Wheels and tyres

363

Tyre repair

WARNING

When the tyres are inflated at different pres-
sures or at a pressure that is too low then a
tyre may be damaged resulting in a loss of
control of the vehicle and a serious or fatal
accident.

If the lamp   lights up, reduce speed im-

mediately and avoid any sudden turning or
braking manoeuvres. Stop when possible,
and check the tyre pressure and status.

The tyre pressure loss indicator only works

correctly if all the tyres are at the correct
pressure when cold, and it is subsequently
calibrated according to the described pro-
cedure.

If a tyre has not been punctured and it does

not have to be changed immediately, drive to
the nearest specialised workshop at a mod-
erate speed and have the tyre checked and
inflated to the correct pressure.

Note

Driving for the first time with new tyres at

a high speed can cause them to slightly ex-
pand, which could then produce an air pres-
sure warning.

If excessively low tyre pressure is detected

with the ignition on, an audible warning will
sound. In the event that there is a fault in the
system, an audible warning will sound.

Driving on unpaved roads for a long pe-

riod of time, or sporty driving, may tempora-
rily deactivate the system. The control lamp
shows a fault, but disappears when road
conditions or the driving style change.

Do not only rely on the tyre pressure moni-

toring system. Regularly check your tyres to
ensure that the tyre pressure is correct and
that the tyres are not damaged due to punc-
ture, cuts, tears and impacts/dents. Remove
objects from the tyres only when they have
not pierced the tyres.

The tyre pressure monitoring indicator

does not function when there is a fault in the
ESC or ABS

›››

page 177

.

Troubleshooting

 Low tyre pressure

The control lamp switches on yellow.
The inflation pressure of one or more wheels is
much lower than the value set by the driver, or
the tyre has structural damage. In addition, a
audible warning sounds and a text message is
displayed on the instrument panel screen.

 Stop the vehicle!

 Stop the vehicle safely

as soon as possible.

Check all tyres and pressures.

Replace any damaged tyres.

 Fault in the tyre pressure loss indicator

The control lamp flashes for approximately 1
minute and then lights up permanently in yel-
low.

If the tyre is inflated correctly, switch the igni-

tion off and on again.

Re-calibrate the tyre pressure monitoring sys-

tem

›››

page 362

If the fault continues, go to a specialised

workshop.

Tyre repair

TMS (Tyre Mobility System) puncture
repair kit

The puncture repair kit (Tyre Mobility System)
will reliably seal punctures caused by the pen-
etration of a foreign body of up to about

4 mm

in diameter.

 Do not remove foreign objects,

e.g. screws or nails, from the tyre.

After inserting the sealant residue in the tyre,
you must again check the tyre pressure about
10 minutes after starting the engine.
You should only use the tyre mobility set if the
vehicle is parked in a safe place, you are famil-
iar with the procedure and you have the nec-
essary tyre mobility set. Otherwise, you should
seek professional assistance.

CarManuals2.com

364

Wheels and tyres

1

Do not use the tyre sealant in the following
cases:

If the wheel rim has been damaged.

In outside temperatures below -20°C (-4°F).

In the event of cuts or perforations in the tyre

greater than 4 mm.

If you have been driving with very low pres-

sure or a completely flat tyre.

If the sealant bottle has passed its use by

date.

WARNING

Using the puncture repair kit can be danger-
ous, particularly when filling the tyre on the
roadside. To reduce the risk of serious injury,
consider the following:

Stop the vehicle safely as soon as possible.

Park it at a safe distance from surrounding
traffic to fill the tyre.

Ensure the ground on which you park is flat

and solid.

All passengers and particularly children

must keep a safe distance from the work
area.

Turn on the hazard warning lights to warn

other road users.

Always stop the engine, apply the elec-

tronic parking brake and put it in gear if fitted
with a manual gearbox, or press the parking

lock button P if fitted with an automatic gear
box, to reduce the risk of involuntary move-
ment of the vehicle .

Use the tyre mobility system only if you

are familiar with the necessary procedures.
Otherwise, you should seek professional as-
sistance.

 The tyre mobility set is intended for tempo-

rary emergency use only until you can reach
the nearest specialised workshop.

Replace the repaired tyre with the tyre mo-

bility set as soon as possible.

 The sealant is a health hazard and must be

cleaned immediately if it comes into contact
with the skin.

Always keep the tyre mobility set out of the

reach of small children.

WARNING

A tyre filled with sealant does not have the
same performance properties as a conven-
tional tyre.

Never drive faster than 80 km/h (50 mph).

Avoid heavy acceleration, hard braking

and fast cornering.

Drive for only 10 minutes at a maximum

speed of 80 km/h (50 mph) and then check
the tyre.

For the sake of the environment

Dispose of used or expired sealant observing
any legal requirements.

Note

A new bottle of sealant can be purchased at
SEAT dealerships.

Note

Take into account the separate instruction
manual provided by the tyre mobility system
manufacturer.

Anti-puncture kit contents

Fig. 258

Standard display: contents of the

anti-puncture kit.

The anti-puncture kit is located underneath the
floor covering in the luggage compartment. In-
cludes the following components

›››

Fig. 258

:

Valve insert remover

CarManuals2.com

Wheels and tyres

365

Tyre repair

2

3

4

5

6

7

8

9

10

11

A sticker to be adhered to the instrument
cluster, within the driver's visual field, to re-
mind that the maximum advisable speed
“max. 80 km/h” or “max. 50 mph”
Filler tube with cap
Air compressor (depending on the version,
the model may vary).
ON/OFF switch
Air bleed screw (it can also be integrated in
the inflator tube).
Warning provided by tyre pressure monitor-
ing system (it can also be integrated in the
inflator tube).
Tube for inflating tyres
12 volt connector
Bottle of sealant
Spare tyre valve

The

valve insert remover



1

 has a gap at the

lower end for a valve insert. The valve insert can
only be screwed or unscrewed in this way. This
also applies to its replacement part

11

.

Sealing and inflating a tyre

Sealing the tyre

Unscrew the tyre valve cap and insert. Use

the device

›››

Fig. 258



1

 to remove the valve

cap. Place it on a clean surface.

Shake the tyre sealant bottle vigorously

›››

Fig. 258



10

 .

Screw the tyre inflation hose

›››

Fig. 258



3

into the tyre sealant bottle. The bottle's seal will
break automatically.

Remove the filler cap

›››

Fig. 258



3

 and

screw the open end of the tube into the tyre
valve.

With the bottle upside down, empty

all

 of the

contents into the tyre.

Remove the bottle from the valve.

Replace the howitzer with the device

›››

Fig. 258



1

 onto the tyre valve.

Inflating the tyre

Screw the tyre inflation tube of the compres-

sor

›››

Fig. 258



8

 on the tyre valve.

 Check that the air evacuation screw is

closed

›››

Fig. 258



6

 .

Start the engine and leave it running.

Attach the connector

›››

Fig. 258



9

 to the

vehicle’s 12 volt power outlet

›››

page 241

.

Switch on the air compressor with ON/OFF

switch

›››

Fig. 258



5

 .

Keep the air compressor running until it rea-

ches a pressure of 2.0-2.5 bar (29-36 psi/
200-250 kPa).

A maximum of 8 minutes

.

Disconnect the air compressor.

If it does not reach the pressure indicated,

unscrew the tyre inflator tube from the valve.

 Move the vehicle 10m so that the sealant is

distributed throughout the tyre.

Screw the compressor tyre inflator into the

valve.

Repeat the inflation process.

If it still does not come up to pressure, the

tyre is too badly damaged. Stop and seek as-
sistance from authorised personnel.

Disconnect the air compressor. Unscrew the

tyre inflation tube from the tyre valve.

When the tyre pressure is between 2.5 and

2.0 bars, continue driving without exceeding
80 km/h (50 mph).

Attach the sticker

›››

Fig. 258



2

 to the instru-

ment panel display, within the driver's field of
vision.

Check the pressure again after 10 minutes

›››

page 366

.

WARNING

When inflating the wheel, the air compressor
and the inflator tube may become hot.

Protect hands and skin from hot parts.

Do not place the hot flexible inflator tube

or hot air compressor on flammable material.

Allow them to cool before storing the de-

vice.

 If it is not possible to inflate the tyre to at

least 2.0 bars (29 psi / 200 kPa), the tyre is
too badly damaged. The sealant is not in a
good condition to seal the tyre. Do not con-
tinue driving. Seek specialist assistance.

CarManuals2.com

366

Wheels and tyres

NOTICE

Switch off the air compressor after a maxi-
mum of 8 operational minutes to avoid over-
heating! Before switching on the air com-
pressor again, let it cool for several minutes.

Check after 10 minutes of driving

Screw in the inflator tube

›››

Fig. 258



8

 again

and check the pressure on the gauge

7

.

1.3 bar (19 psi / 130 kPa) and lower:

Stop the vehicle!

 The tyre cannot be sealed

sufficiently with the tyre mobility set.

You should obtain professional assistance

›››

.

1.4 bar (20 psi/140 kPa) and higher:

Set the tyre pressure to the correct value

again.

Carefully resume your journey until you reach

the nearest specialised workshop without ex-
ceeding 80 km/h (50 mph).

Have the damaged tyre replaced.

WARNING

Driving with an unsealed tyre is dangerous
and can cause accidents and serious injury.

Do not continue driving if the tyre pressure

is 1.3 bar (19 psi / 130 kPa) and lower.

Seek specialist assistance.

CarManuals2.com

Maintenance

367

Service

Maintenance

Service

Service work and the Digital Mainte-
nance Plan

Log of services performed (“Digital Mainte-
nance Plan”)

The SEAT dealership or a specialised workshop
records Service receipts in a central system.
Thanks to this comprehensive documentation
of the service history, it is possible to reproduce
the services performed any time. SEAT recom-
mends requesting a Service receipt after every
service carried out containing all the services
carried out on the system.
Whenever there is a new service the receipt is
replaced with a current one.

