DB2 Server for VSE & VM Application Programming (Version 7 Release 5)

SQL statements are stored with the package when you preprocess the program.

The system uses them to automatically bind the program again. It does this

dynamically (that is, while it is running). If the rebinding works, a new package is

created and stored in the database and the system then continues execution of the

program. If the rebinding does not work, an error code is returned to the program

in the SQLCA, and the program stops running.

A successful rebinding has no negative effect on your program except for a slight

delay in processing your first SQL statement. To minimize this delay, you can use

the DBSU REBIND PACKAGE command to rebind the invalid package after it has

been invalidated, but before it is executed. See the DB2 Server for VSE & VM

Database Services Utility manual for information on this command.

Running by Mode

Using Multiple User Mode

The job control for multiple user mode executes the application program; the

application server must already be initialized. The application program

communicates with the application server, which resides in a separate partition,

through the DB2 Server for VSE linkage module (ARIPRDID or ARIRRTED). The

linkage module is given control for each SQL statement in the application program.

You can invoke the application with standard job control statements or CICS/VSE

procedures. It is recommended that you specify SIZE=AUTO. (Specify SIZE=750K

for PL/I programs.) Figure 34 shows job control for invoking programs in multiple

user mode:

// JOB USER PROGRAM

// EXEC PGM=MYPROG,SIZE=AUTO

Figure 34. Invoking a User Program in Multiple User Mode

Using Single User Mode

The job control for single user mode invokes the application server and passes to

the system the name of the application to be run. The system then loads and

invokes the application program. Once the single user mode application receives

control, it accesses the application server in the same way as multiple user mode

applications. The system supports the VSE register save conventions. See the DB2

Server for VSE System Administration manual for more about single user mode

execution using the VSE register save conventions.

The DB2 Server for VSE & VM Operation manual lists all the initialization

parameters you can specify when you start the system in single user mode. A

system programmer can also determine the best initialization parameters for your

installation and pass them on to you.

Figure 35 on page 184 shows job control for invoking programs in single user

mode. The SIZE=AUTO specification is required. (Specify SIZE-AUTO, 750K for

PL/I programs.)

Chapter 5. Preprocessing and Running a DB2 Server for VSE Program

183

// JOB SINGLE

// EXEC PGM=ARISQLDS,SIZE=AUTO,PARM=’SYSMODE=S,PROGNAME=name’

Figure 35. Invoking a User Program in Multiple User Mode

If your program or the system abnormally ends, you may receive a mini-dump

(depending on what initialization parameters were specified when the system was

started). Mini-dumps are described in the DB2 Server for VSE System Administration

manual.

Running under CICS/VSE Support

DB2 Server for VSE-CICS/VSE support must be initialized before applications can

be run as CICS/VSE transactions. Usually the CICS/VSE support is initialized

when the system is started. Once the support is started, you can use normal

CICS/VSE procedures to invoke transactions that use the system. See the DB2

Server for VSE System Administration manual for more information on starting and

stopping CICS/VSE support.

Accessing Other DB2 Family Application Servers

If your VSE/ESA has been initialized as a VSE/ESA guest system under VM, your

(multiple user mode) VSE application can access a DB2 Server for VM application

server. Therefore, if the application was designed to run in single user mode it

must be converted to multiple user mode. This conversion can be accomplished by

modifying the job control language (JCL). See the DB2 Server for VSE System

Administration manual for more information on VSE Guest Sharing.

Your online CICS/VSE application can also use the DRDA protocol to access other

DB2 Family application servers, including DB2 Server for VM, DB2 Universal

Database Server for OS/390, or DB2 Universal Database (UDB). Before doing this,

the DRDA requester code must be installed on your VSE system. Also each DB2

Family server to be accessed must be defined to the DB2 Server for VSE online

resource adapter as a remote application server. See the DB2 Server for VSE System

Administration manual for more details on defining remote application servers.

Installing Applications that Access the Database Manager

Installing a Batch Application

Installing a batch application involves running the application through a DB2

Server for VSE preprocessor. The preprocessor output must be compiled (or

assembled), and the object decks must be link-edited. Refer to Figure 36 on page

185 for generic JCL for these tasks.

184

Application Programming

MYPROG program name

DLBL IJSYSPH,’PREPROCESSOR.OUTPUT’,0

*-- PREPROCESSOR output

EXTENT SYSPCH,

*--

ASSGN SYSPCH,

*-- SYSPCH assignment

LIBDEF

*-- Library definitions

ASSGN SYSxxx,...

*-- Preprocessor workfiles

DLBL SQLGLOB,

,DISP=(OLD,KEEP)

*-- SQLGLOB parm file

DLBL SQLBIND,

,DISP=(OLD,KEEP)

*-- BIND output file

DLBL BINDWKF,

*-- BIND work file

EXEC ARIPRPx,SIZE=AUTO,PARM=’USERID=SQLDBA/SQLDBAPW,PREPNAME=MYPROG,*

KEEP,

’

*-- Invoke DB2 for VSE PREPROCESSOR

MYPROG input here if SYSRDR and SYSIPT assigned to same device

CLOSE SYSPCH,00D

*-- Close SYSPCH

DLBL IJSYSIN,’PREPROCESSOR.OUTPUT’,0

*-- Input File

EXTENT SYSIPT,

*--

ASSGN SYSIPT,

*--

OPTION CATAL

*--

ACTION MAP

*--

PHASE MYPROG,*

*--

EXEC compiler

*-- Compile

INCLUDE ARIPRDID

*-- DB2 for VSE Resource

Adapter stub

INCLUDE

*-- Include runtime routines

EXEC LNKEDT

*-- Link Edit

CLOSE SYSIPT,00C

*-- Reset SYSIPT

Notes:

1. JCL must be changed to specify the correct DASD extents, Device address, Compiler references & Library

definitions

2. Replace ARIPRPx with the preprocessor name

3. See Table 14 on page 158 for a list of preprocessor work files

4. See “Link-Editing and Loading the Program” on page 180 for a complete list of modules to be included.

Figure 36. Creating an Object Deck and Phase for a Batch Program (Multiple User Mode)

Installing an Online CICS/VSE Application

Two steps are required to install an online application:

1. You must run the application through a DB2 Server for VSE preprocessor. If the

application uses the EXEC CICS interface, it must also be run through the

CICS/VSE translator. The CICS/VSE translator output must be compiled (or

assembled), and the object decks must be link-edited.

2. CICS/VSE must be made aware of the application. You must define the

CICS/VSE transaction identifier to be used to activate the application, and

define the phase associated with the transaction identifier. Refer to Figure 37 on

page 186 for generic JCL for these tasks.

Chapter 5. Preprocessing and Running a DB2 Server for VSE Program

185

MYPROG program name

DLBL IJSYSPH,’PREPROCESSOR.OUTPUT’,0

*-- PREPROCESSOR output

EXTENT SYSPCH,

*--

ASSGN SYSPCH,...

*-- SYSPCH assignment

LIBDEF

*-- Library definitions

ASSGN SYSxxx,...

*-- Preprocessor workfiles

DLBL SQLGLOB,

,DISP=(OLD,KEEP)

*-- SQLGLOB parm file

DLBL SQLBIND,

,DISP=(OLD,KEEP)

*-- BIND output file

DLBL BINDWKF,

*-- BIND work file

EXEC ARIPRPx,SIZE=AUTO,PARM=’USERID=SQLDBA/SQLDBAPW,PREPNAME=MYPROG,*

KEEP,

’

*-- Invoke DB2 for VSE PREPROCESSOR

MYPROG input here if SYSRDR and SYSIPT assigned to same device

CLOSE SYSPCH,00D

*-- Close SYSPCH

For ASSEMBLER only, convert to 80 byte input format for

CICS Translator, dropping the stacker select prefix added

to SYSPCH above. See notes for details

DLBL IJSYSIN,’PREPROCESSOR.OUTPUT’,0

*--} For ASSEMBLER replace

EXTENT SYSIPT,

*--} with statements in the

ASSGN SYSIPT,...

*--} notes section

DLBL IJSYSPH,’TRANSLATOR.OUTPUT’,0

*-- CICS Translator output

EXTENT SYSPCH,

*--

ASSGN SYSPCH,...

*--

EXEC DFHExP1$,SIZE=400K

*-- CICS Translator

CLOSE SYSIPT,00C

*--

CLOSE SYSPCH,00D

*--

DLBL IJSYSIN,’TRANSLATOR.OUTPUT’,0

*-- CICS Translator output

EXTENT SYSIPT,

*--

(input to the compiler)

ASSGN SYSIPT,...

*--

OPTION CATAL

*--

ACTION MAP

*--

PHASE MYPROG,*

*--

INCLUDE DFHxxxx

*-- CICS host language module

EXEC compiler

*-- Compile

INCLUDE ARIRRTED

*-- DB2 for VSE Resource

Adapter stub

INCLUDE

*-- Include runtime routines

EXEC LNKEDT

*-- Link Edit

CLOSE SYSIPT,00C

*-- Reset SYSIPT

Figure 37. Creating an Object Deck and Phase for an Online Program (Multiple User Mode) (Part

186

Application Programming

Notes:

1. JCL must be changed to specify the correct DASD extents, Device address, Compiler/Translator references and

Library definitions

2. Replace ARIPRPx with the preprocessor name

3. Replace DFHExP1$ with the CICS Host Language Translator

4. See Table 14 on page 158 for a list of preprocessor work files

5. See “Link-Editing and Loading the Program” on page 180 for a complete list of modules to be included

6. For assembler and C, the following statements are to replace the three statements identified in the JCL:

// DLBL UIN,’PREPROCESSOR.OUTPUT’,0

*-- Output from DB2 for VSE Preprocessor

// EXTENT SYS004,

// ASSGN SYS004,...

// DLBL UOUT,’OBJMAINT.OUTPUT’,0

*-- Output from strip operation

// EXTENT SYS005,

// ASSGN SYS005,..

// EXEC OBJMAINT

./ LIST PARM=JOB

./ BLOCK BLKSIZE=80

./ COPY

// DLBL IJSYSIN,’OBJMAINT.OUTPUT’,0

*-- Input to Translator

// EXTENT SYSIPT,

// ASSGN SYSIPT,..

Figure 37. Creating an Object Deck and Phase for an Online Program (Multiple User Mode) (Part 2 of 2)

Distributing Packages across Like and Unlike Systems

To run your application program on another DB2 Server for VSE & VM database

manager, you can simply distribute its load module and the DB2 Server for VSE &

VM package. (You do not have to distribute the source code and then preprocess

and compile it on the other system). Reload the package to all application servers

that your package accesses, and send the load module to all DB2 Server for VSE &

VM application requesters that your program accesses. You can unload the package

to be distributed from the application server into a file, and subsequently reload

the file into the new application server. Only the owner of the package or the

database administrator can unload or reload the package.

If the package is distributed among application servers that are at different release

levels of the system, a run-time error occurs if the package uses a feature that is

not available on the application server on which the package was reloaded. To

ensure that the load module and the package that you are distributing are meant

to be used together, use the preprocessor parameter CTOKEN to place the same

consistency token in both the load module and the package. Refer to

“Preprocessing the Program” on page 156. If the two tokens do not match, the

application server stops the program from running. For information on distributing

packages on both like and unlike systems, refer to the DB2 Server for VSE & VM

Database Services Utility manual.

If your Batch/VSE or CICS/VSE application is to run at other DB2 Family

application servers, do the following:

v When you preprocess your application, specify the BIND option so that a bind

file is created.

v If CICS/VSE, CICS translate, compile, and linkedit the preprocessor source

output to create a VSE phase.

v If Batch, compile, and linkedit the preprocessor source output to create a VSE

phase.

Chapter 5. Preprocessing and Running a DB2 Server for VSE Program

187

v Use the CBND transaction or Batch Binder to generate a package at each DB2

application server at which the application is to be run. CBND uses the bind file

created in the preprocessor step above.

For more information on CBND, see “Creating a Package Using CBND and Batch

Binding.”

Creating a Package Using CBND and Batch Binding

Binding is the process of creating packages against local or remote application

server. Binding can be performed through online binder (CICS transaction CBND)

or Batch Binder (program ARIPBIN). Both CBND or Batch Binder require that

preprocessing creates the bindfile successfully. The same bindfile can be used as

input for CBND or ARIPBIN. The output of preprocessing with ″BIND″ option is

termed as bind-record (bindfile) in VSE. The bind-record (bindfile) contains prep

parameters and modified SQL statements for each preprocessed program. In VSE,

one bind-record (bindfile) per program is written to the KSDS VSAM bindfile as a

series of records. The bind-records for multiple programs can be written to the

VSAM bindfile, unlike VM that creates one CMS bindfile for each program. CBND

or Batch Binder takes specific bind-record(bindfile) as input from the VSAM

bindfile for the package creation.

