DRIVING CORRECTION DEVICES AND AIDS (3/5)
Electronic stability program
Understeer control
Operating faults
(ESC) with understeer control
This system optimises the action of the
When the system detects an operat-
and traction control
ESC in the case of pronounced under-
ing fault the message “Check ESC”
steering (loss of front axle road hold-
and warning lights
and
Electronic stability program ESC
ing).
appear on the instrument panel. In
This system helps you to keep control
Traction control
this case, the ESC and traction control
of the vehicle in critical driving condi-
system are deactivated.
tions (avoiding an obstacle, loss of grip
This system helps to limit wheelspin of
on a bend, etc.).
the drive wheels and to control the ve-
Consult an approved dealer.
hicle when pulling away, accelerating or
Operating principle
decelerating.
A sensor in the steering wheel detects
Operating principle
the direction selected by the driver.
Using the wheel sensors, the system
Other sensors fitted throughout the ve-
measures and compares the speed of
hicle measure the actual direction.
the drive wheels at all times and slows
down their over-rotation. If a wheel is
The system compares driver input to
starting to slip, the system brakes au-
the actual trajectory of the vehicle and
tomatically until the drive supplied be-
corrects the trajectory if necessary by
comes compatible with the level of grip
controlling the braking of certain wheels
under the wheel again.
and/or engine power. In the event that
The system also adjusts the engine
the system is triggered, the
speed to the grip available under the
warning light flashes on the instrument
wheels, independently of the pressure
panel.
exerted on the accelerator pedal.
In some situations (driving on very wet
ground: snow, mud, etc. or driving with
snow chains fitted), the system may
reduce the engine output to limit wheel-
spin.
2.34
CarManuals2.co
DRIVING CORRECTION DEVICES AND AIDS (4/5)
Emergency brake assist
Hazard warning lights switching on
Depending on the vehicle, these may
This system supplements the ABS
light up in the event of sudden decel-
and helps reduce vehicle stopping dis-
eration.
tances.
Braking anticipation
Operating principle
Depending on the vehicle, when you
The system enables detection of an
rapidly release the accelerator, the
emergency braking situation. In this
system anticipates the braking ma-
case, the braking system immediately
noeuvre in order to reduce stopping
develops maximum power and may
distances.
trigger ABS regulation.
Special cases
ABS braking is maintained as long as
the brake pedal is applied.
When using the cruise control:
These functions are an ad-
- if you use the accelerator, when you
ditional aid in the event of
release it, the system may be trig-
critical driving conditions,
gered;
enabling the vehicle behav-
- if you do not use the accelerator, the
iour to be adapted to suit the driving
system will not be triggered.
conditions.
These functions do not take the
Operating faults
place of the driver. They do not
When the system detects an operating
increase the vehicle’s limits and
fault the message “WARNING: Check
should not encourage you to
Braking System” appears on the instru-
drive more quickly. Under no cir-
cumstances should they replace
ing light.
the vigilance or responsibility of the
driver when manoeuvring the vehi-
Consult an approved dealer.
cle (the driver must always be ready
for sudden incidents which may
occur when driving).
2.35
CarManuals2.co
DRIVING CORRECTION DEVICES AND AIDS (5/5)
Hill start assistance
The hill start assistance
Depending on the gradient of the in-
system cannot completely
cline, this system assists the driver
prevent the vehicle from
when starting on a hill. It prevents the
rolling backwards in all sit-
vehicle from rolling backwards by au-
uations (extremely steep gradients
tomatically applying the brakes when
etc.).
the driver lifts his/her foot off the brake
In all cases, the driver may depress
pedal to depress the accelerator pedal.
the brake pedal to prevent the vehi-
cle from rolling backwards.
System operation
The hill start assistance function
It only operates when the gear lever is
should not be used for prolonged
in a position other than neutral (other
stops: use the brake pedal.
than N or P on automatic gearboxes)
and the vehicle is completely stationary
This function is not designed to im-
(brake pedal depressed).
mobilise the vehicle permanently.
