Wheels and tyres

331

Tyre repair

Tyre repair

TMS (Tyre Mobility System) puncture
repair kit

The puncture repair kit (Tyre Mobility System)
will reliably seal punctures caused by the pen-
etration of a foreign body of up to about

4 mm

in diameter.

Do not remove foreign objects,

e.g. screws or nails, from the tyre.

After inserting the sealant residue in the tyre,
you must again check the tyre pressure about
10 minutes after starting the engine.
You should only use the tyre mobility set if the
vehicle is parked in a safe place, you are famil-
iar with the procedure and you have the nec-
essary tyre mobility set. Otherwise, you should
seek professional assistance.

Do not use the tyre sealant in the following
cases:

●

If the wheel rim has been damaged.

●

In outside temperatures below -20°C (-4°F).

●

In the event of cuts or perforations in the tyre

greater than 4 mm.

●

If you have been driving with very low pres-

sure or a completely flat tyre.

●

If the sealant bottle has passed its use by

date.

WARNING

Using the puncture repair kit can be danger-
ous, particularly when filling the tyre on the
roadside. To reduce the risk of serious injury,
consider the following:

●

Stop the vehicle safely as soon as possible.

Park it at a safe distance from surrounding
traffic to fill the tyre.

●

Ensure the ground on which you park is flat

and solid.

●

All passengers and particularly children

must keep a safe distance from the work
area.

●

Turn on the hazard warning lights to warn

other road users.

●

Always stop the engine, apply the elec-

tronic parking brake and put it in gear if fitted
with a manual gearbox, or press the parking
lock button P if fitted with an automatic gear
box, to reduce the risk of involuntary move-
ment of the vehicle .

●

Use the tyre mobility system only if you

are familiar with the necessary procedures.
Otherwise, you should seek professional as-
sistance.

●

The tyre mobility set is intended for tempo-

rary emergency use only until you can reach
the nearest specialised workshop.

●

Replace the repaired tyre with the tyre mo-

bility set as soon as possible.

●

The sealant is a health hazard and must be

cleaned immediately if it comes into contact
with the skin.

●

Always keep the tyre mobility set out of the

reach of small children.

WARNING

A tyre filled with sealant does not have the
same performance properties as a conven-
tional tyre.

●

Never drive faster than 80 km/h (50 mph).

●

Avoid heavy acceleration, hard braking

and fast cornering.

●

Drive for only 10 minutes at a maximum

speed of 80 km/h (50 mph) and then check
the tyre.

For the sake of the environment

Dispose of used or expired sealant observing
any legal requirements.

Note

A new bottle of sealant can be purchased at
SEAT dealerships.

Note

Take into account the separate instruction
manual provided by the tyre mobility system
manufacturer.

CarManuals2.com

332

Wheels and tyres

Anti-puncture kit contents

Fig. 227

Standard display: contents of the

anti-puncture kit.

The anti-puncture kit is located underneath the
floor covering in the luggage compartment. In-
cludes the following components

›››

Fig. 227

Valve insert remover
A sticker to be adhered to the instrument
cluster, within the driver's visual field, to re-
mind that the maximum advisable speed
“max. 80 km/h” or “max. 50 mph”
Filler tube with cap
Air compressor (depending on the version,
the model may vary).
ON/OFF switch
Air bleed screw (it can also be integrated in
the inflator tube).

Warning provided by tyre pressure monitor-
ing system (it can also be integrated in the
inflator tube).
Tube for inflating tyres
12 volt connector
Bottle of sealant
Spare tyre valve

The

valve insert remover

has a gap at the

lower end for a valve insert. The valve insert can
only be screwed or unscrewed in this way. This
also applies to its replacement part

Sealing and inflating a tyre

Sealing the tyre

●

Unscrew the tyre valve cap and insert. Use

the device

›››

Fig. 227

to remove the valve

cap. Place it on a clean surface.

●

Shake the tyre sealant bottle vigorously

›››

Fig. 227

●

Screw the tyre inflation hose

›››

Fig. 227

into the tyre sealant bottle. The bottle's seal will
break automatically.

●

Remove the filler cap

›››

Fig. 227

and

screw the open end of the tube into the tyre
valve.

●

With the bottle upside down, empty

all

of the

contents into the tyre.

●

Remove the bottle from the valve.

●

Replace the howitzer with the device

›››

Fig. 227

onto the tyre valve.

Inflating the tyre

●

Screw the tyre inflation tube of the compres-

sor

›››

Fig. 227

on the tyre valve.

●

Check that the air evacuation screw is

closed

›››

Fig. 227

●

Start the engine and leave it running.

●

Attach the connector

›››

Fig. 227

to the

vehicle’s 12 volt power outlet

›››

page 212

●

Switch on the air compressor with ON/OFF

switch

›››

Fig. 227

●

Keep the air compressor running until it rea-

ches a pressure of 2.0-2.5 bar (29-36 psi/
200-250 kPa).

A maximum of 8 minutes

●

Disconnect the air compressor.

●

If it does not reach the pressure indicated,

unscrew the tyre inflator tube from the valve.

●

Move the vehicle 10m so that the sealant is

distributed throughout the tyre.

●

Screw the compressor tyre inflator into the

valve.

●

Repeat the inflation process.

●

If it still does not come up to pressure, the

tyre is too badly damaged. Stop and seek as-
sistance from authorised personnel.

●

Disconnect the air compressor. Unscrew the

tyre inflation tube from the tyre valve.

CarManuals2.com

Wheels and tyres

333

Tyre repair

●

When the tyre pressure is between 2.5 and

2.0 bars, continue driving without exceeding
80 km/h (50 mph).

●

Attach the sticker

›››

Fig. 227

to the instru-

ment panel display, within the driver's field of
vision.

●

Check the pressure again after 10 minutes

›››

page 333

WARNING

When inflating the wheel, the air compressor
and the inflator tube may become hot.

●

Protect hands and skin from hot parts.

●

Do not place the hot flexible inflator tube

or hot air compressor on flammable material.

●

Allow them to cool before storing the de-

vice.

●

If it is not possible to inflate the tyre to at

least 2.0 bars (29 psi / 200 kPa), the tyre is
too badly damaged. The sealant is not in a
good condition to seal the tyre. Do not con-
tinue driving. Seek specialist assistance.

NOTICE

Switch off the air compressor after a maxi-
mum of 8 operational minutes to avoid over-
heating! Before switching on the air com-
pressor again, let it cool for several minutes.

Check after 10 minutes of driving

Screw in the inflator tube

›››

Fig. 227

again

and check the pressure on the gauge

1.3 bar (19 psi / 130 kPa) and lower:

●

Stop the vehicle!

The tyre cannot be sealed

sufficiently with the tyre mobility set.

●

You should obtain professional assistance

›››

1.4 bar (20 psi/140 kPa) and higher:

●

Set the tyre pressure to the correct value

again.

●

Carefully resume your journey until you reach

the nearest specialised workshop without ex-
ceeding 80 km/h (50 mph).

●

Have the damaged tyre replaced.

WARNING

Driving with an unsealed tyre is dangerous
and can cause accidents and serious injury.

●

Do not continue driving if the tyre pressure

is 1.3 bar (19 psi / 130 kPa) and lower.

●

Seek specialist assistance.

CarManuals2.com

334

Maintenance

Maintenance

Service

Service work and the Digital Mainte-
nance Plan

Log of services performed (“Digital Mainte-
nance Plan”)

The SEAT dealership or a specialised workshop
records Service receipts in a central system.
Thanks to this comprehensive documentation
of the service history, it is possible to reproduce
the services performed any time. SEAT recom-
mends requesting a Service receipt after every
service carried out containing all the services
carried out on the system.
Whenever there is a new service the receipt is
replaced with a current one.

The Digital Maintenance Plan is not availa-
ble in some markets. In this case, your SEAT
dealer will inform you about the current
documentation of the work.

Service works

In the Digital Maintenance Plan, your SEAT au-
thorised service or specialised workshop docu-
ments the following information:

●

When each one of the services was carried

out.

●

Whether a specific repair has been sugges-

ted, e.g. changing the brake pads in the near
future.

●

If you have expressed a special request for

the maintenance. Your Service Advisor will write
the work order.

●

The components or fluids that were changed.

●

The date of the next service.

The Long Life Mobility Warranty is valid until the
next inspection. This information is documented
in all checks performed.
The type and the volume of the service may
vary from one vehicle to another. A specialised
workshop will be able to provide specific infor-
mation on the jobs for your vehicle.

WARNING

If the services are insufficient or not per-
formed and if the service intervals are not
observed, the vehicle may be immobilised in
traffic cause an accident and severe injuries.

●

Make sure that any repairs are carried out

by a SEAT authorised service or specialised
workshop.

NOTICE

SEAT cannot be held liable for any damage
to the vehicle due to insufficient work or of
lack of availability of spare parts.

Note

Regular services on the vehicle not only
maintain its value, but also its correct opera-
tion and road safety. For this reason, conduct
the services in accordance with SEAT guide-
lines.

Set Service or Flexible Service Inter-
vals

Services are classified as

oil change service

and

inspection

. The service interval display

on the instrument panel display serves as a re-
minder of the next service.
Depending on the features, the engine and the
conditions of use of the car, either the

Fixed

service

or the

Flexible service

will be applied

for an oil change service..

How to know which type of service needs to
his vehicle

Check the tables below:

CarManuals2.com

Maintenance

335

Service

Oil change service

PR No.

Type of
service

Service interval

QI1

Fixed

Every

5000 km

or after

1 year

QI2

Every

7500 km

or after

1 year

QI3

Every

10000 km

or after

1 year

QI4

Every

15000 km

or after

1 year

QI6

Flexible

According to the service in-
terval display.

The data are based on normal conditions of use.

Whatever happens first.

Inspection Service

According to the service interval display.

The data are based on normal conditions of use.

Particular characteristics of the Flexible
Service

Regarding the

Flexible Service

the oil change

service only has to be performed when the ve-
hicle needs it. To calculate when you have to
carry out this service, take into account the in-
dividual conditions of use and personal driving

style. A major component of the flexible service
the use of LongLife oil instead of conventional
engine oil.
Bear in mind the information about the specifi-
cations of the engine oil according to the VW
standard

›››

page 308

If you do not want to the flexible service you
can select the fixed service. However, a fixed
service may affect service costs.

The Service

Advisor will gladly advise you.

At SEAT, the dates of the services are indicated
by the service intervals display:

●

on the instrument panel

›››

page 28

●

in the infotainment system: menu

> Set-

tings > Service

;

> Vehicle sta-

tus > Service

›››

page 34

The service interval display gives information
for service dates that involve an engine oil
change or an inspection. When the time for the
corresponding service comes, additional work
required, such as the change of brake fluid and
the spark plugs, can be carried out.

Information about the terms of use

The service intervals and groups are usually
based on

normal conditions of use

If, on the other hand, the vehicle is under

ad-

verse conditions of use

, some of the work

must be carried out before the next service pe-
riod or even between service intervals.

Conditions of use adverse include:

●

The use of fuel with a high sulphur content.

●

Frequent short trips.

●

Letting the engine idle for a long period of

time, as in the case of taxis.

●

Using the vehicle in areas with thick dust.

●

Frequent driving with a trailer (depending on

equipment).

●

Using the vehicle mostly in situations with a

lot of traffic and stops (e.g. in the city).

●

Using the vehicle mostly in winter.

This applies especially for the following
parts (depending on equipment):

●

Dust and pollen filter

●

Air Care allergen filter

●

Air filter

●

Toothed chain

●

Particulate filter

●

Engine oil

The Service Advisor of your specialised
workshop will gladly inform you

about the

need of performing service work between nor-
mal service intervals, always considering the
conditions of use of your vehicle.

CarManuals2.com

336

Maintenance

WARNING

If the services are insufficient or not per-
formed and if the service intervals are not
observed, the vehicle may be immobilised in
traffic and cause accidents and severe inju-
ries.

●

Have the services conducted at authorised

SEAT services or specialised workshops.

NOTICE

SEAT cannot be held liable for any damage
to the vehicle due to insufficient work or of
lack of availability of spare parts.

Service sets

Sets of services include all the

maintenance

works

needed to ensure the safety and the

smooth running of the vehicle (

depending on

the conditions of use and the features of the
vehicle

, such as the engine, gearbox, or oper-

ating fluids).
Maintenance services are divided into

inspec-

tion

and

review

services. Consult the details of

the jobs required for your vehicle at:

●

Your SEAT authorised service

●

Your specialised workshop

Due to technical reasons (continuous develop-
ment of components) the sets of services may
vary. Your SEAT authorised service or special-
ised workshop is always receiving updates in
time.

