Seat Ateca (2023 year). Manual in english

Visibility

107

Windscreen wiper and rear window wiper systems

Note

●

When the vehicle stops while the wiper is

on, the wiper switches to operating tempora-
rily at the next lower wiping level.

●

If the driver’s or passenger door is opened

when the vehicle is stationary, the wipers re-
turn to the starting position and are switched
off. If the door is closed or the wiper lever is
moved within a few seconds, the wiper turns
on again.

●

In winter, the service position of the wipers

can be useful to make it easier to lift the wip-
ers off the windscreen when the vehicle is
going to be left stationary

›››

page 287

Wiper functions

Automatic rear window wipe

The rear wiper switches on automatically when
the wiper is switched on and reverse gear is en-
gaged. The automatic rear window wiper acti-
vation when engaging reverse gear can be ac-
tivated and deactivated in the infotainment sys-
tem, in the vehicle settings menu

›››

page 35

Heated windscreen washer nozzles

The heating defrosts any windscreen washer
nozzles that have frozen. The heat output is
automatically adjusted according to the ambi-
ent temperature when the ignition is switched

on. The heater only defrosts the nozzles, but
not the flexible pipes through which the washer
fluid passes.

Note

The windscreen will be wiped again approx-
imately 5 seconds after the windscreen
washer has been activated, provided the ve-
hicle is moving (“drip” function). If you acti-
vate the wipers less than 3 seconds after the
“drip” function, a new wash sequence will
begin without performing the last wipe. For
the “drip” function to work again, you have to
turn the ignition off and then on again.

Note

The wiper will try to wipe away any obsta-
cles that are on the windscreen. The wiper
will stop moving if the obstacle is still block-
ing its path. Remove the obstacle and switch
on the wiper again.

Rain and light sensor

Fig. 87

Windscreen wipers lever: adjust the

rain sensor

Fig. 88

Rain sensor sensitive surface

The rain sensor controls the frequency of the
windscreen wiper intervals, depending on the
amount of rain

›››

Push the lever to the desired position

›››

Fig. 87

Rain sensor off.

CarManuals2.com

108

Visibility

Rain sensor on; automatic wipe if neces-
sary.
Setting sensitivity level of rain sensor:
– Set control to the right: high sensitivity.
– Set control to the left: low sensitivity.

When the ignition is switched off and then back
on, the rain sensor stays on and starts operat-
ing again when the windscreen wipers are in
position

›››

Fig. 87

and the vehicle is travel-

ling at more than 16 km/h (10 mph).

Abnormal operation of the rain and light
sensor

The possible causes of anomalies and errone-
ous interpretations

in the sensitive surface area

›››

Fig. 88

of the rain sensor are, among others:

●

Damaged wipers

: a film of water on the

damaged blades may lengthen the activation
time, reduce the washing intervals or result in a
fast and continuous wipe.

●

Insects

: the impact of insects may cause the

wiper to activate.

●

Salt on the road

: in winter, salt spread on

the roads may cause an excessively long wipe
when the windscreen is almost dry.

●

Dirt

: dry dust, wax, coating on glass (Lotus

effect) or traces of detergent (car wash) may
reduce the effectiveness of the rain sensor or
make it react more slowly, later or not at all.

Regularly clean the sensitive surface of the rain
sensor

›››

Fig. 88

(arrow) and check for possi-

ble damage to the wiper blades.

●

Windscreen crack

: the impact of a stone will

trigger a single wipe cycle with the rain sensor
on. Next the rain sensor detects the reduction in
the sensitive surface area and adapts accord-
ingly. The behaviour of the sensor will vary with
the size of the damage caused by the stone.

WARNING

The rain sensor may not detect enough rain
to switch on the wipers.

●

If necessary, switch on the wipers man-

ually when water on the windscreen ob-
structs visibility.

Note

●

To remove wax and coatings, we recom-

mend a window cleaner containing alcohol.

●

Do not put stickers on the windscreen in

front of the rain sensor. This may cause sen-
sor disruption or faults.

Mirrors

General safety instructions

The exterior and interior mirrors allow the driver
to observe vehicles driving behind and adapt
his or her driving behaviour accordingly.

For safe driving, it is important for the driver
to adjust the exterior mirrors and interior mirror
correctly before setting off.
When looking through the exterior mirrors and
the interior mirror, it is not possible to see the
entire area behind and to the sides of the vehi-
cle. These areas outside the field of view are
known as the blind spot. Other road users and
objects may be in the blind spot.

WARNING

Adjusting the exterior mirrors and interior
mirror while driving can distract the driver.
This could cause accidents and lead to seri-
ous injuries

●

Only adjust the exterior mirrors and interior

mirror when the vehicle is stationary.

●

When parking, changing lanes, overtaking

or turning, always keep a close eye on your
surroundings, as other road users or objects
may also be in the blind spot.

●

Always make sure that the mirrors are ad-

justed correctly and that visibility to the rear
is not reduced by ice, snow, fogging or other
objects.

CarManuals2.com

Visibility

109

Mirrors

WARNING

A failure to accurately estimate the distance
to vehicles driving behind can lead to serious
accidents and injuries.

●

Curved (convex or aspherical) mirrors in-

crease the field of view and objects in them
appear smaller and further away.

●

Curved mirrors do not allow you to pre-

cisely calculate the distance to vehicles
driving behind, so using them when changing
lanes could cause serious accidents and in-
juries.

●

If possible, use the interior mirror to pre-

cisely calculate the distance to vehicles
driving behind you, or to other objects.

●

Always make sure you have sufficient visi-

bility to the rear.

WARNING

The automatic anti-dazzle mirrors contain an
electrolyte fluid which could leak if the mirror
is broken.

●

If it gets out, the electrolyte fluid can

irritate the skin, eyes and respiratory or-
gans, particularly in the case of people with
asthma or similar diseases. Immediately in-
hale enough fresh air and get out of the vehi-
cle, or open all windows and doors if this is
not possible.

●

If the electrolytic fluid comes into contact

with your eyes or skin, immediately rinse the
affected area with plenty of water for at
least 15 minutes and seek medical advice.

●

If the fluid comes into contact with foot-

wear or clothing, rinse immediately with
plenty of water for at least 15 minutes.
Clean thoroughly before using the footwear
or clothing in question again.

●

If the electrolytic fluid is swallowed, imme-

diately rinse the mouth with plenty of water
for at least 15 minutes. Do not induce vomit-
ing unless advised by a doctor. Immediately
seek medical attention.

NOTICE

Electrolyte fluid may leak if the automatic
anti-dazzle mirror is broken. This liquid at-
tacks plastic surfaces. Therefore, it should
be cleaned as fast as possible with a damp
sponge or similar.

Interior mirror

Fig. 89

Manual anti-dazzle function for rear

vision mirror

Manual anti-dazzle function for interior rear
vision mirror

●

To darken the rear view mirror, press the mir-

ror button updates

›››

Fig. 89

(arrow).

●

To return to the basic position, press the back

of the button.

Rear view mirror with automatic anti-dazzle
function

When the ignition is switched on, the sensors in
the mirror measure the light falling on it from
behind and in front.
The interior mirror automatically darkens based
on the measured values.
If the light falling onto the sensors is blocked or
interrupted, e.g. by a sunshade blind or hanging
objects, the automatic anti-dazzle interior mir-

CarManuals2.com

110

Visibility

Regulation in right-hand drive vehicles is symmetrical

ror does not work or does not work properly.
Similarly, the use of portable navigation devi-
ces attached to the windscreen or close to the
automatic anti-dazzle interior mirror can affect
the operation of the sensors

›››

The automatic anti-dazzle function is deactiva-
ted in certain situations, e.g. when reverse gear
is engaged.

WARNING

Light from screens of portable navigation
devices can cause malfunctions of the au-
tomatic anti-dazzle interior mirror and may
cause serious accidents and injuries.

●

Abnormal operation of the automatic anti-

dazzle function may result in it being impos-
sible to use the interior mirror to precisely
calculate the distance to vehicles driving be-
hind, or to other objects.

Adjusting the exterior mirrors

Fig. 90

Detail of the driver door: control for the

exterior mirror.

Turn the control to the corresponding position.

Moving the control to the desired position
adjusts the mirrors on the driver's side ( ,
left) and on the passenger's side ( , right)

in the desired direction.

Depending on the equipment fitted on
the vehicle, the mirrors may be heated ac-
cording to the outside temperature.

Folding the mirrors

›››

The exterior mirror cannot be adjusted and
all functions are deactivated.

