Skoda Karoq (2019 year). Instruction - part 8





Switches Infotainment on/off



 Overview of Infotainment menu

» page 130



 - Display of the main screen “HOME”

» page 131

Volume up
Volume down
Touch screen

» page 126

Description – Infotainment Amundsen

Fig. 168  Infotainment Amundsen

Left control dial for switching Infotainment on and off; volume adjustment
Control dial for calls and confirmations



 - Radio menu

» page 146



 - Media menu

» page 149



 - Telephone menu

» page 160



 - Voice control

» page 132



 - Navigation menu

» page 179



 - SmartLink menu

» page 174



 - Vehicle system settings

» page 201



 Overview of Infotainment menu

» page 130

Touch screen

» page 126

1

2

3

1

2
3
4
5
6
7
8
9

Description – Infotainment Bolero

Fig. 169  Infotainment Bolero

Left control dial for switching Infotainment on and off; volume adjustment
Control dial for calls and confirmations



 - Radio menu

» page 146



 - Media menu

» page 149



 - Telephone menu

» page 160



 - Voice control

» page 132



 - Infotainment settings

» page 135



 - SmartLink menu

» page 174



 - Vehicle system settings

» page 201



 Overview of Infotainment menu

» page 130

Touch screen

» page 126

1

2
3
4
5
6
7
8
9

125

Introductory information

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Description – Infotainment Swing

Fig. 170  Infotainment Swing

Left control dial for switching Infotainment on and off; volume adjustment
Control dial for calls and confirmations



 - Radio menu

» page 146



 - Media menu

» page 149

Depending on equipment fitted:



 - Telephone menu

» page 160



 Muting



 - Infotainment settings

» page 143

Depending on equipment fitted:



 - Menu SmartLink (Press) / turn on / off the voice control function

SmartLink (hold)

» page 174



 - Sound settings

» page 143



 - Vehicle system settings

» page 201

Touch screen

» page 126

SD card slot

» page 152

1

2
3

4
5

6
7
8

External module

applies to Infotainment Amundsen and Columbus.

Fig. 171

Example of an external module

Depending on the vehicle configuration and Infotainment type, all the follow-

ing elements must not be included in the external module.
The external module is located in the storage compartment on the front pas-

senger side

» Fig. 171

.

SD1 card slot
SD2 card slot

 - CD / DVD eject button

CD / DVD slot
SIM card slot

Touch screen

The Infotainment can be operated by lightly touching the screen with your

fingers.
The brightness level of the screen can be set by

» page 135

 or

» page 143

.

To protect the screen, a suitable protective film for touch screens can be used.
The screen can be cleaned with a soft cloth and pure spirit if necessary.

1

2
3
4
5

126

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infotainment operation

Infotainment operation

Screen areas

Fig. 172

Screen areas

Description of the display

» Fig. 172

Status line with time and outdoor temperature data and other information
Information and the operation of the current menu
Function surfaces of the current menu

Operation principles

Fig. 173

Screen display

Description of the display

» Fig. 173

Identification of the current menu
Return to the higher-level menu
Scroll symbol – moving in the menu is possible by moving fingers up or

down on the scroll symbol

A
B
C

A
B
C

Menu item with “Checkbox”

 - Function is switched on

 - Function is switched off

 Opens a sub-menu of the menu item with a “pop-up window”

Function surfaces

The screen areas which confirm a function or a menu are called “function sur-

faces”.

White text - the surface is active and thus selectable

Grey text - the surface is inactive and thus not selectable

Green frame - currently selected surface

Selecting menu/menu item/function

Drag your finger over the screen in the required direction.

By moving your finger over the slider

Turning the knob  (not applicable to Infotainment Columbus).

Confirming menu/menu item/function

By tapping on the function surface.

Press the wheel  (not applicable to Infotainment Columbus).

Returning to higher-level menu

By tapping the function surface .

By tapping on the screen outside of the “pop-up window”.

By pressing the corresponding button next to the screen (e.g. in the Media

menu, by pressing the sensor field/the



 button) (not applicable to Info-

tainment Columbus).

Select the menu item / function value

 - Selected menu item/function value

 - Deselected menu item/function value

Set value

By tapping the function surface  or  the bottom of the screen.

By touching or moving your finger over the scale.

Turning the knob  (not applicable to Infotainment Columbus).

Note

Depending on the equipment, the Infotainment can also be operated by means

of the buttons on the multifunction steering wheel. Further information

» page 52

.

D

E

127

Infotainment operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Operating the menus

Fig. 174  Operating the menus

Operating the menus

» Fig. 174

Browse the menu- List entries
Enlargement/reduction of the menu window (applies to the infotainment

Columbus)
Expand/reduce the menu window (applies to Infotainment Amundsen)
Open / close the menu window
Close the menu window

Alphanumeric with keyboard

Fig. 175

Example of the keyboard display

The alphanumeric keypad is used to enter for letters, numbers and characters.

