Toyota Sienna (2019 year). Manual - part 7

SIENNA_OM_OM08025U_(U)

97

2. Instrument cluster

2

Instru

me
nt clu

ster

?

Speed limit display (if equipped)
Select to set the display of speed limit information stored in the nav-
igation system to on with the speed limit caution indicator (yellow)
enabled,  on  with  the  speed  limit  caution  not  enabled,  or  off.  If
enabled, the speed limit caution indicator will come on if the vehicle
speed exceeds the displayed speed limit.

The display may not be available for some regions.

?

BSM (Blind Spot Monitor) (if equipped)
The  brightness  of  the  outside  rear  view  mirror  indicators  can  be
adjusted. (

P. 548)

?

RCTA (Rear Cross Traffic Alert buzzer) (if equipped)
The buzzer sound volume can be adjusted. (

P. 548)

?

Maintenance Reset
Select to reset the maintenance data (

P. 399)

?

Initialization
Registered or changed meter settings will be deleted or returned to
their default setting.

?

Pop-up display
In some situations, such as when a switch operation is performed, a pop-up
display, such as the operating shift position, will be temporarily displayed on
the multi-information display.
The pop-up display function can be set on/off. (

P. 540)

?

Setting display automatic cancelation
In  the  following  situations,  setting  display  in  which  the  settings  can  be
changed through the meter control switch will automatically be turned off.

?

If a warning message appears while the setting display is displayed

?

When the vehicle begins to move while the setting display is displayed

?

Liquid crystal display
Small  spots  or  light  spots  may  appear  on  the  display. This  phenomenon  is
characteristic of liquid crystal displays, and there is no problem continuing to
use the display.

98

SIENNA_OM_OM08025U_(U)

2. Instrument cluster

WARNING

?

The information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal
information display. At extremely low temperatures, the display monitor may
respond slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear
number appearing on the display. This lag could cause the driver to down-
shift  again,  causing  rapid  and  excessive  engine  braking  and  possibly  an
accident resulting in death or injury.

?

Cautions during setting up the display
As the engine needs to be running during setting up the display, ensure that
the vehicle is parked in a place with adequate ventilation. In a closed area
such as a garage, exhaust gases including harmful carbon monoxide (CO)
may  collect  and  enter  the  vehicle.  This  may  lead  to  death  or  a  serious
health hazard.

NOTICE

?

During setting up the display
To prevent battery discharge, ensure that the engine is running while setting
up the display features.

99

SIENNA_OM_OM08025U_(U)

2. Instrument cluster

2

Instru

me
nt clu

ster

Fuel consumption information



Entune Audio or Entune Audio Plus (vehicles without Data Commu-
nication Module)

Press the “MENU” button.
Select  “Info”  on  the  “Menu”
screen.

If the “History” screen is displayed,
select “Trip Information”.

Fuel  consumption  information  can  be  displayed  on  the  audio/
visual system screen.

Trip information

1

2

100

SIENNA_OM_OM08025U_(U)

2. Instrument cluster



Entune Audio or Entune Audio Plus (vehicles with Data Communi-
cation Module)/Entune Premium Audio
Press the “MENU” button.
Select “Info” on the “Menu” screen.
Select “ECO” on the “Information” screen.

If the “History” screen is displayed, select “Trip Information”.

Resetting the consumption data
Average  vehicle  speed  since
the engine was started
Elapsed  time  since  the  engine
was started
Fuel consumption in the past 15
minutes
Cruising range (

P. 102)

Current fuel consumption

Average fuel consumption for the past 15 minutes is divided by color
into past averages and averages attained since the engine switch was
last  turned  to  IGNITION  ON  mode.  Use  the  displayed  average  fuel
consumption as a reference.

This image is an example only.

1

2

3

1

2

3

4

5

6

SIENNA_OM_OM08025U_(U)

101

2. Instrument cluster

2

Instru

me
nt clu

ster



Entune Audio or Entune Audio Plus (vehicles without Data Commu-
nication Module)

Press the “MENU” button.
Select  “Info”  on  the  “Menu”
screen.