Additional service offers

Approved spare parts

Original SEAT Spare Parts have been con-
ceived for their vehicles and approved by SEAT,
with a special emphasis on safety. These parts
correspond exactly to the manufacturer's re-
quirements in terms of design, accuracy of the
measurements and materials. The original SEAT
Spare Parts have been conceived exclusively
for your vehicle. For this reason, we always rec-
ommend the use of Original SEAT Spare Parts.
SEAT cannot be held liable for the safety and
suitability of parts from other manufacturers.

Approved spare parts

Approved spare parts, following the manufac-
turer's requirements, are an additional service
to you, offering the possibility of replacing com-
plete sets, such as: light engine, gearboxes,
heads, control units, electrical components,
etc.
These parts are,

approved parts

, and are the

same as the factory parts, which are also ap-
proved spare parts.

Original accessories

We recommend you only use SEAT Original Ac-
cessories and SEAT approved accessories for
your vehicle. The reliability, safety and suitabil-
ity of these accessories have been inspected
specifically for this type of vehicle. SEAT cannot
be held liable for the safety and suitability of
parts from other manufacturers.

Service Mobility

As of the moment you purchase your SEAT ve-
hicle you will be able to enjoy the benefits and
coverage of Service Mobility.
For the first two years after the purchase, your
new SEAT vehicle is automatically covered by
Service Mobility at no additional cost.
If you wish to enjoy this service after this period,
you can extend SEAT Service Mobility as long
as you carry out the recommended Inspection
and Maintenance Services at a SEAT Author-
ised Service.
If your SEAT vehicle is immobilised due to a fault
or an accident, our assistance services will help
you keep moving.
Take into account that the SEAT Mobility Serv-
ice differs depending on the country in which
the vehicle was purchased. For further informa-
tion ask your SEAT dealership or the SEAT web-
site in your country.

CarManuals2.com

Maintenance

337

Vehicle upkeep and cleaning

Vehicle upkeep and clean-
ing

Basic observations

Regular and careful care helps to maintain the
value of your vehicle. In addition, it may be-
come a prerequisite to demand the warranty
in the event of corrosion damage and deficien-
cies in the paint coat of the bodywork.
Specialised workshops have the necessary
care products. Please follow the instructions for
application on the packaging.

WARNING

●

Cleaning products and other materials

used for car care can be damaging to your
health if misused.

●

Always keep care products in a safe place,

out of the reach of children. Danger of poi-
soning!

For the sake of the environment

●

When purchasing car care products, chose

products that are compatible with the envi-
ronment.

●

The waste from car-care products should

not be disposed of with ordinary household
waste.

Washing the vehicle

The longer you take to clean the tanks, e.g. re-
mains of insects, bird excrements, tree resin or
anti frost salt adhered to your vehicle, the more
damage it can cause to the surface. High tem-
peratures, for instance strong sunlight, further
intensify the damage.
Before washing the car, soften the dirt using
plenty of water.
To remove encrusted dirt such as insects, bird
droppings or tree resin, use a lot of water and a
microfibre cloth.
Have the underside of the vehicle washed after
the end of the anti frost salts in winter.

High pressure cleaning equipment

When washing the vehicle with a high-pressure
cleaner, always follow the operating instruc-
tions for the equipment. This applies particu-
larly to the operating pressure and the distance
between the spraying water.
Do not aim the jet directly towards the side
windows, doors, sunroof or covers; the same
applies for the tyres, rubber hoses, damping
material, sensors or camera lenses. Keep a dis-
tance of at least 40 cm.
Do not remove snow and ice with a high-pres-
sure cleaner.
Do not use a nozzle that sprays the water out in
a direct stream or one that has a rotating jet for
forcing off dirt.

The water temperature must not exceed 60°C.

Automatic car washes

Spray the vehicle before starting the car wash.
Make sure that the windows and sunroof are
closed and the wipers are deactivated. Bear
in mind the instructions of the car wash tunnel
operator, especially if your vehicle has detach-
able parts.
Use of car washes without brushes if possible.

Washing by hand

Clean your vehicle from top to bottom with a
soft sponge or with a brush. Only use cleaning
products that do not contain solvents.

Polishing

Polishing is only necessary when the vehicle's
paintwork has lost its gloss and cannot be re-
stored with care products.
Do not polish matt painted surfaces! If the
paintwork is polished, the surface will be irrep-
arably damaged.

Washing vehicles with a matte paint by hand

To prevent damage to the vehicle when wash-
ing it, first remove the thicker dust and dirt.
To remove traces of insects, grease and finger-
prints, it is best to use a special cleaner for
matte paint.

CarManuals2.com

338

Maintenance

Neutral soap solution: maximum of two tablespoons in 1 l of water.

Apply the product with a microfibre cloth. To
avoid damaging the surface of the paint, do not
apply too much pressure.
Rinse with plenty of water. Then clean it with a
neutral cleaning product and a soft microfibre
cloth.
Rinse the vehicle again with plenty of water and
then leave it to dry. Remove traces of water
with a leather cloth.

WARNING

●

Only wash the vehicle with the ignition

switched off or according to the specifica-
tions of the car wash tunnel operator. Acci-
dent hazard!

●

When cleaning the underbody or the inside

of the wheel arches, protect yourself from
sharp or pointy metal parts. Risk of cut!

●

After cleaning the brakes could act more

slowly due to moisture or, in winter, the ice on
the brake discs and pads. Accident hazard!
In this case the brakes should be dried by
pressing the brake pedal several times.

WARNING

Incorrect use of high-pressure cleaning
equipment can cause damage. This can lead
to accidents and serious injuries.

●

Never direct the jet of the high-pressure

cleaning equipment directly at the orange
high-voltage cables, the high-voltage sys-
tem components or the 12-volt on-board net-
work.

NOTICE

●

Before washing the vehicle in an automatic

car wash, please make sure to retract the
exterior mirrors to prevent them from being
damaged. The electric folding exterior mir-
rors should only be folded/unfolded electri-
cally!

●

Do not wash the vehicle in direct sunlight.

Risk of damaging the paint job!

●

Do not use sponges, abrasive household

sponges or similar to clean insect remains.
Risk of damaging the surface!

●

Vehicle parts with matte paint:

–

Do not use polish or hard wax. Risk of

damaging the surface!

–

Never select washing programmes that

include the use of wax. This could damage
the appearance of matte paint.

–

Do not put stickers or magnets on parts

with matte paint, as removing them may
damage the paint.

For the sake of the environment

The car should only be washed in special
wash bays. These places are prepared to
prevent oily water from getting into the pub-
lic drains.

Cleaning the exterior

Below can be found some recommendations on
the cleaning and upkeep of individual vehicle
components.
Go to your specialised workshop if you have
special questions or parts that are not listed.
Take the general considerations into account

›››

page 340,

Take special care with...

Windscreen wipers

●

Dirt:

Soft cloth with windscreen cleaner.

Headlights / Tail lights

●

Dirt:

Soft sponge with neutral soap solution

CarManuals2.com

Maintenance

339

Vehicle upkeep and cleaning

Neutral soap solution: maximum of two tablespoons in 1 l of water.

Sensors / Camera lenses

●

Dirt:

–

Sensors

: soft cloth with a solvent-free

cleaning product.

–

Camera lenses

: soft cloth with an alcohol-

free cleaning product.

●

Snow/ice:

Hand brush/Solvent-free antifreeze

spray

Wheels

●

Antifreeze salt:

Water.

●

Brake abrasion dust:

Special acid-free clean-

ing product.

End exhausts

●

Antifreeze salt:

Water, if a fine steel cleaning

product is required, or a non-abrasive and non-
corrosive cleaning product.

Covers / Trims

●

Dirt:

Neutral soap solution

, if a fine steel

cleaning product is required.

Paint

●

Paint flaws:

Check the paint's colour code at

an authorised service and restore with a touch-
up pencil.

●

Spilled fuel:

Immediately rinse with water.

●

Tank with environmental rust:

Apply rust re-

mover and then apply hard wax. Go you your
specialised workshop if you have any queries.

●

Corrosion:

Have your specialised workshop

take care of this.

●

Water does not form droplets on the clean

paint:

Maintain with hard wax (at least twice a

year).

●

No shine despite maintenance/unattractive

paint:

Treat with suitable wax and apply paint

preservative afterwards if the wax used does
not contain preservative ingredients.

●

Tanks, e.g. insect remains, bird droppings, tree

sap, road salt:

Immediately soak with water and

remove with a microfibre cloth.

●

Grease-based dirt, e.g. cosmetic products or

sunscreen:

Remove immediately with a neutral

soap solution

and a soft cloth.

Carbon fibre parts

●

Dirt:

Clean in the same way as painted parts

›››

page 337

Decoration slides

●

Dirt:

Soft sponge with neutral soap solution

Interior cleaning

›››

page 340,

Take special care with...

Windows

●

Dirt:

Apply windscreen cleaner and then dry

with a cloth.

Covers / Trims

●

Dirt:

Neutral soap solution

Plastic parts

●

Dirt:

Damp cloth.

●

Encrusted dirt:

Neutral soap solution

, if possi-

ble a solvent-free plastic cleaning product.

Displays/instrument panel

●

Dirt:

Soft cloth with a liquid crystal display

cleaner.

Control panels

●

Dirt:

Soft brush, then a soft cloth with a neu-

tral soap solution

CarManuals2.com

340

Maintenance

Neutral soap solution: maximum of two tablespoons in 1 l of water.

Seat belts

●

Dirt:

Neutral soap solution

, allowed to dry

before retracting.

Fabrics, artificial, Alcantara leather

●

Particles of dirt stuck to surfaces:

Vacuum

cleaner.

●

Water-based dirt, e.g. coffee, tea, blood etc.:

Absorbent cloth and neutral soap solution

●

Grease-based dirt, e.g. oil, make-up, etc.:

Ap-

ply a neutral soap solution

. Absorb the dis-

solved grease and paint particles drying with
an absorbent cloth, in case you must treat it
with water afterwards.

●

Special dirt, e.g. pens, nail polish, dispersion

paint, shoe polish, etc.:

Special stain remove:

dry with an absorbent cloth, if applicable, ap-
ply neutral soap solution afterwards

Natural leather

●

Recent dirt:

Cotton cloth with neutral soap

solution

●

Water-based dirt, e.g. coffee, tea, blood etc.:

–

Recent stains:

absorbent cloth.

–

Dry stains:

stain remover suitable for

leather.

●

Grease-based dirt, e.g. oil, make-up, etc.:

–

Recent stains:

absorbent cloth and suitable

stain remover for leather.

–

Dry stains:

grease solvent spray.

●

Special dirt, e.g. pens, nail polish, dispersion

paint, shoe cream etc.:

Stain remover suitable

for leather.

●

Care:

Apply preservative cream regularly to

protect from sunlight. Use a coloured preserva-
tive if required.

Carbon fibre parts

●

Dirt:

Clean as with plastic parts.

Take special care with...

Headlights/tail lights

●

Do not clean the headlights/tail lights with a

dry cloth or sponge.

●

Do not use cleaning products that contain

alcohol. Risk of cracks!

Wheels

●

Do not use for paint wax or other abrasive

products.

●

If the protective coating on the paint of the

rim has been damaged due to stone impacts,
scratches, etc., the damage should be repaired
immediately.

Camera lenses

●

Do not use hot or warm water to remove ice

or snow from the camera lenses. Risk of crack-
ing the lens!

●

To clean the camera lens, never use abra-

sive cleaning products or products with alcohol.
Risk of scratches and cracks!

Windows

●

Remove snow and ice from windows and ex-

terior mirrors with a plastic scraper only. To
avoid scratches, the scraper should only be
pushed in one direction and not moved to and
fro.

●

Never remove snow or ice from windows and

rearview mirrors with warm or hot water. Risk of
cracks on the windows!

●

To prevent damage to the heating of the rear

window, do not put stickers over the heating
elements.

Covers/trims

●

Do not use cleaning products or chrome

based cleaning agents.

Paint

●

The vehicle must be free from dirt and dust

before applying wax or care products. Risk of
scratches!

CarManuals2.com

Maintenance

341

Vehicle upkeep and cleaning

●

Do not apply wax or care products if the vehi-

cle is exposed to direct sunlight. Risk of damag-
ing the paint job!

●

The ambient rust deposits must not be re-

moved through friction. Risk of damaging the
paint job!

●

Remove cosmetic products and sunlight im-

mediately. Risk of damaging the paint job!

Displays/instrument panel

●

The displays, the instrument panel and the

trim around it must not be cleaned dry. Risk of
scratches!

●

Make sure that the instrument panel is

switched off and cooled down before cleaning.

●

Make sure that no liquid leaks between the

instrument panel and the trim. Risk of damage!

Control panels

●

Make sure that no liquid leaks into the control

panels. Risk of damage!

Seat belts

●

Do not remove the seat belts to clean them.

●

Seat belts and their components must never

be cleaned with chemical products, nor should
they be allowed to come into contact with cor-
rosive liquids, solvents or sharp objects. Risk of
damaging the fabric!

