DB2 Server for VSE & VM Application Programming (Version 7 Release 5)

* prep parameters for program SAMPLE

ISOL(CS)

*cursor stability isolation level

TIME(ISO)

BLOCK

*indicate inserts and retrieves in groups

Figure 29. An Example of a Preprocessor Option File

Using the Flagger at Preprocessor Time

The Flagger is invoked at preprocessor time by the optional parameter SQLFLAG

It provides an auditing function on the static SQL statements in the host program.

This function is independent of the other preprocessor functions, and has no

bearing on whether the preprocessor run will complete satisfactorily.

The audit compares the static SQL statements with the SAA standard or the

SQL-89 standard. SQL-89 is a collective term that implies support of SQL as

defined by the Federal Information Processing Standards (FIPS) 127-1. It includes:

v ANSI X.3.135-1989 (without the Integrity Enhancement feature)

v ANSI X.3.168-1989

v ISO 9075-1989 (without the Integrity Enhancement feature)

In addition to basic syntax checking against SQL-89, Flagger optionally performs

semantics checking against SQL-89. This includes some integrity checking between

the SQL statements and the database. For example, it checks:

v Whether a statement contains column names or table names that do not

currently exist.

v Whether a statement contains ambiguity among column names, such as an

unqualified name for a column that exists in more than one of the tables in the

query.

v Whether a statement contains inconsistencies between the data types of the host

variables and their corresponding table columns.

Any statements that do not conform to the standards are flagged in the form of

information messages in the preprocessor output listing. Flagger, however, does

not force you to comply with the standards. The purpose of Flagger is to provide

guidance for those users who want to conform to these standards, so that they can

have SQL consistency across operating environments.

Note: The DB2 Server for VM product is a superset of the SQL-89 standard

without the Integrity Enhancement feature. For example, the datetime data

types are not part of SQL-89 and the CONNECT statement is not part of

SQL-89. The use of extensions such as these will generate information

messages for deviations from the standard specified in the SQLFLAG

parameter.

The Flagger messages generated at preprocessor time range from ARI5500 to

ARI5599, and are further classified as follows:

1. ARI5500-ARI5539 and ARI5570-ARI5599 are information messages that indicate

that an extension to the SQL-89 standard (nonconformance) has been found.

These start with “FLAGGER message.”

2. ARI5540-ARI5569 are warning messages that indicate a failure on the part of

Flagger itself.

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

133

In this event, SQL-89 semantics checking will be turned off and its syntax

checking may or may not be turned off, depending on the nature of the failure.

However, the preprocessor run itself will continue, and any inconsistencies

discovered by Flagger prior to the failure will be included in the output listing

of the run.

Improving Performance Using Preprocessing Parameters

When preprocessing your program, you can specify two performance parameters,

the SBLocK/BLocK/NOBLocK option, and the ISOLation level option. The format

and use of these options within the SQLPREP EXEC was discussed under

“Preprocessing the Program” on page 114. The next section discusses when you

would want to specify each of these options.

(Other performance considerations are discussed in the DB2 Server for VSE & VM

Database Administration manual.)

Selecting the Isolation Level to Lock Data

The database manager puts locks on data that your program works with, to keep

other users from reading or changing that data. You can specify either to lock all

the data that the current logical unit of work (LUW) has read, to lock just the row

or page of data that a cursor is currently pointing to, or to not lock any data being

read. This is called specifying the isolation level of the lock.

The isolation level used by an application is set using the ISOLation preprocessing

parameter. On SELECT, SELECT INTO, INSERT, searched UPDATE, and DELETE

statements, the WITH clause may be specified to override the value specified on

the preprocessing parameter.

If you choose to put a lock on all the data that your program’s current LUW has

read, this is called specifying isolation level repeatable read. Repeatable read locks are

held until the end of the LUW. If you choose to put a lock on just the row or page

of data that your cursor is pointing to, then you are specifying isolation level cursor

stability. With cursor stability locking, when the cursor moves, the system frees all

the data previously read by the program that was held by the lock. If you choose

not to lock the data that your program will read, this is called specifying isolation

level uncommitted read. With uncommitted read, no locks are held on the data being

read, and as a result, the data can be changed by other applications.

Both repeatable read and cursor stability provide you with the following data

isolation from other concurrent users:

v Your LUW cannot modify or read any data that another active LUW has

modified. Similarly, if your LUW has modified some data, no one else can

modify or read that data until your LUW has ended. Modify means to apply

INSERT, DELETE, UPDATE, or PUT commands; READ means to apply SELECT

or FETCH commands.

v If your LUW has a cursor pointing to a row of data, no other LUW can modify

that data. Similarly, your LUW cannot modify a row to which another user has a

cursor pointing.

In addition to the above, repeatable read locking provides you with the following

data isolation from other concurrent users:

v No other LUW can modify any row that your active LUW has read. Also, you

cannot modify any data that another active LUW, specifying repeatable read, has

read.

134

Application Programming

v You do not have to worry about your data being changed between reads, as

long as you do not end your LUW between those reads.

This extra isolation has its drawbacks, however. When you specify repeatable read

for data in public dbspaces with PAGE or ROW level locking, you reduce the

concurrency of the data. This means that other users may be locked out from the

data for a long time, causing delays in their programs’ executions.

If you specify cursor stability instead, you reduce these locking problems by

making the data more available. With this isolation level, the system does not hold

the locks as long. After a cursor has moved past a row or page of data, the lock on

that data is dropped. This increases concurrency so that other users can access data

faster.

Cursor stability can, however, cause some data inconsistencies. For instance:

If a user’s LUW reads data twice, it can get different results. This could happen

if another user modifies the data and commits the changes between read

operations.

A modification based on a prior reading can be incorrect. This can occur if

another LUW modifies the rows that a user has read and commits the changes

before that user can do the modification. (Note that when the user is retrieving

data in application programs, the only row that is safe from modification is the

one that is currently being pointed to by a cursor.)

If an SQL statement in the user’s LUW is traversing a table by way of an index,

the user might find the same row twice. (This case applies to FETCH cursors,

searched INSERT by way of subselect, and searched UPDATE with subselect

that traverse a table by way of an index.) This can occur because, after the

user’s statement reads the row the first time, another user can update the

column value that is indexed and commit the change. The change could cause

the committed row to be ahead of the row currently being retrieved by the

statement. The first user’s statement would then find the row again with its

updated index column value.

If an SQL statement in the LUW is traversing a table by way of an index, it can

fail to find a row (or rows) even if the row meets the selection criteria. (This

situation applies to FETCH cursors, Searched DELETE, Searched INSERT by

way of the subselect, and Searched UPDATE by way of the subselect that

traverse a table by way of an index.) This can occur because while the LUW is

reading, another user modifies the indexed column in the row and commits the

change (as above). The change could cause the committed row to be behind the

row the user’s statement is currently reading. Thus, the statement would not

find the row, even if the row met the selection criteria.

If you enter a SELECT statement to retrieve a single row, a cursor is opened

when the system processes the statement and is closed when the row is

returned. All PAGE and ROW level locks are released when the cursor is

closed; therefore, no locks are held after the row is returned. For single-row

processing using a SELECT statement with a fully qualified unique index, a

cursor is not opened and again no locks are held once the row has been

returned. As a result, applications which update a selected column based on

the values retrieved may have unexpected results because the lock was not

held for the duration of the LUW. For example:

HOST_EMPNO = ’000250’

EXEC SQL SELECT SALARY

/* HOST_SALARY is 19180

INTO :HOST_SALARY

FROM EMPLOYEE

WHERE EMPNO = :HOST_EMPNO;

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

135

HOST_SALARY = HOST_SALARY + 1000;

/* HOST_SALARY increased to 20180 */

EXEC SQL UPDATE EMPLOYEE

/* UPDATE SALARY in EMPLOYEE

SET SALARY = :HOST_SALARY; /* TABLE with HOST_SALARY

WHERE EMPNO = :HOST_EMPNO;

EXEC SQL SELECT SALARY

/* HOST_SALARY may not be 20180

INTO :HOST_SALARY

/* because lock was not held for*/

FROM EMPLOYEE

/* the duration of the LUW

WHERE EMPNO = :HOST_EMPNO;

COMMIT WORK;

In the previous example, it is possible that two or more users could read the

salary column with the same value at approximately the same time. They

would then each increment the number and issue the UPDATE statement. The

second user would wait for the first user’s update to finish, and then overwrite

it with the same number.

Unlike RR or CS, uncommitted read does not provide any data isolation from

other concurrent users. Like CS though, concurrency is improved, although at the

risk of data inconsistency. UR can cause similar data inconsistencies as those

described for CS and should only be used when it is not necessary that the data

you are reading be committed.

An application using isolation level UR is still restricted to access only data for

which it has authorization. However, because it will be able to read uncommited

changes, it will be able to read additional rows which an application, with the

same authorization but using RR or CS, could not. This is illustrated by the

following example.

Rows of table:

Scenario: 1

U1 reads (using UR) A B

U2 inserts D

U1 continues reading C D E

<---D

U2 rolls back

-- U1 has read a non-existent row

Scenario: 2

U1 reads (using CS) A B

U2 inserts D

U1 continues reading C, must wait to read D

U2 rolls back

U1 continues reading E

Note: In scenario 1, U1 has read an extra row which U1 in

scenario 2 could not.

When should each of these options be chosen for your program? Usually, you

should specify repeatable read locking. Only use cursor stability if your program

causes or will cause locking problems. For instance, you would probably want to

use cursor stability for transactions that perform terminal reads without

performing a COMMIT or ROLLBACK, or programs that do bulk reading, because

it is handy for programs that browse through large amounts of data. For programs

that perform commits or rollbacks before issuing terminal reads, you should use

repeatable read locking, because they probably will not cause locking problems.

Also, any application that needs to protect itself against updates should also use

repeatable read locking. For programs where concurrency is wanted, for example,

data being queried simultaneous to being updated, you would use uncommitted

read locking. Of course, this would be for applications where data integrity was

136

Application Programming

not important because the data being read may not necessarily have been

committed. For single row processing (UPDATE and DELETE, for example) by

way of unique indexes, cursor stability performs no better, and may perform

worse, than repeatable read isolation.

