CHAIRMAN OF THE JOINT

CHIEFS OF STAFF

MANUAL

J-3

CJCSM 3150.15C

DISTRIBUTION: A, B, C, J, S

20 November 2009

STANDARD SPECIFIED GEOGRAPHIC LOCATION FILE REQUEST (GEOREQ)

Reference(s): See Enclosure F.

1. Purpose. This manual outlines procedures supporting the maintenance of

the Standard Geographic Location file (GEOFILE), as part of the joint reporting

structure as described in reference a.

2. Cancellation. CJCSM 3150.15B, 1 October 2002 with CH-1, 31 October

2003 and CH-2, 1 November 2005 are canceled.

3. Applicability. This manual applies to all combatant commanders,

subunified commands, joint task forces, subordinate commands and all others,

as appropriate, involved in using GEOFILE during military planning and

operations.

4. Policy. The GEOFILE is the authoritative automated repository of the

Department of Defense for the registration of military installations and

worldwide geographic locations subject to reference during military planning

and operations.

5. Definitions

a. Specified Geographic Location File Request (GEOREQ). The GEOREQ

provides the Joint Staff with the means to manage the registration,

cancellation, and maintenance of GEOLOC codes and their associated

descriptive elements. See Enclosure A for GEOREQ content.

b. Specified Geolocation (GEOLOC) Code. The GEOLOC code provides a

standard coded representation to identify a specified geographic location when

that location is identified within DOD data systems. As such, GEOLOC codes

facilitate rapid and compatible data interchange within DOD systems.

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

6. Responsibilities

a. The Deputy Director for Global Operations, Command Systems

Operations Division (J-3/DDGO/CSOD), is responsible for the overall

management and administration of the GEOFILE and is the approving

authority for the registration of all GEOFILE data.

b. The Chief of Staff, U.S. Army; Chief of Naval Operations; Chief of Staff,

U.S. Air Force; Commandant of the Marine Corps; DOD agencies that use the

GEOFILE; combatant commanders, and the Joint Staff are responsible for

originating GEOREQs, as required.

c. USTRANSCOM is responsible for reporting data values to populate the

GEOFILE with defense transportation regulation (DTR) codes for air terminals,

water ports, consolidation and containerization points, and CONUS freight

distribution centers. When air terminal identifier codes/International Civil

Aviation Organization (ICAO) codes have not been assigned, USTRANSCOM

may create “pseudo” values when coded data is required to support air

transportation operations.

d. NGA is the primary agency responsible for reporting data for the four-

character ICAO code (as determined from appropriate sources) to be used in

the GEOFILE. ICAO codes reported for the GEOFILE should match the ICAO

codes in the NGA automated air facilities intelligence file (AAFIF). When an

established code for the GEOFILE ICAO code value does not exist,

USTRANSCOM may create “pseudo” ICAO values when required to support air

transportation operations. ICAO value adjustments can be made as necessary

to support operational requirements. NGA is a major requesting agency for the

registration of airports, which could include ICAO codes. In accordance with

the following procedures, NGA may also originate GEOLOC codes for air

facilities.

(1) In order to expedite the identification of air installations with

GEOLOC codes to be both in the AAFIF and the GEOFILE, the following block

of 400 codes is reserved for use by NGA: (AF00-AF99, AG00-AG99, AH00-

AH99, and AJ00-AJ99).

(2) GEOLOC code is one of the descriptive data elements available when

an air facility is added to the AAFIF. If the added air facility may be used in

any military or USG activity requiring location identification, a GEOLOC code

should be entered in the AAFIF. If upon examination of the specified GEOFILE

database an existing GEOLOC is not found, NGA may assign a GEOLOC from

the next available code in the block of codes reserved for NGA.

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

(3) When NGA assigns a GEOLOC code from the NGA-reserved block of

codes, prompt action must be taken to have that GEOLOC code registered in

the GEOFILE. By e-mail, by newsgroup, by telephone, by fax, or other

expeditious communications media, NGA must provide J-3/DDGO/CSOD or

its designated agent the data necessary to add a new GEOLOC to the

GEOFILE.

e. DISA’S Joint Staff Support Center (JSSC) is responsible for receiving

GEOREQs, processing updates to the GEOFILE, and networking data to JOPES

database sites.

7. Procedures. Requests for GEOLOC codes, changes to descriptive data, and

cancellations will be prepared per instructions contained in Enclosure A and

its appendix. Requests will be submitted to DISA/JSSC in accordance with the

following procedures.

a. When to submit a GEOREQ

(1) To request the registration of a specified geographic location.

(2) To change any data elements describing a registered GEOLOC.

(3) To cancel a registered GEOLOC code.

b. Jurisdiction. The Service having jurisdiction over the installation will

normally request a GEOLOC code identifying a military installation. Unless

overriding justification exists, tenant Services or DOD agencies at these

installations will use the GEOLOC codes established at the request of the

Service or agency having jurisdiction. Only one GEOLOC code will be used to

identify a specific installation type code for specific geographic location.

c. How to submit a GEOREQ

(1) Transmit GEOREQs to the J-3/CSOD or JSSC by fax, letter,

gccs.jopes.fm newsgroup message, memorandum, NIPRNET e-mail, or

SIPRNET e-mail (jopes@nmcc.smil.mil). Any input medium is acceptable as

long as the basic data elements are identified. The basic data elements are

location name, country and/or state code, type of installation, geographic

coordinates, and the identification of the requesting organization. If known,

the ICAO should be provided for air-capable geolocations. The DTR code

should also be provided if available. Additional geolocation-related data

elements can be determined at the time of record creation. See table 1 for

information to be submitted.

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

Information

Required/Optional

Comments

Request Type

Required

Add/Change/Cancel

Requesting Organization

Required

GEO Location Name

Required

Max of 35 Characters - A/N

Installation Type (ITC)

Required

See Encl B, pg B-1

Country/State Code

Required

See Encl C, pg C-A-1 & C-B-1

Longitude

Required

Latitude

Required

Security Classification

Required

Always “U” (unclassified)

Required for change or cancel

GEOCODE

Optional

requests

DTR Code

Optional

ICAO

Optional

Record Owner’s UIC

Optional

Logistic Planning and

Optional

See Encl D, pg D-1

Reporting Code

Table 1. Information for GEO Location Registration

(2) GEOREQ requests will normally be processed with a routine priority.

When GEOLOC code information is essential to the planning or execution of

current military operations, the highest priority will be used. In these

instances, transmission during MINIMIZE is authorized.

d. Annual Validation. The GEOLOC code requester will be responsible for

providing accurate and current data for all descriptive data elements. Record

owners will verify the accuracy and utility of their records once a year. The

Joint Staff, J-3/DDGO/CSOD will be advised of the results of these

verifications not later than the last workday of March. Negative reports are

required.

e. Special Geographic Locations. Special geographic locations have been

created to support a generic environment for locations when a GEOLOC is

required for data entry, but a specific GEOLOC is not immediately in the

GEOFILE.

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

(1) For each country code used in the GEOFILE, a generic center-of-

country GEOLOC has been created to allow reference to a location within a

country when a specific name and coordinates are not already in the file or

specific data is not desired. These GEOLOC codes generally begin with the

values “UN,” “XO,” or “XQ.”

(2) For general military planning, to allow a requirement for GEOLOC

entry for a military operation, the installation type code (ITC) “OPA” is defined.

Using the ITC of OPA, a series of generic locations are provided in the

GEOFILE. These locations can be used for maritime operating activities,

amphibious landing zones, maneuver areas, and/or other military operations.

f. Cancellations

(1) A request for the cancellation of a GEOLOC should be submitted

when it is no longer required. Recipients will be responsible for coordinating

with their subordinates, as appropriate, and notifying J-3/DDGO/CSOD if a

GEOLOC should be returned to active status.