Activating exterior mirror functions

The following exterior mirror functions can
be activated and deactivated in the vehi-
cle settings menu of the infotainment system

›››

page 35

Synchronized regulation of the exterior mir-
rors

The synchronised mirror setting simultaneously
adjusts the right hand exterior mirror when the
left mirror is adjusted

●

Turn the control to position

●

Adjust the left-hand exterior mirror. The right

exterior mirror will be adjusted at the same time
(synchronised).

●

If necessary, correct the setting of the right

hand mirror: turn the control to position

Fold the rearview mirrors when locking the
vehicle

When the vehicle is locked or unlocked from
the outside, the exterior mirrors can be folded in
or out automatically, depending on the equip-
ment. For this purpose, the rotary control has to
be in position , , , or .
If the rotary control of the electric exterior mir-
rors is in the folded position, the exterior mirrors
remain folded.

CarManuals2.com

Visibility

111

Sun protection

Regulation in right-hand drive vehicles is symmetrical

Memory function

The memory buttons

›››

page 96

can be used

to save and turn on settings for the exterior mir-
rors.
The settings will also be saved in the key or in
the user of the online services.

Saving the passenger rear view mirror set-
tings for reversing

●

Switch the ignition on.

●

In the infotainment system, select

Settings > Mirrors and wipers >

Mirrors > Lower in reverse gear

›››

page 35

●

Select the R

position on the control.

●

Select reverse gear.

●

Adjust the front passenger exterior mirror so

that you can see, for example, the kerb area
well.

●

Release the reverse gear.

●

The adjusted position for the rear view mirror

is stored.

Activating the passenger side exterior mirror
settings for reversing

●

Turn the exterior mirror control knob to posi-

tion

●

Engage reverse gear with the ignition

switched on. The right-hand exterior rear-view
mirror will move to the saved position.
The passenger side exterior mirror leaves the
saved reversing position when the vehicle is
travelling faster than approx. 15 km/h (9 mph),
or if the control is turned from position to an-
other position.

WARNING

Fold and unfold the exterior mirror, taking
care to avoid injuries.

●

Only fold or unfold the exterior mirror

when there is no-one in the way of the mirror.

●

When moving the mirror, take care not to

trap fingers between the mirror and the mir-
ror bracket.

NOTICE

●

Before washing the vehicle in an automatic

car wash, please make sure to fold the ex-
terior mirrors in to prevent them from being
damaged.

●

The electrically folding exterior mirrors

must only be operated electrically, not by
hand, and this could damage their electric
drive.

For the sake of the environment

Do not leave the exterior mirror heating on
for longer than necessary. Otherwise it cau-
ses unnecessary energy consumption.

Note

If the electrical adjustment should fail to op-
erate, both of the mirrors can be adjusted
by hand by lightly pressing the edge of the
mirror glass.

Sun protection

Sun blind

Fig. 91

Sun visor

CarManuals2.com

112

Visibility

Options for adjusting driver and front pas-
senger sun visors

●

Lower the sun visor towards the windscreen.

●

The sun visor can be pulled out of its mount-

ing and turned towards the door

›››

Fig. 91

●

Swing the sun visor towards the door, longitu-

dinally backwards.
There is a vanity mirror on the sun visor, with
a cover. When the cover is opened

a light

comes on.
The lamp goes out when the vanity mirror cover
is closed or the sun visor is pushed back up.

WARNING

Folded sun blinds can reduce visibility.

●

Always store sun blinds and visors in their

housing when not in use.

Note

The light above the sun visor automatically
switches off after a few minutes in certain
conditions. This prevents the battery from
discharging.

CarManuals2.com

Air conditioning

113

Heating, ventilation and cooling

Air conditioning

Heating, ventilation and
cooling

Introduction

Depending on the vehicle’s equipment, several
systems may have been fitted:

●

The

manual air conditioning system

heats,

cools and dehumidifies the air.

●

The

Climatronic

is an automatic air condi-

tioner that heats, cools and dehumidifies the
air.

With the Climatronic’s automatic mode it is
possible to automatically regulate the air tem-
perature, distribution and flow to achieve opti-
mal thermal comfort.
To switch a specific function on, press the ap-
propriate button. Press the button again to
switch off the function.
The illuminated LEDs next to the buttons indi-
cate that the function is switched on.
In the air conditioning settings in the info-
tainment system, the yellow function buttons
indicate that the function is switched on

›››

page 118

Economic use of the air conditioning

When the air conditioning is switched on, the
compressor consumes engine power and has
influence on fuel consumption.
The air conditioning operates most effectively
with the windows and the sunroof closed. How-
ever, if the passenger compartment has heated
up after standing in the sun for some time, the
air inside can be cooled more quickly by briefly
opening the windows and the sunroof.

Dust and pollen filter

The dust and pollen filter with its activated
charcoal cartridge serves as a barrier against
impurities in the air taken into the vehicle inte-
rior.
The dust and pollen filter must be changed reg-
ularly so that air conditioner performance is not
adversely affected.
If the filter loses efficiency prematurely due to
use in areas with very high levels of air pollu-
tion, the filter must be changed more frequently
than stated in the Service Schedule.

Air vents

To ensure proper heating, cooling and ventila-
tion in the vehicle interior, the air vents must
remain open.
There are other additional, non-adjustable air
vents in the instrument panel, in the footwells
and in the rear area of the passenger compart-
ment.

WARNING

Reduced visibility through the windows in-
creases the risk of serious accidents.

●

Always ensure that all windows are free of

ice and snow, and that they are not fogged,
so as to maintain good visibility of everything
outside.

●

Only drive when you have good visibility.

●

Always ensure that you use the air condi-

tioner and heated rear window to maintain
good visibility.

●

Never leave the air recirculation on for a

long period of time. If the cooling system
is switched off and air recirculation mode
switched on, the windows can mist over very
quickly, considerably limiting visibility.

●

Switch air recirculation mode off when it is

not required.

NOTICE

Food, medicines and other objects sensitive
to heat or cold may be damaged or made
unsuitable for use by the air coming from the
vents.

●

Never place food, medicines or other tem-

perature-sensitive objects close to the air
vents.

CarManuals2.com

114

Air conditioning

Note

●

When the cooling system is turned off, air

coming from the outside will not be dried. To
prevent fogging of the windows, SEAT recom-
mends leaving the cooling system turned on.
To do this, press the function button

. The

icon should light up.

●

The maximum heat output required to de-

frost windows as quickly as possible is only
available when the engine has reached its
normal running temperature.

●

Keep the air intake slots in front of the

windscreen free of snow, ice and leaves to
ensure heating and cooling are not impaired,
and to prevent the windows from misting
over.

●

The air from the vents flows through the ve-

hicle interior and is extracted by slots in the
luggage compartment designed for this pur-
pose. Therefore, you should avoid obstruct-
ing these slots with any kind of object.

●

It is advisable to turn on the air condition-

ing at least once a month, to lubricate the
system gaskets and prevent leaks. If a de-
crease in the cooling capacity is detected,
a Technical Service should be consulted to
check the system.

●

When the engine is under extreme strain,

switch off the compressor for a moment.

CarManuals2.com

Air conditioning

115

Heating, ventilation and cooling

Climatronic controls and functions

Fig. 92

In the centre console: Climatronic control

panel.

Temperature

The temperature of the right and left sides can
be adjusted separately using the adjusters. The
selected temperature is shown on the display of
the climate control panel.

Synchronizes the driver’s temperature
settings to the passenger side. Activates
the temperature regulator for the pas-

senger side to set a different temperature.

In this mode, the system automatically
regulates the interior temperature, fan
speed and air distribution for optimal

thermal comfort. The

mode will deac-

tivate as soon as manual changes are
made to the fan speed, air distribution,
windscreen demisting or air recirculation.

Switches the cooling system on or off.
The cooling mode cools and dehumidi-
fies the air.

The recirculation of air and the cooling
system turn on automatically and air dis-
tribution adjusts automatically to the posi-

tion .

Adjust the fan power.

The defrost/demisting function removes
ice and fog from the windscreen. The air
is dehumidified and the fan is set high.

Open the air conditioning settings in
the infotainment system

›››

page 118

The climate control operation and set-

tings menu will be displayed in the infotain-
ment system screen.

The heated rear window only works when
the engine is running and switches off
automatically after a maximum of 10 mi-

nutes. It should be switched off as soon as
the glass is demisted. By saving electrical
power you can also save fuel.

To avoid possible damage to the battery,
an automatic temporary disconnection of
this function is possible, coming back on
when normal operating conditions are re-
established.

Switches the air recirculation mode on
and off

›››

page 118

Switches seat heating on and off

›››

page 119

Switches the auxiliary heater on or off

›››

page 122

Switch off the air conditioning system.
If the fan is manually set to , it also
switches off.

