CHILD SAFETY: attachment using the ISOFIX system (2/4)
Installation visual for the four-seat estate version
Child seat attached using the
²
Seat not suitable for fitting child
ISOFIX mounting
seats.
ü
Seat which allows an ISOFIX
Carrying a passenger is
child seat to be fitted.
STRICTLY PROHIBITED.
The rear side seats are fitted with an
anchorage point which enables the fit-
ting of a universal ISOFIX forward-fac-
ing child seat, as indicated by the
symbol. The anchorage points are lo-
Using a child safety system
cated behind the bench seat at the
which is not approved for
bottom of each side seatback.
this vehicle will not properly
protect the baby or child.
They risk serious or even fatal injury.
1.49
CarManuals2.co
CHILD SAFETY: attachment using the ISOFIX system (3/4)
The table below summarises the information already shown on the diagram on the previous pages, to ensure the regu-
lations in force are respected.
Estate version
Front passenger seat
Rear seats
Weight of
Seat size
without
Type of child seat
with airbag
Centre seat
the child
[Height]
airbag
Side
without
or airbag
seats
Five-seater
deactivation
deactivated
version ONLY
Transverse carrycot
F, G
< 10 kg
X
X
IL (1)
X
Approved for group 0
[L1, L2]
Rear-facing shell seat
E
Approved
< 13 kg
X
X
IL (2)
IL (2) (4)
[R1]
group 0 or 0+
D
< 13 kg
X
X
IL (2)
IL (2)(4)
[R2]
Rear-facing seat
Approved for group 0+ or 1
C
9 to 18 kg
X
X
X
IL (2)(4)
[R3]
Forward-facing seat
A, B, B1
9 kg to 18 kg
X
X
IUF-IL (3)
IUF-IL (3)(4)
Approved for group 1
[F3, F2, F2X]
15 kg to 25
Booster seat
kg and 22
[B2]
X
X
IUF-IL (3)
X
Approved for group 2 or 3
kg to 36 kg
I-Size seat
X
X
X
X
1.50
CarManuals2.co
CHILD SAFETY: attachment using the ISOFIX system (4/4)
Refer to the “Child safety equipment” booklet available from the network to choose the seat suited to your child and rec-
ommended for your vehicle.
X = Seat not suitable for fitting child seats.
IUF
= Seat which allows forward facing child seats with “Universal” approval to be attached using ISOFIX attachments; check
that it can be fitted correctly.
IL = Seat which allows approved “Semi-Universal” or “Vehicle specific” child seats to be fitted using ISOFIX attachments; check
that it can be fitted correctly.
(1) A carrycot can be installed across the vehicle and will take up at least two seats. Position the child with his or her feet nearest
the door.
(2) In order to install a rear-facing child seat, move the front seat as far forward as possible, then move the front seat back as far
as it will go, without allowing it to come into contact with the child seat.
(3) In all situations, remove the rear headrest of the seat on which the child seat is positioned. This must be done before fitting the
child seat. ➥ 3.22. Move the seat in front of the child forwards, move the seatback forward to avoid contact between the seat
and the child’s legs.
The size of the ISOFIX child seat is indicated by a letter:
- A, B, B1 [F3, F2, F2X]: for forward-facing seats in group 1 (9 to 18 kg);
- C [R3]: rear-facing seats in group 1 (9 to 18 kg);
- D, E [R2, R1]: for rear-facing seats or shell seats in group 0 or 0+ (under 13 kg);
- F, G [L1, L2]: carrycots in group 0 (under 10 kg);
- [B2]: boosters in groups 2 and 3 (15 to 25 kg and 22 to 36 kg).
(4) RISK OF DEATH OR SERIOUS INJURY: a child seat with a floor support must never be fitted on the centre seat.
1.51
CarManuals2.co
CHILD SAFETY: deactivating, activating AIRBAG front passenger (1/3)
2
1
Front passengerairbag
To deactivate the airbag: with the
vehicle stationary and the ignition
deactivation
switched off, push and turn lock 1 to
Before installing a child seat on the
the OFF position.
front passenger seat:
When the ignition is switched on, you
The passenger airbag must
- check that the child seat can be in-
must check that the warning light 2
only be activated or deacti-
stalled on this seat;
vated when the vehicle is
]
is properly lit.
- it is essential to deactivate the
stationary with the igni-
airbag for a rear-facing child seat.
This warning light remains continu-
tion off.
ously lit to let you know that you can
If handled when the ignition is on,
fit a child seat.
the warning light å
comes on.
Switch the ignition off then on again
to reset the airbag in accordance
with the lock position.
1.52
CarManuals2.co
CHILD SAFETY: deactivating, activating AIRBAG front passenger (2/3)
A
A
3
The markings on the dashboard and
the labels A on each side of the pas-
senger sun visor 3 (example: label
shown above) remind you of these in-
structions.
DANGER
Since operation of the front
passenger airbag is not
compatible with the po-
sition of a rear-facing child seat,
NEVER fit a rear-facing child re-
straint system in a seat protected
by an ACTIVATED front AIRBAG .
This can lead to the DEATH of the
CHILD or SERIOUS INJURY.
1.53
CarManuals2.co
CHILD SAFETY: deactivating, activating AIRBAG front passenger (3/3)
DANGER
2
Since operation of the front
passenger airbag is not
compatible with the po-
sition of a rear-facing child seat,
NEVER fit a rear-facing child re-
straint system in a seat protected
by an ACTIVATED front AIRBAG.
This can lead to the DEATH of the
CHILD or SERIOUS INJURY.
1
Front passengerairbag
Operating faults
activation
It is forbidden to fit a rear-facing child
You should reactivate the airbag as
seat to the front passenger seat if the
soon as you remove the child seat from
airbag activation/deactivation system is
the front passenger seat to ensure the
faulty.
The passenger airbag may
protection of the front passenger in the
Allowing any other passenger to sit in
only be activated or deacti-
event of an impact.
that seat is not recommended.
vated when the vehicle is
stationary with the igni-
To reactivate the airbag: with the
Contact your approved dealer as soon
tion off.
vehicle stationary and the ignition
as possible.
switched off, press and turn the lock 1
If handled when the ignition is on,
to the ON position.
the warning light å
comes on.