If  the  “Trip  Information”  screen  is
displayed, select “History”.



Entune Audio or Entune Audio Plus (vehicles with Data Communi-
cation Module)/Entune Premium Audio
Press the “MENU” button.
Select “Info” on the “Menu” screen.
Select “ECO” on the “Information” screen.

If the “Trip Information” screen is displayed, select “History”.

Resetting the past record data
Best recorded fuel consumption
Current fuel economy
Previous

fuel

consumption

record



Entune  Audio  and  Entune
Audio Plus

Displays  the  daily  average  fuel  consumption.  (Instead  of  the  date,
“Trip 1” through “Trip 5” will be displayed.)



Entune Premium Audio

Displays the daily average fuel consumption.

Updating the average fuel consumption data

The  average  fuel  consumption  history  is  divided  by  color  into  past
averages  and  the  average  fuel  consumption  since  the  last  updated.
Use the displayed average fuel consumption as a reference.

This image is an example only.

History

1

2

1

2

3

1

2

3

4

5

102

SIENNA_OM_OM08025U_(U)

2. Instrument cluster

?

Updating the past record data
Update the average fuel consumption by selecting “Clip” to measure the cur-
rent fuel consumption again.

?

Resetting the data
The fuel consumption data can be deleted by selecting “Clear”.

?

Cruising range
Displays the estimated maximum distance that can be driven with the quan-
tity of fuel remaining.
This distance is computed based on your average fuel consumption.
As a result, the actual distance that can be driven may differ from that dis-
played.

103

SIENNA_OM_OM08025U_(U)

3

Operation of

each component

3-1. Key information

Keys .................................. 104

3-2. Opening, closing and

locking the doors

Front doors........................ 110
Sliding doors ..................... 121
Back door.......................... 133
Smart key system ............. 143

3-3. Adjusting the seats

Front seats ........................ 149
Rear seats......................... 152
Driving position memory ... 169
Head restraints.................. 173

3-4. Adjusting the steering

wheel and mirrors

Steering wheel .................. 177
Inside rear view mirror ...... 179
Outside rear view

mirrors............................. 181

3-5. Opening, closing the

windows and moon roof

Power windows ................. 184
Quarter windows ............... 187
Moon roof.......................... 189

104

SIENNA_OM_OM08025U_(U)

3-1. Key information

Keys

The following keys are provided with the vehicle.



Vehicles without a smart key system

Master keys (black)
Valet key (gray)
Key number plate



Vehicles with a smart key system

Electronic keys

• Operating the smart key system

(

P. 143)

• Operating  the  wireless  remote

control function

Mechanical keys
Key number plate

The keys

1

2

3

1

2

3

SIENNA_OM_OM08025U_(U)

105

3-1. Key information

3

Op
eration

 o

f each

 compo

nen
t



Vehicles without a smart key system (type A)

Locks all doors (

P. 111)

Unlocks all doors (

P. 111)

Sounds the alarm (

P. 106)



Vehicles without a smart key system (type B)

Locks all doors (

P. 111)

Unlocks all doors (

P. 111)

Opens  and  closes  the  left  side
power sliding door (

P. 124)

Opens and closes the right side
power sliding door (

P. 124)

Opens  and  closes  the  power
back door

*

 (

P. 135)

Sounds the alarm (

P. 106)

*

: If equipped



Vehicles with a smart key system

Locks all doors (

P. 111)

Unlocks all doors (

P. 111)

Opens  and  closes  the  left  side
power sliding door (

P. 124)

Opens and closes the right side
power sliding door (

P. 124)

Opens  and  closes  the  power
back door (

P. 135)

Sounds the alarm (

P. 106)

Wireless remote control

1

2

3

1

2

3

4

5

6

1

2

3

4

5

6

106

SIENNA_OM_OM08025U_(U)

3-1. Key information

To  take  out  the  mechanical  key,
push the release button and take
the key out.