Air distribution

The airflow adjusts automatically for comfort. It
can also be manually distributed to the desired
zone by pressing the corresponding button:

CarManuals2.com

116

Air conditioning

The airflow is directed towards the chest

The airflow is directed towards the foot-
well.
The airflow is directed at the windscreen.

Air Conditioning settings in Infotainment

Open the auxiliary heater menu in the air con-
ditioning settings in the infotainment system

›››

page 122

The Air Care Climatronic allergen filter can re-
duce the amount of harmful substances that
get inside, including allergens

›››

page 118

Windscreen heating

Switches the heated windscreen on and off
with the engine running

›››

page 120

Steering wheel heating

Switches steering wheel heating on and off

›››

page 120

CarManuals2.com

Air conditioning

117

Heating, ventilation and cooling

Manual air conditioning controls

Fig. 93

In the centre console: manual air

conditioning control panel.

Cooling mode

Press the button to switch on or off the cooling
system.

Temperature

Turn the control to adjust the temperature.

Fan

Turning the regulator

sets the fan power.

At level 0 the fan and manual air conditioning
are disconnected. Level 6 is the maximum.

Air distribution

Turning regulator

distributes the air to the

desired zone:

The airflow is directed towards the chest

The airflow is directed towards the chest
and the footwell area.

The airflow is directed towards the foot-
well.
The airflow is directed towards the wind-
screen and the footwell area.

Defrost/demist function.

The air flow

is directed towards the windscreen.Air re-
circulation is automatically deactivated

or not activated in the first place. Increase
the fan power to clear the windscreen of
condensation as soon as possible. To de-
humidify the air, the cooling system will au-
tomatically switch on.

Maximum cooling power

When the regulator is in position air recircu-
lation and the cooling system switch on auto-
matically. Set the air distribution to position
to achieve thermal comfort in the shortest pos-
sible time.

Rear window heating

This only works when the engine is running and
switches off automatically after a maximum of
10 minutes.
It should be switched off as soon as the glass
is demisted. By saving electrical power you can
also save fuel.
To avoid possible damage to the battery,
an automatic temporary disconnection of this
function is possible, coming back on when nor-
mal operating conditions are re-established.

CarManuals2.com

118

Air conditioning

Air recirculation

Seat heating

Switching off

Manually set the fan to .

Setting the temperature on the info-
tainment system

The air conditioning settings in the infotainment
system are available in the Climatronic. De-
pending on the vehicle equipment.

Open the air conditioning menu

●

Press the

button on the Climatronic con-

trol panel.
The current air conditioning settings are dis-
played at the top of the screen. The current air
conditioning settings are displayed at the top of
the screen.

Arrow colour representation

The colour represented by the arrows does not
indicate the outlet temperature of the air, but
the requested temperature depending on the
surrounding conditions.

General settings submenu

Sets the following functions:

●

Automatic air recirculation mode

›››

page 118

●

Automatic front window heating

›››

page 120

Presets submenu

Sets the cooling system to automatic or man-
ual mode, or switches off the air conditioning.

Air conditioning profile

Adjust the power of the fan in AUTO mode.
Valid for the front and rear air conditioning con-
trol unit.

Air recirculation

Air recirculation mode prevents the ambient air
from entering the interior.
When the outside temperature is very high,
selecting manual air recirculation mode for a
short period refreshes the vehicle interior more
quickly.
For safety reasons, air recirculation is switched
off in the following situations:

●

When the button is pressed or the air dis-

tributor is turned to

●

When a sensor detects that the vehicle's win-

dows could mist up.

Switching the manual air recirculation mode
on and off

●

Press the

button to switch manual air re-

circulation on or off.

Climatronic automatic air recirculation
mode

With the automatic air recirculation mode ac-
tivated, the entry of fresh air into the cabin in-
terior is enabled. If the system detects a high
concentration of hazardous substances in the
ambient air, air recirculation mode is switched
on automatically. When the level of impurities
drops to within a normal range, recirculation
mode is switched off.
The system is unable to detect unpleasant
smells.
The air recirculation will

not

connect automati-

cally in versions without humidity sensor and in
the following external conditions:

●

The outside temperature is lower than +3°C

(+38°F).

●

The cooling system is switched off and the

outside temperature is below +10°C (+50°F).

●

The cooling system is switched off, the out-

side temperature is below +15°C (+59°F) and
the windscreen wipers are switched on.

CarManuals2.com

Air conditioning

119

Heating, ventilation and cooling

Air Care Climatronic with allergen filter

The Air Care Climatronic allergen filter can
reduce the amount of harmful substances, in-
cluding allergens, that get inside.
If the Air Care option is switched on, the air con-
ditioning’s air recirculation mode is maximised
until there is a risk of the windows misting up
due to humidity inside the vehicle and the out-
side temperature, in models without a humidity
sensor.

●

Open the air conditioning settings in the info-

tainment system

›››

page 118

●

Switch the Air Care function on or off using

Air Care active

WARNING

Stuffy or used air will increase fatigue and
reduce driver concentration possibly result-
ing in a serious accident.

●

Never leave the fresh air fan turned off or

use the air recirculation for long periods of
time; the air in the vehicle interior will not be
refreshed.

NOTICE

In vehicles with an air conditioner, do not
smoke when air recirculation is switched on.
The smoke may be deposited on the cool-
ing evaporator and on the active combina-
tion filter and cause permanent unpleasant
odours.

Note

When the outside temperature is very high,
briefly switching on the air recirculation
mode helps to cool the vehicle interior more
quickly.

Seat heating

With the engine running, the front seats and
side rear seats can be electrically heated to
three power levels.

Control seat heating

●

Press or on the control panel to turn on

the seat heating at maximum power.

●

Press the or button repeatedly to adjust it

to the required level.

●

To turn off seat heating, press or several

times until no LEDs are lit.
If the ignition is switched on again in approx.
the next 10 minutes, the driver seat heating is
automatically turned on to the level set the last
time.

Cases in which the heat seating should not
be switched on

Do not switch the seat heating on if any of the
following conditions are met:

●

The seat is occupied by a person with limited

perception of pain or temperature.

●

The seat is not occupied.

●

The seat has a cover.

●

A child seat has been installed on the seat.

●

The seat cushion is wet or damp.

●

The outdoor or indoor temperature is greater

than +25°C (77°F).

WARNING

People who cannot perceive pain or temper-
ature because of medications, paralysis or
chronic diseases (e.g. diabetes) or have a
limited perception of these, may suffer burns
to the back, buttocks or legs when using seat
heating.

●

People with limited pain and temperature

thresholds must never use seat heating.

●

If an abnormality in the device's tempera-

ture control is detected, have it checked by a
specialist workshop.

WARNING

If the fabric of the cushion is wet, this can
adversely affect the operation of the seat
heating, increasing the risk of burns.

●

Make sure the seat cushion is dry prior to

using the seat heater.

●

Do not sit on the seat with clothing that is

wet or damp.

●

Do not leave clothing that is wet or damp

on the seat.

●

Do not spill liquids on the seat.

CarManuals2.com

120

Air conditioning

NOTICE

●

To avoid damaging the heating elements of

the seat heaters, please do not kneel on the
seat or apply sharp pressure to a single point
on the seat cushion or backrest.

●

Liquids, sharps objects and insulating ma-

terials (e.g. covers or child seats) can dam-
age the seat heating.

●

In the event of smells, switch off the seat

heating immediately and have it inspected
by a specialised workshop.

●

If the original seat upholstery is replaced

by another material, the seat heating may
overheat or its operation may be limited.

For the sake of the environment

The seat heating should remain on only when
needed. Otherwise, it is unnecessary energy
consumption.

Steering wheel heating

Steering wheel heating works only with the en-
gine running.
The selected steering wheel heating level will
be displayed on the instrument panel display.

Adjust the steering wheel heating by press-
ing on the multifunction steering wheel

●

Short press (less than 1 second):

The heating is switched on at its maximum level.
Press the steering wheel button repeatedly to
set the desired level. To switch off steering
wheel heating, press the steering wheel button
repeatedly until the heated steering wheel
icon is displayed on the instrument cluster.

●

Long press (more than 1 second):

The heating is switched off directly from the
current operating level. Another long press on
the button switches on the heating directly at
the last level saved before switching off.

Automatic disconnection

The steering wheel heating will be switched off
automatically when any of the following condi-
tions are met:

●

Electrical energy consumption is too high.

●

The steering wheel heating system is faulty.

●

If the ignition is switched off.

Windscreen heating

Fig. 94

Windscreen humidity and temperature

sensor.

Fig. 95

Areas for placing electronic

accessories

The brake servo works only when the engine is
running.