A
B

C
D

Description of the alphanumeric keyboard

» Fig. 175

Input line
Context-dependent:



 - Toggle upper case to lower case and vice versa



 - Switch to special characters



 - Switch to numbers

Context-dependent:



 - Switch to numbers



 - Switch to Latin letters



 - Switch to Cyrillic letters

- Display of visited entries (the number of visited entries is displayed in the

function surface)
Erase the entered characters
By holding the variants of each type are displayed.

Switch between keyboards with specific characters of the selected

languages

» page 136

 or

» page 143

Enters a blank
Move the cursor within the input line to the left
Move the cursor within the input line to the right
Confirmation of the entered number

Search

While entering characters, a search is made for corresponding entries.
The entry such as a telephone contact to be searched for must be entered

along with the special characters (diacritics).
By tapping the function surface  a list of matching entries opens.

A
B

C

  



128

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Gesture control

Only valid for Infotainment Columbus.

Fig. 176

Example of a menu with

gesture control

Some menus of Infotainment Columbus can be operated by means of hand

gestures by slowly moving the hand back and forth approximately 8 cm above

the Infotainment screen.
The menus with gesture control feature the symbol  in the lower right-hand

corner

» Fig. 176

.

Switching the function on / off

The gesture control function is switched on at the factory.

To switch the function on/off, tap the sensor field



 and then the function

surface  → Screen → Hand gesture .

Acoustic confirmation of gesture

When the function is switched on, Infotainment indicates that a gesture has

been recognised by means of an acoustic signal.

To activate/deactivate the acoustic confirmation of a recognised gesture,

tap the sensor field



 and then the function surface  → Screen → Audible

hand gesture feedback.

Visual confirmation of the gesture

When the function is switched on and a gesture has been recognised, Infotain-

ment shows an animation with the bottom bar moving in the direction of the

hand movement.

To activate/deactivate the visual confirmation of a recognised gesture, tap

the sensor field



 and then the function surface  → Screen → Visual hand

gesture feedback.

Switching Infotainment on/off

Only applies to Infotainment Columbus

To switch on Infotainment, press

.

To switch off Infotainment, hold

.

Applies to Infotainment Amundsen, Bolero, Swing

To power on/off Infotainment, press

.

Automatic switch-on of Infotainment

If Infotainment was not turned off with

 before the ignition was turned off,

it will automatically switch on when the ignition is switched on.

Automatic switch-off of Infotainment

If the vehicle key is pulled out of the ignition lock while Infotainment is switch-

ed on, Infotainment will switch off automatically.
If the vehicle is fitted with the starter button, Infotainment will switch off au-

tomatically after the engine is switched off and the door is opened.
With the ignition off, Infotainment will automatically turn off after about 30

minutes.
Infotainment turns off automatically under certain circumstances. Infotain-

ment informs of this via a text message on the Infotainment screen.

Restart Infotainment

If Infotainment does not respond (if it “freezes”) This can be restarted by hold-

ing

 for longer than 10 s.

Show time and date on the screen

Standby mode

With the ignition off and infotainment (standbyMode), it is possible to display

the time and date in the Infotainment screen.
Applies to Infotainment Columbus, Amundsen, Bolero

To switch the time and date display on/off, press the



 sensor field and

then tap the function surface  → Screen Show clock in standby mode.

The display mode can be changed by finger motion across the screen side-

ways.
Applies to Infotainment Swing

To switch the time and date display on/off, press the



 button, then tap

the function surface Screen → Show clock in standby mode.

129

Infotainment operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

"Screen off" mode

With the ignition on and functions Switch off screen (in 10 seconds) and Display clock

when screen is off

» page 135

 enabled, it is possible to display the time and date

when the Infotainment screen is switched off.
The display type depends on the display mode selected in standby mode (does

not apply to the Infotainment Swing).

Adjusting the volume

Every change in volume is displayed on the screen.

Only applies to Infotainment Columbus

To increase the volume, tap the function surface

.

To decrease the volume, tap the function surface

.

To activate/deactivate the mute setting, tap the sensor field

.

Applies to Infotainment Amundsen, Bolero, Swing

To increase the volume, turn the controller

 clockwise.

To reduce volume, turn the controller

 anticlockwise.

To mute, turn the controller

 to the left to 0.

or: To activate/deactivate the mute setting, press the button



 (applies

to Infotainment Swing).

The following symbol appears in the display when the sound is muted .
If, at the time of muting, sound is being played from a source in the Media

menu, then the playback is stopped.

CAUTION

High volumes can cause sound resonance in the vehicle.

When changing or connecting an audio source, this may cause sudden

changes in volume. Reduce the volume before changing or connecting an au-

dio source.

Infotainment menus

Applies to Infotainment Columbus, Amundsen, Bolero.