One additional isolation level exists in DRDA protocol: Read Stability (RS). RS is

not supported by a DB2 Server for VSE & VM application server, but it is

recognized as a valid preprocessing option by the database manager. For more

information on this option, refer to the DB2 Server for VSE & VM SQL Reference

manual.

Upon receiving a request for the RS isolation level, an application server escalates

it to RR and proceeds without indicating the escalation to the application requester.

You can also mix isolation levels, to have your program set, change, and control its

own isolation level as it is running. You can specify mixed isolation level with the

USER option of the ISOLation preprocessor parameter, as detailed under

“Preprocessing the Program” on page 114.

If you choose this option, your program must pass the isolation level value to the

application server by a program variable. It must declare a one-character program

variable and must set this variable to the desired isolation level value before

executing SQL statements. For repeatable read, your program should set this

variable to R; for cursor stability, the variable should be set to C; and for

uncommitted read, the variable should be set to U. The program can change the

variable at any time so that subsequent SQL statements are executed at the new

isolation level value. However, if your program changes the isolation level while a

cursor is OPEN, the change does not take effect for operations on that cursor until

it has been closed and opened again. That is, until the cursor is closed all

operations on that cursor are executed at the isolation level value that was in effect

when the cursor was opened. Note that the changed isolation level will be used

(without error) for SQL statements not referencing the opened cursor.

If the program sets the isolation level variable to a value other than C, R or U, or if

it fails to initialize the variable, the system stops execution and returns an error

code in the SQLCA.

Table 12 shows the isolation level variable name for each of the host languages.

Table 12. Variable Names for Specifying Mixed Isolation Levels

Host Language

Variable Name

Example

assembler

SQLISL

SQLISL DS CL1

SQLISL

char SQLISL;

COBOL

SQL-ISL

01 SQL-ISL PIC X(1).

Fortran

SQLISL

CHARACTER SQLISL

PL/I

SQLISL

DCL SQLISL CHAR(1);

Note: If you forget to declare the isolation level variable in a PL/I program, the

PL/I compiler issues an informational message which can, in some

environments, be suppressed.

If you preprocess using DRDA protocol, the USER isolation level option is not

supported. In DRDA protocol, the application requester changes any USER

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

137

isolation level request to CS. If you preprocess using SQLDS protocol but later

invoke the package using DRDA protocol, the application server defaults to the CS

isolation level at run time. If a package is preprocessed and invoked using SQLDS

protocol, the isolation level setting is not affected.

Isolation level cursor stability or uncommitted read only has meaning for data in

public dbspaces with ROW or PAGE level locking. Data in private dbspaces or in

public dbspaces with DBSPACE level locking always uses repeatable read isolation.

However, programs which access such data and do not require repeatable read

should be preprocessed with cursor stability or uncommitted read. The data

concurrency requirements might change and cause the data to be moved to a

public dbspace with PAGE or ROW level locking. In this case, the program would

not need to be repreprocessed to run at isolation level cursor stability or

uncommitted read.

To use the features of CS or UR, data must reside in public dbspaces with PAGE or

ROW level locking. DML statements against private dbspaces or public dbspaces

with PAGE or ROW level locking under isolation level CS or UR are handled the

same as if isolation level RR were used.

When the system uses a dbspace scan (that is, does not use an index) to access a

table in a dbspace with ROW level locking using isolation level cursor stability, the

effect is the same as repeatable read. That is, no other LUW can update the table

until the logical unit of work performing the dbspace scan ends. Also, if an LUW

is updating a table, another LUW (using cursor stability) cannot access that table

with a dbspace scan until the updating LUW ends. This reduced concurrency for

dbspace scans does not apply to tables in dbspaces with PAGE level locking, or to

accessing tables through indexes. Because most database accesses will typically use

indexes, the reduced concurrency caused by dbspace scans should not occur

frequently.

The isolation level specification affects UPDATE and DELETE processing as well as

SELECT processing. For UPDATE and DELETE processing, the system acquires

UPDATE locks. UPDATE locks can be acquired for both cursor stability and

repeatable read isolation level settings. If the user actually wants to update or

delete the data, the UPDATE lock is changed to an EXCLUSIVE lock; otherwise,

the UPDATE lock is changed to a SHARE lock.

Note the following about UPDATE LOCKS:

v They are used for page or row locking, but not for dbspace locking.

v They apply to index pages or index keys only for the Searched DELETE

statement.

v For Positioned DELETE processing, the named cursor must have been declared

in the FOR UPDATE clause of the DECLARE CURSOR statement.

v For FETCH processing that uses repeatable read isolation level, these locks are

acquired only if certain predicates are present in the statement. See the DB2

Server for VSE & VM Database Administration manual for more information.

Internally generated SELECT, UPDATE, or DELETE statements use cursor stability

locking no matter what the isolation level is set to. (See “Enforcing Referential

Integrity” on page 299 for information on these statements). Conversely, data

definition statements such as CREATE, ACQUIRE, or GRANT, use repeatable read

locking no matter what the isolation level is set to. These statements, therefore,

should not play a role in your choice of isolation level.

138

Application Programming

Note: Catalog access for SQL statement preprocessing is also always done with

repeatable read locking.

Using the Blocking Option to Process Rows in Groups

You can insert and retrieve rows in groups or blocks, instead of one at a time. This

is called specifying the blocking option. Specifying one of the blocking options

(SBLocK, BLock or IBLocK), improves performance for DB2 Server for VM

application programs that:

v Execute in multiple user mode, and

v Retrieve or insert multiple rows.

You can specify the blocking option as a DB2 Server for VM preprocessor

parameter, or SBL0cK or BLocK as an option on the CREATE PACKAGE statement.

After a program has been preprocessed with the blocking option, all eligible cursor

SELECTs and all eligible cursor INSERTs within the program are blocked. You do

not have to specify a block size or block factor.

When using DRDA protocol, you can specify the block size by using the SQLINIT

EXEC. Performance is closely related to block size when using DRDA protocol.

The programs that would benefit the most from blocking are those that do

multiple-row inserts (with PUT statements or Insert statements) or multiple-row

SELECTs (with FETCH statements). In both cases, a cursor must be defined. (See

“Retrieving or Inserting Multiple Rows” on page 33; for more information on

cursors.) Thus, a general rule for blocking is use blocking for programs that declare

cursors or that have multiple contiguous homogenous insert statements.

A program can use either PUT, FETCH or INSERT statements without being

sensitive to whether the system is blocking. These statements work regardless of

whether you specified the blocking option. What information is returned in the

SQLCA after each PUT, FETCH or INSERT, however, depends on whether blocking

is in effect or not.

Remember that when you preprocess a program with the blocking option, all

eligible INSERT and SELECT cursors are blocked. You cannot specify blocking for

just INSERTs or for just SELECTs. If you specify the blocking option, it

automatically applies to both. However, specifying the IBLocK option applies only

to normal INSERT statements in the application program, that are homogenous

and contiguous.

When are INSERT or SELECT statements not eligible for blocking? The database

manager sometimes overrides blocking for a particular cursor because of storage

limitations in the virtual machine, or because of SQL statement ineligibility. The

following SQL statements are ineligible for blocking and cause blocking to be

overridden automatically for the cursors they refer to:

v DECLARE CURSOR...FOR UPDATE

v Any DECLARE CURSOR statement with a related select-statement containing a

long string

v Any DECLARE CURSOR statement that has a subsequent DELETE...WHERE

CURRENT OF statement

v Any DECLARE CURSOR statement that has a corresponding UPDATE...WHERE

CURRENT OF statement and the program is preprocessed with NOFOR

support.

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

139

The system also disqualifies blocking if it cannot fit at least two rows into a block.

(The number of rows that fit into a block may differ from one

PUT/FETCH/INSERT statement to the next, even when such statements operate

on the same table.)

The system does not halt the program when it overrides blocking. Instead, in each

of the above cases, it sets a warning flag in the SQLCA. The warning can be

detected by using WHENEVER SQLWARNING in the program. See “Using the

Automatic Error-Handling Facilities” on page 197 for more information on the

SQLCA and the SQL WHENEVER declarative statement.

Note: The DECLARE CURSOR... statement can also be written without the FOR

UPDATE OF clause, even though positioned updating is subsequently done.

(This is allowed when NOFOR support is invoked at preprocessor time.) In

this case, blocking is also ineligible.

The system also overrides blocking for all programs running in single user mode.

In this instance, the system does not usually return a warning to the SQLCA. A

warning is returned to the SQLCA for programs running in single user mode if:

v The program is preprocessed with the BLocK option

v An SQL statement that is being processed dynamically (with PREPARE) is

disqualified for blocking.

The DBS Utility may get blocking ineligible warnings when it is run in single user

mode because it is preprocessed with the BLocK option, but uses PREPARE to

process SELECT statements.

Note: Always CLOSE a cursor before issuing a COMMIT statement, especially

when blocking. If you commit changes before closing an insert cursor that is

being blocked, you receive an error. If you are using DRDA protocol and if

the HOLD option is in effect, your application does not have to close the

cursor before committing the LUW.

Imposing Blocking Restrictions:

1. The length of host variables in the SQLDA or host_variable_list cannot be

changed after the first FETCH, PUT or INSERT when blocking.

2. The data type of host variables in the SQLDA or host_variable_list cannot be

changed after the first FETCH, PUT or INSERT when blocking.

3. The number of data elements in the host_variable_list or SQLDA cannot be

changed after the first FETCH, PUT or INSERT when blocking.

4. If a COMMIT is issued while a blocking PUT cursor is open, an error occurs.

When blocking is active, a single SQLCA is returned with each block of rows. This

SQLCA is returned to the application program with the last row in the block.

However, for the final block of rows, the FETCH that returns the “not found”

condition (SQLCODE = +100 and SQLSTATE='02000') will return the SQLCA. (For

more information on SQLCA refer to “Using the SQLCA” on page 199). This has

the following implications for application programming:

v No warning conditions are returned to the application until the SQLCA is

returned.

