Toyota Sienna (2019 year). Manual - part 5

1-1. For safe use

SIENNA_OM_OM08025U_(U)

Fo
r safety and securi



Type A

Latch the hooks of the lower
straps

onto

the

LATCH

anchors.  If  the  child  restraint
has  a  top  tether  strap,  the  top
tether  strap  should  be  latched
onto the top tether strap anchor.
For owners in Canada:
The symbol on a child restraint
system  indicates  the  presence
of a lower connector system.



Type B

Latch  the  buckles  onto  the
LATCH  anchors.  If  the  child
restraint has a top tether strap,
the  top  tether  strap  should  be
latched onto the top tether strap
anchor.
For owners in Canada:
The symbol on a child restraint
system  indicates  the  presence
of a lower connector system.

Canada only

1-1. For safe use

SIENNA_OM_OM08025U_(U)



Manual seat

Fold the seatback while pulling
the  strap.  Return  the  seatback
and  secure  it  at  the  1st  lock
position  (most  upright  posi-
tion). Adjust the seatback to the
11th lock position.

1st lock position
11th lock position



Power seat

Fold  down  the  seatback  by
pressing  the  folding/returning
switch  (

P. 161). Raise the

seatback by pressing the same
switch, the returning switch
(

P. 164) or the seatback angle

adjustment switch (

P. 154).

(The seatback will automatically
stop.) Do not touch the switch
while the seatback is moving,
because the operation will stop.
Widen the gap between the seat cushion and seatback slightly.

Installation with LATCH system (third seat)

1-1. For safe use

SIENNA_OM_OM08025U_(U)

Fo
r safety and securi



Type A

Latch the hooks of the lower
straps

onto

the

LATCH



Type B

Canada only

1-1. For safe use

SIENNA_OM_OM08025U_(U)

Rear facing

Infant seat/convertible seat

Place the child restraint sys-
tem on the rear seat facing
the rear of the vehicle.

Run the seat belt through the
child  restraint  system  and
insert  the  plate  into  the
buckle.  Make  sure  that  the
belt is not twisted.

Fully extend the shoulder belt
and allow it to retract to put it
in lock mode. In lock mode,
the belt cannot be extended.

While  pushing  the  child
restraint  system  down  into
the  rear  seat,  allow  the
shoulder  belt  to  retract  until
the  child  restraint  system  is
securely in place.

After  the  shoulder  belt  has
retracted to a point where there
is  no  slack  in  the  belt,  pull  the
belt  to  check  that  it  cannot  be
extended.

Installing child restraints using a seat belt (child restraint lock
function belt)

1-1. For safe use

SIENNA_OM_OM08025U_(U)

Fo
r safety and securi

Forward facing

Convertible seat

Place the child restraint sys-
tem on the seat facing the
front of the vehicle.

Run the seat belt through the
child  restraint  system  and
insert  the  plate  into  the
buckle.  Make  sure  that  the
belt is not twisted.

Fully extend the shoulder belt
and allow it to retract to put it
in lock mode. In lock mode,
the belt cannot be extended.

While  pushing  the  child
restraint system into the rear
seat,  allow  the  shoulder  belt
to  retract  until  the  child
restraint  system  is  securely
in place.

After  the  shoulder  belt  has
retracted to a point where there
is  no  slack  in  the  belt,  pull  the
belt  to  check  that  it  cannot  be
extended.

If the child restraint has a top tether strap, the top tether strap
should be latched onto the top tether strap anchor. (

P. 71, 72)

1-1. For safe use

SIENNA_OM_OM08025U_(U)

Booster seat

Place the child restraint sys-
tem on the seat facing the
front of the vehicle.

Sit  the  child  in  the  child
restraint system. Fit the seat
belt to the child restraint sys-
tem  according  to  the  manu-
facturer’s  instructions  and
insert  the  plate  into  the
buckle.  Make  sure  that  the
belt is not twisted.

Check that the shoulder belt is correctly positioned over the child’s
shoulder and that the lap belt is as low as possible. (

P. 30)

Push the buckle release button
and fully retract the seat belt.

Removing a child restraint installed with a seat belt

1-1. For safe use

SIENNA_OM_OM08025U_(U)

Fo
r safety and securi

Secure the child restraint sys-
tem using the seat belt or
LATCH anchors, and adjust the
head restraint to the uppermost
position.

: Ottoman seat only

Latch the hook onto the anchor
bracket and tighten the top
tether strap.

Make sure the top tether strap is
securely latched.

Adjust the head restraint to the
downmost lock position.

Child restraint systems with a top tether strap (second seat)

1-1. For safe use

SIENNA_OM_OM08025U_(U)

Center seat

Secure  the  child  restraint
system using the seat belt or
LATCH  anchors.  Adjust  the
head  restraint  to  the  upper-
most position.