Fig. 177

Overview of Infotainment me-

nus: Grid display

Fig. 178

Overview of Infotainment me-

nus: List

To display the overview of Infotainment menus, press the



 sensor field.

To set the display mode, press the button



 sensor field and then tap the

function surface  → Screen → Menu:.

Select the Grid display

» Fig. 177

 or Horizont. Display

» Fig. 178

 option.

Overview of Infotainment menus

Radio menu

» page 146

Media menu

» page 149

“ŠKODA Connect” Online Services

» page 13

SmartLink menu

» page 174

With a connection established to an external device,  the actual connec-

tion is shown instead of a symbol

 Android Auto

» page 175

 Apple CarPlay

» page 176

 MirrorLink®

» page 177

Telephone menu

» page 160

130

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Vehicle system settings

» page 201

Navigation menu

» page 179

 (Applies to Infotainment Columbus, Amund-

sen)
List of traffic reports (TMC) (applies to Infotainment Columbus, Amund-

sen)

» page 199

Media Command menu (applies to Infotainment Columbus, Amundsen)

» page 158

Images menu

» page 155

- Sound settings

» page 135

Air conditioning menu

» page 118

Infotainment settings

» page 135

Main screen “HOME”

Only valid for Infotainment Columbus.

Fig. 179

HOME main screen

To display the information, tap the



 sensor field.

The “HOME” main screen contains three windows.
In the left window

» Fig. 179

 the navigation map is always displayed. By tapping

the screen within this window, the Navigation main menu is displayed.
The contents of the window to the right can be changed. By holding the func-

tion surface

A

, the list of selectable menus is displayed.

By tapping the function surface

A

 or by double-finger tapping on the screen

within each window, the appropriate main menu is displayed.
If there are other pages in the window, then the associated symbols are dis-

played in area

B

. By moving your finger across the screen within each win-

dow, it is possible to display these pages.

Configuration wizard

The Configuration wizard is automatically displayed if there are at least two

non-selected menu items after turning on Infotainment, or if a new user ac-

count in personalisation is selected.

For instruction display in Infotainment Columbus, Amundsen and Bolero, tap the



 sensor field and then tap on the function surface  → Configuration wizard.

For instruction displayin Infotainment Swing, press the



 button, then tap the

function surface Configuration wizard.

The Configuration wizard allows you to set the following menu items in se-

quence.

Identification of the personalisation user account

» page 57

Time and date format
Storing the radio station with the strongest reception signal at present
Pairing and connecting a telephone to Infotainment
Home Address provided (valid for Infotainment Columbus, Amundsen)
Setting “ŠKODA Connect” online services

The selected menu item is marked with the

 symbol.

Operating using an application in the external device

Some Infotainment functions can be operated using an application in the sup-

ported external device.
For the complete functionality of the application, data transmission from ex-

ternal devices must be activated and, if necessary, operation of the Infotain-

ment via the application must be approved.

Applies to Infotainment Columbus, Amundsen, Bolero

Activate data transfer in Infotainment. To do so, tap the



 sensor field and

then the function surface  → Mobile device data transfer → Activate data transfer

for ŠKODA Apps.

Release Infotainment operation using the application. To do so, tap the



sensor field and then the function surface  Tap→ Mobile device data transfer →

Operation via apps: → Confirm/Allow .

Connect Infotainment to an external device via WLAN

» page 172

.

In the external device, launch an application for Infotainment operation (e.g.

ŠKODA Media Command).

131

Infotainment operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Applies to Infotainment Swing

Activate data transfer in Infotainment. Press the



 button and then tap on

the function surface Activate data transfer for ŠKODA apps.

Note

The description of Infotainment operation ŠKODA Media Command is part of

the application.

Voice control

Introduction to the subject

Applies to Infotainment Columbus, Amundsen, Bolero.

The navigation, telephone, radio and media menu can be operated by voice

commands.
The voice control system can be used either by the driver or by the front pas-

senger.

Function requirements for voice control

Infotainment is switched on.
There will be no telephone call using a telephone connected to Infotain-

ment.
The parking aid is not active.

Requirements for optimum voice command recognition

The voice commands must only be issued when the

 symbol is displayed on

the Infotainment screen and the input tone has completely faded.

Speak at your normal volume without intonation and long breaks.

Avoid poor pronunciation.

Close the doors and window in order to avoid disturbing environmental influ-

ences on the function of the voice control.

You are recommended to speak louder at higher speeds, so that the sound of

your voice is not drowned out by the increased ambient noise.

During voice control, limit additional noise in the vehicle, e.g. passengers talk-

ing at the same time.

WARNING

The emergency number should be dialled manually. Your voice commands

may not be recognized in such situations. The telephone connection may

not be established or the connection may take too much time to complete.