For example, if SQLWARN3 is set (to indicate that the application has fewer

target variables in the INTO clause than the number of items in the SELECT

list), the application will not be notified until either the last row in a block or the

“not found” condition is returned.

140

Application Programming

v If SQLWARN1 (truncation occurrence) is set, it is impossible to tell from the

SQLCA information which row (or rows) in a block caused the warning

condition. However, if the application resets the indicator variable to 0 before

each fetch, and then examines the indicator variable after each fetch, truncation

can be detected on an ongoing basis.

Using the Blocking Option in DRDA Protocol: When the database manager is

acting as an application requester in DRDA protocol, no blocking is provided on a

PUT statement using the BLocK option and for a normal INSERT statement using

the IBLocK option.

When the IBLocK or BLocK parameters are specified in DRDA protocol, all eligible

homogenous INSERT/PUT statements are grouped together for processing.

Homogenous INSERT statements are defined as a set of insert statements that:

v Access the same DB2 Table.

v Access the same set of columns in that table, in the same order.

There must be an ’SQL COMMIT’ statement after a set of homogenous insert

statements. This causes the buffer to be sent, processed by the DB2 UDB Server

and response received and parsed by the Application requester.

The IBLocK parameter does not work under private protocol.

This is particularly useful, if you are loading a large amount of data while using

DRDA protocol.

In DRDA protocol, the block size for FETCH/PUT/INSERT statements is

determined by the QRYBLKSIZE parameter in SQLINIT. For information on

SQLINIT, refer to the DB2 Server for VSE & VM Database Administration manual.

Using the INCLUDE Statement

Including External Source Files

The inclusion of external source files is indicated to the DB2 Server for VM

preprocessor by an embedded SQL statement, the INCLUDE statement, in the

user’s source code. This statement can appear anywhere that an SQL statement can

appear, and indicates within the source code where the external source is to be

placed. The syntax for the INCLUDE statement is as follows:

►► INCLUDE text_file_name

►◄

where text_file_name is a 1- to 8-character identifier that identifies the file name of

the external source file. Text_file_name cannot be delimited by double quotation

marks. The first character must be a letter (A-Z), $, #, or @; the remaining

characters must be letters, digits (0-9), $, #, @, or underscore (_), unless further

restricted by the operating system. Also, text_file_name cannot be SQLCA or

SQLDA, because these are special INCLUDE keywords.

Including Secondary Input

You can use the INCLUDE statement to obtain secondary input from a CMS file. If

a source program input to a DB2 Server for VM preprocessor uses the INCLUDE

facility, any files to be used as secondary input must be accessed by the user. A

search of all accessed CMS mini-disks for the file name and file type is conducted

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

141

in standard CMS search order and the first match determines the file mode. This

filename, filetype, and filemode are used as the secondary input or external source.

The CMS file containing the secondary input statements must be fixed-length,

80-character records.

The INCLUDE statement causes input to be read from the specified file name until

the end of the file, at which time the SYSIN input resumes. The file to be included

must have an appropriate file type:

ASMCOPY

assembler

CCOPY

COBCOPY

COBOL

FORTCOPY

Fortran

PLICOPY

PL/I

The file mode is determined by the search of the virtual machine’s accessed

minidisks. If the INCLUDE statement specifies a file name that is not located on

any user-accessed CMS mini-disk, an error will result.

Secondary input must not contain preprocessor INCLUDE statements other than

INCLUDE SQLDA or INCLUDE SQLCA, although it may contain both host

language and SQL statements. If an INCLUDE statement is encountered, an error

will result.

Compiling the Program

After you successfully preprocess your program, you can compile it using your

normal host language compiler. By preprocessing, you have already done all the

translating that the program needs for the database manager. Just use the new

code that you got after you preprocessed. Compile this code as you would any

other program, using the usual compilers.

This book does not cover the specifics of compiling your host-language code.

However, there are several special rules for SQL programs, depending on the host

language, that you must follow:

v If your PL/I application program contains DBCS data, you must specify the

GRAPHIC option for the compiler. If your COBOL application program contains

DBCS data or is reentrant, the output of the DB2 Server for VM preprocessor

must be processed by the COBOL II Release 2 (or later) program.

v If the QUOTE option is used for the DB2 Server for VM COBOL preprocessor, it

should also be used for the COBOL compiler.

v If the NOSEQuence option is used for the DB2 Server for VM C preprocessor,

the NOSEQ and MARGINS (1,80) options must be used with the C compiler.

v If the compiler provides a mechanism whereby run-time program interrupts are

trapped before control returns to CMS, the database manager may not identify

that an abnormal termination has occurred. As a result, an implicit COMMIT is

executed instead of an implicit ROLLBACK. See the host language appendixes

for a discussion of program interrupts.

Link-Editing and Loading the Program

After compilation, programs must be link-edited and loaded before they can be

run.

142

Application Programming

Link-Editing the Program with DB2 Server for VM TEXT Files

To enable your program to communicate with the application server, you must

link-edit your program with one or more DB2 Server for VM TEXT files, one of

which is the resource adapter stub. Every DB2 Server for VM application program

must be link-edited with this stub; Fortran and COBOL programs need to be

link-edited with additional TEXT files.

Using the Resource Adapter Stub Routine

The resource adapter stub routine has a file name of ARIRVSTC, but is invoked by

its entry point name ARIPRDI. To link-edit this stub routine successfully with the

user program, you must INCLUDE ARIRVSTC or place the TEXT files in a CMS

TXTLIB. This will make the entry point ARIPRDI known to the link-edit process.

Using Other TEXT Files

Other files that need to be link-edited, depending on the host language, include:

v For all programs written in Fortran, you must also link-edit the TEXT files

ARIPEIFA and ARIPSTR. If the Fortran program uses the TEXT file ARISSMF,

this file must also be link-edited (refer to “Examining the SQLCA” on page 202

for more information).

v For all reentrant programs written in COBOL, you must also link-edit the TEXT

file ARIPADR4. Non-reentrant COBOL programs may continue to link-edit the

TEXT file ARIPADR until they are repreprocessed and recompiled. After, they

must link-edit the TEXT file ARIPADR4.

v For all programs that use the DBS Utility, you must also include ARIDBS which

is a member of ARISQLLD LOADLIB. (For information on the DBS Utility refer

to the DB2 Server for VSE & VM Database Services Utility manual.)

v For all programs (except Fortran programs) that use the TEXT file ARISSMA,

you must also link-edit this file (refer to “Examining the SQLCA” on page 202

for more information).

v For all programs that use the TEXT file ARIGMSGC, you must also link-edit this

file (refer to “Examining the SQLCA” on page 202 for more information).

If you receive an unresolved external reference message for a module name that

begins with ARI or SQL, check the link process to ensure that all required extra

linkage modules are included.

Some of these modules contain entry points with names that are different from the

module name. The code generated by the DB2 Server for VM preprocessor can

reference one of these entry points, depending on the SQL statements in your

application.

Including the TEXT File in the Link-Editing

Using the CMS LOAD Command

One way to link-edit these TEXT files to your program is to INCLUDE them after

your program name in the CMS LOAD command. Then, when you load your

program, the CMS linkage editor automatically links your program to the TEXT

files relocatable modules that you specified, and resolves virtual storage addresses

among the TEXT files.

For example, SAMPLE1 is the user’s program name and ARIRVSTC is the TEXT

file in the CMS LOAD command below:

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

143

LOAD SAMPLE1 ARIRVSTC

To see other examples of REXX EXEC’s that use the CMS LOAD command, see

any of the REXX EXEC’s listed in Table 3 on page 21.

Note that if the user machine has READ access to the production minidisk, the

CMS LOAD command will automatically load the needed TEXT file, searching all

accessed CMS minidisks in ascending order (A through Z) for TEXT files that it

needs. For additional information about CMS LOAD, see the VM/ESA: CMS

Command Reference manual.

Using the CMS TXTLIB Command

Instead of specifying ARIRVSTC in the CMS LOAD command, you can put

ARIRVSTC and all your application TEXT files into a TXTLIB. To create a TXTLIB,

enter:

TXTLIB GEN my-lib ARIRVSTC program-name . . .

To add new programs to a TXTLIB, enter the following command:

TXTLIB ADD my-lib program-name2 program-name3

After a program is in a TXTLIB, enter the following commands to perform the

link-edit:

GLOBAL TXTLIB my-lib

LOAD program-name

For more information about TXTLIB, see the VM/ESA: CMS Command Reference

manual.

Creating a Load Module Using the CMS GENMOD Command

All of the TEXT files are on the DB2 Server for VM production minidisk (Q-disk).

After loading the DB2 Server for VM application, you should create a module by

issuing the CMS GENMOD command. This module can be used in multiple user

mode, but is not required; it is required, however, to run in single user mode. For

example, to create a module for an assembler application program called

SAMPLE1 that has been compiled and added to a TXTLIB called LIBRARY1, enter

the following commands:

GLOBAL TXTLIB LIBRARY1

LOAD SAMPLE1

GENMOD SAMPLE1

This creates a CMS file with a file name of SAMPLE1 and a file type of MODULE.

To see other examples of REXX EXEC’s that use the CMS GENMOD command, see

any of the REXX EXEC’s listed in Table 3 on page 21.

Running the Program

Using a Consistency Token

Consistency tokens ensure that a program’s load module and the database package

are used together. When preprocessing, you can instruct the preprocessor to place a

consistency token in both the load module and the package (see CTOKEN

parameter on page 122). If the two tokens do not match, the application server

prevents the program from running.

144

Application Programming

Note: If you inadvertently forget to compile or link-edit a new version of a

program, you can run an old version of a program with a new version of

the package. Conversely, with multiple application servers, you can

inadvertently run a new version of a program with an old version of the

package. In either situation, you will probably get program errors or

incorrect results if you have not used consistency tokens.

Loading the Package and Rebinding

The package that the preprocessors stored carries out the SQL request. When the

application server loads the package, it checks that the package is still valid. A

package may not be valid if one of its dependencies has been dropped. For

example, some index that the package uses may have been dropped.