CarManuals2.com

Air conditioning

121

Heating, ventilation and cooling

The heated windscreen is comprised of a set
of heated wires placed between the layers of
the windscreen which, when electric current is
supplied to them, heat up and cause the tem-
perature of the glass to rise.
Its function is to assist the air-conditioning sys-
tem to prevent the windscreen from misting up
or to demist it faster if it does mist up.
The system can be switched on manually or
automatically.

Manual activation

●

Press the button in the air conditioning

settings in the infotainment system.
The heated windscreen is switched off based
on the outside temperature and, in any case,
after approximately 8 minutes.

Automatic activation

The heated windscreen switches on automati-
cally when a window is at risk of misting up.

●

Open the air conditioning settings in the info-

tainment system

›››

page 118

●

Switch the automatic heated windscreen on

or off.
The automatic heated windscreen is switched
on, even when the air conditioning is switched
off.

Thermal windscreen using the defrost func-
tion

If the defrost function is switched on and a sen-
sor detects that the windscreen could mist up,
the heated windscreen switches on.

When does the heated windscreen switch
off?

The heated windscreen switches off when one
of the following conditions is met:

●

Power consumption is too high.

●

The air conditioner fuse is faulty.

●

If the preset time has elapsed.

Location of electronic accessories

The windscreen heating has a film that reflects
infra-red rays. This film interferes with the op-
eration of electronic accessories (e.g. remote
tolls or similar devices). To avoid this, there are
defined areas next to the interior mirror where
these devices can be placed

›››

Fig. 95

(ar-

rows).
These areas should not be covered and stickers
should not be placed on them, as this could
cause anomalies in the operation of electronic
components placed there.

Troubleshooting

The cooling system cannot be switched on
or its operation is limited

If the air conditioning system cannot be
switched on, this may be caused by the follow-
ing:

●

The engine is not running.

●

The fan is switched off.

●

The air conditioner fuse has blown.

●

The outside temperature is lower than ap-

proximately 0°C (+32°F).

●

The air conditioner compressor has been

temporarily switched off because the engine
coolant temperature is too high.

●

Another fault in the vehicle. Have the air con-

ditioner checked by a specialised workshop.

The heating and fresh air system cannot be
switched on or operates in a limited way

●

The heating and fresh air system and the de-

frost function operate best when the engine is
hot.

●

If the fault continues, consult a specialised

workshop.

CarManuals2.com

122

Air conditioning

The windows are misted up

Windows mist up when they are cooler than
the ambient temperature and the air is very
damp. Cold air can absorb less moisture than
hot air, so the windows mist up more often in
cold weather.

●

The air vent in front of the windscreen keeps

it free of ice, snow and leaves, which improves
the performance of the heating and cooling
systems.

●

The air grooves located at the rear of the

luggage compartment must be kept clear to
allow the air to circulate through the vehicle
from front to back.

●

Switch on the demist function.

Change the temperature unit (Climatronic)

The temperature display can be changed from
Celsius to Fahrenheit on the Infotainment sys-
tem screen using the function button

> Set-

tings > Units

Water or water vapour under the vehicle

If the humidity and temperature outside the ve-
hicle are high,

condensation

can drip off the

evaporator in the cooling system and form a
pool underneath the vehicle. This is normal and
does not indicate a leak!
When the outside humidity is high and the am-
bient temperature is low, condensation water
may evaporate when the stationary air condi-
tioning is operating. In this case, steam may

be released from underneath the vehicle. This
does not mean that the vehicle has any dam-
age.

Note

After starting the engine, any residual humid-
ity in the air conditioner could mist over the
windscreen. Switch on the defrost function
as soon as possible to clear the windscreen
of condensation.

Auxiliary heating and venti-
lation

Introduction

With the auxiliary heating and ventilation, it is
possible to heat the vehicle interior in winter
and ventilate it in summer. It can also be used
to demist the windscreen and remove ice or
even a thin layer of snow. The auxiliary heating
is powered by fuel from the vehicle’s tank and
can even continue to operate when the ignition
is switched off. The auxiliary ventilation is pow-
ered by the 12-volt vehicle battery.
The auxiliary heating can be controlled by the
SEAT CONNECT mobile app or through the My-
SEAT website.

The auxiliary heater can be switched on using
the fast heating button of the air conditioning
controls, with the remote control or by previ-
ously programming a departure time in the aux-
iliary heater menu of the infotainment system.
If the outside temperature is very high, the vehi-
cle interior can be ventilated with the engine off
using the auxiliary heater.

Auxiliary heating exhaust system

The exhaust gases generated by the auxiliary
heater are removed via an exhaust pipe fitted
underneath the vehicle. This exhaust pipe must
not be blocked by snow, mud or anything else.

WARNING

The auxiliary heater exhaust fumes contain
carbon monoxide, an odourless and colour-
less toxic gas. Carbon monoxide can cause
people to lose consciousness. It can also
cause death.

●

Never switch on the auxiliary heater or

leave it running in enclosed spaces or areas
with no ventilation.

●

Never programme the auxiliary heater so

that it switches itself on and is running in an
enclosed space or an area with no ventila-
tion.

CarManuals2.com

Air conditioning

123

Auxiliary heating and ventilation

WARNING

The components of the auxiliary heater are
extremely hot and could cause a fire.

●

Always park your vehicle so that no part

of the exhaust system can come in contact
with easily flammable materials that might
be below the vehicle, such as dried grass.

NOTICE

Never place food, medicines or other tem-
perature-sensitive objects close to the air
vents. Food, medicines and other objects
sensitive to heat or cold may be damaged
or made unsuitable for use by the air coming
from the vents.

Switching the auxiliary heater and
ventilation on and off

The auxiliary heating can operate with the igni-
tion switched on and off.

Open the Auxiliary heater menu

●

Open the air conditioning settings in the info-

tainment system.

●

Press the function button.

Switching on the auxiliary heater

The auxiliary heating can be switched off in the
following ways:

●

Press the immediate heat button on the air

conditioning controls.

●

: Press the button on the remote control

›››

page 124

●

: Set the departure time

›››

page 125

●

: Using the App or MySEAT website.

If the 12-volt vehicle battery is low on charge or
the tank is empty, the auxiliary heating cannot
be switched on.

Switch off the auxiliary heating manually

The auxiliary heater can be switched off man-
ually in the following ways:

●

Press the immediate heat button on the air

conditioning controls.

●

: Press button on the remote control.

●

: Using the SEAT CONNECT mobile app or

the MySEAT website.

The auxiliary heater switches off automati-
cally

●

At the scheduled departure time or the end of

the set operating period

›››

page 125

●

If the yellow indicator lamp (fuel gauge)

lights up.

●

If the 12-volt battery's charge level drops

sharply.
To burn the remaining fuel in the auxiliary heat-
ing, it continues to operate briefly once it has
been turned off manually or automatically.

Using the auxiliary heating as a supplemen-
tary heater

If the engine has been started, the auxiliary
heating can continue to operate as a supple-
mentary heating system. The following condi-
tion must be met for this to happen:

●

The

Automatic supplementary heater

function can be switched on in the infotainment
system's air conditioning settings.

●

The outside temperature is lower than +5 °C

(+41 °F).
The supplementary heating system switches off
again automatically after a while.

Note

●

Noises will be heard while the auxiliary

heater is running.

●

When the air humidity is high and the in-

side temperature low, condensation from the
heating and ventilating system may evapo-
rate when the auxiliary heater is switched
on. In this case, steam may be released from
underneath the vehicle. This does not mean
that there is a vehicle malfunction.

●

If the vehicle is tilted, e.g. if parked on a

slope, the operation of the auxiliary heater
may be restricted if the fuel tank level is low
(just above the reserve level).

●

If the auxiliary heater is used a number of

times for a long period of time, the 12-volt
battery will lose its charge. To recharge the
battery, the vehicle must be driven for a

CarManuals2.com

124

Air conditioning

number of kilometres from time to time. As
a guideline: the journey should last approxi-
mately as long as the heater was connected.

●

At temperatures below +5 °C (+41 °F), the

auxiliary heater may switch itself on auto-
matically when the engine is switched on.
The auxiliary heater is switched off again af-
ter a certain time.

●

While the vehicle is stopped, the auxiliary

heating can be switched on up to a maximum
of three consecutive times in a row with the
maximum operating duration.

Remote control

Fig. 96

Independent heating: radiofrequency

remote control key

Switch on

: Press the button for about one

second

Switch off

: Press the button for about one

second

If the buttons of the remote control are pressed
unnecessarily, it could switch on the auxiliary
heater involuntarily, even when it is out of range
or when the control lamp is flashing.

Remote control LED

When the buttons are pressed, the LED of re-
mote control

›››

Fig. 96

gives the user a

range of information:

It lights up for approx. 2 seconds

●

In green

: The auxiliary heater has been

switched on using the button.