CAUTION

The messages are generated by Infotainment. Flawless clarity (e.g. road or

city name) cannot always be guaranteed.

For some Infotainment languages, there is no voice control available. Info-

tainment indicates this fact through a text message that is displayed after set-

ting the device language screen.

Note

During voice control, no nav. announcements and traffic announcements are

played.

Voice control on / off

Fig. 180

Voice control: Main menu

Switching on

Press the button  on the multifunction steering wheel or the



 sensor

field on the Infotainment (does not apply to Infotainment Columbus).

The main menu is displayed

» Fig. 180

.

Switching off

Press the button twice  on the multifunction steering wheel or the



sensor field on the Infotainment twice (does not apply to Infotainment Co-

lumbus).

or: Issue the voice command “End voice control”.

132

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Operation principle

Fig. 181

Example of screen display

In the voice control main menu

» Fig. 180

 on page 132 There are basic voice

commands for the individual menus.
Other voice commands are displayed by tapping the respective functional area

or issuing the name of the respective command (e.g. Navigation). The screen

shows the following

» Fig. 181

.

Context-dependent:

 The system is waiting for a voice command

 The system recognises a voice command

 The system plays a message

 Voice command entry was stopped

Available list entries
Possible voice commands
Display other possible voice commands

Voice commands that can be issued, are indicated in “quotation marks”.

Note

The display of the voice control symbols

A



» Fig. 181

 are dependent of the

equipment fitted also on the display of the instrument cluster.

A

B
C

Voice commands

Enter

The voice command must only be issued when the symbol

 is displayed in

the Infotainment screen and the input tone has completely faded. The input

tone can be switched on / off. To do so, tap the



 sensor field and then the

function surface  → Voice control.
It is not necessary to wait for the end of message playback when Infotainment

is playing a message. The Infotainment message can be acknowledged by tap-

ping the



 sensor field (does not apply to Infotainment Columbus) or press-

ing the button  on the multifunction steering wheel. Then a voice command

can be issued. The voice control is hereby much faster.

Stop

This allows for more time for input of the voice command (e.g. in the list of

visited contacts).
The process for the voice command input can be stopped by moving a finger

up/down across the screen or by turning the controller  (not applicable to In-

fotainment Columbus).
When stopping, the symbol changes from

 .

Restore

The procedure for voice command input can be restarted in one of the follow-

ing ways.

By tapping the function surface .

By tapping the



 sensor field on the Infotainment (does not apply to Info-

tainment Columbus).

By pressing the key  on the multifunction steering wheel.

Not recognising a voice command

If a voice command is not detected three times in succession by Infotainment,

then the voice control is stopped.

Correction of a voice command input

A voice command can be corrected, modified or re-entered by tapping the



 sensor field (does not apply to Infotainment Columbus) or pressing the

button  on the multifunction steering wheel. However, this is only possible

as long as the symbol

 appears on the screen.

You do not have to wait until the voice command is recognised by Infotain-

ment.

133

Infotainment operation

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Voice commands can be used during voice control

Voice command

Operation

Back

Return to the previous menu

Help

reproducing and displaying possible voice com-

mands

Voice commands that can be used while browsing the list entries

Voice command

Operation

Next page

Browse menu / list / directory

Previous page
First page
Last page

Additional Information

Navigation - applies to Infotainment Columbus

If the set Infotainment language matches the language of currently selected

country when entering the destination, then the destination address can be

entered in one step.
The voice command “Navigate” can be issued and straight away, the city,

street and street number (if it is included in the navigation data) Interest (POI)

or a contact with the previously stored address.

Navigation - applies to Infotainment Amundsen

To the destination, you are first required to issue the command“enter ad-

dress” and then follow Infotainment instructions.
It is not necessary to spell city and street names if the entered destination is

located in a country that has no voice control available for the language.

Online POI search – applies to Infotainment Columbus, Amundsen

When “Infotainment Online”

» page 18

 services are activated, a POI search can

also be carried out online by issuing the voice command “Find online POI”.

Radio

In order for a radio station can be selected using voice command, the station

must be stored in the list of available stations

» page 147

 or in the preset list

» page 147

.

Updating the Infotainment software

Fig. 182

Available software updates on

the ŠKODA website

The software update ensures optimum operation of Infotainment (e.g. Com-

patibility with new telephones).
Information on Infotainment compatibility can be found on the following

ŠKODA Internet pages. This takes place by reading the QR code

» Fig. 182

 or

after typing the following address into the web browser.

http://go.skoda.eu/updateportal

Applies to Infotainment Columbus, Amundsen, Bolero

To determine the software version, tap the



 sensor field and then the

function surface  → System information.

To start the software update, tap the



 sensor field and then tap the

function surface  → System information → Update software.

Applies to Infotainment Swing

To determine the software version, press the



 button, then tap on the

system information function surface.