Note: In VSE, the terms bindfile and bind-record are same. These tems are used

interchangeably. VSAM bindfile refers to a VSAM KSDS dataset that stores

bind-record (bindfile) for each preprocessed program as a sequence of

records.

CBND -Online Binding

If a bind-record (bind file) file is generated after preprocessing, it can be used to

create a package in a remote or local application server. This enables the CICS

online application program to access a remote DRDA server. To convert the SQL

statements in a bind file into a package, use the CBND CICS transaction. CBND

can be used to bind all applications whose bind file was generated by the

preprocessor to a remote or local server. To create a package locally, for a Fortran

application, you still need to run the batch preprocessor. Executing the

preprocessor with the BIND option and executing CBND are complementary. The

preprocessor creates and stores the bind file in a master or private VSAM file and

CBND reads the bind file back into an application server.

If using the CBND command, you must be either the owner of the program whose

bind file you are binding to a remote server or a database administrator.

A second level transaction, CB2D, is required for CBND to complete the bind

process. The CB2D transaction is invoked internally by CBND through an EXEC

CICS START command. One or more CB2D transactions can be started by one

CBND transaction based on the number of application servers specified in the

CBND DBLIST input parameter. Each CB2D is responsible for connecting to a

target database and creating a package. This transaction needs to be defined

during installation to fully enable the CBND function.

The CBND transaction has 13 parameters:

188

Application Programming

►► CBND PACKAGE(

package_id)

►

collection_id.

►

INfile

( private_file_id

)

►

►◄

▼

NEW

REPLACE

KEEP

REVOKE

OWner

( authorization_name

)

QUALifier

( collection_id

)

NOCHECK

CHECK

ERROR

DBList

(

▼

server_name

)

USERid

( authorization_name/password

)

MSGQueue

( name

)

QRY

Note: For any options not specified on the CBND transaction, the default option will be

the option specified when the package was preprocessed, unless otherwise noted.

Batch Binder

If a bind-record (bind file) is generated after processing, it can be used to create a

package in a remote or local application server. Batch Binder can be used to bind

all applications whose bind-record (bind file) was generated by the preprocessor, to

a remote or local server. Executing the preprocessor with the BIND option and

executing Batch Binder are complementary. Batch Binder cannot be used to create

the packages for FORTRAN.

Batch Binder can be invoked by calling batch binding phase ARIPBIN through jcl

to perform binding. Batch Binder jcl must use same DLBL statement for SQLBIND

that was used at the time of preprocessing the program. Binder does not require

bind Work file. Batch binder takes 11 parameter through param parameters.

Table 17. Data Sets Required by All Preprocessors

Data Set

Used For

SYSLST

Print (report) output is written here

SQLGLOB

CHARNAME and DBCS options are obtained from this VSAM file

SQLBIND

SQLBIND points to VSAM bindfile

Chapter 5. Preprocessing and Running a DB2 Server for VSE Program

189

// JOB BATCH BINDER

// LIBDEF *,SEARCH=(STSPVT.DEVELOP,STSPVT.DB2750)

// ASSGN SYSIPT,SYSRDR

// DLBL VSEUCAT,’VSEMCH.USER.CATALOG’,,VSAM

// DLBL SQLGLOB,’V750.DB2750.GLOB.FILE’,,VSAM,CAT=V750CAT,

DISP=(OLD,KEEP)

// DLBL SQLBIND,’V750.DB2750.BIND.FILE’,,VSAM,CAT=V750CAT,

DISP=(OLD,KEEP)

// EXEC PGM=ARIPBIN,SIZE=AUTO,PARM=’bindparms’

Figure 38. Invoking the DB2 Server for VSE Binder (Part 1 of 2)

Notes:

1. JCL must be changed to specify the correct libdef and library.

2. Parameters of ’bindparms’ are discussed in ″Binding Parameters″ below.

3. A typical invocation of ARIPBIN phase with bind parameters:

// EXEC ARIPBIN,SIZE=AUTO,PARM=’PACKAGE(COLID.PACK),DB(DBNAME),

USERID(USER1/PASSWD1),OWNER(OWNER1),NEW’

Figure 38. Invoking the DB2 Server for VSE Binder (Part 2 of 2)

Refer to DB2 Server for VSE Program Directory for more information on coding

LIBDEF statements.

Binding Parameters (BindParms)

Binding parameters mentioned below are common to CBND and Batch Binder

unless otherwise stated.

Table 18. Binding Parameters

Parameter

Description

PACKAGE (positional

This parameter identifies the package to be created and the

parameter 1)

associated bind file. The associated bind file must be created by the

DB2 Server for VSE preprocessor and its contents must not be

changed in any way. collection_id.package_id is the name by which

the database manager identifies the package to be created and the

associated bind file. The collection_id portion is optional, and fully

qualifies the package_id and any unqualified objects referenced

within the package.

If the collection_id is not specified, and the user_id is, the

collection_id defaults to the user_id. If neither is specified, the

collection_id defaults to the connected authorization-id.

You must be the owner of the bind file that you want to bind. To

bind another user’s bind file, you must have DBA authority.

190

Application Programming

Table 18. Binding Parameters (continued)

Parameter

Description

REPLACE

This parameter is specified if an existing package is to be replaced

by the bind. If the package does not exist, a new package is created

without an error or warning message.

KEEP causes the existing grants of RUN privilege to remain in

effect when the package is bound. However, if the owner of the

package is not entitled to grant all privileges embodied in the

package, all existing grants of the RUN privilege are revoked. The

KEEP and REVOKE parameters apply if the package has

previously been created and the owner of the package has granted

the RUN privilege on the resulting package to other users. The

KEEP and REVOKE parameters are allowed only with REPLACE.

If the REVOKE parameter is specified, all existing grants of the

RUN privilege are revoked. The KEEP and REVOKE parameters

are allowed only with REPLACE.

NEW

The NEW parameter is specified if the package to be created does

not exist and is to be created. If the package with the same name

and owner already exists in the remote application server, binding

fails.

OWner

This parameter specifies the authorization_name of the owner of the

package being created. The OWner parameter is to be used when

you are binding against a remote application server. However, if

you specify this parameter when binding against a local DB2

Server for VSE & VM application server, the authorization_name

must be the same as the application server authorization ID.

QUALifier

This parameter specifies the default collection_id within the package

to resolve unqualified object names in static SQL statements.

The QUALifier parameter is meant to be used when you are

binding against a remote application server. If you specify this

parameter when binding against a DB2 Server for VSE & VM

application server, the collection_id must be the same as the

application server authorization ID.

NOCHECK

This parameter is specified if you want the application server to

check all SQL statements for validity and perform package

functions. It will generate a package if no statement-parsing error

was found; If you specify the NOCHECK parameter, it overrides

the ERROR parameter in the bind file

CHECK

This parameter is specified if you want the application server to

check all SQL statements for validity and generates error messages

if necessary, but does not generate a package; If you specify

CHECK parameter, it overrides NOCHECK or ERROR parameter

in the bind file.

Chapter 5. Preprocessing and Running a DB2 Server for VSE Program

191

Table 18. Binding Parameters (continued)

Parameter

Description

ERROR

This parameter specifies how statement parsing errors are

tolerated. If the ERROR option is specified, then syntactic or

semantic errors detected at the application server side will not stop

the creation of the package. If the ERROR option is not specified in

both binding and the bind file, the application server will not

create the package when those errors occur.

With the ERROR option, a syntactic error will cause the DB2 for

VSE & VM database to generate an Error Section in the package.

At run-time, invocation of this statement will yield SQLCODE -525

With the ERROR option, the creation of a package fails only if

there was a DRDA protocol error, or a severe error detected on the

AS side.

QRY

This parameter causes binder (online/batch) to display the

preprocessor options stored in the header of the bind file. No

package functions will be performed if QRY is specified.

For CBND only:

The preprocessor options will be displayed at the terminal where

CBND was invoked. MSGQueue is ignored if QRY is specified.

An example of displayed output of binding with QRY option is as

follows:

ARI5418I - THE BIND OPTIONS CURRENTLY IN EFFECT FOR

- PACKAGE SQLDBA.MYPROG ARE:

- NOCHECK

- KEEP

- BLOCK

- ISQL(CS)

- EXPLAIN(NO)

- APPLICATION SERVER DEFAULT DATE

- APPLICATION SERVER DEFAULT TIME

- NOEXIST

- REPLACE

- APOST

- CTOKEN(NO)

- CCSIDS(500)

- CCSIDM(0)

- CCSIDG(0)

- APPLICATION SERVER DEFAULT CHARSUB

- DEFAULT PACKAGE LABEL

192

Application Programming

Table 18. Binding Parameters (continued)

Parameter

Description

INfile

This parameter identifies the 7-character VSAM file name that

stores the bind-records (bindfiles) created by the preprocessor. This

file is used as DLBL filename which identifies the VSAM bindfile

used for input. If this parameter is omitted, the bind-record

(bindfile) is assumed to reside in the master VSAM file named

SQLBIND. If your bind-record (bindfile) resides in a private VSAM

file, you will then specify the 7-character private file name.

SQLBIND is also used as the DLBL label which identifies the

bindfile used for input. DLBL label name must be SQLBIND

irrespective of usage of private VSAM file or default VSAM file.

For CBND only:

VSAM bindfile must be defined to CICS through FCT or RDO

(CICS/ESA R410). Default SQLBIND is defined to CICS during

installation. If using private VSAM bindfile, you must make sure

that this VSAM file is properly defined to CICS.

DBname

This parameter applies to Batch Binder only. This parameter

specifies the name of the target application server. If this parameter

is omitted, the bind file is bound to the default application server.

DBList

This parameter applies to CBND only. This parameter specifies a

list of application servers on which the bind file will be bound.

If this parameter is omitted, the bind file is bound to the default

application server. For more information on establishing a default

application server, see the DB2 Server for VSE & VM Database

Administration manual.

USERid

This parameter specifies the userid and password that CBND or

Batch Binder will use to execute a CONNECT statement to gain

access to each application server where the package will be

created. This parameter cannot be omitted for Batch Binder.

If this parameter is omitted, CBND will connect implicitly to the

application server where the package will be created. That is, the

online resource adapter will establish the userid for this particular

CBND transaction. For more information on how the userid is

established in the case of an implicit connect, see the DB2 Server for

VSE & VM Database Administration manual.

MSGQueue

This parameter applies to CBND only. This parameter specifies the

name of the temporary storage queue to be used to store the bind

error or warning message (if any). If this parameter is omitted, no

error or warning message will be stored, CBND will just display a

summary report of the bind process on the terminal where CBND

was invoked. The summary report contains the bind options used

for the bind process, host variables, declarations, and the result of

the bind. The user can browse the message queue specified using

CEBR when CBND completes. This queue is kept in main storage

and is not recoverable. It stays until it is purged by CEBR or if

CICS is recycled. The user must determine when they should

delete queues that are no longer needed to prevent possible short

on temporary storage situations.

The preprocessor requires the job control statement DLBL SQLGLOB. In addition,

when you want the preprocessor to generate a bind file, job control statements

DLBL SQLBIND and DLBL BINDWKF are required. These DLBL statements must

Chapter 5. Preprocessing and Running a DB2 Server for VSE Program

193

be provided in either the preprocess job control or the system standard label area.

The DLBL SQLBIND indicates the VSAM file into which the preprocessor should

place the output bind file. The BINDWKF indicates the work file into which the

preprocessor should use when performing VSAM I/O against the bind file. The

DLBL SQLGLOB contains the CHARNAME and DBCS options which are

necessary for bind file creation. See Figure 39. As mentioned earlier, you can

suppress SQLBIND output through CHECK and NOBIND parameters of the

preprocessor.

// DLBL

SQLBIND,’DB2.BIND.MASTER’,,VSAM,CAT=catalog,DISP=(OLD,KEEP)

// DLBL

BINDWKF,’DB2.BIND.WORKF’,,VSAM,CAT=catalog

// DLBL

SQLGLOB,’DB2.SQLGLOB.MASTER’,,VSAM,CAT=catalog,DISP=(OLD,KEEP)

Figure 39. DLBL Statements for SQLBIND and SQLGLOB VSAM file

A user can choose to store the bind file generated by the preprocessor in a master

DB2 Server for VSE VSAM bind file, or in a private VSAM bind file.

If a user chose to have his application program’s bind file stored in the master DB2

Server for VSE VSAM bind file, the user should specify the recommended VSAM

dataset name “DB2.BIND.MASTER” on the DLBL SQLBIND job control statement.

This master VSAM bind file is defined to the system when DB2 Server for VSE

Version 7 Release 1 was installed. Therefore, the user does not need to define or set

up the file. However, if a different cluster name was used to define the master

VSAM file, the user should then specify the corresponding dataset name used.

