored vehicles and other hardened targets, such as field fortifications. It operates

day or night under all weather conditions and provides a high first-round hit capability against mobile and station-

ary targets. The TOW 2 can be mounted on the M998 Series 1-1/4 ton, 4x4 HMMWV, M1045, and M1046.

TECHNICAL CHARACTERISTICS

Weight

550 lb (250 kg)

Volume

60.0 cu ft (1.7 cu m)

Length

75.0 in. (190.5 cm)

Width

40.5 in. (102.9 cm)

Height

34.0 in. (86.6 cm)

MAJOR COMPONENTS

Qty

Item

Qty

Item

Encased Missile

Night Sight

Day Sight Tracker

Launch Tube

Traversing Unit

Power Conditioner

Tripod

Battery Assembly

Missile Guidance Set

1-5

TM 8000-10/1D

GUIDED MISSILE SYSTEM, TOW 2 WEAPON SYSTEM, M220E4 - CONTINUED

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

K46952E

00554C

Paper, Lens

NNNP40

N/A

85588B

Sight Subassembly

10085144

N/A

85591B

Tracker Assembly

10225748

N/A

85593B

Sensor Assembly

10192412

N/A

85595C

Damper, Azimuth

35560

N/A

85598B

Damper, Azimuth

10191248

N/A

85600D

Modulator, Assembly

13218350

N/A

87008B

Tube, TOW

11486778

N/A

87511B

Wire/Harness Branch

10085148

N/A

88903B

Circuit Card

13099805

N/A

89149B

Clamp Assembly

13195080

N/A

89151B

Wire/Harness Branch

13194973

N/A

8B866B

Cell Assembly, Optic

10192166

N/A

8B975C

Sight Optical LAU

13218329

N/A

8E503B

Miss/Guidance Set

13099890-0307

N/A

8E503C

Miss/Guidance Set

13099890-0408

REFERENCES

• TM 9-1425-450-12; Operator’s and Maintenance Manual, TOW 2 Weapon System Guided Missile System,

M220E4.

• See SL-1-2 for a complete listing of applicable publications.

1-6

TM 8000-10/1D

LAUNCHER SYSTEM, SABER, M41 (ITAS)

TAMCN E0055

NSN TBD

ID TBD

TM8K-118

DESCRIPTION AND FUNCTION

Guided missile launch system, Saber, M41 Improved Target Acquisition System (ITAS) is a portable, missile

launch system that is designed to fire all current and future TOW Missiles to defeat heavily armored vehicles and

field fortifications. It operates day or night under all weather conditions. Equipped with laser rangefinder, Far Tar-

get Locator (FTL), and digital zoom, it provides twice the target acquisition range, detection, and identification of

current systems with unmatched surveillance capability. It is equipped with automatic boresighting, Built In Test

(BIT), embedded training, and lithium ion battery. The system can also be the M998 Series 1-1/4 ton, 4x4,

HMMWV, M1045, and M1046.

TECHNICAL CHARACTERISTICS

Weight:

TBD

Volume:

TBD

Length:

TBD

Width:

TBD

Height:

TBD

MAJOR COMPONENTS

Qty

Item

Qty

Item

Encased Missile

Fire Control Subsystem (FCS)

Target Acquisition System (TAS)

Lithium Battery Box (LBB)

Traversing Unit (TU), Modified

Far Target Locator (FTL)

Launch Tube

Tripod

Commander’s Viewer Kit

Lithium Ion AC Charger

1-7

TM 8000-10/1D

LAUNCHER SYSTEM, SABER, M41 (ITAS) - CONTINUED

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

TBD

Vehicle Mounted Battery Charger

TBD

Vehicle Modification Kit

TBD

TOW Gunner Protection Kit (TGPK)

TBD

Electronic Circuit Resistance Test

TBD

Set (ECIRTS)

TBD

Missile Simulation Round - Anti-Tank

TBD

Weapon Effect Signature Simulator

(MSR ATWESS)

TBD

Basic Skills Trainer (BST)

TBD

Fault Simulation Cards

TBD

REFERENCES

• TBD

• See SL-1-2 for a complete listing of applicable publications.

1-8

TM 8000-10/1D

JAVELIN WEAPONS SYSTEM, COMMAND LAUNCH UNIT (CLU), M98A1

TAMCN E02077B

NSN 1430-01-478-5345

ID 09397B

TM8K-004

DESCRIPTION AND FUNCTION

Javelin, M98A1 is a medium-range, man-portable, recoilless, antitank assault weapon capable of defeating

current and projected enemy armor and hovering enemy helicopters. The Javelin can be used during the day or

night or during degraded weather conditions, including electronic and electro-optical countermeasures. The mis-

sile has a Top Attack and a Direct Attack mode to defeat enemy armor and hovering enemy helicopters.

TECHNICAL CHARACTERISTICS

CLU w/ Battery:

Effective Range, Top Attack Mode:

Weight

14.16 lb (5.3 kg)

Min

492 ft (150 m)

Length

13.71 in. (13.71 cm)

Max

6,562 ft (2,000 m)

Height

13.34 in. (33.89 cm)

Effective Range, Direct Attack Mode:

Width

19.65 in. (49.91 cm)

Min

213 ft (65 m)

Round:

Max

6,562 ft (2,000 m)

Weight

34.16 lb (12.75 kg)

Length

47.60 in. (120.90 cm)

Width

11.75 in. (29.85 cm)

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

Bag, Carry

Cleaning, Kit, Lens

Associated Component Identification Numbers

00554C

85600D

89151B

8F580B

8F630B

8F638B

8G222B

85588B

87008B

8B866B

8F616B

8F631B

8F657B

8G287B

85591B

87511B

8B975C

8F622B

8F632B

8F663B

8H081B

85593B

88900C

8E503B

8F623B

8F633B

8F688B

8H160B

85595C

88903B

8E503C

8F627B

8F634B

8G195B

8H362B

85598B

89149B

8F449B

8F628B

8F637B

8G210B

8H363B

8I912B

REFERENCES

• TM 09397B-12/1; Operator’s Manual, Javelin Weapons System.