●

If you find any damage to the belt webbing,

belt fittings, the belt retractor or the buckle, ask
your specialised workshop to replace the belt
in question.

Fabrics/artificial leather/microfibre

●

Do not treat artificial leather/microfibre with

leather cleaning products, solvents, wax polish,
shoe cream, stain removers or similar products.

●

If the stain is very hard to remove, take the

vehicle to a specialised workshop to have it re-
moved there. This will prevent damage.

●

Do not use steam cleaners, brushes, hard

sponges, etc. to clean.

●

Do not turn on seat heating to dry the seats.

●

Sharp objects on clothing, such as zips, rivets

or belts can damage the surface.

●

Open Velcro, e.g. on clothes can damage the

seat upholstery. Make sure that Velcro fasten-
ers are closed.

Natural leather

●

Never use solvents, wax polish, shoe cream,

spot removers or similar products on leather.

●

Sharp objects on clothing, such as zips, rivets

or belts can damage the surface.

●

Do not use steam cleaners, brushes, hard

sponges, etc. to clean.

●

Do not turn on seat heating to dry the seats.

●

Avoid exposing leather to direct sunlight for

long periods, otherwise it may tend to lose
some of its colour. If the car is left for a pro-
longed period in the bright sun, it is best to
cover the leather.

WARNING

Do not use water-repellent coatings on the
windscreen. In bad visibility conditions such
as humid weather, darkness or when the sun
is in its lowest point, visibility may be impac-
ted. Accident hazard! Such coatings can also
cause the windscreen wiper blades to make
noise.

Note

●

Remains of insects can be removed much

more easily with previously treated paint.

●

Regular car care treatments can prevent

deposits of ambient rust.

Remove the vehicle from traffic

If you want to leave your vehicle stationary
for a long period of time, contact a qualified
workshop. They will gladly inform you about
the necessary measures, such as anti-corrosion
protection, Service and storage.
Also take into account the indications relat-
ing to the vehicle’s battery

342

Maintenance

Accessories, spare parts
and repair work

Introduction

Always ask your dealer or specialist retailer for
advice before purchasing accessories and re-
placement parts.
Your vehicle is designed to offer a high standard
of active and passive safety. For this reason, we
recommend that you ask a SEAT Official Serv-
ice for advice before fitting accessories or re-
placement parts. Your SEAT Official Service has
the latest information from the manufacturer
and can recommend accessories and replace-
ment parts which are suitable for your require-
ments. They can also answer any questions
you might have regarding official regulations.
We recommend only using

SEAT accessories

and

genuine SEAT parts

®. SEAT has tested

these parts and accessories for suitability, reli-
ability and safety. SEAT Official Services have
the necessary experience and facilities to en-
sure that the parts are installed correctly and
professionally.
Although SEAT continuously monitors the mar-
ket, it cannot judge whether products

not au-

thorised by SEAT

meet the vehicle’s reliability,

safety and suitability requirements. SEAT there-
fore accepts no liability for these products,
even if, in certain cases, they are authorised
by an officially recognised technical inspection
institute or official body.

Any

retro-fitted equipment

which has a di-

rect effect on the vehicle and/or the way it
is driven, such as a cruise control system

electronically-controlled suspension

, must

be approved for use in your vehicle and bear
the

mark (the European Union's authorisation

symbol).
If

any additional electrical devices

are fitted

which do not serve to control the vehicle itself
(for instance a refrigerator box, laptop or venti-
lator fan, etc.), they must bear the marking
(manufacturer conformity declaration in the Eu-
ropean Union).

WARNING

Accessories, for example telephone holders
or cup holders, should never be fitted on the
covers, or within the working range of the air-
bags. Otherwise, there is a danger of injury if
the airbag is triggered in an accident.

Technical modifications

Unauthorised modifications to the electronic
components, software, wiring or data transfer
in the vehicle may cause malfunctioning.
You will appreciate that your SEAT dealership
cannot be held liable for any damage caused
by modifications and/or work performed incor-
rectly.
For this reason we recommend asking official
SEAT service centres to do any necessary work
using

genuine SEAT

parts®.

WARNING

Incorrectly performed modifications or other
work on your vehicle can lead to malfunc-
tions and cause accidents.

Radio telephones and office equip-
ment

Radio transmitters (fixed installation)

Any retrofit installations of radio transmitters
in the vehicle require prior approval. SEAT gen-
erally authorises in-vehicle installations of ap-
proved types of radio transmitters provided
that:

●

The antenna is installed correctly.

●

The aerial is installed on the exterior of the

vehicle (and shielded cables are used together
with non-reflective aerial trimming).

●

The effective transmitting power does not ex-

ceed 10 Watts at the aerial base.
A SEAT Official Service and specialised work-
shop will be able to inform you about options
for installing and operating radio transmitters
with a higher transmitting power.

Mobile radio transmitters

Commercial mobile telephones or radio equip-
ment might interfere with the electronics of your
vehicle and cause malfunctions. This may be
due to:

CarManuals2.com

Maintenance

343

Accessories, spare parts and repair work

●

No external aerial.

●

External aerial incorrectly installed.

●

Transmitting power more than 10 W.

You must, therefore, do not operate portable
mobile telephones or radio equipment

inside

the vehicle

without a properly installed external

aerial

›››

Please note also that the maximum range of
the equipment can only be achieved with an

external

aerial.

Business equipment

Retrofit installation of business or private equip-
ment in the vehicle is permitted, provided the
equipment cannot interfere with the driver's im-
mediate control of the vehicle and that any
such equipment carries the mark. Any retro-
fit equipment that could influence the driver's
control of the vehicle must have a type appro-
val for your vehicle and must carry the

mark.

WARNING

Mobile telephones or radio equipment which
is operated inside the vehicle without a prop-
erly installed external aerial can create ex-
cessive magnetic fields that could cause a
health hazard.

Note

●

The posterior fitting of electric and elec-

tronic equipment in this vehicle affects its li-
cence and could lead to the withdrawal of
the vehicle registration document under cer-
tain circumstances.

●

Please use the mobile telephone/radio op-

erating instructions.

CarManuals2.com

344

Information for the user

Information for the user

Warranty

Fault-free operation warranty

SEAT Authorised Services ensure the perfect
condition of new vehicles. Check the purchase
agreement or complementary additional docu-
mentation provided by your Technical Service
to see the conditions and the terms of the war-
ranty. Consult further information in this regard
in your SEAT Official Service.

Information stored by the
control units

Storage of accident data (Event Data
Recorder)

Your vehicle has an event data recorder (EDR).
The EDR’s function is to record data in the event
of a mild or serious accident. These data are
used to support the analysis of how different
vehicle systems behaved.
The EDR records, over a reduced time range
(normally 10 seconds or less), dynamic driving
data and data from the restraint systems, such
as:

●

How different vehicle systems worked.

●

Whether the driver and the occupants were

wearing their seat belts.

●

How hard the acceleration or brake pedal

was pressed.

●

Vehicle speed.

●

GPS position.

These data will provide a better understanding
of the circumstances of the accident.
Data from the driving assist systems are also
recorded. This includes data such as whether
the systems were inactive or active and if such
action had an impact on the vehicle’s dynamic
behaviour, changing its path in the aforemen-
tioned situations, accelerating or decelerating
the vehicle.
Depending on vehicle equipment, this includes
data from systems such as:

●

the adaptive cruise control

●

the lane assist system

●

parking assistants

●

the emergency brake functions.

The EDR data are only recorded in specific ac-
cident situations. No data are recorded in nor-
mal driving conditions.
No audio or video data inside or around the
vehicle are recorded. Under no circumstances
are personal data such as name, age, or gen-
der recorded. Nevertheless, third parties (such
as criminal proceedings authorities) may relate

the contents of the EDR data to other data
sources and create a personal reference in the
context of an accident investigation.
In order to read the EDR data it is necessary
to access (if legally permitted to do so) the
vehicle's ODB (“On-Board-Diagnose”) interface
while the vehicle is switched on.
SEAT will not have access to EDR data unless
the owner (or, in “Leasing” cases, the lessee or
hirer) gives their consent. There may be excep-
tions to this, depending on legal or contractual
provisions.
Due to legal requirements in safety-related
products, SEAT may use the EDR data for field
research and in order to improve vehicle system
quality. Any data used for the purposes of re-
search will be treated anonymously (in other
words, no reference will be made to the vehicle,
their owner or the lessee/hirer).

Vehicle antennas

Infotainment system and antennas

The infotainment system's antennas are instal-
led on different locations on the vehicle:

●

On the roof.

●

On the windscreen, between the layers of

glass.

●

On the rear and side windows with a printed

antenna structure

›››

CarManuals2.com

Information for the user

345

Materials and recycling information

NOTICE

The printed antenna structure on the rear
and side windows can be damaged by ob-
jects rubbing against it or by the use of
corrosive products, or products containing
acids.

●

Do not apply any stickers to the rear and

side window areas.

●

Never clean the antenna structure with

corrosive or acidic products.

Materials and recycling in-
formation

Environmental compatibility

Environmental protection is a top priority in the
design, choice of materials and manufacture of
your new SEAT.

Constructive measures to encourage recy-
cling

●

Joints and connections designed for easy

dismantling.

●

Modular construction to facilitate disman-

tling.

●

Increased use of single-grade materials.

●

Plastic parts and elastomers are marked in

accordance with ISO 1043, ISO 11469 and ISO
1629.

Choice of materials

●

Use of recycled materials.

●

Use of compatible plastics in the same part if

its components are not easily separated.

●

Use of recycled materials and/or materials

originating from renewable sources.

●

Reduction of volatile components, including

odour, in plastic materials.

●

Use of CFC-free coolants.

Ban on heavy metals, with the exceptions
dictated by law (Annex II of ELV Directive
2000/53/EC)

: cadmium, lead, mercury, hexa-

valent chromium.

Manufacturing methods

●

Reduction of the quantity of thinner in the

protective wax for cavities.

●

Use of plastic film as protection during vehi-

cle transport.

●

Use of solvent-free stickers.

●

Use of CFC-free coolants in cooling systems.

●

Recycling and energy recovery from residues

(RDF).

●

Improvement in the quality of waste water.

●

Use of systems for the recovery of residual

heat (thermal recovery, enthalpy wheels, etc.).

●

The use of water-soluble paints.

Recycling of electrical or electronic
devices

All electrical or electronic devices (EED) that
are not permanently fitted in the vehicle must
be marked with the following symbol:

This symbol indicates that EED must not be dis-
carded as home waste but through selective
waste collection.

Product recycling

CarManuals2.com

346

Information for the user

For the sake of the environment

The Triman logo and the Infotri symbol con-
tain important information for the classifica-
tion of the end consumer.

Italy. Environmental labelling

Legislative decree no. 116 (3 September 2020),
which transposes EU Directive 2018/851 on
waste, and EU Directive 2018/852 on packag-
ing and packaging waste, states that all pack-
aging must be properly labelled to facilitate
the collection, reuse, recovery and recycling of
packaging, and to give users correct informa-
tion about the final destination of the packag-
ing.
Information about the environmental labelling
of packaging present in the vehicle can be
accessed by scanning the following QR code,
which links to a website where the information
required by this regulation can be found:

Radioelectrical equipment

Simplified declaration of conformity

Your vehicle has different radioelectrical de-
vices. The manufacturers of these devices
declare that they comply with Directive
2014/53/EU when legally required.
The full text of the EU compliance declaration is
available online at the following address:

www.seat.com/generalinfo

United Kingdom

Your vehicle has different radioelectrical devi-
ces. The manufacturers of these devices de-
clare that they comply with the UK Radio
Equipment Regulations 2017 (SI 2017/1206) if
required by law.
The full text of the declaration of conformity
is available online at the following Internet ad-
dress:

www.seat.com/generalinfo

Ukraine

Your vehicle has different radioelectrical devi-
ces. The manufacturers of these devices de-
clare that they comply with Ukraine Decree
355/2017 (TR Radio Equipment) where legally
required.
The full text of the declaration of conformity
is available online at the following Internet ad-
dress:

www.seat.com/generalinfo

Addresses of the manufacturers

The address of the manufacturers of compo-
nents that, due to their size or nature, cannot
include a sticker are listed below, as long as it is
legally required:

Central control unit (BCM)

Robert Bosch GmbH/Braunschweig
Theodor-Heuss-Strasse 12
38122 - Braunschweig, Germany
Phone: 0049 53188890

Keyless Access System

HELLA GmbH & Co. KGaA/Hamm
Roemerstr. 66
59075 - Hamm, Germany
Phone: 0049 23817980

CarManuals2.com

Information for the user

347

Radioelectrical equipment

Roof antenna

ASK Industries S.p.A
Via dell'Industria n.12/14/16
60037 Monte San Vito (AN), Italy
Phone: +3907174521
Website: www.askgroup.it

Mitsumi Electronics Europe GmbH
Siemensstrasse 32
63225 Langen, Germany
Phone: +49 (0) 6103913-0
Website: www.minebeamitsumi.co.jp