The system holds the vehicle for ap-
If necessary, use the brake pedal to
proximately 2 seconds. The brakes are
stop the vehicle.
then gradually released (the vehicle will
The driver must remain particularly
move according to the slope).
vigilant when driving on slippery or
low-grip surfaces.
Risk of serious injury.
2.36
CarManuals2.co
LANE DEPARTURE WARNING (1/5)
1
Using information from the 1 camera,
the function warns the driver when a
continuous or broken line is crossed
or when approaching the roadside (di-
vider, barrier, pavement, embankment,
etc.) without the direction indicator
This function is an addi-
lights being activated.
tional driving aid. This func-
tion is not under any cir-
Note: make sure the windscreen is not
cumstances intended to
obscured (dirt, mud, snow, condensa-
replace the due care and attention
tion etc.).
of the driver, who should at all times
be in control of the vehicle.
The lane departure warning func-
tion does not correct the vehi-
cle’s trajectory.
2.37
CarManuals2.co
LANE DEPARTURE WARNING (2/5)
Operation
When the function is activated, the
warning light and the left and
right lines 3 are displayed in grey on the
instrument panel.
The function is set to notify the
3
driver if:
2
- speed is between approximately
43 mph (70 km/h) and 112 mph
(180 km/h);
and
- the
warning light and left/right
line indicators 3 are coloured white.
Activation/deactivation
The warning function is triggered
The function alerts the driver:
To activate the function, press the 2
if the vehicle breaches a line or ap-
- by a vibration in the steering wheel;
switch as many times as required to
proaches a roadside (divider, barrier,
and
pavement, embankment, etc.) without
select “Lane Departure Warning” on
the direction indicator lights being ac-
- the
warning light and 3 the in-
the instrument panel. The “Lane depar-
tivated.
dicator for the crossed line turn red.
ture warning on” message and “”
warning light are displayed on the in-
strument panel.
To disable the function, press the 2
switch as many times as required to
select
“Lane departure warning off”
(or, depending on the vehicle “Lane
Keeping deactivated”) on the instru-
Each time the vehicle is started,
ment panel. Warning light
goes
the function continues the mode
out on the instrument panel.
saved the last time the engine was
stopped.
2.38
CarManuals2.co
LANE DEPARTURE WARNING (3/5)
Temporarily not available
Conditions for non-activation
- very fast lane departure;
of the system
The system cannot be activated when:
4
- driving continuously on a line;
- four seconds approximately after
- reverse gear is engaged;
changing lanes;
- the field of vision of the camera is ob-
- tight bends;
structed;
- impaired visibility;
- the û
warning light is displayed.
- activation of one of the direction indi-
cator lights;
The
warning light and the left/
right line indicators turn to grey on the
- strong acceleration;
instrument panel.
- ...
When the function is not available, the
Adjustment
-
“Warning”: adjust the line detection
warning light and the left/right in-
sensitivity level. To do this, select:
Vehicles fitted with a multimedia
dicators turn to grey on the instrument
screen.
- “Late”: line detected when cross-
panel.
ing;
To access the multimedia screen func-
tion settings 4, refer to the multimedia
- “Standard”: line detected on ap-
instructions:
proach;
- “Vibration”: adjust the steering wheel
- “Early”: line detected nearby.
vibration level;
Please refer to the multimedia instruc-
tions for further information.
2.39
CarManuals2.co
LANE DEPARTURE WARNING (4/5)
-
press the 6 or 7 control repeatedly to
Operating faults
reach the “DRIVING ASSIST” menu.
In the event of a malfunction, the left
Press the switch 8 OK;
and right line indicators (and, depend-
-
scroll repeatedly pressing control 6
or 7 to access the “Lane Departure
ing on display style, the
warning
Sensitivity” or
“Lane Departure
light) disappear or stay grey on the in-
Vibration” menu. Press the switch 8
strument panel.