When the ignition is switched on, you
Switch the ignition off then on again
must check that the warning light 2
to reset the airbag in accordance
]
is off.
with the lock position.
The front passenger airbag is activated.
1.54
CarManuals2.co
AUDIBLE AND VISUAL SIGNALS
1
1
3
2
Horn
Hazard warning lights
Direction indicators
é
Press one of the locations 2 to activate
Press switch 3.
Move stalk 1 parallel to the steering
the horn.
wheel and in the direction you are going
This switch activates all four direction
to turn it.
indicators and the side indicator lights
Headlight flasher
simultaneously.
One-touch mode
Pull stalk 1 towards you then release it
It must only be used in an emergency to
Briefly shift the stalk
1 upwards or
to flash the headlights.
warn drivers of other vehicles that you
downwards, not exceeding the point
have had to stop in an area where stop-
of resistance, then release it: the stalk
ping is prohibited or unexpected, or that
will return to its original position and the
you are obliged to drive under special
direction indicator light concerned will
conditions.
flash three times.
1.55
CarManuals2.co
DRIVER’S POSITION: LEFT-HAND DRIVE (1/4)
1
2
3
4
5
6
7
8
9
10
11
12
2
1
13
28
27
26
25
24
23
22
21
17
16
15
14
20
19
18
1.56
CarManuals2.co
DRIVER’S POSITION: LEFT-HAND DRIVE (2/4)
The presence of the equipment DEPENDS ON THE VEHICLE VERSION AND COUNTRY.
1
Side air vent.
11
Location for radio, navigation
system or storage compartments.
2
Side demister outlet.
12
Location for passenger airbag or
3
Stalk for:
storage compartment.
– direction indicator lights,
13
Passenger airbag activation or de-
- exterior lights,
activation switch.
- front fog lights,
14
Passenger glove compartment or
– rear fog lights.
storage compartment.
4
Dashboard storage compartment
15
Controls for:
sockets USB and accessories
–
activation/deactivation of the parking
socket.
distance control,
5
Horn.
–
activation/deactivation of central
door locking,
6
Instrument panel.
–
activation/deactivation of the hazard
warning lights,
7
Driver airbag location.
-
heated front seats,
8
Steering column stalk for wind-
-
activation/deactivation of ECO
screen and rear screen wash/
mode,
wiper.
-
deactivating/activating the function
9
Centre air vents.
Stop and Start.
10
Central demister outlet.
1.57
CarManuals2.co
DRIVER’S POSITION: LEFT-HAND DRIVE (3/4)
1
2
3
4
5
6
7
8
9
10
11
12
2
1
13
28
27
26
25
24
23
22
21
17
16
15
14
20
19
18
1.58
CarManuals2.co
DRIVER’S POSITION: LEFT-HAND DRIVE (4/4)
The presence of the equipment DEPENDS ON THE VEHICLE VERSION AND COUNTRY.
16
Controls for:
24
Cruise control/speed limiter con-
trols and main switch.
– heating or air conditioning,
- rear screen and door mirror de-icing.
25
Driver’s glove compartment and
fuse box.
17
Storage compartment.
26
Beam adjustment control.
18
Handbrake.
27
Bonnet release control.
19
Gearstick.
28
Controls for:
20
Location for ashtray or cup holder
– adjustment of the exterior rear view
and cigarette lighter or accesso-
mirrors,
ries socket.
- activating/deactivating the grip con-
21
Radio remote control.
trol,
- activation/deactivation of ESC,
22
Ignition switch.
- activating/deactivating the blind spot
23
Controls for:
warning function.
– trip computer and warning system in-
formation readout,
– multimedia system voice control.
1.59
CarManuals2.co
WARNING LIGHTS (1/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
A
The
warning light means
you should drive very carefully to
an approved dealer as soon as pos-
sible. If you fail to follow this recom-
mendation, you risk damaging your
vehicle.
Instrument panel A
If no lights or sounds are ap-
Warning light
®
re-
parent, this indicates a fault
quires you to stop immedi-
in the instrument panel. This
ately, for your own safety,
indicates that it is essential
as soon as traffic conditions
to stop immediately (as soon as traf-
allow. Switch off the engine and do
fic conditions allow). Ensure that the
not restart it. Contact an approved
vehicle is correctly immobilised and
Dealer.
contact an approved Dealer.
1.60
CarManuals2.co
WARNING LIGHTS (2/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Left-hand direction indicator
Variable power-assisted
c
tell-tale
U
steering warning light
Right-hand direction indica-
It lights up when the ignition or the
b
tor tell-tale
engine is switched on and goes off after
A
a few seconds.
Toxic Fume Filter System
Ä
Warning Light
If it comes on while driving, alongside
the warning light
®
, this means
On vehicles that are equipped, this light
there is a system fault.
comes on when the engine is started
and, depending on the vehicle, when
Contact an authorised dealer.
the ignition is switched off while the
Particle filter system warn-
engine is in the standby phase ➥ 2.5
ing light ➥ 2.8 ➥ 2.10.
then it goes out.
- If it lights up continuously, consult
your approved dealer as soon as
possible;
Side light warning light
š
- If it flashes, reduce the engine speed
until the light stops flashing. Contact
Main beam headlight tell-tale
á
your approved Dealer as soon as
light
possible ➥ 2.16.
Dipped beam headlight tell-
k
tale
Front fog light tell-tale light
g
Rear fog light tell-tale
f
1.61
CarManuals2.co
WARNING LIGHTS (3/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Urgent stop warning light
Coolant temperature warn-
®
Ô
(red)
ing light
This lights up when the ignition or
This lights up blue when you switch on
engine is switched on and goes out as
the ignition or start the engine.
A
soon as the engine is running. It comes
on with other warning lights and/or mes-
If it turns red, stop and let the engine
sages and is accompanied by a beep.
idle for a minute or two.
