Toyota Sequoia (2018 year). Manual - part 9

SEQUOIA_OM_USA_OM0C011U

■

Folding down the third seats (manual type)

Pull the head restraint lock
release lever to fold the head
restraint.

Pull the lever to unlock the seatback and then fold the seatback
down.



From rear door side



From back door side

130

SEQUOIA_OM_USA_OM0C011U

■

Folding down the third seat (power type)

Press and hold the seatback folding switch until the seatback folds
down fully and the buzzer sounds.

The outside head restraints are folded automatically.

■

The power third seat can be folded down/returned when
Turn the engine switch to the “LOCK” position or the shift lever is in P, with the
rear door opened (from rear door side) or back door opened (from back door
side).



From rear door side



From back door side

131

SEQUOIA_OM_USA_OM0C011U

WARNING

■

When folding the rear seatbacks down
Observe the following precautions.
Failure to do so may result in death or serious injury.

●

Do not fold the seatbacks down while driving.

●

Stop the vehicle on level ground, set the parking brake and shift the shift
lever to P.

●

Do not allow anyone to sit on a folded seatback or in the luggage compart-
ment while driving.

●

Do not allow children to enter the luggage compartment.

■

Seat adjustment

●

To reduce the risk of sliding under the lap belt during a collision, do not
recline the seat more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply
restraint forces directly to the abdomen, or your neck may contact the
shoulder belt, increasing the risk of death or serious injury in the event of
an accident.
Adjustments should not be made while driving as the seat may unexpect-
edly move and cause the driver to lose control of the vehicle.

●

Take care when adjusting the seat position to ensure that other passen-
gers are not injured by the moving seat.

●

Do not put your hands under the seat or near the moving parts to avoid
injury.
Fingers or hands may become jammed in the seat mechanism.

●

Do not depress the second seat release pedal from the third seat while the
second seat is occupied.

■

After returning the rear seatback to the upright position
Observe the following precautions.
Failure to do so may result in death or serious injury.

●

Make sure the seatback is securely locked by pushing it forward and rear-
ward on the top.

●

Check that the seat belts are not twisted or caught in the seatback.

132

SEQUOIA_OM_USA_OM0C011U

NOTICE

■

Stowing the seat belts
The seat belts and the buckles must be stowed.

■

Second seatback board weight capacity (if equipped)
Do not place any object heavier than 220 lb. (100 kg) on the second seat-
back board.

■

Before sliding the second center seat to the most forward position
(vehicles with bench type second seat)
Ensure that the cup holder on the front console box is closed.

133

SEQUOIA_OM_USA_OM0C011U

Driving position memory

∗

The steering wheel will automatically adjusted to allow the driver to
enter and exit the vehicle easily.

When all of the following have
been performed, the steering
wheel will automatically
adjusted to a position that
allows driver to enter and exit
the vehicle easily.

• The shift lever has been

shifted to P.

• The engine switch has been

turned to the “ON” position.

• The driver’s seat belt has been unfastened.

When any of the following has been performed, the steering wheel
will automatically return to their original positions.

• The engine switch has been turned to the “ACC” or “ON” posi-

tion.

• The driver’s seat belt has been fastened.

∗

: If equipped

This feature automatically adjusts the front seats, steering wheel
and outside rear view mirrors to make entering and exiting the
vehicle easier or to suit your preferences.

Power easy access system

134

SEQUOIA_OM_USA_OM0C011U

Your preferred driving position (the position of the driver’s seat, steer-
ing wheel and outside rear view mirrors) can be recorded and recalled
by pressing a button.

Two different driving positions can be recorded into memory.

■

Recording procedure

Check that the shift lever is in P.

Turn the engine switch to “ON” position.

Adjust the driver’s seat, steering wheel, and outside rear view
mirrors to the desired positions.

While pressing the “SET”
button, or within 3 seconds
after the “SET” button is
pressed, press button “1” or
“2” until the buzzer sounds.

If the selected button has
already been preset, the previ-
ously recorded position will be
overwritten.

■

Recall procedure

Check that the shift lever is in P.

Turn the engine switch to “ON” position.

Press one of the buttons for
the driving position you want
to recall until the buzzer
sounds.

Driving position memory

135

SEQUOIA_OM_USA_OM0C011U

■

To stop the position recall operation part-way through
Perform any of the following:

●

Press the “SET” button.

●

Press button “1” or “2”.

●

Operate any of the seat adjustment switches (only cancels seat position
recall).

●

Operate the tilt and telescopic steering control switch (only cancels steering
wheel position recall).

■

Seat positions that can be memorized (

→P. 120)

The adjusted positions other than the position adjusted by lumbar support
switch can be recorded.

■

Operating the driving position memory after turning the engine switch
off
Recorded seat positions can be activated up to 180 seconds after the driver’s
door is opened and another 60 seconds after it is closed again.

■

In order to correctly use the driving position memory function
If a seat position is already in the furthest possible position and the seat is
operated in the same direction, the recorded position may be slightly different
when it is recalled.

136

SEQUOIA_OM_USA_OM0C011U

Each key can be registered to recall your preferred driving position.

■

Registering procedure

Record your driving position to button “1” or “2” before performing
the following:

Carry only the key you want to register, and then close the driver’s
door.
If 2 or more keys are in the vehicle, the driving position cannot be
recorded properly.

Check that the shift lever is in P.

Turn the engine switch to “ON” position.

Recall the driving position that you want to record.

While pressing the recalled
button, press and hold the
door lock switch (either lock
or unlock) until the buzzer
sounds.