Molex CVS Hildesheim GmbH
Daimlerring 31
31135 Hildesheim, Germany
Phone: +49 3377 3160
Website: www.molex.com

Antenna amplifiers

ASK Industries S.p.A
Via dell'Industria n.12/14/16
60037 Monte San Vito (AN), Italy
Phone: +3907174521
Website: www.askgroup.it

Hirschmann Car Communication GmbH
Stuttgarter Strasse 45-51
72654 Neckartenzlingen, Germany
Phone: +49 7127 140
Website: www.te.com

KATHREIN Automotive GmbH
Römerring 1

31137 Hildesheim, Germany
Phone: +498,031,184-0
Website: www.kathrein.com

Molex CVS Hildesheim GmbH
Daimlerring 31
31135 Hildesheim, Germany
Phone: +49 3377 3160
Website: www.molex.com

Navigation antenna

Hirschmann Car Communication GmbH
Stuttgarter Strasse 45-51
72654 Neckartenzlingen, Germany
Phone: +49 7127 140
Website: www.te.com

KATHREIN Automotive GmbH
Römerring 1
31137 Hildesheim, Germany
Phone: +498,031,184-0
Website: www.kathrein.com

Connectivity Box

Molex CVS Dabendorf GmbH
Märkische Strasse 72
15806 Zossen OT Dabendorf, Germany
Phone:+49 3377 3160
Website: www.molex.com

Basic infotainment system

Panasonic Automotive Systems Czech
U Panasonicu 266
530 06, Pardubice, Czech Republic

Optional infotainment system

LG Electronics Mlawa SP
LG Electronics 7
06 500, Mlawa

Remote control key

Digades GmbH Digitales Und Ana/Zittau
Äußere Weberstr. 20
02763 - Zittau, Germany
Phone: 0049 358357750

Instrument panel

Analogue SE38x/SE316

Visteon Electronics Germany GmbH
Visteonstr. 4-10
50170 Kerpen, Germany

Analogue all other models

Continental Automotive Spain, S.A.
Crta. de Rubí a Ullastrell, nº 12-30
08191 Rubí (Barcelona - Spain)

CarManuals2.com

348

Information for the user

The commissioning or authorisation of radioelectrical technology may be restricted in some European countries, forbidden or only allowed with additional
requirements.

FPK (digital)

Continental Automotive GmbH
VDO-Strasse 1,
64832 Babenhausen, Germany

Panasonic Automotive Systems Europe GmbH
Robert Bosch Str. 27-29
63225 Langen, Germany

Panasonic Automotive Systems Czech, s.r.o.
U Panasonicu 266
530 06, Pardubice, Czech Republic

Front radar sensors

MRR for SE38X

Robert Bosch GmbH
Markwiesenstrasse, 46
72770 Reutlingen (Kusterdingen) Germany

MRR for Tarraco, Ateca, Ibiza, Arona

Automotive Distance Control Systems GmbH
Peter-Dornier-Strasse, 10
88131, Lindau, Germany

Rear radar sensors

Hella GmbH & Co. KGaA
Rixbecker Straße 75
59552 Lippstadt (Germany)

Online Connectivity Unit

LG ELECTRONICS INC.
10, Magokjungang 10-ro,
Gangseo-gu, Seoul, Republic of Korea

Radio equipment, frequency band,
maximum transmitting power

Below can be found details of the radio equip-
ment

that can be fitted to all SEAT models.

Unless otherwise stated, the data are valid for
all models (variations are indicated in footnotes
to the tables):

Frequency band

Max. station
power

Key with radio-operated remote control
(vehicle)

433.05-434.78 MHz

10 mW (ERP)

433.05-434.79 MHz

10 mW

868.0-868.6 MHz

25 mW

434.42 MHz

32 µW

Radio-operated remote control (auxiliary
heater)

868.7-869.2 MHz (869.0 MHz)

25 mW

868.0-868.6 MHz (868.3 MHz)

3.1 mW

Valid for: Leon, Ateca, Tarraco

Valid for: Alhambra

Transmitter-Receiver (auxiliary heater)

868.7-869.2 MHz (869.0 MHz)

23.5 mW

868.0-868.6 MHz (868.3 MHz)

23.5 mW

Valid for: Leon, Ateca, Tarraco

Valid for: Alhambra

Bluetooth

2402-2480 MHz

6 dBm

2400-2483.5 MHz

10 dBm

CarManuals2.com

Information for the user

349

Radioelectrical equipment

Connection to the vehicle’s external an-
tenna

GSM 900: 880-915 MHz

33 dBm

GSM 1800: 1710-1785 MHz

30 dBm

WCDMA FDD I: 1920-1980 MHz

24 dBm

WCDMA FDD lll: 1710-1785 MHz

21 dBm

WCDMA FDD VIII: 880-915 MHz

21 dBm

LTE FDD1: 1920-1980 MHz

23 dBm

LTE FDD3: 1710-1785 MHz

23 dBm

LTE FDD7: 2500-2570 MHz

23 dBm

LTE FDD8: 880-915 MHz

23 dBm

LTE FFD20: 832-862 MHz

23 dBm

✓

Valid for: Tarraco, Leon

Connection to the vehicle’s external an-
tenna

GSM 900: 880-915 MHz

33 dBm

GSM 1800: 1710-1785 MHz

30 dBm

WCDMA FDD I: 1920-1980 MHz

24 dBm

✓

Valid for: Alhambra

Wireless hotspot

2400-2483.5 MHz

10 dBm

✓

Valid for: Leon, Ateca, Tarraco

Keyless Access

434.42 MHz

32 µW

✓

Valid for: Ibiza, Arona, Leon, Ateca, Tarraco

Radar sensors for front assist systems

76 GHz-77 GHz

28.2 dBm

35.0 dBm

Valid for: Leon, Alhambra

Valid for: Ibiza, Arona, Ateca, Tarraco

Radar sensors for rear assist systems

24050-24250 MHz

20 dBm

✓

Valid for: Ibiza, Arona, Leon, Ateca, Tarraco

Wireless charging function

110-120 kHz

5 W

✓

Valid for: Ibiza, Arona, Leon, Ateca, Tarraco

Instrument cluster

125 kHz

40 dBµA/m

Online Connectivity Unit

EGSM900: 880-915 MHz

33 dBm

DCS1800: 1710-1785 MHz

31 dBm

UMTS FDD 1: 1920-1980 MHz

24 dBm

UMTS FDD 3: 1710-1785 MHz

24 dBm

UMTS FDD 8: 880-915 MHz

24 dBm

E-UTRA FDD 1: 1920-1980 MHz

23.5 dBm

E-UTRA FDD 3: 1710-1785 MHz

23.0 dBm

E-UTRA FDD 7: 2500-2570 MHz

23.5 dBm

E-UTRA FDD 8: 880-915 MHz

23.0 dBm

E-UTRA FDD 20: 832-862 MHz

23.5 dBm

E-UTRA FDD 28: 703-748 MHz

23.0 dBm

✓

Valid for: Ibiza, Arona, Leon, Ateca, Tarraco

Additional information for countries
outside the European Union

Mexico

Your vehicle has different radioelectrical de-
vices. The manufacturers of these devices
declare that they comply with Directive
RLVCOAR15-0008 when legally required. The
full text of the declaration of conformity is avail-
able online at the following Internet address:
https://www.seat.mx/servicio/mi-seat/manual-
del-propietario.html

CarManuals2.com

350

Information for the user

Certificate: RLVHERS17-0286. RS4 Hella
KGaA Hueck & Co. short-range radar
IFT:RLVHERS17-0286. The operation of this
equipment is subject to the following two con-
ditions: (1) this equipment or device may not
cause harmful interference, and (2) this equip-
ment or device must accept any interference,
including interference that may cause unde-
sired operation.

United Kingdom

The following applies to importers in the UK
market:
Volkswagen Group United Kingdom Ltd.
Yeomans Drive, Blakelands
Milton Keynes, MK 14 5AN
United Kingdom

Turkey

Telsiz Ekipmanları Yönetmeliği (2014/53/AB)

Aracınızda çeşitli telsiz ekipmanları bulunmak-
tadır.
Telsiz Ekipmanlari Yönetmeliği (2014/53/AB)
açısından Türkiye pazarı için radyo ekipmanı
ithalatçısı (bu bilgi sadece resmi temsilcimiz
olan Doğuş Otomotiv Servis ve Ticaret A.Ş.’nin
ithal ettiği ürünler için geçerlidir):
Doğuş Otomotiv Servis ve Ticaret A.Ş.
Şekerpınar Mahallesi, Anadolu Caddesi, No: 22
ve 45
41420 Çayırova/Kocaeli

Ukraine

мпортер

ТОВ

Порше

Укра

на

просп

Павла

Тичини

, 1

оф

„

“, 4-

поверх

02152

Ки

Укра

на

Importer:

Porsche Ukraine LLC
Pavla Tychyny ave. 1V, Office “B”, 4th floor
02152 Kyiv, Ukraine.

CarManuals2.com

Technical data

351

Indications about the technical data

Technical data

Indications about the tech-
nical data

Vehicle identification data

The values indicated in the technical data may
differ depending on optional equipment or ver-
sion of the model, as well as in the case of spe-
cial vehicles and equipment for certain coun-
tries.
The information in the official vehicle documen-
tation takes precedence at all times.

Abbreviations used in the Technical Specifi-
cations section

Kilowatt, engine power measure-
ment.

Horsepower (not currently used),
engine power measurement unit.

rpm, 1/min

Revolutions per minute – engine
speed.

Newton metres, unit of engine tor-
que.

Cetane number, indication of the
diesel combustion power.

RON

Research octane number, indication
of the knock resistance of petrol.

Vehicle ID number

The vehicle ID number can be found in the fol-
lowing places:

●

One the vehicle's data label.

●

In front, under the windscreen.

●

To the right in the engine compartment.

Type plate

The type plate is located on the vehicle’s right
hand door frame. Vehicles for certain export
countries do not have a type plate.

Performance

The values apply only to optimal road and
weather conditions.
The vehicle’s performance has been calculated
without any equipment that would affect it, e.g.
accessories.

Fuel consumption

Approved consumption values are derived from
measurements performed or supervised by
certified EU laboratories, according to the legis-
lation in force at the time (for more information,
see the Publications Office of the European
Union on the EUR-Lex website: © European Un-
ion, http://eur-lex.europa.eu/) and apply to the
specified vehicle characteristics.

The values relating to fuel consumption and
CO

emissions can be found in the documenta-

tion provided to the purchaser of the vehicle at
the time of purchase.
Fuel consumption and CO

emissions depend

on the equipment/features of each individual
vehicle, as well as on the driving style, road
conditions, traffic conditions, environmental
conditions, load or number of passengers.

Tank level

Vehicles with front-wheel
drive:

50 l, 7 l reserve

Vehicles with all-wheel
drive

55 l, 8.5 l reserve

Adblue tank volume

approx. 11 l

approx. 13 l

The amount filled using a dispenser nozzle may

be less. In conditions of extreme cold, the amount
filled may be less. The values depend on the equip-
ment.

Weights

The kerb weight values apply to the vehicle
as ready to drive with a driver (75 kg), oper-
ating fluids and, if applicable, tools and the
spare wheel. The kerb weight increases with

CarManuals2.com

Technical data

353

Indications about the technical data

Engine specifications

Petrol engines

1.0 TSI Start-Stop

1.4 TSI Start-Stop

1.5 TSI Start-Stop

2.0 TSI Start-Stop

Power output in kW (hp) at 1/min

81 (110)/5,500

110 (150)/

5,000-6,000

110 (150)/5,000-6,000

140 (190)/

4,200-6,000

Maximum torque (Nm at 1/min)

200/2,000-3,000

250/1,500-3,500

250/1,500-4,000

320/1,500-4,100

No. of cylinders/displacement (cm

)

3/999

4/1,395

4/1498

4/1,984

Fuel

Super 95 / Normal 91 (with a slight power loss) ROZ

Gearbox

manual

DSG

manual

DSG

DSG 4Drive

Top speed (km/h)

180 (V)

195 (VI)

202 (V)

214 (V)

Acceleration from 0-100 km/h (s)

11.3

9.1

9.0

7.1

Maximum authorised weight (kg)

1,870

1,930

1,940

2,090

Diesel engines

2.0 TDI CR Start-

Stop

2.0 TDI CR Start-

Stop

2.0 TDI CR Start-

Stop

2.0 TDI CR Start-Stop

Power output in kW (hp) at 1/min

85 (116)/2,750-4,250

105 (143)/

3,500-4,000

110 (150)/

3,250-4,200

110 (150)/3,000-4,200

Maximum torque (Nm at 1/min)

300/1,600-2,500

320/1,750-3,000

340/1,600-3,000

360/1,600-2,750

No. of cylinders/displacement (cm

)

4/1,968

Fuel

Diesel according to standard EN 590, min. 51 CN

Gearbox

manual

DSG

manual

DSG

DSG 4Drive

Top speed (km/h)

185 (V)

193 (V)

202 (V)

202 (VI)

197 (VI)

Acceleration from 0-100 km/h (s)

10.9

9.4

9.3

9.0

8.7

Maximum authorised weight (kg)

1,990

2,000

2,030

2,120

CarManuals2.com

Technical data

355

Indications about the technical data

›››

Fig. 228

ATECA

ATECA 4Drive

Front projection (mm)

871

Rear projection (mm)

872

880

Wheelbase (mm)

2,638

2,630

Length (mm)

4,381

Front

track (mm)

1,576

1,572

Back

track (mm)

1,541

1,544

Width (mm)

1,841

Height at kerb weight (mm)

1,601

1,615

1,611

1,625

Ground clearance between the axles (mm)

176

189

Front projection angle limited by the bumper

maximum 18.9°

maximum 19.9°

Rear projection angle limited by the bumper

maximum 27.4°

maximum 27.8°

Turning radius (m)

10.2

This data will change depending on the type of wheel rim.

