Toyota Sequoia (2018 year). Manual - part 10

SEQUOIA_OM_USA_OM0C011U

Power windows

The power windows can be opened and closed using the switches.

Operating the switch moves the windows as follows:

Closing

One-touch closing
(front windows only)

Opening

One-touch opening
(front windows only)

: To stop the window partway, oper-

ate the switch in the opposite direc-
tion.

Press the switch to lock the pas-
senger window switches and back
window switch.

Use this switch to prevent children
from accidentally opening or clos-
ing a passenger window and back
window.

Opening and closing procedures

Window lock switch

150

SEQUOIA_OM_USA_OM0C011U

■

The power windows can be operated when
The engine switch is in the “ON” position.

■

Operating the power windows after turning the engine off
The power windows can be operated for approximately 45 seconds even
after the engine switch is turned to the “ACC” or “LOCK” position. They can-
not, however, be operated once either front door is opened.

■

Jam protection function (front windows only)
If an object becomes jammed between the window and the window frame
while the window is closing, window movement is stopped and the window is
opened slightly.

■

When the power window does not close normally
If the jam protection function is operating abnormally and a window cannot be
closed, perform the following operations using the power window switch on
the front door.

●

After stopping the vehicle, the window can be closed by holding the power
window switch in the one-touch closing position while the engine switch is
turned to the “ON” position.

●

If the window still cannot be closed even by carrying out the operation as
explained above, initialize the function by performing the following proce-
dure.

Hold the power window switch in the one-touch closing position. Continue
holding the switch for a further 6 seconds after the window has closed.

Hold the power window switch in the one-touch opening position. Con-
tinue holding the switch for a further 2 seconds after the window has
opened completely.

Hold the power window switch in the one-touch closing position once
again. Continue holding the switch for a further 2 seconds after the win-
dow has closed.

If you release the switch while the window is moving, start again from the
beginning.
If the window re-opens slightly after performing the above procedure cor-
rectly, have the vehicle inspected by your Toyota dealer.

■

Door lock linked window operation
The power windows can be opened and closed using the key.

(

→P. 104)

: These settings must be customized at your Toyota dealer.

■

Customization
Settings (e.g. key linked operation) can be changed.
(Customizable features

→P. 520)

151

SEQUOIA_OM_USA_OM0C011U

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

Closing the windows

●

The driver is responsible for all the power window operations, including the
operation for the passengers. In order to prevent accidental operation,
especially by a child, do not let a child operate the power windows. It is
possible for children and other passengers to have body parts caught in
the power window. Also, when riding with a child, it is recommended to use
the window lock switch. (

→P. 149)

●

Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.

●

When using the key or mechanical key and operating the power windows,
operate the power window after checking to make sure that there is no
possibility of any passenger having any of their body parts caught in the
window. Also do not let a child operate window by the key. It is possible for
children and other passengers to get caught in the power window.

●

When exiting the vehicle, turn the engine switch off, carry the key and exit
the vehicle along with the child. There may be accidental operation, due to
mischief, etc., that may possibly lead to an accident.

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection
function.

●

The jam protection function may not work if something gets jammed just
before the window is fully closed. Be careful not to get any part of your
body jammed in the window.

152

SEQUOIA_OM_USA_OM0C011U

Power back window



From inside the vehicle

One-touch closing

1, 2

Closing

One-touch opening

Opening

: Pressing the switch in the opposite

direction will stop window travel
partway.

: During off-road traveling, the one-

touch closing operation

may be

deactivated depending on the vehi-
cle speed and road surface condi-
tions. At that time, close the
window using the normal closing
operation



From outside the vehicle

Opening

Closing

Turn the key fully and hold it.

The power back window can be opened and closed using the
switch or key.

Opening and closing procedures

153

SEQUOIA_OM_USA_OM0C011U

■

The power back window can be operated from inside the vehicle when

●

The engine switch is in the “ON” position.

●

The power back window can be opened when the rear window wiper is
working, but the wiper stops working until the window is closed again.
If the power back window is not fully closed, the rear window wiper, washer,
and defogger will not work.

■

Operating the power back window from inside the vehicle after turning
the engine off
The power back window can be operated for approximately 45 seconds even
after the engine switch is turned to the “ACC” or “LOCK” position. It cannot,
however, be operated once either front door is opened.

■

Jam protection function
If an object becomes caught between the window and the window frame, win-
dow travel is stopped and the window is opened slightly.