If a user chose to have the application program’s bind file stored in a private

VSAM bind file, the user must specify the name of the private VSAM bind file on

the DLBL SQLBIND job control. The user must first define the private VSAM bind

file, using the same VSAM characteristics as the master VSAM bind file. For more

information on how to define the VSAM cluster for the private bind file, see the

DB2 Server for VSE Program Directory.

194

Application Programming

Doing Your Own Testing

Checking Warnings and Errors at Preprocessor Time

If errors or warnings are detected during preprocessing, the preprocessor inserts

messages into the modified source code and preprocessor listing files to indicate

that a problem was encountered. A return code is also issued indicating the

severity of the problem.

Messages associated with warning conditions are inserted into the files in comment

form so that the compilation of the modified source code is not inhibited. A return

code of 4 is issued and, if no problems of greater severity are found, package

processing occurs. All warnings should be investigated, because they may indicate

a situation that must be corrected before the program is executed. For example, if

you use the NOEXIST preprocessor option and a table is not found at

preprocessing time, the database manager issues a warning because it assumes that

the table will be created before the program is executed. If the program is executed

and the table is not found, the successful execution of the program is inhibited and

an error results.

DB2 Server for VM

Messages associated with error conditions are treated differently if the

preprocessor option ERROR is specified.

When you are preprocessing without the ERROR option, messages are

inserted in the files in uncommented form so that the compilation process is

inhibited. A return code of 8 or greater is issued, and no package processing

occurs.

When preprocessing with the ERROR option, most statement-parsing errors

are tolerated. Messages associated with these errors are inserted into the files

in commented form, and the return code is downgraded to a warning:

detection of these errors does not inhibit package processing. However, some

statement-parsing errors, such as errors with host identifiers and all errors

that could jeopardize the integrity of the package, are too severe to be

ignored. Such errors are treated as outlined for preprocessing without the

ERROR option.

Because the ERROR option allows preprocessing to complete successfully

even though errors have been detected, ensure that each statement is

preprocessed successfully on the application server on which the statement

will be executed. Check the preprocessor listing associated with the binding

application server.

DB2 Server for VSE

When you are preprocessing, messages associated with error conditions are

inserted in the files in uncommented form so that the compilation process is

inhibited. A return code of 8 or greater is issued, and no package processing

occurs.

To check for error and warning conditions:

196

Application Programming

1. Scan the modified source code or preprocessor listing file for error and warning

message. Error message numbers are formatted as ARInnnnE, and warning

message numbers as ARInnnnW or ARInnnnI.

Messages generated during preprocessor initialization and termination are

stored in the listing file, not in the modified source code. A listing file

containing these messages is produced regardless of whether the NOPRint

preprocessor parameter is specified.

2. Look up the message numbers, SQLCODES and SQLSTATES issued by the

system in the DB2 Server for VM Messages and Codes or the DB2 Server for VSE

Messages and Codes manual.

3. If the error was detected by a non-DB2 Server for VM application server or

non-DB2 Server for VSE application server, look up the SQLCODE and

SQLSTATE explanations in the Messages and Codes manual associated with the

database management system that detected the problem.

4. Use ISQL HELP for online information about messages and SQLCODEs issued

by the database manager. To obtain limited online help information for

SQLSTATEs, type HELP SQLSTATE from ISQL.

Testing SQL Statements

Several facilities are available to help you test SQL statements:

v Interactive facilities such as ISQL or QMF can be used for testing statements;

however, the range of statements that can be tested with these facilities is

limited. For example, you cannot test the following:

- Statements that use host language delimiters, host variables, cursors, or

statement names.

- Dynamic or extended dynamic SQL statements.

For other static SQL statements, however, these facilities are fast and easy to use,

and you can do data definitions, authorizations, and data control tasks. For

information on ISQL, see the DB2 Server for VSE & VM Interactive SQL Guide and

Reference manual.

v The DBS Utility can be used for testing the same range of SQL statements that

can be tested using ISQL or QMF. In addition, it lets you use file input and

output, which makes submitting and reviewing test conditions easier, and lets

you set up and restore test databases with DBS Utility data load and unload

commands. For information on the DBS Utility, see the DB2 Server for VSE & VM

Database Services Utility manual.

v DB2 Server RXSQL can be used for testing statements with host variables,

statement names, and cursors. You can test dynamic and extended dynamic SQL

statements. DB2 Server RXSQL can be used to prototype application programs.

For information on DB2 Server RXSQL, see the DB2 REXX SQL for VM/ESA

Installation and Reference manual.

Using the Automatic Error-Handling Facilities

Every SQL application program must provide for error handling, by declaring an

SQL Communications Area (or alternatively, just the SQLCODE variable, as

described later in this section). This area receives messages that the database

manager sends to the program. By testing certain fields of this area, you can test

for certain conditions during the program’s execution.

Error handling helps protect the integrity of the database when a program fails.

For example, consider the two-step operation needed to transfer $500 from one

account to another in a bank:

Chapter 6. Testing and Debugging

197

1. Subtract $500 from account A

2. Add $500 to account B.

If the system or your program fails after the first statement is executed, some

customer has just “lost” $500. This type of incomplete update is said to leave the

database in an inconsistent state.

To avoid creating an inconsistent state, use a logical unit of work (LUW). An LUW

is a group of related SQL statements, possibly with intervening host language

code, that you want treated as a unit. The two steps in the previous example

would make up a single LUW. SQL requests within an LUW can be made against

a remote application server; such an LUW is called a remote unit of work.

LUWs prevent inconsistencies caused by system errors or SQL statement errors.

For system errors, the system automatically restores all changes made during the

LUW where it encountered the error. This rollback of the LUW is identified by a

negative SQLCODE and a W in the SQLWARN6. When a non-severe SQL error

occurs, the system restores all changes made by the statement in error. This

statement rollback is identified by a negative SQL code and a blank in

SQLWARN6. For work done in the LUW before execution of the statement in error,

do the following:

v Declare an SQL Communications Area (or just the SQLCODE variable)

v Code an SQL WHENEVER statement

v Code the actions to be taken if an error occurs.

To declare the SQL Communications Area (SQLCA), code this statement in your

program:

INCLUDE SQLCA

When you preprocess your program, the system inserts host language variable

declarations in place of the INCLUDE SQLCA statement, and SQL communicates

with your program using this group of variables. The system uses the variables for

warning flags, error codes, and diagnostic information. All these variables are

discussed in the DB2 Server for VSE & VM SQL Reference manual.

The system returns a return code in SQLCODE after executing each SQL statement.

When a statement is executed successfully, SQLCODE is set to 0 (SQLSTATE is

'00000'). The system indicates error conditions by returning a negative SQLCODE.

A positive SQLCODE indicates normal or warning conditions experienced while

executing the statement.

The system also returns a return code in SQLSTATE after executing each SQL

statement. SQLSTATE provides common return codes for IBM’s relational database

products. SQLSTATE values comply with the SQL92 standard. For a discussion of

return codes in SQLSTATE, refer to the DB2 Server for VSE & VM SQL Reference

manual.

The system supports a stand-alone SQLCODE. If you request this support, you

must not include the SQLCA definition in your program. You must, however,

provide the integer variable SQLCODE (SQLCOD in Fortran). Refer to “Parameters

for SQLPREP EXEC for Single and Multiple User Modes” on page 118 or “Defining

the Preprocessing Parameters” on page 160 for information on the preprocessor

parameters that provide NOSQLCA support.

The following WHENEVER statement specifies a system action that is to occur

when an SQL error (that is, a negative SQLCODE) is returned:

198

Application Programming

WHENEVER SQLERROR GO TO ERRCHK

That is, whenever an SQL error (SQLERROR) occurs, program control is

transferred to code which follows a specific label, such as ERRCHK. This code

should include logic to analyze the error indicators in the SQLCA. Depending on

how ERRCHK is defined, action may be taken to execute the next sequential

program instruction, to carry out some special functions, or, as in most cases, to

roll back the current LUW and end the program.

Using the SQLCA

As mentioned previously, the database manager returns a return code in the

SQLCA after almost every SQL statement. The only statements that do not return

SQLCODEs are SQL declarative statements, which are not executed; therefore, no

SQLCODE can be returned. (Never test for an SQLCODE after a declarative

statement.) The following are examples of declarative statements:

v BEGIN DECLARE SECTION

v END DECLARE SECTION

v WHENEVER

v INCLUDE SQLCA

v INCLUDE SQLDA.

When a nondeclarative statement is in error, the system reverses any changes to

the database caused by that statement. For any previous work done in the LUW,

you have to tell the system what action to take.

Table 19 shows a representation of the SQLCA structure with host-language

independent data type descriptions. (Refer to the appendixes for the SQLCA data

types of a particular programming language.)

Table 19. SQLCA Structure (in Pseudocode)

SQLCA -- a structure composed of:

SQLCAID -- character string of length 8

SQLCABC -- 31-bit binary integer

SQLCODE -- 31-bit binary integer

SQLERRM -- varying character string of maximum length

SQLERRP -- character string of length 8

SQLERRD -- an array composed of:

SQLERRD(1) -- 31-bit binary integer

SQLERRD(2) -- 31-bit binary integer

SQLERRD(3) -- 31-bit binary integer

SQLERRD(4) -- 31-bit binary integer

SQLERRD(5) -- 31-bit binary integer

SQLERRD(6) -- 31-bit binary integer

SQLWARN -- a sub-structure composed of:

SQLWARN0 -- single character

SQLWARN1 -- single character

SQLWARN2 -- single character

SQLWARN3 -- single character

SQLWARN4 -- single character

SQLWARN5 -- single character

SQLWARN6 -- single character

SQLWARN7 -- single character

SQLWARN8 -- single character

SQLWARN9 -- single character

SQLWARNA -- single character

SQLSTATE - character string of length 5

Chapter 6. Testing and Debugging

199

The DB2 Server for VSE & VM SQL Reference manual explains the structure of the

SQLCA, and describes each field in detail. Some tips about SQLERRM and

SQLWARN fields are provided below.

Using the SQLERRM Field

The message texts associated with particular SQLCODEs (which can be found in

the DB2 Server for VM Messages and Codes or the DB2 Server for VSE Messages and

Codes manual) or retrieved with a call to ARIGMSG (refer to “Examining the

SQLCA” on page 202 for more information), often include variables which are

returned in the SQLERRM field of the SQLCA. In some situations, the format of

the last variable in the SQLERRM field is 'FOnn', which specifies the format

number of the SQLCODE message text. The 'FO' is an abbreviation for format, and

'nn' represents the number that identifies the version of the message text that

applies. If there is more than one variable returned through SQLERRM, the

variables are separated by X'FF'.

The first two bytes of SQLERRM (which is varying-length) contain the total length

of the string.

See “Handling Numeric Conversion Errors” on page 213 for the values of this field

when a numeric conversion occurs in an outer select and “Handling Errors in a

Select-List” on page 212 for the values when an error occurs while evaluating

expressions in an outer select.

Using the SQLWARN Field

This field contains characters that warn of various conditions encountered during

the processing of your statement. Alternatively, specific warnings may be indicated

by positive values in the SQLCA field, SQLCODE. For example, a warning

indicator is set when the system ignores null values in computing an average.

When the system encounters a particular condition, it sets the corresponding

warning character to a designated value, such as W, N, or Z. When the system

encounters two different warning conditions and must set the warning character to

either W or N, the system randomly chooses one value. If the system encounters

three different warning conditions and must set the value of the warning character

to W, N, or Z, the system sets the value of the warning character to W or N, but

not Z. The warning character Z is, therefore, overridden by W or N. One or more

warning characters may be set to W regardless of the code returned in SQLCODE.

The meanings of the warning characters are listed in the DB2 Server for VSE & VM

SQL Reference manual.

Because there is only one return code structure in each program, you should copy

out of the structure any information that you wish to save before the next SQL

statement is executed. Of particular note are the SQLCODE and the warning

indicators (SQLWARN).

Examining Errors

Using the WHENEVER Statement

The WHENEVER statement is a nonexecutable statement that assists you in

reacting to unusual conditions, based on data returned in the SQLCA.

The following three conditions can be addressed with WHENEVER statements:

SQLERROR Occurs when SQLCODE is negative.

200

Application Programming

SQLWARNING

Occurs when SQLCODE is positive but not 100, or when

SQLCODE is zero and SQLWARN0 is W.

NOT FOUND Occurs when SQLCODE is 100 (SQLSTATE is '02000').

Each SQL statement is within the scope of one WHENEVER statement for each of

the three conditions. A WHENEVER statement for an already specified condition

can be overridden at any time by coding another WHENEVER statement for the

same conditions.

One of three actions can be taken for a WHENEVER statement:

GOTO or GO TO

Transfers control to a specified location.

STOP

Terminates the program. The STOP action cannot

be used with the NOT FOUND condition.

CONTINUE

Executes the next sequential instruction.

If a WHENEVER statement is not coded for a condition, it is processed as if the

condition were CONTINUE.