The Digital Maintenance Plan is not availa-
ble in some markets. In this case, your SEAT
dealer will inform you about the current
documentation of the work.

Service works

In the Digital Maintenance Plan, your SEAT au-
thorised service or specialised workshop docu-
ments the following information:

When each one of the services was carried

out.

Whether a specific repair has been sugges-

ted, e.g. changing the brake pads in the near
future.

If you have expressed a special request for

the maintenance. Your Service Advisor will write
the work order.

The components or fluids that were changed.

The date of the next service.

The Long Life Mobility Warranty is valid until the
next inspection. This information is documented
in all checks performed.
The type and the volume of the service may
vary from one vehicle to another. A specialised
workshop will be able to provide specific infor-
mation on the jobs for your vehicle.

WARNING

If the services are insufficient or not per-
formed and if the service intervals are not
observed, the vehicle may be immobilised in
traffic cause an accident and severe injuries.

Make sure that any repairs are carried out

by a SEAT authorised service or specialised
workshop.

NOTICE

SEAT cannot be held liable for any damage
to the vehicle due to insufficient work or of
lack of availability of spare parts.

Note

Regular services on the vehicle not only
maintain its value, but also its correct opera-
tion and road safety. For this reason, conduct
the services in accordance with SEAT guide-
lines.

Set Service or Flexible Service Inter-
vals

Services are classified as

oil change service

and

inspection

. The service interval display

on the instrument panel display serves as a re-
minder of the next service.
Depending on the features, the engine and the
conditions of use of the car, either the

Fixed

service

 or the

Flexible service

 will be applied

for an oil change service..

How to know which type of service needs to
his vehicle

Check the tables below:

CarManuals2.com

368

Maintenance

Oil change service

a)

PR No.

Type of
service

Service interval

QI1

Fixed

Every

5000 km

 or after

1 year

b)

QI2

Every

7500 km

 or after

1 year

b)

QI3

Every

10000 km

 or after

1 year

b)

QI4

Every

15000 km

 or after

1 year

b)

QI6

Flexible

According to the service in-
terval display.

a)

 The data are based on normal conditions of use.

b)

 Whatever happens first.

Inspection Service

a)

According to the service interval display.

a)

 The data are based on normal conditions of use.

Particular characteristics of the Flexible
Service

Regarding the

Flexible Service

 the oil change

service only has to be performed when the ve-
hicle needs it. To calculate when you have to
carry out this service, take into account the in-
dividual conditions of use and personal driving

style. A major component of the flexible service
the use of LongLife oil instead of conventional
engine oil.
Bear in mind the information about the specifi-
cations of the engine oil according to the VW
standard

›››

page 339

.

If you do not want to the flexible service you
can select the fixed service. However, a fixed
service may affect service costs.

 The Service

Advisor will gladly advise you.

At SEAT, the dates of the services are indicated
by the service intervals display:

on the instrument panel

›››

page 30

 in the infotainment system: menu

 > Set-

tings > Service

OR



 > Vehicle sta-

tus > Service



›››

page 36

.

The service interval display gives information
for service dates that involve an engine oil
change or an inspection. When the time for the
corresponding service comes, additional work
required, such as the change of brake fluid and
the spark plugs, can be carried out.

Information about the terms of use

The service intervals and groups are usually
based on

normal conditions of use

.

If, on the other hand, the vehicle is under

ad-

verse conditions of use

, some of the work

must be carried out before the next service pe-
riod or even between service intervals.

Conditions of use adverse include:

The use of fuel with a high sulphur content.

Frequent short trips.

Letting the engine idle for a long period of

time, as in the case of taxis.

Using the vehicle in areas with thick dust.

Frequent driving with a trailer (depending on

equipment).

 Using the vehicle mostly in situations with a

lot of traffic and stops (e.g. in the city).

Using the vehicle mostly in winter.

This applies especially for the following
parts (depending on equipment):

Dust and pollen filter

Air Care allergen filter

Air filter

Toothed chain

Particulate filter

Engine oil

The Service Advisor of your specialised
workshop will gladly inform you

 about the

need of performing service work between nor-
mal service intervals, always considering the
conditions of use of your vehicle.

CarManuals2.com

Maintenance

369

Additional service offers

WARNING

If the services are insufficient or not per-
formed and if the service intervals are not
observed, the vehicle may be immobilised in
traffic and cause accidents and severe inju-
ries.

Have the services conducted at authorised

SEAT services or specialised workshops.

NOTICE

SEAT cannot be held liable for any damage
to the vehicle due to insufficient work or of
lack of availability of spare parts.

Service sets

Sets of services include all the

maintenance

works

 needed to ensure the safety and the

smooth running of the vehicle (

depending on

the conditions of use and the features of the
vehicle

, such as the engine, gearbox, or oper-

ating fluids).
Maintenance services are divided into

inspec-

tion

 and

review

 services. Consult the details of

the jobs required for your vehicle at:

Your SEAT authorised service

Your specialised workshop

Due to technical reasons (continuous develop-
ment of components) the sets of services may
vary. Your SEAT authorised service or special-
ised workshop is always receiving updates in
time.

Additional service offers

Approved spare parts

Original SEAT Spare Parts have been con-
ceived for their vehicles and approved by SEAT,
with a special emphasis on safety. These parts
correspond exactly to the manufacturer's re-
quirements in terms of design, accuracy of the
measurements and materials. The original SEAT
Spare Parts have been conceived exclusively
for your vehicle. For this reason, we always rec-
ommend the use of Original SEAT Spare Parts.
SEAT cannot be held liable for the safety and
suitability of parts from other manufacturers.

Approved spare parts

Approved spare parts, following the manufac-
turer's requirements, are an additional service
to you, offering the possibility of replacing com-
plete sets, such as: light engine, gearboxes,
heads, control units, electrical components,
etc.
These parts are,

approved parts

, and are the

same as the factory parts, which are also ap-
proved spare parts.

Original accessories

We recommend you only use SEAT Original Ac-
cessories and SEAT approved accessories for
your vehicle. The reliability, safety and suitabil-
ity of these accessories have been inspected
specifically for this type of vehicle. SEAT cannot
be held liable for the safety and suitability of
parts from other manufacturers.

Service Mobility

As of the moment you purchase your SEAT ve-
hicle you will be able to enjoy the benefits and
coverage of Service Mobility.
For the first two years after the purchase, your
new SEAT vehicle is automatically covered by
Service Mobility at no additional cost.
If you wish to enjoy this service after this period,
you can extend SEAT Service Mobility as long
as you carry out the recommended Inspection
and Maintenance Services at a SEAT Author-
ised Service.
If your SEAT vehicle is immobilised due to a fault
or an accident, our assistance services will help
you keep moving.
Take into account that the SEAT Mobility Serv-
ice differs depending on the country in which
the vehicle was purchased. For further informa-
tion ask your SEAT dealership or the SEAT web-
site in your country.

CarManuals2.com

370

Maintenance

Vehicle upkeep and clean-
ing

Basic observations

Regular and careful care helps to maintain the
value of your vehicle. In addition, it may be-
come a prerequisite to demand the warranty
in the event of corrosion damage and deficien-
cies in the paint coat of the bodywork.
Specialised workshops have the necessary
care products. Please follow the instructions for
application on the packaging.

WARNING

Cleaning products and other materials

used for car care can be damaging to your
health if misused.

Always keep care products in a safe place,

out of the reach of children. Danger of poi-
soning!

For the sake of the environment

When purchasing car care products, chose

products that are compatible with the envi-
ronment.

The waste from car-care products should

not be disposed of with ordinary household
waste.

Washing the vehicle

The longer you take to clean the tanks, e.g. re-
mains of insects, bird excrements, tree resin or
anti frost salt adhered to your vehicle, the more
damage it can cause to the surface. High tem-
peratures, for instance strong sunlight, further
intensify the damage.
Before washing the car, soften the dirt using
plenty of water.
To remove encrusted dirt such as insects, bird
droppings or tree resin, use a lot of water and a
microfibre cloth.
Have the underside of the vehicle washed after
the end of the anti frost salts in winter.

High pressure cleaning equipment

When washing the vehicle with a high-pressure
cleaner, always follow the operating instruc-
tions for the equipment. This applies particu-
larly to the operating pressure and the distance
between the spraying water.
Do not aim the jet directly towards the side
windows, doors, sunroof or covers; the same
applies for the tyres, rubber hoses, damping
material, sensors or camera lenses. Keep a dis-
tance of at least 40 cm.
Do not remove snow and ice with a high-pres-
sure cleaner.
Do not use a nozzle that sprays the water out in
a direct stream or one that has a rotating jet for
forcing off dirt.

The water temperature must not exceed 60°C.

Automatic car washes

Spray the vehicle before starting the car wash.
Make sure that the windows and sunroof are
closed and the wipers are deactivated. Bear
in mind the instructions of the car wash tunnel
operator, especially if your vehicle has detach-
able parts.
Use of car washes without brushes if possible.

Washing by hand

Clean your vehicle from top to bottom with a
soft sponge or with a brush. Only use cleaning
products that do not contain solvents.

Polishing

Polishing is only necessary when the vehicle's
paintwork has lost its gloss and cannot be re-
stored with care products.
Do not polish matt painted surfaces! If the
paintwork is polished, the surface will be irrep-
arably damaged.

Washing vehicles with a matte paint by hand

To prevent damage to the vehicle when wash-
ing it, first remove the thicker dust and dirt.
To remove traces of insects, grease and finger-
prints, it is best to use a special cleaner for
matte paint.