• See SL-1-2 for a complete listing of applicable publications.

1-9

TM 8000-10/1D

LAUNCHER, ASSAULT, ROCKET, 83 MM (SMAW), MK 153

TAMCN E09157M

NSN 1055-01-164-4608

ID 08673A

TM8K-005

DESCRIPTION AND FUNCTION

Launcher, Assault, Rocket, 83 mm (SMAW), MK153 is a man-portable assault weapon employed at the rifle

company level. It is capable of defeating field fortifications (bunkers), urban structures (concrete/masonry), and

has a secondary capability of destroying light armor. It employs a dual-mode warhead, which automatically dis-

criminates between relatively soft targets (earth/logs/sandbags) and hard targets (concrete/masonry/light armor),

functioning in the delay mode against soft targets and in the immediate detonation mode against hard targets.

TECHNICAL CHARACTERISTICS

Operating Temp Range

-40ºF to +140ºF

Effective Range:

(-40ºC to +60ºC)

Min

55.8 ft (17 m)

Weight (Approx)

29.34 lb (13.3 kg)

Max

820 ft (250 m)

Length (Approx)

54 in. (1.36 m)

MAJOR COMPONENTS

Qty

Item

Qty

Item

Front Open Sight

Sighting Rifle

Rear Open Sight

Bipod

Launcher Tube

Front Pistol Grip

Carrying Sling

Shoulder Rest

Sight Mount

Firing Mechanism

Telescopic Sight

Round

1-10

TM 8000-10/1D

LAUNCHER, ASSAULT, ROCKET, 83 MM (SMAW), MK 153 - CONTINUED

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

E11627G (17B)

10796B

Sight, Night Vision, AN/PVS-17B and 17C

E11607G (17C)

10796C

K47425F

07798A

Rag, Wiping, 5 lb.

A-A-222

E20702E

08969A

TK Boresight

MK145MOD0

C43102F

08951A

Carrier BKPK

82A5027A300

N/A

09576A

Mod Kit

82A5027A6430

N/A

8A538B

Telescope

82A5027A1500

N/A

8C544B

Tube, Assembly

82A5027A6100

N/A

8C544C

Tube, Assembly

82A5027A6101

N/A

8E094B

Subassembly Tube

82A5027A5133

N/A

8H373B

Firing Assembly

82A5027A1200

N/A

8H621B

Generator, Firing

82A5027A1210

N/A

8I145B

Trainer, Assembly/Rocket

82A5027A4000

N/A

8I287B

Rifle, Assembly

82A5027A5132

N/A

8I338B

Rifle, Spotting

82A5027A5200

REFERENCES

• TM 08673A-10/1B; Operator’s Manual, Launcher, Assault, Rocket, 83 mm (SMAW).

• TM 08673A-25&P/2A; Maintenance Manual, Launcher, Assault, Rocket, 83 mm (SMAW).

• See SL-1-2 for a complete listing of applicable publications.

1-11

TM 8000-10/1D

LAUNCHER, GRENADE, 40 MM, M203

TAMCN E08927M

NSN 1010-00-179-6447

ID 07700A

M203

TM8K-006

DESCRIPTION AND FUNCTION

Launcher, Grenade, 40 mm, M203 is used while attached to a M16A2 rifle. It is a lightweight, compact,

breech-loading, pump-action, single-shot launcher. The launcher consists of a hand guard and sight assembly

with an adjustable metallic folding blade; sight assembly; plastic handguard; and receiver assembly housing the

barrel latch, barrel stop, and firing mechanism. The launcher is capable of firing a variety of 40 mm ammunition.

TECHNICAL CHARACTERISTICS

Weight

3 lb (1.4 kg)

Length of Rifling

10 in. (25.4 cm)

Length of Barrel

12 in. (30.5 cm)

Maximum Range

400 m (1,320 ft)

Number of Lands

MAJOR COMPONENTS

Qty

Item

Qty

Item

Leaf Sight Assembly

Barrel Assembly

Hand Guard Assembly

Receiver Assembly

Quadrant Sight Assembly

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

E14412M

05538C

Rifle, 5.56 mm, M16A2

N/A

10090A

Thermal Sight

AN/PVS-13 (V)1

E17797B

11065A

Day/Night Sight

AN/PSQ-18A

E09567B

10471A

Laser Borelight

LBS

REFERENCES

• TM 07700A-10/1A; Operator’s Manual, Launcher, Grenade, 40 mm, M203 and M203A1.

• TM 07700A-23&P/2; Maintenance Manual, Launcher, Grenade, 40 mm, M203 and M203A1, W/E.

• See SL-1-2 for a complete listing of applicable publications.

1-12

TM 8000-10/1D

LAUNCHER, GRENADE, 40 MM, M203A1

TAMCN E08927M

NSN 1010-01-434-9028

ID 07700B

M203A1

TM8K-007

DESCRIPTION AND FUNCTION

Launcher, Grenade, 40 mm, M203A1 is used while attached to the M4, 5.56 mm Carbine Series. It is a light-

weight, compact, breech-loading, pump-action, single-shot launcher that is functionally identical to the M203. It

uses the quick release bracket and is equipped with the M5 adapter rail system.