(2) Canceled GEOLOC records are not deleted but remain in the

database as a historical record.

g. Newsgroup Reporting. The GCCS-J Newsgroup, gccs.jopes.fm, is

available via the SIPRNET for requesting changes to or reporting any problems

noted with GEOFILE or any of the standard reference files. The newsgroup

provides users with easy access to the functional database manager for quick

application of requested changes and resolution of problems. All GEOFILE

users are encouraged to describe any suspected GEOFILE problems by

reporting the incident directly to J-3/DDGO/CSOD via this Newsgroup.

J-3/DDGO/CSOD will be responsible for problem resolution.

h. Distribution

(1) GEOFILE updates will be distributed as necessary to support

operational requirements. Changes may be made as frequently as every 30

minutes. Distribution of GEOFILE updates to JOPES database sites is an

automated process. A newsgroup message will be posted to the GCCS

newsgroup when the GEOFILE is updated.

(2) DISA/JSSC processes transactions for GEOFILE updates

interactively online. Delete processing will be in accordance with paragraph 7.f.

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

8. Summary of Changes

a. Primary changes are (1) the addition of USAFRICOM and subsequent

realignment of areas of responsibility for USEUCOM and USCENTCOM, (2) an

update of the table containing Installation Type Codes (ITCs), and (3) the use of

the ISO (International Organization for Standardization) 3166 2-character

codes as the standard for naming countries of the world, replacing the previous

Federal Information Processing Standards (FIPS) Publication 10-4.

b. This document has adopted the ISO 3166 2-character code in all but 34

instances. In these instances, where there is a conflict with U.S. Department

of State recognized country names or a country is not listed in ISO 3166, the

FIPS 10-4 code was retained.

9. Reports Requirements. Reports required by this manual are exempt from

normal reporting procedures in accordance with DOD Manual 8910.01M,

reference b.

10. Releasability. NOT FOR PUBLIC RELEASE. This manual is approved for

limited release. DOD components (to include the combatant commands), Joint

Staff, and other federal agencies may obtain copies of this manual through

controlled Internet access from the CJCS directives library on the SIPRNET at

http://jointstaff.js.smil.mil/portal/site/jsportal/jelmgr. Additional information

may be obtained from the J-3/CSOD JOPES Program Manager’s office.

11. Effective Date. This manual is effective upon receipt.

B. E. GROOMS

RADM, USN

Vice Director, Joint Staff

Enclosure(s):

A - GEOREQ Content

B - Installation Type Codes

C - Standard DOD Data Elements

D - Logistics Planning and Reporting Codes

E - Geographical AOR Codes for Combatant Commands

F - References

GL - Glossary

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

TABLE OF CONTENTS

Page

ENCLOSURE A -- GENERAL INFORMATION

General

A-1

Report Identifier

A-1

Security Classification

A-1

Transaction Code

A-1

Specified Geolocation Code

A-1

Geolocation Name (GENOA)

A-1

Installation Type Code

A-2

DTR Code

A-2

Country/State/Bodies of Water Code

A-2

GSA City Codes

A-2

Geographic Coordinates

A-2

Logistic Planning and Reporting Code

A-3

Record Status

A-3

Record Owner’s UIC

A-3

Prime Geolocation Code (COGEO)

A-3

International Civil Aviation Organization (ICAO) Code

A-3

Geographical Area of Responsibility (GEOAOR) Code

A-3

Appendix - GEOFILE Automatic Data Processing Criteria

A-A-1

ENCLOSURE B -- INSTALLATION TYPE CODES

B-1

ENCLOSURE C -- STANDARD DOD DATA ELEMENTS

C-1

Appendix A -- Data Element: Countries of the World

C-A-1

Appendix B -- Data Element: States of the United States

C-B-1

Appendix C -- Data Element: Water Bodies of the World

C-C-1

ENCLOSURE D -- LOGISTIC PLANNING AND REPORTING CODES

D-1

ENCLOSURE E -- GEOGRAPHICAL AREA OF RESPONSIBILITY

CODES FOR THE COMBATANT COMMANDS

E-1

ENCLOSURE F - REFERENCES

F-1

GLOSSARY -- ABBREVIATIONS AND ACRONYMS

GL-1

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

FIGURE

PAGE

D-1 The World With Combatant Commanders’ AORs

D-1

D-2 LPR Area 1 (USCENTCOM) Subareas

D-3

D-3 LPR Area 3 (USNORTHCOM) Subareas

D-5

D-4 FEMA Regional Boundaries

D-7

D-5 LPR Area 4 (USEUCOM) Subareas

D-9

D-6 LPR Area 5 (USPACOM) Subareas

D-11

D-7 LPR Area 6 (USSOUTHCOM) Subareas

D-13

D-8 LPR Area 7 (USAFRICOM) Subareas

D-15

D-9 USEUCOM, USPACOM, USNORTHCOM (North Pole View)

D-16

D-10 USAFRICOM, USPACOM, USSOUTHCOM (South Pole View)

D-17

D-11 The World With Combatant Command AORs (larger size)

D-18

TABLE

Information for GEO Location Registration

A-1

Samples of GEONA Modifiers and Their Abbreviations

A-2

A-A-1 GEOREQ Data Fields

A-A-2

A-A-2 ASCII File Format for GEOFILE Database

A-A-3

D-1 Subarea LPR Codes for USCENTCOM

D-2

D-2 Subarea LPR Codes for USNORTHCOM

D-4

D-3 Subarea LPR Codes for East Coast, Gulf Coast, and West Coast

D-6

D-4 Subarea LPR Codes for USEUCOM

D-8

D-5 Subarea LPR Codes for USPACOM

D-10

D-6 Subarea LPR Codes for USSOUTHCOM

D-12

D-7 Subarea LPR Codes for USAFRICOM

D-14

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

ENCLOSURE A

GEOREQ CONTENT

1. General. This enclosure describes the content of the GEOREQ, including

field length and composition. When appropriate, it designates the authoritative

sources for codes and spelling of locations. It also provides abbreviations for

common geographical modifiers. Example format, content, structure, and

report preparation instructions are included in the appendix to this enclosure.

2. Report Identifier. Enter GEOREQ, the report identifier.

3. Security Classification. A one-character alphabetic code used for the

classification of the data included in the report. At present, only unclassified

reports will be made and will be represented by the code “U.”

4. Transaction Code. A one-character alphabetic code, either “A” for add, “C”

for change, or “D” for cancel (delete), to indicate the type of request involved in

the transaction. GEOLOC records normally will not be deleted but will remain

in the database in a canceled status. Selected canceled GEOLOC records can

be deleted after close coordination between the JS-CSOD/JSSC and the record

owner.

5. Specified Geolocation Code. A four-character alphanumeric entry used to

represent the specified geographic location of a location or place at which a

military organization may be located or a location or place of military

significance. This code is assigned by the Joint Staff. The GEOLOC field must

be blank when requesting registration. The location must have a registered

GEOLOC code when requesting a change to data elements of a registered

GEOLOC code or cancellation of a GEOLOC.

6. Geolocation Name (GEONA). A distinguishable and meaningful name with a

maximum of 35 alphanumeric characters that identifies the specified

geographic location of interest (e.g., CP Peary, Ft. Lee, Andrews AFB, Norfolk

NAS). Its use is required in all requests for registration and cancellation.

When a GEONA contains a modifier, the abbreviation for the modifier can be

used in place of the modifier (see Table A-1).