Distance to the roof.

Dimension to the roof bars.

CarManuals2.com

Index

357

Index

Numbers and Symbols

4Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
12-volt battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 312

assisted start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  288
charge level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  315
charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  313
control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  315
disconnect and connect . . . . . . . . . . . . . . . . . . . .  313
electrolyte level . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  313
energy management . . . . . . . . . . . . . . . . . . . . . . .  315
replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  313

ACC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  162
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  342
Activating SEAT CONNECT . . . . . . . . . . . . . . . . . . .  216
Adapting the playback volume . . . . . . . . . . . . . . .  234
Adaptive Cruise Control . . . . . . . . . . . . . . . . . . . . . .  162

control and warning lamp . . . . . . . . . . . . . . . . . .  167
malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  167
operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  163
special driving situations . . . . . . . . . . . . . . . . . . . .  165
status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  163
System limitations . . . . . . . . . . . . . . . . . . . . . . . . . .  166

AdBlue®

control and warning lamps . . . . . . . . . . . . . . . . .  282
information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  281
loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  281
minimum filling capacity . . . . . . . . . . . . . . . . . . . .  281
specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  281
tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  281

Adjust

front seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  92
headrest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  95
lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  104
seat with memory . . . . . . . . . . . . . . . . . . . . . . . . . . .  96
seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  37
time and date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  27

Adjusting the seat belt . . . . . . . . . . . . . . . . . . . . . . . . . 43
Air conditioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113

air recirculation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  118
controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  115
Infotainment system settings . . . . . . . . . . . . . . . .  118
manual air conditioning . . . . . . . . . . . . . . . . . . . . .  117
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  121

Air recirculation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Airbag system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  48
control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  48
deactivation of the front airbag . . . . . . . . . . . . . .  50
description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  47
front airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  49
how it works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  48

Airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

activating and deactivating . . . . . . . . . . . . . . . . .  50
description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  47
for the head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  52
for the knees . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  52
front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  49
side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  50

Android Auto™

disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  224
establish connection . . . . . . . . . . . . . . . . . . . . . . .  224
menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  224
requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  224
special characteristics . . . . . . . . . . . . . . . . . . . . .  224

Anti-lock brake system . . . . . . . . . . . . . . . . . . . . . . . . 151

Anti-puncture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 331
Anti-puncture kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 331

check after 10 minutes . . . . . . . . . . . . . . . . . . . . .  333
components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  332
inflating the tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . .  332
sealing the tyre . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  332

Anti-puncture set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 331
Anti-theft alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

interior monitoring and anti-tow system . . . . . . 76
trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270

Anti-theft alarm system . . . . . . . . . . . . . . . . . . . . . . . . 76
Anti-trap function

glass roof sun blind . . . . . . . . . . . . . . . . . . . . . . . . . .  88
sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  88
windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  85

Antifreeze . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 303
Apple CarPlay

disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  223
establish connection . . . . . . . . . . . . . . . . . . . . . . .  223
menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  223
requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  223
special characteristics . . . . . . . . . . . . . . . . . . . . .  223

Applications (apps) . . . . . . . . . . . . . . . . . . . . . . . . . . .  223
Approved spare parts . . . . . . . . . . . . . . . . . . . . . . . .  336
Area View system . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  159
Aspects to think about before starting the vehicle
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  36
Assistance systems

adaptive cruise control . . . . . . . . . . . . . . . . . . . . .  162
area view system . . . . . . . . . . . . . . . . . . . . . . . . . . .  159
Auto-Hold function . . . . . . . . . . . . . . . . . . . . . . . . . .  185
connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  155
cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  159
driver alert system . . . . . . . . . . . . . . . . . . . . . . . . . . .  23
driving assist (Travel Assist) . . . . . . . . . . . . . . . . .  175
Emergency Assist . . . . . . . . . . . . . . . . . . . . . . . . . . .  177

CarManuals2.com

358

Index

emergency braking (Front Assist) . . . . . . . . . . .  169
front camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  157
front radar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  156
general notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  155
Hill Hold Control (HHC) . . . . . . . . . . . . . . . . . . . . .  146
lane departure warning (Side Assist) . . . . . . . .  179
parking aid Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . .  188
peripheral view system (Top View Camera)

202

PreCrash system . . . . . . . . . . . . . . . . . . . . . . . . . . . .  45
predictive speed adjustment . . . . . . . . . . . . . . . .  167
rear parking aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  191
rear radar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  157
road signs detection system . . . . . . . . . . . . . . . . .  24
safety advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  155
speed limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  161
switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  155
system limits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  155
Trailer assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  205
tyre pressure monitor indicator . . . . . . . . . . . . .  329
tyre pressure monitoring . . . . . . . . . . . . . . . . . . .  330
ultrasound sensors . . . . . . . . . . . . . . . . . . . . . . . . .  158

Assisted start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288
Audible warning

lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
unbuckled seat belt . . . . . . . . . . . . . . . . . . . . . . . . . 40

Audio warning signals

warning and control lamps . . . . . . . . . . . . . . . . . . . 11

Auto Lock (central locking) . . . . . . . . . . . . . . . . . . . . .  72
Auto Unlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  72
Auto-Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  185
Auto-Hold function . . . . . . . . . . . . . . . . . . . . . . . . . . . .  185
Automatic car wash . . . . . . . . . . . . . . . . . . . . . . . . . .  337

disconnecting the Auto-Hold function . . . . . . . 185

Automatic dipped beam headlight control . . . . . 99

Automatic gearbox

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  140
downhill assistant . . . . . . . . . . . . . . . . . . . . . . . . . .  146
driving tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  142
launch-control program . . . . . . . . . . . . . . . . . . . .  143
selector lever positions . . . . . . . . . . . . . . . . . . . . .  140
steering wheel with shift paddles . . . . . . . . . . . .  141
tiptronic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  141

Auxiliary heating

activate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  125
connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  123
electricity consumers . . . . . . . . . . . . . . . . . . . . . . .  122
programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  125
radio-operated remote control . . . . . . . . . . . . .  124
special characteristics . . . . . . . . . . . . . . . . . . . . . .  122
switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  123

Average fuel consumption . . . . . . . . . . . . . . . . . . . . . 16

Backrest of the rear seat

folding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
raise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Bag hooks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  212, 264
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  69
Before starting the vehicle . . . . . . . . . . . . . . . . . . . . .  36
Belt force limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  44
Belt tightening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  44
Bicycle carrier

fitting onto the coverable tow hook . . . . . . . . . 275
max. load rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . 275

Biodiesel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280
Blown bulbs

change a bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 298

Bonnet

opening and closing . . . . . . . . . . . . . . . . . . . . . . . 302

Brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 306

Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  306
brake servo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  150
braking assistant . . . . . . . . . . . . . . . . . . . . . . . . . . . .  151
electronic parking brake . . . . . . . . . . . . . . . . . . . .  184
new brake pads . . . . . . . . . . . . . . . . . . . . . . . . . . . .  150

Braking assistant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Braking system

warning lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Brands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235

Camera

cleaning the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 26

Catalytic converter . . . . . . . . . . . . . . . . . . . . . . . . . .  283
Central armrests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  97
Central locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  72

anti-theft alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  76
auto-locking due to involuntary opening . . . . .  72
central locking switch . . . . . . . . . . . . . . . . . . . . . . . .  74
emergency lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  78
Keyless Access system . . . . . . . . . . . . . . . . . . . . . .  70
remote control key . . . . . . . . . . . . . . . . . . . . . . . . . . .  73

Cetane index (diesel fuel) . . . . . . . . . . . . . . . . . . . . 280
Change a bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 298

tail light bulb in the rear lid . . . . . . . . . . . . . . . . . 299

Change the wiper blades . . . . . . . . . . . . . . . . . . . . 286
Changing a wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323

raise the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . .  327
subsequent work . . . . . . . . . . . . . . . . . . . . . . . . . . .  328
wheel nuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  326

Changing parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 342
Changing the battery

of the vehicle key . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

CarManuals2.com

Index

359

Check lists

requirements for Android Auto™ . . . . . . . . . . . .  224
requirements for Apple CarPlay . . . . . . . . . . . .  223
requirements for MirrorLink® . . . . . . . . . . . . . . . .  225

Child lock

electric windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Child seats

attachment systems . . . . . . . . . . . . . . . . . . . . . . . . .  56
group classification . . . . . . . . . . . . . . . . . . . . . . . . .  54
i-Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  57
ISOFIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  57
safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . .  54
securing with the seat belt . . . . . . . . . . . . . . . . . .  60
Top Tether system . . . . . . . . . . . . . . . . . . . . . . . . . . . .  60

Cleaning

high pressure cleaning equipment . . . . . . . . . .  337
special care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  340
vehicle exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  338
vehicle interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  339
washing the vehicle . . . . . . . . . . . . . . . . . . . . . . . .  337

Climate control

windscreen heating . . . . . . . . . . . . . . . . . . . . . . . . . 120

Clocks

set the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Closing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  302
rear lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  80
sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  87
windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Clutch (lamp) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Coming Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Connectivity

WLAN access point . . . . . . . . . . . . . . . . . . . . . . . . . 220

Control and warning lamps

12-volt battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 315
ACC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167

adaptive cruise control . . . . . . . . . . . . . . . . . . . . .  163
AdBlue® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  282
air conditioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  121
airbag system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  48
airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  50
anti-lock brake system ABS . . . . . . . . . . . . . . . . .  154
automatic gearbox . . . . . . . . . . . . . . . . . . . . . . . . .  140
braking system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  151
cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  160
cruise control (GRA) . . . . . . . . . . . . . . . . . . . . . . . .  159
electromechanical steering . . . . . . . . . . . . . . . .  148
emissions control . . . . . . . . . . . . . . . . . . . . . . . . . . .  284
engine coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  18
engine management . . . . . . . . . . . . . . . . . . . . . . .  284
engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  311
ESC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  154
ESC in Sport mode . . . . . . . . . . . . . . . . . . . . . . . . .  153
ESC off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  153
fuel reserve . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  17
hill descent control . . . . . . . . . . . . . . . . . . . . . . . . .  146
Lane Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  174
lane departure warning (Side Assist) . . . . . . . .  180
lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  99
parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  185
particulate filter . . . . . . . . . . . . . . . . . . . . . . .  283, 284
press on the brake . . . . . . . . . . . . . . . . . . . . . . . . . .  162
refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  17, 279
remote control (independent heating) . . . . . .  124
seat belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  40
speed limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  162
Start-Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  136
steering column . . . . . . . . . . . . . . . . . . . . . . . . . . . .  148
TCS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  154
tow hook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  274
tyre pressure monitor system . . . . . . . . . . . . . . .  330

Control lamps

overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Controls on the steering wheel . . . . . . . . . . . . . . . . 90
Convenience close function

sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Convenience open function

sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Cooling system

check the coolant . . . . . . . . . . . . . . . . . . . . . . . . . . 304
refilling coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . 304

Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  235
Cornering light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  100
Correct position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  37

driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
passenger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Cruise control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Cruise control system . . . . . . . . . . . . . . . . . . . . . . . . . 159

control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160

Current documentation attached . . . . . . . . . . . . . 227

Dangers of not using the seat belt . . . . . . . . . . . . . .  41
Data label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  351
Data transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  215
Deactivating SEAT CONNECT services . . . . . . .  218
Deactivation of the front airbag . . . . . . . . . . . . . . .  50
Diesel

refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280

Disposal

seat belt tensioners . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Door cylinder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  78
Door handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  78
Door lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  78

CarManuals2.com

360

Index

Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

child lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Downhill assistance function . . . . . . . . . . . . . . . . . .  146
downhill assistant . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  146
Drawers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  211
Drink holder

bottle holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  211
front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  211
in the rear central armrest . . . . . . . . . . . . . . . . . . .  211