●

In red

: The auxiliary heater has been switched

off using the button.

Flashes slowly for approx. 2 seconds

●

In green

: No on signal has been received. The

remote control is out of range. Move closer to
the vehicle.

●

In red

: No off signal has been received. The

remote control is out of range. Move closer to
the vehicle.

It flashes irregularly

●

In green

: The independent heating is blocked.

Possible causes: the fuel tank is almost empty,
the 12-volt battery charge is very low or there is
a fault.

It lights up or flashes steadily

●

In orange (then in green or in red)

: The remote

control battery is almost flat. However, the on
or off signal has been received.

●

In orange (then flashes green or red)

: The re-

mote control battery is almost flat. No on or off
signal has been received.

Flashes for around 5 seconds

●

In orange

: The remote control battery is flat.

No on or off signal has been received.

Range

The range of the remote control is a few hun-
dred meters when the battery is fully charged
and under optimal conditions.

●

A distance of at least 2 m must be left be-

tween the remote control and the vehicle.

●

There should be no obstacle between the re-

mote control and the vehicle.

●

Secure the remote control with the chrome

›››

Fig. 96

vertically facing upwards.

●

Do not cover the antenna.

The range of the control is considerably less in
poor weather conditions, if there are buildings
in the vicinity or if the battery is low.

Changing the remote control battery

If the indicator lamp does not come on, the re-
mote control's battery must be replaced.

CarManuals2.com

Air conditioning

125

Auxiliary heating and ventilation

●

Insert a suitable tool, e.g. a screwdriver, into

the indentation in the remote control housing, in
the direction of the arrow

›››

Fig. 96

●

With the help of the same tool, lift the lid until

the housing locking element is released.

●

Slightly move the cover in the direction of the

arrow.

●

Remove the cover.

●

To remove the battery, carefully insert a tool

like a screwdriver into the indentation next to
the battery.

●

Use the screwdriver to lift up the battery until

it releases from its housing.

●

Remove the old battery.

●

Insert a new battery of the same type and

make sure it clicks into place. When inserting
the battery, make sure that the polarity is cor-
rect.

●

Fit the cover onto the remote control housing.

●

Slide the cover in the direction opposite to the

arrow until it clicks into place

›››

Fig. 96

WARNING

Swallowing a battery with a 20 mm diameter
or any other button battery can cause seri-
ous and even fatal injuries within a very short
time.

●

Always keep the remote control, keyrings

with batteries, the spare batteries, button
batteries and all other batteries over 20 mm
out of reach of children.

●

If you suspect that someone may have

swallowed a battery, seek immediate medi-
cal attention.

NOTICE

●

The radio frequency remote control con-

tains electronic components. Therefore,
avoid getting it wet and exposing it to knocks
or direct sunlight.

●

The use of inappropriate batteries may

damage the radio frequency remote control.
For this reason, always replace the used bat-
tery with another of the same voltage, size
and specifications.

For the sake of the environment

●

Please dispose of your used batteries cor-

rectly and with respect for the environment.

●

The remote control battery may contain

perchlorate. Observe the legal provisions re-
garding disposal.

●

Care should be taken so as not to operate

the remote control unintentionally so as to
prevent the auxiliary heater being switched
on accidentally.

Programming the auxiliary heater

Before

programming it, check that the vehicle's

date and time are set correctly

›››

The auxiliary heater is programmed in the

Aux-

iliary heater

menu of the infotainment sys-

tem.

Set the operating duration of the auxiliary
heating

●

Open the

Auxiliary heater

menu.

●

Press the

Set

function button.

●

To set the operating time, press the

Operat-

ing duration

button.

The set operating duration is taken into account
when the auxiliary heating is switched on using
the immediate heat button or the remote
control.
The maximum duration of the auxiliary heating
is 60 minutes.

CarManuals2.com

126

Air conditioning

Set the departure time

Activating this function only affects the heating
or ventilation. The departure time must be reac-
tivated whenever the vehicle is started.

●

Open the

Auxiliary heater

menu.

●

Press the

Set

function button.

●

Select one of the memory spaces for a

De-

parture time

●

Press the

Activate

function button.

Manual air conditioning

: The scheduled depar-

ture time determines when the auxiliary heating
or ventilation will be switched off. The start of
the heating or ventilation process depends on
the programmed duration of operation.

Climatronic

: The vehicle uses the programmed

departure time to automatically calculate the
time at which the heating or ventilation process
should begin to attain the set temperature.
A departure time can be scheduled in the App
or on the MySEAT website.

Checking the programming

If a departure time is activated, the yellow LED
on the immediate heat button lights up on
the Climatronic control panel, approximately
ten seconds after the ignition is switched off.

WARNING

Never programme the auxiliary heater so
that it switches itself on and is running in
an enclosed space or an area with no ven-
tilation. The auxiliary heater exhaust fumes
contain carbon monoxide, an odourless and
colourless toxic gas. Carbon monoxide can
cause people to lose consciousness. It can
also cause death.

CarManuals2.com

Driving

127

Driving indications

Driving

Driving indications

Pedals

●

Ensure that you can always press the accel-

erator, brake and clutch pedals unimpaired to
the floor.

●

Ensure that the pedals can return unimpaired

to their initial positions.

●

Ensure that the floor mats are securely fas-

tened during the trip and do not obstruct the
pedals

›››

Only use floor mats which leave the pedals
clear and which are secured to prevent them
from slipping. You can obtain suitable floor mats
from a specialised dealership. Fasteners for
floor mats are fitted in the footwells.

Wear suitable footwear

Always wear shoes which support your feet
properly and give you a good feeling for the
pedals.

WARNING

●

Restricting pedal operation can lead to

critical situations while driving.

●

Never lay or fit floor mats or other floor

coverings over the original floor mats. This
would reduce the pedal area and could ob-
struct the pedals. Risk of accident.

●

Never place objects in the driver footwell.

An object could move into the pedal area
and impair pedal operation.

Selecting the optimal gear

Depending on the equipment on the instrument
panel screen, a recommendation is shown with
the gear that should be engaged to optimise
consumption.
On vehicles with

automatic transmission

, it is

only displayed when driving in Tiptronic mode

›››

page 141

No recommendation will appear if the optimal
gear is engaged. The current gear will be dis-
played.

Display

Meaning

Optimum gear.

4 5

Changing to a higher gear is rec-
ommended.

2 1

Changing to a lower gear is rec-
ommended.

Information regarding the “cleanliness” of
the particulate filter

When the exhaust system detects that the par-
ticulate filter is close to saturation, this system’s
self-cleaning function recommends the optimal
gear for that function

›››

page 283

WARNING

The gear change recommendation is an aux-
iliary function and in no case should be a
substitute for careful driving.

●

Responsibility for selecting the correct

gear, depending on the circumstances, rests
solely with the driver.

For the sake of the environment

Selecting the correct gear can help to save
fuel.

Note

The recommended gear display turns off
when you are no longer in tiptronic mode.

Economical and environmentally
friendly driving

Fuel consumption, environmental pollution and
wear to the engine, brakes and tyres all depend
largely on driving style. Consumption can be
reduced between 10-15% with an efficient driv-
ing type. The following section gives you some

CarManuals2.com

128

Driving

tips on lessening the impact on the environment
and reducing your operating costs at the same
time.

Active cylinder management (ACT®)

Depending on vehicle equipment, the active
cylinder management (ACT®) may deactivate
some of the engine cylinders if the driving sit-
uation does not require too much power. The
number of active cylinders can be seen on the
instrument panel display

›››

page 16

Foresight when driving

If you think ahead when driving, you will need
to brake less and thus accelerate less. Take ad-
vantage of the inertia of the vehicle whenever
possible, with a

gear engaged

. This takes ad-

vantage of the engine braking effect, reducing
wear on the brakes and tyres. Emissions and
fuel consumption will drop to zero.

Changing gear to save energy

An effective way of saving is to change

in ad-

vance

to a higher gear.

Manual gearbox:

change from first to second

gear as soon as possible. Choosing the cor-
rect gear saves fuel. Select the highest possi-
ble gear suitable for the driving situation (the
engine should continue to run with cyclical reg-
ularity).

Automatic transmission:

accelerate gradually

and without reaching the “kick-down” position.

Avoid driving at high speed

Avoid travelling at your vehicle’s top speed,
whenever possible. Fuel consumption, emission
of harmful gases and noise pollution multiply as
speed is increased. Driving at moderate speeds
will help to save fuel.