A-1

Enclosure A

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

MODIFIER

ABBREVIATION

Camp

East

Fort

Mount

Mountain

MTN

North

Northeast

Northwest

Saint

South

Southeast

Southwest

West

Table A-1. Samples of GEONA Modifiers and Their Abbreviations

7. Installation Type Code. A three-character alphabetic entry identifying the

type of installation represented by a GEOLOC code, e.g., “CTY” for city, “PRT”

for Port, and required in all requests for registration.

(Authorized codes and

their explanations are contained in Enclosure B.)

8. DTR Code. A three-character alphanumeric code for air terminals, water

ports, consolidation and containerization points, and CONUS freight

distribution centers published in DOD Regulation 4500.9-R. USTRANSCOM

provides DTR codes for input to the GEOFILE. (See reference c.)

9. Country/State/Bodies of Water Code. A two-character alphanumeric entry

representing geographic-political areas. Required in all requests for

registration. Appendixes A, B, and C of Enclosure C list these codes for quick

reference and are current as of this publication.

(See references d, e, and f.)

10. GSA City Code. A four-character nonmilitary code for cities of the United

States as contained in reference e.

11. Geographic Coordinates. The 15 alphanumeric characters indicating the

intersecting lines of latitude and longitude determining the coordinate point of

a geographic location. Required in all requests for registration. Coordinates

A-3

Enclosure A

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

will be entered in the sequence prescribed by the DOD standard data chain

“Geographic Coordinates, Seconds.” The coordinates for a specified geographic

location should be those reasonably available from a good quality source, e.g.,

Global Positioning System, well-known commercial references such as The

Times Atlas of the World, charts and maps, base or station engineer records,

and celestial or geographic fixes. Although not necessary for general use, the

positions for seconds are included in the field to satisfy those instances

requiring more definitive coordinates. Otherwise, enter zeros in the seconds’

positions.

12. Logistic Planning and Reporting Code. A two-character alphanumeric code

designated to meet the needs of the military logistic community. The code is

described in Enclosure D. The code is assigned by the Joint Staff.

13. Record Status. A one-character alphabetic code indicating the record is

active (“A”) or canceled (“C”) by record owner. If canceled, the GEOLOC records

normally will not be deleted but will remain in the database for historical

purposes. Selected canceled GEOLOCs will be deleted after close coordination

between the JS-CSOD/JSSC and the record owner.

14. Record Owner’s UIC. The six-character alphanumeric code identifying the

reporting organization for a GEOLOC code. The record owner’s UIC

organization is responsible for maintenance of GEOLOC code data. The Joint

Staff will use this field to identify record owners of the data.

15. Prime Geolocation Code (COGEO). A four-character alphanumeric

GEOLOC used to group different installation types at the same location with a

common code. The GEOLOC code assigned to the host or predominant

installation will normally be the Prime Geolocation Code for other installation

type codes registered at that location. For example, the GEOLOC code

assigned for Minot AFB will be the COGEO for all other installation type codes

registered for that location such as administration (ADM), ammunition storage

(AMO), and storage (STG).

16. International Civil Aviation Organization (ICAO) Code. A four-character

code in the GEOFILE used to identify air facilities that may be used for

worldwide airlift operations. The GEOFILE ICAO code includes codes for areas

of the world not listed by the ICAO (i.e., host nation identified code and

USTRANSCOM-created pseudo codes).

17. Geographical Area of Responsibility (GEOAOR) Code. A one-character

numeric code representing the combatant command area in which the

GEOLOC is located. GEOAOR codes are listed in Enclosure E.

A-3

Enclosure A

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

APPENDIX TO ENCLOSURE A

GEOFILE AUTOMATIC DATA PROCESSING CRITERIA

1. Purpose. This appendix describes the format, allowable characters, and

report content of GEOREQ transactions. A format for external systems

interface is also provided.

2. Allowable Characters for Field Content (TYPE DATA)

a. Alphabetic characters (A) from A to Z. Left-justified with trailing or

embedded blanks.

b. Numeric characters (N) from 0 to 9. Right-justified with leading zeros.

c. Alpha/Numeric (A/N)

(1) Comma (,).

(2) Open and close parenthesis ().

(3) Hyphen, dash, minus sign (-).

d. Table A-A-1 lists the specific data fields contained in the GEOREQ.

A-A-1

Appendix

Enclosure A

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

DATA

FIELD

TYPE

DATA ELEMENT NAME

FIELD

DESCRIPTOR

DATA

Security Classification

1 A

Transaction Code

1 A

Geolocation Code

GEOLOC

4 A/N

Geolocation Name

GEONA

35 A/N

Installation Type Code

GEODE

3 A

Defense Transportation Regulation Code

DTR

3 A/N

Country/State Code

CRTCD

2 A/N

GSA City Code

GCITY

4 A/N

Geographic Coordinates

POINT

15 A/N

Logistic Planning and Reporting Code

LPRCO

2 A/N

Record Status

RECSTAT

1 A

Record Owner’s UIC

RUIC

6 A/N

Prime Geolocation Code

COGEO

4 A/N

International Civil Aviation Organization Code

ICAO

4 A/N

Geographic Area of Responsibility Code

GEOAOR

1 N

Table A-A-1. GEOREQ Data Fields

A-A-2

Appendix

Enclosure A

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

3. Table A-A-2 contains a sequential ASCII file format for the GEOFILE

database for interface with external systems. The GCCS core database

contains a different GEOFILE structure in Oracle tables.

COLUMNS

SIZE

FIELD NAME

DESCRIPTION

1-4

GEOLOC

Geographic Location Code

5-5

RECLEV

Fixed Value Of 1

6-7

RECTYP

Fixed Value Of 01

8-12

FILLER

Blanks

13-29

GEONA

Geographic Location Name

30-32

GEODE

Installation Type Code

33-34

CRTCD

Country/State Code

35-39

CRTNM

Abbreviated Country/State Name

40-58

FILLER

Blanks

59-73

POINT

Geographic Coordinates

74-75

LPRCO

Logistic Planning And Reporting Code

76-79

COGEO

Prime Geolocation Code

80-85

RUIC

Record Owner’s UIC

86-88

DTR

Defense Transportation Regulation Codes

89-99

FILLER

Blanks

100-103

ICAO

International Civil Aviation Organization Code

104-112

FILLER

Blanks

113-118

UPDATE

Date Of Last Update

119-124

ADATE

Date Record Added

125-130

CDATE

Date Record Canceled

131-145

COSNM

Country/State Name

146-146

GEOAOR

Geographic Area of Responsibility Code

147-147

RECSTAT

Record Status

148-148

RECCLAS

Record Classification

149-156

FILLER

Blanks

Table A-A-2. ASCII File Format for GEOFILE Database

A-A-3

Appendix

Enclosure A

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

ENCLOSURE B

INSTALLATION TYPE CODES

This enclosure contains the codes, names, and descriptions of authorized

installation type codes. Only those geographic locations and military

installations meeting the purpose and scope of the file will be added to this list.

Recommended additions, deletions, and changes to the list should be referred

to the Joint Staff, J-39/CSOD for evaluation in coordination with other users of

the GEOFILE.

INSTALLATION TYPE CODES

CODE

NAME

DESCRIPTION

ABS

Air Base

An installation from which operations can be

conducted and/or that is capable of providing

sustained support for major activities of importance

to Air Force combat, combat support, and training

missions. Usually applied to installations located in

a foreign country where the name cannot indicate

permanency.

ADM

Administration

An installation not part of a larger installation (such

as an Air Force base) used for the management and

execution of all military matters not included in

tactics and strategy primarily in the fields of logistic

and personnel management. Included under this

description are such items as police, postal, plant

representation, development, unit administration,

attaché, and foreign mission, including regional

offices.

