SsangYong Actyon Sports II. Service manual - part 129
02-15
3170-01
2) Sectional Diagram
3) Gear Ratio
Transmission housing
Extension housing
Main shaft
Counter shaft
Main drive gear
Intermediate plate
Gear
Teeth
Final gear ratio
Input
Output
1st
13 38
4.489
2nd
23 35
2.337
3rd
33 29
1.350
4th
28 43
1.000
5th
47 24
0.784
6th
52 23
0.679
R
13 36
4.253
Idle: 25