TECHNICAL CHARACTERISTICS

Weight

3 lb

Max Range

1,312 ft (400 m)

Length of Barrel

12 in.

Minimum Safe Distance:

Max Effective Range:

1,148 ft (350 m)

Combat Situation

101 ft (31 m)

(area target)

Training Situation

541 ft (165 m)

492 ft (150 m)

(point target)

MAJOR COMPONENTS

Qty

Item

Qty

Item

Leaf Sight Assembly

Barrel Assembly

Hand Guard Assembly

Receiver Assembly

Quadrant Sight Assembly

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

E01957M

10012A

Carbine, 5.56 mm

E01907M

10012B

Carbine, 5.56 mm

M4A1 CQBW

N/A

10090A

Thermal Sight

AN/PVS-13(V)1

E17797B

11065A

Day/Night Sight

AN/PSQ-18A

E09567B

10471A

Laser Borelight

LBS

REFERENCES

• TM 07700A-10/1A; Operator’s Manual, Launcher, Grenade, 40 mm, M203 and M203A1.

• TM 07700A-23&P/2; Maintenance Manual, Launcher, Grenade, 40 mm, M203 and M203A1, W/E.

• See SL-1-2 for a complete listing of applicable publications.

1-13

TM 8000-10/1D

LAUNCHER, GRENADE, MULTI-SHOT, 40 MM, M32

TAMCN E00252M

NSN 1010-01-535-0989

ID 11235A

TM8K-008

DESCRIPTION AND FUNCTION

The Launcher, Grenade, Multi-Shot, 40 mm, M32 multi-shot grenade launcher is a hand held, semi-auto-

matic, revolving action grenade launcher. It provides enhanced fire power at the squad level. With its 5.5-inch

chamber, the M32 can be loaded with six 40 mm rounds and is capable of firing all DODTI and NATO standard

lethal and non-lethal 40x46 low velocity munitions.

TECHNICAL CHARACTERISTICS

Caliber

40 mm

Cylinder Capacity

6 rounds of 40x46 mm

Weight

13.2 lb (4.92 kg)

Max Effective Range

1,230 ft (375 m)

(Area)

Length

28 to 32 in. (71.12 to 81.28 cm)

(collapsible buttstock)

Employment

Individual

MAJOR COMPONENTS

Qty

Item

Qty

Item

Barrel-Receiver Assembly

Sight Assembly

Cylinder Assembly

Stock Assembly

Trigger Assembly

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

N/A

8J945B

Sight Assembly

REFERENCES

• TM 11235A-IN; 40 mm Multi-Shot Grenade Launcher.

1-14

TM 8000-10/1D

MACHINE GUN, 7.62 MM, M240

TAMCN E09987M

NSN 1005-01-025-8095

ID 08670A

TM8K-009

DESCRIPTION AND FUNCTION

Machine Gun, 7.62 mm, M240 is a lightweight, air-cooled, disintegrating metallic link-belt fed, vehicle

mounted machine gun designed as a coaxial weapon for tanks and 7.62 mm firepower for lighter vehicles. It is

gas-operated with a fixed headspace. It consists of a barrel assembly, buffer assembly, driving space assembly,

bolt and operating rod assembly, trigger and frame assembly, cover assembly, feed tray, and receiver assembly.

TECHNICAL CHARACTERISTICS

Weight

22.2 lb (10.3 kg)

Rate of Fire:

Range:

Cyclic

650 to 950 rounds/min - Change

barrel every minute

Max

4,095 yd (3,725 m)

Sustained

100 rounds/min - Change barrel

Max Effective (Point)

874 yd (800 m)

every 10 minutes

Max Effective (Area)

1,968 yd (1,800 m)

Rapid

200 rounds/min - Change barrel

Tracer Burnout

Approx 985 yd (900 m)

every 2 minutes

MAJOR COMPONENTS

Qty

Item

Qty

Item

Barrel Assembly

Trigger Housing Assembly

Buffer and Spade Grip Assembly

Cover Assembly

Driving Spring Rod Assembly

Feed Tray

Bolt and Operating Rod Assembly

Receiver Assembly

ASSOCIATED COMPONENTS

• None

REFERENCES

• TM 08670A-10/1B; Operator’s Manual, Machine Gun, 7.62 mm, M240.

• TM 08670A/09712A-23&P/2C; Maintenance Manual, Machine Gun, M240 series.

• See SL-1-2 for a complete listing of applicable publications.

1-15

TM 8000-10/1D

MACHINE GUN, 7.62 MM, M240E1

TAMCN E0961

NSN 1005-01-252-4288

ID 09111A

TM8K-010

DESCRIPTION AND FUNCTION

Machine Gun, 7.62 mm, M240E1 is designed with front and rear sights, uses 7.62 mm ammunition, and is

pintle-mounted on light armored vehicles. It is gas-operated and fires from the open bolt position. The M240E1

has a spade grip for closed-in space triggering for use on vehicles.

TECHNICAL CHARACTERISTICS

Weight

25.7 lb (11.66 kg)

Rate of Fire:

Range:

Cyclic

650 to 950 rounds/min - Change

Max

4,095 yd (3,725 m)

barrel every minute

Max Effective (Point)

874 yd (800 m)

Sustained

100 rounds/min - Change barrel

Max Effective (Area)

1,968 yd (1,800 m)

every 10 minutes

Tracer Burnout

Approx 985 yd (900 m)

Rapid

200 rounds/min - Change barrel

every 2 minutes

MAJOR COMPONENTS

Qty

Item

Qty

Item

Barrel Assembly

Trigger Housing Assembly

Buffer and Spade Grip Assembly

Cover Assembly

Driving Spring Rod Assembly

Feed Tray

Bolt and Operating Rod Assembly

Receiver Assembly

ASSOCIATED COMPONENTS

• None

REFERENCES

• TM 08670A-10/1B; Operator’s Manual, Machine Gun, 7.62 mm, M240E1.