The  mechanical  key  can  only  be
inserted  in  one  direction,  as  the
key only has grooves on one side.
If  the  key  cannot  be  inserted  in  a
lock  cylinder,  turn  it  over  and  re-
attempt to insert it.
After  using  the  mechanical  key,  store  it  in  the  electronic  key.  Carry  the
mechanical key together with the electronic key. If the electronic key bat-
tery  is  depleted  or  the  entry  function  does  not  operate  properly,  you  will
need the mechanical key. (

P. 503)

?

Panic mode



Vehicles without a smart key system



Vehicles with a smart key system

Using the mechanical key (vehicles with a smart key system)

When

  is  pressed  for  longer  than

about  one  second,  an  alarm  will  sound
intermittently  and  the  vehicle  lights  will
flash  to  deter  any  person  from  trying  to
break into or damage your vehicle.
To stop the alarm, press any button on the
wireless remote control.

When

  is  pressed  for  longer  than

about  one  second,  an  alarm  will  sound
intermittently  and  the  vehicle  lights  will
flash  to  deter  any  person  from  trying  to
break into or damage your vehicle.
To stop the alarm, press any button on the
electronic key.

SIENNA_OM_OM08025U_(U)

107

3-1. Key information

3

Op
eration

 o

f each

 compo

nen
t

?

When required to leave the vehicle’s key with a parking attendant
Lock the glove box as circumstances demand. (

P. 351)

On  vehicles  without  the  smart  key  system,  provide  the  attendant  with  the
valet key.
On vehicles with the smart key system, remove the mechanical key for your
own use and provide the attendant with the electronic key only.

?

If you lose your keys
New genuine keys can be made by your Toyota dealer using a master key
(vehicles without a smart key system) or the other key (vehicles with a smart
key system) and the key number stamped on your key number plate. Keep
the plate in a safe place such as your wallet, not in the vehicle.

?

When riding in an aircraft
When  bringing  a  key  with  wireless  remote  control  function  onto  an  aircraft,
make sure you do not press any buttons on the key while inside the aircraft
cabin. If you are carrying the key in your bag etc., ensure that the buttons are
not likely to be pressed accidentally. Pressing a button may cause the key to
emit radio waves that could interfere with the operation of the aircraft.

?

Conditions affecting the operation of the smart key system or wireless
remote control
P. 118

?

Key battery depletion



Vehicles without a smart key system

If the wireless remote control function does not operate, the battery may be
depleted. Replace the battery when necessary. (

P. 436)



Vehicles with a smart key system

?

The standard battery life is 1 to 2 years.

?

If the battery becomes low, an alarm will sound in the cabin when the engine
stops. (

P. 436, 481)

?

As the electronic key always receives radio waves, the battery will become
depleted even if the electronic key is not used. The following symptoms indi-
cate  that  the  electronic  key  battery  may  be  depleted.  Replace  the  battery
when necessary. (

P. 436)

• The smart key system or the wireless remote control does not operate.
• The detection area becomes smaller.
• The LED indicator on the key surface does not turn on.

?

To  avoid  serious  deterioration,  do  not  leave  the  electronic  key  within  3 ft.
(1 m) of the following electrical appliances that produce a magnetic field.
• TVs
• Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
• Induction cookers
• Table lamps

108

SIENNA_OM_OM08025U_(U)

3-1. Key information

?

When the key battery is fully depleted
P. 436

?

Confirmation of the registered key number
The number of keys already registered to the vehicle can be confirmed. Ask
your Toyota dealer for details.

?

Certification  for  wireless  remote  control  (vehicles  without  a  smart  key
system)
This  device  complies  with  Part  15  of  the  FCC  Rules  and  with  RSS-210  of
Industry Canada. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept
any  interference  received,  including  interference  that  may  cause  undesired
operation.

?

Certification for wireless remote control (vehicles with a smart key sys-
tem)



For vehicles sold in the U.S.A.

FCC ID: HYQ14ADR

FCC ID: HYQ14AEH

FCC ID: HYQ13CZM

FCC ID: HYQ13CZN

FCC ID: NI4TMLF8-20
NOTE:
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence,  and  (2)  this  device  must  accept  any  interference  received,  including
interference that may cause undesired operation.
FCC WARNING:
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.