OK ;
In some cases, they are accompa-
5
6
-
scroll repeatedly pressing control 6
nied by the message “Front camera to
or 7 to adjust the setting. Press the 8
check” or the
warning light on
OK switch.
the instrument panel.
Consult an approved dealer.
8
7
Adjustments (continued)
Vehicles not fitted with a multimedia
screen
- With the vehicle stopped, press the 5
switch as many times as required to
reach the “Vehicle” tab;
- press the 6 or 7 control repeatedly to
reach the “Settings” menu. Press the
switch 8 OK;
2.40
CarManuals2.co
LANE DEPARTURE WARNING (5/5)
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle.
System servicing/repairs
- In the event of an impact, the camera alignment may be changed, and its operation may consequently be affected. Deactivate
the function, then consult an authorised dealer.
- Any work in the area where the camera is located (repairs, replacements, windscreen modifications etc.) must be carried
out by a qualified professional.
Only an authorised dealer is qualified to service the system.
In the event of system disturbance
Some conditions can disturb or damage the operation of the system, such as:
- windscreen obscured (by dirt, ice, snow, condensation etc.);
- a complex environment (tunnel etc.);
- poor weather conditions (snow, rain, hail, black ice etc.) ;
- poor visibility (night, fog etc.);
- the road markings are irregular or difficult to distinguish (e.g. partially erased, excessive spacing, distorted road surface) ;
- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);
- the road is narrow, winding or undulating (tight bends etc.);
- closely following a vehicle travelling in the same lane.
Risk of false alarms or absence of warnings
2.41
CarManuals2.co
LANE KEEPING ASSIST (1/6)
Note: make sure the windscreen is not
1
obscured (dirt, mud, snow, condensa-
tion etc.).
Using information from the 1 camera,
This function is an addi-
the function triggers corrective action
tional driving aid and the
on the vehicle steering system when
driver is responsible for
a continuous or broken line is crossed
steering wheel operation.
or when approaching the roadside (di-
This system is not a substitute for
vider, barrier, pavement, embankment,
the driver and the driver must drive
etc.) without the direction indicator
with his hands on the streering
lights being activated.
wheel when driving.
Always be careful when driving, as
the system may not be unexpect-
edly deactivated or operated, or
may operate unecessarily depend-
ing on the road conditions and at-
tention circumstances.
You can retake control of the ve-
hicle at any time by operating the
steering wheel.
2.42
CarManuals2.co
LANE KEEPING ASSIST (2/6)
To disable the function, press the 2
switch as many times as required to
select “Lane Keeping deactivated” on
the instrument panel.
Warning light
goes out on the in-
strument panel.
Note: deactivating the “Lane Keeping
2
Assist” function causes deactivation of
the “Lane Departure Warning” function.
Activation/deactivation
To activate the function, press the 2
switch as many times as required to
select “Lane Keeping Assist” on the in-
strument panel.
The “Lane Keeping activated” message
and “
” warning light are displayed
on the instrument panel.
When Lane Keeping Assist is activated,
the “Lane Departure Warning” function
is automatically activated. ➥ 2.37
Each time the vehicle is started,
the function continues the mode
saved the last time the engine was
stopped.
2.43
CarManuals2.co
LANE KEEPING ASSIST (3/6)
The function operates if the vehicle
Special case
breaches a line or if the vehicle ap-
When using the system:
proaches the roadside (divider, barrier,
-
If the system can no longer detect
pavement, embankment, etc.) without
any action by the driver on the steer-
the direction indicator lights being ac-
tivated.
ing wheel, the
warning light
appears in orange on the instrument
In these cases:
3
panel, accompanied by the message
- the function triggers an action on the
“Keep hands on steering wheel” and
vehicle’s steering system to correct
an audible warning.
the vehicle trajectory;
-
if the system is active for too long,
- the 3 indicator on the side of the
an audible warning is emitted and
breached line turns to yellow on the
the indicator 3 on the side of the line
instrument panel.
concerned flashes until the driver
takes control.
Note: on bends, the function allows for
slightly cutting the bend.