To start the software update, press the



 button, then tap on the system

information → update software function surface.

134

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Infotainment settings - Columbus, Amundsen, Bolero

Infotainment system settings

sound settings

Tap the



 sensor field and then the function surface  .

Volume - Volume settings

Radio announcements - Volume adjustment of traffic announcements (TP)

Navigation announcements - Volume adjustment of navigation announcements

(does not apply to infotainment Bolero)

Voice control - volume setting for voice output

Maximum switch-on volume - Setting the maximum volume when switching on

Infotainment

Speed-dependent Volume adjustment - Increases the volume as speed increases

Bluetooth audio: - Volume setting of the device connected via Bluetooth

®

 au-

dio profile

Quiet - Low volume

Medium - Medium volume

Loud - High volume

Entertainment fading while parking – Lowers the audio volume (e.g. radio vol-

ume) with activated parking aid

Entertainment fading (nav. announcements) - Lowers the audio volume (e.g. radio

volume) in the event of a navigation announcement

Bass - Mid - Treble - Setting the equalizer

Balance - Fader - Sets the balance between left and right, front and rear

CANTON Equaliser - Setting the equalizer

Individual- Adjustment of treble, mid and bass

Profile - Setting of the profile (e.g. RockClassical and so on.)

CANTON Optimisation -Setting the optimum room sound perception

All areas - Setting optimised for the whole vehicle interior

Front - Optimised setting for the front seats

Driver - Optimised setting for the driver

CANTON surround - Setting the surround sound levels (“-9 ”Stereo / “+9”full

surround)

Subwoofer - Subwoofer volume settings

Sound focus -Setting the optimum room sound perception

All areas - Setting optimised for the whole vehicle interior

Driver - Optimised setting for the driver

Touchscreen tone - Switch on/off audible tone when touching the screen

No navigation sound during call - Switching on / off the nav. announcements dur-

ing a telephone conversation (does not apply to Infotainment Bolero)

Screen settings

Tap the



 sensor field and then the function surface  Tap→ Screen.

Menu: Setting the Infotainment menu display

Horizont. Display - Horizontal display

» Fig. 178

 on page 130

Grid display - Grid display

» Fig. 177

 on page 130

Switch off screen (in 10 seconds) - Enable/disable the automatic power off func-

tion

Display clock when screen is off - Time and date display when the screen is

switched off

Brightness: - Adjusts the brightness of the screen

Touchscreen tone - Switch on/off audible tone when touching the screen

Menu button tone - Turn on / off the acoustic signal by pressing a button next to

the screen

Hand gesture - Enable/disable the gesture control using hand movements via

the Infotainment screen (applies to Infotainment Columbus)

Visual hand gesture feedback - Enable/disable the animation when a gesture is

recognised (applies to Infotainment Columbus)

Audible hand gesture feedback - Enable/disable acoustic signal when a gesture is

recognised (applies to Infotainment Columbus)

Animation when finger near screen - Turn the proximity sensors on/off (When the

function is on, e.g.Navigation will be shown in the main menu when moving a

finger towards the bottom bar with the functional surfaces on the screen)

Show clock in standby mode - Time and date displayed on the screen when the

ignition is switched on and Infotainment is switched off

Time and date settings

Tap the



 sensor field and then the function surface  → Time and date.

Clock time source: Time source settings: manual/GPS (applies to Infotainment

Columbus, Amundsen)

Time: - Time settings

Summer (DST) - Switches summer time on/off

Automatic summer time - Switches the automatic switch to summer time on/off

Time zone: - Select the time zone

Time format: - Set the time format

135

Infotainment settings - Columbus, Amundsen, Bolero

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Date: - Date settings

Date format: - Set the date format

Setting the Infotainment language

Tap the



 sensor field and then the function surface  → Language.

Select the Infotainment language.

In some languages, after selecting the function surfaceFemale and Male are dis-

played for the choice of voice prompts for Infotainment.

Note

When a language is selected which does not support voice control, Infotain-

ment will indicate with a message on the screen.

The messages are generated by Infotainment. Flawless clarity (e.g. road or

city name) cannot always be guaranteed.

Additional keypad language settings

Tap the



 sensor field and then the function surface  → Additional keypad

languages.

In this menu, a keyboard language set can be added to allow the entering of

characters other than those in the currently selected language.

Unit settings

Tap the



 sensor field and then the function surface  Tap on→ Units .

Distance: - Distance units

Speed: - Speed units

Temperature: - Temperature units

Volume: - Volume units

Fuel consumption: - Consumption units

Pressure: - Pressure units for tyre pressure

Settings for data transfer

Activated data transfer enables data transfer between the Infotainment sys-

tem and the external device or the operation of some Infotainment functions

using the applications of the external device (e.g. ŠKODA Media Command).

Tap the



 sensor field and then the function surface  → Mobile device data

transfer.

