PREPARATION  –  A750F AUTOMATIC TRANSMISSION

PP–19

PP

RECOMMENDED TOOLS

09040-00011

Hexagon Wrench Set

(09043-20060)

Socket Hexagon Wrench 6

(09043-20100)

Socket Hexagon Wrench 10

09082-00040

TOYOTA Electrical Tester

(09083-00150)

Test Lead Set

PP–20

PREPARATION  –  A750F AUTOMATIC TRANSMISSION

PP

EQUIPMENT

Feeler gauge

Cylinder gauge

Vernier calipers

Dial indicator

Micrometer

Straight edge

Torque wrench

Angle gauge

V-block

Dial indicator or dial indicator with magnetic base

PREPARATION  –  A750F AUTOMATIC TRANSMISSION

PP–21

PP

LUBRICANT

Item

Capacity

Classification

Automatic transmission fluid: (Dry fill)

10.4 litter (11 US qts, 9.2 lmp. qts)

ATF WS

Automatic transmission fluid: (Drain and refill)

3.0 litter (3.2 US qts, 2.6 lmp. qts)

ATF WS

PP–20

PREPARATION  –  CLUTCH

PP

PREPARATION

PREPARATION

CLUTCH

SST

09023-00101

Union Nut Wrench 10 mm

09301-00220

Clutch Guide Tool

09333-00013

Universal Joint Bearing Remover
& Replacer
