SsangYong Rodius (2013 year). Service manual - part 187

03-8

▶ Rear 1st row (3 point + 2 point)

▶ Rear 2nd row (3 point + 2 point)

▶ Rear 3rd row (3 point + 2 point)

▶ Front Seat Belt (3 point)

2. COMPOSITIONS OF SEAT BELT

1) 11 Passengers

03-9

7410-01

2) 9 Passengers

▶ Front Seat Belt (3 point)

▶ Rear 1st row (3 point)

▶ Rear 2nd row (3 point)

▶ Rear 3rd row (3 point + 2 point)

03-10

3) 7 Passengers

▶ Front Seat Belt (3 point)

▶ Rear 2nd row (3 point)

▶ Rear 1st row (3 point)

03-11

7410-01

3. SEAT LAYOUT

1) Layout - 11 Passengers

Front seat : Move 36 mm from the far end to the front

Rear 1st seat : Movable

Rear 2nd seat: Movable

Rear 3rd seat : Fixed

·
·
·
·

Passenger's seat

Second row seat(right)

Third row seat(right)

Driver's seat

Second row seat(left)

Third row seat(left)

Center jump seat

Fourth row seats