If the button could not be regis-
tered, the buzzer sounds contin-
uously for approximately 3
seconds.

■

Recall procedure

Make sure that the doors are locked before recalling the driving
position. Carry the key that has been registered to the driving
position, and then unlock and open the driver’s door using the
wireless remote control.

The driving position will move to the recorded position (not including the
steering wheel).

If the driving position is in a position that has already been recorded, the
seat and outside rear view mirrors will not move.

Turn the engine switch to the “ACC” or “ON” position, or fasten a
seat belt.

The seat and steering wheel will move to the recorded position.

Memory recall function

137

SEQUOIA_OM_USA_OM0C011U

■

Cancelation procedure

Carry only the key you want to cancel and then close the driver’s
door.
If 2 or more keys are in the vehicle, the driving position cannot be
canceled properly.

Turn the engine switch to the “ON” position.

While pressing the “SET” button, press and hold the door lock
switch (either lock or unlock) until the buzzer sounds twice.

If the button could not be canceled, the buzzer sounds continuously for
approximately 3 seconds.

■

Recalling the driving position using the memory recall function
Different driving positions can be registered for each key. Therefore, the driv-
ing position that is recalled may be different depending on the key being car-
ried.

■

Customization
The unlock door settings of the memory recall function can be customized.
(Customizable features:

→P. 520)

WARNING

■

Seat adjustment caution
Take care during seat adjustment so that the seat does not strike the rear
passenger or squeeze your body against the steering wheel.

138

SEQUOIA_OM_USA_OM0C011U

Head restraints

Pull the head restraints up.

Down

Push the head restraint down while
pressing the lock release button.



Center seat

Pull the head restraints up.

Down

Push the head restraint down while
pressing the lock release button.



Outer seats

To use

Lift up the head restraint until it
locks.

To fold

Pull the head restraint lock release
lever to fold the head restraint.

Head restraints are provided for all seats.

Front and second seats

Lock release button

Third seats

Lock release button

139

SEQUOIA_OM_USA_OM0C011U

■

Removing the head restraints

■

Installing the head restraints

■

Adjusting the height of the head restraints (front and second outer
seats)

■

Adjusting the second and third center seat head restraint
Always raise the head restraint one level from the stowed position when
using.

Pull the head restraint up while pressing
the lock release button.

The head restraint of second center seat
(if equipped) and third outer seats cannot
be removed.

Align the head restraint with the installa-
tion holes and push it down to the lock
position.
Press and hold the lock release button
when lowering the head restraint.

Make sure that the head restraints are
adjusted so that the center of the head
restraint is closest to the top of your ears.

WARNING

■

Head restraint precautions
Observe the following precautions regarding the head restraints. Failure to
do so may result in death or serious injury.

●

Use the head restraints designed for each respective seat.

●

Adjust the head restraints to the correct position at all times.

●

After adjusting the head restraints, push down on them and make sure
they are locked in position.

●

Do not drive with the head restraints removed.

Lock release button

Lock release

button

140

SEQUOIA_OM_USA_OM0C011U

Steering wheel



Manual adjustment type

Hold the steering wheel and
push the lever down.

Adjust to the ideal position by
moving the steering wheel hori-
zontally and vertically.

After adjustment, pull the lever up
to secure the steering wheel.



Power adjustment type

Operating the switch moves the steering wheel in the following direc-
tions:

Down

Toward the driver

Away from the driver

The steering wheel can be adjusted to a comfortable position.

Adjustment procedure

141

SEQUOIA_OM_USA_OM0C011U

To sound the horn, press on or
close to the

mark.

■

The steering wheel can be adjusted when (power adjustment type)
The engine switch is in “ACC” or “ON” position.

■

Automatic adjustment of the steering position (if equipped)
A desired steering position can be entered to memory and recalled automati-
cally by the driving position memory system. (

→P. 133)

■

Power easy access system (vehicles with driving position memory)
The steering wheel move in accordance with engine switch position and the
driver’s seat belt condition. (

→P. 133)

■

After adjusting the steering wheel (manual adjustment type)
Make sure that the steering wheel is securely locked.
The horn may not sound if the steering wheel is not securely locked.

Horn

WARNING

■

Caution while driving
Do not adjust the steering wheel while driving.
Doing so may cause the driver to mishandle the vehicle and cause an acci-
dent, resulting in death or serious injury.

■

After adjusting the steering wheel (manual adjustment type)
Make sure that the steering wheel is securely locked.
Otherwise, the steering wheel may move suddenly, possibly causing an
accident, resulting in death or serious injury.

142

SEQUOIA_OM_USA_OM0C011U

Inside rear view mirror

The height of the rear view mirror can be adjusted to suit your driving
posture.

Adjust the height of the rear view
mirror by moving it up and down.



Manual anti-glare inside rear view mirror

Normal position

Anti-glare position

The rear view mirror’s position can be adjusted to enable suffi-
cient confirmation of the rear view.

Adjusting the height of rear view mirror

Anti-glare function

143

SEQUOIA_OM_USA_OM0C011U



Auto anti-glare inside rear view mirror

Responding to the level of brightness of the headlights of vehicles
behind, the reflected light is automatically reduced.

Changing automatic anti-glare function mode
On/off

When the automatic anti-glare function is in ON mode, the indicator illumi-
nates.
The function will set to ON mode each time the engine switch is turned to
the “ON” position.
Pressing the button turns the function to OFF mode. (The indicator also
turns off.)



Type A



Type B

Indicator

144