Operation
When the function is activated, the
If the corrective action on the steer-
Please note that the system
warning light and the left and
ing system is not sufficient, the
warning may appear late
right lines 3 are displayed in grey on the
warning light and 3 indicator on the side
according to road condi-
instrument panel.
of the breached line turn to red on the
tions when driver’s hands
instrument panel, accompanied by a vi-
are off the steering wheel.
The function is set to operate when
bration on the steering wheel.
the vehicle speed is between approxi-
Always have your hands on the
mately 43 mph (70 km/h) and 112 mph
steering wheel when driving.
(180 km/h) and if the
warning
The system may warn driver that
light and 3 correction indicators are col-
driver is not holding the steering
oured white.
wheel when the driver operates
steering wheel excessively or holds
on the steering wheel softly.
You can interrupt the trajectory cor-
rection at any time by moving the
steering wheel.
2.44
CarManuals2.co
LANE KEEPING ASSIST (4/6)
Temporarily not available
Conditions for non-activation
– very fast lane departure;
of the system
4
The system cannot be activated when:
- driving continuously on a line;
- four seconds approximately after
- reverse gear is engaged;
changing lanes;
- the field of vision of the camera is ob-
- tight bends;
structed;
- impaired visibility;
- the û
warning light is displayed.
- activation of one of the direction indi-
The
warning light and the left/
cator lights;
right line warning lights are displayed in
- strong acceleration;
grey on the instrument panel.
– emergency braking;
- ...
Adjustment
-
“Warning”: adjust the line detection
If the function is unavailable, the
Vehicles fitted with a multimedia
sensitivity level. To do this, select:
warning light and the left/right correc-
screen.
- “Late”: line detected when cross-
tion warning lights 3 appear in grey on
To access the multimedia screen func-
ing;
the instrument panel.
tion settings 4, refer to the multimedia
- “Standard”: line detected on ap-
instructions:
proach;
- “Vibration”: adjust steering wheel
- “Early”: line detected nearby.
vibration for the
“Lane Departure
Warning” function;
Please refer to the multimedia instruc-
tions for further information.
2.45
CarManuals2.co
LANE KEEPING ASSIST (5/6)
- press the 6 or 7 control repeatedly to
Operating faults
reach the “DRIVING ASSIST” menu.
When the system detects an operating
Press the switch 8 OK;
fault, the
warning light lights up
– scroll repeatedly by pressing 6 or 7
on the instrument panel, with the mes-
to reach the “Lane Keeping sen-
sage “Front camera to check”.
sitivity” menu. Press the switch 8
Consult an approved dealer.
OK ;
- scroll repeatedly pressing control 6
6
or 7 to adjust the setting. Press the 8
5
OK button.
8
7
Adjustments (continued)
Vehicles not fitted with a multimedia
screen
- With the vehicle stopped, press the
switch 5 as many times as required
to reach the “Vehicle” tab;
- press the 6 or 7 control repeatedly to
reach the “Settings” menu. Press the
switch 8 OK;
2.46
CarManuals2.co
LANE KEEPING ASSIST (6/6)
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle.
System servicing/repairs
- In the event of an impact, the camera alignment may be changed, and its operation may consequently be affected. Deactivate
the function and consult an authorised dealer.
- Any work in the area where the camera is located (repairs, replacements, windscreen modifications etc.) must be carried
out by a qualified professional.
Only an authorised dealer is qualified to service the system.
In the event of system disturbance
Some conditions can disturb or damage the operation of the system, such as:
- windscreen obscured (by dirt, ice, snow, condensation etc.);
- a complex environment (tunnel etc.);
- poor weather conditions (snow, rain, hail, black ice etc.) ;
- poor visibility (night, fog etc.);
- the road markings are irregular or difficult to distinguish (e.g. partially erased, excessive spacing, distorted road surface) ;
- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);
- the road is narrow, winding or undulating (tight bends etc.);
- closely following a vehicle travelling in the same lane.
In this case, the “Lane Keeping Assist” may react incorrectly or not at all.