• TM 08670A/09712A-23&P/2C; Maintenance Manual, Machine Gun, M240 series.

• See SL-1-2 for a complete listing of applicable publications.

1-16

TM 8000-10/1D

MACHINE GUN, 7.6 MM, M240B

TAMCN E09897M

NSN 1005-01-412-3129

ID 09712B

TM8K-011

DESCRIPTION AND FUNCTION

Machine Gun, 7.62 mm, M240B is the ground-employed version of the basic Machine Gun, 7.62 mm, M240.

It is air-cooled, disintegrating metallic link-belt fed, gas-operated with a fixed headspace, and is designed for all

applications requiring 7.62 mm automatic firepower. Capable of vehicle mount with pintle of AAV R7, C7.

TECHNICAL CHARACTERISTICS

Length (Overall)

49 in. (124 cm)

Range:

Weight:

Max

4,075 yd (3,725 m)

w/ Barrel

Approx 27.1 lb (10.11 kg)

Max Effective (Point)

874 yd (800 m)

w/ Spare Barrel

Approx 6.6 lb (2.46 kg)

w/ M122A1 Tripod

M122 Tripod Mount

Approx 15.0 lb (5.6 kg)

Max Effective (Area)

1,968 yd (1,800 m)

Rate of Fire:

w/ M122A1 Tripod

Cyclic

600 to 650 rounds/min with

Tracer Burnout

Approx 985 yd (900 m)

hydraulic buffer

Sustained

100 rounds/min

Rapid

200 rounds/min

MAJOR COMPONENTS

Qty

Item

Qty

Item

Barrel Assembly

Flex Mount

Buttstock and Buffer Assembly

Drive Spring Assembly

Bolt and Operating Rod Assembly

Trigger Housing Assembly

Cover Assembly

Feed Tray

Receiver Assembly

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

E11202M

06510A

M122 Tripod Mount

E0081

M122A1

M35 MMGVM

REFERENCES

• TM 08670A/09712A-23&P/2C; Maintenance Manual, Machine Gun, M240 series.

• See SL-1-2 for a complete listing of applicable publications.

1-17

TM 8000-10/1D

MACHINE GUN, 40 MM, MK 19 W/BKT

TAMCN E09947M

NSN 1010-01-490-9697

ID 08521B

TM8K-012

DESCRIPTION AND FUNCTION

Machine Gun, 40 mm, MK 19 w/BKT is an air-cooled, disintegrating metallic link-belt fed, blowback-oper-

ated, fully automatic weapon and is crew-transportable. It fires a variety of 40 mm grenades. The M430 (HEDP)

40 mm grenade will pierce armor up to 2 inches thick (at zero degrees obliquity) and will produce fragments to kill

personnel within 5 meters and wound personnel within 15 meters of the point of impact. The weapon is used in

conjunction with the M998 series of 1-1/4 ton, 4x4, HMMWV, M1043, and M1044.

TECHNICAL CHARACTERISTICS

Length

43.1 in. (109.47 cm)

Rate of Fire

325 to 375 rounds/min

Width

14.0 in. (11.5 cm)

Range:

Height

8.8 in. (22.4 cm)

Effective Point Target

1,640 yd (1,500 m)

Weight

75.6 lb (34.30 kg)

Effective Area Target

2,410 yd (2,212 m)

Cube

1 cu ft (.028 cu m)

MAJOR COMPONENTS

Qty

Item

Qty

Item

Receiver Assembly

Sear Assembly

Feed Slide Assembly and Tray

Bolt and Back Plate Assembly

Top Cover Assembly

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

E11232M

MOD 5

Mount, Machine Gun, MK64

MOD 5

E11262B

Mount, Tripod, Machine Gun

E11592B

AN/TVS-5A

Sight, Night Vision

AN/TVS-5A

E11232B

MK93, Mount, Machine Gun

REFERENCES

• TM 08521A-10/1A; Operator’s Manual, Machine Gun, 40 mm, MK 19 MOD 3.

• TM 08521A-23&P/2A Maintenance Manual, Machine Gun, 40 mm, MK 19 MOD 3.

• See SL-1-2 for a complete listing of applicable publications.

1-18

TM 8000-10/1D

MACHINE GUN, CALIBER .50, BROWNING, M2, HEAVY BARREL, FLEXIBLE

TAMCN E09807M

NSN 1005-00-726-5636

ID 02498B

TM8K-013

DESCRIPTION AND FUNCTION

Machine Gun, Caliber .50, Browning, M2, Heavy Barrel, Flexible is an automatic, recoil-operated, disinte-

grating metallic link-belt fed, air-cooled machine gun with an adjustable headspace that is crew-transportable. By

repositioning some of the component parts, ammunition may be fed from either the left or the right side. The

metallic link-belt is used to feed the ammunition into the weapon. This gun has a back plate with spade grips, trig-

ger, safety selector, and bolt latch release. This gun may be mounted on most vehicles and tanks as an anti-per-

sonnel and anti-aircraft weapon. The weapon can be used in conjunction with the M998 series of 1 1/4 ton, 4x4,

HMMWV, M1043, and M1044.