For a full discussion of the WHENEVER statement, see the DB2 Server for VSE &

VM SQL Reference manual.

Determining the Scope of the WHENEVER Statement

The scope of a WHENEVER statement is determined by its position in the source

program listing, not by its place in the logic flow. (This is because WHENEVER is

a declarative statement.) For example:

DO WHILE (X > Y)

EXEC SQL CREATE INDEX I1 ON EMP_ACT (ACTNO)

(host language code)

EXEC SQL DELETE FROM EMP_ACT

WHERE EMPN = '000220'

EXEC SQL WHENEVER SQLERROR STOP

First WHENEVER

(host language code)

EXEC SQL SELECT EMPNO, PROJNO, ACTNO INTO :EMPNUM.

(host language code)

EXEC SQL WHENEVER SQLERROR CONTINUE

Second WHENEVER

END-DO

EXEC SQL DROP INDEX I1

In the pseudocode program fragment above, the scope of the first WHENEVER is

only the SELECT INTO statement. The second WHENEVER applies to the DROP

INDEX statement (and to all SQL statements that follow it until another

WHENEVER is encountered). The CREATE INDEX and DELETE statements are

not covered by a WHENEVER (there is no preceding WHENEVER); therefore, the

default CONTINUE action applies for WHENEVER conditions.

Chapter 6. Testing and Debugging

201

Examining the SQLCA

The SQLCA structure can be examined using the WHENEVER statement. You can

test for both general (SQLCODE < 0 | SQLWARN0 <> blank) and specific

(SQLCODE = -911 | SQLWARN6 = ’W’) warning or error conditions. To do this,

use a WHENEVER statement with a GOTO somewhere in the source program

before the SQL statements for which you want to directly examine the SQLCA.

For example, Figure 40 shows pseudocode for an error handling routine:

EXEC SQL WHENEVER SQLERROR GOTO ERRCHK

ERRCHK: * Prevent further errors from branching here

EXEC SQL WHENEVER SQLERROR CONTINUE

* Handle severe errors first

IF SQLWARN0 = ’S’

DISPLAY(’A SEVERE ERROR HAS OCCURRED.’)

DISPLAY(’SQLCODE = ’ SQLCODE)

STOP

END-IF

* Describe the error

DISPLAY(’AN ERROR HAS OCCURRED.’)

DISPLAY(’SQLCODE =’ SQLCODE)

EXEC SQL ROLLBACK WORK

* Check for errors

IF SQLCODE < 0

DISPLAY(’ROLLBACK WORK FAILED. SQLCODE = ’)

DISPLAY(SQLCODE)

* Recovery from error is complete.

ELSE

DISPLAY(’ROLLBACK WORK SUCCEEDED.’)

END-IF

Figure 40. Pseudocode Error-Handling Routine

When an error occurs, control is passed to the ERRCHK label. Then, in order to

prevent a program loop in this routine, a WHENEVER SQLERROR CONTINUE

statement is issued. (It is safe to do this because WHENEVER statements never

return an SQLCODE.) Next, the severity of the error is determined. If a severe

error occurs, the execution of any SQL statements on this application server (except

a CONNECT statement) terminates the application abnormally. The pseudocode

example reports the error and ends.

If the error is not severe, the pseudocode example displays an informational

message giving the SQLCODE, and an attempt is made to undo any changes. The

pseudocode example determines whether the ROLLBACK successfully completed,

by checking the SQLCODE after the ROLLBACK statement.

202

Application Programming

After a severe error, only a CONNECT statement is permitted. If the application

program reconnects to the application server in which the severe error occurred,

two possibilities exist. If the application server has been restarted or has otherwise

recovered, the application may continue; otherwise, another severe error will result.

If your application program is accessing multiple application servers, you can enter

a CONNECT statement to switch to another application server and continue

processing.

Retrieving the Text Message for an SQLCODE using SQLCA: If an SQL error

occurs, the error message can be retrieved through a call to ARIGMSG for both

VSE and VM. The pseudo formats of these calls in each of the languages are:

CALL ARIGMSG,(PSQLCA, PMESSAGE, PBYTESALLOCATED, PRC, IDSPSQLCA, PLANGUAGE), VL

/* Assembly Language */

ARIGMSG(PSQLCA, PMESSAGE, PBYTESALLOCATED, PRC, IDSPSQLCA, PLANGUAGE)

/* C

CALL ’ARIGMSG’ USING PSQLCA, PMESSAGE, PBYTESALLOCATED, PRC, IDSPSQLCA, PLANGUAGE.

/* COBOL

CALL ARIGMSG(PSQLCA, PMESSAGE, PBYTESALLOCATED, PRC, IDSPSQLCA, PLANGUAGE)

/* Fortran

CALL ARIGMSG(PSQLCA, PMESSAGE, PBYTESALLOCATED, PRC, IDSPSQLCA, PLANGUAGE);

/* PL/I

Descriptions of the various parameters are given in Table 20.

Table 20. SQLCA Parameter Description

Parameter Name

Description

PSQLCA

A pointer to the SQLCA structure.

PMESSAGE

A pointer to a fixed length character array to store

the error message. The returned text is formatted as

one continuous string. The SQLCODE, SQLSTATE,

SQLERRD(1), and SQLERRD(2) fields of SQLCA are

automatically appended to the returned text. Memory

for PMESSAGE must be allocated within the

application program and must be large enough to

store the entire text and SQLCA fields. The appended

SQLCA will require 58 bytes.

PBYTESALLOCATED

A pointer to an integer (4 bytes) used both as an

input and output parameter. On input, it specifies the

number bytes allocated for PMESSAGE by the

application program. On output, it returns the

number of those bytes that were actually used to

store the returned text and SQLCA fields.

PRC

A pointer to an integer (4 bytes) return code

specifying whether any errors occurred in retrieving

the text.

Chapter 6. Testing and Debugging

203

Table 20. SQLCA Parameter Description (continued)

Parameter Name

Description

IDSPSQLCA

An integer specifying whether the entire SQLCA will

be appended to the end of the returned message. The

append will occur if the flag is 1. The format of the

appended string will be:

SQLCODE = sqlcode. SQLSTATE = sqlstate. SQLERRD

= sqlerrd(0), sqlerrd(1), sqlerrd(2), sqlerrd(3), sqlerrd(4),

sqlerrd(5).

SQLWARN = sqlwarn0, sqlwarn1, sqlwarn2, sqlwarn3,

sqlwarn4, sqlwarn5, sqlwarn6, sqlwarn7, sqlwarn8,

sqlwarn9, sqlwarnA.

The string will be 111 bytes long. If a severe error

occurred in retrieving the message, the API will

override the user’s specification and output all the

SQLCA fields.

PLANGUAGE

A pointer to a fixed length character array specifying

the language identifier of the message repository.

Supported language identifiers, LANGID, are

AMENG, UCENG, FRANC, GER, and KANJI. The

LANGID may consist of both upper and lower case

letters. Only the first five (or first three if using GER)

characters of the LANGID will be processed to

determine the specified language. Therefore

″AMeng″, ″UCENGword″, or ″GERcat in the hat″ will

be interpreted as AMENG, UCENG, and GER

respectively. The default language may be used by

specifying a LANGID starting with one or more

blank spaces such as ″ ″ or ″ ″ or ″ GER ″.

Note: DB2 for VSE Batch does not support switching

to another language. Therefore the default is used

regardless of the LANGID specification.

Descriptions of the various return codes stored in RC are given in Table 21.

Table 21. ARIGMSG Return Codes

Return Codes

Description

The message was returned successfully.

The memory allocated to store either the text or appended

SQLCA fields was insufficient causing the message to be

truncated.

-1

One or more parameters are invalid (such as pointer to

SQLCA was null, etc).

-2

The specified language ID is invalid or is not enabled.

-3

The message repository could not be accessed.

-4

The SQLCODE number is out of range (invalid).

-5

The message for the SQLCODE could not be found in the

repository

204

Application Programming

EXEC SQL INCLUDE SQLCA

MAIN PROGRAM

EXEC SQL SELECT MAX(NCOLS) INTO :MAX_NCOLS FROM SYSTEM.NEWCATALOG;

*If there was an error

IF SQLCODE <> 0 THEN

*Declare

1) character arrays to store the returned text and the language

* 2) integers to store the number of bytes allocated

* and the return code from ARIGMSG

DECLARE SMESSAGESTRING AS CHARACTER(400)

DECLARE SLANGUAGESTRING AS CHARACTER(5)

DECLARE INUMBEROFBYTES, IRETURNCODE AS INTEGER

*SMESSAGESTRING may store up to 400 bytes

INUMBEROFBYTES = 400;

*Find the addresses of the variables declared above

DECLARE PSQLCA, PMESSAGE, PBYTESALLOCATED, PRC, PLANGUAGE AS POINTER

PSQLCA = ADDRESSOF(SQLCA)

PMESSAGE = ADDRESSOF(SMESSAGESTRING)

PBYTESALLOCATED = ADDRESSOF(INUMBEROFBYTES)

PRC = ADDRESSOF(IRETURNCODE)

PLANGUAGE = ADDRESSOF(SLANGUAGESTRING)

*Specify the language ID

SLANGUAGESTRING = "Ameng"

*Now retrieve the error message and set the IDSPSQLCA flag to 0

*(so that not all the SQLCA fields are appended).

CALL ARIGMSG(PSQLCA, PMESSAGE, PBYTESALLOCATED, PRC, 0 , PLANGUAGE);

*If there was a severe error in the retrieval

IF IRETURNCODE < 0 THEN

IF IRETURNCODE = -1 THEN

* If one or more of the six parameters was invalid

*(such as the pointer PLANGUAGE was null)

ELSEIF IRETURNCODE = -2 THEN

* If the specified language ID is invalid (such as "Canadianese")

ELSEIF IRETURNCODE = -3 THEN

*If the message repository could not be accessed

ELSE

* If the message still could not be retrieved then output the entire

SQLCA.

* INUMBEROFBYTES now stores the length (in bytes)

* of the returned text and SQLCA

IF IRETURNCODE= -4 THEN

* If the SQLCODE was out of range (invalid)

CALL DISPLAYMESSAGE( SMESSAGESTRING, INUMBEROFBYTES)

ELSE

* If the message for the SQLCODE could not be retrieved from the repository

CALL DISPLAYMESSAGE( SMESSAGESTRING, INUMBEROFBYTES)

END IF

*If the message was retrieved successfully or with minor errors

*(such as having the message truncated)

ELSE

*Print the error message

CALL DISPLAYMESSAGE( SMESSAGESTRING, INUMBEROFBYTES)

END IF

Figure 41. Pseudocode to Display the SQL Error Message

Sample outputs of the pseudocode program in Figure 41 are:

1. The message was successfully retrieved:

SYSTEM.NEWCATALOG was not found in the system catalog.

SQLCODE =

-204. SQLSTATE = 42704. SQLERRD = -100,

206

Application Programming

The message was truncated:

SYSTEM.NEWCATALOG was not found in the system.

The message was not retrieved because it could not be found in the repository:

SQLCODE =

-204. SQLSTATE = 42704. SQLERRD = -100,

SQLWARN =

DB2 Server for VSE

Notes:

For assembler you must INCLUDE modules ARIPRDID and ARIGMSGD

before the link-edit step.

For C you must:

v Within the program itself, append the end-of-string character ″\0″ to

end of the returned text before displaying it on the screen.

v Include the statement

#pragma linkage (ARIGMSG,OS);

to indicate that System/390 linkage is used in the call to ARIGMSG.

v INCLUDE modules ARIPRDID and ARIGMSGD before the link-edit

step.

For COBOL you must INCLUDE modules ARIPRDID, ARIPADR4, and

ARIGMSGD before the link-edit step. If the program was preprocessed

prior to SQL/DS Version 2 Release 2, use ARIPADR instead of ARIPADR4.

For Fortran you must INCLUDE modules ARIPRDID, ARIPEIFA,

ARIGMSGD, and ARIPSTR before the link-edit step.

For PL/I you must:

v Declare ARIGMSG as an external entry point to indicate that

System/390 linkage is used in the call to ARIGMSG:

DCL ARIGMSG ENTRY EXTERNAL OPTIONS(ASM,RETCODE);

v INCLUDE modules ARIPRDID and ARIGMSGD before the link-edit

step.