Reduce idling time

In vehicles with the Start-Stop system idling is
automatically reduced. In vehicles without the
Start-Stop system it is worth switching off the
engine, for example, at level crossings and at
traffic lights that remain red for long periods of
time. When an engine has reached operating
temperature, and depending on the cylinder
capacity, keeping it switched off for a minimum
of about 5 seconds already saves more than
the amount of fuel necessary for restarting.
The engine takes a long time to warm up when
it is idling. Mechanical wear and pollutant emis-
sions are also especially high during this initial
warm-up phase. It is therefore best to drive
off immediately after starting the engine. Avoid
running the engine at high speed.

Regular maintenance

Regular servicing helps in saving fuel even be-
fore the engine is started. A well-serviced en-
gine gives you the benefit of

improved fuel

efficiency

as well as maximum reliability and

an enhanced resale value. A badly serviced en-
gine can consume up to 10% more fuel than
necessary.

Avoid short journeys

The engine and catalytic converter need to
reach their optimal

operating temperature

order to minimise fuel consumption and emis-
sions.
A cold engine consumes a disproportionate
amount of fuel. The engine reaches its work-
ing temperature after about four kilometres (2.5
miles), when fuel consumption will return to a
normal level.

Check tyre pressure

Always make sure the tyres are inflated to the
correct pressures

›››

page 319

to save fuel. If

the pressure is below half bar, fuel consumption
may increase by 5%. Due to the greater rolling
resistance, under-inflation also increases tyre
wear and impairs handling.
Do not use winter tyres all year round as they
increase fuel consumption by up to 10%.

Avoid carrying unnecessary loads

Given that every kilo of extra

weight

will in-

crease the fuel consumption, it is advisable
make sure that no unnecessary loads are being
transported.
Since the luggage rack increases the

aerody-

namic drag

of the vehicle, you should remove

it when not needed. At speeds of 100-120 km/h
(62-75 mph), this will save 12% of fuel.

CarManuals2.com

Driving

129

Driving indications

Save electrical energy

The engine drives the alternator, thereby gen-
erating electricity. This implies that any in-
crease in power consumption also increases
fuel consumption! For this reason, switch off any
unneeded electrical devices. Devices that use
a lot of electricity include the blower at a high
setting, the rear window heating or the seat
heating.

Note

●

If you have the Start-Stop system, it is rec-

ommended that it should not be disconnec-
ted.

●

It is recommended that you close the win-

dows when driving at more than 60 km/h
(37 mph).

●

Do not drive with your foot resting on the

clutch pedal, as the pressure can make the
plate slip. This causes wear and can damage
the clutch plate.

●

Do not ride the clutch on a hill, use the

brake. The fuel consumption will be lower
and you will prevent the clutch plate from
being damaged.

●

Use the engine brake on downhills by

changing to the gear that is best suited for
the gradient. Fuel consumption will be “zero”
and the brakes will not suffer.

Driving with a loaded vehicle

In order to achieve appropriate driving charac-
teristics when the vehicle is loaded, please note
the following:

●

Place all luggage securely

›››

page 259

●

Accelerate with particular care and precau-

tion.

●

Avoid sudden braking and manoeuvres.

●

Brake earlier than usual.

●

If applicable, please note the information

about the roof rack

›››

page 265

WARNING

Loads that move around could seriously
threaten the vehicle's stability and safety,
extend the braking distance during hard or
emergency braking and lead to serious acci-
dents and injuries.

●

Secure the load correctly to prevent it from

moving around.

●

Secure heavy objects with suitable lashing

straps or tie-down belts.

●

Ensure that the rear seat backrests are se-

curely engaged.

Driving with the rear lid open

Driving with the rear lid open is particularly
dangerous. Secure all objects and the open
rear lid correctly and take any necessary
measures.
Driving with the rear lid open increases the aer-
odynamic drag of the vehicle, along with fuel
consumption. It is therefore recommended that
you do not drive with the rear lid open.

WARNING

Driving with the rear lid unlocked or open can
cause serious injury.

●

Always drive with the rear lid closed.

●

Place all objects securely inside the lug-

gage compartment. Otherwise, loose ob-
jects could fall out of the luggage compart-
ment and injure road users driving behind.

●

Always drive carefully and with special

care and anticipation.

●

Avoid braking and sudden manoeuvres, as

the open rear lid could move uncontrollably.

●

When transporting objects that protrude

from the luggage compartment, mark them
accordingly to warn other road users. Please
bear in mind all legal provisions.

●

Never use the rear lid to support or secure

objects protruding from the luggage com-
partment.

CarManuals2.com

130

Driving

●

If a luggage rack is fitted on the rear lid, re-

move it and the load when you have to drive
with the rear lid open.

NOTICE

An open rear lid changes the height and, in
some cases, the length of the vehicle.

Note

Depending on the country, it may be forbid-
den to drive with the rear lid open. Please
observe the legal regulations of the country
in question.

Driving on flooded roads

To prevent damage to the vehicle driving on
flooded roads, take the following into account:

●

Water should

never

come above the lower

edge of the bodywork.

●

Drive at pedestrian speed.

●

Never stop the vehicle in the water, drive in

reverse or stop the engine.

●

Vehicles driving in the opposite direction form

waves that can raise the water level so high
that your vehicle will not be able to cross the
water safely.

WARNING

After driving through flooded zones, braking
effectiveness can decrease if the brake discs
or pads are damp

›››

page 150

Note

●

Driving through flooded areas may se-

verely damage vehicle components such as
the engine, drive train or electrical system.

●

Avoid driving through salt water (corrosion)

›››

page 337

●

Whenever driving through water, the

Start-Stop system must be switched off

›››

page 136

Running in

Please observe the instructions for running-in
new components.

Running-in the engine

A new engine must be driven through a
run-in period during its first 1500 kilometres
(1000 miles). During its first few hours of run-
ning, the internal friction in the engine is greater
than later on when all the moving parts have
bedded down.
How the vehicle is driven for the first 1500 km
(1000 miles) influences the future engine per-
formance. Throughout the life of the vehicle,
it should be driven at a moderate speed (es-

pecially when the engine is cold) this will re-
duce engine wear and increase its useful life.
Never drive at extremely low engine speeds.
Always engage a lower gear when the engine
works “irregularly”.

For the first 1000 km or

600 miles, please note:

●

Do not use full throttle.

●

Do not force the engine above two thirds of its

maximum speed.

●

Do not tow a trailer.

Between 1000 and 1500 kilometres (600 to
1000 miles)

gradually

increase power until

reaching the maximum speed and high engine
speeds.

Running in new tyres and brake pads

●

Replacement of wheel rims and new tyres

›››

page 318

●

Information about brakes

›››

page 150

For the sake of the environment

If the engine is run in gently, the life of the
engine will be increased and the engine oil
consumption reduced.

Four-wheel drive (4Drive)

On four-wheel drive models, the engine power
is distributed to all four wheels

CarManuals2.com

Driving

131

Driving indications

General notes

On four-wheel drive vehicles, the engine power
is distributed to all four wheels. The distribution
of power is controlled automatically according
to your driving style and the road conditions.
See also

›››

page 151

The four-wheel drive is specially designed to
complement the superior engine power. This
combination gives the vehicle exceptional han-
dling and performance capabilities, both on
normal roads and in more difficult conditions,
such as snow and ice. Even so (or perhaps es-
pecially for this reason), it is important to ob-
serve certain safety points

›››

Winter tyres

Thanks to four-wheel drive, your vehicle will
have plenty of traction in winter conditions,
even with the standard tyres. Nevertheless, we
still recommend that winter tyres or all-season
tyres be fitted on all four wheels to give even
better braking response.

Snow chains

On roads where snow chains are mandatory,
this also applies to cars with four-wheel drive

›››

page 322

Changing tyres

On vehicles with four-wheel drive, all four tyres
must have the same rolling circumference. Also
avoid using tyres with varying tread depths

›››

page 318

Off-roader?

Your SEAT vehicle is not an off-roader: in fact,
the ground clearance is not enough to be used
as such. Avoid consequently rough tracks and
uneven terrain.

WARNING

●

Even with four-wheel drive, you should al-

ways adjust your speed to suit the condi-
tions. Do not let the extra safety features
tempt you into taking any risks when driving.
Accident hazard!

●

The braking capability of your vehicle is

limited by the tyres' grip. It is therefore no dif-
ferent from a car without four-wheel drive. So
do not be tempted to drive too fast on firm or
slippery roads just because the vehicle still
has good acceleration in these conditions.
Accident hazard!

●

On wet roads bear in mind that the front

wheels may start to “aquaplane” and lose
contact with the road if the car is driven too
fast. If this should happen, there will be no
sudden increase in engine speed to warn the
driver, as occurs with a front-wheel drive car.

For this reason you should always choose
a driving speed suitable for the road condi-
tions. Accident hazard!