TECHNICAL CHARACTERISTICS

Weight:

Rate of Fire (Max)

450 to 550 rounds/min

Gun

82 lb (37.2 kg)

Maximum Range

Barrel

26 lb (11.8 kg)

API, M8:

Length:

30-deg elevation

6,470 yd (5,972 m)

Barrel

45 in. (114.3 cm)

35-deg elevation

7,460 yd (6,886 m)

Overall

65 in. (165.1 cm)

MAJOR COMPONENTS

Qty

Item

Qty

Item

Flash Hider

Retracting Slide Assembly

Barrel Assembly/Group

Barrel Buffer Group

Back Plate Assembly/Group

Barrel Extension Group

Bolt Group and Rod Assembly

Cover and Receiver Group

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

E11262B

07937A

Mount, Tripod, Machine Gun, Caliber .50

Blank Firing Adapter

M19

E11232B

Mount, Machine Gun

M93

REFERENCES

• SL-3-02498B; Components List, Machine Gun, Cal .50, Browning, M2.

• TM 02498A-10/1; Operator’s Manual, Machine Gun, Caliber .50, Browning, M2.

• TM 02498A-23&P/2A; Maintenance Manual, Machine Gun, Caliber .50, Browning, M2.

• See SL-1-2 for a complete listing of applicable publications.

1-19

TM 8000-10/1D

MACHINE GUN, CALIBER .50, M2, HEAVY BARREL, FLEXIBLE, M48 TURRET TYPE

TAMCN E0984

NSN 1005-00-957-3893

ID 02498C

TM8K108

DESCRIPTION AND FUNCTION

Machine Gun, Caliber .50, M2, Heavy Barrel, Flexible, M48 Turret Type is an air-cooled, recoil-operated,

alternate-feed, automatic, crew-served weapon. The weapon is mounted on the M1 and M1A1 Abrams main bat-

tle tank commander’s station. It provides automatic weapon suppression fire for offensive and defensive pur-

poses. This weapon can be used effectively against personnel, light armored vehicles, and low, slow flying

aircraft.

TECHNICAL CHARACTERISTICS

Weight:

Twist, Right-Hand (One Turn)

15 in. (38.2 cm)

Gun

84 lb (38.1 kg)

Feed

Link-belt

Barrel

26 lb (11.8 kg)

Operation

Short recoil

Length:

Muzzle Velocity

3,050 ft/sec

(929.6 mps)

Barrel

45 in. (114.3 cm)

Maximum Range

7,400 yd (6,767 m)

Overall

65.1 in. (165.4 cm)

Maximum Effective Range

2,000 yd (1,829 m)

Rifling

41.9 in. (106.4 cm)

Rate of Fire (Cyclic)

450 to 600 rounds/min

Number of Lands and Grooves

MAJOR COMPONENTS

Qty

Item

Qty

Item

Flash Hider

Retracting Slide Assembly

Barrel Assembly/Group

Barrel Buffer Group

Back Plate Assembly/Group

Barrel Extension Group

Bolt Group and Rod Assembly

Cover and Receiver Groups

ASSOCIATED COMPONENTS

• None

REFERENCES

• SL-3-02498B; Components List, Machine Gun, Cal .50, Browning, M2.

• TM 02498A-10/1; Operator’s Manual, Machine Gun, Caliber .50, Browning, M2.

• TM 02498A-23&P/2A; Maintenance Manual, Machine Gun, Caliber .50, Browning, M2.

• See SL-1-2 for a complete listing of applicable publications.

1-20

TM 8000-10/1D

MACHINE GUN, LIGHT, SQUAD, 5.56 MM, M249

TAMCN E09607M

NSN 1005-01-127-7510

ID 08671A

TM8K-107

DESCRIPTION AND FUNCTION

Machine Gun, Light, Squad, 5.56 mm, M249 is a portable, gas-operated, magazine or disintegrating metallic

link-belt fed, light machine gun with fixed headspace. The M249 engages point targets out to 800 meters, firing

the improved, NATO standard 5.56 mm cartridge (M855). It has a fixed regulator. The addition of accessory rails

has been implemented.

TECHNICAL CHARACTERISTICS

Weight

15.16 lb (6.875 kg)

Range:

(w/ Bipod and Tools)

Max Effective

1,094 yd (1,000 m) (area target)

Length:

Rate of Fire:

Overall

40.75 in. (103.5 cm)

Cyclic

850 rounds/min (normal)

Barrel

20.5 in. (52.1 cm)

1,000 rounds/min (max)

Range:

Sustained

50 rounds/min

Max

3,938.4 yd (3,600 m)

Rapid

100 rounds/min

MAJOR COMPONENTS

Qty

Item

Qty

Item

Barrel Assembly

Slide Assembly

Rear Sight Assembly

Operating Rod Assembly

Cover and Feed Mechanism Assembly

Receiver Assembly

Feed Tray Assembly

Trigger Mechanism Assembly

Cocking Handle Assembly

Handguard Assembly

Buttstock and Shoulder Assembly

Bipod, Machine Gun

Piston Assembly

Gas Cylinder Assembly

Bolt Assembly

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

E11202M

06510A

Mount, Tripod, Machine Gun, 7.62 mm

M122

REFERENCES

• TM 08671A-10/1A; Operator’s Manual, Machine Gun, Light, Squad, 5.56 mm, M249 W/E.

• TM 08671A-23&P/2A; Maintenance Manual, Machine Gun, Light, Squad, 5.56 mm, M249 W/E.

• See SL-1-2 for a complete listing of applicable publications.

1-21

TM 8000-10/1D

MORTAR, 60 MM, LIGHTWEIGHT, COMPANY, M224

TAMCN E10657M

NSN 1010-01-020-5626

ID 08206A

TM8K-016

DESCRIPTION AND FUNCTION

Mortar, 60 mm, Lightweight, Company, M224 is a smooth bore, muzzle-loading, high-angle-of-fire weapon.