Chapter 6. Testing and Debugging

207

DB2 Server for VM

Notes:

For assembler language, load modules ARIRVSTC and ARIGMSGC, as

follows:

LOAD program_name ARIRVSTC ARIGMSGC

For C, you must:

v Within the program itself, append the end-of-string character ″\0″ to

end of the returned text before displaying it on the screen.

v Include the statement:

#pragma linkage (ARIGMSG,OS);

to indicate that System/390 linkage is used in the call to ARIGMSG.

v Load modules ARIRVSTC and ARIGMSGC:

LOAD program_name ARIRVSTC ARIGMSGC (RESET CEESTART

For COBOL, load modules ARIRVSTC, ARIPADR (or ARIPADR4), and

ARIGMSGC:

LOAD program_name ARIRVSTC ARIPADR (or ARIPADR4) ARIGMSGC

For Fortran, load modules ARIRVSTC, ARIPEIFA, ARIPSTR, and

ARIGMSGC:

LOAD program_name ARIRVSTC ARIPEIFA ARIPSTR ARIGMSGC

For PL/I, you must:

v Declare ARIGMSG as an external entry point, to indicate that

System/390 linkage is used in the call to ARIGMSG:

DCL ARIGMSG ENTRY EXTERNAL OPTIONS(ASM,RETCODE);

v Load modules ARIRVSTC and ARIGMSGC:

LOAD program_name ARIRVSTC ARIGMSGC (RESET CEESTART

Using TEXT Files to Get SQLCA Field Information: When an SQL error occurs,

you can examine the SQLCA in order to determine the problem. To reduce the

time taken to do so, you can issue a call from the application to either a DB2

Server for VSE module, a DB2 Server for VM TEXT file ARISSMF (for Fortran

programs), or a TEXT file ARISSMA (for all other programs). The pseudo formats

of these calls in each of the languages are:

CALL ARISSMA,(SQLCA,S1,S2,S3,S4,S5),VL

/* Assembly Language */

ARISSMA(SQLCA,S1,S2,S3,S4,S5)

/* ’C’

CALL ’ARISSMA’ USING SQLCA S1 S2 S3 S4 S5.

/* COBOL

CALL ARISSMF(SQLCA,SQLERP,S1,S2,S3,S4,S5)

/* Fortran

CALL ARISSMA(SQLCA,S1,S2,S3,S4,S5);

/* PL/I

In this example, S1, S2, S3, S4, and S5 are character strings declared within the

program and according to the rules of the specific language. Each string will

contain information on specific SQLCA fields, after the call to ARISSMA/ARISSMF.

Table 22 shows the parameter name for the strings, their SQL name, their lengths,

and the corresponding SQLCA fields.

Table 22. SQLCA Error Information Strings

Parameter Name

SQL Name

Length

SQLCA Field

SQLCSTR1

SQLCODE

208

Application Programming

Table 22. SQLCA Error Information Strings (continued)

Parameter Name

SQL Name

Length

SQLCA Field

SQLCSTR2

SQLERRD1

SQLCSTR3

SQLERRD2

SQLCSTR4

SQLERRP (part 1)

SQLCSTR5

SQLERRP (part 2)

DB2 Server for VSE

Notes:

For assembler you must INCLUDE modules ARIPRDID and ARISSMA

before the link-edit step.

For C you must:

v Declare the strings 1 character longer than that shown in the table. Also,

within the program itself, you must append the end-of-string character

“\0” to the last position within each of the character strings before

displaying them on the screen.

v Include the statement

#pragma linkage (ARISSMA,OS);

to indicate that System/390 linkage is used in the call to ARISSMA.

v INCLUDE modules ARIPRDID and ARISSMA before the link-edit step.

For COBOL you must INCLUDE modules ARIPRDID, ARIPADR4, and

ARISSMA before the link-edit step. If the program was preprocessed prior

to SQL/DS Version 2 Release 2, use ARIPADR instead of ARIPADR4.

For Fortran you must INCLUDE modules ARIPRDID, ARIPEIFA,

ARISSMF, and ARIPSTR before the link-edit step.

For PL/I you must:

v Declare ARISSMA as an external entry point to indicate that

System/390 linkage is used in the call to ARISSMA:

DCL ARISSMA ENTRY EXTERNAL OPTIONS(ASM,RETCODE);

v INCLUDE modules ARIPRDID and ARISSMA before the link-edit step.

Chapter 6. Testing and Debugging

209

DB2 Server for VM

Notes:

For assembler language, load modules ARIRVSTC and ARISSMA, as

follows:

LOAD program_name ARIRVSTC ARISSMA

For C, you must:

v Declare the strings one character longer than that shown in the table.

Also, within the program itself, you must append the end-of-string

character “\0” to the last position within each of the character strings

before displaying them on the screen.

v Include the statement:

#pragma linkage (ARISSMA,OS);

to indicate that System/390 linkage is used in the call to ARISSMA.

v Load modules ARIRVSTC and ARISSMA:

LOAD program_name ARIRVSTC ARISSMA (RESET CEESTART

For COBOL, load modules ARIRVSTC, ARIPADR (or ARIPADR4), and

ARISSMA:

LOAD program_name ARIRVSTC ARIPADR (or ARIPADR4) ARISSMA

For Fortran, load modules ARIRVSTC, ARIPEIFA, ARIPSTR, and

ARISSMF:

LOAD program_name ARIRVSTC ARIPEIFA ARIPSTR ARISSMF

For PL/I, you must:

v Declare ARISSMA as an external entry point, to indicate that

System/390 linkage is used in the call to ARISSMA:

DCL ARISSMA ENTRY EXTERNAL OPTIONS(ASM,RETCODE);

v Load modules ARIRVSTC and ARISSMA:

LOAD program_name ARIRVSTC ARISSMA (RESET CEESTART

ARISSMA/ARISSMF returns information in the strings to your program. This

information can be displayed or can be written to a file. The format in which the

information is returned is shown below.

SQLCSTR1

PRCS/nnnnnnnn; where n is the decimal representation of the

absolute value of the SQLCODE, right-justified, and padded with

0’s for a total length of 8 digits.

SQLCSTR2

PRCS/nnnnnnnn; where n is the decimal representation of the

absolute value of the SQLERRD1, right-justified and padded with

0’s for a total length of 8 digits.

SQLCSTR3

PRCS/nnnnnnnn; where n is the decimal representation of the

absolute value of the SQLERRD2, right-justified and padded with

0’s for a total length of 8 digits.

SQLCSTR4

FLDS/SQLERRP. This value is always returned in the string.

SQLCSTR5

VALU/Caaaaaaaa; where a is left-justified, padded by blanks, and is

the module name provided in field SQLERRP.

Suppose the SQLCA fields have the following values when the error occurred:

210

Application Programming

SQLCODE = -901

SQLERRD1 = -160

SQLERRD2 = -33

SQLERRP = ARIXOEX

then the values of the strings will be:

SQLCSTR1

==> PRCS/00000901

SQLCSTR2

==> PRCS/00000160

SQLCSTR3

==> PRCS/00000033

SQLCSTR4

==> FLDS/SQLERRP

SQLCSTR5

==> VALU/CARIXOEX

These values may be displayed as shown in the pseudocode in Figure

42:

EXEC SQL WHENEVER SQLERROR GOTO ERROR

ERROR:

* Display string information

CALL ARISSMA

DISPLAY(’SQLCSTR1 =’SQLCSTR1)

DISPLAY(’SQLCSTR2 =’SQLCSTR2)

DISPLAY(’SQLCSTR3 =’SQLCSTR3)

DISPLAY(’SQLCSTR4 =’SQLCSTR4)

DISPLAY(’SQLCSTR5 =’SQLCSTR5)

Figure 42. Pseudocode to Display Error Information

DB2 Server for VSE

Another reason an application might want to process the SQLERROR

condition is for graceful cleanup and termination. An example of this is a

CICS/VSE conversational transaction. Rather than abnormally terminating on

SQLERROR, a conversational transaction might do the following:

v Issue a CICS/VSE SYNCPOINT ROLLBACK or SQL ROLLBACK. This

backs out uncommitted changes to CICS/VSE and DB2 Server for VSE

recoverable resources.

v Issue an error message to the terminal user. Such a message typically

informs the user of the state of affairs and identifies the user’s options for

proceeding with the transaction.

The ISQL transaction handles SQLERROR in a similar manner. That is, rather

than terminating the ISQL session, the user is given an error message and

allowed to proceed.

Chapter 6. Testing and Debugging

211

DB2 Server for VM

The processing of the SQLERROR condition not only allows an application to

terminate normally, but also permits easy recovery from errors. An example

of this is the ISQL application. Rather than terminating the ISQL session, the

user is given an error message and allowed to proceed. In fact, the

application could give the user the opportunity to indicate whether backout is

necessary. ISQL does this when you omit the WHERE clause in an UPDATE

or DELETE statement by checking SQLWARN4. That way, you have the

chance to confirm that all the rows in the table are to be deleted or updated.

Additional code could be added to the pseudocode example to check for this

situation.

Handling Errors in a Select-List

The database manager tolerates the occurrence of certain errors resulting from the

execution of expressions occurring in a select_list of an outer select statement.

Handling Arithmetic Errors

The arithmetic errors that can be tolerated are listed in Table 23.

Table 23. Tolerated Arithmetic Errors

Arithmetic Errors That Will Be Tolerated

v DECIMAL

- Divide Exception

- Decimal Overflow

v FLOAT

- Divide Exception

- Exponent Overflow

v INTEGER, SMALLINT

- Divide Exception

- Fixed Point Overflow

Note: FLOAT can be either single-precision or double-precision float. Refer to

“Assigning Data Types When the Column Is Created” on page 44 for more

information on floating-point data types.

Errors in date and time arithmetic are not tolerated. For example,

DATE(’9999-12-31’) + 1 DAY

results in a negative SQLCODE because the result would be an invalid date.

In the next example however, if the value of C2 is zero, the arithmetic error would

be tolerated.

DATE(’1999-12-31’) + C1/C2 DAYS

The expression in the outer select_list may be by itself, or it can be an argument in

a scalar or column function other than the column functions AVG and SUM.

If the errors occur on an outer select_list, and every output host variable that is

associated with the expression that is in error has an associated output indicator

variable, the system does the following:

v The output indicator variable for each arithmetic expression in error is set to -2.

212

Application Programming

v A positive warning SQLCODE is placed in the SQLCA.

v SQLWARN0 in the SQLCA remains unaffected.

v The value of the associated host variable is undefined.

v Execution of the statement continues, such that all expressions and values not

having arithmetic errors are returned.

v If the statement is a FETCH, the cursor remains open.

However, if the errors do not occur on the outer select_list, or if there are arithmetic

errors on the select_list and not every output host variable that is associated with

the expression in error has an associated output indicator variable, the system

takes the following actions:

v A negative error SQLCODE -802 (SQLSTATE '22003') is returned in the SQLCA.

v The values of the host variables and any supplied indicator variables in the

select_list are undefined.

v Execution of the statement is halted.

v If the statement is a FETCH, the cursor will remain open.

In either case, the SQLERRM of the SQLCA error message will identify the first

expression in error in the outer select_list. The following are returned in the error

message:

v The exception type

v The arithmetic operation being performed at the time of the error

v The data type of the select_list items being manipulated

v The ordinal position of the expression in error.

Depending on when the error is detected, some parts of the error message will be

blank.

Handling Numeric Conversion Errors

The numeric conversion errors that can be tolerated are listed in Table 24.

Table 24. Tolerated Numeric Conversion Errors

v FLOAT to

- DECIMAL

- INTEGER

- SMALLINT

v DECIMAL to

- DECIMAL

- FLOAT

- INTEGER

- SMALLINT

v INTEGER to

- DECIMAL

- SMALLINT

v SMALLINT to

- DECIMAL

Note: FLOAT can be either single-precision or double-precision float. Refer to

“Assigning Data Types When the Column Is Created” on page 44 for more

information on floating-point data types.

If an error occurs while converting numeric values into the data type of the host

variables, and output indicator variables are provided with host variables, for

which numeric conversion errors occurred, the system does the following:

Chapter 6. Testing and Debugging

213

v The output indicator variable for each host variable for which a numeric

conversion error occurred is set to -2.

v If no other warning SQLCODE is contained in the SQLCA, then a positive

warning SQLCODE is placed in the SQLCA and the error message tokens in

SQLERRM will identify the first conversion error.

v SQLWARN0 in the SQLCA is unaffected.

v The values of the associated host variables are undefined.

v Execution of the statement continues such that all values not in error are

returned to your program.

v If the statement is a FETCH then the cursor will remain open.

If output indicator variables are not provided for host variables for which numeric

conversion errors occurred, the system does the following:

v A negative error SQLCODE is placed in the SQLCA

v The SQLCA error message tokens identify the first conversion error

v The values of the host variables and indicators are undefined

v Execution of the statement is halted

v If the statement is a FETCH then the cursor will remain open.

In either case, the SQLERRM of the SQLCA will identify the first expression in

error, and the following will be returned in the error message:

1. The data type of the value being moved into the host variable

2. The ordinal position of the expression in error

3. The data type of the host variable.

Handling CCSID Conversion Errors

The database manager tolerates CCSID conversion errors in which a character or

characters have been mapped to the defined error byte.