AFB

Air Force Base

An installation from which operations can be

conducted and/or that is capable of providing

sustained support for major activities of importance

to Air Force combat, combat support, and training

missions. Usually applied to permanent installations

located within the United States.

AFD

Airfield

A primary or auxiliary installation with an aircraft

operating area in which the Department of Defense

and others have concurrent use of the real property

involved, and the designation “airfield” is in general

use by a civil, commercial, or governmental service

agency or foreign country.

B-9

Enclosure B

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

INSTALLATION TYPE CODES

CODE

NAME

DESCRIPTION

AFS

Air Force Station

An installation without an aircraft operating area

that, as its primary mission, supports a function of

the radar or communications system, supply, major

headquarters, or other non-flying functions

approved by HQ USAF.

AGB

Air National

A base with an aircraft operating area used

Guard Base

exclusively by the Air National Guard.

AGS

Air National

A station without an aircraft operating area used

Guard Station

exclusively by the Air National Guard.

AIN

An Army installation not elsewhere described in this

Army Installation

list.

AMO

Ammunition

A facility for storing ammunition, ordnance, or

Storage

explosive material.

ANX

Annex

A facility for miscellaneous functions, such as

garages, parking, motor pool, gap fillers, and guard

compounds.

APT

Airport

An installation with an active aircraft operating area

not meeting the criteria to be an international

airport, a civil airport (CAP), a joint use airport, or a

military airport and having natural or permanent-

type surface runway. Airfields under construction

with no runway yet usable are included in this

category.

ARB

Air Force Reserve

An AFB with an aircraft operating area used

Base

exclusively by the Air Force Reserve. Usually applied

to permanent installations located within the United

States.

ARP

Air Refueling Point

A point at the beginning of an aircraft’s air refueling

operations. This point will usually be the air

refueling track’s initial point (IP), entry point (EP),

anchor navigation point (AN). The specific type of

point will depend on the characteristics of the air

refueling track identified.

ARS

Air Force Reserve

An Air Force station without an aircraft operating

Station

area used exclusively by the Air Force Reserve.

Usually applied to permanent installations located

within the United States.

B-9

Enclosure B

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

INSTALLATION TYPE CODES

CODE

NAME

DESCRIPTION

ASN

Air Station

An installation without aircraft operating areas that,

as its primary mission, supports a function of major

headquarters, radar or communications systems,

supply, or other non-flying functions. Usually

applies to installations located in a foreign country

where the name cannot indicate permanency.

ATM

Air Terminal

An installation provided with the facilities for

loading and unloading aircraft and the transit

handling of traffic (passengers, cargo, and mail)

moved by aircraft. The term “air terminal” is

generally used by civil, commercial, or a

governmental service agency or foreign country

where the U.S. Government has concurrent use of

real property.

BAY

Bay

A recess in the shore or an inlet of a sea between

two capes or headlands -- not as large as a gulf but

larger than a cove.

BHG

Housing for single military personnel, including

Bachelor Housing

transient quarters.

CAP

Civil Airport

An installation with an active aircraft operating area

not meeting the criteria to be called an international

airport but controlled and operated by civil

authorities. Civil aircraft primarily uses it, although

the military may have landing privileges and/or

contract rights. Minimum facilities are available

that include a control tower or some similar control

system, such as a flight service station (FSS) that

issues clearances and advises when there is no

tower or the tower is not in operation. The FSS can

also have a remote communication outlet or can be

collocated with an aeronautical advisory station.

The Common Air Traffic Advisory Frequency advises

on known traffic around airfields with no tower.

Lighting (may be flare pots, etc.), petroleum, oils,

and lubricants (POL), and facilities for first-echelon

maintenance or better must also be available.

CGI

Coast Guard

A Coast Guard installation not elsewhere described

Installation

in this list.

B-9

Enclosure B

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

INSTALLATION TYPE CODES

CODE

NAME

DESCRIPTION

CHL

Channel

1. A natural or artificial waterway that either

periodically or continuously contains moving water,

or forms a connecting link between two bodies of

water. 2. The deepest portion of a stream, bay, or

strait through which the main volume or current of

water flows.

CHP

Civil Heliport

A permanent landing area used for civilian

helicopter operations.

CLN

Clinic

A facility for providing general clinic (outpatient)

services, primarily for active duty military

personnel. Subject to the availability of space and

facilities and capabilities of the medical staff,

provides general clinic services for other authorized

persons as prescribed by title 10, U.S. Code, and

other current directives.

CNL

Canal

1. An artificial watercourse cut through land.

2. A long narrow arm of the sea extending inland,

between islands, or between islands and the

mainland.

COC

Command

A facility from which a commander or his or her

Operations Center

representatives direct operations and control forces.

It is organized to gather, process, analyze, display,

and disseminate planning and operational data and

to perform other related tasks.

COM

Communication

For ground-to-ground, ground-to-air, radio,

Strategic

telephone, or other communications, except radio

relay or repeat functions (see radio relay).

CPE

Cape

A point or head of land projecting into a sea or other

body of water.

CTY

City

A geographical location within a city or the

metropolitan area of a city.

DEP

Depot

An installation with a primary mission to support

an activity for the receipt, classification, storage,

accounting, issue, maintenance, procurement,

manufacture, assembly, research, salvage, or

disposal of material.

B-9

Enclosure B

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

INSTALLATION TYPE CODES

CODE

NAME

DESCRIPTION

DFP

Defense Fuel

An installation under the jurisdiction of the Defense

Support Point

Logistics Agency engaged in receiving, processing,

and shipping of bulk petroleum products.

DOC

Dock

A pier, wharf, or boat dock.

DSS

Deep Space

A facility used to collect deep-space metric track

Surveillance

and deep-space space object identification data.

Facility

Ground-based electro-optical deep-space

surveillance.

DZC

Drop Zone Center

A point representing the designated air point for the

Point

drop zone or the geographic center of the drop zone.

FHG

Family Housing

Family or dependent housing, including transient

family quarters.

GLF

Gulf

A large embayment in the coast in which the

entrance generally is wider than the length.

HSP

Hospital

An installation with the capability of providing

inpatient medical treatment.

IAP

International

An installation with an active aircraft operating area

Airport

meeting the criteria established by the ICAO to be

designated as an international airport.

(Any airport

designated by the contracting state as an airport of

entry and departure for international air traffic,

where the formalities of customs, immigration,

public health, animal and plant quarantine, and

similar procedures are carried out.)

JAP

Joint-Use Airport

An installation with an active aircraft operating area

not meeting the criteria to be called an international

airport, but is jointly controlled, used and/or

operated by both civil and military agencies. The

military agencies must be permanent operational

flight line tenants, with or without the aircraft

stationed on the airport. Facilities are the same as

for CAPs.

LKE

Lake

An inland body of water, usually fresh water,

formed by glaciers, river drainage, etc., larger than a

pool or pond.

B-9

Enclosure B

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

INSTALLATION TYPE CODES

CODE

NAME

DESCRIPTION

MAP

Military Airport

An installation with an active aircraft operating area

not meeting the criteria to be called an international

airport, but is an active military airfield controlled

and operated by military authorities. It is primarily

for use by military aircraft, although civil aircraft

may have landing privileges and/or contract rights.

Facilities are the same as for CAPs.

MAS

Marine Corps Air

An installation from which operations can be

Station

conducted and that is capable of providing

sustained support for major activities of importance

to Marine Corps operations, sustainment, combat

support, and training missions. Can be applied to

permanent installations located both in CONUS and

OCONUS.

MBK

Marine Barracks

Provides such security as approved by the Chief of

Naval Operations or Commandant of the Marine

Corps.