It requires you to stop immediately, for
The temperature should drop and the
your own safety, as soon as traffic con-
warning light should switch off or turn
ditions allow. Switch off the engine and
blue again. Otherwise, stop the engine.
do not restart it.
Let the engine cool down before check-
Contact an approved Dealer.
ing the coolant.
Warning light (orange)
Contact an approved Dealer.
This lights up when the ignition
is switched on and goes out as soon as
Brake circuit fault warning
the engine is started. It can light up in
D
light
conjunction with other warning lights
and/or messages on the instrument
It lights up when the ignition or the
panel.
engine is switched on and goes off after
a few seconds.
It means you should drive very care-
fully to an authorised dealer as soon
If it comes on during braking and is ac-
as possible. If you fail to follow this rec-
companied by the
®
warning light
ommendation, you risk damaging your
and a beep, it indicates that the fluid
vehicle.
level in the circuit is low or that there is
a braking system fault. Stop as soon as
traffic conditions allow and contact an
authorised dealer.
1.62
CarManuals2.co
WARNING LIGHTS (4/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Preheating warning light
Anti-lock braking warning
É
(diesel version)
x
light
This should come on when the igni-
It lights up when the ignition or the
tion is switched on. It indicates that the
engine is switched on and goes off after
A
heater plugs are in operation. It goes
a few seconds.
out when preheating is complete. The
engine can be started.
If it lights up when you are driving, it in-
dicates a fault in the anti-lock braking
Indicator lightAirbag
system.
å
It lights up when the ignition or
Braking will then be as normal, without
the engine is switched on and goes off
the ABS. Contact an approved Dealer
after a few seconds.
as soon as possible.
If it does not come on when the igni-
Warning light for reagent
tion is switched on, or comes on when
level and faults in the exhaust
the engine is running, there is a fault in
gas reduction system ➥ 1.99.
the system.
Oil pressure warning light
Gear change indicator
À
Contact your approved Dealer as soon
‰ Š
It lights up when the ignition or
This lights up to advise you to
as possible.
the engine is switched on and goes off
change to a higher gear (arrow pointing
after a few seconds.
Low fuel level warning light
upwards) or lower gear (arrow pointing
If it comes on on the road, accompa-
L
It lights up orange when the ig-
downwards) ➥ 2.12.
nied by the
®
warning light and a
nition or the engine is switched on then,
beep, stop immediately and cut the ig-
depending on the vehicle, goes off after
nition.
a few seconds or is displayed in white.
If it comes on orange while driving and
Check the oil level ➥ 4.4. If the level is
is accompanied by a beep, fill up with
normal, the warning light is related to
fuel as soon as possible. There is only
something else.
approximately 31 miles (50 km) worth
Call an approved Dealer.
of fuel left.
1.63
CarManuals2.co
WARNING LIGHTS (5/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Warning light for the elec-
Cruise control warning
tronic stability program
Ϧ
lights ➥ 2.33.
(ESC) and traction control system
Speed limiter warning light
This lights up when the ignition is
Ð
➥ 2.30.
A
switched on and goes out after a few
Excess speed warning light
seconds.
Depending on the vehicle
There are several reasons for the warn-
and country, it lights up and a beep
ing light to appear: ➥ 2.25.
sounds. This beep sounds as soon as
the vehicle is travelling at over 75 mph
Warning light for non-availa-
(120 km/h). This warning light remains
bility of the electronic stabil-
lit for as long as the vehicle is travelling
ity program (ESC) and traction con-
at over 74 mph (120 km/h).
trol system ➥ 2.25.
Engine standby warning
2
Door(s) open warning light
light ➥ 2.5.
➥ 1.9.
Unavailability of engine
Battery charge warning light
Ú
standby warning light
It lights up when the ignition or
Mode warning light ECO
➥ 2.5.
the engine is switched on and goes off
after a few seconds.
It comes on when ECO mode is acti-
If it comes on on the road, accompa-
vated ➥ 2.12.
nied by the
®
warning light and a
Handbrake
“on” warning
beep, this indicates an overload or dis-
}
light ➥ 2.21.
charge in the electrical circuit.
Tyre pressure monitoring
Stop as soon as traffic conditions allow
system
and contact an approved Dealer.
➥ 2.18.
1.64
CarManuals2.co
WARNING LIGHTS (6/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Front and rear seat belt re-
ß
minder warning light ➥ 1.20.
B
On display B
Passenger Airbag ON
➥ 1.52.
Passenger Airbag OFF
¹
➥ 1.52.
1.65
CarManuals2.co
DISPLAYS AND INDICATORS
B
A
2
3
1
4
Fuel gauge 1 or 4
Trip computer and warning
system A or B
The number of squares lit shows the
fuel level.
➥ 1.67
If the minimum level is reached, the
Speedometers 2 and,
warning light L
on the instrument
panel comes on and a beep sounds. Fill
depending on the vehicle, 3
up as soon as possible.
(km or miles per hour)
Control your speed according to the ap-
5
proved speedometer only2.
The indicator 3 is provided as an indi-
cation.
Rev counter 5 (rpm x 1000)
1.66
CarManuals2.co
ON-BOARD COMPUTER: general information (1/2)
Display selection keys 2 or 3
h) engine coolant temperature;
1
Scroll through the following information
i)
clock and exterior temperature;
by repeated short presses on button 2
j)
general adjustment.
or 3 (the display depends on the vehicle
equipment and country):
2
a) total mileage and trip mileage re-
corder;
b) journey parameters:
- average fuel consumption;
3
- current fuel consumption;
- estimated range with remaining
fuel;
- distance travelled;
Trip computer and warning
- average speed;
system 1
c) current speed;
Depending on the vehicle, this includes
d) distance before service;
the following functions:
e) tyre pressure reset;
- distance travelled;
f)
trip log, operating faults and informa-
- journey parameters;
tion message readout;
- information messages;
g) estimated range with remaining rea-
- operating fault messages
(con-
gent;
- warning messages (connected to the
®
warning light).