Activate data transfer for ŠKODA apps- Turning data transfer on and off

Use apps to operate: - Setting Infotainment operation via the applications of the

external device (applies to Infotainment Columbus, Amundsen)

Deactivate - Deactivate Infotainment operation via an external device

Confirm - Infotainment operation with required confirmation

Allow - Infotainment operation without required confirmation

Voice control settings

Tap the



 sensor field and then the function surface  → Voice control.

Example commands (Infotainment system) - Turn on/off display of the menu con-

taining voice commands in the Infotainment screen when voice control is ac-

tivated

Example commands (instrument cluster) - Turn on/off display of the menu contain-

ing basic voice commands when voice control is activated

Voice control session start tone - Switch on/off the audible signal when turning on

the voice control

Voice control session end tone - Switch on/off the audible signal when voice con-

trol ends

Input tone in voice dialogue - Switch on/off the audible signal for the voice input

End tone in voice dialogue - Switch on/off the audible after the voice input

Safe removal of the external device

Tap the



 sensor field and then the function surface  Remove safely: and

select the external device to be removed.

Reset to factory settings

Tap the



 sensor field and then the function surface  → Factory settings.

In this menu, all or only chosen settings can be restored.

Bluetooth

®

Settings

Tap the



 sensor field and then the function surface  → Bluetooth.

136

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Bluetooth - Switch on/off Bluetooth

®

 function

Visibility: Switch the visibility of the Bluetooth

®

 device for other Bluetooth

®

 de-

vices on/off

Name: - Changing the name of the Bluetooth

®

device

Paired devices - Display the list of coupled Bluetooth

®

Devices

Find devices - Searches for available Bluetooth

®

 devices

Bluetooth audio (A2DP/AVRCP) - Turn on/off the ability to connect a Bluetooth

®

audio device (e.g. MP3 player, tablet etc...)

Wireless settings

Applies to Infotainment Columbus, Amundsen.

Tap the



 sensor field and then the function surface  → WLAN.

WLAN - List of available hotspots of external devices

WLAN - Turn on / off Infotainment wireless

WPS Quick Connect (WPS button) - Establishing a secure connection to the hot-

spot of the external device using WPS (applies to Infotainment Amundsen)

Manual settings - Setting the parameters for search and connection to the

hotspot of the external device

Network name - Enter the Hotspot name

Network key - Setting the access password

Security level: Security setting (WPA2 always set)

Connect - Connection establishment

Find - Search / Restore the list of available hotspots

Mobile hotspot - Setting Infotainment hotspot (in the functional surface the

symbol is  displayed with the number of connected external devices)

Mobile hotspot - Turn on / off Infotainment hotspot

WPS quick connection (WPS button) - Establishing a secure connection to the In-

fotainment hotspot via WPS (applies to Amundsen)

Hotspot (WLAN) settings - Setting the parameters for the connection to Info-

tainment hotspot

Security level: Security setting (WPA2 always set)

Network key - Input of the access password

SSID: ... - Name of the infotainment Hotspots

Do not send network name (SSID) -Turn Infotainment hotspot visibility on/off

Store - Storage of Infotainment hotspot parameters

Network settings

Applies to the infotainment Columbus with seated in the external module SIM

card as well as for the Infotainment Amundsen with the connected Carstick-

Device.

Tap the



 sensor field and then the function surface  → Network.

Network settings - Sets the data connection from the associated telephone

service provider (APN settings)

Access point name: ... - Setting of the access point name

User name: ... - Setting of the user name

Password: ... - Password setting

Authentication: Sets the check type

Normal - Without verification

Secure - Verification required

Reset Access Point (APN) - Delete the parameters for the network setting

Store - Storage of the parameters for the network setting

Network provider: ... - Selection of the network provider (the menu item is visi-

ble when the SIM card is inserted in the external module or CarStick device)

Data roaming - Enable / disable the use of data roaming connection

Current connection details - Display of information on data downloaded (by tap-

ping the function surface Reset the data information is deleted)

Data connection: Usage settings for the data connection (Internet connection)

of the SIM card inserted in the external module or CarStick device

Off - Use of the data connection is not possible

Ask - Use of the data connection is only possible after it has been confirmed

On - Use of the data connection is possible at any time

ŠKODA Connect Online Services settings

Tap the



 sensor field and then the function surface  → ŠKODA Connect

(Online Services).

Services Management - Information on licensing of the respective online serv-

ices and the option to switch them on/off

registration - Enter the registration PIN code for online services (in the user

profile on the website ŠKODA Connect Portal receive)

System information

Tap the



 sensor field and then the function surface  → System information.

137

Infotainment settings - Columbus, Amundsen, Bolero

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The information available will be displayed, for example regarding the Infotain-

ment hardware and software, the Bluetooth

®

 software version, the navigation

database version, etc.