Packages are also invalidated when primary keys and referential constraints are

added to, dropped from, activated, or deactivated on tables that the modules

depend on. The following rules apply:

v If a primary key is added, dropped, activated, or deactivated, all packages that

have a dependency on the parent table will be invalidated. This includes any

tables that have a foreign key relationship with the parent table.

v If a foreign key is added, dropped, activated, or deactivated, all packages that

have a dependency on the dependent table or parent table will be invalidated.

The system has an internal change management facility that keeps track of whether

packages are valid or not. If a package is valid, the system begins running the

program; if the package is not valid, the system tries to re-create it. The original

SQL statements are stored with the package when you preprocess the program.

The system uses them to automatically bind the program again. It does this

dynamically (that is, while it is running). If the rebinding works, a new package is

created and stored in the database and the system then continues execution of the

program. If the rebinding does not work, an error code is returned to the program

in the SQLCA, and the program stops running.

A successful rebinding has no negative effect on your program except for a slight

delay in processing your first SQL statement. To minimize this delay, you can use

the DBSU REBIND PACKAGE command to rebind the invalid package after it has

been invalidated, but before it is executed. See the DB2 Server for VSE & VM

Database Services Utility manual for information on this command.

Using Multiple User Mode

When the database manager has been started in multiple user mode, the user

machine should have IPLed CMS and been initialized for DB2 Server for VM

processing (by the SQLINIT EXEC).

If the program has any input or output files, file definitions may be required. The

CMS FILEDEF command is described in the VM/ESA: CMS Command Reference

manual.

In addition, if your application was compiled using a Language Environment

Compiler, the Language Environment must be available at runtime for your

application to use the dynamic library routines. One way to do this is by including

SCEERUN LOADLIB on the GLOBAL LOADLIB list. For more information, see the

compiler documentation.

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

145

If a module was created, you can execute the program by specifying the name of

the module followed by any user program parameters. For example, the following

command starts assembler program SAMPLE1 in multiple user mode, and passes

the user parameters directly to the program:

SAMPLE1 parm1 parm2

If a module was not created, you can execute the program by first specifying the

CMS LOAD command, as described in the previous section, and then the CMS

START command. For example, to execute the program SAMPLE1, enter:

LOAD SAMPLE1 ARIRVSTC

START SAMP parm1 parm2

where:

SAMP

is the control section name or entry point name that receives

control at run time. If an asterisk (*) is used (instead of a name),

control is passed to the default entry point.

parm1 parm2

are parameters passed to the program. If parameters are passed,

the control name or section name or * operand must be specified;

otherwise the first parameter is taken as the entry point.

When parameters are passed on the START command, the requirements of both

CMS and the language of the application program must be met. See the VM/ESA:

CMS Command Reference manual, for a description of the CMS START command

and the appropriate language guide or reference manuals for details on how to

pass parameters.

Using Single User Mode

Single user mode application programs are programs that run in the same machine

as the DB2 Server for VM code and that are under the control of the database

manager. In this case, the user machine and the database machine are the same.

Single user mode programs are invoked by starting the application server with the

SQLSTART EXEC. (Before invoking the system, you must enter IPL CMS.) You

must specify both the mode (SYSMODE=S) and your program name

(PROGNAME=name) when you enter the SQLSTART EXEC.

When SQLSTART is invoked, the systems loads the program (identified by the

PROGNAME parameter) and passes control to it after the system is initialized. For

single user mode, the module must be available.

The DB2 Server for VSE & VM Operation manual lists all the initialization

parameters you can specify when you start the system in single user mode. A

system programmer can also determine the best initialization parameters for your

system and pass them on to you.

The following is an example of the SQLSTART EXEC for invoking programs in

single user mode with no user parameters:

146

Application Programming

SQLSTART DB(SQLDBA) PARM(SYSMODE=S,LOGMODE=A,DUMPTYPE=N,PROGNAME=SAMPLE1)

Note: If your program or the database manager ends abnormally, you may receive

a minidump (depending on what initialization parameters were specified).

Mini-dumps are described in the DB2 Server for VSE & VM Diagnosis Guide

and Reference manual.

Specifying User Parameters in Single User Mode

When starting the database manager in single user mode, you can also specify user

parameters to be passed to your application program using the PARM keyword of

the SQLSTART EXEC. The SQLSTART EXEC purges the CMS program and console

stacks. Thus, any program run in single user mode cannot rely on console or

program stack input.

Place a slash (/) between the initialization parameters and the user parameters. For

example:

SQLSTART DB(SQLDBA)

PARM(SYSMODE=S,LOGMODE=A,DUMPTYPE=N,PROGNAME=SAMPLE1/parm1,parm2)

Note: Only the first 130 characters of the command line are read by CMS. The

exception to this rule occurs when SQLSTART is called from a user-written

EXEC; then CMS reads the first 256 characters. If you specify many

initialization parameters and user parameters, they will not fit on the

command line. Thus, you must use a CMS file for some of the parameters.

Because user parameters cannot be specified in a CMS file, you should

specify the initialization parameters in the CMS file, and the user parameters

on the command line.

A program written in C, PL/I, COBOL or Fortran requires an interface routine to

process the user parameters.

Distributing Packages across Like and Unlike Systems

To run your application program on another DB2 Server for VSE & VM database

manager, you can simply distribute its load module and the DB2 Server for VSE &

VM package. (You do not have to distribute the source code and then preprocess

and compile it on the other system). Reload the package to all application servers

that your package accesses, and send the load module to all DB2 Server for VSE &

VM application requesters that your program accesses. You can unload the package

to be distributed from the application server into a file, and subsequently reload

the file into the new application server. Only the owner of the package or the

database administrator can unload or reload the package.

If the package is distributed among application servers that are at different release

levels of the system or are non-DB2 Server for VM or DB2 Server for VSE servers,

a run-time error occurs if the package uses a feature that is not available on the

application server on which the package was reloaded. To ensure that the load

module and the package that you are distributing are meant to be used together,

use the preprocessor parameter CTOKEN to place the same consistency token in

both the load module and the package. Refer to “Preprocessing the Program” on

page 114. If the two tokens do not match, the application server stops the program

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

147

from running. For information on distributing packages on both like and unlike

systems, and on distributing packages using DRDA protocol, refer to the DB2

Server for VSE & VM Database Services Utility manual.

If your application is to run at other DB2 Family application servers, do the

following:

v Use Binding to generate a package at each DB2 application server at which the

application is to be run.

v Binding can be invoked using SQLBIND EXEC.

v SQLBIND EXEC uses the bind file created in the preprocessor step above.

For more information on VM Binding, see “Binding to Create Package.”

Binding to Create Package

Binding is the process of creating the package in target database using the bindfile

as input. Preprocessing with ″BIND″ option and binding are complementary to

each other. Binding can be invoked multiple times to bind the packages to one or

more databases. It must be ensured that bindfile is not corrupted or modified to

get proper results. Creation of package using binding can be done for COBOL, C,

Pl/1 and assembler preprocessed programs only.

SQLBIND exec can be used to perform binding. SQLBIND exec can not be used in

single user mode to bind to DB2 Server for VM. For each application server

specified, the SQLBIND EXEC:

1. Establishes a link to the application server.

2. Binds the bindfile to the application server to create the package.

3. Displays summary messages showing the results for this binding.

4. Creates two files with filename same as bindfile and filetype BINDLST and

BINDOUT in A-disk that must be accesses as R/W. These files contain

summary and output of binding.

To perform binding, you must be either the owner of the program whose bind file

you are binding to a remote server or a database administrator. SQLBIND takes 11

parameters, one of them is positional and mandatory. Parameters and their details

are given below:

►► SQLBIND PACKAGE

(

package_id

)

►

collection_id.

►

INfile

( fn ft fm

)

►

REPLACE

KEEP

NOCHECK

BOPT

(

NEW

REVOKE

CHECK

)

ERROR

►

OWner

( authorization_name

)

QUALifier

( collection_id

)

148

Application Programming

►

DBFile

(

fn ft fm

)

▼

DBList

(

server_name

)

►

►◄

USERid

( authorization_name/password

)

QRY

PACKAGE(collection_id.package_id)

This parameter identifies the package to be created and the associated bind

file. The associated bind file must be created by the DB2 Server for VSE

preprocessor and its contents must not be changed in any way.

collection_id.package_id is the name by which the database manager identifies

the package to be created and the associated bind file. The collection_id

portion is optional, and fully qualifies the package_id and any unqualified

objects referenced within the package.

If the collection_id is not specified, and the user_id is, the collection_id

defaults to the user_id. If neither is specified, the collection_id defaults to the

connected authorization-id. You must be the owner of the bind file that you

want to bind. To bind another user’s bind file, you must have DBA authority.

INfile (filename)

INfile (filename filetype)

INfile (filename filetype filemode)

This optional parameter specifies the file name, file type and file mode of the

bindfile. If filename is omitted, SQLBIND is assumed to be the file name while

ftype and fmode is default to BINDFILE and A respectively.

If this form of the INfile parameter is supplied, the following CMS FILEDEF

command is issued for the bindfile:

FILEDEF SQLBIND DISK fn ft fm (RECFM FB LRECL 80 BLOCK 800)

BOPT

The BOPT parameter identifies one or more of the following sub-parameters.

NEW/REPLACE

NEW

The NEW parameter is specified if the package to be created does not exist

and is to be created. If the package with the same name and owner already

exists in the remote application server, binding fails.

REPLACE

This parameter is specified if an existing package is to be replaced by the bind.

If the package does not exist, a new package is created without an error or

warning message. REPLACE is the default option.

KEEP/REVOKE

KEEP

KEEP causes the existing grants of RUN privilege to remain in effect when the

package is bound. However, if the owner of the package is not entitled to grant

all privileges embodied in the package, all existing grants of the RUN privilege

are revoked. The KEEP and REVOKE parameters apply if the package has

previously been created and the owner of the package has granted the RUN

privilege on the resulting package to other users. The KEEP and REVOKE

parameters are allowed only with REPLACE.

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

149

REVOKE

If the REVOKE parameter is specified, all existing grants of the RUN privilege

are revoked. The KEEP and REVOKE parameters are allowed only with

REPLACE.