Driver alert system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Driving

driving on flooded roads . . . . . . . . . . . . . . . . . . . .  130
economical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  127
loaded vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  129
safe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  36
trips abroad . . . . . . . . . . . . . . . . . . . . . . . . . . . .  104, 131
with the luggage compartment open . . . . . . .  129
with trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  272

Driving Assist (Travel Assist)

see Travel Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

Driving data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  21
Driving data indicator . . . . . . . . . . . . . . . . . . . . . . . . . .  21
Driving mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  149
Driving on flooded roads . . . . . . . . . . . . . . . . . . . . .  130
Driving profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  149
Driving with a loaded vehicle . . . . . . . . . . . . . . . . .  129
Driving with the luggage compartment open .  129
DSG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  140
Duplicate keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  67
Dust and pollen filter . . . . . . . . . . . . . . . . . . . . . . . . . .  113
Dynamic headlight range control . . . . . . . . . . . . .  104

e-Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
E10

see Ethanol (fuel) . . . . . . . . . . . . . . . . . . . . . . . . . . 280

Easy Open

special characteristics . . . . . . . . . . . . . . . . . . . . . . 82

Eco-driving notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  27
Electric devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  212
Electric windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  84
Electrolyte . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  313
Electronic differential lock . . . . . . . . . . . . . . . . . . . . .  151
Electronic immobilizer . . . . . . . . . . . . . . . . . . . . . . . . .  135
Electronic parking brake . . . . . . . . . . . . . . . . . . . . . .  184

control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

Electronic Stability Control (ESC) . . . . . . . . . . . . . 151
Emergencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

anti-puncture kit . . . . . . . . . . . . . . . . . . . . . . . . . . . .  331
changing a wheel . . . . . . . . . . . . . . . . . . . . . . . . . .  323
changing the battery . . . . . . . . . . . . . . . . . . . . . . .  313
emergency vehicle towing . . . . . . . . . . . . . . . . .  290
hazard warning lights . . . . . . . . . . . . . . . . . . . . . . . .  63
jump leads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  288
replace a blown fuse . . . . . . . . . . . . . . . . . . . . . . .  296
vehicle tool kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  286

Emergency Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

connecting and disconnecting . . . . . . . . . . . . . .  178
problems and solutions . . . . . . . . . . . . . . . . . . . . .  179
see Emergency Assist . . . . . . . . . . . . . . . . . . . . . . .  177
status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  178

Emergency braking assist system . . . . . . . . . . . . . 156

activating and deactivating . . . . . . . . . . . . . . . . .  172
status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  170
system limitations . . . . . . . . . . . . . . . . . . . . . . . . . . .  171
temporarily deactivating . . . . . . . . . . . . . . . . . . . .  172
warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  170

Emergency braking warning . . . . . . . . . . . . . . . . . . .  63
Emergency call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  64
Emergency call service . . . . . . . . . . . . . . . . . . . . . . . .  64
Emergency locking of the front passenger door 78

Emergency opening

driver's door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
rear lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Emergency operation

front passenger door . . . . . . . . . . . . . . . . . . . . . . . . 78

Emissions control system

AdBlue® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  281
catalytic converter . . . . . . . . . . . . . . . . . . . . . . . . .  283
control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  284
particulate filter . . . . . . . . . . . . . . . . . . . . . . . . . . . .  283

Energy management . . . . . . . . . . . . . . . . . . . . . . . . . 315
Engine

noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  133
running in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  130
start (driver instructions with the mechanical
contact) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  136
Start-Stop system . . . . . . . . . . . . . . . . . . . . . . . . . .  136

Engine and ignition

emergency start . . . . . . . . . . . . . . . . . . . . . . . . . . . .  135
preheat the engine . . . . . . . . . . . . . . . . . . . . . . . . .  133
starting the engine . . . . . . . . . . . . . . . . . . . . . . . . . .  133
starting the engine with Press & Drive . . . . . . .  133
switching off the engine . . . . . . . . . . . . . . . . . . . .  134

Engine compartment

battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  312
engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  310
opening and closing . . . . . . . . . . . . . . . . . . . . . . .  302
safety instructions . . . . . . . . . . . . . . . . . . . . . . . . .  300

Engine coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 303

check the level . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  304
exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  20
specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  303
temperature indicator . . . . . . . . . . . . . . . . . . . . . . . . .  18
warning lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  18

Engine failure

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284

CarManuals2.com

Index

361

Engine management . . . . . . . . . . . . . . . . . . . . . . . . . 283

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284

Engine oil

change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  308, 311
check the oil level . . . . . . . . . . . . . . . . . . . . . . . . . .  310
consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  310
dipstick . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  310
inspection service . . . . . . . . . . . . . . . . . . . . . . . . . .  308
maintenance frequencies . . . . . . . . . . . . . . . . . .  308
refill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  310
specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  308

Engine oil pressure

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 311

Engine specifications . . . . . . . . . . . . . . . . . . . . . . . . . 353
Environment

ecological driving . . . . . . . . . . . . . . . . . . . . . . . . . . .  127
environmental compatibility . . . . . . . . . . . . . . . .  345
recycling of electrical appliances . . . . . . . . . .  345
refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  278

Environmental tip

refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278

ESC

connecting and disconnecting . . . . . . . . . . . . .  153
electronic stability control (ESC) . . . . . . . . . . . .  151
Sport mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  153

Ethanol (fuel) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  280
Event Data Recorder . . . . . . . . . . . . . . . . . . . . . . . . .  344
Exhaust gases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  283
Exiting a parking space

with the parking assist system . . . . . . . . . . . . . . 199

Exterior lighting

change a bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 298

Exterior mirrors

driving with a trailer . . . . . . . . . . . . . . . . . . . . . . . . 268
folding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

heated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

External antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 342
External audio sources

adapting the playback volume . . . . . . . . . . . . . 234

Fabrics: clean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  339
Factors that have a negative influence on safe
driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  36
Fastening rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  263
Filling capacities

AdBlue® tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 281
window washer water . . . . . . . . . . . . . . . . . . . . . . 307

Filling the tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  279
Fire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  64
Four-wheel drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  130
Frequency bands . . . . . . . . . . . . . . . . . . . . . . . . . . . .  240
Front bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  300
Front camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  157
Front compartment

brake fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  306
coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  303, 304
windscreen washer reservoir . . . . . . . . . . . . . . .  307

Front passenger front airbag

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Fuel

diesel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  280
ethanol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  280
fuel gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  17
identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  279
petrol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  279
refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  279
saving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  127

Fuel consumption

inertia disconnection . . . . . . . . . . . . . . . . . . . . . . . . 127
why does consumption increase? . . . . . . . . . . 284

Fuel gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Fuel tank cap

opening and closing . . . . . . . . . . . . . . . . . . . . . . . . 279

Fuel tank flap

opening and closing . . . . . . . . . . . . . . . . . . . . . . . . 279

Full Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221

applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  223
settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  223
symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  223

Full-LED headlights . . . . . . . . . . . . . . . . . . . . . . . . . . . 298
Fuses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 294

colour coded . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  295
fuse box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  295, 296
preparations for replacing fuses . . . . . . . . . . . .  296
recognise blown fuses . . . . . . . . . . . . . . . . . . . . .  296
replace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  296

Gear change

manual gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

Gear indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  127
Gear-change recommendation . . . . . . . . . . . . . . .  127
Glass roof sun blind . . . . . . . . . . . . . . . . . . . . . . . . . . . .  88

anti-trap function . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Glove compartment . . . . . . . . . . . . . . . . . . . . . . . . . . 210

Hangers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 212
Hazard warning lights . . . . . . . . . . . . . . . . . . . . . . . . . . 63
HDC

see Hill descent control (HDC) . . . . . . . . . . . . . . 146

CarManuals2.com

362

Index

Head-on collisions and the laws of physics . . . . . 41
Headlight range control . . . . . . . . . . . . . . . . . . . . . . 104
Headlights

trips abroad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Headrest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
removing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Heating and fresh air . . . . . . . . . . . . . . . . . . . . . . . . . . 117
HHC

see Hill Hold Control (HHC) . . . . . . . . . . . . . . . . . 146

Hill descent control (HDC)

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146

Hill Hold Control (HHC) . . . . . . . . . . . . . . . . . . . . . . . 146

i-Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  57
Identification of fuels . . . . . . . . . . . . . . . . . . . . . . . . .  279
Inertia mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  144
Infotainment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  227

adapt menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  233
Android Auto™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  224
Apple CarPlay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  223
assistants and vehicle settings . . . . . . . . . . . . . . .  35
before first use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  227
clean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  235
connecting and disconnecting . . . . . . . . . . . . .  233
customise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  233
customised menus . . . . . . . . . . . . . . . . . . . . . . . . .  233
drop-down menu . . . . . . . . . . . . . . . . . . . . . . . . . . .  233
executing functions . . . . . . . . . . . . . . . . . . . . . . . . .  233
function buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  32
help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  30
initial configuration . . . . . . . . . . . . . . . . . . . . . . . . . .  33
Internet access . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  221
Media mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  243

MirrorLink® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  225
navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  246
operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  233
overview and controls . . . . . . . . . . . . . . . . .  230, 231
Radio mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  239
safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . .  227
share a WLAN connection . . . . . . . . . . . . . . . . . .  220
sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  234
system settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  234
technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  235
telephone interface . . . . . . . . . . . . . . . . . . . . . . . .  253
tutorial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  30
vehicle information . . . . . . . . . . . . . . . . . . . . . . . . . .  34
Wi-Fi Protected Setup (WPS) . . . . . . . . . . . . . . . .  221
WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  220

Infotainment system

see Infotainment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  308, 334
Inspection reminder . . . . . . . . . . . . . . . . . . . . . . . . . . . .  28
Inspection service . . . . . . . . . . . . . . . . . . . . . . . . . . . .  308
Instrument panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  13

Basic digital . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  14
digital (SEAT Digital Cockpit) . . . . . . . . . . . . . . . .  16
service intervals display . . . . . . . . . . . . . . . . . . . . .  28
status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  19
symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  11
time and date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  27
use with the multifunction steering wheel . . . .  29
warning and control lamps . . . . . . . . . . . . . . . . . . .  11
warning and information messages . . . . . . . . . .  22

Instrument panel display . . . . . . . . . . . . . . . . 14, 16, 19
Instrument panel lighting . . . . . . . . . . . . . . . . . . . . . 104
Interior mirror

anti-dazzle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Interior monitoring and the anti-tow system

activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

ISOFIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
ISOFIX system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 286

position points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 327

Jump leads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288
Jump start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288

description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288
jump leads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288

Key switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Keyless Access

Press & Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  132
starting the engine . . . . . . . . . . . . . . . . . . . . . . . . . .  133
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  71
unlocking and locking the vehicle . . . . . . . . . . . .  70

Keys

changing the battery . . . . . . . . . . . . . . . . . . . . . . . .  69
instructions for the driver (mechanical contact)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  136
pull out the key blade . . . . . . . . . . . . . . . . . . . . . . .  68
remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  67
spare key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  67
synchronise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  69
unlock and lock . . . . . . . . . . . . . . . . . . . . . . . . . .  73, 78
vehicle key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  67

Lane Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173

control and warning lamp . . . . . . . . . . . . . . . . . . . 174
control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174

Lane Assist system . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173

CarManuals2.com

Index

363

Lane departure warning (Side Assist)

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  180
driving situations . . . . . . . . . . . . . . . . . . . . . . . . . . . .  181
how it works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  179
indication on the exterior mirror . . . . . . . . . . . . .  180
lane change Plus . . . . . . . . . . . . . . . . . . . . . . . . . . .  180
system limitations . . . . . . . . . . . . . . . . . . . . . . . . . . .  179

Launch-control (automatic transmission) . . . . .  143
Leaving Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  103
Legal provisions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  217
Licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  235
Lift the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  327
Light Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  102
Lights

audible warnings . . . . . . . . . . . . . . . . . . . . . . . . . . .  100
AUTO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  99
change a bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  298
coming home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  103
control and warning lamps . . . . . . . . . . . . . . . . . .  99
control lighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  104
controlling the lights . . . . . . . . . . . . . . . . . . . . . . . . .  99
cornering light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  100
daytime running lights . . . . . . . . . . . . . . . . . . . . . .  100
dipped beam headlights . . . . . . . . . . . . . . . . . . . .  99
fog light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  101
headlight range control . . . . . . . . . . . . . . . . . . . .  104
instrument lighting . . . . . . . . . . . . . . . . . . . . . . . . . .  104
interior lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  105
leaving home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  103
main beam assist . . . . . . . . . . . . . . . . . . . . . . . . . . .  102
main beam headlight lever . . . . . . . . . . . . . . . . . .  101
main beam headlights . . . . . . . . . . . . . . . . . . . . . .  99
reading lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  105
side lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  99
switching on and off . . . . . . . . . . . . . . . . . . . . . . . . .  99
turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  101