To Update the Infotainment software, Bluetooth

®

 software version, etc., tap

on the function surface Update software.

To Update the navigation database and the POI categories created in the

user profile on the ŠKODA Connect Portal website, tap on the function sur-

face Online update.

The information on available software updates is obtained from a ŠKODA Part-

ner or from the following ŠKODA Internet pages.

http://go.skoda.eu/updateportal

Radio menu settings

Settings for all broadcasting ranges

Tap on the Radio main menu function  .

Sound - Sound settings

Scan - Automatic playback of short portions of all available stations in the

current frequency range

Arrow buttons: - Setting the function of the function surfaces  

Preset list - Change between stations stored under the preset buttons

Station list - Change between all available stations of the selected broadcast-

ing range

Traffic programme (TP) - Switches TP traffic programme on/off

Delete presets - Deletes station buttons

Station logos - manual management of station logos

Radio text - Switching the text display radio (FM and DAB) on and off

Advanced settings - further settings that are different depending on the selec-

ted broadcasting range(FM and DAB)

Advanced settings (FM)

Select the FM band in the Radio main menu and tap on the function surface

 → Advanced settings.

Autostore station logos- Automatic storage of the station logos

Region for station logo: - Setting the region for station logo

Automatic frequency control (AF) - Activates/deactivates the search for alterna-

tive frequencies of the station currently being played

Radio Data System (RDS) - enable/disable RDS function (receiving additional in-

formation from the station)

RDS Regional: Switch on/off automatic tracking of related regional stations

Fixed - Maintains the selected regional station continuously. When the sig-

nal is lost, another station must be set manually.

Automatic - Auto-selects the station with the best reception at the moment.

If you lose reception in the given the region, Infotainment will automatically

set another available region.

Advanced settings (DAB)

In the Radio main menu, select the DAB range and tap on the function sur-

face  → Advanced settings.

Autostore station logos- Automatic storage of the station logos

DAB traffic announcements - Switch on/off DAB traffic announcements

Other DAB announcements - Switch on/off other announcements (e.g., warnings,

regional weather, sports reports, financial news)

DAB - DAB station tracking - Activate/deactivate automatic DAB station tracking

on another frequency or in other station groups

Automatic DAB - FM switching - Switch on/off auto-switching from DAB to the

FM broadcasting range if the DAB signal is lost

Switch to a similar station - Activate/deactivate automatic switching to another

station with similar content in the event of signal loss (applies to Infotain-

ment Columbus)

L-band - Enable / disable the availability of L-band

Automatic change from DAB to FM

If DAB reception is poor, the device tries to find an FM station.
The station name is followed by () while the station is being received on the

FM band. When the corresponding DAB station is can be received again, the

system automatically switches from FM to DAB.
If a DAB station is also not available in the FM band due to poor reception, In-

fotainment will be switched to mute.

L-band

For the DAB radio reception in different countries, different broadcasting

ranges are used. In some countries the DAB radio reception is only possible in

the so called L-band.

138

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If no L-band DAB radio reception is possible in the country then we recom-

mend turning off the L-band. The channel scan is therefore faster.

Media menu settings

Tap on the function surface in the Media main menu  .

Sound - sound settings

Manage Jukebox - Administration (record / delete) supported files (audio / vid-

eo) in Infotainment internal memory (applies to Infotainment Columbus)

Mix/repeat including subfolders - Switching the title display including subfolders

Bluetooth - Settings for the Bluetooth

®

 function

WLAN - Wi-Fi settings (applies to Infotainment Columbus, Amundsen)

Video (DVD) settings - Setting the parameters of the DVD video (applies to Info-

tainment Columbus)

Remove safely: - Safe removal of the external device

Traffic programme (TP) - Switches traffic programme on/off

Image menu settings

In the images main menu, tap on the function surface  .

Image view: - Image view settings

Full - Display the maximum image size while retaining the aspect ratio

Automatic - Full screen display

Display time: - Set the display time for the slideshow

Repeat slideshow - Switching on/off the slideshow repeat

Video DVD menu settings

Only valid for Infotainment Columbus.

In the Video DVD main menu, tap on the function surface  .

Depending on the DVD some of the following menu items are displayed.

Format: - Set the screen width/height ratio

Audio channel: - Select the audio channel

Subtitles: - Subtitle selection

Enter/change PIN for parental settings - Management of the PIN code for parental

control

Parental control: - Parental control settings

Settings

In the Telephone main menu, tap on the function surface  .