The cannon assembly is composed of a barrel, combination base cap, and firing mechanism. The base cap is hol-

lowed and threaded to screw onto the barrel. The mount consists of a bipod and base plate that is provided with

screw-type elevating and traversing mechanisms to elevate/traverse the mortar. It has a spring-type shock

absorber to absorb the shock of recoil during firing. Weapon Record Book, Part II (NAVMC 10558A) is provided

with the mortar.

TECHNICAL CHARACTERISTICS

Weight:

Range:

Conventional Mode

46.5 lb (21.1 kg)

Minimum

231 ft (70 m)

Hand-Held Mode

18.0 lb (8.2 kg)

Maximum

11,517 ft (3,490 m)

Length

40.0 in. (1.0 m)

MAJOR COMPONENTS

Qty

Item

Cannon

Base Plate M7/M8

Bipod

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

E17802E

02368B

Sight, Bore, Optical

M45/M45A1

N/A

Sight, Bore, Optical

M115

N/A

88129C

Sight Unit (Tritium Powered Radioactive Device [RAD])

M64A1

REFERENCES

• TM 08206A-10/1A; Operator’s Manual, Lightweight Company Mortar, 60 mm, M224.

• TM 08206A-23&P/2A; Maintenance Manual, Lightweight Company Mortar, 60 mm, M224.

• See SL-1-2 for a complete listing of applicable publications.

1-22

TM 8000-10/1D

MORTAR, MEDIUM, EXTENDED RANGE, 81 MM, M252

TAMCN E10957M

NSN 1015-01-164-6651

ID 09922A

TM8K-017

DESCRIPTION AND FUNCTION

Mortar, Medium, Extended Range, 81 mm, M252 is a crew-served, lightweight mortar that is highly accurate

and provides for a range of 4,500 meters to 5,650 meters. The cannon has a removable breech plug and firing

pin. The muzzle end has a short tapered lead-in for the cartridge and blast attenuator device (BAD). The breech

end is finned for better cooling. Weapon Record Book, Part II (NAVMC 10558A) is provided with the mortar.

TECHNICAL CHARACTERISTICS

Weight (with BAD)

89 lb (39.72 kg)

Diameter of Baseplate

1 ft, 10 in. (0.56 m)

Overall Length:

Rate of Fire:

w/ BAD

4 ft, 7 in. (1.40 m)

Sustained

15 rounds/min

w/o BAD

4 ft, 2 in. (1.27 m)

Maximum

30 rounds/min for 2 min

MAJOR COMPONENTS

Qty

Item

Mortar Mount

Cannon

Baseplate

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

E17802E

02368B

Sight, Bore, Optical

M45/M45A1

N/A

88129C

Sight Unit, Gunners Quad (Tritium Powered Radioactive

M64A1

Device [RAD])

REFERENCES

• TM 09922A-10/1; Operator’s Manual, Mortar, 81 mm, M252.

• TM 09922A-23&P/2A; Maintenance Manual, Mortar, 81 mm, M252.

• See SL-1-2 for a complete listing of applicable publications.

1-23

TM 8000-10/1D

MOUNT, MACHINE GUN, MK64 MOD 5

TAMCN E11232B

NSN 1010-01-180-9319

ID 09017A

TM8K-018

DESCRIPTION AND FUNCTION

Mount, Machine Gun, MK64 MOD 5 includes components that can employ three different types of machine

guns on a variety of gun mounts. Its central component is the carriage and cradle assembly. Other features

include ammunition containers and container brackets, components to provide control over the machine gun

while mounted, and components to provide machine gun and user protection.

TECHNICAL CHARACTERISTICS

Weight:

Weight (Continued):

Ammo Box Mounting Tray

10 lb (4.54 kg)

Feed Throat Assembly

2 lb (0.9 kg)

Assembly

Pintle Adapter Assembly

8.5 lb (3.85 kg)

Bracket Mounting Assembly

6 lb (2.7 kg)

Platform Assembly

2 lb (0.9 kg)

Cal .50 Mounting Adapter Assembly

4 lb (1.8 kg)

Traversing and Elevation Assembly

10 lb (4.54 kg)

Carriage and Cradle Assembly

21 lb (9.5 kg)

MAJOR COMPONENTS

Qty

Item

Qty

Item

Ammunition Box Mounting Tray Assembly

Feed Throat Assembly

Bracket Mounting Assembly

Pintle Adapter Assembly

Caliber .50 Mounting Adapter Assembly

Platform Assembly

Carriage and Cradle Assembly

Traversing and Elevation Assembly

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

N/A

Machine Gun, 7.62 mm

M60E3

E09807M

02498B

Machine Gun, Caliber .50, Browning

E09947M

N/A

Machine Gun, 40 mm, MK19

MOD3

N/A

Heavy Barrel, Flexible

REFERENCES

• TM 1005-13A&P/1; Operator’s, Unit, and Direct Support Maintenance Manual, Mount, Machine Gun, MK64 MOD 5.

• See SL-1-2 for a complete listing of applicable publications.

1-24

TM 8000-10/1D

MOUNT, VEHICLE, MEDIUM MACHINE GUN, M35 (MMGVM)

TAMCN E00817

NSN 1005-01-557-2693

ID TBD

TM8K-119

DESCRIPTION AND FUNCTION

M35 Medium Machine Gun Vehicle Mount (MMGVM) is a lightweight, vehicle mounting platform for the

M240 series and M249 series weapons and ammunition. Supplied with Traverse and Elevation Mechanism (T&E)

and used in conjunction with a Universal Pintle Adapter (UPA), it provides an adjustable, low-maintenance, easy-

to-operate vehicle mount that accepts either weapon series without having to change mount configuration. A grab

handle on the mount aids in weapon control and stability.