All these functions are described on the
following pages.
1.67
CarManuals2.co
ON-BOARD COMPUTER: general information (2/2)
Interpreting some of the
values displayed after
resetting
The values showing average fuel con-
sumption and average speed will
become more stable and reliable the
2
further you have travelled since the last
time the Reset button was pressed.
The average fuel consumption may de-
3
crease when:
- the vehicle stops accelerating;
- the engine reaches its operating
temperature (if the engine was cold
when the reset key was pressed);
Trip mileage resetting
- when driving from an urban area
With ‘trip mileage recorder’ selected on
onto the open road.
the display, press on button 2 or 3 until
the mileage recorder resets to zero.
Automatic resetting of the
journey parameters
Resetting the journey
Resetting occurs automatically when
parameters (reset button)
the maximum value of any of the pa-
With one of the journey parameters se-
rameters is exceeded.
lected on the display, press button 2
or 3 until the display resets.
1.68
CarManuals2.co
TRIP COMPUTER AND WARNING SYSTEM: journey parameters (1/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
101778 km
112.4 km
a) Total mileage and trip mileage recorder.
Average
b) Journey parameters:
Average fuel consumption.
The value is displayed after having travelled at least 400 metres since the last
5.8 L/100
reset.
Current
Current fuel consumption.
Value displayed after reaching a speed of 12 mph (20 km/h), depending on the
7.4 L/100
vehicle.
1.69
CarManuals2.co
TRIP COMPUTER AND WARNING SYSTEM: journey parameters (2/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
Range
b) Journey parameters (continued):
Estimated range with remaining fuel.
541 km
The value is displayed after driving 400 metres.
Distance
Distance travelled since last reset.
522 km
Average
Average speed since the last reset.
The value is displayed after driving 400 metres.
123.4 km/h
55.8 mph (90 km/h)
c) Current speed (depending on the vehicle).
1.70
CarManuals2.co
TRIP COMPUTER AND WARNING SYSTEM: journey parameters (3/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
On-board computer with mileage-
before-service message
d) Service distance.
With the ignition switched on, the engine not running and
SERVICE
Service in
the display set to “Service Intervals”, press button 2 or 3 for
INTERVALS
30 000 Km / 12 mo.
approximately 5 seconds to display the mileage before service
(distance or time to the next service). When the distance value
approaches its limit, there are several possible scenarios:
- range less than 930 miles (1,500 km) or one month: the
Service due in
message “Service due in” is displayed accompanied by the
nearest term (distance or time);
300 Km / 24 Days
- range equal to 0 miles (0 km) or date of service reached:
the message “Service required” is displayed accompanied by
The vehicle requires a service as soon as possible.
Service required
Reset: to reset the distance before the next service, press and hold button 2 or 3 for approximately 10 seconds until the display
shows the mileage before service permanently.
NB: if a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the
event of an oil change, both the distance before the next service and the next oil change should be reset.
1.71
CarManuals2.co
TRIP COMPUTER AND WARNING SYSTEM: journey parameters (4/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
On-board computer with distance before
next service message (cntd.)
d) Mileage before service
With the ignition on, the engine not running and the display
SERVICE
Oil change in
showing “Service Intervals”, press button 2 or 3 for about 5 sec-
INTERVALS
onds to display the mileage before the next service, then press
30 000 Km / 12 mo.
button 2 to view the mileage before the next oil change (distance
or time remaining before the next service). When the distance
value approaches its limit, there are several possible scenarios:
Service due in
- range less than 930 miles (1,500 km) or one month: the
message “Service due in” is displayed accompanied by the
300 Km / 24 Days
nearest term (distance or time);
- range equal to 0 miles (0 km) or date of oil change reached:
the message “Service required” is displayed accompanied by
Service required
The vehicle requires an oil change as soon as possible.
Depending on the vehicle, the mileage before an oil change varies according to the driving style (frequent driving at low speed,
door-to-door journeys, extensive use at idling speed, towing a trailer, etc.). The distance remaining until the next oil change can
therefore decrease more quickly in some cases than the actual distance travelled.
Reset: to reset the distance before the next service, press and hold button 2 or 3 for approximately 10 seconds until the display
shows the mileage before oil change permanently.
NB: if a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the
event of an oil change, both the distance before the next service and the next oil change should be reset.
1.72
CarManuals2.co
TRIP COMPUTER AND WARNING SYSTEM: journey parameters (5/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
e) Reset the tyre pressure.
Tyre pressure
➥ 2.18.
init. long press
f) Trip log.
No message
Successive display:
memorised
- information messages (ESC deactivated/acti-
vated, STOP and START activated etc.);
- operating fault messages (check injection
system, check airbag, etc.).
g) Estimated range with remaining reagent.
Top Up AdBlue
before 2400 km
➥ 1.99.
1.73
CarManuals2.co
TRIP COMPUTER AND WARNING SYSTEM: journey parameters (6/6)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
h) Engine coolant temperature.
i) Clock and outdoor temperature.
j) General settings.
Settings
Press button 2 or 3 for approximately 5 seconds
(press and hold)
to select the display language.
Settings
Indicates that to access the “General settings”
access when the
menu, you must stop the vehicle.
vehicle is stationary
1.74
CarManuals2.co
TRIP COMPUTER AND WARNING SYSTEM: information messages
These can help in the vehicle starting phase, or give information about a selection or a driving status.
Examples of information messages are given in the following pages.
Examples of messages
Interpreting the display selected
“Battery Low
Indicates that the vehicle must be started to recharge the battery (e.g. after the engine has been
Start Engine”
switched off for some time whilst listening to the radio).
“Vehicle Checks
Displayed with the ignition on when the vehicle is running self-diagnostics.
in Progress”
“Auto Door Lock OFF”
Indicates that the automatic door locking while driving is deactivated ➥ 1.8.
“WARNING: Top
Indicates that the oil level needs adjusting ➥ 4.6.
Up Engine Oil”
1.75
CarManuals2.co
TRIP COMPUTER AND WARNING SYSTEM: operating fault messages
soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle.