For vehicles sold in Canada

NOTE:
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, includ-
ing interference that may cause undesired operation of the device.
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, includ-
ing interference that may cause undesired operation of the device.

?

Customization
Settings (e.g. wireless remote control system) can be changed.
(Customizable features:

P. 543, 544)

SIENNA_OM_OM08025U_(U)

109

3-1. Key information

3

Op
eration

 o

f each

 compo

nen
t

NOTICE

?

To prevent key damage

?

Do not drop the keys, subject them to strong shocks or bend them.

?

Do not expose the keys to high temperatures for long periods of time.

?

Do not get the keys wet or wash them in an ultrasonic washer etc.

?

Do not attach metallic or magnetic materials to the keys or place the keys
close to such materials.

?

Do not disassemble the keys.

?

Do not attach a sticker or anything else to the surface of the electronic key.

?

Do not place the keys near objects that produce magnetic fields, such as
TVs,  audio  systems  and  induction  cookers,  or  medical  electrical  equip-
ment, such as low-frequency therapy equipment.

?

Carrying the electronic key on your person (vehicles with a smart key
system)
Carry  the  electronic  key  3.9 in.  (10 cm)  or  more  away  from  electric  appli-
ances  that  are  turned  on.  Radio  waves  emitted  from  electric  appliances
within 3.9 in. (10 cm) of the electronic key may interfere with the key, caus-
ing the key to not function properly.

?

In case of a smart key system malfunction or other key-related prob-
lems (vehicles with a smart key system)
Take your vehicle with all the electronic keys provided with your vehicle to
your Toyota dealer.

?

When a vehicle key is lost (vehicles with a smart key system)
If the key remains lost, the risk of vehicle theft increases significantly. Visit
your Toyota dealer immediately with all remaining electronic keys that were
provided with your vehicle.

110

SIENNA_OM_OM08025U_(U)

3-2. Opening, closing and locking the doors

Front doors

?

Entry function (vehicles with a smart key system)

Carry the electronic key to enable this function.

Grip the driver’s door handle
to  unlock  the  door.  Grip  the
passenger’s  door  handle  to
unlock all the doors.

*

Make  sure  to  touch  the  sensor
on the back of the handle.
The  doors  cannot  be  unlocked
for 3 seconds after the doors are
locked.

*

: The door unlock settings can be changed. (

P. 117)

Touch the lock sensor (the indentation on the upper part of the
door handle) to lock all the doors.

Check that the door is securely locked.

Unlocking and locking the doors from the outside

1

2

SIENNA_OM_OM08025U_(U)

111

3-2. Opening, closing and locking the doors

3

Op
eration

 o

f each

 compo

nen
t

?

Wireless remote control



Vehicles without a smart key system (type A)

Locks all doors

Check  that  the  door  is  securely
locked.

Unlocks all doors

Pressing the button unlocks the
driver’s side doors. Pressing the
button  again  within  3 seconds
unlocks the other doors.



Vehicles without a smart key system (type B)

Locks all doors

Check  that  the  door  is  securely
locked.

Unlocks all doors

Pressing the button unlocks the
driver’s side doors. Pressing the
button  again  within  3 seconds
unlocks the other doors.



Vehicles with a smart key system

Locks all doors

Check  that  the  door  is  securely
locked.

Unlocks all doors

Pressing the button unlocks the
driver’s side doors. Pressing the
button  again  within  3 seconds
unlocks the other doors.

1

2

1

2

1

2

112

SIENNA_OM_OM08025U_(U)

3-2. Opening, closing and locking the doors

?

Key



Vehicles without a smart key system

Locks all the doors
Unlocks all the doors

Turning  the  key  unlocks  the
driver’s  side  doors.  Turning  the
key  again  within  3  seconds
unlocks the other doors.



Vehicles with a smart key system

The  doors  can  also  be  locked  and  unlocked  with  the  mechanical
key. (

P. 503)

1

2