TECHNICAL CHARACTERISTICS

Weight (w/o UPA):

12.5 lb (5.67 kg)

Length (mount only):

12.5 in. (31.75 cm)

Weight (w/ UPA):

TBD

Width (mount only):

17.0 in. (43.18 cm)

Height (mount only):

8.0 in. (20 cm)

MAJOR COMPONENTS

Qty

Item

Qty

Item

Cradle Assembly

Ammunition Can Holder (ACH)

Pintle

ACH Bracket

Front Mounting Pin

Ammunition Clip

Rear Mounting Pin

Shock Cords

Grab Handle

Traverse and Elevation Mechanism

1-25

TM 8000-10/1D

MOUNT, MACHINE GUN, MK93

TAMCN E11232B

NSN 1010-01-502-7547

ID 08017B

TM8K-120

DESCRIPTION AND FUNCTION

The MK93 machine gun mount is a dual purpose, soft mount for the MK19 Grenade Machine Gun (GMG)

and M2 Heavy Machine Gun (HMG). The MK93 is designed for use with either a tripod or a vehicular mount

(using the MK175 pintle pedestal). It requires no external adapters or tools to mount either weapon system, mak-

ing change-overs much easier. The MK93 will provide the capacity to optimize operational capabilities of the M2

HMG and the MK19 GMG in both vehicular and ground mounted modes. It provides platform stabilization,

improves accuracy, increases hit probability while decreasing the time and effort to install and interchange weap-

ons. The MK93 replaces the MK64 MOD 5 cradle.

TECHNICAL CHARACTERISTICS

Weight:

30.2 lb (13.7 kg)

Width:

10.0 in. (254 mm)

w/MK175 pintle:

40.2 lb (18.2 kg)

w/MK175 pintle:

10.0 in. (254 mm)

Height:

6.8 in. (172 mm)

Length:

22.0 in. (558 mm)

w/MK175 pintle:

16.8 in. (426.7 mm)

w/MK175 pintle:

22.0 in. (558 mm)

MAJOR COMPONENTS

Qty

Item

Qty

Item

Carriage and cradle assembly

Ammunition can holder

Train stop bracket

Bolt-on small pintle

Bolt-on large pintle

Stowage bar assembly

ASSOCIATED COMPONENTS

TAM #

ID #

Nomenclature

Type/Model

E9807M

02498B

Machine Gun, Caliber .50, Browning

E09947M

08521A

Machine Gun, 40mm, MK19

MOD 3

REFERENCES

• See SL-1-2 for a complete listing of applicable publications.

1-27

TM 8000-10/1D

MOUNT, TRIPOD, MACHINE GUN, 7.62 MM, M122

TAMNC E11202M

NSN 1005-00-710-5599

ID 06510A

TM8K-019

DESCRIPTION AND FUNCTION

Mount, Tripod, Machine Gun, 7.62 mm, M122 is a lightweight, portable, folding mount used for ground fire.

It consists of three main groups: the tripod, the traversing and elevating mechanism, and the pintle. The travers-

ing and elevating mechanism has a quick disconnect adapter that fastens to a plate beneath the receiver of the

weapon. When released, the weapon may be traversed a full 360 degrees and manually elevated or depressed.

The pintle has a platform with a quick disconnect latch that uncouples the weapon from the mount by pressing for-

ward on the release latch (only one pintle is provided per tripod).

TECHNICAL CHARACTERISTICS

Weight

15 lb (6.8 kg)

Length:

Height

14 in. (35.6 cm)

Extended

32.5 in. (82.6 cm)

Folded for Transport

27 in. (68.6 cm)

Spread of Rear Legs

30 in. (76.2 cm)

MAJOR COMPONENTS

Qty

Item

Qty

Item

Adapter Assembly

Right Leg Latch

Pintle Assembly

Traversing and Elevation Mechanism

Pintle Lock Assembly

Assembly

ASSOCIATED COMPONENTS

• Ground Mounted Machine Guns

• M249 SAW

• M240B

REFERENCES

• TM 1005-13A&P/1; Operator’s, Unit, and Direct Support Maintenance Manual, M122 Machine Gun Tripod

Mount.

• See SL-1-2 for a complete listing of applicable publications.

1-28

TM 8000-10/1D

MOUNT, TRIPOD, MACHINE GUN, CALIBER .50, M3

TAMCN E11262B

NSN 1005-00-322-9716

ID 07937A

TM8K-104

DESCRIPTION AND FUNCTION

Mount, Tripod, Machine Gun, Caliber .50, M3 is a lightweight, portable, folding mount. It consists of three

telescoping tubular legs joined in a tripod head; the two rear legs are joined and supported by a traversing bar.

The traversing bar forms a single A-truss and serves as a rear support for the traversing and elevating mecha-

nism that supports the mounted gun. The tripod head furnishes a front support for the mounted gun and is sup-

ported by the short front leg. This mount is stowed on vehicles and tanks for ground use when conditions warrant.

The tripod is used with the M2 and MK19 machine guns.