If this occurred during CCSID conversion of data to be returned to the user, and

output indicator variables are provided with host variables, the system does the

following:

v For each host variable for which the CCSID conversion error byte mapping has

occurred, the output indicator is set to -2.

v If no other warning SQLCODE is in the SQLCA, a positive warning SQLCODE

is placed there, and the error message tokens in SQLERRM will identify the first

conversion error.

v SQLWARN0 in the SQLCA is unaffected.

v The values of the associated host variables are undefined.

v Execution of the statement continues and returns all correct values to your

program.

v For a FETCH statement, the cursor remains open.

If output indicator variables are not provided for host variables for which CCSID

conversion errors occurred, the database manager does the following:

v A negative SQLCODE is placed in the SQLCA.

v The SQLCA error message tokens identify the first conversion error.

v The values of the host variables, and any indicators, are undefined.

v Execution of the statement is halted.

v For a FETCH statement, the cursor remains open.

214

Application Programming

Chapter 7. Using Dynamic Statements

Dynamically Defining SQL Statements

216

Analyzing the Elements of SQLVAR

224

Comparing Non-Query Statements to Query

Allocating Storage for the Result of the

Statements

216

Select-Statement

225

Using Non-Query Statements

216

Retrieving the Query Result

226

Executing Non-Parameterized Statements . . . 216

Executing a Parameterized SELECT Statement

227

Executing Parameterized Statements

218

Generating an Additional SELECT Statement

227

Using Query Statements

220

Executing a Parameterized Non-Query Statement

230

Executing a Non-Parameterized Select-Statement 220

Generating a SELECT Statement

230

Using the PREPARE and DESCRIBE

Using an Alternative to a Scanning Routine . . . 231

Statements

220

Ensuring Data Type Equivalence in a Dynamically

Declaring the SQL Descriptor Area (SQLDA)

220

Defined Query

232

Processing a Run-Time Query Using the

Summarizing the Fields of the SQLDA

234

SQLDA

221

Using the SQLN Field

236

Allocating Storage for the SQLDA Using the

Using the SQLD Field in the SQLDA

236

SQLVAR Array

222

Using the PREPARE Statement

237

Initializing the SQLN Field of the SQLDA

222

SQL Functions Not Supported in Dynamic

Inserting Values in the SQLDA

222

Statements

238

215

Dynamically Defining SQL Statements

Previous chapters have described how to code various SQL statements directly into

a program and have the database manager preprocess them. For some kinds of

applications, however, it is desirable to execute SQL statements that are not known

until the program is actually running. An example would be a program to support

an interactive user who wishes to type queries and receive results at a terminal. In

this case, you cannot embed the SQL statements in the program and have the DB2

Server for VSE & VM preprocessor recognize them, because the program reads the

statements from a terminal when it is running. To support applications such as

this, the system provides facilities for executing SQL statements that are specified

at run time.

For a detailed description of each of these statements, see the DB2 Server for VSE &

VM SQL Reference manual. The following SQL statements define dynamic

statements.

v PREPARE - prepares a single statement for execution

v DESCRIBE - obtains information about columns in the select_list of a prepared

select-statement

v EXECUTE - executes a non-select-statement in a package

v EXECUTE IMMEDIATE - prepares a single statement and immediately executes

v DECLARE CURSOR - in connection with OPEN, FETCH, PUT, and CLOSE,

executes a SELECT or an INSERT statement

v OPEN (cursor)

v FETCH (cursor)

v PUT (cursor)

v CLOSE (cursor).

Comparing Non-Query Statements to Query Statements

The SQL statements that you can dynamically define and execute fall into one of

two categories: non-query SQL statements (such as ALTER, CREATE, DELETE,

INSERT, and UPDATE) and query statements (such as SELECT). General usage

techniques for both categories are discussed below; specific statement syntax is

shown in the following sections.

Using Non-Query Statements

Executing Non-Parameterized Statements

The simplest SQL statements to execute dynamically are those that do not return

any result other than values in the SQLCA. No output host variables are used. This

is the case with all data definition and data control statements, and with all data

manipulation statements except SELECT.

Suppose an inventory control program is designed around the following table:

CREATE TABLE INVENTORY

(PARTNO

SMALLINT

NOT NULL,

DESCRIPTION

VARCHAR(24)

QONHAND

INTEGER

)

The program reads SQL DELETE statements similar to these from a terminal:

216

Application Programming

DELETE FROM INVENTORY WHERE PARTNO =221

DELETE FROM INVENTORY WHERE PARTNO =315

DELETE FROM INVENTORY WHERE PARTNO =807

After reading a statement, the program immediately executes it.

SQL statements must be prepared before they can be executed. Because the SQL

statements are read at run time, they have not been prepared. An SQL statement

called EXECUTE IMMEDIATE causes an SQL statement to be prepared and

executed—all at run time. Here is a pseudocode solution to the above problem:

EXEC SQL BEGIN DECLARE SECTION

DECLARE DSTRING VARYING CHARACTER (80)

EXEC SQL END DECLARE SECTION

READ DSTRING FROM TERMINAL

EXEC SQL EXECUTE IMMEDIATE :DSTRING

A DELETE statement is read into a host variable called DSTRING. DSTRING is

then used as a parameter in the EXECUTE IMMEDIATE statement, causing the

DELETE statement to be immediately prepared and executed.

A host variable can be used as a parameter for the EXECUTE IMMEDIATE

statement. The table below shows how the host variable must be declared in the

different languages:

Table 25. Declaring of Host Variables

Fixed-

Length

Varying-Length

Language

Variable

String Constant

Assembler

COBOL

Fortran

PL/I

The Fixed-Length Variable refers to CHAR host variables, Varying-Length Variable

refers to VARCHAR host variables, and String Constant refers to quoted character

string constants. The following is an example of a String Constant dynamic

statement:

EXECUTE IMMEDIATE ’DELETE FROM INVENTORY WHERE PARTNO=201’

The SQL statement submitted to EXECUTE IMMEDIATE must not contain host

language delimiters or SQL delimited identifiers. That is, the statement must be in

basic form. Avoid using either delimited identifiers or strings of DBCS characters

in statements specified in string constants.

Note: The preferred method is to use a host variable rather than the string

constant.

The EXECUTE IMMEDIATE statement itself, however, must have appropriate

delimiters. For example, in COBOL all SQL statements must be preceded by EXEC

SQL, and followed by the END-EXEC keyword as follows:

Chapter 7. Using Dynamic Statements

217

EXEC SQL EXECUTE IMMEDIATE

’DELETE FROM INVENTORY WHERE PARTNO = 201’

END-EXEC.

If the host language you are using permits it, you can concatenate a constant to a

variable. For example, PL/I uses two vertical bars (||) as the concatenation

symbol:

EXEC SQL EXECUTE IMMEDIATE ’DELETE FROM INVENTORY WHERE’ || PREDS;

Note: The concatenation symbol used here is not the same as the concatenation

operator discussed in Chapter 3, “Coding the Body of a Program,” on page

23.

The “EXEC SQL” and the semicolon (;) are the host language delimiters for PL/I.

At run time, the variable PREDS should contain a character string representing one

or more predicates that complete the DELETE statement. The variable PREDS must

not be used as a host variable, since it is being concatenated to the constant string.

Executing Parameterized Statements

In the example above, note that the DELETE statements that were dynamically

executed contained no host variables. That is, they were executed only once, with a

single value for PARTNO. Suppose that you wanted to execute the DELETE

statement repeatedly with different values, without having to key in the entire

statement each time. Consider how it might be done if you coded the DELETE

statement directly in a program:

READ PART FROM SYSIPT

DO WHILE (PART ¬= 0)

EXEC SQL DELETE FROM INVENTORY WHERE PARTNO = :PART

READ PART FROM SYSIPT

END-DO

The loop is repeated until a PART of 0 is read.

Now, suppose that you wish to read both the DELETE statement and the part

numbers from a terminal for dynamic execution. When this is done, the DELETE

statement itself should not contain host variables; rather, it should contain question

marks (?) to indicate where the value is to be substituted:

DELETE FROM INVENTORY WHERE PARTNO = ?

This type of statement is called a parameterized SQL statement (a parameter is an

input host variable). Thus far, none of the dynamic statements contained any

parameter markers, and they could be executed using EXECUTE IMMEDIATE.

Parameterized SQL statements require a slightly more complex facility called

PREPARE and EXECUTE. This facility can be thought of as an EXECUTE

IMMEDIATE performed in two steps. The first step (PREPARE) causes the

parameterized statement to be prepared, and gives it a name of your choosing.

(This name should not be declared as a host variable.) The second step (EXECUTE)

causes the statement to be executed using values that you supply for the

parameters. After a statement is prepared, it can be executed many times. Here is

the pseudocode:

218

Application Programming

READ DSTRING FROM TERMINAL

Preprocess the DELETE

DO WHILE (DSTRING

= ")

statement and call it

EXEC SQL PREPARE S1 FROM :DSTRING

S1.

READ PART FROM TERMINAL

DO WHILE ( PART

= 0)

EXEC SQL EXECUTE S1 USING :PART

READ PART FROM TERMINAL

END-DO

Execute S1 (the DELETE

READ DSTRING FROM TERMINAL

statement) repeatedly

END-DO

using different values

for PARTNO.

END-DO

You must not execute a dynamically defined statement after ending the logical unit

of work in which the statement was prepared. If you do, an error is issued.

In routines similar to the above example, the number of parameters and their data

types must be known, because the host variables that provide input data are

declared when the program is being written.

Naturally, this greatly limits the number of different SQL statements that you can

read in. In the above example, the only SQL statements that can be executed are

those containing a single parameter. This single parameter is defined as a 15-bit

integer in the program, and must be used as such. For example, the pseudocode

above can also process the statements below. (At the terminal, the user types in a

statement followed by values for the parameter markers.)

INSERT INTO INVENTORY (PARTNO) VALUES(?)

For each value you provide for “?”, the INSERT statement is executed, and a new

row is inserted into INVENTORY. The value you provide is placed in the PARTNO

column. The other columns of the table are given the null value (provided they are

nullable).

UPDATE INVENTORY SET DESCRIPTION = ’GEAR’ WHERE PARTNO = ?

For each value you provide for “?”, the UPDATE statement is executed, and the

DESCRIPTION column of the INVENTORY table is set to ’GEAR’.

UPDATE INVENTORY SET QONHAND = 0 WHERE PARTNO = ?

For each value you provide for “?”, the UPDATE statement is executed, and the

QONHAND column in the INVENTORY table is set to 0.

Obviously there are some applications for this kind of dynamic statement

processing, but they are quite specialized. Suppose new parts are added to the

inventory. Each part is a different kind of gear, and none of the parts are yet in the

warehouse. The input stream for the pseudocode above would be as follows:

INSERT INTO INVENTORY (PARTNO) VALUES (?)

301

302

303

304

UPDATE INVENTORY SET DESCRIPTION = ’GEAR’ WHERE PARTNO

= ?

301

302

303

304

Chapter 7. Using Dynamic Statements

219

UPDATE INVENTORY SET QONHAND = 0 WHERE PARTNO = ?

301

302

303

304

Using Query Statements

Executing a Non-Parameterized Select-Statement

Using the PREPARE and DESCRIBE Statements

A somewhat more complex facility is needed for executing a dynamically defined

select-statement. Usually, a select-statement returns the result of a query into one or

more host variables. When the query is read from a terminal at run time, however,

you cannot know in advance how many and what type of variables to allocate to

receive the result. The database manager therefore provides a special statement

called DESCRIBE by which a program can obtain a description of the data types of

a query result. After using the DESCRIBE statement, the program can dynamically

allocate storage areas of the correct size and type to receive the result of the query.

If DESCRIBE is used on a prepared SQL statement that was not a SELECT, the

system indicates this by returning a zero in the variable SQLD of the SQL

descriptor area.

When handling a run-time query, the program first uses the PREPARE statement

which (as in the previous section) preprocesses the SQL statement. The PREPARE

step also associates a statement-name with the query. The DESCRIBE statement is

then used to obtain a description of the answer set. On the basis of this

description, the program dynamically allocates a storage area suitable to hold one

row of the result. The program then reads the query result by associating the name

of the statement with a cursor and by using cursor manipulation statements

(OPEN, FETCH, and CLOSE).

SELECT INTO statements cannot be executed dynamically.

Declaring the SQL Descriptor Area (SQLDA)

Dynamically defined queries center around a structure called the SQL Descriptor

Area (SQLDA). The SQLDA is usually a based structure; that is, storage for it is

allocated dynamically at run time. Figure 43 on page 221 is a representation of the

SQLDA structure with host-language-independent data type descriptions. Each

host language has different considerations for the SQLDA structure; you should

read the section on dynamic statements in the appropriate appendix before you

attempt to code a program that uses the SQLDA. In addition, see “Summarizing

the Fields of the SQLDA” on page 234 for information about the fields of the

SQLDA.