CarManuals2.com

Maintenance

371

Vehicle upkeep and cleaning

1)

Neutral soap solution: maximum of two tablespoons in 1 l of water.

Apply the product with a microfibre cloth. To
avoid damaging the surface of the paint, do not
apply too much pressure.
Rinse with plenty of water. Then clean it with a
neutral cleaning product and a soft microfibre
cloth.
Rinse the vehicle again with plenty of water and
then leave it to dry. Remove traces of water
with a leather cloth.

WARNING

Only wash the vehicle with the ignition

switched off or according to the specifica-
tions of the car wash tunnel operator. Acci-
dent hazard!

When cleaning the underbody or the inside

of the wheel arches, protect yourself from
sharp or pointy metal parts. Risk of cut!

After cleaning the brakes could act more

slowly due to moisture or, in winter, the ice on
the brake discs and pads. Accident hazard!
In this case the brakes should be dried by
pressing the brake pedal several times.

WARNING

Incorrect use of high-pressure cleaning
equipment can cause damage. This can lead
to accidents and serious injuries.

Never direct the jet of the high-pressure

cleaning equipment directly at the orange
high-voltage cables, the high-voltage sys-
tem components or the 12-volt on-board net-
work.

NOTICE

Before washing the vehicle in an automatic

car wash, please make sure to retract the
exterior mirrors to prevent them from being
damaged. The electric folding exterior mir-
rors should only be folded/unfolded electri-
cally!

Do not wash the vehicle in direct sunlight.

Risk of damaging the paint job!

Do not use sponges, abrasive household

sponges or similar to clean insect remains.
Risk of damaging the surface!

Vehicle parts with matte paint:

Do not use polish or hard wax. Risk of

damaging the surface!

Never select washing programmes that

include the use of wax. This could damage
the appearance of matte paint.

Do not put stickers or magnets on parts

with matte paint, as removing them may
damage the paint.

For the sake of the environment

The car should only be washed in special
wash bays. These places are prepared to
prevent oily water from getting into the pub-
lic drains.

Cleaning the exterior

Below can be found some recommendations on
the cleaning and upkeep of individual vehicle
components.
Go to your specialised workshop if you have
special questions or parts that are not listed.
Take the general considerations into account

›››

page 373,

Take special care with...

.

Windscreen wipers

Dirt:

 Soft cloth with windscreen cleaner.

Headlights / Tail lights

Dirt:

 Soft sponge with neutral soap solution

1)

.

CarManuals2.com

372

Maintenance

1)

Neutral soap solution: maximum of two tablespoons in 1 l of water.

Sensors / Camera lenses

Dirt:

Sensors

: soft cloth with a solvent-free

cleaning product.

Camera lenses

: soft cloth with an alcohol-

free cleaning product.

Snow/ice:

 Hand brush/Solvent-free antifreeze

spray

Wheels

Antifreeze salt:

 Water.

Brake abrasion dust:

 Special acid-free clean-

ing product.

End exhausts

Antifreeze salt:

 Water, if a fine steel cleaning

product is required, or a non-abrasive and non-
corrosive cleaning product.

Covers / Trims

Dirt:

 Neutral soap solution

1)

, if a fine steel

cleaning product is required.

Paint

Paint flaws:

 Check the paint's colour code at

an authorised service and restore with a touch-
up pencil.

Spilled fuel:

 Immediately rinse with water.

Tank with environmental rust:

 Apply rust re-

mover and then apply hard wax. Go you your
specialised workshop if you have any queries.

Corrosion:

 Have your specialised workshop

take care of this.

Water does not form droplets on the clean

paint:

Maintain with hard wax (at least twice a

year).

No shine despite maintenance/unattractive

paint:

 Treat with suitable wax and apply paint

preservative afterwards if the wax used does
not contain preservative ingredients.

Tanks, e.g. insect remains, bird droppings, tree

sap, road salt:

 Immediately soak with water and

remove with a microfibre cloth.

Grease-based dirt, e.g. cosmetic products or

sunscreen:

 Remove immediately with a neutral

soap solution

1)

 and a soft cloth.

Carbon fibre parts

Dirt:

 Clean in the same way as painted parts

›››

page 370

.

Decoration slides

Dirt:

 Soft sponge with neutral soap solution

1)

.

Interior cleaning

Below can be found some recommendations on
the cleaning and upkeep of individual vehicle
components.
Go to your specialised workshop if you have
special questions or parts that are not listed.
Take the general considerations into account

›››

page 373,

Take special care with...

.

Windows

Dirt:

 Apply windscreen cleaner and then dry

with a cloth.

Covers / Trims

Dirt:

 Neutral soap solution

1)

.

Plastic parts

Dirt:

 Damp cloth.

Encrusted dirt:

 Neutral soap solution

1)

, if possi-

ble a solvent-free plastic cleaning product.

Displays/instrument panel

Dirt:

 Soft cloth with a liquid crystal display

cleaner.

Control panels

Dirt:

 Soft brush, then a soft cloth with a neu-

tral soap solution

1)

.

CarManuals2.com

Maintenance

373

Vehicle upkeep and cleaning

1)

Neutral soap solution: maximum of two tablespoons in 1 l of water.

Seat belts

Dirt:

 Neutral soap solution

1)

, allowed to dry

before retracting.

Fabrics, artificial, Alcantara leather

Particles of dirt stuck to surfaces:

 Vacuum

cleaner.

Water-based dirt, e.g. coffee, tea, blood etc.:

Absorbent cloth and neutral soap solution

1)

.

Grease-based dirt, e.g. oil, make-up, etc.:

 Ap-

ply a neutral soap solution

1)

. Absorb the dis-

solved grease and paint particles drying with
an absorbent cloth, in case you must treat it
with water afterwards.

Special dirt, e.g. pens, nail polish, dispersion

paint, shoe polish, etc.:

 Special stain remove:

dry with an absorbent cloth, if applicable, ap-
ply neutral soap solution afterwards

1)

.

Natural leather

Recent dirt:

 Cotton cloth with neutral soap

solution

1)

.

Water-based dirt, e.g. coffee, tea, blood etc.:

Recent stains:

 absorbent cloth.

Dry stains:

 stain remover suitable for

leather.

Grease-based dirt, e.g. oil, make-up, etc.:

Recent stains:

 absorbent cloth and suitable

stain remover for leather.

Dry stains:

 grease solvent spray.

Special dirt, e.g. pens, nail polish, dispersion

paint, shoe cream etc.:

 Stain remover suitable

for leather.

Care:

 Apply preservative cream regularly to

protect from sunlight. Use a coloured preserva-
tive if required.

Carbon fibre parts

Dirt:

 Clean as with plastic parts.

Take special care with...

Headlights/tail lights

Do not clean the headlights/tail lights with a

dry cloth or sponge.

Do not use cleaning products that contain

alcohol. Risk of cracks!

Wheels

Do not use for paint wax or other abrasive

products.

If the protective coating on the paint of the

rim has been damaged due to stone impacts,
scratches, etc., the damage should be repaired
immediately.

Camera lenses

Do not use hot or warm water to remove ice

or snow from the camera lenses. Risk of crack-
ing the lens!

To clean the camera lens, never use abra-

sive cleaning products or products with alcohol.
Risk of scratches and cracks!

Windows

Remove snow and ice from windows and ex-

terior mirrors with a plastic scraper only. To
avoid scratches, the scraper should only be
pushed in one direction and not moved to and
fro.

Never remove snow or ice from windows and

rearview mirrors with warm or hot water. Risk of
cracks on the windows!

To prevent damage to the heating of the rear

window, do not put stickers over the heating
elements.

Covers/trims

Do not use cleaning products or chrome

based cleaning agents.

Paint

The vehicle must be free from dirt and dust

before applying wax or care products. Risk of
scratches!

CarManuals2.com

374

Maintenance

Do not apply wax or care products if the vehi-

cle is exposed to direct sunlight. Risk of damag-
ing the paint job!

 The ambient rust deposits must not be re-

moved through friction. Risk of damaging the
paint job!

Remove cosmetic products and sunlight im-

mediately. Risk of damaging the paint job!

Displays/instrument panel

The displays, the instrument panel and the

trim around it must not be cleaned dry. Risk of
scratches!

Make sure that the instrument panel is

switched off and cooled down before cleaning.

Make sure that no liquid leaks between the

instrument panel and the trim. Risk of damage!

Control panels

Make sure that no liquid leaks into the control

panels. Risk of damage!

Seat belts

Do not remove the seat belts to clean them.

Seat belts and their components must never

be cleaned with chemical products, nor should
they be allowed to come into contact with cor-
rosive liquids, solvents or sharp objects. Risk of
damaging the fabric!

If you find any damage to the belt webbing,

belt fittings, the belt retractor or the buckle, ask
your specialised workshop to replace the belt
in question.

Fabrics/artificial leather/microfibre

Do not treat artificial leather/microfibre with

leather cleaning products, solvents, wax polish,
shoe cream, stain removers or similar products.

If the stain is very hard to remove, take the

vehicle to a specialised workshop to have it re-
moved there. This will prevent damage.

Do not use steam cleaners, brushes, hard

sponges, etc. to clean.

Do not turn on seat heating to dry the seats.

Sharp objects on clothing, such as zips, rivets

or belts can damage the surface.

Open Velcro, e.g. on clothes can damage the

seat upholstery. Make sure that Velcro fasten-
ers are closed.

Natural leather

Never use solvents, wax polish, shoe cream,

spot removers or similar products on leather.

Sharp objects on clothing, such as zips, rivets

or belts can damage the surface.

Do not use steam cleaners, brushes, hard

sponges, etc. to clean.

Do not turn on seat heating to dry the seats.