Risk of unwanted, incorrect correction or no correction of trajectory.
Deactivating the function
You must disable the function if:
- the area of the camera has been damaged (on the windscreen side or the interior rear-view mirror side);
- the road is slippery (snow, black ice, aquaplaning, gravel etc.) ;
- poor visibility (night, fog etc.);
- the windscreen is cracked or distorted (do not carry out windscreen repairs in this area; have it changed by an Authorised
Dealer);
- the vehicle is towing a trailer or a caravan;
- the vehicle is entering an area with several surface markings (an area with road works etc.).
2.47
CarManuals2.co
BLIND SPOT WARNING (1/7)
A
B
C
A
B
Using information from the sensors in-
Special feature
stalled on each side of the rear bumper
Ensure that the C area around the
(area C), the function warns the driver:
radars on each side of the rear bumper
are not obstructed (by dirt, mud, snow
- when another vehicle appears in the
etc.)
detection area A;
If a radar is obscured, the message
and/or
“Side radars no visibility” will appear on
- when there is a risk of collision with
the instrument panel. Clean the area
a vehicle that is in area B, driving
where the sensors are located.
faster than you.
This function is an addi-
tional driving aid. This func-
The function warns you when the ve-
tion is not under any cir-
hicle is travelling at a speed above ap-
cumstances intended to
proximately 9 mph (15 km/h).
replace the due care and attention
of the driver, who should at all times
be in control of the vehicle.
2.48
CarManuals2.co
BLIND SPOT WARNING (2/7)
- press the switch 5 OK again to acti-
vate or deactivate the function:
1
=
function activated
<
function deactivated
3
2
5
4
Activation/deactivation
- press the 3 or 4 control repeatedly to
reach the “Settings” menu. Press the
Vehicles fitted with a multimedia
switch 5 OK;
screen 1
- press the 3 or 4 control repeatedly to
To activate or deactivate the function,
reach the “DRIVING ASSIST” menu.
refer to the multimedia instructions.
Press the switch 5 OK;
Select “ON” or “OFF”.
- press the 3 or 4 control repeatedly to
reach the “Blind spot alert” menu and
Vehicles not fitted with a multimedia
press the 5 OK switch;
screen
- With the vehicle stopped, press the 2
switch as many times as required to
The system’s detection range oper-
reach the “Vehicle” tab;
ates according to a standard lane
width. When driving in a narrow
lane, the function can warn you
when a vehicle is detected beyond
the adjacent lane.
2.49
CarManuals2.co
BLIND SPOT WARNING (3/7)
6
A
B
7
A
B
Indicator 6
Operation
An indicator light 6 is located on each
The function warns you when the speed
rear view mirror 7.
of your vehicle is over 9 mph (15 km/h):
- when another vehicle is in the blind
Note: clean the rear view mirrors 7 reg-
spot area A and travelling in the
ularly so that the indicators 6 can be
same direction as your vehicle;
seen.
- when a vehicle approaches quickly
from the rear in an adjacent lane
within the range of detection area B.
If you overtake another vehicle, the 6
indicator will only come on if that vehi-
cle remains for a long enough period in
your vehicle’s blind spot A.
The function does not notify the
driver if the other vehicles are not
moving.
2.50
CarManuals2.co
BLIND SPOT WARNING (4/7)
Display E
Conditions for non-function
6
Direction indicator activated, the 6
- When driving on a road with tight
warning light flashes when the func-
bends;
tion detects a vehicle in the blind spot
- in reverse.
warning area and/or a vehicle is rapidly
D
approaching from the rear on the side
If the vehicle is equipped with a towbar
towards which you will turn the wheel.
recognised by the system, the “Trailer:
If you cancel the direction indicator, the
blind spot alert off” message displayed
function will return to the initial warning
on the instrument panel informs you
(display D).
that the function is not operational. For
information on the range of equipment
E
adapted to your vehicle, we advise you
to consult an approved Dealer.