NOCHECK/CHECK

NOCHECK

This parameter is specified if you want the application server to check all SQL

statements for validity and perform package functions. It will generate a

package if no statement-parsing error was found; If you specify the

NOCHECK parameter, it overrides the ERROR parameter in the bind file.

CHECK

This parameter is specified if you want the application server to check all SQL

statements for validity and generates error messages if necessary, but does not

generate a package; If you specify CHECK parameter, it overrides NOCHECK

or ERROR parameter in the bind file.

ERROR

This parameter specifies how statement parsing errors are tolerated. If the

ERROR option is specified, then syntactic or semantic errors detected at the

application server side will not stop the creation of the package. If the ERROR

option is not specified in both CBND and the bind file, the application server

will not create the package when those errors occur. With the ERROR option, a

syntactic error will cause the DB2 for VSE & VM database to generate an Error

Section in the package. At run-time, invocation of this statement will yield

SQLCODE -525. With the ERROR option, the creation of a package fails only if

there was a DRDA protocol error, or a severe error detected on the Application

Server side.

OWner (authorization_name)

This parameter specifies the authorization_name of the owner of the package

being created. The OWner parameter is to be used when you are binding

against a remote application server. However, if you specify this parameter

when binding against a local DB2 Server for VSE & VM application server, the

authorization_name must be the same as the application server authorization

ID.

QUALifier (collection_id)

This parameter specifies the default collection_id within the package to resolve

unqualified object names in static SQL statements. The QUALifier parameter is

meant to be used when you are binding against a remote application server. If

you specify this parameter when binding against a DB2 Server for VSE & VM

application server, the collection_id must be the same as the application server

authorization ID.

DBList (server_name)

This parameter specifies a list of one or more application servers on which the

bind file will be bound. If this parameter is omitted, the bind file is bound to

the default application server. For more information on establishing a default

application server, see the DB2 Server for VSE & VM Database Administration

manual.

DBFile (filename)

DBFile (filename filetype)

DBFile (filename filetype filemode)

This optional parameter specifies the file name, the file type, and optionally the

file mode of a CMS file containing a list of application servers on which the

150

Application Programming

program will be bound. If filetype is not specified, BINDDB will be used as the

default file type. If filemode is not specified, the first file with the given

filename and filetype will be used.

The rules governing the format of the CMS file are as follows:

v Each record has only one application server name.

v The first word in each record is the application server name.

v Comments can be added to the right of the application server name,

separated from the application server name by a blank. will be treated as a

comment.

v An empty record or a record with an ’*’ in the first position will be treated

as a comment.

Note: DBFILE and DBLIST are mutually exclusive.

USERid (authorization_name/password)

This parameter specifies the userid and password that bind will use to execute

a CONNECT statement to gain access to each application server where the

package will be created. If this parameter is omitted, bind will connect

implicitly to the application server where the package will be created.

QRY

This parameter causes bind to display the preprocessor options stored in the

header of the bind file. No package functions will be performed if QRY is

specified.

Note: For any options not specified on the bind, the default option will be the

option specified when the package was preprocessed, unless otherwise

noted.

Chapter 4. Preprocessing and Running a DB2 Server for VM Program

151

Chapter 5. Preprocessing and Running a DB2 Server for VSE

Program

Defining the Steps to Execute the Program . . . 154

Link-Editing the Program with Supplementary

Using 31-Bit Addressing

154

Information

180

How DB2 Establishes User IDs for CICS/VSE

Including Relocatable Modules

180

Transactions

155

Including CICS/VSE Procedures

181

User IDs for Remote CICS/VSE Transactions

156

Including CICS/TS Procedures

181

Using Batch for Remote CICS/VSE Transactions

156

Including Extra Linkage Modules

181

Preprocessing the Program

156

Running the Program

182

Preprocessing by Mode

158

Using a Consistency Token

182

Using Multiple User Mode

158

Loading the Package and Rebinding

182

Using Single User Mode

159

Running by Mode

183

Defining the Preprocessing Parameters

160

Using Multiple User Mode

183

Using the Preprocessor Option Member . . . 170

Using Single User Mode

183

Using the Flagger at Preprocessor Time

170

Running under CICS/VSE Support

184

Using the CICS/VSE Translator

171

Accessing Other DB2 Family Application

Improving Performance Using Preprocessing

Servers

184

Parameters

172

Installing Applications that Access the Database

Selecting the Isolation Level to Lock Data

172

Manager

184

Using the Blocking Option to Process Rows

Installing a Batch Application

184

in Groups

176

Installing an Online CICS/VSE Application . . 185

Using the INCLUDE Statement

179

Distributing Packages across Like and Unlike

Including External Source Members

179

Systems

187

Including a Library Source

179

Creating a Package Using CBND and Batch

Compiling the Program

180

Binding

188

Link-Editing and Loading the Program

180

153

Defining the Steps to Execute the Program

After you code your program, you must follow a series of steps to prepare it to be

run. The number of steps varies depending on the host language of the program

and the environment in which the program is running. However, the steps below

are common in each case. In order to run your DB2 Server for VSE application

program you must:

v Preprocess the SQL code

v Compile the program

v Link-Edit and Load the program

v Run the program.

If the program is an online program, the CICS statements have to be “translated”

before the program is compiled.

When the database manager was installed, your installation may have optionally

chosen to generate the starter database. The statements

// EXEC PROC=ARIS75DB

// EXEC PROC=ARIS75PL

are contained in single user mode job control examples throughout this section in

order to identify the database and the libraries used.

The ARIS75DB procedure contains the DLBL statements required for accessing the

starter database. The ARIS75PL procedure identifies the DB2 Server for VSE

production libraries. To access a different database, you must substitute a different

procedure (or your own DLBL statements) for ARIS75DB. To access your own

libraries, you must substitute a different procedure (or your own VSE LIBDEF

statements) for ARIS75PL.

Determine if the DB2 Server for VSE database and library definition statements are

required by contacting the person who installed the system. Or, refer to the DB2

Server for VSE Program Directory. This manual contains a description of the

database and library definition job control statements required for a database, and

the product-supplied procedures available.

Using

31-Bit Addressing

The application server runs in 31-bit addressing mode (AMODE 31). In single user

mode, the database manager transfers control to the application in the addressing

mode established during link editing of the program. The database manager

continues to operate in 31-bit addressing mode when control returns from the

application program.

If you are writing a multiple user mode application, your application is not

affected by the addressing mode of the application server.

Refer to the DB2 Server for VSE System Administration manual for information on

single user mode and user exits.

154

Application Programming

How DB2

Establishes User IDs for CICS/VSE Transactions

Online DB2 Server for VSE transactions need not issue an SQL CONNECT to

establish the user id within the database manager. When a transaction does not

issue a CONNECT statement with the “userid IDENTIFIED BY password” clause,

DB2 Server for VSE online support attempts to establish the user ID for the

transaction.

This implicit CONNECT capability is useful if your installation requires its

terminal users to sign-on using the CESN transaction. For many DB2 Server for

VSE transactions, your installation might consider the sign-on verification

sufficient. It may also be useful if your installation has just installed the system,

and finds it convenient to have all users identified by one name (for example,

TESTUSER).

DB2 Server for VSE online support establishes a user ID for CICS/VSE transactions

as follows:

If the transaction issues an SQL CONNECT statement with the “userid

IDENTIFIED BY password” clause, the user ID is established explicitly for the

application.

If the transaction does not issue such a CONNECT statement, the online

support attempts to establish the user ID implicitly as follows:

a. If the transaction had a user ID established for a previous logical unit of

work, and the previous logical unit of work did not specify the RELEASE

option for COMMIT WORK or ROLLBACK WORK, that user ID is used.

(Remember that the connection to the application server is dropped every

time a logical unit of work ends with release; thus, the user ID has to be

re-established if the transaction has more than one logical unit of work

ending with release.) Otherwise...

b. If the user has signed on using the CESN transaction and the transaction is

associated with a terminal, the sign-on user ID is used for the user ID.

Otherwise...

c. The user ID that was specified as an input parameter to the transaction that

enabled the DB2 Server for VSE online support to a particular server

becomes the user ID. This transaction could be either CIRB or CIRA. The

person that invoked CIRB or CIRA will know what the user ID is.

However...

d. A user ID need not be specified when CIRB or CIRA is invoked. It is an

optional parameter. If no user ID was specified, and none of the previous

cases applied, the user ID established for your transaction is CICSUSER.

Once the user ID is determined as described above, one more requirement must be

met in order to successfully complete the connection to the application server.

Either the specific user ID must have been granted CONNECT authority or

“ALLUSERS” must have been granted CONNECT authority. “ALLUSERS” is a

special user ID that permits any user ID to be implicitly connected without having

been specifically granted CONNECT authority. “ALLUSERS” can be used by the

DBA to turn on or off the implicit connect capability.

Earlier in this book, it was recommended that you always explicitly connect to the

application server to avoid confusion. However, it is recognized that many

installations have terminal operators that need not be aware of DB2 Server for VSE

user ID or authorization capabilities. In these cases, the DB2 Server for VSE

Chapter 5. Preprocessing and Running a DB2 Server for VSE Program

155

implicit CONNECT support can be very useful. For more details on the CICS

transaction environment, see the DB2 Server for VSE & VM Database Administration

manual.

User IDs for Remote CICS/VSE Transactions

For online DB2 Server for VSE transactions which are accessing a remote server

and which issued an SQL CONNECT statement with the “userid IDENTIFIED BY

password” clause to establish the user ID within the database manager, the user ID

is established explicitly for the transaction.

For online DB2 Server for VSE transactions which are accessing a remote server

and which did not issue an SQL CONNECT statement with the “userid

IDENTIFIED BY password” clause to establish the user id within the database

manager, the Online Resource Adapter will attempt to establish the user ID for the

transaction implicitly as follows:

1. If the transaction had a user ID established for a previous remote logical unit of

work, and the previous logical unit of work did not specify the RELEASE

option for COMMIT WORK or ROLLBACK WORK, and the transaction did not

switch to another application server, that user ID and its corresponding

password are used. (Remember that every time a logical unit of work ends

with RELEASE or the transaction switched to another application server, and

you enter another SQL statement, you are implicitly connected as the CICS

signon userid. Therefore, the user ID has to be re-established if the transaction

has more than one logical unit of work ending with RELEASE or if the

transaction is switching application servers.)