Avoid exposing leather to direct sunlight for

long periods, otherwise it may tend to lose
some of its colour. If the car is left for a pro-
longed period in the bright sun, it is best to
cover the leather.

WARNING

Do not use water-repellent coatings on the
windscreen. In bad visibility conditions such
as humid weather, darkness or when the sun
is in its lowest point, visibility may be impac-
ted. Accident hazard! Such coatings can also
cause the windscreen wiper blades to make
noise.

Note

Remains of insects can be removed much

more easily with previously treated paint.

Regular car care treatments can prevent

deposits of ambient rust.

Remove the vehicle from traffic

If you want to leave your vehicle stationary
for a long period of time, contact a qualified
workshop. They will gladly inform you about
the necessary measures, such as anti-corrosion
protection, Service and storage.
Also take into account the indications relat-
ing to the vehicle’s battery

›››

page 343

 ,

›››

page 343,

Introduction

.

CarManuals2.com

Maintenance

375

Accessories, spare parts and repair work

Accessories, spare parts
and repair work

Introduction

Always ask your dealer or specialist retailer for
advice before purchasing accessories and re-
placement parts.
Your vehicle is designed to offer a high standard
of active and passive safety. For this reason, we
recommend that you ask a SEAT Official Serv-
ice for advice before fitting accessories or re-
placement parts. Your SEAT Official Service has
the latest information from the manufacturer
and can recommend accessories and replace-
ment parts which are suitable for your require-
ments. They can also answer any questions
you might have regarding official regulations.
We recommend only using

SEAT accessories

and

genuine SEAT parts

®. SEAT has tested

these parts and accessories for suitability, reli-
ability and safety. SEAT Official Services have
the necessary experience and facilities to en-
sure that the parts are installed correctly and
professionally.
Although SEAT continuously monitors the mar-
ket, it cannot judge whether products

not au-

thorised by SEAT

 meet the vehicle’s reliability,

safety and suitability requirements. SEAT there-
fore accepts no liability for these products,
even if, in certain cases, they are authorised
by an officially recognised technical inspection
institute or official body.

Any

retro-fitted equipment

 which has a di-

rect effect on the vehicle and/or the way it
is driven, such as a cruise control system

or

electronically-controlled suspension

, must

be approved for use in your vehicle and bear
the

e

 mark (the European Union's authorisation

symbol).
If

any additional electrical devices

 are fitted

which do not serve to control the vehicle itself
(for instance a refrigerator box, laptop or venti-
lator fan, etc.), they must bear the   marking
(manufacturer conformity declaration in the Eu-
ropean Union).

WARNING

Accessories, for example telephone holders
or cup holders, should never be fitted on the
covers, or within the working range of the air-
bags. Otherwise, there is a danger of injury if
the airbag is triggered in an accident.

Technical modifications

Unauthorised modifications to the electronic
components, software, wiring or data transfer
in the vehicle may cause malfunctioning.
You will appreciate that your SEAT dealership
cannot be held liable for any damage caused
by modifications and/or work performed incor-
rectly.
For this reason we recommend asking official
SEAT service centres to do any necessary work
using

genuine SEAT

 parts®.

WARNING

Incorrectly performed modifications or other
work on your vehicle can lead to malfunc-
tions and cause accidents.

Radio telephones and office equip-
ment

Radio transmitters (fixed installation)

Any retrofit installations of radio transmitters
in the vehicle require prior approval. SEAT gen-
erally authorises in-vehicle installations of ap-
proved types of radio transmitters provided
that:

The antenna is installed correctly.

The aerial is installed on the exterior of the

vehicle (and shielded cables are used together
with non-reflective aerial trimming).

The effective transmitting power does not ex-

ceed 10 Watts at the aerial base.
A SEAT Official Service and specialised work-
shop will be able to inform you about options
for installing and operating radio transmitters
with a higher transmitting power.

Mobile radio transmitters

Commercial mobile telephones or radio equip-
ment might interfere with the electronics of your
vehicle and cause malfunctions. This may be
due to:

CarManuals2.com

376

Maintenance

No external aerial.

External aerial incorrectly installed.

Transmitting power more than 10 W.

You must, therefore, do not operate portable
mobile telephones or radio equipment

inside

the vehicle

 without a properly installed external

aerial

›››

.

Please note also that the maximum range of
the equipment can only be achieved with an

external

 aerial.

Business equipment

Retrofit installation of business or private equip-
ment in the vehicle is permitted, provided the
equipment cannot interfere with the driver's im-
mediate control of the vehicle and that any
such equipment carries the   mark. Any retro-
fit equipment that could influence the driver's
control of the vehicle must have a type appro-
val for your vehicle and must carry the

e

 mark.

WARNING

Mobile telephones or radio equipment which
is operated inside the vehicle without a prop-
erly installed external aerial can create ex-
cessive magnetic fields that could cause a
health hazard.

Note

The posterior fitting of electric and elec-

tronic equipment in this vehicle affects its li-
cence and could lead to the withdrawal of
the vehicle registration document under cer-
tain circumstances.

Please use the mobile telephone/radio op-

erating instructions.

CarManuals2.com

Information for the user

377

Information stored by the control units

Information for the user

Warranty

Fault-free operation warranty

SEAT Authorised Services ensure the perfect
condition of new vehicles. Check the purchase
agreement or complementary additional docu-
mentation provided by your Technical Service
to see the conditions and the terms of the war-
ranty. Consult further information in this regard
in your SEAT Official Service.

Commercial warranty for high volt-
age batteries for electric and hybrid
vehicles

To supplement the aforementioned warranties
and guarantees, SEAT Official Services also
grant a guarantee for high voltage batteries ex-
isting in many countries.
Consult the details of this guarantee in the
sales contract or contact a SEAT Official Serv-
ice.

Information stored by the
control units

Storage of accident data (Event Data
Recorder)

Your vehicle has an event data recorder (EDR).
The EDR’s function is to record data in the event
of a mild or serious accident. These data are
used to support the analysis of how different
vehicle systems behaved.
The EDR records, over a reduced time range
(normally 10 seconds or less), dynamic driving
data and data from the restraint systems, such
as:

How different vehicle systems worked.

Whether the driver and the occupants were

wearing their seat belts.

How hard the acceleration or brake pedal

was pressed.

Vehicle speed.

GPS position.

These data will provide a better understanding
of the circumstances of the accident.
Data from the driving assist systems are also
recorded. This includes data such as whether
the systems were inactive or active and if such
action had an impact on the vehicle’s dynamic

behaviour, changing its path in the aforemen-
tioned situations, accelerating or decelerating
the vehicle.
Depending on vehicle equipment, this includes
data from systems such as:

the adaptive cruise control

the lane assist system

parking assistants

the emergency brake functions.

The EDR data are only recorded in specific ac-
cident situations. No data are recorded in nor-
mal driving conditions.
No audio or video data inside or around the
vehicle are recorded. Under no circumstances
are personal data such as name, age, or gen-
der recorded. Nevertheless, third parties (such
as criminal proceedings authorities) may relate
the contents of the EDR data to other data
sources and create a personal reference in the
context of an accident investigation.
In order to read the EDR data it is necessary
to access (if legally permitted to do so) the
vehicle's ODB (“On-Board-Diagnose”) interface
while the vehicle is switched on.
SEAT will not have access to EDR data unless
the owner (or, in “Leasing” cases, the lessee or
hirer) gives their consent. There may be excep-
tions to this, depending on legal or contractual
provisions.

CarManuals2.com

378

Information for the user

Due to legal requirements in safety-related
products, SEAT may use the EDR data for field
research and in order to improve vehicle system
quality. Any data used for the purposes of re-
search will be treated anonymously (in other
words, no reference will be made to the vehicle,
their owner or the lessee/hirer).

Vehicle antennas

Infotainment system and antennas

The infotainment system's antennas are instal-
led on different locations on the vehicle:

On the roof.

On the windscreen, between the layers of

glass.

On the rear and side windows with a printed

antenna structure

›››

.

NOTICE

The printed antenna structure on the rear
and side windows can be damaged by ob-
jects rubbing against it or by the use of
corrosive products, or products containing
acids.

Do not apply any stickers to the rear and

side window areas.

Never clean the antenna structure with

corrosive or acidic products.

Materials and recycling in-
formation

Environmental compatibility

Environmental protection is a top priority in the
design, choice of materials and manufacture of
your new SEAT.

Constructive measures to encourage recy-
cling

Joints and connections designed for easy

dismantling.

Modular construction to facilitate disman-

tling.

Increased use of single-grade materials.

Plastic parts and elastomers are marked in

accordance with ISO 1043, ISO 11469 and ISO
1629.

Choice of materials

Use of recycled materials.

Use of compatible plastics in the same part if

its components are not easily separated.

Use of recycled materials and/or materials

originating from renewable sources.

Reduction of volatile components, including

odour, in plastic materials.

Use of CFC-free coolants.

Ban on heavy metals, with the exceptions
dictated by law (Annex II of ELV Directive
2000/53/EC)

: cadmium, lead, mercury, hexa-

valent chromium.

Manufacturing methods

Reduction of the quantity of thinner in the

protective wax for cavities.

Use of plastic film as protection during vehi-

cle transport.

Use of solvent-free stickers.

Use of CFC-free coolants in cooling systems.

Recycling and energy recovery from residues

(RDF).

Improvement in the quality of waste water.

Use of systems for the recovery of residual

heat (thermal recovery, enthalpy wheels, etc.).

The use of water-soluble paints.

Recycling of electrical or electronic
devices

All electrical or electronic devices (EED) that
are not permanently fitted in the vehicle must
be marked with the following symbol:

This symbol indicates that EED must not be dis-
carded as home waste but through selective
waste collection.