TECHNICAL CHARACTERISTICS

Weight

44 lb (19.96 kg)

Length:

Traversing Range:

Extended

74.5 in. (189.23 cm)

w/ Elevating Mechanism

45 deg

Folded

45.5 in. (115.57 cm)

Free

360 deg

Spread of Rear Legs

61.5 in. (156.21 cm)

Max Elevation

5.6 deg

Shipping Data

Max Depression

-14 deg

(1 mount per wood box):

Length

48.75 in. (123.83 cm)

Width

10.88 in. (27.64 cm)

Height

8.63 in. (21.92 cm)

MAJOR COMPONENTS

Qty

Item

Qty

Item

Traversing and Elevation Mechanism

Rear Right Leg

Front Leg

Pintle Lock Assembly

Rear Left Leg

ASSOCIATED COMPONENTS

• Ground Mounted Machine Guns

REFERENCES

• TM 1005-13A&P/1; Operator’s, Unit, and Direct Support Maintenance Manual, M3 Machine Gun Tripod Mount.

• See SL-1-2 for a complete listing of applicable publications.

1-29

TM 8000-10/1D

PISTOL, M45 CLOSE QUARTERS BATTLE PISTOL (CQBP) .45 CALIBER

TAMCN E12512M

NSN 1005-01-521-4072

ID 09795B

TM8K-021

DESCRIPTION AND FUNCTION

Pistol, M45 Close Quarters Battle Pistol (CQBP) .45 Caliber is an air-cooled, magazine-fed, recoil-operated,

automatic-loading, defensive hand weapon. It is fed from a seven-round, stainless steel magazine and is a semi-

automatic weapon, firing one round each time the trigger is squeezed. The weapon can be carried in either a hip

or shoulder holster and may be securely connected to the shooter by the pistol lanyard.

TECHNICAL CHARACTERISTICS

Length:

Safety

Ambidextrous thumb safety

Overall

8.37 in. (21.26 cm)

Range:

Barrel

5.03 in. (12.78 cm)

Max

1,640 yd (1,500 m)

Weight:

Max Effective

54.6 yd (50 m)

Empty Magazine

2.5 lb (.933 kg)

Muzzle Velocity

830 ft/sec

Loaded Magazine

3.0 lb (1.12 kg)

MAJOR COMPONENTS

Qty

Item

Qty

Item

Slide Group

Receiver Assembly

Slide Stop

ASSOCIATED COMPONENTS

• Holster

• Lanyard

REFERENCES

• TM 09795B-OR; Operator’s Manual with Component List, M45 Close Quarters Battle Pistol (CQBP)

.45 Caliber.

• TM 09795B-IN; Organizational and Intermediate Maintenance Manual with Repair Parts List (RPL),

M45 Close Quarters Battle Pistol (CQBP) .45 Caliber.

1-30

TM 8000-10/1D

PISTOL, SEMI-AUTOMATIC, 9 MM, M9 AND M9A1

TAMCN E12502M

NSN 1005-01-118-2640

ID 08993A

E12452M

1005-01-525-7966

08993B

TM8K-022

DESCRIPTION AND FUNCTION

Pistol, Semi-automatic, 9 mm, M9 (shown above) and M9A1 is a magazine-fed, recoil-operated, double-

action pistol, chambered for the 9 mm cartridge. It is a defensive hand weapon, with a 15-round capacity, used for

ranges less than 50 yards. Upon firing, the pressure developed by the combustion gases recoils the slide and bar-

rel assembly. After a short run, the locking block will stop the rearward movement of the barrel and release the

slide, which continues rearward movement. The slide will then extract and eject the fired cartridge case, cock the

hammer, and compress the recoil spring. The slide moves forward under recoil spring pressure, feeding the next

round. The slide stop holds the slide and barrel assembly open after the last round has been fired and ejected.

The M9A1 lower receiver has an integral MIL-STD-1913 for mounting accessories.

TECHNICAL CHARACTERISTICS

Length

8.54 in. (21.7 cm)

Width

1.50 in. (3.8 cm)

Barrel Length

4.92 in. (12.5 cm)

Height

5.51 in. (14.0 cm)

Weight:

Range:

Empty Magazine

960 g (33.86 oz)

Max

1,969.2 yd (1,800 m)

Loaded Magazine

1,145 g (40.89 oz)

Max Effective

54.7 yd (50 m)

Muzzle Velocity

1,230.3 ft/sec (375 mps)

MAJOR COMPONENTS

Qty

Item

Qty

Item

Slide and Barrel Assembly

Receiver Assembly

ASSOCIATED COMPONENTS

• Holster

• Lanyard

REFERENCES

• TM 1005A-10/1; Operator’s Manual, Pistol, Semi-automatic, 9 mm, M9.

• TM 1005A-23&P/2A; Maintenance Manual, Pistol, Semi-automatic, 9 mm, M9.

• See SL-1-2 for a complete listing of applicable publications.

1-31

TM 8000-10/1D

RIFLE, 7.62 MM, M14, ENHANCED MARKSMAN RIFLE (EMR)

TAMCN E03117M

NSN 1005-01-553-5196

ID 11473A

TM8K-023

DESCRIPTION AND FUNCTION

Rifle, 7.62 mm, M14, Enhanced Marksman Rifle (EMR) is a lightweight, air-cooled, gas-operated, 20-round

magazine-fed, shoulder weapon with semi-automatic fire, and is used primarily for precision. It is equipped with

the Scout Sniper Day Scope and an adjustable bipod assembly.

TECHNICAL CHARACTERISTICS

Length (Overall)

44-1/8 in. (112.3 cm)

Range:

Weight:

Max

4,073 yd (3,725 m)

Empty Magazine

13 lb (4.85 kg)

Maximum Effective

842 yd (770 m)

Loaded Magazine

16.6 lb (6.20 kg)

Rate of Fire (Semi-automatic)

60 RPM

MAJOR COMPONENTS

TBD

ASSOCIATED COMPONENTS

• Case, Carrying

• SSDS

REFERENCES

TBD

1-32

Military reference books and manuals (2009-2023, Volume 8) - page 38