They disappear when the display selection key is pressed or after several seconds and are stored in the computer log. The
warning light stays on. Examples of operating fault messages are given in the following pages.
Examples of messages
Interpreting the display selected
“Clean diesel filter”
Indicates the presence of water in the diesel filter; contact an approved Dealer
as soon as possible.
“Check vehicle”
Indicates a fault in one of the pedal sensors, battery management system or oil
level sensor.
“Check airbag”
Indicates a fault in the restraint system in addition to the seat belts. In the event
of an accident, it is possible that they may not be triggered.
“Check anti- pollution system”
- Indicates a fault in the vehicle’s emission control system.
- Indicates a fault in the exhaust gas reduction system when it is accompanied
by the
warning light. ➥ 1.99.
“WARNING: Check SOS Call”
Indicates a fault in the emergency call system.
1.76
CarManuals2.co
TRIP COMPUTER AND WARNING SYSTEM: warning message
These appear with the® warning light and require you to stop immediately, for your own safety, as soon as traf-
fic conditions allow. Stop your engine and do not restart it. Contact an approved Dealer.
Some examples of warning messages are given below. Note: the messages appear on the display either individually or al-
ternately (when there are several messages to be displayed), and may be accompanied by a warning light and/or a beep.
Examples of messages
Interpreting the display selected
“Engine failure hazard”
Indicates an injection fault, the vehicle’s engine has overheated or there is a
serious engine fault.
“Power steering fault”
Indicates a fault in the steering system.
“WARNING: Braking System”
Indicates a fault in the braking system. Apply the electronic parking brake ma-
nually and ensure that the vehicle is immobilised using a chock.
“Electric failure DANGER”
Indicates a fault in the vehicle battery charging circuit (alternator etc.).
1.77
CarManuals2.co
CLOCK AND EXTERIOR TEMPERATURE (1/2)
1
12:00
3
2
Vehicles not fitted with a multimedia
screen
To access the 3 display for setting the
time, press and hold the 1 or 2 switch
for a few seconds.
The hour reading flashes. You are now
in setting mode, press switch 1 or 2 to
set the hour.
Wait a few seconds, the minutes flash:
repeatedly press switch 1 or 2 to set
them.
When setting is complete, wait a few
seconds before changing the display.
1.78
CarManuals2.co
CLOCK AND EXTERIOR TEMPERATURE (2/2)
External temperature
indicator
Special note:
When the exterior temperature is - 3°C
to + 3°C, the °C characters flash (sig-
A
nalling a risk of ice on the road).
Vehicles fitted with a multimedia
screen A
The time and exterior temperature are
displayed on the multimedia screen A.
Refer to the multimedia instructions.
External temperature in-
dicator
As ice formation is related
Depending on the vehicle, If the
to climatic exposure, local
electrical supply is cut (battery dis-
air humidity and temperature, the
connected, broken supply wire,
external temperature alone is not
etc.), the clock will automatically
sufficient to detect ice.
go back to the right time after a few
minutes once the system is capable
of receiving information GPS.
1.79
CarManuals2.co
STEERING WHEEL, POWER-ASSISTED STEERING
Power-assisted steering
Never drive with an inadequately
charged battery.
Variable power-assisted steering
The variable power assisted steering
system is equipped with an electronic
control system which alters the level of
assistance to suit the vehicle speed.
1
Steering is made easier during parking
manoeuvres (for added comfort) while
Never leave the steering wheel on
the force needed to steer increases
full lock when the vehicle is station-
progressively as the speed rises (for
ary.
enhanced safety at high speeds).
Adjusting the steering wheel
Special feature of Stop and Start
Depending on the vehicle, the steering
With the engine on standby, power-
With the engine switched off, or if
wheel position is adjustable.
assisted steering is no longer opera-
there is a system fault, it is still pos-
tional. In this case, it returns to its origi-
sible to turn the steering wheel. The
Lower the lever 1 and position the
nal state when the engine is restarted
force required will be greater.
steering wheel in the required position.
or when the speed exceeds 1 mph
Then, raise the lever fully, beyond the
(1 km/h) (hill, slope etc.).
point of resistance to lock the steering
wheel.
Never turn the steering wheel when
Make sure that the steering wheel is
the vehicle battery is disconnected.
correctly locked.
Never switch off the igni-
tion when travelling down-
hill, and avoid doing so in
For safety reasons, carry
normal driving (assistance
out any adjustments when
is not provided).
the vehicle is stationary.
1.80
CarManuals2.co
REAR VIEW MIRRORS (1/2)
Rear view mirror with lever 1
When driving at night, to avoid being
dazzled by the headlights of the vehicle
behind, depress the little lever located
behind rear view mirror 1.
Rear view mirror without lever 1
2
The rear view mirror darkens automa-
tically at night if you are being followed
1
by a vehicle with its lights on.
Interior rear view mirror
Fixed door mirrors
Its position can be adjusted.
To adjust, press the mirror 2.
Objects observed in the
door mirror glass are actu-
ally closer than they appear.
For your safety, take this
into account in order to correctly
assess the distance before any ma-
For safety reasons, carry
noeuvre.
out any adjustments when
the vehicle is not being
driven.
1.81
CarManuals2.co
REAR VIEW MIRRORS (2/2)
C
D
D
4
5
0
E
A
B
C
E
3
Door mirrors with electrical
Wide angle rear view mirror 5
The various zones seen by the driver
(depending on the vehicle)
are:
adjustment:
- C in the the wide-angle rear view
With the ignition on, move button 3:
Lower the sun visor 4 to access the
mirror;
- position A to adjust the left-hand
special mirror to increase side vision
- D via the passenger window;
door mirror;
when manoeuvring.
- E in the exterior rear view mirror.
- position B to adjust the right-hand
door mirror;
0 is the neutral centre position.
Heated door mirrors
(depending on the vehicle)
Engine running, mirror de-icing is car-
ried out at the same time as rear screen
de-icing. ➥ 3.4.