Display D
First warning: direction indicator not
activated, the 6 warning light indicates
that a vehicle is detected in the blind
spot area and/or that a vehicle is rap-
idly approaching from the rear in an ad-
jacent lane.
When the engine is started, the
system adopts the last status saved
before the ignition was switched off
(refer to the previous pages).
2.51
CarManuals2.co
BLIND SPOT WARNING (5/7)
Operating faults
If the system detects a fault, the mes-
sage “Check Side radars” is displayed
on the instrument panel. Consult an ap-
proved dealer.
-The system’s detection
range operates according
to a standard lane width. If
you are driving in wide traf-
fic lanes, the system might not
be able to detect a vehicle in the
blind spot.
- The system might be disrupted
momentarily if it is exposed to
strong electromagnetic waves
(as beneath high-tension power
lines) or to very poor weather
conditions
(heavy rain, snow
etc.). Remain aware of driving
conditions.
Due to the presence of sensors
There is a risk of accidents.
behind the bumper, it is advisable to
entrust any operation on the bumper
(repair, replacement, paintwork,
etc.) to a qualified professional.
2.52
CarManuals2.co
BLIND SPOT WARNING (6/7)
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle.
The driver should always adapt their speed to the traffic conditions, regardless of the system indications.
The system should under no circumstances be taken to be an obstacle detector or an anti-collision system.
System servicing/repairs
- In the event of an impact, radar alignment may be changed, and its operation will consequently be affected. Deactivate the
function and consult an authorised dealer.
- Any work in the area where the radars are located (repairs, replacements, etc.) must be carried out by a qualified profes-
sional.
Only an authorised dealer is qualified to service the system.
System disturbance
Some conditions can disturb or damage the operation of the system, such as:
- complex surroundings (metal bridges, tunnels, roads with barriers at the edge, etc.);
- poor weather conditions (snow, hail, black ice, etc.).
Risk of false alarms or absence of warnings
In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.
2.53
CarManuals2.co
BLIND SPOT WARNING (7/7)
Limitation of the system operation
- The radar area should be kept clean and free of any modifications in order to ensure the proper operation of the
system.
- Small objects moving close to the vehicle (motorcycles, bicycles, pedestrians, etc.) may not be recognised by the system.
- When turning into a bend, the radars may temporarily cease to detect vehicles in adjacent lanes.
- The function may warn you late if two other vehicles are approaching from the rear, driving side by side in the adjacent lanes
(i.e. driving on a 3-lane road) at a much higher speed than your vehicle.
- The system may not provide a warning when the other vehicles are travelling at a significantly different speed.
- If the vehicle is being overtaken by a long vehicle (e.g. heavy goods vehicle overtaking at a similar speed to the vehicle) the
system may interrupt the warning before the end of the manoeuvre.
- The vehicle is travelling on a winding road.
Deactivating the function
You must disable the function if:
- the radar area has been damaged (rear bumper);
- the vehicle is fitted with a towbar that is not recognised by the system.
2.54
CarManuals2.co
SAFE DISTANCE ALERT (1/4)
Note: ensure that the windscreen and
1
the bumper are not obscured (by dirt,
mud, snow, condensation forming,
etc.).
The function is activated when the vehi-
cle speed is between about 19 and
124 mph (30 and 200 km/h).
2
Using the information from the radar 2
and camera 1, this function informs the
driver of the time interval between their
vehicle and the vehicle in front so that a
safe stopping distance between the two
vehicles can be maintained.
This function is an addi-
tional driving aid. This func-
tion is not under any cir-
cumstances intended to
replace the due care and attention
of the driver, who should at all times
be in control of the vehicle.
2.55
CarManuals2.co
SAFE DISTANCE ALERT (2/4)
- press the 5 or 6 control repeatedly to
reach the “Distance warning” menu.