Trips abroad

The vehicle has been manufactured for a spe-
cific country and meets the approval regula-
tions in force in that country at the time it was
manufactured.
If you are going to use the vehicle abroad tem-
porarily or for a short period of time, please
observe the relevant instructions.
Some countries have special safety regulations
and provisions that the vehicle may not com-
ply with. Before travelling abroad, SEAT recom-
mends that you seek information from one of
your dealers about the legal provisions in force
in your destination country.
If you are going to sell the vehicle in another
country or use it there for a longer period of
time, please observe the legal regulations in
force in the country in question.
In some cases it may be necessary to install or
remove certain equipment at a later date, and
to deactivate certain functions. Sets and types
of services may also be affected. In particular,
this can occur if the vehicle is to be used in an-
other climatic region for a long period of time.
Due to the different frequency bands around
the world, the factory-fitted infotainment sys-
tem may not work in another country.

CarManuals2.com

132

Driving

With petrol vehicles, it should be ensured that
lead-free petrol is available throughout the
journey. Seek information about service station
networks selling unleaded fuel.

SEAT importers and distributors will provide in-
formation about the technical preparation that
your vehicle requires and also about necessary
maintenance and repair possibilities.

NOTICE

SEAT does not accept liability for any dam-
age to the vehicle due to the use of a lower
quality fuel, an inadequate service or the
non-availability of genuine spare parts.

Starting and stopping the
engine

Switching the ignition on/off

Fig. 97

In the lower part of the centre console:

start button.

The engine can be started with a start button
(Press & Drive). To do so, there must be a valid
key inside the vehicle in the area of the front or
rear seats, or on the centre console.
In vehicles with the Keyless Access system, the
engine can also be started with the key in the
luggage compartment.
Opening the driver's door

when exiting the ve-

hicle

activates the electronic lock on the steer-

ing column if the ignition is disabled.

Switching the ignition on/off

If you only want to switch on the ignition (with-
out starting the engine), briefly press the start
button once

without pressing

the brake pedal

or the clutch pedal

›››

page 133

The starter button text

flashes

like a heartbeat when the system is preset for
switching the ignition on and off.

Automatic ignition disconnection

If the driver leaves the vehicle, taking the key
with them but leaving the ignition on, the igni-
tion does not switch off automatically. The igni-
tion is switched off by pressing the lock button
on the remote control or by pressing the sen-
sor surface on the door lever.

›››

page 70

Automatic deactivation of the ignition on ve-
hicles with the Start-Stop system

The ignition is switched off automatically when
the vehicle is stopped and the automatic en-
gine shutdown is active, if:

●

The driver's seat belt is not fastened,

●

the driver does not step on any pedal,

●

the driver door is opened.

After automatically turning off the ignition, if the
dipped beam is on, the side light remains
on for approx. 30 minutes (if the battery has
enough charge). If the driver locks the vehicle
or manually turns off the light, the side light
goes out.

CarManuals2.com

Driving

133

Starting and stopping the engine

Engine restart feature

If no key is detected inside the vehicle after the
engine stops, you will only have 5 seconds to
restart it. A warning will display on the dash
panel screen.
After this interval, it will not be possible to start
the engine without a valid key inside the vehicle.

Function “My Beat”

For vehicles with a convenience key there is the
“My Beat” function. This feature provides an ad-
ditional indication of the vehicle ignition system.
When entering the vehicle, the start button

›››

Fig. 97

flashes to draw attention to it.

When the ignition is on/off, the engine start but-
ton flashes.
With the ignition is switched off, the start button
goes off after a few seconds.
With the engine running, the start button light
stays on, indicating that the engine is running.
The time elapsed between the moment the
user starts the engine with the start button and
the lighting changes from flashing to fixed will
depend on specific engine size characteristics.
When the start button is used to stop the en-
gine, the button starts flashing again.
In vehicles

with the Start-Stop system

, the

“My Beat” function also offers additional infor-
mation:

●

When the engine stops during the Stop

phase, the light of the start button stays on,
as the Start-Stop system remains active even
though the engine is off.

●

When the engine cannot be started again

with the Start-Stop system

›››

page 136

and

needs to be started manually, the start button
flashes to indicate this situation.

WARNING

When switching on the ignition, do not press
the brake or clutch pedal, otherwise the en-
gine could start immediately.

WARNING

If vehicle keys are used negligently or with-
out due care, this may cause accidents and
serious injury.

●

Never leave any key inside the vehicle

when you leave it. Otherwise, a child or un-
authorised person could lock the vehicle,
start the engine or connect the ignition and
operate any of the electrical equipment.

Note

●

Before leaving the vehicle, always discon-

nect the ignition and, if appropriate, take into
account the instructions on the screen of the
dash panel.

●

If the vehicle is stationary for a long time

with the engine off and the ignition on, the
vehicle battery might be discharged and it
might not be possible to start the engine.

●

In vehicles with diesel engines, wait until

the warning light goes off before starting
the engine.

●

If during the STOP phase you press the

button, the ignition is switched

off and the push-button flashes.

●

If the following indication appears on the

instrument cluster display:

“Start-Stop

system deactivated: Start the en-
gine manually”

; the button

will flash.

Starting the engine

●

Vehicles with manual transmission:

put the

gear lever in neutral, press the clutch pedal and
keep it pressed in this position until the engine
starts.

●

Vehicles with automatic transmission:

put the

selector lever in

, press the brake pedal

and keep it pressed in this position until the en-
gine starts.

CarManuals2.com

134

Driving

●

Press the start button without pressing the

accelerator. There must be a valid key in the
vehicle for the engine to start. After starting the
engine, the lighting of the

button

remains fixed indicating that the engine is run-
ning.

●

Once the engine starts, release the start but-

ton.

●

If the engine does not start, stop and wait

for around 1 minute to try again. If necessary,
perform an emergency start

›››

page 135

Diesel engines can take a few seconds longer
than usual to start on cold days. During pre-
heating, the warning lamp remains lit. To
avoid unnecessary discharging of the battery,
do not use any other major electrical equip-
ment while the glow plugs are pre-heating.
The preheating time depends on the coolant
and exterior temperatures. With the engine at
operating temperature, or at outside tempera-
tures above +8°C, the warning lamp will light
up for about one second. This means that you
can start the engine almost immediately.

Starting a diesel engine after having run out
of fuel

If the fuel tank of a diesel vehicle was run until
completely empty, after refuelling it can last
longer than normal to start the engine, even
up to a minute. This is because the fuel system
must eliminate air first.

WARNING

Do not keep the engine running in confined
spaces, as there is a risk of poisoning.

●

The exhaust gases contain carbon monox-

ide, an odourless and colourless poisonous
gas that can cause loss of consciousness
and death.

WARNING

Do not get out of the vehicle with the en-
gine running, especially if a gear is engaged.
The vehicle could then suddenly move or
something strange could happen that would
cause damage, fire or serious injury.

WARNING

Never use cold start sprays, they could ex-
plode or cause the engine to run at high revs.
Doing this risks injury.

NOTICE

●

The starter motor or the engine may be

damaged if you try to restart the engine im-
mediately after switching it off.

●

When the engine is cold, you should avoid

high engine speeds, driving at full throttle
and over-loading the engine, as this could
cause engine damage.

For the sake of the environment

Do not warm-up the engine by running the
engine with the vehicle stationary. Start off
immediately, driving gently. This helps the
engine reach operating temperature faster
and reduces emissions.

Note

Electrical components with a high power
consumption are switched off temporarily
when the engine starts.

●

When starting with a cold engine, noise

levels may briefly increase. This is quite nor-
mal, and no cause for concern.

●

When the outside temperature is below

+5 °C (+41 °F), if the engine is diesel, some
smoke may appear under the vehicle when
the fuel-operated auxiliary heater is on.

Turning off the engine

●

Bring the vehicle to a full stop

›››

●

Vehicles with manual transmission:

fully de-

press the clutch.

●

Vehicles with automatic transmission:

Move

the selector lever to the

position.

●

Apply the electronic parking brake.

●

Briefly press the start button.

CarManuals2.com

Driving

135

Starting and stopping the engine

Emergency disconnection

If the engine does not switch off after briefly
pressing the starter button, an emergency dis-
connect will be required:

●

Press the start button twice within 3 seconds

or press it once for more than 1 second .

WARNING

Never switch off the engine while the vehicle
is moving. This could cause loss of control of
the vehicle, accidents and serious injury.

●

The airbags and belt tensioners do not

work when the ignition is switched off.

●

The brake servo does not work with the

engine off. Therefore, you need to press the
break pedal harder to brake the vehicle.

●

Power steering does not work when the en-

gine is not running. You need more strength
to steer when the engine is switched off.

●

If the ignition is switched off, the steering

column could be locked, making it impossi-
ble to control the vehicle.