220

Application Programming

SQLDA -- a based structure composed of:

SQLDAID -- character string of length 8

SQLDABC -- 31-bit binary integer

SQLN

-- 15-bit binary integer

SQLD

-- 15-bit binary integer

SQLVAR

-- an array composed of:

SQLTYPE -- 15-bit binary integer

SQLLEN

-- 15-bit binary integer

SQLPRCSN -- 1-byte (used for DECIMAL)

SQLSCALE -- 1-byte (used for DECIMAL)

SQLDATA -- 31-bit binary integer (pointer)

SQLIND

-- 31-bit binary integer (pointer)

SQLNAME -- varying-length character string

of up to 30 characters

Figure 43. SQLDA Structure (in Pseudocode)

Note: The SQLLEN field can be divided into two subfields. The subfields are used

only when working with DECIMAL values. Such usage is described in the

following section.

To include the declaration of the descriptor area in an assembler, C, or PL/I

program, specify:

INCLUDE SQLDA

The INCLUDE SQLDA statement must not be placed in the SQL declare section.

As with the SQLCA, you can code this structure directly instead of using the

INCLUDE SQLDA statement. If you choose to declare the structure directly, you

can specify any name for it. For example, you can call it SPACE1 or DAREA

instead of SQLDA.

Processing a Run-Time Query Using the SQLDA

To process a run-time query, you must declare the SQLDA structure. Below is an

illustration showing the SQLDA structure as a box; similar illustrations are used in

following examples. Remember that SQLDA is a based structure (or, in assembler,

a DSECT); no storage has actually been allocated yet.

SQLDAID

SQLDABC

SQLN

SQLD

SQLVAR

(1) SQLTYPE

(1)

(2)

SQLDATA

(2) SQLLEN

11 is the length

SQLIND

of the character

string in SQLNAME.

SQLNAME

SQLNAME is a 30-byte

area immediately

following 11.

The meanings of the various fields are described as they are used. A summary of

the meanings of the fields of the SQLDA is presented later for quick reference.

If a select-statement is assigned to the variable QSTRING, it can be read in from

SYSIPT (DB2 Server for VSE) a terminal (DB2 Server for VM) or assigned within

the program itself. In this example, the following select-statement is read in from the

terminal:

SELECT DESCRIPTION, QONHAND FROM INVENTORY WHERE PARTNO = 221

Chapter 7. Using Dynamic Statements

221

This select-statement has no INTO clause. When it is read in, it is assigned to the

host variable QSTRING, which is then preprocessed by the PREPARE statement:

READ QSTRING FROM TERMINAL

EXEC SQL PREPARE S1 FROM :QSTRING

Allocating Storage for the SQLDA Using the SQLVAR Array

Now you can allocate storage for the SQLDA. The techniques for acquiring storage

are language dependent; refer to the appropriate compiler or assembler manual.

Note: The usage of the SQLDA depends on the USING clause option of the

DESCRIBE statement (discussed later in this chapter). In this section, it is

assumed that the NAMES option of the USING clause has been specified.

The amount of storage you need to allocate depends upon how many

elements you want to have in the SQLVAR array. Each select_list item must

have a corresponding SQLVAR array element. Therefore, the number of

select_list items determines how many SQLVAR array elements you should

allocate. However, because select-statements are specified at run time, it is

not possible to know how many select_list items there will be. Consequently,

you must guess.

Suppose, in this example, that no more than three items are ever expected in

the select_list. This means that the SQLVAR array should have a dimension

of three, because each item in a select_list must have a corresponding entry

in SQLVAR.

Initializing the SQLN Field of the SQLDA

Having allocated an SQLDA of what you hope will be adequate size, you must

now initialize the SQLDA field called SQLN. SQLN is set to the number of

SQLVAR array elements you have allocated (that is, SQLN is the dimension of the

SQLVAR array). In this example, you must set SQLN to 3. Here’s the pseudocode

for what was done so far:

Allocate an SQLDA of size 3

SQLN = 3

Inserting Values in the SQLDA

Having allocated storage, you can now DESCRIBE the statement. (Make sure that

SQLN is set before the DESCRIBE.)

DESCRIBE S1 INTO SQLDA

When the DESCRIBE is executed, the system places values in the SQLDA. These

values provide information about the select_list.

Figure 44 on page 223 shows the contents of the SQLDA after the DESCRIBE is

executed for the example select-statement. The third SQLVAR element is not shown

because it was not used.

222

Application Programming

Eye-catcher

S Q L D A

SQLN and SQLD

148

449

500(2)

X ' 01 ' (1)

D E

SQLVAR

Element 1

S C R I P T I O

497

Q O N H A N

SQLVAR

Element 2

Note:

1. The hexadecimal value

X ' 01 ' is in byte 1.

Bytes 2, 3, and 4 are

undefined.

2. Bytes 1 and 2

contain X ' 000 '. The

value 500 is in bytes

3 and 4.

Figure 44. Contents of SQLDA after Executing the DESCRIBE

The SQLDAID and SQLDABC fields are initialized by the system when a

DESCRIBE statement is executed (you can ignore these for now).

If you do not allocate a large enough SQLDA structure, SQLD will be set to the

number of required SQLVAR elements after the DESCRIBE. Suppose, for example,

that the select-statement contained four select_list expressions instead of two. The

SQLDA was allocated with an SQLVAR dimension of three. The system cannot

describe the entire select_list because there is not enough storage. In this case,

SQLD is set to the actual number of select_list expressions; the rest of the structure

is ignored. Thus, after a DESCRIBE it is a good practice to check SQLN. If SQLN is

less than SQLD, you need to allocate a larger SQLDA based on the value in SQLD:

EXEC SQL DESCRIBE S1 INTO SQLDA

IF (SQLN < SQLD)

Allocate a larger SQLDA using the value of SQLD.

Reset SQLN to the larger value.

EXEC SQL DESCRIBE S1 INTO SQLDA

END-IF

For the example select-statement, however, the SQLDA was of adequate size.

SQLVAR has a dimension of three, and there are only two select_list expressions.

SQLN remains set to 3, and SQLD is set to 2.

Chapter 7. Using Dynamic Statements

223

If you use DESCRIBE on a non-select-statement, SQLD is set to 0. If your program

is designed to process both query and non-query statements, you can describe each

statement (after it is prepared) to determine whether it is a query. This example

routine is designed to process only query statements, so no test is provided.

Analyzing the Elements of SQLVAR

Your program must now analyze the elements of SQLVAR. Remember that each

element describes a single select_list expression. Consider again the select-statement

that is being processed:

SELECT DESCRIPTION, QONHAND FROM INVENTORY WHERE PARTNO = 221

The first item in the select_list is DESCRIPTION. As illustrated in the beginning of

this section, each SQLVAR element contains the fields SQLTYPE, SQLLEN,

SQLDATA, SQLIND, and SQLNAME. The system returns a code in SQLTYPE that

describes the data type of the expression and tells you whether nulls are

applicable. For a detailed explanation on how to interpret the codes returned in

SQLTYPE, refer to the DB2 Server for VSE & VM SQL Reference manual.

For example, SQLTYPE is set to 449 in the first SQLVAR element. This indicates

that DESCRIPTION is a VARCHAR column and that nulls are permitted in the

column.

The system sets SQLLEN to the length of the column. For character strings,

SQLLEN is set to the maximum number of bytes of the string. For graphic strings,

SQLLEN is set to the maximum number of double-byte characters in the string.

For decimal data, the precision and scale are returned in the first and second bytes,

respectively. (Recall that the SQLLEN field has two sub-fields called SQLPRCSN

and SQLSCALE for this purpose.) For other data types, SQLLEN is set as follows:

SMALLINT

-- SQLLEN = 2

INTEGER

-- SQLLEN = 4

Single precision float

-- SQLLEN = 4

Double precision float

-- SQLLEN = 8

DATE

-- SQLLEN = 10 or LOCAL

TIME

-- SQLLEN =

8 or LOCAL

TIMESTAMP

-- SQLLEN = 26

Note: For DATE, TIME, and TIMESTAMP, see “Using Datetime Data Types” on

page 46.

Because the data type of DESCRIPTION is VARCHAR, SQLLEN is set equal to the

maximum length of the character string. For DESCRIPTION, that length is 24.

When the select-statement is later executed, a storage area large enough to hold a

VARCHAR(24) string will be needed. In addition, because nulls are permitted in

DESCRIPTION, a storage area for a null indicator variable would also be needed.

For character and graphic string columns, the system puts the CCSID attribute of

the column in bytes 3 and 4 of the SQLDATA field. In Figure 44 on page 223,

DESCRIPTION is a character column; therefore, the CCSID of DESCRIPTION is

stored in the SQLDATA field of element 1. The example shows a CCSID of 500,

which means that the data stored in the column is stored in CCSID 500 format.

For character string columns, the database manager stores an indicator in byte 1 of

the SQLIND field. The indicator is set according to the subtype associated with the

column. In Figure 44 on page 223, the indicator for DESCRIPTION is set to X'01',

which means that DESCRIPTION has a subtype of SBCS. Columns with a subtype

of SBCS can contain single-byte character set characters only. For DB2 Server for

VM, byte 1 is not set when DRDA protocol is in use.

224

Application Programming

The last field in an SQLVAR element is a varying-length character string called

SQLNAME. The first two bytes of SQLNAME contain the length of the character

data. The character data itself is usually the name of the field used in the select_list

expression (DESCRIPTION in the above example). The exceptions to this are

select_list items that are unnamed, such as functions (for example, SUM(SALARY))

and expressions (A+B-C). These exceptions are described in greater detail under

“Summarizing the Fields of the SQLDA” on page 234.

The second SQLVAR element in the above example contains the information for

the QONHAND select_list item. The 497 code in SQLTYPE indicates that

QONHAND is an INTEGER column that permits nulls. For an INTEGER data

type, SQLLEN is set to 4. SQLNAME contains the character string QONHAND,

and has the length byte set to 7.

Allocating Storage for the Result of the Select-Statement

After analyzing the result of the DESCRIBE, you can allocate storage for variables

that will contain the result of the select-statement. For DESCRIPTION, a varying

character field of length 24 must be allocated; for QONHAND, a binary integer of

31 bits (plus sign) must be allocated. Both QONHAND and DESCRIPTION permit

nulls, so you must allocate two additional halfwords to function as indicator

variables.

After the storage is allocated, you must change the SQLDA. For each element of

the SQLVAR array, do the following:

v Set SQLDATA to the address of the area in which the results will be placed.

v Set SQLIND to the address of the area in which the indicator information will be

placed.

v If the data type of the area in which the results will be stored is character or

graphic and you want to override the CCSID of the data area with, for example,

the CCSID of the column, you must do the following:

- For DB2 Server for VM, if you are using the SQLDS protocol, change the 6th

position of the SQLDAID field to '+'. For example, set the SQLDAID field to

'SQLDA+ '.

- For DB2 Server for VSE, change the 6th position of the SQLDAID field to '+'.

For example, set the SQLDAID field to 'SQLDA+ '.

- Set the length of the SQLNAME field to 8. (The length here is not the

SQLLEN field, but is the length associated with the SQLNAME field. For

example, in the SQLDA defined for C, the field referred to is sqlname.length.)

- Initialize bytes 1 and 2 of the SQLNAME field to 0

- Put the CCSID override value in bytes 3 and 4 of the SQLNAME field.

Note: When no override is present, the CCSID of the data area defaults to the

application requester’s default.

In the following example, the SQLDA is updated to contain the appropriate

addresses. Because a CCSID override is not required, the SQLNAME field is not

modified. Here is what the structure now looks like:

Chapter 7. Using Dynamic Statements

225

S Q L D A

148

Main Variable:

449

Varying Character (24)

D E

Indicator:

S C

Halfword

Main Variable:

Binary Integer Fullword

497

Indicator:

Q O N H

Halfword

This is the pseudocode for what was done so far:

EXEC SQL INCLUDE SQLDA

READ QSTRING FROM TERMINAL

EXEC SQL PREPARE S1 FROM :QSTRING

Allocate an SQLDA of size 3.

SQLN = 3

EXEC SQL DESCRIBE S1 INTO SQLDA

IF (SQLN < SQLD)

Allocate a larger SQLDA using the value of SQLD.

Reset SQLN to the larger value.

EXEC SQL DESCRIBE S1 INTO SQLDA

END-IF

Analyze the results of the DESCRIBE.

Allocate storage to hold select_list results.

Set SQLDATA and SQLIND for each select_list item.

Retrieving the Query Result

Now comes the easy part: retrieving the query result. Dynamically defined queries,

as noted earlier, must not have an INTO clause. Thus, all dynamically defined

queries must use a cursor. Special forms of the DECLARE, OPEN, and FETCH

statements are used for dynamically defined queries.