Latch the hook onto the
anchor bracket and tighten
the top tether strap.

Make sure the top tether strap is
securely latched.

Adjust the head restraint to
the downmost position.

Right outboard seat
Latch the hook onto the anchor
bracket and tighten the top
tether strap.

Make sure the top tether strap is
securely latched.
Pull the head restraint up to use.

Child restraint systems with a top tether strap (third seat)

1-1. For safe use

SIENNA_OM_OM08025U_(U)

Fo
r safety and securi

Laws and regulations pertaining to anchorages
The LATCH system conforms to FMVSS225 or CMVSS210.2.
Child restraint systems conforming to FMVSS213 or CMVSS213 specifica-
tions can be used.
This vehicle is designed to conform to the SAE J1819.

WARNING

When installing a booster seat
To prevent the belt from going into ALR lock mode, do not fully extend the
shoulder belt. ALR mode causes the belt to tighten only. This could cause
injury or discomfort to the child. (

P. 34)

When installing a child restraint system
Follow the directions given in the child restraint system installation manual
and fix the child restraint system securely in place.
If the child restraint system is not correctly fixed in place, the child or other
passengers may be seriously injured or even killed in the event of sudden
braking, sudden swerving or an accident.

If  the  driver’s  seat  interferes  with  the
child  restraint  system  and  prevents  it
from being attached correctly, attach the
child  restraint  system  to  the  right-hand
rear seat.

Adjust the front passenger seat or sec-
ond seats so that it does not interfere
with the child restraint system.

Only put a forward-facing child restraint
system on the front seat when unavoid-
able.  When  installing  a  forward-facing
child  restraint  system  on the  front  pas-
senger seat, move the seat as far back
as possible even if the “AIR BAG OFF”
indicator  light  is  illuminated.  Failure  to
do  so  may  result  in  death  or  serious
injury if the airbags deploy (inflate).

1-1. For safe use

SIENNA_OM_OM08025U_(U)

WARNING

When installing a child restraint system

When installing a child restraint system on the third center seat, adjust
both seatbacks at the same angle. Otherwise, the child restraint system
cannot be securely restrained and this may cause death or serious injuries
in the event of sudden braking, sudden swerving or an accident.

When using the LATCH anchors for a child restraint system, move the seat
as far back as possible (second seat only), with the seatback close to the
child restraint system.

When a booster seat is installed, always ensure that the shoulder belt is
positioned across the center of the child’s shoulder. The belt should be
kept away from the child’s neck, but not so that it could fall off the child’s
shoulder. Failing to do so may result in death or serious injury in the event
of sudden braking, sudden swerving or an accident.

Ensure that the belt and plate are securely locked and the seat belt is not
twisted.

Shake the child restraint system left and right, and forward and backward
to ensure that it has been securely installed.

After securing a child restraint system, never adjust the seat.

Follow all installation instructions provided by the child restraint system
manufacturer.

When securing some types of child restraint systems in second (8-passen-
ger models) or third row seats, it may not be possible to properly use the
seat belts in positions next to the child restraint without interfering with it or
affecting seat belt effectiveness. Be sure your seat belt fits snugly across
your shoulder and low on your hips. if it dose not, or if it interferes with the
child restraint, move to a different position. Failure to do so may result in
death or serious injury.

1-1. For safe use

SIENNA_OM_OM08025U_(U)

Fo
r safety and securi

WARNING

When installing a child restraint system to the AUTO ACCESS SEAT
(if equipped)

Do not use a seat belt extender
If a seat belt extender is used when installing a child restraint system, the
seat belt will not securely hold the child restraint system, which could cause
death or serious injury to the child or other passengers in the event of sud-
den braking, sudden swerving or an accident.

To correctly attach a child restraint system to the anchors
When using the LATCH anchors, be sure that there are no foreign objects
around the anchors and that the seat belt is not caught behind the child
restraint system. Make sure the child restraint system is securely attached,
or it may cause death or serious injury to the child or other passengers in
the event of a sudden braking, sudden swerving or an accident.

Do  not  operate  the  AUTO  ACCESS
SEAT  while  a  child  restraint  system  is
fixed  to  the  seat  by  the  child  restraint
lock function belt.
If you force the seat operation, the seat,
seat  belt  or  child  restraint  system  may
be damaged, or may cause an injury.

If a child restraint system is fixed to the
AUTO ACCESS SEAT by the LATCH
system, be careful that the child’s head,
hands and legs do not hit the body of
the vehicle when operating the seat.
Injuries may be caused.

1-1. For safe use

SIENNA_OM_OM08025U_(U)

Exhaust gas precautions

Harmful substance to the human body is included in exhaust
gases if inhaled.