1.82
CarManuals2.co
EXTERIOR LIGHTING AND SIGNALS (1/4)
1
2
3
1
Side lights
Daytime running lights
š
function
Turn the ring 2 until the symbol
(front lights only)
is opposite mark 3.
This indicator light on the instrument
If fitted on the vehicle, the daytime run-
panel comes on.
ning lights come on automatically with
no action on stalk 1 when the engine is
Before driving at night,
started, and they go off once the engine
check that the electrical
is switched off.
equipment is operating cor-
Note: Daytime running light will go out
rectly and adjust the head-
automatically when the indicator is in
light beams (if your vehicle is not
operation.
carrying its normal load). ➥ 1.87.
When driving on the left-hand side
As a general precaution, check that
of the road in a left-hand drive vehi-
the lights are not obscured (by dirt,
cle (or vice versa), you must adjust
mud, snow or objects being trans-
your lights for the length of your
ported).
stay. ➥ 1.87.
1.83
CarManuals2.co
EXTERIOR LIGHTING AND SIGNALS (2/4)
To switch off the dipped
Main beam headlights
á
beam headlights:
With the engine running and
1
2
3
4
the dipped beam headlights lit, push
- turn the ring 2 to position š
stalk 1. This indicator light on the instru-
or
ment panel comes on.
– depending on the vehicle, to position
To return to the dipped headlight posi-
0;
tion, pull the stalk 1 towards you again.
Warning light k
goes out on the in-
Lights-on reminder buzzer
strument panel.
If the lights are on after the engine is
Switching off the lights
switched off, a warning beep sounds
The lights will go out automatically
when the driver’s door is opened to
when the engine is switched off, the
warn you that the lights are still on (to
driver’s door is opened or the vehicle
avoid draining the battery).
is locked. In this case, when you start
Dipped beam
the engine the lights will be switched
k
headlights
back on according to the position of the
ring 2, taking into account the exterior
Manual operation
light level, without moving the stalk 1.
Turn the ring 2 until the symbol is oppo-
site mark 3. This indicator light on the
instrument panel comes on.
Automatic operation
(depending on vehicle)
Turn ring 2 until the AUTO symbol is op-
posite mark 3: with the engine running,
the dipped beam headlights switch on
or off automatically depending on the
brightness of the light outside, without
any action on stalk 1.
1.84
CarManuals2.co
EXTERIOR LIGHTING AND SIGNALS (3/4)
Rear fog light
Switching off the lights
f
Turn centre ring 4 on the stalk
Turn centre ring 4 again until mark 3
1
3
4
until the symbol faces mark 3, then re-
is opposite the symbol for the fog light
lease it.
that you want to switch off. The corre-
sponding indicator light will go out on
Depending on the vehicle, the stalk re-
the instrument panel;
turns to the initial position or stays in
position.
The front and rear fog lights switch off
when the exterior lights are switched
Operation of the fog lights depends on
off.
the exterior lighting selected, and an in-
dicator light will light up on the instru-
ment panel.
To avoid inconveniencing other road
users, remember to switch off the rear
fog light when it is no longer needed.
Front fog lights
g
Turn centre ring 4 on stalk 1
until the symbol faces mark 3, then re-
lease it.
Operation of the fog lights depends on
the exterior lighting position selected,
and an indicator light will light up on the
When driving in fog or snow, or
instrument panel.
when transporting objects which are
higher than the roof, the headlights
do not come on automatically.
Switching on the fog lights remains
the responsibility of the driver: the
indicator lights on the instrument
panel inform you whether the fog
lights are lit (indicator light on) or not
(indicator light not on).
1.85
CarManuals2.co
EXTERIOR LIGHTING AND SIGNALS (4/4)
To increase this duration, you may pull
the stalk up to four times (total time re-
1
2
stricted to two minutes).
The message “Follow-me home_ _ _”
along with the times the lights will be on
for is displayed on the instrument panel
to confirm this action. You can then lock
your vehicle.
To switch off the lights before they go
out automatically, turn ring 2 to any po-
sition, then return it to position AUTO.
“See-me-home lighting”
function
(depending on the vehicle)
This function allows you to briefly switch
on the dipped beam headlights (to pro-
vide light when opening a gate, etc.).
With the engine lights switched off,
the 2 ring in AUTO, pull the lever 1 to-
wards you: the side lights and dipped
beam headlights will switch on for ap-
proximately 30 seconds along with the
š
and k
warning lights on the
instrument panel.
1.86
CarManuals2.co
HEADLIGHT BEAM ADJUSTMENT
Examples of positions for adjusting
control A according to the load
Driver alone or with front passenger
0
A
Driver with one front passenger and
1
one rear passenger
Driver with one front passenger and
2
Control A is used to adjust the height
two rear passengers
of the headlight beams according to the
load.
Turn control A anticlockwise to lower
Driver with one front passenger and
3
the beams and clockwise to raise them.
two or three rear passengers
Driver with one front passenger,
3
three rear passengers and luggage
The table below gives some examples. In all cases, adjust control A according to the
vehicle load so that the road can be seen and other drivers are not dazzled.
If driving on the left in a left-hand
drive vehicle (or vice versa), drivers
must have the lights adjusted by an
authorised dealer for the duration of
the trip.
1.87
CarManuals2.co
WINDSCREEN WASH, WIPE (1/5)
2
1
A
1
B
C
D
E
Vehicle fitted with intermittent
Special note
windscreen wipers
When driving the vehicle, the wiping
speed slows down whenever the ve-
A single sweep
hicle stops. For example, fast wiping
A short push will trigger one sweep
speed will slow to normal wiping speed.
of the wipers.
As soon as the vehicle moves off,
B stop
wiping will return to the speed originally
C intermittent wiping
selected.
The wipers will pause for sev-
If stalk 1 is operated, it overrides and
eral seconds between sweeps.
cancels the automatic function.
Depending on the vehicle, you can
change the time interval between
sweeps by turning the ring 2.
D slow continuous wiping
E fast continuous wiping
1.88
CarManuals2.co
WINDSCREEN WASH, WIPE (2/5)
When activating automatic wiping or
when increasing sensitivity, one sweep
of the blades is performed.
