weight

The combined weight of installed regular pro-

duction options weighing over 5 lb. (2.3 kg) in

excess of the standard items which they

replace, not previously considered in curb

weight or accessory weight, including heavy

duty brakes, ride levelers, roof rack, heavy

duty battery, and special trim

Rim

A metal support for a tire or a tire and tube

assembly upon which the tire beads are

seated

Rim diameter

(Wheel diameter)

Nominal diameter of the bead seat

Rim size designation

Rim diameter and width

Rim type designation

The industry manufacturer’s designation for a

rim by style or code

Rim width

Nominal distance between rim flanges

Vehicle

capacity

weight

(Total

load

capacity)

The rated cargo and luggage load plus 150 lb.

(68 kg) times the vehicle’s designated seating

capacity

Vehicle maximum load

on the tire

The load on an individual tire that is deter-

mined by distributing to each axle its share of

the maximum loaded vehicle weight, and

dividing by two

Vehicle normal load on

the tire

The load on an individual tire that is deter-

mined by distributing to each axle its share of

curb weight, accessory weight, and normal

occupant weight (distributed in accordance

with Table 1

below), and dividing by two

Weather side

The surface area of the rim not covered by the

inflated tire

Bead

The part of the tire that is made of steel wires,

wrapped or reinforced by ply cords and that is

shaped to fit the rim

Bead separation

A breakdown of the bond between compo-

nents in the bead

Tire related term

Meaning

482

Bias ply tire

A pneumatic tire in which the ply cords that

extend to the beads are laid at alternate

angles substantially less than 90 degrees to

the centerline of the tread

Carcass

The tire structure, except tread and sidewall

rubber which, when inflated, bears the load

Chunking

The breaking away of pieces of the tread or

sidewall

Cord

The strands forming the plies in the tire

Cord separation

The parting of cords from adjacent rubber

compounds

Cracking

Any parting within the tread, sidewall, or inner-

liner of the tire extending to cord material

A pneumatic tire with an inverted flange tire

and rim system in which the rim is designed

with rim flanges pointed radially inward and

the tire is designed to fit on the underside of

the rim in a manner that encloses the rim

flanges inside the air cavity of the tire

Extra load tire

A tire designed to operate at higher loads and

at higher inflation pressures than the corre-

sponding standard tire

Groove

The space between two adjacent tread ribs

Innerliner

The layer(s) forming the inside surface of a

tubeless tire that contains the inflating medium

within the tire

Innerliner separation

The parting of the innerliner from cord material

in the carcass

Intended

outboard

sidewall

(a) The sidewall that contains a whitewall,

bears white lettering, or bears manufac-

turer, brand, and/or model name molding

that is higher or deeper than the same

molding on the other sidewall of the tire, or

(b) The outward facing sidewall of an asym-

metrical tire that has a particular side that

must always face outward when mounted

on a vehicle

Tire related term

Meaning

483

Vehi

Light truck (LT) tire

A tire designated by its manufacturer as pri-

marily intended for use on lightweight trucks

or multipurpose passenger vehicles

Load rating

The maximum load that a tire is rated to carry

for a given inflation pressure

Maximum load rating

The load rating for a tire at the maximum per-

missible inflation pressure for that tire

Maximum permissible

inflation pressure

The maximum cold inflation pressure to which

a tire may be inflated

Measuring rim

The rim on which a tire is fitted for physical

dimension requirements

Open splice

Any parting at any junction of tread, sidewall,

or innerliner that extends to cord material

Outer diameter

The overall diameter of an inflated new tire

Overall width

The linear distance between the exteriors of

the sidewalls of an inflated tire, including ele-

vations due to labeling, decorations, or protec-

tive bands or ribs

Passenger car tire

A tire intended for use on passenger cars,

multipurpose passenger vehicles, and trucks,

that have a gross vehicle weight rating

(GVWR) of 10,000 lb. or less.