CarManuals2.com

Information for the user

379

Radioelectrical equipment

Product recycling

For the sake of the environment

The Triman logo and the Infotri symbol con-
tain important information for the classifica-
tion of the end consumer.

Italy. Environmental labelling

Legislative decree no. 116 (3 September 2020),
which transposes EU Directive 2018/851 on
waste, and EU Directive 2018/852 on packag-
ing and packaging waste, states that all pack-
aging must be properly labelled to facilitate
the collection, reuse, recovery and recycling of
packaging, and to give users correct informa-
tion about the final destination of the packag-
ing.
Information about the environmental labelling
of packaging present in the vehicle can be
accessed by scanning the following QR code,
which links to a website where the information
required by this regulation can be found:

Radioelectrical equipment

Simplified declaration of conformity

Your vehicle has different radioelectrical de-
vices. The manufacturers of these devices
declare that they comply with Directive
2014/53/EU when legally required.

The full text of the EU compliance declaration is
available online at the following address:

www.seat.com/generalinfo

United Kingdom

Your vehicle has different radioelectrical devi-
ces. The manufacturers of these devices de-
clare that they comply with the UK Radio
Equipment Regulations 2017 (SI 2017/1206) if
required by law.
The full text of the declaration of conformity
is available online at the following Internet ad-
dress:

www.seat.com/generalinfo

Ukraine

Your vehicle has different radioelectrical devi-
ces. The manufacturers of these devices de-
clare that they comply with Ukraine Decree
355/2017 (TR Radio Equipment) where legally
required.
The full text of the declaration of conformity
is available online at the following Internet ad-
dress:

www.seat.com/generalinfo

CarManuals2.com

380

Information for the user

Addresses of the manufacturers

The address of the manufacturers of compo-
nents that, due to their size or nature, cannot
include a sticker are listed below, as long as it is
legally required:

Central control unit (BCM)

Robert Bosch GmbH/Braunschweig
Theodor-Heuss-Strasse 12
38122 - Braunschweig, Germany
Phone: 0049 53188890

Keyless Access System

HELLA GmbH & Co. KGaA/Hamm
Roemerstr. 66
59075 - Hamm, Germany
Phone: 0049 23817980

Roof antenna

ASK Industries S.p.A
Via dell'Industria n.12/14/16
60037 Monte San Vito (AN), Italy
Phone: +3907174521
Website: www.askgroup.it

Mitsumi Electronics Europe GmbH
Siemensstrasse 32
63225 Langen, Germany
Phone: +49 (0) 6103913-0
Website: www.minebeamitsumi.co.jp

Molex CVS Hildesheim GmbH

Daimlerring 31
31135 Hildesheim, Germany
Phone: +49 3377 3160
Website: www.molex.com

Antenna amplifiers

ASK Industries S.p.A
Via dell'Industria n.12/14/16
60037 Monte San Vito (AN), Italy
Phone: +3907174521
Website: www.askgroup.it

Hirschmann Car Communication GmbH
Stuttgarter Strasse 45-51
72654 Neckartenzlingen, Germany
Phone: +49 7127 140
Website: www.te.com

KATHREIN Automotive GmbH
Römerring 1
31137 Hildesheim, Germany
Phone: +498,031,184-0
Website: www.kathrein.com

Molex CVS Hildesheim GmbH
Daimlerring 31
31135 Hildesheim, Germany
Phone: +49 3377 3160
Website: www.molex.com

Navigation antenna

Hirschmann Car Communication GmbH
Stuttgarter Strasse 45-51
72654 Neckartenzlingen, Germany
Phone: +49 7127 140
Website: www.te.com

KATHREIN Automotive GmbH
Römerring 1
31137 Hildesheim, Germany
Phone: +498,031,184-0
Website: www.kathrein.com

Connectivity Box

Molex CVS Dabendorf GmbH
Märkische Strasse 72
15806 Zossen OT Dabendorf, Germany
Phone:+49 3377 3160
Website: www.molex.com

Basic infotainment system

Panasonic Automotive Systems Czech
U Panasonicu 266
530 06, Pardubice, Czech Republic

Optional infotainment system

LG Electronics Mlawa SP
LG Electronics 7
06 500, Mlawa

CarManuals2.com

Information for the user

381

Radioelectrical equipment

1)

The commissioning or authorisation of radioelectrical technology may be restricted in some European countries, forbidden or only allowed with additional
requirements.

Remote control key

Digades GmbH Digitales Und Ana/Zittau
Äußere Weberstr. 20
02763 - Zittau, Germany
Phone: 0049 358357750

Instrument panel

Analogue SE38x/SE316

Visteon Electronics Germany GmbH
Visteonstr. 4-10
50170 Kerpen, Germany


Analogue all other models

Continental Automotive Spain, S.A.
Crta. de Rubí a Ullastrell, nº 12-30
08191 Rubí (Barcelona - Spain)


FPK (digital)

Continental Automotive GmbH
VDO-Strasse 1,
64832 Babenhausen, Germany

Panasonic Automotive Systems Europe GmbH
Robert Bosch Str. 27-29
63225 Langen, Germany

Panasonic Automotive Systems Czech, s.r.o.
U Panasonicu 266
530 06, Pardubice, Czech Republic

Front radar sensors

MRR for SE38X

Robert Bosch GmbH
Markwiesenstrasse, 46
72770 Reutlingen (Kusterdingen) Germany


MRR for Tarraco, Ateca, Ibiza, Arona

Automotive Distance Control Systems GmbH
Peter-Dornier-Strasse, 10
88131, Lindau, Germany

Rear radar sensors

Hella GmbH & Co. KGaA
Rixbecker Straße 75
59552 Lippstadt (Germany)

Online Connectivity Unit

LG ELECTRONICS INC.
10, Magokjungang 10-ro,
Gangseo-gu, Seoul, Republic of Korea

Radio equipment, frequency band,
maximum transmitting power

Below can be found details of the radio equip-
ment

1)

 that can be fitted to all SEAT models.

Unless otherwise stated, the data are valid for
all models (variations are indicated in footnotes
to the tables):

Frequency band

Max. station
power

Key with radio-operated remote control
(vehicle)

433.05-434.78 MHz

10 mW (ERP)

433.05-434.79 MHz

10 mW

868.0-868.6 MHz

25 mW

434.42 MHz

32 µW

Radio-operated remote control (auxiliary
heater)

868.7-869.2 MHz (869.0 MHz)

25 mW

a)

868.0-868.6 MHz (868.3 MHz)

3.1 mW

b)

a)

 Valid for: Leon, Ateca, Tarraco

b)

 Valid for: Alhambra

Transmitter-Receiver (auxiliary heater)

868.7-869.2 MHz (869.0 MHz)

23.5 mW

a)

868.0-868.6 MHz (868.3 MHz)

23.5 mW

b)

a)

 Valid for: Leon, Ateca, Tarraco

b)

 Valid for: Alhambra

Bluetooth

2402-2480 MHz

6 dBm

2400-2483.5 MHz

10 dBm

CarManuals2.com

382

Information for the user

Connection to the vehicle’s external an-
tenna

GSM 900: 880-915 MHz

33 dBm

GSM 1800: 1710-1785 MHz

30 dBm

WCDMA FDD I: 1920-1980 MHz

24 dBm

WCDMA FDD lll: 1710-1785 MHz

21 dBm

WCDMA FDD VIII: 880-915 MHz

21 dBm

LTE FDD1: 1920-1980 MHz

23 dBm

LTE FDD3: 1710-1785 MHz

23 dBm

LTE FDD7: 2500-2570 MHz

23 dBm

LTE FDD8: 880-915 MHz

23 dBm

LTE FFD20: 832-862 MHz

23 dBm

 Valid for: Tarraco, Leon

Connection to the vehicle’s external an-
tenna

GSM 900: 880-915 MHz

33 dBm

GSM 1800: 1710-1785 MHz

30 dBm

WCDMA FDD I: 1920-1980 MHz

24 dBm

 Valid for: Alhambra

Wireless hotspot

2400-2483.5 MHz

10 dBm

 Valid for: Leon, Ateca, Tarraco

Keyless Access

434.42 MHz

32 µW

 Valid for: Ibiza, Arona, Leon, Ateca, Tarraco

Radar sensors for front assist systems

76 GHz-77 GHz

28.2 dBm

a)

35.0 dBm

b)

a)



Valid for: Leon, Alhambra

b)



Valid for: Ibiza, Arona, Ateca, Tarraco

Radar sensors for rear assist systems

24050-24250 MHz

20 dBm

 Valid for: Ibiza, Arona, Leon, Ateca, Tarraco

Wireless charging function

110-120 kHz

5 W

 Valid for: Ibiza, Arona, Leon, Ateca, Tarraco

Instrument cluster

125 kHz

40 dBµA/m

Online Connectivity Unit

EGSM900: 880-915 MHz

33 dBm

DCS1800: 1710-1785 MHz

31 dBm

UMTS FDD 1: 1920-1980 MHz

24 dBm

UMTS FDD 3: 1710-1785 MHz

24 dBm

UMTS FDD 8: 880-915 MHz

24 dBm

E-UTRA FDD 1: 1920-1980 MHz

23.5 dBm

E-UTRA FDD 3: 1710-1785 MHz

23.0 dBm

E-UTRA FDD 7: 2500-2570 MHz

23.5 dBm

E-UTRA FDD 8: 880-915 MHz

23.0 dBm

E-UTRA FDD 20: 832-862 MHz

23.5 dBm

E-UTRA FDD 28: 703-748 MHz

23.0 dBm

 Valid for: Ibiza, Arona, Leon, Ateca, Tarraco

Additional information for countries
outside the European Union

Mexico

Your vehicle has different radioelectrical de-
vices. The manufacturers of these devices
declare that they comply with Directive
RLVCOAR15-0008 when legally required. The
full text of the declaration of conformity is avail-
able online at the following Internet address:
https://www.seat.mx/servicio/mi-seat/manual-
del-propietario.html

CarManuals2.com

Information for the user

383

Radioelectrical equipment

Certificate: RLVHERS17-0286. RS4 Hella
KGaA Hueck & Co. short-range radar
IFT:RLVHERS17-0286. The operation of this
equipment is subject to the following two con-
ditions: (1) this equipment or device may not
cause harmful interference, and (2) this equip-
ment or device must accept any interference,
including interference that may cause unde-
sired operation.