Loading the luggage compartment

fastening rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  263
general advice . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  259
luggage compartment . . . . . . . . . . . . . . . . . . . . .  259
positioning the load . . . . . . . . . . . . . . . . . . . . . . . .  259
positioning the luggage . . . . . . . . . . . . . . . . . . . .  259
roof carrier system . . . . . . . . . . . . . . . . . . . . . . . . .  266
trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  272
trapdoor for transporting long objects . . . . .  264

Lock and unlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

in the locking cylinder . . . . . . . . . . . . . . . . . . . . . . . 78
with the central locking switch. . . . . . . . . . . . . . . . 74

Luggage compartment . . . . . . . . . . . . . . . . . . . 80, 259

electric opening and closing . . . . . . . . . . . . . . . .  80
emergency unlocking . . . . . . . . . . . . . . . . . . . . . . .  83
enlarge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  93
features of the electric rear lid . . . . . . . . . . . . . . .  81
luggage compartment lighting . . . . . . . . . . . . .  105
net bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  263
net partition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  262
opening and closing controlled by sensors (Easy
Open) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  82
removing and fitting the shelf . . . . . . . . . . . . . .  260
store the rear shelf. . . . . . . . . . . . . . . . . . . . . . . . . .  261
variable luggage compartment floor . . . . . . .  261

Luggage compartment floor . . . . . . . . . . . . . . . . . . 261
Luggage net

luggage compartment . . . . . . . . . . . . . . . . . . . . . 263

Lumbar support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Main beam assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  102
Main beam headlight lever . . . . . . . . . . . . . . . . . . . .  101
Maintenance frequencies . . . . . . . . . . . . . . . . . . . .  308

Malfunction

adaptive cruise control . . . . . . . . . . . . . . . . . . . . .  167
clutch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  145
PreCrash system . . . . . . . . . . . . . . . . . . . . . . . . . . . .  46
sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  86
towing device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  270

Manual gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  139
Mats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  127
Media Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  243

equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244
symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244

Memory function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Microfiber: clean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 339
MirrorLink®

disconnecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  225
establish connection . . . . . . . . . . . . . . . . . . . . . . .  225
menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  225
requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  225
settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  223
special characteristics . . . . . . . . . . . . . . . . . . . . .  225

Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

adjusting the exterior mirrors . . . . . . . . . . . . . . . . 110
anti-dazzle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Mobile phones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  342
Mobility Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  336
Multimedia . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  226, 239

favourites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  244
play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  244
select source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  244

Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 246, 249

decrease the navigation map . . . . . . . . . . . . . .  247
edit route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  251
enter an address for a guide destination . . .  249
favourite destinations . . . . . . . . . . . . . . . . . . . . . .  250

CarManuals2.com

364

Index

frequent destinations . . . . . . . . . . . . . . . . . . . . . . .  250
function: entering destination . . . . . . . . . . . . . .  249
functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  248
increase the navigation map . . . . . . . . . . . . . . .  247
last destinations . . . . . . . . . . . . . . . . . . . . . . . . . . . .  250
learn usage pattern . . . . . . . . . . . . . . . . . . . . . . . .  252
limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  246
navigation announcements . . . . . . . . . . . . . . . .  246
operating the navigation map . . . . . . . . . . . . . .  247
route details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  251
save destination . . . . . . . . . . . . . . . . . . . . . . . . . . .  250
saved data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  247
saved destinations . . . . . . . . . . . . . . . . . . . . . . . . .  250
symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  248
traffic reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  251
updating navigation data . . . . . . . . . . . . . . . . . .  249
use contact details . . . . . . . . . . . . . . . . . . . . . . . . .  250

Net bag

luggage compartment . . . . . . . . . . . . . . . . . . . . . 263

Net partition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
Noise

auxiliary heating . . . . . . . . . . . . . . . . . . . . . . . . . . . .  122
brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  150
parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  184
tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  317

Number of seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Octane (petrol) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279
Odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14, 16

partial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
total . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Oil change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  311
On-board toolkit . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  286
One-touch signalling function . . . . . . . . . . . . . . . . .  101
Online services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  215

Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  302
rear lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  80
sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  87
tank cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  279
windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  84

Opening and closing . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

bonnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  302
by remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . .  73
doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  77
in the locking cylinder . . . . . . . . . . . . . . . . . . . . . . .  78
rear lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  80
rear lid with electric opening and closing . . . .  80
sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  87
sunshade blind . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  88
tank cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  279
windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  84
with the central locking switch. . . . . . . . . . . . . . . .  74

Operation in winter

diesel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  280
salt on the roads . . . . . . . . . . . . . . . . . . . . . . . . . . . .  108
snow chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  322
tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  322

Original accessories . . . . . . . . . . . . . . . . . . . . . . . . . 336
Overview

of warning and control lamps . . . . . . . . . . . . . . . . .  11
overview (left hand drive) . . . . . . . . . . . . . . . . . . . . .  9
overview (right hand drive) . . . . . . . . . . . . . . . . . . .  10
view of the vehicle from inside . . . . . . . . . . . . . . . .  8
view of the vehicle from the front . . . . . . . . . . . . . .  6
view of the vehicle from the rear . . . . . . . . . . . . . . .  7

Ownership accreditation . . . . . . . . . . . . . . . . . . . . . . 217

Painting the vehicle

care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 338

Park assist

fault . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  188
operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  190
parking aid plus . . . . . . . . . . . . . . . . . . . . . . . . . . . .  188
rear parking aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  191
see the Parking assist system . . . . . . . . . . . . . . .  193
sensors and camera: clean . . . . . . . . . . . . . . . .  338
surroundings warning . . . . . . . . . . . . . . . . . . . . . . .  188
visual indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  191

Parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

automatic gearbox . . . . . . . . . . . . . . . . . . . . . . . . . 142
with the parking assist system . . . . . . . . . . . . . . 198

Parking assist system . . . . . . . . . . . . . . . . . . . . . . . . . 193

angle parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  198
description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  194
leaving a parking space (only when parallel
parked) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  199
parallel parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  198
parking conditions . . . . . . . . . . . . . . . . . . . . . . . . . .  198
stop early . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  195

Parking systems

automatic brake operation . . . . . . . . . . . . . . . . .  186
reverse assist (Rear View Camera) . . . . . . . . .  200
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  187

Partial odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  27
Particulate filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  283
Pedals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  38, 127
Peripheral view system (Top View Camera) . . .  202

menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  204
modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  204
special characteristics . . . . . . . . . . . . . . . . . . . . .  203
usage instructions . . . . . . . . . . . . . . . . . . . . . . . . . .  204

Petrol

additives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  279
particulate filter . . . . . . . . . . . . . . . . . . . . . . . . . . . .  283
refuelling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  279

CarManuals2.com

Index

365

Places with risk of explosion . . . . . . . . . . . . . . . . . .  254
Places with special regulations . . . . . . . . . . . . . . .  254
Power sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  212

trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 270

PreCrash system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Front Assist monitoring system . . . . . . . . . . . . . . .  45
malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  46
selecting the driving profile . . . . . . . . . . . . . . . . . .  46
status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  46

Predictive speed adjustment . . . . . . . . . . . . . . . . . . 167

activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  168
driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  168
limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  168
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . .  169

Preheat the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Press & Drive

start button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
starting the engine . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219

settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219

Radar sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239

equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  240
frequency bands . . . . . . . . . . . . . . . . . . . . . . . . . . .  240
preset buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  240
symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  240
Traffic information (TP) . . . . . . . . . . . . . . . . . . . . .  241
tune station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  240
type of reception . . . . . . . . . . . . . . . . . . . . . . . . . . .  240

Radio mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  239
Radio screen: clean . . . . . . . . . . . . . . . . . . . . . . . . . .  339
Radio telephones . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  342
Rain and light sensor . . . . . . . . . . . . . . . . . . . . . . . . . .  107

Rain sensor

function control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

Raise the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 327
RCTA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
Rear cross traffic alert (RCTA) . . . . . . . . . . . . . . . . 208
Rear fog light

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Rear lid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79, 83
Rear mounting

towing device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 277

Rear parking aid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

visual indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

Rear radar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Rear seat

fold down with the remote unlocking lever . . . 98

Rear Traffic Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  208
Rear View Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . .  200
Rear window wiper . . . . . . . . . . . . . . . . . . . . . . . . . . .  106
Refuelling

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  17
fuel gauge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  17
opening the fuel tank flap. . . . . . . . . . . . . . . . . . .  279
safety warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . .  278

Releasing the seat belt . . . . . . . . . . . . . . . . . . . . . . . . 42
Remote control (independent heating) . . . . . . . . 124
Remote control key

unlock and lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Repair work . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  342
Requirements for Apple CarPlay . . . . . . . . . . . . . .  223
Reverse assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  200
Reverse assist (Rear View) . . . . . . . . . . . . . . . . . . . .  200

parking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
shown on the display . . . . . . . . . . . . . . . . . . . . . . . 201

Reverse assist system . . . . . . . . . . . . . . . . . . . . . . . . 200
Revolution counter . . . . . . . . . . . . . . . . . . . . . . . 14, 16, 17

Road signs

shown on the display . . . . . . . . . . . . . . . . . . . . . . . . 24

Road signs detection system . . . . . . . . . . . . . . . . . . 24

how it works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  24
limited operation . . . . . . . . . . . . . . . . . . . . . . . . . . . .  26
shown on the display . . . . . . . . . . . . . . . . . . . . . . . .  24
speed warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  25
windscreen damage . . . . . . . . . . . . . . . . . . . . . . . . .  26

Roof carrier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265

fix the crossbars . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266

Roof carrier system . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
Roof rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 265
Rotation direction

tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 328

Running in

new brake pads . . . . . . . . . . . . . . . . . . . . . . . . . . . .  150
new engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  130
new tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  317

Safe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  74, 135
Safe driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  36
Safe security system . . . . . . . . . . . . . . . . . . . . . . . . . . .  74

troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Safety

child safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  53
child seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  53
safe driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  36

Safety equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

head-protection airbags . . . . . . . . . . . . . . . . . . . .  52
seat belt tensioners . . . . . . . . . . . . . . . . . . . . . . . . . .  45
side airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  50
using child seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  54
using seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  40

CarManuals2.com

366

Index

Save fuel

inertia mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144

Screen

clean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 235

Seat belt tensioners . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Seat belts

adjusting the seat belt . . . . . . . . . . . . . . . . . . . . . . .  43
adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  42
automatic retractor, tensioner and belt force
limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  44
control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  40
maintenance and disposal of seat belt
tensioners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  45
protective function . . . . . . . . . . . . . . . . . . . . . . . . . .  39
purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  46
safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . .  40
symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  40
unfastened . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  41

SEAT CONNECT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215

activation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  216
deactivate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  218
faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  218
legal provisions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  217

SEAT Digital Cockpit . . . . . . . . . . . . . . . . . . . . . . . . . . .  16
SEAT Drive Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  148
SEAT Drive Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . .  148

see Drive profile selection . . . . . . . . . . . . . . . . . . 148
selecting a profile . . . . . . . . . . . . . . . . . . . . . . . . . . 149

Seat heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  119
SEAT Ident . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  217
Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  92

adjusting the headrests . . . . . . . . . . . . . . . . . . . . . .  95
armrest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  97
backrest of the rear seat . . . . . . . . . . . . . . . . . . . .  93
electric settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  93

fitting the headrest . . . . . . . . . . . . . . . . . . . . . . . . . .  95
heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  119
incorrect positions . . . . . . . . . . . . . . . . . . . . . . . . . . .  38
manual adjustment . . . . . . . . . . . . . . . . . . . . . . . . . .  92
memory function . . . . . . . . . . . . . . . . . . . . . . . . . . . .  96
number of seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  38
removing the headrest . . . . . . . . . . . . . . . . . . . . . .  95

Selection of driving profile

characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

Selective catalytic reduction . . . . . . . . . . . . . . . . . . 281
Selector lever (automatic gearbox)

positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Selling the vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217
Service

Digital Maintenance plan . . . . . . . . . . . . . . . . . . .  334
inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  334
proof of Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  334
service sets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  336
service works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 334
terms of use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  335

Service interval display . . . . . . . . . . . . . . . . . . . . . . . . 27
Service intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Service Menu

service interval display . . . . . . . . . . . . . . . . . . . . . . . 27
vehicle identification number . . . . . . . . . . . . . . . . 27

Service Mobility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  336
Set of vehicle keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  67
Shift paddles (automatic transmission) . . . . . . . .  141
Snow chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  322
Sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  234
Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 342
Spare wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  324
Special characteristics

