PREPARATION  –  A750E AUTOMATIC TRANSMISSION

PP–17

PP

EQUIPMENT

Feeler gauge

Cylinder gauge

Vernier calipers

Dial indicator

Micrometer

Straight edge

Torque wrench

Angle gauge

V-block

Dial indicator or dial indicator with magnetic base

PP–18

PREPARATION  –  A750E AUTOMATIC TRANSMISSION

PP

LUBRICANT

Item

Capacity

Classification

Automatic transmission fluid: (Dry fill)

10.4 liter (11 US qts, 9.2 lmp. qts)

ATF WS

Automatic transmission fluid: (Drain and refill)

3.0 liter (3.2 US qts, 2.6 lmp. qts)

ATF WS

PREPARATION  –  A750F AUTOMATIC TRANSMISSION

PP–17

PP

PREPARATION

PREPARATION

A750F AUTOMATIC TRANSMISSION

SST

09023-12701

Union Nut Wrench 17mm

09226-10010

Crankshaft Front & Rear Bearing
Replacer

09320-89010

Transfer Clutch Spring
Compressor

09350-30020

TOYOTA Automatic Transmission
Tool Set

(09350-07020)

Oil Pump Puller

(09350-07040)

No.2 Piston Spring Compressor

(09350-07050)

No.3 Piston Spring Compressor

(09350-07060)

No.1 Snap Ring Expander

(09350-07070)

No.2 Snap Ring Expander

(09350-07080)

Brake Reaction Sleeve Puller

(09350-07090)

Brake No.1 Piston Puller

PP–18

PREPARATION  –  A750F AUTOMATIC TRANSMISSION

PP

(09350-07110)

Oil Seal Replacer

(09351-32140)

Oil Seal Replacer

09350-32014

TOYOTA Automatic Transmission
Tool Set

(09351-32020)

Stator Stopper

09351-40010

Tool Set, TOYOTA Automatic
Transmission

09387-00070

First & Reverse Brake Wrench

09843-18040

Diagnosis Check Wire No.2

09992-00095

Automatic Transmission Oil
Pressure Gauge Set

(09992-00231)

Adaptor C

(09992-00271)

Gauge Assy