MCC

Marine Corps

Provides training facilities, logistic support, and

Camp

limited administrative support for Fleet Marine

Force units.

MFC

Maintenance

For maintenance functions at other than depot or

plant level.

MGI

A Marine Corps ground installation.

Marine Ground

Installation

MHP

Military Heliport

A permanent landing area used for military

helicopter operations. Also applies to joint military-

civil use.

MSL

Missile

A separate but not self-sustaining installation used

by operational units for the assembly, launch,

guidance, etc., of air defense, tactical, or strategic

missiles.

MTK

Missile Tracking

An installation or facility used for electronic or

Site

optical tracking of missiles during research, testing,

and/or development phases.

NAC

Naval Activity

An installation officially designated a naval activity.

B-9

Enclosure B

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

INSTALLATION TYPE CODES

CODE

NAME

DESCRIPTION

NAS

Naval Air Station

An installation from which operations can be

conducted and that is capable of providing

sustained support for major activities of importance

to Navy operations, sustainment, combat support,

and training missions. Can be applied to

permanent installations located both in CONUS and

OCONUS.

NAV

NAVAID Site

An installation providing navigational aid, either

visually or electronically, such as a TACAN, VOR,

ILS Marker, and BEACON, LORAN.

NBA

Naval Base

A naval installation officially designated a naval

base.

NYI

A Navy installation not elsewhere describe in this

Navy Installation

list.

OCN

Ocean

1. The intercommunicating body of salt water

occupying the depressions of the earth's surface.

2. One of the major primary subdivisions of the

above, bounded by continents, the equator, and

other imaginary lines.

OPA

Operating Area

A defined area of operation for exercises, war games,

or real world.

POL

POL Retail

A facility for receiving, processing, and shipping

Distribution

bulk petroleum products. Primarily for depot-level

Station

storage and resupply.

PRT

Port

An installation at which ships may discharge or

receive cargo. The term “port” should not be used in

conjunction with air facilities designated as aerial

ports or airports, etc.

PSG

Passage

A narrow navigable pass or channel between two

landmasses or shoals.

RBS

Radar Bomb

Facilities supporting radar bomb scoring

Scoring

detachments and equipment.

REC

Recreation

A recreation facility of any sort.

RPA

Rural Populated

An unincorporated area.

Area

B-9

Enclosure B

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

INSTALLATION TYPE CODES

CODE

NAME

DESCRIPTION

RRC

Radar Receiver

A site whose primary mission is the operation of a

radar receiver and that exists apart from any major

military installation.

RRJ

Railroad Junction

A railhead or railroad junction.

RRL

Radio Relay

A site primarily occupied by a radio relay,

microwave relay, and repeater equipment, manned

or unmanned.

RSC

Research Facility

An installation having a primary function of

or Center

increasing knowledge of natural phenomena,

environment, and the solution of problems in the

field of science.

RTC

Reserve Training

A facility for training nonassigned Reserve

Center

personnel.

RTR

Radar Installation

A site whose primary mission is the operation of

radar transmitting arrays or receivers existing apart

from any major military installation.

SCH

School

A Service or dependents’ school.

SEA

Sea

A subdivision of an ocean. All seas except inland

seas are physically interconnected parts of the

earth's total salt water system. Two types are

distinguished, Mediterranean and adjacent.

Mediterranean seas are groups of seas, collectively

separated from the major water body as an

individual sea. Adjacent seas are those connected

individually to the larger body.

STG

Storage

A facility primarily used for storing other than

ammunition, explosive, or POL supplies having no

depot functions.

STR

Strait

A narrow sea channel separating two landmasses.

SVC

Service

A facility primarily used for personnel services,

troop or dependents, such as post or base exchange

facilities, commissaries, Service clubs,

noncommissioned officers’ clubs, officers’ clubs, or

bus station.

B-9

Enclosure B

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

INSTALLATION TYPE CODES

CODE

NAME

DESCRIPTION

TNG

Training

Any type of training installation not elsewhere

described in this list.

TST

Test Annex

Facilities used in direct support of equipment and

personnel required for testing materiel and systems.

WAE

Weather Station

An installation for the collection, processing, or

dissemination of weather data (except an

installation collecting such data for research only).

WSS

Water System

Water supply facilities, including wells, reservoirs,

water pipelines, filter plants, pumping stations, etc.

B-9

Enclosure B

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

APPENDIX A TO ENCLOSURE C

DATA ELEMENT: COUNTRIES OF THE WORLD

DATA ITEM NAME

CODE

AFGHANISTAN

AKROTIRI SOVEREIGN BASE AREA **

ALBANIA

ALGERIA

AMERICAN SAMOA **

ANDORRA

ANGOLA

ANGUILLA

ANTARCTICA **

ANTIGUA AND BARBUDA

ARGENTINA

ARMENIA

ARUBA

ASHMORE AND CARTIER ISLANDS **

AUSTRALIA **

AUSTRIA **

AZERBAIJAN

BAHAMAS, THE ** (AJA BAHAMAS)

BAHRAIN

BAKER ISLAND **

BANGLADESH

BARBADOS

BASSAS DA INDIA **

BELARUS

C-A-11

Appendix A

Enclosure C

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

DATA ITEM NAME

CODE

BELGIUM

BELIZE

BENIN

BERMUDA

BHUTAN

BOLIVIA, (AKA PLURINATIONAL STATE OF BOLIVIA) *

BOSNIA AND HERZEGOVINA

BOTSWANA

BOUVET ISLAND

BRAZIL

BRITISH INDIAN OCEAN TERRITORY

BRUNEI, (AKA BRUNEI DARUSSALAM) *

BULGARIA

BURKINA FASO **

BURMA, (AKA MYANMAR)

BURUNDI

CAMBODIA

CAMEROON

CANADA

CAPE VERDE

CAYMAN ISLANDS

CENTRAL AFRICAN REPUBLIC

CHAD

CHILE

CHINA

CHRISTMAS ISLAND

C-A-11

Appendix A

Enclosure C

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

DATA ITEM NAME

CODE

CLIPPERTON ISLAND **

COCOS (KEELING) ISLANDS

COLOMBIA

COMOROS

CONGO (BRAZZAVILLE), (AKA CONGO) *

CONGO (KINSHASA), (AKA THE DEMOCRATIC

REPUBLIC OF THE CONGO)*

COOK ISLANDS

CORAL SEA ISLANDS **

COSTA RICA **

CÔTE D’IVOIRE *

CROATIA

CUBA

CYPRUS

CZECH REPUBLIC

DENMARK

DHEKELIA SOVEREIGN BASE AREA **

DJIBOUTI

DOMINICA

DOMINICAN REPUBLIC

ECUADOR

EGYPT

EL SALVADOR

EQUATORIAL GUINEA

ERITREA

ESTONIA

ETHIOPIA

C-A-11

Appendix A

Enclosure C

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

DATA ITEM NAME

CODE

ETOROFU, HABOMAI, KUNASHIRI AND SHIKOTAN

ISLANDS **

EUROPA ISLAND **

FALKLAND ISLANDS (ISLAS MALVINAS), (AKA

FALKLAND ISLANDS (MALVINAS)) *

FAROE ISLANDS

FIJI

FINLAND

FRANCE

FRENCH GUIANA

FRENCH POLYNESIA

FRENCH SOUTHERN AND ANTARCTIC LANDS, (AKA

FRENCH SOUTHERN TERRITORIES) *

GABON

GAMBIA

GAZA, (AKA PALESTINIAN TERRITORY, OCCUPIED)