Android Auto™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  224
Apple CarPlay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  223
high pressure cleaning equipment . . . . . . . . . .  274

MirrorLink® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225
peripheral view system (Top View Camera)

203

tow start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  290
towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  290
trailer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  272

Speed limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161

control lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  162
indication on display . . . . . . . . . . . . . . . . . . . . . . . .  161
operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  161

Speed symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  317
Stabilisation of the towing vehicle and trailer
combination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  273
Start button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  132
Start the engine by towing . . . . . . . . . . . . . . . . . . . .  291

special characteristics . . . . . . . . . . . . . . . . . . . . . 290

Start-Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Start-Stop system

disconnect and connect manually . . . . . . . . .  138
driver indications . . . . . . . . . . . . . . . . . . . . . . . . . . .  138
how it works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  136
lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  136
stopping and starting the engine . . . . . . . . . . .  136
the engine does not turn off . . . . . . . . . . . . . . . . .  136
the engine starts by itself . . . . . . . . . . . . . . . . . . .  136

Status display

adaptive cruise control . . . . . . . . . . . . . . . . . . . . .  163
doors, front bonnet and rear lid open . . . . . . . .  19
Eco-driving notes . . . . . . . . . . . . . . . . . . . . . . . . . . . .  27
Emergency Assist . . . . . . . . . . . . . . . . . . . . . . . . . . .  178
Emergency brake assistance system (Front
Assist) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  170
instrument panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  19
odometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  20
outside temperature . . . . . . . . . . . . . . . . . . . . . . . . .  20
PreCrash system . . . . . . . . . . . . . . . . . . . . . . . . . . . .  46
road signs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  24

CarManuals2.com

Index

367

SEAT Drive Profile . . . . . . . . . . . . . . . . . . . . . . . . . .  148
selector lever positions . . . . . . . . . . . . . . . . . . . . .  140
service intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  28
speed limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  161
speed warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  20
time and date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  27
Travel Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  175
tyre pressure monitoring . . . . . . . . . . . . . . . . . . . .  329
warning and information messages . . . . . . . . . .  22

Steering

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  148
electromechanical steering . . . . . . . . . . . . . . . . .  147
steering assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  147

Steering assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Steering wheel

adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  91
controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  90
heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  120
shift paddles (automatic transmission) . . . . . .  141

Steering wheel heating . . . . . . . . . . . . . . . . . . . . . . . 120
Storage compartment . . . . . . . . . . . . . . . . . . . . . . . . 210

drawers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  211
glove compartment . . . . . . . . . . . . . . . . . . . . . . . .  210
on-board documentation . . . . . . . . . . . . . . . . . . .  210
other object holders . . . . . . . . . . . . . . . . . . . . . . . .  212

Storage compartment accessories

see Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210

Storage of accident data . . . . . . . . . . . . . . . . . . . . . 344
Storing objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 259

bag hooks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  264
fastening rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  263
loading the trailer . . . . . . . . . . . . . . . . . . . . . . . . . . .  272
net bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  263
net partition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  262
positioning the load . . . . . . . . . . . . . . . . . . . . . . . .  259
positioning the luggage . . . . . . . . . . . . . . . . . . . .  259

roof carrier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  265
roof carrier system . . . . . . . . . . . . . . . . . . . .  265, 266
trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  267
trailer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  272
trapdoor for transporting long objects . . . . .  264

Sun blind . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  111
Sun protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  111
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  86, 87

anti-trap function . . . . . . . . . . . . . . . . . . . . . . . . . . . .  88
convenience open/close function . . . . . . . . . . .  87
malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  86
sunshade blind . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  88

Switching off

telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254

Symbols

see Warning and control lamps . . . . . . . . . . . . . . . 11

System settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234

Tail lights on the rear lid

remove the bulb holder . . . . . . . . . . . . . . . . . . . . 299

Technical data

engine specifications . . . . . . . . . . . . . . . . . . . . . . .  353
vehicle dimensions . . . . . . . . . . . . . . . . . . . . . . . . .  354
vertical load on the tow hitch . . . . . . . . . . . . . . .  267
weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  351

Technical modifications . . . . . . . . . . . . . . . . . . . . . . 342
Telephone

connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  254
contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  257
favourites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  257
pairing a mobile phone . . . . . . . . . . . . . . . . . . . . .  254
phone book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  257
send messages . . . . . . . . . . . . . . . . . . . . . . . . . . . .  256
speed dial buttons . . . . . . . . . . . . . . . . . . . . . . . . . .  257

switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
to call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 256

Telephone interface . . . . . . . . . . . . . . . . . . . . . . . . . . . 253

equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  253
places with risk of explosion . . . . . . . . . . . . . . . .  254
symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  253

Time

adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Tiptronic (automatic transmission) . . . . . . . . . . . . . 141
Top Tether . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Top Tether System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Top View Camera

see the Peripheral view system (Top View
Camera) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202

Torque

wheel nuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 328

Touch screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . 230, 231
Tow cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268, 270
Tow hook

control lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274
unlocking electrically . . . . . . . . . . . . . . . . . . . . . . . 274

Towable loads

loading the trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . 272

Towing device

fitting a bicycle carrier . . . . . . . . . . . . . . . . . . . . .  275
fitting later . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  277
malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  270
tow hook with electric unlocking . . . . . . . . . . . .  274

Towing the vehicle

emergency towing . . . . . . . . . . . . . . . . . . . . . . . . .  292
front towline anchorage . . . . . . . . . . . . . . . . . . . .  293
prior steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  292
rear towline anchorage . . . . . . . . . . . . . . . . . . . .  293
special characteristics . . . . . . . . . . . . . . . . . . . . .  290
tow bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  290

CarManuals2.com

368

Index

tow cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
towing prohibited . . . . . . . . . . . . . . . . . . . . . . . . . . . 291

Traction control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  151
Traffic information . . . . . . . . . . . . . . . . . . . . . . . . . . . .  251
Traffic information (TP) . . . . . . . . . . . . . . . . . . . . . . . .  241
Traffic programme

see TP (traffic information) . . . . . . . . . . . . . . . . . . 241

Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267

adjusting the headlights . . . . . . . . . . . . . . . . . . . .  272
anti-theft alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . .  270
connecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  270
exterior mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  268
hitching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  270
LED tail lights . . . . . . . . . . . . . . . . . . . . . . . . . .  268, 270
loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  272
malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  270
power socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  270
retrofitting a towing bracket . . . . . . . . . . . . . . . .  277
stabilisation of the towing vehicle and trailer
combination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  273
tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  268, 270
technical requirements . . . . . . . . . . . . . . . . . . . . .  268
tow cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  268, 270
towable loads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  272
Trailer assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  205
trailer mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  272
unlocking the tow hook electrically . . . . . . . . .  274
vertical load on the tow hitch . . . . . . . . . .  267, 272

Trailer Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 205

automatic brake operation . . . . . . . . . . . . . . . . .  206
check list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  206
malfunction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  205
operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  206
see Trailer Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . .  205
troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . .  207

Trailer mode

see Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267

Transportation of children . . . . . . . . . . . . . . . . . . . . . .  53
Trapdoor for transporting long objects . . . . . . .  264
Travel Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  175

connecting and disconnecting . . . . . . . . . . . . .  176
problems and solutions . . . . . . . . . . . . . . . . . . . . .  177
status display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  175

Trips abroad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

headlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Troubleshooting

AdBlue® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  282
DSG gearbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  145
Emergency Assist . . . . . . . . . . . . . . . . . . . . . . . . . . .  179
Start-Stop system . . . . . . . . . . . . . . . . . . . . . . . . . .  138
Trailer assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  207
Travel Assist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  177

Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  101
Turning off the lights . . . . . . . . . . . . . . . . . . . . . . . . . . .  99
Turning on the lights . . . . . . . . . . . . . . . . . . . . . . . . . . .  99
Tyre pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  319
Tyre pressure monitor system . . . . . . . . . . . . . . . .  330
Tyre pressure monitor systems

tyre pressure monitor indicator . . . . . . . . . . . . . 329

Tyre profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  321
Tyre repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  331
Tyre repair kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  331
Tyre tread depth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  321
Tyre wear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  321
Tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  317

accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  317
change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  323
directional tread pattern . . . . . . . . . . . . . . .  317, 328
for winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  322
foreign objects inserted . . . . . . . . . . . . . . . . . . . . .  317
new tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  318

snow chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  322
speed symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  317
tread wear indicators . . . . . . . . . . . . . . . . . . . . . . .  321
tyre pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  319
useful life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  319

Ultrasound sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Unlock and lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

by remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . .  73
doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  77
with the central locking switch. . . . . . . . . . . . . . . .  74

USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226
USB port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226

Vanity mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Variable luggage compartment floor . . . . . . . . . 261
Vehicle

data label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  351
engine specifications . . . . . . . . . . . . . . . . . . . . . . .  353
identification data . . . . . . . . . . . . . . . . . . . . . . . . . .  351
interior view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  8
lending or selling . . . . . . . . . . . . . . . . . . . . . . . . . . . .  217
overview (left hand drive) . . . . . . . . . . . . . . . . . . . . .  9
overview (right hand drive) . . . . . . . . . . . . . . . . . . .  10
raise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  327
unlocking and locking (Keyless Access) . . . . .  70
vehicle ID number . . . . . . . . . . . . . . . . . . . . . . . . . .  351
view from behind . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  7
view from the front . . . . . . . . . . . . . . . . . . . . . . . . . . . .  6

Vehicle care

wiper blade service position . . . . . . . . . . . . . . . . 286

Vehicle conservation . . . . . . . . . . . . . . . . . . . . . . . . . 337
Vehicle conservation products . . . . . . . . . . . . . . . . 337

CarManuals2.com

Index

369

Vehicle dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . .  354
Vehicle information . . . . . . . . . . . . . . . . . . . . . . . . . . . .  34
Vehicle location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  217
Vehicle seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  38
Vehicle settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  35
Vehicle tool kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  286
Ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  113
Vertical load on the tow hitch . . . . . . . . . . . . . . . . .  267

loading the trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . 272

Voice control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237

Android Auto™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  225
end . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  238
Siri™ (Apple CarPlay™) . . . . . . . . . . . . . . . . . . . . .  224
start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  238
wake word: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  237

Volume

set for external audio sources . . . . . . . . . . . . . . 234

Warning lamps

overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Warning triangle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 344
Washing the vehicle

cleaning the exterior . . . . . . . . . . . . . . . . . . . . . . .  338
high pressure cleaning equipment . . . . . . . . . .  337
interior cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . .  339
special care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  340
special characteristics . . . . . . . . . . . . . . . . . . . . . .  82

Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  351
Wheel balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  319
Wheel central trim . . . . . . . . . . . . . . . . . . . . . . . . . . . .  325
Wheel nuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  321

anti-theft device . . . . . . . . . . . . . . . . . . . . . . . . . . . 326
caps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 325

loosen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 326
torque . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 328

Wheel spanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 286
Wheels

change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  323
changing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  321
new wheels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  318
removing and attaching . . . . . . . . . . . . . . . . . . . .  328
snow chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  322
spare wheel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  324
wheel central trim . . . . . . . . . . . . . . . . . . . . . . . . . .  325
wheel nuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  321

Window controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Window washer

window washer lever . . . . . . . . . . . . . . . . . . . . . . . 106

Window washer system . . . . . . . . . . . . . . . . . . . . . . 307
Window washer water

check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  307
filling quantities . . . . . . . . . . . . . . . . . . . . . . . . . . . .  307
refill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  307

Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

anti-trap function . . . . . . . . . . . . . . . . . . . . . . . . . . . .  85
automatic opening/closing . . . . . . . . . . . . . . . . . .  85
automatic operation . . . . . . . . . . . . . . . . . . . . . . . . .  85

Windscreen

heating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Windscreen heating . . . . . . . . . . . . . . . . . . . . . . . . . .  120
Windscreen washer . . . . . . . . . . . . . . . . . . . . . . . . . .  106
Windscreen wipers . . . . . . . . . . . . . . . . . . . . . . . . . . .  106

functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  107
lift the blade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  286
rain and light sensor . . . . . . . . . . . . . . . . . . . . . . . .  107
reposition the blade . . . . . . . . . . . . . . . . . . . . . . . .  286
service position . . . . . . . . . . . . . . . . . . . . . . . . . . . .  286
special characteristics . . . . . . . . . . . . . . . . . . . . .  106
thermal washing ejectors . . . . . . . . . . . . . . . . . . .  107

Winter conditions

sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267

Winter tyres . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 322
Wiper and rear window wiper blades

cleaning the vehicle . . . . . . . . . . . . . . . . . . .  287, 338
replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  287
service position . . . . . . . . . . . . . . . . . . . . . . . . . . . .  286

WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220

CarManuals2.com

Seat Ateca (2023 year). Manual in english - page 11