2. The user ID returned by the CICS ASSIGN command is used for the user ID.

Using Batch for Remote CICS/VSE Transactions

Application programs running in batch can connect to remote application servers,

process some work, and then CONNECT to another application server (local or

remote) and do more processing.VSE Batch application programs which are

accessing a remote server and use the SQL CONNECT statement, can manipulate

and access remote data managed by application servers. The CONNECT statement

must be the first SQL statement issued by the Batch application. The VSE Batch

application only accesses one remote database per unit of work.

The current unit of work must be completed by using the COMMIT or

ROLLBACK statements before the CONNECT statement can be used to switch to

another userid or application server.

Before a batch application program can access a remote application server, the

following tasks must be completed:

v VSE TCP/IP support is installed and enabled

v The Dbname Directory has been updated to identify the remote application

server being accessible through TCP/IP

v Update the SQLGLOB file with default parameters for userids accessing remote

servers. This task is optional.

Preprocessing the Program

Preprocessing performs the following actions :

156

Application Programming

v It changes the SQL source code so that it can be processed during host language

compiling

v It does either or both of the following:

- It converts the SQL statements into a package, and binds the package to the

database.

- It creates a bind file that can subsequently be used by the online utility

(CBND) or Batch Binder to create a package in a remote (or local) database.

The preprocessor replaces all the SQL statements in the program with host

language code that invokes the new package. The new version of the program also

contains the SQL statements in comment form. The package, created either by the

preprocessor, by CBND or Batch Binder, contains information to carry out the SQL

requests made by the program. The database manager follows the best access path

to the data for each SQL statement in the program, using available indexes and

data statistics of which the system keeps track.

When the program is run, the new code calls the system to handle each SQL

statement. It also links the program to the application server and translates

messages and statements between the two.

The preprocessors supplied with the database manager have the following

program names:

ARIPRPA - Assembler Preprocessor

ARIPRPB - C Preprocessor

ARIPRPC - COBOL Preprocessor

ARIPRPF - Fortran Preprocessor

ARIPRPP - PL/I Preprocessor

You preprocess your program to prepare it to use the system. To preprocess your

program, you invoke the appropriate preprocessor through VSE job control

statements. A job control ASSGN SYSIPT statement should point to your source

program. Other job control statements must point to where the preprocessor

should place the modified source-program output (ASSGN SYSPCH) and printed

output (ASSGN SYSLST).

You can suppress SYSPCH and SYSLST output through NOPRINT and

NOPUNCH parameters to the preprocessor.

The preprocessor requires the job control statement DLBL SQLGLOB. In addition,

when you want the preprocessor to generate a bind file, job control statements

DLBL SQLBIND and DLBL BINDWKF are required. These DLBL statements must

be provided in either the preprocess job control or the system standard label

subarea. For more information see “Creating a Package Using CBND and Batch

Binding” on page 188.

You can supply preprocessor parameters through the VSE EXEC statement PARM

keyword. The preprocessor parameters are described later in this chapter.

If the preprocessor encounters an SQL error, it inserts statements in the modified

source code that cause a subsequent compile (or assemble) to fail.

If the preprocessor encounters a severe error in an SQL statement, all processing

stops. Syntactic checking is only performed on subsequent SQL statements if the

error is not severe. The preprocessor also puts statements in the preprocessed

Chapter 5. Preprocessing and Running a DB2 Server for VSE Program

157

program which will cause a subsequent compile to fail. If successful, the

preprocessor places an entry in the SYSTEM.SYSACCESS catalog to record the

newly created package.

Different job control is required to invoke the preprocessors depending on whether

the system is running in multiple user or single user mode.

Preprocessing by Mode

Prior to invoking any of the preprocessors, data sets for input, output, and work

files must be assigned. Data sets used by each of the preprocessors are shown in

Table 13 and Table 14. Many VSE systems may already have the logical units

assigned and data set labels defined during the IPL procedure.

Table 13. Data Sets Required by All Preprocessors

Data Set

Used For

SYSIPT

Source input is read from here

SYSPCH

Modified source output is written here

SYSLST

Print (report) output is written here

SQLGLOB

CHARNAME and DBCS options are obtained from this VSAM file

SQLBIND

Bind-records (bindfiles) are written to this VSAM file (needed only if the

BIND preprocessor option is specified).

BINDWKF

A VSAM work file used when performing VSAM I/O against the bind file

(needed only if the BIND preprocessor option is specified).

Table 14. Work Files Required for Each Preprocessor

Preprocessor

Data Set

Requirement

Assembler

SYS001

The file must be the same size as the source input file.

SYS001

The file must be the same size as the source input file.

COBOL

SYS001

One logical record for each line of source code plus about 10 records for each

SQL statement. Also, add an allowance for diagnostic messages.

SYS002

Approximately 20 to 60 logical records for each SQL statement. The number

you should reserve depends on the complexity of the SQL statement —

particularly the number of host variables referenced.

SYS003

Approximately 10 to 40 logical records for each SQL statement. (This number

also depends on host variable references.)

SYS004

The file must be the same size as the source input file.

Fortran

SYS001

One logical record for each line of source code plus about 10 records for each

SQL statement. Also, add an allowance for diagnostic messages.

SYS002

Approximately 20 to 60 logical records for each SQL statement. The number

you should reserve depends on the complexity of the SQL statement —

particularly the number of host variables referenced.

SYS003

The file must be the same size as the source input file.

PL/I

SYS001

The file must be the same size as the source input file.

Using Multiple User Mode

When invoking any preprocessor in multiple user mode, it is recommended that

you specify SIZE=AUTO.

158

Application Programming

Figure 30 shows generic job control that invokes a preprocessor in multiple user

mode.

// JOB jobname

// ASSGN SYSIPT,cuu

*-- } Optional - may be

// ASSGN SYSPCH,cuu

*-- }

assigned by

// ASSGN SYSLST,cuu

*-- }

standard label

// ASSGN SYSxxx,cuu

*-- Preprocessor work files

// DLBL SQLGLOB,

,DISP=(OLD,KEEP)

*-- } Optional - may be

// DLBL SQLBIND,

,DISP=(OLD,KEEP)

*-- }

provided by

// DLBL BINDWKF,

*-- }

standard label

// EXEC PGM=ARIPRPx,SIZE=AUTO,PARM=’prepparms’

. Input card stream if SYSRDR and SYSIPT are

. assigned to the same device or file

Note:

JCL must be changed to specify the correct Device address and Library definitions

Replace ARIPRPx with preprocessor name

PrepParms are discussed in “Defining the Preprocessing Parameters” on page 160.

You can code your own LIBDEF statements.

Refer to the DB2 Server for VSE Program Directory for more information on coding LIBDEF statements.

You can replace the input card stream with the READ MEMBER statement if the source file has been

cataloged as membertype A.

Refer to the DB2 Server for VSE Program Directory for more information on the READ MEMBER

statement.

Figure 30. Invoking the DB2 Server for VSE Preprocessor in Multiple User Mode

Using Single User Mode

When invoking any preprocessor in single user mode, you must specify

SIZE=AUTO. The job control for single user mode initializes the system with the

preprocessor name and desired parameters. Figure 31 shows generic job control

that invokes a preprocessor in single user mode:

The job control starts the system and invokes the preprocessor. The EXEC

statement initializes the system in single user mode and passes to it (as a

parameter) the name of the preprocessor (ARIPRPx). Note that the slash (/) is

actually written in the EXEC statement. It separates the general DB2 Server for

VSE options (such as SYSMODE and PROGNAME) from the preprocessor options

(such as PREPNAME and USERID). For prepparms, specify desired preprocessor

parameters; the parameters are in the following section.

The DB2 Server for VSE & VM Operation manual lists all the DB2 Server for VSE

initialization parameters for single user mode. However, the person who installs

the system should determine what the best initialization parameters for your

installation are, and pass these on to you.

Note: COBOL programs invoking COBOL SORT cannot be run in single user

mode.

Chapter 5. Preprocessing and Running a DB2 Server for VSE Program

159

// JOB jobname

// EXEC PROC=ARIS75DB

*-- DB2 for VSE Starter database

// EXEC PROC=ARIS75PL

*-- Library definition

// ASSGN SYSIPT,cuu

*-- } Optional - may be

// ASSGN SYSPCH,cuu

*-- }

assigned by

// ASSGN SYSLST,cuu

*-- }

standard label

// ASSGN SYSxxx,cuu

*-- Preprocessor workfiles

// DLBL SQLGLOB,

,DISP=(OLD,KEEP)

*-- } Optional - may be

// DLBL SQLBIND,

,DISP=(OLD,KEEP)

*-- }

provided by

// DLBL BINDWKF,

*-- }

standard label

// EXEC PGM=ARISQLDS,SIZE=AUTO,PARM=’SYSMODE=S,LOGMODE=A,

PROGNAME=ARIPRPx/prepparms’

. Input card stream if SYSRDR and SYSIPT are

. assigned to the same device or file

Note:

1. JCL must be changed to specify the correct Device address

2. Replace ARIPRPx with preprocessor name

3. PrepParms are discussed in “Defining the Preprocessing Parameters.”

Figure 31. Invoking the DB2 Server for VSE Preprocessor in Single User Mode

Defining the Preprocessing Parameters

The following are parameters for all DB2 Server for VSE preprocessors unless

otherwise noted.

Program Preparation Parameters

►► PARM= ' PREPname=

package_id

►

collection_id.

► ,USERid= authorization_name/password

►

,DBNAME= server_name

►

►◄

,PrepFile=

( membername

)

.membertype

prepparms

prepparms:

,APOST

,NOBIND

,NOBLocK

►

(1)

(2)

,BLocK

,CCSIDGraphic

(integer)

,Quote

,BIND

,IBLocK

160

Application Programming

►

,CCSIDMixed

(integer)

,CCSIDSbcs

(integer)

,NOCHECK

(1)

►

,CHARSUB

(

Sbcs

)

,CHECK

,COB2

,COBRC

Mixed

,ERROR

Bit

,CTOKEN

(NO)

,NOEXIST

►

,CTOKEN

(

)

,DATE

(

EUR

)

,EXIST

ISO

YES

JIS

LOCAL

USA

,EXPLAIN

(NO)

(4)

►

,EXPLAIN

(

)

(3)

,DYNALC

YES

,NOFOR

Notes:

COBOL only (DB2 Server for VSE only).