United Kingdom

The following applies to importers in the UK
market:
Volkswagen Group United Kingdom Ltd.
Yeomans Drive, Blakelands
Milton Keynes, MK 14 5AN
United Kingdom

Turkey

Telsiz Ekipmanları Yönetmeliği (2014/53/AB)

Aracınızda çeşitli telsiz ekipmanları bulunmak-
tadır.
Telsiz Ekipmanlari Yönetmeliği (2014/53/AB)
açısından Türkiye pazarı için radyo ekipmanı
ithalatçısı (bu bilgi sadece resmi temsilcimiz
olan Doğuş Otomotiv Servis ve Ticaret A.Ş.’nin
ithal ettiği ürünler için geçerlidir):
Doğuş Otomotiv Servis ve Ticaret A.Ş.
Şekerpınar Mahallesi, Anadolu Caddesi, No: 22
ve 45
41420 Çayırova/Kocaeli

Ukraine

І

мпортер

:

ТОВ

 «

Порше



Укра

ї

на

»

просп

Павла



Тичини

, 1

В

оф

і

с

 „

В

“, 4-

й

поверх

02152

Ки

ї

в

Укра

ї

на

.

Importer:

Porsche Ukraine LLC
Pavla Tychyny ave. 1V, Office “B”, 4th floor
02152 Kyiv, Ukraine.

CarManuals2.com

384

Technical data

Technical data

Indications about the tech-
nical data

Vehicle identification data

The values indicated in the technical data may
differ depending on optional equipment or ver-
sion of the model, as well as in the case of spe-
cial vehicles and equipment for certain coun-
tries.
The information in the official vehicle documen-
tation takes precedence at all times.

Abbreviations used in the Technical Specifi-
cations section

kW

Kilowatt, engine power measure-
ment.

PS

Horsepower (not currently used),
engine power measurement unit.

rpm, 1/min

Revolutions per minute – engine
speed.

Nm

Newton metres, unit of engine tor-
que.

CZ

Cetane number, indication of the
diesel combustion power.

RON

Research octane number, indication
of the knock resistance of petrol.

Vehicle ID number

The vehicle ID number can be found in the fol-
lowing places:

 One the vehicle's data label.

 In front, under the windscreen.

 To the right in the engine compartment.

Type plate

The type plate is located on the vehicle’s right
hand door frame. Vehicles for certain export
countries do not have a type plate.

Performance

The values apply only to optimal road and
weather conditions.
The vehicle’s performance has been calculated
without any equipment that would affect it, e.g.
accessories.

Fuel consumption

Approved consumption values are derived from
measurements performed or supervised by
certified EU laboratories, according to the legis-
lation in force at the time (for more information,
see the Publications Office of the European
Union on the EUR-Lex website: © European Un-
ion, http://eur-lex.europa.eu/) and apply to the
specified vehicle characteristics.

The values relating to fuel consumption and
CO

2

 emissions can be found in the documenta-

tion provided to the purchaser of the vehicle at
the time of purchase.
Fuel consumption and CO

2

 emissions depend

on the equipment/features of each individual
vehicle, as well as on the driving style, road
conditions, traffic conditions, environmental
conditions, load or number of passengers.

Tank level

Vehicles with front-wheel
drive:

58 l, 7 l reserve

Vehicles with all-wheel
drive

60 l, 8.5 l reserve

Plug-in hybrid vehicles
(PHEV)

45 l, 5 l reserve

Adblue tank volume

approx. 18 l

a)

a)

 The amount filled using a dispenser nozzle may

be less. In conditions of extreme cold, the amount
filled may be less.

High-voltage battery

Type and capacity

Plug-in hybrid vehicles
(PHEV)

Li-ion 12.8 kWh 48V

CarManuals2.com

Technical data

385

Indications about the technical data

Weights

The kerb weight values apply to the vehicle
as ready to drive with a driver (75 kg), oper-
ating fluids and, if applicable, tools and the
spare wheel. The kerb weight increases with
optional equipment and retrofitting of accesso-
ries, which reduces the possible payload ac-
cordingly.

Load on the roof

The maximum authorised load on the roof of
your vehicle is 75 kg.

Trailer weight

The maximum permitted drawbar load on the
ball head of the towing bracket is

80 kg

.

WARNING

The values indicated for the maximum per-
mitted weights must not be exceeded. There
is a risk of accident and damage!

CarManuals2.com

386

Technical data

Engine specifications

Petrol engine

1.4 TSI Start-Stop PHEV

TSI engine power in kW (hp) at 1/min

110 (150)/5,000-6,000

Electric motor power in kW (hp) at 1/min

86 (117)/2,600-6,500

TSI engine + electric motor power in kW (hp) at 1/min

180 (245)/5,000-6,000

TSI engine maximum torque (Nm at 1/min)

250/1,550-3,500

Electric motor maximum torque (Nm at 1/min)

330/0-2,600

Maximum torque of TSI engine + electric motor (Nm at 1/min)

400/0-3,500

No. of cylinders/displacement (cm

3

)

4/1,395

Fuel

Super 95 ROZ / Normal 91 (with a slight power loss) ROZ

Gearbox

DSG

Top speed (km/h)

205 (V)

Acceleration from 0-100 km/h (s)

7.6

Maximum authorized weight (kg) (5 seats)

2,390

CarManuals2.com

Technical data

387

Indications about the technical data

Petrol engines

1.4 TSI Start-Stop

1.5 TSI Start-Stop ACT®

2.0 TSI Start-Stop

Power output in kW (hp) at 1/min

110 (150) 5,000-6,000

110 (150)/5,000-6,000

140 (190)/4,200-6,000

180 (245)/5,000-6,500

Maximum torque (Nm at 1/min)

250/1,500-3,500

250/1,500-4,000

320/1,500-4,100

370/1,600-4,300

No. of cylinders/displacement
(cm

3

)

4/1,395

4/1,498

4/1,984

4/1,984

Fuel

Super 95 / Normal 91 (with a slight power loss) ROZ

Gearbox

DSG

manual

DSG

DSG 4Drive

DSG 4Drive

Top speed (km/h)

195 (V)

199 (V)

199 (VI)

210 (V)

228 (V)

Acceleration from 0-100 km/h (s)

9.3

9.9

9.7

7.8

6.3

Maximum authorized weight (kg)
(5/7 seats)

2,170/2,360

2,160/2,350

2,190/2,380

2,370/2,450

2,370/2,450

Diesel engines

2.0 TDI CR Start-Stop

Power output in kW (hp) at 1/min

110 (150)/3,250-4,200

110 (150)/3,000-4,200

147 (200)/3,600-4,100

Maximum torque (Nm at 1/min)

340/1,600-3,000

360/1,600-2,750

400/1,750-3,500

No. of cylinders/displacement (cm

3

)

4/1,968

4/1,968

4/1.96

Fuel

Diesel according to standard EN 590, min. 51 CN

Gearbox

manual

DSG

DSG 4Drive

Top speed (km/h)

198 (VI)

196 (VI)

210 (VI)

Acceleration from 0-100 km/h (s)

10.2

9.9

7.8

Maximum authorized weight (kg) (5/7 seats)

2,240/2,430

2,270/2,460

2,380/2,470

CarManuals2.com

388

Technical data

Dimensions.

Fig. 259

Dimensions.

CarManuals2.com

Technical data

389

Indications about the technical data

›››

Fig. 259

TARRACO

A

Front projection (mm)

926

B

Rear projection (mm)

1,019

C

Wheelbase (mm)

2,790

D

Length (mm)

4,735

E

Front

a)

 track (mm)

1,585

F

Back

a)

 track (mm)

1,574

G

Width (mm)

1,839

H

Height at kerb weight (mm)

1,658

b)

1,674

c)

I

Ground clearance between the axles (mm)

192

J

Front projection angle limited by the bumper

maximum 19.1°

K

Rear projection angle limited by the bumper

maximum 21.4°

Turning radius (m)

11.9

a)

 This data will change depending on the type of wheel rim. Values for wheel 215/65 R17 ET38.

b)

 Distance to the roof.

c)

 Dimension to the roof bars.