Press the switch 7 OK;
3
- Press the switch 7 OK again to acti-
vate or deactivate the function:
=
function activated
<
function deactivated
4
5
7
6
Activating/deactivating the
Vehicles not fitted with a multimedia
screen
function
- With the vehicle stopped, press the
Vehicles fitted with a multimedia
switch 4 as many times as required
screen 3
to reach the “Vehicle” tab;
To activate or deactivate the function,
- press the 5 or 6 control repeatedly to
refer to the multimedia instructions.
reach the “Settings” menu. Press the
Select “ON” or “OFF”.
switch 7 OK;
- press the 5 or 6 control repeatedly to
reach the “DRIVING ASSIST” menu.
Press the switch 7 OK;
Each time the vehicle is started,
the function continues the mode
saved the last time the engine was
stopped.
2.56
CarManuals2.co
SAFE DISTANCE ALERT (3/4)
- C (orange): the time interval falls be-
8
tween around 1 and 2 seconds (in-
A
sufficient distance between the two
vehicles);
- D (red): the time interval is less than
or equal to around one second (very
The measurement is dis-
B
insufficient distance between the two
played for information: the
vehicles).
system does not carry out
any action on the vehicle.
If the interval between the two vehi-
C
cles is less than approximately 0.5 sec-
This function is not designed for use
onds, the 8 indicator and the D display
in urban conditions or for a dynamic
will flash in red on the instrument panel
driving style (sudden cornering, ac-
along with “-.- s”.
celeration, braking, etc.), but rather
D
for stable driving conditions.
Under certain conditions, the time inter-
val may not be displayed:
The function does not interact with
Operation
the braking system.
- while cornering;
With the function activated, the 8 in-
The radar and camera zones must
- when changing lane;
dicator is displayed on the instrument
be kept clean and free of any tam-
panel and informs the driver of the dis-
- if the vehicle in front is sufficiently far
pering in order to ensure the proper
tance between their vehicle and the ve-
or outside the range of the radar or
operation of the system.
hicle in front.
camera.
Any work carried out in the area
- A (grey): function not operational;
where the radar or camera is lo-
cated (repairs, replacements, wind-
- A (green): no vehicle detected;
screen and/or bumper modifica-
- B (green): the time interval is greater
tions, etc.) must be carried out by a
than or equal to around two seconds
qualified professional.
(distance between the two vehicles
adapted to your speed);
2.57
CarManuals2.co
SAFE DISTANCE ALERT (4/4)
This function is an additional driving aid. This function is not under any circumstances intended to replace the due care
and attention of the driver, who should at all times be in control of the vehicle.
System servicing/repairs
- In the event of an impact, the radar and/or camera alignment may be changed and its operation may consequently be af-
fected. Deactivate the function and consult an authorised dealer.
- Any work carried out in the area where the radar and/or camera is located (replacements, repairs, windscreen and/or
bumper modifications, etc.) must be carried out by a qualified professional.
Only an authorised dealer is qualified to service the system.
In the event of system disturbance
- obstruction of the windscreen or the bumper (by dirt, glass, snow, condensation, etc.);
- a complex environment (metal bridge, tunnel etc.);
- poor weather conditions (snow, hail, black ice etc.);
- poor visibility (night, fog etc.);
- poor contrast between the vehicle preceding it and the surrounding area (e.g. white vehicle in a snowy area etc.) ;
- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);
- the road is narrow, winding and undulating (tight bends etc.)
Risk of erroneous false alarms.
2.58
CarManuals2.co
360° CAMERA (1/10)
1
5
4
2
2
3
Using information from cameras 1, 2,
Operation
- front side view (depending on the ve-
and 3 located in the front bumper, door
hicle): using camera 2 (passenger
The cameras transmit four separate
mirrors and on the tailgate, as well as
side).
views to the multimedia screen 5.
ultrasonic detectors 4 located in the ve-
They enable you to view the vehicle
The ultrasonic detectors detect obsta-
hicle bumpers, the feature assists with
surroundings:
cles at the front, rear and (depending
difficult manoeuvres (e.g. parking) by
- front view: using camera 1;
on the vehicle) side of the vehicle.
displaying the vehicle surroundings.