Ply

A layer of rubber-coated parallel cords

Ply separation

A parting of rubber compound between adja-

cent plies

Pneumatic tire

A mechanical device made of rubber, chemi-

cals, fabric and steel or other materials, that,

when mounted on an automotive wheel, pro-

vides the traction and contains the gas or fluid

that sustains the load

Radial ply tire

A pneumatic tire in which the ply cords that

extend to the beads are laid at substantially 90

degrees to the centerline of the tread

Reinforced tire

A tire designed to operate at higher loads and

at higher inflation pressures than the corre-

sponding standard tire

Tire related term

Meaning

484

: Table 1

 Occupant loading and distribution for vehicle normal load for

various designated seating capacities

Section width

The linear distance between the exteriors of

the sidewalls of an inflated tire, excluding ele-

vations due to labeling, decoration, or protec-

tive bands

Sidewall

That portion of a tire between the tread and

bead

Sidewall separation

The parting of the rubber compound from the

cord material in the sidewall

Snow tire

A tire that attains a traction index equal to or

greater than 110, compared to the ASTM E-

1136 Standard Reference Test Tire, when

using the snow traction test as described in

ASTM F-1805-00, Standard Test Method for

Single Wheel Driving Traction in a Straight

Line on Snow-and Ice-Covered Surfaces, and

which is marked with an Alpine Symbol (

)

on at least one sidewall

Test rim

The rim on which a tire is fitted for testing, and

may be any rim listed as appropriate for use

with that tire

Tread

That portion of a tire that comes into contact

with the road

Tread rib

A tread section running circumferentially

around a tire

Tread separation

Pulling away of the tread from the tire carcass

Treadwear indicators

(TWI)

The projections within the principal grooves

designed to give a visual indication of the

degrees of wear of the tread

Wheel-holding fixture

The fixture used to hold the wheel and tire

assembly securely during testing

Tire related term

Meaning

485

Vehi

Designated seating

capacity, Number of

occupants

Vehicle normal load,

Number of occupants

Occupant distribution

in a normally loaded

vehicle

2 through 4

2 in front

5 through 10

2 in front, 1 in second

seat

11 through 15

2 in front, 1 in second

seat, 1 in third seat, 1

in fourth seat

16 through 20

2 in front, 2 in second

seat, 2 in third seat, 1

in fourth seat

486

Customizable features

■

Changing using the multi-information display

Press “

” or “” of the meter control switches, select

Press “

” or “” of the meter control switches, select “Meter Set-

tings”, and then press

Press “

” or “” of the meter control switches, select the item, and

then press

Press “

” or “” of the meter control switches, select the desired

setting, and then press

To go back to the previous screen or exit the customize mode,
press

Your vehicle includes a variety of electronic features that can be
personalized to suit your preferences. The settings of these fea-
tures can be changed using the multi-information display or at
your Toyota dealer.

Customizing vehicle features

487

Vehi

■

Changing on the audio system screen

Press the “MENU” button.

Select “Setup” on the “Menu” screen.

Select “General” or “Vehicle” on the “Setup” screen.
Various setting can be changed. Refer to the list of settings that can
be changed for details.

Some function settings are changed simultaneously with other func-
tions when customized. Contact your Toyota dealer for further details.

Settings that can be changed using the multi-information display
Settings that can be changed on the audio system screen
Settings that can be changed by your Toyota dealer

Definition of symbols: O = Available, — = Not available

Customizable features

488

■

Gauges, meters and multi-information display (

P. 88, 91)

: The default setting varies according to country.

: 2 of the following items: current fuel consumption (gauge display), current

fuel consumption (numerical display), average fuel economy (after reset),
average  fuel  economy  (after  start),  average  fuel  economy  (after  refuel),
average  vehicle  speed  (after  reset),  average  vehicle  speed  (after  start),
elapsed  time  (after  reset),  elapsed  time  (after  start),  distance  (driving
range), distance (after start), blank.

Function

Default setting

Customized

setting

Language

English

French

O O O

Units

miles (MPG)

km (km/L)

O O O

km (L/100 km)

°F

°C

O O O

Eco Driving Indicator
Light

(Self-lighting)

Off

O — O

Drive information 1

Current fuel

consumption

(gauge display)

O — O

Average fuel

economy

(after reset)

Drive information 2

Distance

(driving range)

O — O

Average vehicle

speed (after reset)

Pop-up display

Off

–

Speed limit

With caution

Only display

–

OFF

489

Vehi

■

Instrument cluster (

P. 94)

Function

Default setting

Customized

setting

Sensor  sensitivity  for
darkening  the  bright-
ness of the instrument
cluster  depending  on
the outside brightness