CarManuals2.com

Index

391

Index

Numbers and Symbols

4Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  151
12-volt battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  343

assisted start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  320
charge level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  347
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  345
control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  346
disconnect and connect . . . . . . . . . . . . . . . . . . .  345
electrolyte level . . . . . . . . . . . . . . . . . . . . . . . . . . . .  344
energy management . . . . . . . . . . . . . . . . . . . . . . .  347
replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  345

A

ACC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  188
Access aid for the third row . . . . . . . . . . . . . . . . . . . .  117
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  375
Activating SEAT CONNECT . . . . . . . . . . . . . . . . . . .  245
Adapting the playback volume . . . . . . . . . . . . . . .  263
Adaptive Cruise Control . . . . . . . . . . . . . . . . . . . . . .  188

control and warning lamp . . . . . . . . . . . . . . . . . .  193
malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  193
operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  190
special driving situations . . . . . . . . . . . . . . . . . . . .  191
status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  190
System limitations . . . . . . . . . . . . . . . . . . . . . . . . . .  192

AdBlue®

control and warning lamps . . . . . . . . . . . . . . . . .  315
information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  313
loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  314
minimum filling capacity . . . . . . . . . . . . . . . . . . . .  313
specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  314
tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  313

Adjust

fold down the front passenger’s backrest . . .  109
front seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  108
headrest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  113
lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  124
rear seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  111
seat with memory . . . . . . . . . . . . . . . . . . . . . . . . . . .  115
seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  39
time and date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  30

Adjusting the seat belt . . . . . . . . . . . . . . . . . . . . . . . . .  45
Air conditioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  132

air recirculation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  137
controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  134
Infotainment system settings . . . . . . . . . . . . . . . .  137
manual air conditioning . . . . . . . . . . . . . . . . . . . . .  136
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  141

Air recirculation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  137
Airbag system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  49

activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  50
control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  51
deactivation of the front airbag . . . . . . . . . . . . . .  52
description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  49
front airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  51
how it works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  50

Airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  49

activating and deactivating . . . . . . . . . . . . . . . . .  52
description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  49
for the head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  54
for the knees . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  55
front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  51
side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  53

Android Auto™

disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  253
establish connection . . . . . . . . . . . . . . . . . . . . . . .  253
menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  253

requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  253
special characteristics . . . . . . . . . . . . . . . . . . . . .  253

Anti-lock brake system . . . . . . . . . . . . . . . . . . . . . . . .  177
Anti-puncture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  363
Anti-puncture kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  363

check after 10 minutes . . . . . . . . . . . . . . . . . . . . .  366
components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  364
inflating the tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . .  365
sealing the tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . .  365

Anti-puncture set . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  363
Anti-theft alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  91

interior monitoring and anti-tow system . . . . .  92
trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  301

Anti-theft alarm system . . . . . . . . . . . . . . . . . . . . . . . .  91
Anti-trap function

glass roof sun blind . . . . . . . . . . . . . . . . . . . . . . . . .  104
sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  103
windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  101

Antifreeze . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  334
Apple CarPlay

disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  252
establish connection . . . . . . . . . . . . . . . . . . . . . . .  252
menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  252
requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  252
special characteristics . . . . . . . . . . . . . . . . . . . . .  252

Applications (apps) . . . . . . . . . . . . . . . . . . . . . . . . . . .  252
Approved spare parts . . . . . . . . . . . . . . . . . . . . . . . .  369
Area View system . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  185
Aspects to think about before starting the vehicle
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  38
Assistance systems

adaptive cruise control . . . . . . . . . . . . . . . . . . . . .  188
area view system . . . . . . . . . . . . . . . . . . . . . . . . . . .  185
Auto-Hold function . . . . . . . . . . . . . . . . . . . . . . . . . .  211
connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  181
cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  185

CarManuals2.com

392

Index

driver alert system . . . . . . . . . . . . . . . . . . . . . . . . . . .  25
driving assist (Travel Assist) . . . . . . . . . . . . . . . . .  201
Emergency Assist . . . . . . . . . . . . . . . . . . . . . . . . . .  204
emergency braking (Front Assist) . . . . . . . . . . .  196
front camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  183
front radar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  182
general notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  181
Hill Hold Control (HHC) . . . . . . . . . . . . . . . . . . . . . .  171
lane departure warning (Side Assist) . . . . . . .  205
parking aid Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  214
peripheral view system (Top View Camera) .  229
PreCrash system . . . . . . . . . . . . . . . . . . . . . . . . . . . .  47
predictive speed adjustment . . . . . . . . . . . . . . .  194
rear parking aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  217
rear radar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  183
road signs detection system . . . . . . . . . . . . . . . . .  27
safety advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  181
speed limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  187
switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  181
system limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  181
Trailer assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  233
tyre pressure monitor indicator . . . . . . . . . . . . .  362
tyre pressure monitoring . . . . . . . . . . . . . . . . . . .  363
ultrasound sensors . . . . . . . . . . . . . . . . . . . . . . . . .  184

Assisted start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  320
Audible warning

lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  120
unbuckled seat belt . . . . . . . . . . . . . . . . . . . . . . . . .  42

Audio warning signals

warning and control lamps . . . . . . . . . . . . . . . . . . .  11

Auto Lock (central locking) . . . . . . . . . . . . . . . . . . . . .  88
Auto Unlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  88
Auto-Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  211
Auto-Hold function . . . . . . . . . . . . . . . . . . . . . . . . . . . .  211
Automatic car wash . . . . . . . . . . . . . . . . . . . . . . . . . .  370

disconnecting the Auto-Hold function . . . . . . .  211

Automatic dipped beam headlight control . . . .  119
Automatic gearbox

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  164
downhill assistant . . . . . . . . . . . . . . . . . . . . . . . . . . .  171
driving tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  167
launch-control program . . . . . . . . . . . . . . . . . . . .  168
selector lever positions . . . . . . . . . . . . . . . . . . . . .  164
steering wheel with shift paddles . . . . . . . . . . .  166
tiptronic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  166

Auxiliary heating

activate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  145
connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  142
electricity consumers . . . . . . . . . . . . . . . . . . . . . . .  141
programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  145
radio-operated remote control . . . . . . . . . . . . .  143
special characteristics . . . . . . . . . . . . . . . . . . . . . .  141
switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  142

Average fuel consumption . . . . . . . . . . . . . . . . . . . . .  16

B

Backrest of the rear seat

folding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  112
raise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  112

Bag hooks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  240, 296
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  84
Before starting the vehicle . . . . . . . . . . . . . . . . . . . . .  38
Belt force limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  46
Belt tightening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  46
Bicycle carrier

fitting onto the coverable tow hook . . . . . . . . .  307
max. load rating . . . . . . . . . . . . . . . . . . . . . . . . . . . .  307

Biodiesel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  313
Blown bulbs

change a bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  330

Bonnet

opening and closing . . . . . . . . . . . . . . . . . . . . . . . .  333

Brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  337
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  175

brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  337
brake servo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  175
braking assistant . . . . . . . . . . . . . . . . . . . . . . . . . . . .  177
electronic parking brake . . . . . . . . . . . . . . . . . . . .  210
new brake pads . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  175

Braking assistant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  177
Braking system

warning lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  176

Brands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  264

C

Camera

cleaning the vehicle . . . . . . . . . . . . . . . . . . . . . . . . .  28

Catalytic converter . . . . . . . . . . . . . . . . . . . . . . . . . . .  316
Central armrests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  116
Central locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  87

anti-theft alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  91
auto-locking due to involuntary opening . . . . .  88
central locking switch . . . . . . . . . . . . . . . . . . . . . . .  89
emergency lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  94
Keyless Access system . . . . . . . . . . . . . . . . . . . . . .  85
remote control key . . . . . . . . . . . . . . . . . . . . . . . . . .  89

Cetane index (diesel fuel) . . . . . . . . . . . . . . . . . . . . .  313
Change a bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  330
Change the wiper blades . . . . . . . . . . . . . . . . . . . . .  318
Changing a wheel . . . . . . . . . . . . . . . . . . . . . . . . . . .  356

raise the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . .  360
subsequent work . . . . . . . . . . . . . . . . . . . . . . . . . . .  361
wheel nuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  359

Changing parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  375
Changing the battery

of the vehicle key . . . . . . . . . . . . . . . . . . . . . . . . . . . .  84

CarManuals2.com

Index

393

Charging cable

for charging stations (AC) . . . . . . . . . . . . . . . . . . .  80
for sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  80

Charging socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  73
Charging the high-voltage battery

charging cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  80
charging modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  71
charging process display . . . . . . . . . . . . . . . . . . . .  74
emergency unlocking . . . . . . . . . . . . . . . . . . . . . . . .  76
Infotainment system settings . . . . . . . . . . . . . . . . .  77
programmed charging . . . . . . . . . . . . . . . . . . . . . . .  78
socket (AC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  73
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  75

Check lists

requirements for Android Auto™ . . . . . . . . . . . .  253
requirements for Apple CarPlay . . . . . . . . . . . .  252
requirements for MirrorLink® . . . . . . . . . . . . . . . .  254
reverse assist (Rear View) . . . . . . . . . . . . . . . . . .  226

Child lock

electric windows . . . . . . . . . . . . . . . . . . . . . . . . . . . .  99

Child seats

attachment systems . . . . . . . . . . . . . . . . . . . . . . . . .  58
group classification . . . . . . . . . . . . . . . . . . . . . . . . .  56
i-Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  59
ISOFIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  59
safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . .  57
securing with the seat belt . . . . . . . . . . . . . . . . . . .  63
Top Tether system . . . . . . . . . . . . . . . . . . . . . . .  62, 63

Cleaning

high pressure cleaning equipment . . . . . . . . . .  370
special care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  373
vehicle exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  371
vehicle interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  372
washing the vehicle . . . . . . . . . . . . . . . . . . . . . . . .  370

Climate control

rear controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  137
setting the temperature . . . . . . . . . . . . . . . . . . . . .  137
stationary air conditioning . . . . . . . . . . . . . . . . . .  145
windscreen heating . . . . . . . . . . . . . . . . . . . . . . . .  140

Clocks

set the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  30

Closing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  87

bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  333
rear lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  102
windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Clutch (lamp) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  170
Coming Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  123
Connectivity