Ignored by Fortran (DB2 Server for VSE only).

Implied if STDSQL(89) is specified for DB2 Server for VSE.

COBOL, PL/I, C, and Assembler only.

prepparms (continued):

,NOGRaphic

,ISOLation

(RR)

,KEEP

►

(1)

,ISOLation

(

)

,REVOKE

,GRaphic

USER

,LineCount

(60)

,PACKAGE

►

,LABEL

(label_text)

,LineCount

(integer)

,NOPACKAGE

,PRint

,PUnch

,REPLACE

,SEQuence

►

,NOPRint

,NOPUnch

,NEW

(2)

,NOSEQuence

(3)

►

,NOSQLCA

,SQLFLAG

(

SAA

)

(COMPLETE)

Chapter 5. Preprocessing and Running a DB2 Server for VSE Program

161

,STDSQL

(NO)

►

,STDSQL

(

)

,TIME

(

EUR

)

(4)

ISO

JIS

LOCAL

USA

Notes:

PL/1 and COBOL only (DB2 Server for VSE only).

C only.

Implied if STDSQL(89) is specified.

86 is a synonym for 89.

Specify these parameters using the PARM keyword of the VSE job control EXEC

statement. The order in which you specify them is unimportant. You must separate

all preprocessor parameters by a comma or by one or more blanks. (See Table 15.)

Note: The maximum number of bytes that can be included within the quotation

marks after the PARM keyword is 100. Therefore, you should take

advantage of the abbreviations and defaults for the preprocessor parameters.

Table 15. Specifying Preprocessor Parameters

Multiple User Mode

// EXEC PGM=ARIPRPx,SIZE=AUTO,PARM=’PREP=MYJOB,USERID=SAM/SECRET’

Single User Mode

Col. 72 -----------------

// EXEC PGM=ARISQLDS,SIZE=AUTO,PARM=’SYSMODE=S,LOGMODE=A,

PROGNAME=ARIPRPx/PREPNAME=MYJOB,USERID=SAM/SECRET’

In single user mode, the first / separates the preprocessor parameters from the DB2 Server for VSE initialization

parameters. The second / separates the authorization-name from the password in the USERID preprocessor

parameter (described below).

If you want to keep the authorization-name and password secret, you must

suppress the printout of the job control EXEC statement that contains the

preprocessor parameters. To do this, surround the preprocessor job control with the

statements shown in Figure 32.

NOLOG

<--- Suppress display of JCL on the system

// OPTION NOLOG

<--- Suppress output to SYSLST

(c)

LOG

<--- Resume output to the CONSOLE

// OPTION LOG

<--- Resume output to SYSLST

Figure 32. Suppressing Job Control Display of Authorization-Name and Password

If the program is preprocessed successfully and PACKAGE was specified, an entry

is made in the DB2 Server for VSE catalog table SYSTEM.SYSACCESS. The

CREATOR column is set to the value specified for authorization-name; the TNAME

162

Application Programming

column is set to the value specified for PREPNAME. For more information about

the DB2 Server for VSE catalog, refer to the DB2 Server for VSE & VM SQL

Reference manual.

PREPname=package_id

PREPname=collection_id.package-id

The collection_id.package_id is the name by which the database manager

identifies the package. The collection_id portion is optional, and fully qualifies

the package_id and any unqualified objects referenced within the package.

If collection_id is not specified, it defaults to the authorization_name specified on

the USERid parameter. If it is specified, it must equal the authorization_name

specified on the USERid parameter.

USERid=authorization_name/password

The authorization_name is the name by which the application server identifies

the owner of a package. The password should agree with the one established

for this authorization_name by a DB2 Server for VSE GRANT CONNECT

statement. This information is used when executing a CONNECT statement to

gain access to the application server, which determines whether proper

authorization exists for the static SQL statements in the program.

DBNAME=server_name

This parameter identifies the name of the application server to be accessed by

the SQL statements in the preprocessor source file. This parameter is used as

the server_name in the TO clause of the CONNECT statement executed at

preprocessing time. If this parameter is not specified, the preprocessor accesses

the default application server.

Refer to the DB2 Server for VSE System Administration manual for a discussion

of the default application server.

PrepFile=(membername)

PrepFile=(membername.membertype)

The PrepFile parameter identifies the membername and optionally

membertype of a VSE source member containing the list of preprocessor

parameters. If membertype is not specified, it defaults to A.

The following parameters can be specified in the PrepFile or in the

preprocessor parameters. For a more detailed discussion of the options file, see

“Using the Preprocessor Option Member” on page 170.

PrepParm

The following parameters specify the preprocessor options.

APOST

Quote (COBOL preprocessor only)

If you do not specify this parameter, the preprocessor defaults to APOST

and generates single quotation mark (') delimiters for its internal source

declarations. The Quote preprocessor parameter should be used whenever

the Quote parameter is used in the COBOL compiler. Quote causes the

preprocessor to use double quotation marks (") as constant delimiters in

the VALUE clauses of the declarations it generates.

The use of a single quotation mark (') or double quotation marks (") in

SQL statements is not affected by this parameter.

APOST/Quote is stored in the bind file header if BIND is specified and a

bind file is successfully created after preprocessing.

NOBIND

Chapter 5. Preprocessing and Running a DB2 Server for VSE Program

163

BIND

If you specify the NOBIND parameter, the preprocessor does not create a

bind file; NOBIND is the default.

If you specify the BIND parameter, the preprocessor creates a bind file. A

bind file will not be created if NOCHECK is in effect and there was an

error found during SQL statement validation. BIND is ignored if CHECK is

specified. For a more detailed discussion of the bind file, see “Creating a

Package Using CBND and Batch Binding” on page 188.

Note: The Fortran preprocessor ignores the BIND parameter, if specified.

NOBLocK

BLocK

IBLocK

When the BLock parameter is specified, all eligible query cursors return

results in groups of rows, and all eligible insert cursors process inserts in

groups of rows. If the IBLocK parameter is specified, all normal

homogenous inserts are processed in groups. If you do not specify this

parameter, NOBLock is the default. This improves the performance of

programs running in multiple user mode, where many rows are inserted or

retrieved. For a discussion of eligible cursors, see “Using the Blocking

Option to Process Rows in Groups” on page 176.

When NOBLocK is specified, rows are not grouped.

BLock/NOBLock is stored in the bind file header if BIND is specified and

a bind file is successfully created after preprocessing.

If you want to change the BLocK option, you must recompile (or

reassemble) and relink your program after preprocessing it. You must also

use CBND to rebuild the package if BIND is specified. Preprocessing alone

does not change the BLocK setting. You must also use CBND to rebuild the

package if BIND is specified.

CCSIDGraphic (integer)

This parameter specifies the default CCSID attribute to be used for graphic

columns created in the package, if an explicit CCSID is not specified on the

CREATE or ALTER statements in the package. If this parameter is not

specified, the target application server uses the system default. This option

is stored in the bind file header if BIND is specified and a bind file is

successfully created after preprocessing.

CCSIDMixed (integer)

This parameter specifies the default CCSID attribute to be used for

character columns created with the mixed subtype in the package, if an

explicit CCSID is not specified on the CREATE or ALTER statements in the

package. If this parameter is not specified, the target application server

uses the system default. This option is stored in the bind file header if

BIND is specified and a bind file is successfully created after

preprocessing.

CCSIDSbcs (integer)

This parameter specifies the default CCSID attribute to be used for

character columns created with the SBCS subtype in the package, if an

explicit CCSID is not specified on the CREATE or ALTER statements in the

package. If this parameter is not specified, the target application server

uses the system default. This option is stored in the bind file header if

BIND is specified and a bind file is successfully created after

preprocessing.

164

Application Programming

CHARSUB (Sbcs)

CHARSUB (Mixed)

CHARSUB (Bit)

This parameter specifies the character subtype attribute to be used for

character columns created in the package, if an explicit subtype or CCSID

is not specified. If you do not specify this parameter, the target application

server uses the system default. This option is stored in the bind file header

if BIND is specified and a bind file is successfully created after

preprocessing.

NOCHECK

CHECK

ERROR

If you specify the NOCHECK parameter, the preprocessor executes

normally; that is, it validates all SQL statements when performing package

functions. If NOPACKAGE is specified, package functions are not

performed and so NOCHECK is ignored in this case. NOCHECK will be

stored in the BIND file header if BIND is specified and a bind file is

successfully created after preprocessing; NOCHECK is the default.

If you specify the CHECK parameter, the preprocessor checks all SQL

statements for validity and generates error messages if necessary, but does

not generate a package or bind file. PACKAGE and BIND are ignored if

CHECK is specified.

If you specify ERROR, the preprocessor executes normally except that most

statement-parsing errors are tolerated. When one of these errors is

detected, the preprocessor generates an error message in the output listing

and the modified source code in commented form, and continues

processing. The program can be compiled and executed, but the erroneous

statement cannot be executed. If NOPACKAGE is specified, package

functions are not performed and so ERROR is ignored in this case. ERROR

will be stored in the bind file header if BIND is specified and a bind file is

successfully created after preprocessing.

You should use the ERROR option when you are also generating a bind

file and intend to bind it against a remote application server, where at least

one statement in the program is specific to an unlike application server.

COB2 (COBOL preprocessor only)

This parameter enables you to use certain COBOL II functions that are

supported by the COBOL II Release 3 compiler and later. Refer to “Using

the COB2 Parameter (DB2 Server for VSE)” on page 360 for a list of those

functions.

COBRC (COBOL preprocessor only)

If this parameter is specified, the preprocessor will generate the statement

'MOVE ZEROS TO RETURN-CODE' after it generates a call to ARIPRDI.