WARNING

Exhaust gases include harmful carbon monoxide (CO), which is colorless and
odorless. Observe the following precautions.
Failure to do so may cause exhaust gases enter the vehicle and may lead to
an accident caused by light-headedness, or may lead to death or a serious
health hazard.

Important points while driving

Keep the back door closed.

If you smell exhaust gases in the vehicle even when the back door is
closed, open the windows and have the vehicle inspected at your Toyota
dealer as soon as possible.

When parking

If the vehicle is in a poorly ventilated area or a closed area, such as a
garage, stop the engine.

Do not leave the vehicle with the engine on for a long time.
If such a situation cannot be avoided, park the vehicle in an open space
and ensure that exhaust fumes do not enter the vehicle interior.

Do not leave the engine running in an area with snow build-up, or where it
is snowing. If snowbanks build up around the vehicle while the engine is
running, exhaust gases may collect and enter the vehicle.

Exhaust pipe
The exhaust system needs to be checked periodically. If there is a hole or
crack caused by corrosion, damage to a joint or abnormal exhaust noise, be
sure to have the vehicle inspected and repaired by your Toyota dealer.

1-2. Theft deterrent system

SIENNA_OM_OM08025U_(U)

Fo
r safety and securi

Engine immobilizer system



Vehicles without a smart key
system

The  indicator  light  flashes  after
the  key  has  been  removed  from
the  engine  switch  to  indicate  that
the system is operating.
The  indicator  light  stops  flashing
after the registered key has been
inserted into the engine switch to
indicate that the system has been
canceled.



Vehicles with a smart key system

The indicator light flashes after the engine switch has been turned off
to indicate that the system is operating.
The indicator light stops flashing after the engine switch has been
turned to ACCESSORY or IGNITION ON mode to indicate that the
system has been canceled.

The vehicle’s keys have built-in transponder chips that prevent
the engine from starting if a key has not been previously regis-
tered in the vehicle’s on-board computer.
Never leave the keys inside the vehicle when you leave the vehi-
cle.

This system is designed to help prevent vehicle theft but does not
guarantee absolute security against all vehicle thefts.

1-2. Theft deterrent system

SIENNA_OM_OM08025U_(U)

System maintenance
The vehicle has a maintenance-free type engine immobilizer system.

Conditions that may cause the system to malfunction

If the grip portion of the key is in contact with a metallic object

If the key is in close proximity to or touching a key to the security system
(key with a built-in transponder chip) of another vehicle

Certifications for the engine immobilizer system



For vehicles sold in the U.S.A.

Vehicles without a smart key system
FCC ID: WRKRI-44BTY
Vehicles with a smart key system
FCC ID: NI4TMIMB-1
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.



For vehicles sold in Canada

WARNING

Certifications for the engine immobilizer system
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.

NOTICE

To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper
operation of the system cannot be guaranteed.

1-2. Theft deterrent system

SIENNA_OM_OM08025U_(U)

Fo
r safety and securi

Alarm



The alarm uses light and sound to give an alert when an intrusion is
detected.
The alarm is triggered in the following situations when the alarm is
set:

A locked door is unlocked or opened in any way other than using
the entry function (vehicles with a smart key system) or wireless
remote control. (The doors will lock again automatically.)

The hood is opened.

Close  the  doors  and  hood,  and
lock  all  the  doors  using  the  entry
function (vehicles with a smart key
system)  or  wireless  remote  con-
trol. The  system  will  be  set  auto-
matically after 30 seconds.

The indicator light changes from
being on to flashing when the sys-
tem is set.

Do one of the following to deactivate or stop the alarm:

Unlock the doors using the entry function (vehicles with a smart key
system) or wireless remote control.

Vehicles without a smart key system: Turn the engine switch to the
“ACC” or “ON” position, or start the engine.
Vehicles with a smart key system: Turn the engine switch to
ACCESSORY or IGNITION ON mode, or start the engine.
(The alarm will be deactivated or stopped after a few seconds.)



: If equipped

The alarm

Setting the alarm system

Deactivating or stopping the alarm

1-2. Theft deterrent system

SIENNA_OM_OM08025U_(U)

System maintenance
The vehicle has a maintenance-free type alarm system.

Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of
the following:

Nobody is in the vehicle.

The windows and moon roof (if equipped) are closed before the alarm is set.

No valuables or other personal items are left in the vehicle.

Triggering of the alarm
The alarm may be triggered in the following situations.
(Stopping the alarm deactivates the alarm system.)

The doors are unlocked using the key.

A person inside the vehicle opens a door
or hood.

The battery is recharged or replaced
when the vehicle is locked. (

P. 505)

Content .. 3 4 5 6 ..