Hands-free - Switch a call to the telephone/back to Infotainment (the menu

item is displayed during a call)

Select mobile phone - Search for available telephones/list of paired tele-

phones/select telephone

Bluetooth - Bluetooth

®

 settings

» page 136

User profile - User profile settings

Manage favourites - Set the function surfaces for your favourite contacts

Mailbox number: - Enter the mailbox phone number

Network selection - Select the telephone service provider of the SIM card in-

serted in the external module (valid for Infotainment Columbus with the

SIM card slot in the external module)

Priority assignment: - Select the phone service priority of the SIM card inser-

ted in the external module (applies to Infotainment Columbus with the SIM

card slot in the external module)

Automatic - Depending on the telephone service provider

Telephone call - telephone calls are preferred

Data transfer - A data connection is preferred

Sort by: - Arrangement of telephone contact list

Surname - Sort by contact name

1st name - Sort by contact's first name

Profile name: Rename the profile of the SIM card inserted in the external

module (applies to Infotainment Columbus with the SIM card slot in the ex-

ternal module)

Import contacts: - Import telephone contacts

Select device contacts - Open the coupled Telephones menu (applies to Info-

tainment Columbus with the SIM card slot in the external module - if the

SIM card is inserted in the external module)

Select ring tone - Select the ring tone (depending on the connected phone)

Reminder: Remember your mobile - Turn on/off the warning mode before forget-

ting the phone in the vehicle (if the phone was connected to the device)

Show pictures for contacts - Switch on/off the display of the image assigned to

the contact

Conference call - Activates/deactivates conference calls

139

Infotainment settings - Columbus, Amundsen, Bolero

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Call settings: - Setting the phone functions of the SIM card inserted in the ex-

ternal module during a call (applies to Infotainment Columbus with the SIM

card slot in the external module)

Hold call: - Switch the display of the option for answering an incoming call

during a call on/off; determine the current divert setting

On - Turn on the display

Off - Turn off the display

Request status - Checking the settings of the SIM card function

Send own number: - Sets the telephone number display for the call receiver

On - Turn on the display

Off - Turn off the display

Network dependent - Telephone service provider dependent display

Request status - Checking the settings of the SIM card function

Delete calls - Delete the selected call type performed via the SIM card inserted

into the external module or via a telephone connected to Infotainment by the

Bluetooth

®

 profile rSAP (applies to Infotainment Columbus with the SIM card

slot in the external module)

All areas - Delete all calls

Missed calls - Delete list of missed calls

Dialled numbers. - Delete outgoing calls

Received calls - Delete list of received calls

Text message settings - Text message settings for the sim card inserted in the

external module or in the telephone connected to Infotainment by the Blue-

tooth

®

 profile rSAP (applies to Infotainment Columbus with the SIM card slot

in the external module)

Standard account - Setting for the use of text messages (only visible when the

SIM card is only used for data services while a telephone is connected to

the Infotainment that supports the Bluetooth

®

 profile MAP)

No standard account - Without priority (selection of the SIM card or the con-

nected telephone required)

SIM - A list of text messages on the SIM card

MAP - A list of text messages of the connected telephone

Service centre number: - Setting the number of SMS services of the telephone

service provider

Store sent text messages - Enable / disable the storage of the text message on

the SIM card

Period of validity: - Adjustment of the period in which the telephone service

provider will try to deliver a text message (for example, if the recipient is

not available or Infotainment is switched off.)

Delete text messages - Delete the data stored on the SIM card text messages

All - Delete all text messages

Inbox - Delete the text messages received

Outbox - Delete draft text messages

Sent - Delete sent text messages

Telephone Interface “Business” - Turn on / off the Telephone function of the exter-

nal module (applies to Infotainment Columbus with the SIM card slot in the

external module)

Use SIM card only for data connection - turn on - Activating only data services / To

turn off - Activation of data and telephone services of the SIM card inserted

in the external module (valid for Infotainment Columbus with the SIM card

slot in the external module)

Network - Setting of the telephone service provider for the sim card inserted

in the external module or in the telephone connected to Infotainment by the

Bluetooth

®

 profile rSAP (applies to Infotainment Columbus with the SIM card

slot in the external module)/the SIM card inserted in the CarStick device (ap-

plies to Infotainment Amundsen)

» page 137

PIN settings: - Setting the PIN code of the SIM card inserted in the external

module (applies to Infotainment Columbus with the SIM card slot in the ex-

ternal module)

Automatic PIN entry - Enable / disable the storage of the PIN code of the SIM

card

Change PIN - Change the PIN code of the SIM card

Add PIN 2. - Enter the second PIN code of the SIM card (when the function

Automatic PIN entry is on or when the SIM card supports another Telephone

service provider)

Forward calls - Setting diversion of incoming calls (valid for Infotainment Co-

lumbus with the SIM card slot in the external module)

All calls - Forward all incoming calls

If engaged - Forwarding incoming calls during a telephone conversation

Unavailable - Forwarding the incoming calls when the vehicle is outside the

range of the telephone service provider signal

If no answer - Redirecting incoming calls when the incoming call is not an-

swered

SmartLink+ menu settings

In the main SmartLink menu, tap on function surface  .

140

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     6      7      8      9     ..