WLAN access point . . . . . . . . . . . . . . . . . . . . . . . . .  249

Control and warning lamps

12-volt battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  346
ACC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  193
adaptive cruise control . . . . . . . . . . . . . . . . . . . . .  190
AdBlue® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  315
air conditioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  141
airbag system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  51
airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  52
anti-lock brake system ABS . . . . . . . . . . . . . . . . .  179
automatic gearbox . . . . . . . . . . . . . . . . . . . . . . . . .  164
braking system . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  176
cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  187
cruise control (GRA) . . . . . . . . . . . . . . . . . . . . . . . .  185
drive system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  159
E-MODE operating mode . . . . . . . . . . . . . . . . . . .  161
electromechanical steering . . . . . . . . . . . . . . . . .  172
emissions control . . . . . . . . . . . . . . . . . . . . . . . . . . .  317
engine coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  20
engine management . . . . . . . . . . . . . . . . . . . . . . .  317
engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  343

ESC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  179
ESC in Sport mode . . . . . . . . . . . . . . . . . . . . . . . . . .  178
ESC off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  178
fuel reserve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  18
high-voltage battery . . . . . . . . . . . . . . . . . . . . . . . . .  75
high-voltage system . . . . . . . . . . . . . . . . . . . . . . . . .  75
hill descent control . . . . . . . . . . . . . . . . . . . . . . . . . .  171
Lane Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . .  200, 201
lane departure warning (Side Assist) . . . . . . .  206
lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  119
parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  211
particulate filter . . . . . . . . . . . . . . . . . . . . . . . .  316, 317
press on the brake . . . . . . . . . . . . . . . . . . . . . . . . . .  188
refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  18, 311
remote control (independent heating) . . . . . .  143
seat belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  42
speed limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  188
Start-Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  161
steering column . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  172
TCS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  179
tow hook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  306
tyre pressure monitor system . . . . . . . . . . . . . . .  363

Control lamps

overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  11

Controls

rear seat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  111

Controls on the steering wheel . . . . . . . . . . . . . . .  106
Convenience close function

sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  103

Convenience open function

sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  103

Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  132
Cooling system

check the coolant . . . . . . . . . . . . . . . . . . . . . . . . . .  336
refilling coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . .  336

Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  264

CarManuals2.com

394

Index

Cornering light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  120
Correct position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  39

driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  39
passenger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  40

Cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  185
Cruise control system . . . . . . . . . . . . . . . . . . . . . . . . .  185

control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  187
operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  186

Current documentation attached . . . . . . . . . . . .  256

D

Dangers of not using the seat belt . . . . . . . . . . . . .  43
Data label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  384
Data transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  244
Deactivating SEAT CONNECT services . . . . . . .  247
Deactivation of the front airbag . . . . . . . . . . . . . . . .  52
Diesel

refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  313

Disposal

seat belt tensioners . . . . . . . . . . . . . . . . . . . . . . . . . .  47

Door cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  93
Door handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  93
Door lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  93
Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  93

child lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  95

Downhill assistance function . . . . . . . . . . . . . . . . . .  171
downhill assistant . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  171
Drawers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  240
Drink holder

bottle holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  239
front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  239
in the rear central armrest . . . . . . . . . . . . . . . . . .  239

Drive system

control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  159

Driver alert system . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  25

Driving

driving on flooded roads . . . . . . . . . . . . . . . . . . . .  151
economical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  148
loaded vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  150
safe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  38
trips abroad . . . . . . . . . . . . . . . . . . . . . . . . . . . .  124, 152
with the luggage compartment open . . . . . . .  150
with trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  304

Driving Assist (Travel Assist)

see Travel Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . .  201

Driving data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  23
Driving data indicator . . . . . . . . . . . . . . . . . . . . . . . . . .  23
Driving mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  175
Driving on flooded roads . . . . . . . . . . . . . . . . . . . . . .  151
Driving profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  175
Driving with a loaded vehicle . . . . . . . . . . . . . . . . .  150
Driving with the luggage compartment open .  150
DSG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  164
Duplicate keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  83
Dust and pollen filter . . . . . . . . . . . . . . . . . . . . . . . . . .  132
Dynamic headlight range control . . . . . . . . . . . . .  124

E

e-Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  66
E-Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  159
E-MODE operating mode

control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  161

E10

see Ethanol (fuel) . . . . . . . . . . . . . . . . . . . . . . . . . . .  313

Easy Open

special characteristics . . . . . . . . . . . . . . . . . . . . . .  98

Eco-driving notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  29
Electric devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  241
Electric windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  99
Electrolyte . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  344
Electronic differential lock . . . . . . . . . . . . . . . . . . . . .  177

Electronic immobilizer . . . . . . . . . . . . . . . . . . . . . . . .  156
Electronic parking brake . . . . . . . . . . . . . . . . . . . . . .  210

control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  211

Electronic Stability Control (ESC) . . . . . . . . . . . . .  177
Emergencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  66

anti-puncture kit . . . . . . . . . . . . . . . . . . . . . . . . . . .  363
changing a wheel . . . . . . . . . . . . . . . . . . . . . . . . . .  356
changing the battery . . . . . . . . . . . . . . . . . . . . . . .  345
emergency vehicle towing . . . . . . . . . . . . . . . . . .  322
hazard warning lights . . . . . . . . . . . . . . . . . . . . . . . .  65
jump leads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  320
replace a blown fuse . . . . . . . . . . . . . . . . . . . . . . .  328
vehicle tool kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  318

Emergency Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . .  204

connecting and disconnecting . . . . . . . . . . . . .  204
problems and solutions . . . . . . . . . . . . . . . . . . . .  205
see Emergency Assist . . . . . . . . . . . . . . . . . . . . . .  204
status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  204

Emergency braking assist system . . . . . . . . . . . . .  182

activating and deactivating . . . . . . . . . . . . . . . .  198
status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  196
system limitations . . . . . . . . . . . . . . . . . . . . . . . . . . .  197
temporarily deactivating . . . . . . . . . . . . . . . . . . .  199
warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  196

Emergency braking warning . . . . . . . . . . . . . . . . . . .  65
Emergency call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  66
Emergency call service . . . . . . . . . . . . . . . . . . . . . . . .  66
Emergency locking of the front passenger door
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  94
Emergency opening

driver's door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  93
rear lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  99

Emergency operation

front passenger door . . . . . . . . . . . . . . . . . . . . . . . .  94

CarManuals2.com

Index

395

Emissions control system

AdBlue® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  313
catalytic converter . . . . . . . . . . . . . . . . . . . . . . . . .  316
control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  317
particulate filter . . . . . . . . . . . . . . . . . . . . . . . . . . . .  316

Energy management . . . . . . . . . . . . . . . . . . . . . . . . .  347
Engine

noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  154
running in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  151
start (driver instructions with the mechanical
contact) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  157
Start-Stop system . . . . . . . . . . . . . . . . . . . . . . . . . . .  161

Engine and ignition

emergency start . . . . . . . . . . . . . . . . . . . . . . . . . . . .  157
preheat the engine . . . . . . . . . . . . . . . . . . . . . . . . .  154
starting the engine . . . . . . . . . . . . . . . . . . . . . . . . . .  154
starting the engine with Press & Drive . . . . . . .  154
switching off the engine . . . . . . . . . . . . . . . . . . . . .  155

Engine compartment

battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  343
engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  341
opening and closing . . . . . . . . . . . . . . . . . . . . . . . .  333
safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . .  331

Engine coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  334

check the level . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  336
exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  22
specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  334
tank (hybrid vehicles) . . . . . . . . . . . . . . . . . . . . . .  335
temperature indicator . . . . . . . . . . . . . . . . . . . . . . . .  20
warning lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  20

Engine failure

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  317

Engine management . . . . . . . . . . . . . . . . . . . . . . . . . .  315

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  317

Engine oil

change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  339, 342
check the oil level . . . . . . . . . . . . . . . . . . . . . . . . . . .  341
consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  341
dipstick . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  341
inspection service . . . . . . . . . . . . . . . . . . . . . . . . . .  339
maintenance frequencies . . . . . . . . . . . . . . . . . .  339
refill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  341
specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  339

Engine oil pressure

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  343

Engine specifications . . . . . . . . . . . . . . . . . . . . . . . . .  386
Environment

ecological driving . . . . . . . . . . . . . . . . . . . . . . . . . .  148
environmental compatibility . . . . . . . . . . . . . . . .  378
recycling of electrical appliances . . . . . . . . . .  378
refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  310

Environmental tip

refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  310

ESC

connecting and disconnecting . . . . . . . . . . . . . .  178
electronic stability control (ESC) . . . . . . . . . . . .  177
Sport mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  178

Ethanol (fuel) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  313
Event Data Recorder . . . . . . . . . . . . . . . . . . . . . . . . .  377
Exhaust gases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  315
Exiting a parking space

with the parking assist system . . . . . . . . . . . . . .  225

Exterior lighting

change a bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  330

Exterior mirrors

driving with a trailer . . . . . . . . . . . . . . . . . . . . . . . .  300
folding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  130
heated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  130
settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  130

External antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  375

External audio sources

adapting the playback volume . . . . . . . . . . . . .  263

F

Fabrics: clean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  372
Factors that have a negative influence on safe
driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  38
Fastening rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  295
Filling capacities

AdBlue® tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  313
window washer water . . . . . . . . . . . . . . . . . . . . . .  338

Filling the tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  311
Fire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  66
Four-wheel drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  151
Frequency bands . . . . . . . . . . . . . . . . . . . . . . . . . . . .  269
Front bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  331
Front camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  183
Front compartment

brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  337
coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  334, 336
windscreen washer reservoir . . . . . . . . . . . . . . .  338

Front passenger front airbag

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  51

Fuel

diesel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  313
ethanol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  313
fuel gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  18
identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  312
petrol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  312
refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  311
saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  148

Fuel consumption

inertia disconnection . . . . . . . . . . . . . . . . . . . . . . .  148
why does consumption increase? . . . . . . . . . . .  317

Fuel gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  18

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  18

CarManuals2.com















Content      ..     10      11      12      13     ..