Standard

-2 to 2

— — O

Sensor  sensitivity  for
returning  the  bright-
ness of the instrument
cluster  to  the  original
level  depending  on
the outside brightness

Standard

-2 to 2

— — O

490

■

Smart key system

and wireless remote control (

P. 112, 125)

: If equipped

Function

Default setting

Customized

setting

Operation

signal

(buzzer)

Off

— O O

1 to 7

Operation

signal

(emergency flashers)

Off

— O O

Unlocking operation

Driver’s door

unlocked in one

step, all doors

unlocked in two

step

All doors unlocked

in one step

— O O

Time  elapsed  before
the  automatic  door
lock  function  is  acti-
vated  if  a  door  is  not
opened  after  being
unlocked

60 seconds

30 seconds

— O O

120 seconds

Open door reminder
buzzer (When locking
the vehicle)

Off

— — O

Locking

operation

when door opened

Off

— O O

491

Vehi

■

Smart key system

(

P. 125)

: If equipped

■

Wireless remote control (

P. 112)

■

Outside rear view mirrors (

P. 146)

Function

Default setting

Customized

setting

Smart key system

Off

— O O

Smart door unlocking

Driver’s door

All the doors

— O O

Number of consecu-
tive door lock opera-
tions

2 times

As many as

desired

— — O

Function

Default setting

Customized

setting

Wireless remote con-
trol

Off

— — O

Function

Default setting

Customized

setting

Automatic mirror fold-
ing and extending
operation

Linked to the

locking/unlocking

of the doors

Off

— — O

Linked to opera-

tion of the engine

switch

— — O

492

■

Power windows (

P. 149)

: Vehicles without a smart key system

: Vehicles with a smart key system

■

Turn signal lever (

P. 186)

Function

Default setting

Customized

setting

Key

or mechanical

key

linked operation

(open)

Off

— — O

Key

or mechanical

key

linked operation

(close)

Off

— — O

Wireless remote con-
trol linked operation
(open only)

Off

— — O

Key

or mechanical

key

wireless

remote control linked
operation

signal

(buzzer)

Off

— — O

Function

Default setting

Customized

setting

Times of flashing of
the lane change sig-
nal flashers

Off

— — O

493

Vehi

■

Automatic light control system (

P. 195)

■

PCS (Pre-Collision System) (

P. 224)

■

LDA (Lane Departure Alert with steering control) (

P. 238)

■

Air conditioning system (

P. 292)

Function

Default setting

Customized

setting

Light sensor sensitiv-
ity

Level 0

Level -2 to 2

— O O

Time  elapsed  before
headlights  automati-
cally  turn  off  after
doors are closed

30 seconds

Off

— O O

60 seconds

90 seconds

Daytime running lights
(except for Canada)

Off

— O O

Function

Default setting

Customized

setting

Pre-collision system

Off

O — O

Warning timing

Middle

Far

O — O

Near

Function

Default setting

Customized

setting

Steering assist

Off

O — O

Alert sensitivity

Standard

High

O — O

Vehicle sway warning

Off

O — O

Vehicle sway warning
sensitivity

Standard

Low

O — O

High

Function

Default setting

Customized

setting

A/C auto switch oper-
ation

Auto

Manual

— O O

494

■

Illumination (

P. 302)

: Vehicles with a smart key system

: If equipped

Function

Default setting

Customized

setting

Time elapsed before

the interior lights turn

off

15 seconds

Off

— O O

7.5 seconds

30 seconds

Operation after the
engine

switch

turned off

Off

— — O

Operation when the
doors are unlocked

Off

— — O

Operation when you
approach the vehicle
with the electronic key
on your person

Off

— — O

Outer mirror illumina-
tion

Off

— — O

Time elapsed before
the outer mirror illumi-
nation turn off

15 seconds

Off

— — O

7.5 seconds

30 seconds

Operation of the outer
mirror

illumination

when you approach
the vehicle with the
electronic key on your
person

1, 2

Off

— — O

Operation of the outer
mirror

illumination

when the doors are
unlocked

Off

— — O

Interior lights illumina-
tion control

Off

— — O

495

Vehi