■

When the power back window does not close normally
If the jam protection function is operating abnormally and a window cannot be
closed, perform the following operations using the power back window
switch.

●

After stopping the vehicle, the window can be closed by holding the power
back window switch in the one-touch closing position while the engine
switch is turned to the “ON” position.

●

If the window still cannot be closed even by carrying out the operation
explained above, initialize the function by performing the following proce-
dure.

Hold the power back window switch in the one-touch closing position.
Continue holding the switch for a further 6 seconds after the window has
closed.

Hold the power back window switch in the one-touch opening position.
Continue holding the switch for a further 2 seconds after the window has
opened completely.

Hold the power back window switch in the one-touch closing position
once again. Continue holding the switch for a further 2 seconds after the
window has closed.

154

SEQUOIA_OM_USA_OM0C011U

■

Customization
Settings (e.g. linked operation) can be changed.
(Customizable features

→P. 520)

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

Caution while driving
Keep the back door and back window closed while driving. If the back door
or the back window is left open, the back door may hit nearby objects while
driving or luggage may be unexpectedly thrown out, causing an accident.
In addition, exhaust gases may enter the vehicle, causing death or a seri-
ous health hazard. Make sure to close the back door and back window
before driving.

■

Closing the power back window

●

The driver is responsible for power back window opening and closing
operations.
In order to prevent accidental operation, especially by a child, do not let a
child operate the power back window. It is possible for children and other
passengers to have body parts caught in the power back window. Also,
when riding with a child, it is recommended to use the window lock switch.
(

→P. 149)

●

Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.

●

When using the key and operating the power back window, operate the
power back window after checking to make sure that there is no possibility
of any passenger having any of their body parts caught in the power back
window. Also, do not let a child operate power back window by the key. It
is possible for children and other passengers to get caught in the power
back window.

●

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection
function.

●

The jam protection function may not work if something gets caught just
before the window fully closes.

155

SEQUOIA_OM_USA_OM0C011U

Moon roof

Opens the moon roof

The moon roof stops slightly before
the fully open position to reduce
wind noise.

Press the switch again to fully open
the moon roof.

Closes the moon roof

: Lightly press either way of the

moon roof switch to stop the moon
roof partway.

Tilts the moon roof up

Tilts the moon roof down

: Lightly press either way of the

moon roof switch to stop the moon
roof partway.

Use the overhead switches to open and close the moon roof and
tilt it up and down.

Opening and closing

Tilting up and down

156

SEQUOIA_OM_USA_OM0C011U

■

The moon roof can be operated when
The engine switch is in the “ON” position.

■

Operating the moon roof after turning the engine off
The moon roof can be operated for approximately 45 seconds even after the
engine switch is turned to the “ACC” or “LOCK” position. They cannot, how-
ever, be operated once either front door is opened.

■

Jam protection function
If an object is detected between the moon roof and the frame while the moon
roof is closing or tilting down, travel is stopped and the moon roof opens
slightly.

■

To reduce moon roof wind noise
When the moon roof is opened automatically, it will stop slightly before the
fully open position. Driving with the moon roof in this position can help reduce
wind noise.

■

Sunshade
The sunshade can be opened and closed manually. However, the sunshade
will open automatically when the moon roof is opened.

157

SEQUOIA_OM_USA_OM0C011U

■

When the moon roof does not close normally
Perform the following procedure:

●

If the moon roof closes but then re-opens slightly

Stop the vehicle.

Press and hold the “SLIDE” switch.

The moon roof will close, reopen and pause for approximately 10 sec-
onds.

Then it will close again, tilt up and stop.

Check to make sure that the moon roof is completely stopped and then
release the switch.

: If the switch is released at the incorrect time, the procedure will have to

be performed again from the beginning.

: If the switch is released after the above mentioned 10 seconds pause,

automatic operation will be disabled. In that case, press and hold the
“SLIDE” or “TILT” switch, and the moon roof will tilt up and stop. Check to
make sure that the moon roof is completely stopped and then release the
switch.

If the moon roof does not fully close even after performing the above proce-
dure correctly, have the vehicle inspected by your Toyota dealer.

■

Moon roof open reminder function
The buzzer sounds and a message is shown on the multi-information display
in the instrument cluster when the engine switch is turned off and the driver’s
door is opened with the moon roof open.

■

Door lock linked moon roof operation
The moon roof can be opened and closed using the key. (

→P. 104)

■

Customization that can be configured at Toyota dealer
Settings (e.g. key linked operation) can be changed.
(Customizable features

→P. 520)

158
