DI06-31
CHANGED BY
EFFECTIVE DATE
AFFECTED VIN
COOLING SYSTEM
DI ENG SM - 2004.9
3. Remove the drain plug and seal in the cylinder block and
drain the coolant.
4. Replace the seal with new one and install the drain plug.
Installation Notice
5. Install the drain plug in bottom of radiator.
6. Add the coolant through the coolant reservoir.
7. Warm up the engine until the thermostat begins to open
and check if the coolant level is at “FULL” mark on the
reservoir. Add if necessary.
2. Loosen the drain plug in bottom of radiator and drain the
coolant.
1. Release the pressure from coolant reservoir by loosening
one notch of coolant reservoir cap, and then remove the
cap.
Draining and Adding of Coolant
Tightening torque
30 Nm
Notice
Scalding hot coolant and steam could be blown out
under pressure, which could cause serious injury.
Never remove the coolant reservoir cap when the
before the temperature goes down below 90°C.
Notice
Collect the drained coolant with a proper container.
Notice
• Keep the coolant mixture ratio of 50:50 (water : anti-
freezer).
• Add the coolant until the water flows out through
the overflow hose.