GEORGIA

GERMANY

GHANA

GIBRALTAR

GLORIOSO ISLANDS

GREECE

GREENLAND

GRENADA

GUADELOUPE

GUAM

GUATEMALA

GUERNSEY

C-A-11

Appendix A

Enclosure C

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

DATA ITEM NAME

CODE

KENYA

KINGMAN REEF

KIRIBATI

KOREA, (NORTH), (AKA DEMOCRATIC PEOPLE’S

REPUBLIC OF KOREA)

KOREA, (SOUTH), (AKA REPUBLIC OF KOREA)

KOSOVO **

KUWAIT

KYRGYZSTAN

LAOS, (AKA LAO PEOPLE’S DEMOCRATIC REPUBLIC)

LATVIA

LEBANON

LESOTHO

LIBERIA

LIBYA, (AKA LIBYAN ARAB JAMAHIRIYA)*

LIECHTENSTEIN

LITHUANIA

LUXEMBOURG

MACAO

MACEDONIA, (AKA THE FORMER YUGOSLAV REPUBLIC

OF MACEDONIA)

MADAGASCAR

MALAWI

MALAYSIA

MALDIVES

MALI

MALTA

C-A-11

Appendix A

Enclosure C

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

DATA ITEM NAME

CODE

SAINT LUCIA

SAINT MARTIN

SAINT PIERRE AND MIQUELON

SAINT VINCENT AND THE GRENADINES

SAMOA

SAN MARINO

SAO TOME AND PRINCIPE

SAUDI ARABIA

SENEGAL

SERBIA

SEYCHELLES

SIERRA LEONE

SINGAPORE

SLOVAKIA

SLOVENIA

SOLOMON ISLANDS

SOMALIA

SOUTH AFRICA

SOUTH GEORGIA AND THE SOUTH SANDWICH ISLANDS

SPAIN

SPRATLEY ISLANDS

SRI LANKA

SUDAN

SURINAME

SVALBARD, (AKA SVALBARD AND JAN MAYEN)

SWAZILAND

C-A-11

Appendix A

Enclosure C

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

DATA ITEM NAME

CODE

SWEDEN

SWITZERLAND

SYRIA, (AKA SYRIAN ARAB REPUBLIC)

TAIWAN, (AKA TAIWAN PROVINCE OF CHINA)

TAJIKISTAN

TANZANIA, (AKA UNITED REPUBLIC OF TANZANIA)

THAILAND

TIMOR-LESTE

TOGO

TOKELAU

TONGA

TRINIDAD AND TOBAGO

TROMELIN ISLAND **

TUNISIA

TURKEY

TURKMENISTAN

TURKS AND CAICOS ISLANDS

TUVALU

UGANDA

UKRAINE

UNITED ARAB EMIRATES (UAE)

UNITED KINGDOM

UNITED STATES

UNITED STATES MINOR OUTLYING ISLANDS *

URUGUAY

UZBEKISTAN

C-A-11

Appendix A

Enclosure C

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

APPENDIX C TO ENCLOSURE C

DATA ELEMENT: WATER BODIES OF THE WORLD

DATA ITEM NAME

ABBREVIATION

CODE

ADRIATIC SEA

ADRTC SEA

AEGEAN SEA

AGEN-SEA

ALBORAN SEA

ALBRN-SEA

AMUNDSEN SEA

AMDSN-SEA

ANDAMAN SEA

ADMN-SEA

ARABIAN SEA

ARB-SEA

ARAFURA SEA

ARFUR-SEA

ARAL SEA

ARAL-SEA

ARCTIC OCEAN

ARTC OCN

BAFFIN BAY

BAFN-BAY

BALEARIC SEA

BALRC-SEA

BALI SEA

BALI-SEA

BALTIC SEA

BLTC-SEA

BANDA SEA

BANDA-SEA

BARENTS SEA

BRNTS-SEA

BASS STRAIT

BASS-STR

BAY OF BENGAL

BAY-BNGL

BAY OF BISCAY

BAY-BSCY

BAY OF FUNDY

BAY-FDY

BEAUFORT SE

BUFRT-SEA

BELLINGSHAUSEN SEA

BLGHSN-SEA

C-C-6

Appendix C

Enclosure C

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

DATA ITEM NAME

ABBREVIATION

CODE

BERING SEA

BER-SEA

BERING STRAIT

BER-STR

BISMARCK SEA

BSMRK-SEA

BLACK SEA

BLK-SEA

BOSPORUS

BSPRS

BRISTOL CHANNEL

BRSTL-CHNL

CARIBBEAN SEA

CRBN-SEA

CASPIAN SEA

CSPN-SEA

CELEBES SEA

CLEBS-SEA

CERAM SEA

CERAM-SEA

CHUKCHI SEA

CKCHI-SEA

COASTAL WATERS OF

CSTL-WTR-ALS

SOUTHEAST ALASKA AND

BRITISH COLUMBIA

CORAL SEA

CORAL-SEA

DARDANELLES

DRDNLS

DAVIS STRAITR

DVS-ST

DENMARK STRAIT

DENMK-STR

DRAKE PASSAGE

DRK-PSG

EAST CHINA SEA

E-CHI-SEA

EAST SIBERIAN SEA

E-SBRN-SEA

ENGLISH CHANNEL

ENGH-CHNL

FLORES SEA

FLRS-SEA

FORMOSA STRAIT

FMSA-STR

C-C-6

Appendix C

Enclosure C

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

DATA ITEM NAME

ABBREVIATION

CODE

GREAT AUSTRALIAN BIGHT

GT-AUSTLN-BHT

GREENLAND SEA

GRNLND-SEA

GULF OF ADEN

GLF-ADEN

GULF OF ALASKA

GLF-ALS

GULF OF ANADYR

GLF-ADYR

GULF OF AQABA

GLF-AQB

GULF OF BONE

GLF-BONE

GULF OF BOTHNIA

GLF-BTHNA

GULF OF CALIFORNIA

GLF-CAL

GULF OF CARPENTARIA

GLF-CRPNTA

GULF OF CHIHLI

GLF-CHLI

GULF OF FINLAND

GLF-FINI

GULF OF GUINEA

GLF-GUIN

GULF OF LION

GLF-LION

GULF OF MEXICO

GLF-MEX

GULF OF OMAN

GLF-OMAN

GULF OF RIGA

GLF-RIGA

GULF OF ST. LAWRENCE

GLF-ST-L

GULF OF SAKHALIN

GLF-SAKHLN

GULF OF SAN JORGE

GLF-SAN-JRG

GULF OF SAN MATIAS

GLF-SAN-MTAS

GULF OF SIAM

GLF-SIAM

GULF OF SUEZ

GLF-SUEZ

C-C-6

Appendix C

Enclosure C

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

DATA ITEM NAME

ABBREVIATION

CODE

GULF OF TATARY

GLF-TARY

GULF OF TOMINI

GLF-TMNI

GULF OF TONKIN

GLF-TNKN

HALMAHERA SEA

HLMRA-SEA

HUDSON BAY

HUDN-BAY

HUDSON STRAIT

HUDN-STR

INDIAN OCEAN

INDN-OCN

INLAND SEA

INL-SEA

INNER SEAS (WEST COAST OF

INNER-SEAS

SCOTLAND)