WARNING

Always take the key with you when you leave
the vehicle. This is particularly important if
there are children in the vehicle, as they
might otherwise be able to start the engine
or use power-operated equipment (e.g. the
electric windows), which could cause inju-
ries.

NOTICE

●

If the vehicle is stopped and the Start-Stop

system switches off the engine, the ignition
remains switched on. Make sure that the ig-
nition is switched off before leaving the vehi-
cle, otherwise the battery could discharge.

●

If the engine has been driven at high speed

for a prolonged period of time, it may over-
heat when switched off. To avoid damage,
allow the engine to run for approximately two
minutes in neutral before switching it off.

Note

After the engine is switched off the radiator
fan may run on for up to 10 minutes, even
if the ignition is switched off. It is also pos-
sible that the fan turns itself on once more
if the coolant temperature increases due to
the heat accumulated in the engine com-
partment or due to its prolonged exposure to
solar radiation.

Electronic immobilizer

The electronic immobiliser helps to prevent the
engine from being started with an unauthorised
key and, consequently, the vehicle being put in
motion.
The vehicle key has an integrated chip which
automatically deactivates the electronic immo-
biliser if there is a valid key inside the passenger
compartment.

The electronic immobiliser is automatically ac-
tivated when there is no longer a valid key in-
side the vehicle.
For this reason, the engine can only be started
with a properly coded Original SEAT key. This
type of keys can be purchased from a SEAT
dealer.

NOTICE

A perfect operation of the vehicle is ensured
if genuine SEAT keys are used.

Emergency starting function

Fig. 98

On the right of the steering column:

emergency start.

If no valid key is detected inside the vehicle,
an emergency start-up will be required. The rel-
evant message will appear in the dash panel
display. This may happen when, for example,
the vehicle key battery is very low.

CarManuals2.com

136

Driving

Only in vehicles with Keyless Access.

●

Immediately after pushing the starter button,

keep the key next to the right trim of the steer-
ing column

›››

Fig. 98

, as close as possible to

the

Kessy

logo.

●

The ignition connects and the engine starts

automatically.

Indications for the driver on the in-
strument cluster screen

Depress the clutch

●

This indication is displayed on vehicles with

a manual gearbox when the driver does not
depress the clutch pedal when starting the en-
gine. The engine can only be started if the
clutch pedal is depressed.

Press the brake

●

This message appears on vehicles with an

automatic gearbox if the driver tries to start the
engine without having the brake pedal pressed.

Select N or P

●

This message appears if you try to start or

stop the engine when the selector lever of the
automatic gearbox is not in position

The engine can only be started and stopped
in those positions.

Engage position P; the vehicle can
move; doors can only be locked in
position P.

●

For safety reasons, this driver message ap-

pears and an audible warning sounds if the se-
lector lever of the automatic gearbox is not in
position

after you switch off the ignition. Move

the selector lever to the

position, otherwise

the vehicle could move.

Gear change: Selector lever in the
drive position!

●

This driver message is displayed when the

selector lever is not in the position

when the

driver door is opened. Additionally, a buzzing
sound is emitted. Put the selector lever in posi-
tion

, otherwise the vehicle could roll away.

Ignition is switched on

●

This driver message is displayed and a buz-

zer is sounded when the driver door is opened
with the ignition switched on.

Start-Stop system

Description and operation

The Start-Stop system helps you to save fuel
and reduce CO

emissions.

In Start-Stop mode, the engine will automati-
cally switch off when the vehicle stops or is
stopping. The ignition remains switched on. The
engine automatically switches back on when
required.
In this scenario, the light of the
button remains lit.

When the ignition is switched on, the Start-Stop
function is automatically activated.

Control lamps

The Start-Stop system is available, the
automatic engine shutdown is active.
The Start-Stop system is not available or
has been disconnected.

Stopping and starting the engine

Vehicles with a manual gearbox:

●

When the vehicle is stopped, put it into neu-

tral and release the clutch pedal. The engine
will stop. The warning lamp will light up on
the display. The engine may be stopped before
the vehicle comes to a standstill (approximately
7 km/h).

●

When you depress the clutch pedal, the en-

gine will start again. The indicator lamp goes
out.

CarManuals2.com

Driving

137

Start-Stop system

Vehicles with an automatic gearbox:

●

Brake until the vehicle has come to a stand-

still, and keep your foot on the brake pedal or
activate the Auto Hold system so that the vehi-
cle remains braked. The engine will stop. The
warning lamp will appear on the display.
The engine may stop before the car stops com-
pletely (approximately 7 or 2 km/h depending
on the vehicle's gearbox).

●

When you take your foot off the brake pedal

the engine will start up again. The indicator
lamp goes out. With the Auto Hold system, the
engine will not start if you remove your foot
from the brake pedal. The car starts when you
press the accelerator pedal.

Basic requirements for the start/stop mode

●

The driver door must be closed.

●

The driver's seat belt must be fastened.

●

The bonnet must be closed.

●

The engine has reached operating tempera-

ture.

●

The reverse gear must not be engaged.

●

The vehicle must not be on a very steep

slope.

The engine does not turn off for various rea-
sons

Before stopping the vehicle, the system verifies
whether certain conditions are met. The engine

does not

switch off, in the following situations

for example:

●

The engine has not yet reached the required

temperature for the Start-Stop mode.

●

The temperature selected on the climate

control has not been reached.

●

The interior temperature is very high/low.

●

De-icing function button activated.

●

Park assist is switched on.

●

The battery is very low.

●

The steering wheel is overly turned or is being

turned.

●

If there is a danger of misting.

●

After engaging reverse gear.

●

In case of a very steep gradient.

is displayed on the instrument cluster

screen; it is also displayed in the driver informa-
tion system,

The engine starts by itself

When stopped, the normal system mode may
be interrupted in the following situations. The
engine restarts without the driver's intervention.

●

The interior temperature differs from the tem-

perature selected on the climate control.

●

Defrost function button activated

●

The brake is pressed several times in a row.

●

The battery is not charged enough.

●

High electricity consumption.

Additional information related to the auto-
matic gearbox

The engine stops when the selector lever is in

and

, as well as in Tiptronic mode. With the

selector lever in

, the engine will also remain

switched off when you take your foot off the
brake pedal.
In order to start the engine up again the ac-
celerator must be pressed, or another gear en-
gaged or the brake released.
If the selector lever is placed in

while stopped,

the engine will start up again.
Change from

to prevent the engine from

accidentally starting when passing through

Additional information about vehicles with
Adaptive Cruise Control (ACC)

In vehicles with ACC function, the engine will
start up again in certain operating conditions if
the radar sensor detects that the vehicle ahead
drives off again.

CarManuals2.com

138

Driving

WARNING

●

Never switch the engine off until the vehi-

cle is stationary. The operation of the brake
and steering will not be fully guaranteed.
More force will be needed to turn the steer-
ing wheel or to brake. You could suffer an
accident and even serious injuries.

●

To avoid injury, make sure that the Start-

Stop system is switched off when working in
the engine compartment

›››

page 138

NOTICE

The Start-Stop system must always be
switched off when driving through flooded
areas

›››

page 130

Note

●

In vehicles with an automatic gearbox,

you can control whether the engine should
switch off or not by reducing or increasing
the brake force applied. While the vehicle re-
mains stopped, the engine will not stop if the
brake pedal is slightly pressed, in traffic jams
with frequent stopping and starting for exam-
ple. As soon as strong pressure is applied to
the brake pedal, the engine will stop.

●

When stopped, the brake pedal must be

kept pressed to ensure that the vehicle does
not move.

●

If the engine “stalls” with a manual gear-

box, it can be directly started up again by
immediately pressing the clutch pedal.

●

If the lever is placed in position D, N or S

after engaging reverse gear, 10 km/h (6 mph)
in a forwards direction must be reached for
the system to be in a condition to stop the
engine.

Manually connecting and discon-
necting the Start-Stop system

Fig. 99

Centre console: Start-Stop system

button.

If you do not wish to use the system, you can
switch it off manually:

●

To manually switch on/off the Start-Stop sys-

tem, press the button

›››

Fig. 99

The button symbol remains lit up in yellow
when the system is switched off.

Note

The system switches on every time the en-
gine is turned off voluntarily.

Troubleshooting

Indications for the driver on the instrument
cluster screen

Start-Stop system deactivated.
Start the engine manually

●

This indication shows that the Start-Stop sys-

tem

cannot

restart the engine.

This happens for 2 reasons: if the driver's door
has been opened or if the driver has unbuckled
the seat belt.

Start-Stop system: Fault! Function
not available

●

There is a fault in the Start-Stop system. Take

the vehicle to a workshop to have the fault re-
paired.

CarManuals2.com

Seat Ateca (2023 year). Manual in english - page 4