1
2
F
Note:
A
1
-
the rain sensor is only intended as a
B
driving aid. In the event of reduced
visibility, the driver should manually
C
activate the wipers. In foggy weather
or during snowfalls, wiping is not au-
D
tomatically triggered and remains
G
E
under the driver’s control;
-
in the event of temperatures below
zero, automatic wiping is not acti-
vated when the vehicle is started. It
is automatically activated as soon as
Vehicle fitted with front
C
automatic wiper function
the vehicle exceeds a certain speed
When this position is selected, the
windscreen wiper rain sensor
(approximately 5 mph (8 km/h));
system detects water on the wind-
The rain sensor is located on the winds-
screen and triggers the wipers at a
-
do not activate automatic wiping in
creen, in front of the interior rear-view
suitable wiping speed. It is possi-
dry weather;
mirror.
ble to change the triggering thresh-
-
fully de-ice the windscreen before
old and the time sweeps by turning
A single sweep
activating automatic wiping;
ring 2:
A short push will trigger one sweep
-
when washing the vehicle under a
- F : minimum sensitivity;
of the wipers.
roller type car wash, return the ring 1
B stop
- G : maximum sensitivity.
to the B position to deactivate auto-
The higher the sensitivity, the quicker
matic wiping.
the wipers will react and the faster
the wipe.
1.89
CarManuals2.co
WINDSCREEN WASH, WIPE (3/5)
Operating faults
Special note
In the event of a malfunction of the au-
When driving the vehicle, the wiping
tomatic wiping, the wiper is set to inter-
speed slows down whenever the vehi-
mittent wiping. Contact an authorised
cle stops. For example, fast wiping
dealer.
A
speed will slow to normal wiping speed.
1
As soon as the vehicle moves off,
The operation of the rain sensor can be
B
wiping will return to the speed originally
disturbed in the event of:
selected.
- damaged wiper blades; a screen
C
If stalk 1 is operated, it overrides and
of water or traces left by a blade in
D
cancels the automatic function.
the sensor’s detection zone may
increase the response time of the
E
Precautions
automatic wiper, or increase the
wiping frequency;
- In the event of ice, check whether the
- a windscreen with any chip or
blades are stuck to the windscreen
crack level with the sensor, or a
before operating the wiping mecha-
windscreen covered in dust, dirt,
nism. If you activate the wipers while
D
slow continuous wiping
insects, ice, the use of washing
the blades are stuck down with ice,
wax and water-repellent chemi-
you may risk damaging both the
E
fast continuous wiping
cals; the automatic wiping will be
blade and the wiper motor.
less sensitive, or even unrespon-
- Do not activate the wipers on a dry
sive.
screen. This will lead to premature
wear or damage to the blades.
1.90
CarManuals2.co
WINDSCREEN WASH, WIPE (4/5)
Specific front wiper position
(service position)
This position enables the blades to be
lifted to remove them from the winds-
A
creen.
1
It may be useful to:
B
- to clean the blades;
C
- to release the blades from the winds-
creen in winter;
D
- replace the blades ➥ 5.35.
E
With the ignition off, set the stalk 1 to
position E (fast wiping speed function).
The blades stop slightly away from the
bonnet.
To return the blades to their lowered po-
sition, with the ignition off, ensure that
the wipers have folded down onto the
windscreen, then set the stalk 1 to posi-
tion B (off).
In the event of obstacles on the
Before switching on the ignition,
windscreen (dirt, snow, ice etc.),
place the wipers on the windscreen.
clean the windscreen (including the
Otherwise, there may a risk of damage
central area located behind the inte-
to the bonnet or the wipers when they
rior rear view mirror) before starting
are switched on.
the wipers (risk of motor overheat-
Before any action involving
ing).
the windscreen
(washing
the vehicle, de-icing, clean-
If an object is preventing a blade
ing the windscreen, etc.)
from moving, it may stop functio-
return stalk 1 to position B (stop).
ning. Remove the obstacle and
reactivate the wiper using the wiper
Risk of injury and/or damage.
stalk.
1.91
CarManuals2.co
WINDSCREEN WASH, WIPE (5/5)
Note:
In temperatures below zero, the washer
liquid risks freezing to the windscreen,
thereby reducing visibility. Heat the
windscreen using the demister control
1
before cleaning.
Efficiency of a wiper blade
Check the condition of the wiper
blades. How long they last depends
on you:
- it must remain clean: clean the
blade and the screen regularly
with soapy water;
- do not use it when the screen is
dry;
Windscreen washer
- free it from the screen when it has
With the ignition on, pull stalk 1 then
not been used for a long time.
release.
In all cases, replace it as soon as
A longer pull will trigger, in addition to
it begins to lose efficiency: approxi-
the windscreen washer, two sweeps
mately once a year. ➥ 5.35.
of the wipers followed, a few seconds
later, by a third.
Precaution for using the
wipers
- In freezing or snowy weather
conditions, clear the screen
When working in the engine
before starting the wipers (risk of
compartment, ensure that
motor overheating);
the windscreen wiper stalk
- ensure that no objects are ob-
is in position B (park).
structing the travel of the blade.
Risk of injury.
1.92
CarManuals2.co
REAR SCREEN WASHER, WIPER (1/2)
To stop the operation, pivot ring 3 again.
Note:
2
3
When washing using a roller type car
1
wash, return the ring 3 on the stalk 1
to the stop position to deactivate auto-
matic wiping.
Follow usage recommendations.
Efficiency of a wiper blade
Check the condition of the wiper
blades. How long they last depends
on you:
- it must remain clean: clean the
blade and the screen regularly
with soapy water;
- do not use it when the screen is
dry;
Rear windscreen wiper
- free it from the screen when it has
Y
With the ignition on, turn ring 3
not been used for a long time.
on stalk 1 to align the symbol with
In all cases, replace it as soon as
mark 2.
Do not use the wiper arm to open or
it begins to lose efficiency: approxi-
- stop;
close the tailgate.
mately once a year. ➥ 5.35.