For more information, see “Using the COBRC Parameter” on page 361

CTOKEN (NO)

CTOKEN (YES)

This parameter causes the preprocessor to store a consistency token in the

modified source code and the package. At run time, consistency tokens in

the program’s load module and package must match before the application

server executes the package. CTOKEN(NO) is the default. If CTOKEN(YES)

is specified, the consistency token generated by the preprocessor will be an

8-byte 390 Time-of-Day (TOD) clock value. If CTOKEN(NO) is specified,

the consistency token will be 8 blanks. For a more detailed discussion of

Chapter 5. Preprocessing and Running a DB2 Server for VSE Program

165

consistency tokens, see “Using a Consistency Token” on page 182. This

option is stored in the bind file header if BIND is specified and a bind file

is successfully created after preprocessing.

DATE (EUR)

DATE (ISO)

DATE (JIS)

DATE (LOCAL)

DATE (USA)

If this parameter is specified, the output date format chosen overrides the

default format specified at installation time; otherwise, all dates will be

returned in the default format specified at installation time. (See the DB2

Server for VSE & VM SQL Reference manual for a description of these

formats.) This option is stored in the bind file header if BIND is specified

and a bind file is successfully created after preprocessing.

NOEXIST

EXIST

If the EXIST parameter is specified, the preprocessor executes normally;

that is, it generates modified source code and performs package functions.

An error will be generated if objects (such as tables) referenced in

statements in the program do not exist or if proper authorization does not

exist.

If the NOEXIST parameter is specified, object and authorization existence

is not required, and if not found, a warning will be issued. NOEXIST is the

default. NOEXIST/EXIST is stored in the bind file header if BIND is

specified and a bind file is successfully created after preprocessing.

EXPLAIN(NO)

EXPLAIN(YES)

This parameter specifies whether explanatory information for all

explainable SQL statements in a package should be produced.

EXPLAIN(NO) is the default.

If EXPLAIN(YES) is specified, each explainable SQL statement in the

program is explained during preprocessing. If you specify EXPLAIN(YES),

an EXPLAIN ALL is executed. The complete set of explanation tables must,

therefore, be available. If they are not available, you receive an SQLCODE

-649

(SQLSTATE = 42704) and preprocessing is not successful. To interpret

the explanation tables, refer to the DB2 Server for VSE & VM Performance

Tuning Handbook manual. This option is stored in the bind file header if

BIND is specified and a bind file is successfully created after

preprocessing.

NOFOR

This parameter enables you to omit the FOR UPDATE OF clause in the

static cursor query statement, and execute positioned updates to any

column in the result table for which you have UPDATE authority. It is

referred to in this manual as NOFOR support.

Note: This option is also implied if the STDSQL (89) or STDSQL (86)

parameter is specified.

DYNALC

This parameter enables you to preprocess an application program

containing FETCH statements for a cursor that is allocated by a dynamic

ALLOCATE CURSOR statement.

166

Application Programming

Note: This option is only accepted by the COBOL, PL/I, C, and Assembler

preprocessors.

NOGRaphic

GRaphic (COBOL and PL/I preprocessors only)

The GRaphic parameter indicates to the preprocessor whether graphic

constants can be used in SQL statements and whether DBCS string format

should be validated. NOGRaphic is the default.

If GRaphic is specified, the preprocessor accepts SQL statements containing

graphic constants, and checks that all strings of DBCS characters are

correctly formatted.

If NOGRaphic is specified, the preprocessor does not allow graphic

constants in SQL statements, and does not verify the format of strings of

DBCS characters.

Note: If the DBCS value in the GLOBAL SQLGLOB parameters is set to

YES, the graphic option is not used and preprocessing occurs as

though GRaphic had been specified. In addition, the default graphic

option becomes GRaphic.

ISOLation (CS)

ISOLation (RR)

ISOLation (UR)

ISOLation (USER)

This parameter lets you specify one of the following isolation levels at

which your program runs:

v Specify RR (repeatable read) to have the database manager hold a lock

on all data read by the program in the current logical unit of work. This

is the default.

v Specify CS (cursor stability) to have the database manager hold a lock

only on the row or page of data pointed to by a cursor.

v Specify UR (uncommitted read) to have the database manager allow

applications to read data without locking, including uncommitted

changes made by other applications.

v Specify USER to have the application program control its isolation level.

See “Selecting the Isolation Level to Lock Data” on page 172 for guidelines

on choosing the isolation level for your program. This option is stored in

the bind file header if BIND is specified and a bind file is successfully

created after preprocessing.

Note: If you want to change the ISOLation option, you must recompile (or

reassemble) and relink your program after preprocessing it. You

must also use CBND to rebuild the package if BIND is specified.

Preprocessing alone does not change the ISOLation setting.

KEEP

REVOKE

These parameters are applicable if the program has previously been

preprocessed, and the owner has granted the RUN privilege on the

resulting package to some other users. Specify the KEEP parameter to

have these grants of the RUN privilege remain in effect when the

preprocessor produces the new package. Specify the REVOKE

parameter to remove all existing grants of the RUN privilege. (These

grants will also be removed if the owner of the program is not entitled

to grant all the privileges embodied in the program.)

Chapter 5. Preprocessing and Running a DB2 Server for VSE Program

167

KEEP is the default. KEEP/REVOKE is stored in the bind file header if

BIND is specified and a bind file is successfully created after

preprocessing.

LABEL (label_text)

This parameter specifies a label for the package. Label_text can be up to

30 characters in length; the default is spaces. This option is stored in

the bind file header if BIND is specified and a bind file is successfully

created after preprocessing.

LineCount (integer)

The parameter determines how many lines per page are to be printed

in the output listing. The value integer specifies the number of lines per

page. The valid range for this value is 10 to 32 767. If no value is

specified, or if there is an error in the specification of the LineCount

parameter, then the default value of 60 is used.

PACKAGE

NOPACKAGE

If you specify the PACKAGE parameter, the preprocessor performs

package functions and creates a package against a local database.

PACKAGE is ignored if CHECK is specified; PACKAGE is the default.

If you specify the NOPACKAGE parameter, the preprocessor does not

perform package functions and will not create a package. If you

specify NOCHECK as well as NOPACKAGE, NOCHECK is ignored. If

you specify ERROR as well as NOPACKAGE, ERROR is ignored.

NOPRint

The PRint parameter specifies that the entire preprocessor modified

source listing output is produced. The NOPRint parameter specifies

that the preprocessor listing output is suppressed, except for the

summary messages that are normally printed at the end. PRint is the

default.

PUnch

NOPUnch

The PUnch parameter specifies that the preprocessor modified source

output is produced. The NOPUnch parameter specifies that the

preprocessor modified source output is suppressed.

REPLACE

NEW

This parameter specifies whether the package being created is new or

whether it will replace an existing package that has the same name. If

REPLACE is specified and no previous package exists with the same

name, no error or warning is issued, and the package is created.

REPLACE is the default. If NEW is specified, an error will occur if the

package already exists with the same name. REPLACE/NEW is stored

in the bind file header if BIND is specified and a bind file is

successfully created after preprocessing.

SEQuence

NOSEQuence (C preprocessor only)

If SEQuence is specified, the preprocessor searches only columns 1

through 72 of the source file. When NOSEQuence is specified, the

preprocessor assumes there are no sequence numbers in the input file

and it accepts input from columns 1 to 80. SEQuence is the default.

168

Application Programming

Note: In the latter case, you must use the NOSEQ and MARGINS

(1,80) C compiler options when compiling the modified source.

NOSQLCA

This parameter allows the user to declare an SQLCODE without

declaring all of the SQLCA structure. It is referred to as NOSQLCA

support in this manual.

Note: This option is also implied if the STDSQL(89) or STDSQL (86)

parameter is specified.

SQLFLAG (SAA)

SQLFLAG (89)

SQLFLAG (89(COMPLETE))

This parameter invokes Flagger, a function that flags those static SQL

statements that do not conform to the SQL-89 standard or IBM’s

Systems Application Architecture* (SAA*) standard on an SQL dialect.

If you specify SAA, it provides syntax checking against the SAA

Database Level 1 standard. If you specify 89, it will provide syntax

checking against the SQL-89 standard. If you specify 89(COMPLETE),

it will provide both syntax and semantics checking against the SQL-89

standard. Note that you cannot check both SAA and SQL-89 in the

same preprocessor run.

See “Using the Flagger at Preprocessor Time” on page 170 for more

details on this facility, including an explanation of the SQL-89

standard.

STDSQL (NO)

STDSQL (89)

STDSQL refers to the SQL Standard that has been implemented in the

user’s application program. If NO is specified or the STDSQL

parameter is not used, the preprocessor uses DB2 Server for VSE

standards. If 89 is specified, functions specific to ANS SQL standard 89

are also provided by the preprocessor. STDSQL(NO) is the default.

These functions consist of the following support:

v NOSQLCA

v NOFOR

Note: STDSQL(86) is a synonym for STDSQL(89).

TIME (EUR)

TIME (ISO)

TIME (JIS)

TIME (LOCAL)

TIME (USA)

If this parameter is specified, the output time format chosen overrides

the default format specified during installation. If it is not specified, all

times will be returned in the default format that was specified during

installation. (See the DB2 Server for VSE & VM SQL Reference manual

for a description of these formats.) This option is stored in the bind file

header if BIND is specified and a bind file is successfully created after

preprocessing.

Chapter 5. Preprocessing and Running a DB2 Server for VSE Program

169

Using the Preprocessor Option Member

Instead of specifying all the preprocessing parameters in the preprocessor job you

can use an options member. This has several advantages. You can maintain a set of

standard options members. They can save time, and ensure consistent use of

preprocessing parameters.

You can use a preprocessor options member by including the PrepFile parameter

when you are preprocessing. The member can contain only one preprocessor

parameter per line. If more are found an error message is returned. Blank lines are

ignored, and the parameters may be in either upper- or lowercase. You can insert

comments into the options file by placing an asterisk (*) to the left of the comment.

Everything to the right of the asterisk is ignored. The file is a VSE source member.

* prep parameters for program SAMPLE

ISOL(CS)

*cursor stability isolation level

TIME(ISO)

BLOCK

*indicate inserts and retrieves in groups

Figure 33. The preprocessor option file example.