IONIAN SEA

IOAN-SEA

IRISH SEA

IRISH-SEA

JAVA SEA

JAVA-SEA

KARA SEA

KARA-SEA

KATTEGAT

KTGAT

KOREA BAY

KOR-BAY

LABRADOR SEA

LBDR-SEA

LACCADIVE SEA

LACDV-SEA

LAKE ERIE

LK-ERIE

LAKE HURON

LK-HRN

LAKE MICHIGAN

LK-MICH

LAKE ONTARIO

LK-ONT

LAKE SUPERIOR

LK-SUPR

LAPTEV SEA

LPTV-SEA

C-C-6

Appendix C

Enclosure C

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

DATA ITEM NAME

ABBREVIATION

CODE

LIGURIAN SEA

LGURN-SEA

LINCOLN SEA

LCLN-SEA

LUZON STRAIT

LZN-STR

MAKASSAR STRAIT

MKSR-STR

MALACCA STRAIT

MALCA-STR

MEDITERRANEAN, EASTERN

E-MED-SEA

MEDITERRANEAN, WESTERN

W-MED-SEA

MOLUCCA SEA

MLUCA-SEA

MOZAMBIQUE CHANNEL

MOZB-CHNL

NORTH ATLANTIC OCEAN

N-ATL-OCN

NORTH PACIFIC OCEAN

N-PAC-OCN

NORTH SEA

N-SEA

NORTHWEST PASSAGE

NW-PSG

NORWEGIAN SEA

NRWGN-SEA

PANAMA CANAL

PNMA-CNL

PERSIAN (ARABIAN) GULF

PERSN-GLF

PHILIPPINE SEA

PHIL-SEA

RED SEA

RED-SEA

RIO DE LA PLATA

RIO-PLTA

ROSS SEA

ROSS-SEA

ST. GEORGES CHANNEL

ST-GRGS-CHNL

ST. LAWRENCE SEAWAY

ST-LAWR-SEAW

SAVU SEA

SAVU-SEA

C-C-6

Appendix C

Enclosure C

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

DATA ITEM NAME

ABBREVIATION

CODE

SCOTIA SEA

SCTA-SEA

SEA OF AZOV

SEA-AZV

SEA OF JAPAN

SEA-JPN

SEA OF MARMARA

SEA-MRMRA

SEA OF OKHOTSK

SEA-OKHIK

SHELEKOVA GULF

SHLKHV-GLF

SINGAPORE STRAIT

SGPOR-STR

SKAGERRAK

SKGRK

SOLOMON SEA

SOLM-SEA

SOUTH ATLANTIC OCEAN

S-ATL-OCN

SOUTH CHINA SEA

S-CHI-SEA

SOUTH PACIFIC OCEAN

S-PAC-OCN

STRAIT OF GIBRALTAR

STR-GBRLTR

SUEZ CANAL

SUEZ CNL

SULU SEA

SULU-SEA

TASMAN SEA

TASM-SEA

TIMOR SEA

TIMOR-SEA

TYRRHENIAN SEA

TYRN-SEA

WEDDELL SEA

WEDL-SEA

WHITE SEA

WHT-SEA

YELLOW SEA

YLOW-SEA

C-C-6

Appendix C

Enclosure C

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

ENCLOSURE D

LOGISTIC PLANNING AND REPORTING CODES

1. This enclosure contains the two-character alphanumeric logistic planning

and reporting (LPR) codes and their associated explanations used by the

military logistic community. LPR codes generally follow the geographical

boundaries outlined in the current version of the Unified Command Plan (UCP)

shown below and in reference g. For logistic planning purposes, these areas

are further broken down into subareas, as defined in this section.

Figure D-1. The World with Combatant Commanders’ AORs

D-1

Enclosure D

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

2. The LPR code for USCENTCOM is 1Z. Subarea codes are in Table D-1 and

are depicted in Figure D-2.

CODE

SUBAREA

Kazakhstan, Uzbekistan, Tajikistan, Kyrgyzstan, and Turkmenistan

The area including the Gulf of Oman, the Gulf of Aden, the Arabian Sea, and

the portion of the Indian Ocean from 68ºE. to 5ºS., and northwest to the

Kenya and Tanzania coastal border.

Egypt and the Red Sea

Saudi Arabia, Yemen, Oman, Kuwait, Persian Gulf, Jordan, Bahrain, United

Arab Emirates, Qatar, Iraq, Syria, and Lebanon

Iran, Pakistan, and Afghanistan

Table D-1. Subarea LPR Codes for USCENTCOM

D-2

Enclosure D

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

3. The LPR code for USNORTHCOM is 3Z. Subarea codes are listed in Table

D-2 and are depicted in Figure D-3.

CODE

SUBAREA

Eastern CONUS (includes FEMA Regions 1 through 4 (see Figure D-4 for

FEMA Regions) and the U.S. staging area for the Arctic)

Western CONUS (includes FEMA Regions 8 through 10 less Hawaii and

Alaska]

Mid-CONUS (includes FEMA Regions 5 through 7)

Eastern Canada (includes Manitoba, Ontario, Quebec, New Brunswick, Nova

Scotia, Prince Edward Island, and Newfoundland)

Mexico, Lower California (includes Gulf of California), and the Gulf of Mexico

out to a line joining the tip of Florida and the tip of the Yucatan Peninsula

Western Canada (includes Saskatchewan, Alberta, British Columbia, and

Yukon)

The waters of the Arctic Ocean, Beaufort Sea, and Lincoln Sea (bounded on

the North by the North Pole, on the east by 45ºW; on the south by

Greenland, Canada’s Northwest Territory, and 68ºN; and on the west by

170ºW).

An area including all of Alaska, the Aleutian Islands, the Bering Sea east of

USPACOM, and the waters of the Gulf of Alaska down to 50ºN between

180ºW and the west coast of Canada. (Note: Forces in Alaska remain

assigned to USPACOM. Territory in Alaska is assigned to USNORTHCOM for

homeland security mission.)

The waters of the North Pacific Ocean bounded on the east by the U.S. west

coast, Mexico, and 92ºW; on the south by 8ºN; on the west by USPACOM;

and on the north by 50ºN (excludes the Gulf of California).

An area bounded on the north by 50ºN, Newfoundland, and eastern Canada

(includes the Gulf of St. Lawrence); on the east by 45ºW; on the south by

USSOUTHCOM; and on the west by the eastern United States and a line

joining the tip of Florida and the tip of the Yucatan Peninsula).

An area bounded on the north by the limits of Baffin Bay; on the east by

Greenland and USEUCOM; on the south by 50ºN; and on the west by the

coast of Canada.

All of the Northwest Territory.

Table D-2. Subarea LPR Codes for USNORTHCOM

D-4

Enclosure D

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

4. For certain planning and reporting purposes, it is necessary to identify the

coastal subareas of CONUS. The coastal subareas, divided into three

geographical areas, are East Coast, Gulf Coast, and West Coast. For ready

reference, the principal ports, Army ports of embarkation, and aerial ports of

embarkation located within each subarea are listed in the Table D-3. FEMA

regional boundaries are depicted in Figure D-4.