- intermittent wiping.
The wipers will pause for several
Precaution for using the
seconds between sweeps.
wipers
Before any action involving
- In freezing or snowy weather
the rear screen (washing
conditions, clear the screen
the vehicle, de-icing, clean-
before starting the wipers (risk of
ing, etc.) return stalk 1 to
motor overheating);
the stop position.
- ensure that no objects are ob-
structing the travel of the blade.
Risk of injury and/or damage.
1.93
CarManuals2.co
REAR SCREEN WASHER, WIPER (2/2)
In the event of obstacles present on the
rear window (dirt, snow, etc.), the wiper
will try to sweep away all the obstacles.
1
If an obstacle prevents the blade from
moving, it can be stopped. Remove the
obstacle, wait for around 30 seconds
and reactivate the wiper using the wiper
stalk.
Precautions
-
In the event of ice, check that the
blades are not stuck to the wind-
screen before operating the wipers.
If you activate the wiper while the
blade is blocked by ice, you risk dam-
aging both the blade and the wiping
motor.
Rear screen wash/wipe
p
-
Do not operate the wipers on a dry
With the ignition on, push and
screen. This will lead to the prema-
hold stalk 1, then release.
ture wear or damage to the blades.
Holding the stalk for longer will trigger
(in addition to the windscreen washer)
two sweeps of the wipers followed,
a few seconds later, by a third (drip
wiping function).
When the stalk is released, it returns to
the rear wipe position.
1.94
CarManuals2.co
FUEL TANK (1/4)
For details on filling the fuel tank, refer
to the information on “Filling with fuel”.
To close it, press the cover B with your
A
hand, as far as it will go.
To fill up with fuel, the engine
Depending on the vehicle, the hook A
must be stopped (and not
B
prevents the sliding side door from
only on standby in the case
opening fully.
of vehicles equipped with
1
the STOP and START function): you
must switch off the ignition ➥ 2.3.
Fire hazard.
C
2
Petrol and diesel versions
Usable capacity of the fuel tank:
50 litres approximately.
Fuel filler cap: this is a
specific type.
To open the fuel flap B, place your
finger in the recess C.
If you have to replace it,
make sure it is identical
On some vehicles, the cap 1 can be un-
to the original cap. Contact an ap-
locked with the ignition key. If not, un-
proved Dealer.
screw the fuel filler cap, it is connected
to the vehicle by a strip of plastic.
Never place the cap near a source
of heat or flame.
Use the cap holder 2 on the flap B
during filling to hold the cap 1 in place.
Do not wash the filler area with a
high-pressure washer.
After filling, check that the cap and
cover are closed.
1.95
CarManuals2.co
FUEL TANK (2/4)
Fuel grade
Use a high-grade fuel that complies
with the legislation in force in each
country. It must comply with the spec-
ifications given on the label D on the
inside of the flap. ➥ 6.7.
Petrol versions
D
It is essential to use unleaded petrol.
The octane rating (RON) must conform
to the information given on the label D
on the inside of the flap ➥ 6.7.
Diesel versions
It is essential to use diesel that con-
Do not mix even small
forms to the information given on the
amounts of petrol
(un-
label D on the inside of the flap ➥ 6.7.
leaded or E85) with diesel.
Do not use ethanol-based
fuel if your vehicle is not compatible
with this fuel.
Do not add reagent to the fuel -
otherwise you risk damaging the
engine.
If you wish to add an additive to the
fuel, use a product approved by our
Technical Department.
Consult an approved dealer.
Fuel types that conform to European
standards with which the engines of
vehicles sold in Europe are compat-
ible: refer to the table ➥ 6.7.
1.96
CarManuals2.co
FUEL TANK (3/4)
Filling with fuel
Petrol versions
Special case
Using leaded petrol will damage the
With the ignition off, insert the nozzle to
When the vehicle has been stopped for
antipollution system and may lead to a
open the valve and insert it fully before
around three months, you must add
loss of warranty.
turning it on to fill the fuel tank (risk of
fuel to prevent damage to the fuel
splashing).
To ensure that the fuel tank is not filled
pump.
with leaded petrol, the fuel tank filler
Keep the nozzle in this position
To do this, with the ignition off, top-up
neck contains a restrictor fitted with a
throughout the entire filling operation.
at least 1.10 gallons (5 litres) then start
foolproof system which only allows
When the pump cuts out automatically
the engine to operate the pump and
the nozzle for unleaded petrol to be
at the end of the filling procedure, a
renew the fuel in the circuit.
used (at the pump).
maximum of two further filling attempts
If it is not possible to add at least 1.10
may be made, as there must be suffi-
gallons (5 litres) of fuel due to the fuel
cient space in the fuel tank to allow for
level in the tank, drive the vehicle until
expansion.
the tank has capacity.
Make sure that no water enters the fuel
tank during filling. The valve and its sur-
round must remain clean.
Persistent fuel odour
If you notice a persistent
fuel odour you should:
-
stop the vehicle as soon as traf-
fic conditions allow and switch off
the ignition;
-
switch on the hazard warning
lights and ask your passengers to
leave the vehicle and stay clear
of the traffic;
-
contact an approved Dealer.
1.97
CarManuals2.co
FUEL TANK (4/4)
Running out of fuel on Diesel
versions
Set the ignition key to “On” position C
➥ 2.2 and wait a few minutes before
starting in order to enable the fuel cir-
cuit to be primed.
If the engine does not start, repeat the
procedure.
If the engine does not start after several
attempts, please contact an authorised
dealer.
Please note when work-
No modifications what-
ing close to the engine that
soever are permitted on
it may be hot. The engine
any part of the fuel supply
cooling fan may also start
system
(electronic units,
wiring, fuel circuit, injectors, pro-
at any moment. The
label
tective covers, etc.) as this may be
in the engine compartment reminds
dangerous (unless undertaken by
you of this.
qualified Network personnel).
Risk of injury.
1.98
CarManuals2.co
|
||
|
|
|