The DECLARE CURSOR statement for the example query is as follows:

DECLARE C1 CURSOR FOR S1

The only difference is that the name of the prepared select-statement (S1) is used

instead of the select-statement.

The actual retrieval of result rows is as follows:

EXEC SQL OPEN C1

EXEC SQL FETCH C1 USING DESCRIPTOR SQLDA

DO WHILE (SQLCODE = 0)

DISPLAY (results pointed to by SQLDATA and SQLIND

for all pertinent SQLVAR elements)

226

Application Programming

EXEC SQL FETCH C1 USING DESCRIPTOR SQLDA

END-DO

DISPLAY (’END OF LIST’)

EXEC SQL CLOSE C1

The cursor is opened, and the result table is evaluated. (Note that there are no

input host variables needed for the example query. Methods of providing input

host variables are discussed later.) The query result rows are then returned using a

FETCH statement (which does not have output host variables in this example).

This statement returns results into the data areas referenced in the descriptor called

SQLDA. The same SQLDA that was set up by DESCRIBE is now being used for

the output of the select-statement.

The next section describes a more general routine in which you can process queries

that have parameters in the WHERE clause. You should not read that section until

you have coded some of the simpler dynamic queries discussed thus far.

Executing a Parameterized SELECT Statement

In the example above, the query that was dynamically executed had no parameters

(input host variables) in the WHERE clause:

SELECT DESCRIPTION, QONHAND FROM INVENTORY WHERE PARTNO = 221

Suppose you wanted to execute the same query a number of times using different

values for PARTNO. A parameterized SQL statement is needed:

SELECT DESCRIPTION, QONHAND FROM INVENTORY WHERE PARTNO = ?

Generating an Additional SELECT Statement

In previous parameterized SQL statements, the number of parameters and their

data types had to be known. What if they are unknown? The DESCRIBE statement,

at first glance, is not feasible because it describes only select_lists. With some

additional programming, however, you can use the DESCRIBE statement to obtain

information about the parameter markers (?). Specifically, the code must scan the

FROM and WHERE clauses to determine the table and column with which the

parameter marker (?) is associated. The code can then construct a select-statement

using those column names in the select_list. For the parameterized statement above,

the following query can be generated:

SELECT PARTNO FROM INVENTORY

The query (assigned to WSTRING below) can then be preprocessed and described:

Allocate an SQLDA of size 3.

SQLN = 3

EXEC SQL PREPARE S2 FROM :WSTRING

EXEC SQL DESCRIBE S2 INTO SQLDA

Here is what the SQLDA looks like after the fabricated select-statement is described.

Only the first element of SQLVAR is shown because the others are not used:

Chapter 7. Using Dynamic Statements

227

Eye-catcher

S Q L D A

SQLN and SQLD

148

500

(SQLDATA)

(SQLIND)

P A

SQLVAR

Element 1

R T N O

An analysis of the SQLDA shows that there is only one parameter marker (?), and

that parameter is associated with PARTNO. The SQLTYPE value (500) indicates

that PARTNO contains integer halfwords. Thus, you need to allocate a binary

integer halfword for the parameter marker (?) variable. SQLDATA must then be set

to point to this area.

Previously, the SQLDA was used in a FETCH statement, and query results were

returned into the storage areas pointed to by SQLDATA and SQLIND. In other

words, the SQLDA was used for output. Now, the SQLDA is going to be used to

provide input values for the WHERE clause by an OPEN statement. When the

SQLDA is being used for input, you must assign values to the dynamically

allocated storage areas pointed to by SQLDATA. If the SQLTYPE value returned by

DESCRIBE indicates that the field permits nulls, you must either supply an

indicator variable pointed to by SQLIND, or reset SQLTYPE to indicate that nulls

are not permitted. If indicator variables are not required, you should reset

SQLTYPE. For example, if the SQLTYPE returned by DESCRIBE is 501, you should

set it to 500 before using the SQLDA to provide input. After the storage for the

parameter markers is allocated, you should read in values and assign them to

those areas. Here is the completed SQLDA (assuming 221 is read in for the

parameter marker (?)):

Eye-catcher

S Q L D A

SQLN and SQLD

148

500

Value for "?":

(SQLIND)

P A

221

SQLVAR

Element 1

R T N O

After an SQLDA is set up in this fashion, it can be referred to in an OPEN

statement that contains a USING clause. For example, a previously declared cursor

called C1 is opened using SQLDA:

OPEN C1 USING DESCRIPTOR SQLDA

Because SQLDA currently has 221 in the field pointed to by SQLDATA, C1 is

evaluated using that value.

Figure 45 on page 229 shows the pseudocode for the complete example. Two

SQLDA-like structures are used. One is called SQLDA, and is the usual structure;

the other (declared directly) is called SQLDA1. The fields of SQLDA1 are suffixed

228

Application Programming

with a “1”; for example, SQLDATA1 and SQLN1. An asterisk in position

of the

pseudocode denotes a comment.

EXEC SQL INCLUDE SQLDA

Directly declare SQLDA1.

* Read in a parameterized query.

READ QSTRING FROM TERMINAL

* PREPARE and DESCRIBE the query; set up the output SQLDA.

EXEC SQL PREPARE S1 FROM :QSTRING

Allocate an SQLDA of size 3.

SQLN = 3

EXEC SQL DESCRIBE S1 INTO SQLDA

IF (SQLN < SQLD)

Allocate a larger SQLDA using the value of SQLD.

Reset SQLN to the larger value.

EXEC SQL DESCRIBE S1 INTO SQLDA

END-IF

Analyze the results of the DESCRIBE.

Allocate storage to hold select list results.

Set SQLDATA and SQLIND for each select_list item.

* Declare a cursor.

EXEC SQL DECLARE C1 CURSOR FOR S1

* Fabricate a query so PREPARE and DESCRIBE can be used to

* set up the input SQLDA1.

Scan the FROM clause and the WHERE clause of QSTRING for

parameter markers (?) and generate an appropriate

query in WSTRING.

Allocate an SQLDA1 of size 1 (1 was obtained from the scan).

SQLN1 = 1

EXEC SQL PREPARE S2 FROM :WSTRING

EXEC SQL DESCRIBE S2 INTO SQLDA1

Analyze the results of the DESCRIBE.

Reset SQLTYPE1 to reflect that there is no indicator variable.

Allocate storage to hold the input values (the parameter marker

(?)

values).

Set SQLDATA1 for each parameter marker (?) value.

* Read in input parameters and retrieve the query results using

* cursor C1. Note that the pseudocode reads in only one parameter

* marker (?). Your actual code must provide for the possibility

* that more than one parameter marker (?) might be provided.

Figure 45. Parameterized Query Statement (Part 1 of 2)

Chapter 7. Using Dynamic Statements

229

READ PARM FROM TERMINAL

DO WHILE (PARM ¬= 0)

Assign PARM to area pointed to by SQLDATA1.

EXEC SQL OPEN C1 USING DESCRIPTOR SQLDA1

EXEC SQL FETCH C1 USING DESCRIPTOR SQLDA

DO WHILE (SQLCODE = 0)

DISPLAY (results pointed to by SQLDATA and SQLIND)

EXEC SQL FETCH C1 USING DESCRIPTOR SQLDA

END-DO

EXEC SQL CLOSE C1

DISPLAY (’ENTER ANOTHER VALUE OR 0’)

READ PARM FROM TERMINAL

END-DO

DISPLAY (’END OF QUERY’)

Figure 45. Parameterized Query Statement (Part 2 of 2)

Executing a Parameterized Non-Query Statement

“Executing Parameterized Statements” on page 218, introduces parameterized

statements, however, it is necessary to know the number of parameter markers (?)

and their data types before run time. The preceding section shows how you can

analyze a parameterized query so that a select-statement can be generated and

subsequently described. The same principle can be used for parameterized

non-query statements.

Generating a SELECT Statement

For example, suppose this DELETE statement is read from the terminal and

assigned to DSTRING:

DELETE FROM QUOTATIONS WHERE PARTNO = ? AND SUPPNO = ?

Suppose also that the number of parameter markers (?) and their corresponding

data types are unknown before run time. The same routine that you coded to scan

the FROM and WHERE clauses of select-statements can be used to scan the above

DELETE statement. Then, a SELECT statement containing the relevant columns can

be constructed:

SELECT PARTNO, SUPPNO FROM QUOTATIONS

This select-statement is then prepared and described as in the previous section. The

setup of the SQLDA is also identical: once the SQLDA is analyzed, space to hold

the parameter marker values is allocated, and these values are read in and

assigned to these locations. The SQLDA will be used for input to the WHERE

clause of the SQL statement; no indicator variables are allowed. Because the

statement is a non-query statement, the SQLDA is pointed to in the EXECUTE

statement. Figure 46 on page 231 illustrates the pseudocode for a parameterized

non-query statement.

230

Application Programming

EXEC SQL INCLUDE SQLDA

READ DSTRING FROM TERMINAL

Scan the FROM clause and the WHERE clause of DSTRING for

parameter markers (?) and generate an appropriate query

in WSTRING.

Allocate an SQLDA of size 2 (2 was obtained from the scan).

SQLN = 2

EXEC SQL PREPARE S2 FROM :WSTRING

EXEC SQL DESCRIBE S2 INTO SQLDA

Analyze the results of the DESCRIBE.

Reset SQLTYPE to reflect that there is no indicator variable.

Allocate storage to hold the input values (the parameter marker

(?)

values).

Set SQLDATA for each parameter marker (?) value.

EXEC SQL PREPARE S1 FROM :DSTRING

Read parameter marker (?) values from the terminal.

* A zero parameter value terminates the DO loop.

DO WHILE (parameters ¬= 0)

Assign the values to the storage allocated for

input variables.

EXEC SQL EXECUTE S1 USING DESCRIPTOR SQLDA

Prompt user for more values.

Read parameter marker (?) values from the terminal.

END-DO

Figure 46. Parameterized Non-Query Statement

You may need a more complex scanning routine, depending on how many

different non-query statements you wish to process. For example, the above

routine would have to be modified if you wanted to process INSERT statements. In

that case, you would have to scan for the table and column names.

Note: Indicator variables are permitted when you are providing input to the

INSERT statement with EXECUTE.

Using an Alternative to a Scanning Routine

In the previous sections on parameterized statements (both query and non-query),

you must rely on a scanning routine to generate a query. Once the query is

generated, DESCRIBE obtains information about the columns and expressions

associated with a parameter marker.

If you have not coded a scanning routine that generates a query, there is a simple

alternative: have the user describe the parameter markers for you, and fill in the

SQLDA yourself. There is no rule that says you must use a DESCRIBE to fill in the

SQLDA. When using the SQLDA for input or output, it does not matter what fills

it in, as long as the needed values are there.

When you use the SQLDA for input (which is always the case for parameter

markers), not all fields have to be filled in. Specifically, SQLDAID and SQLDABC

need not be filled in. Thus, if you choose this method, you will need to ask the

user for the following:

1. How many parameter markers (?) are there?

Chapter 7. Using Dynamic Statements

231

2. What are the data types and lengths of these parameters?

In addition, if the routine is to handle both query and non-query statements, you

may want to ask the user what category of statement it is. (Alternatively, you can

write code to look for the SELECT keyword.)

The code that interrogates the user and sets up the SQLDA would take the place of

the scanning routine and DESCRIBE in the previous sections:

With a Scanning Routine:

READ DSTRING FROM TERMINAL

Scan the FROM and WHERE clauses of DSTRING for parameter markers

(?)

and generate an appropriate query in WSTRING.

Allocate an SQLDA of size 2 (2 was obtained from the scan).

SQLN = 2

EXEC SQL PREPARE S2 FROM :WSTRING

EXEC SQL DESCRIBE S2 INTO SQLDA

Analyze the results of the DESCRIBE.

Reset SQLTYPE to reflect that there is no indicator variable.

Allocate storage to hold the input values

(the parameter marker (?) values).

Set SQLDATA for each parameter marker (?) value.

Without a Scanning Routine:

READ DSTRING FROM TERMINAL

Interrogate user for number of parameter markers (?).

Allocate an SQLDA of that size.

Set SQLN and SQLD to the number of parameter markers (?).

For each parameter marker (?):

Interrogate user for data types, lengths, and

indicators.

Set SQLTYPE and SQLLEN.

Allocate storage to hold the input values

(the parameter marker (?) values).

Set SQLDATA and SQLIND (if applicable) for each

parameter marker (?).

The statement can then be processed in the usual manner.

Ensuring Data Type Equivalence in a Dynamically Defined Query

In previous uses of the SQLDA for input or output, SQLTYPE always described the

data type of the storage area pointed to by SQLDATA. In the following example,

the type code 500 (originally obtained with a DESCRIBE of the select-statement)

describes the data type of the main variable.

232

Application Programming

DB2 Server for VSE & VM Application Programming (Version 7 Release 5) - page 5