SUBAREA LPR CODES FOR East Coast

CODE

SUBAREA

New England (Canadian Border to New York Port): Bath, Casco Bay, Portland, and Searsport,

Maine; Boston, Fall River, Gloucester, and New Bedford, Massachusetts; Bridgeport, New Haven,

New London, and Stamford, Connecticut; Davisville, Newport, and Providence, Rhode Island; and

Portsmouth, New Hampshire

Greater New York Port (Extended): Albany, Brooklyn, and New York, New York; and Bayonne,

Caven Point, Earle, Elizabethport, and Port Newark, New Jersey

Middle Atlantic Coast (New York Port to Hampton Roads): Baltimore and Piney Point, Maryland;

Camden, Gloucester, Trenton, and McGuire AFB, New Jersey; Chester and Philadelphia,

Pennsylvania; and Delaware City, Dover AFB, Lewes, and Wilmington, Delaware

Hampton Roads: Hampton Roads Army Terminal, Newport News, Norfolk, Portsmouth, and

Richmond, Virginia

South Atlantic Coast (Hampton Roads to Key West): Beaufort, Morehead City, Southport, and

Wilmington, North Carolina; Brunswick, Kingland, and Savannah, Georgia; Charleston,

Charleston AFB, and Georgetown, South Carolina; and Fernandina, Jacksonville, Miami, Palm

Beach, and Port Everglades, Florida

SUBAREA LPR CODES FOR Gulf Coast

CODE

SUBAREA

Eastern Gulf Coast (Key West to New Orleans): Gulfport and Pascagoula, Mississippi; Mobile,

Alabama; and Panama City, Pensacola, Port St. Joe, Tampa, and St. Petersburg, Florida

New Orleans Port Area: Baton Rouge, Braithwaite, Chalmette, New Orleans Army Terminal, New

Orleans, and St. Rose, Louisiana

Western Gulf Coast (New Orleans to Mexican Border): Lake Charles, Louisiana; and Beaumont,

Brownsville, Corpus Christi, Freeport, Galveston, Houston, Orange, Port Arthur, Port Isabel, and

Texas City, Texas

SUBAREA LPR CODES FOR West Coast

CODE

SUBAREA

South California (Mexican border to San Francisco Bay): Estero Bay, Los Angeles, Long Beach,

Port Hueneme, San Diego, and San Pedro, California

San Francisco Bay: Alameda, Concord, Oakland, Oakland Army Terminal, Stockton, Rough and

Ready Island, Sacramento, San Francisco, Richmond, and Travis AFB, California

Pacific Northwest (San Francisco Bay to Canadian Border): Astoria and Portland, Oregon;

Bellingham, Bremerton, Everett, Gray’s Harbor, Longview, McChord AFB, Olympia, Port Angeles,

Seattle, Tacoma, and Vancouver, Washington; and Vancouver, British Columbia

Table D-3. Subarea LRP Codes for East Coast, Gulf Coast, and West Coast

D-6

Enclosure D

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

5. The LPR code for USEUCOM is 4Z. Subarea codes are in Table D-4 and are

depicted in Figure D-5.

CODE

SUBAREA

An area of the North Atlantic Ocean bounded on the north by 59ºN; on the east by

12ºW and the coast of Africa (Western Sahara and Mauritania); on the south by

18ºN; and on the west by 45ºW (USNORTHCOM). Replaces LPR subarea codes 2F

and 2K.

Greenland, Iceland, and adjacent waters to their north, east, and south (bounded

by the North Pole, 12ºW and 59 º N).

The Barents Sea, Kara Sea, and Arctic Ocean between 30ºE and 100ºE (Figure D-7)

Russia west of 60ºE (i.e., the Ural Mountains), including offshore islands, all of

Novaya Zemla Island in the Barents Sea, and the Caspian Sea.

Russia between 60ºE and 100ºE, including offshore islands.

Russia east of 100ºE, including offshore islands.

Norway

Germany, Belgium, the Netherlands, and Luxembourg

Denmark and the Baltic Sea west of 16ºE, United Kingdom, Ireland, the Irish Sea

(includes the Isle of Man), North Sea, English Channel (includes Guernsey and

Jersey), Celtic Sea, Bay of Biscay, and North Atlantic Ocean (bounded on the north

by 59ºN and on the west by 12ºW)

France and Monaco

Andorra, Portugal, Spain, Gibraltar, and the Mediterranean Sea west of 8ºE

Italy, San Marino (an enclave in central Italy), the Holy See (Vatican City), Malta,

and the Mediterranean Sea between 8ºE and 20ºE (west of a line drawn from the

coast of Libya at 20ºE to the coast where Albania and Greece meet)

Greece, Turkey, Cyprus, the Black Sea, and the Mediterranean Sea East of area 4P

Sweden, Finland, Latvia, Estonia, Lithuania, and the Baltic Sea, excluding the area

designated in 4J

Poland, Slovakia, the Czech Republic, Switzerland, Austria, Hungary, and

Liechtenstein

Yugoslavia (Serbia & Montenegro) Croatia, Bosnia & Herzegovina, Macedonia,

Slovenia, Albania, Romania, and Bulgaria

Israel

Moldova, Ukraine, Belarus, Georgia, Armenia, Azerbaijan, and the Sea of Azov

An area of the Greenland Sea, Barents Sea, and the Arctic Ocean bounded on the

north by the North Pole, on the east by 30ºE, on the south by the coast of Norway

and 59ºN, and on the west by 12ºW. Includes Svalbard, Jan Mayen, and Faroe

Islands.

Table D-4. Subarea LPR Codes for USEUCOM

D-8

Enclosure D

FOR OFFICIAL USE ONLY

CJCSM 3150.15C

20 November 2009

6. The LPR code for USPACOM is 5Z. Subarea codes are in Table D-5 and are

depicted in Figure D-6.

CODE

SUBAREA

An area bounded on the north by 30ºN; on the east by 180ºE; on the south by the Equator; and on

the west by 160ºE

An area including Taiwan, the Philippine Islands, Hong Kong, the Philippine Sea, the South China

Sea, Burma (Myanmar), Thailand, Cambodia, Vietnam, Laos, Malaysia, Singapore, Indonesia, and

surrounding ocean areas (generally bounded on the north by Southeast Asia and 30ºN; on the east

by 130ºE; on the south by areas 5E and 5S; and on the west by 90ºE)

An area including Australia and the surrounding ocean area between the northern coast of Australia

and 45ºS and between 160ºE and 110ºE

An area bounded on the north by the Equator; on the east by 135ºW; on the south by 30ºS; and on

the west by 165ºE

An area bounded on the north by 30ºN; on the east by 160ºE; on the south by the Equator; and on

the west by 130ºE

An area including Japan, Korea, and adjacent ocean areas from 160ºE to the China mainland, south

to 30ºN; and area 5C and 5G

An area bounded on the north by the Russian mainland; on the east by 180º and USNORTHCOM;

on the south by 30ºN; and on the west by 160ºE

An area bounded on the north by 50ºN; on the east by USNORTHCOM; on the south by 30ºN; and

on the west by 180º

An area bounded on the north by 30ºN; on the east by USNORTHCOM and 120ºW; on the south by

the Equator; and on the west by 180º

An area bounded on the north by USNORTHCOM and 8ºN; on the east by 92ºW; on the south by the

Equator; and on the west by 120ºW

An area bounded on the north by the Equator; on the east by 92ºW; on the south by 30ºS; and on

the west by 135ºW

An area bounded on the north by 90ºN (North Pole); on the east by 170ºW; on the south by the

north coast of Russia (including offshore islands); and on the west by 100ºE

An area bounded on the north by areas 53 and 5C; on the east by areas 5E and 160ºE; on the south

by the South Pole; and on the west by 68ºE (includes Antarctica between 68ºE. and 160ºE)

An area bounded on the north by the Equator; on the east by 165ºE; on the south by 30ºS; and on

the west by Australia and 130ºE

New Zealand and surrounding ocean areas (bounded on the north by 30ºS; on the east by 165ºW;

on the south by 50ºS; and on the west by 160ºE)

An area bounded on the north by 30ºS; on the east by 92ºW and the coast of Antarctica between

27ºW. and 92ºW; on the south by the South Pole; and on the west by 160ºE

An area bounded on the north by the coast of India (less Sri Lanka); on the east by area 5D; on the

south by the Equator; and on the west by 68ºE

Sri Lanka, Bangladesh, India, Bhutan, and Nepal

The Peoples Republic of China and Mongolia

Table D-5. Subarea LPR Codes for USPACOM

D-10

Enclosure D

Military reference books and manuals (2009-2023, Volume 5) - page 14