- rear view: using camera 3;
Note: make sure that the cameras are
- bird’s eye view: using cameras 1, 2
not obscured (by dirt, mud, snow etc.).
and 3;
This function is an additional aid. It cannot, therefore, under any circumstances replace the vigilance or the responsi-
bility of the driver.
The driver should always be ready for sudden incidents while driving: always ensure that there are no small, narrow
moving obstacles (such as a child, animal, pushchair, bicycle, stone, post, etc.) in the blind spot when manoeuvring.
2.59
CarManuals2.co
360° CAMERA (2/10)
5
6
7
A
B
1
Front view 1
The fixed clearance gauge comprises
coloured markers A and B indicating
The view of the front camera is dis-
the distance behind the vehicle:
played on the multimedia screen 5.
- B(yellow) approximately 70 centi-
Fixed clearance gauge 6
metres from the vehicle;
The driver should be aware about
the blind zone which exists approxi-
The “front” view transmitted to the mul-
- A(green) approximately 150 centi-
mately up to 40cm from the end of
timedia screen 5 is displayed with one
metres from the vehicle.
front bumper on “Front view” mode
or two guidelines 6 and 7.
of 360° camera. In order to avoid
Dynamic gauge 7 (depending on the
This system is initially used with the aid
any risk of accident, a driver should
vehicle)
of several gauges (mobile for trajectory
be cautious of visual and auditory
and fixed for distance).
This is shown in blue on the multime-
warning supported from the park-
dia screen 5. It indicates the vehicle tra-
ing assist system. Parking assist
jectory according to the position of the
system displays the distance is
steering wheel in the front view.
shown in the 360° view with colored
indicator lines for each sensor that
registers an obstacle.
2.60
CarManuals2.co
360° CAMERA (3/10)
5
6
7
3
A
B
C
Rear view 3
The fixed clearance gauge comprises
Dynamic gauge 7 (depending on the
coloured markers A, B and C indicating
vehicle)
The view of the rear camera is dis-
the distance behind the vehicle:
played on the multimedia screen 5.
This is shown in blue on the multime-
- C(red) approximately 30 centime-
dia screen 5. It indicates the vehicle tra-
Fixed clearance gauge 6
tres from the vehicle (rear view only);
jectory according to the position of the
steering wheel in the rear view.
The “rear” view transmitted to the multi-
- B(yellow) approximately 70 centi-
media screen 5 is displayed with one or
metres from the vehicle;
two guidelines 6 and 7.
- A(green) approximately 150 centi-
This system is initially used with the aid
metres from the vehicle.
of several gauges (mobile for trajectory
and fixed for distance).
The 5 multimedia screen shows a
reverse image of the rear view 3 as
in a rear view mirror.
2.61
CarManuals2.co
360° CAMERA (4/10)
In front view or rear view:
when manoeuvring on a
The front, rear and side view guide-
slope, objects shown on
lines are a representation projected
the multimedia screen may
onto flat ground; this information
be closer or further away than they
must not be taken into account
seem.
when superimposed on a vertical
Take this into account in order
object or an object on the ground.
to correctly assess the distance
Objects displayed on the edge of
before any manoeuvre.
the multimedia screen may appear
distorted.
In very bright light (snow, vehicle in
sunshine etc.), the camera vision
may be adversely affected.
In the combined represen-
tation from the cameras:
- raised objects (pavement,
vehicle, etc.) may appear
distorted in bird’s eye view;
- any objects on top of the vehicle
are not displayed.
2.62
CarManuals2.co
360° CAMERA (5/10)
9
8
9
2
Bird’s eye view
Front side view on passenger
The bird’s eye view is a combined rep-
side 2
resentation from cameras 1, 2 and 3.
(depending on the vehicle)
It displays a view of the top of the vehi-
The camera, fitted in the door mirror,
cle and its surroundings.
transmits a side view to the multimedia
screen 5.
This can be used to confirm a view of
the vehicle position in relation to its im-
Depending on the vehicle, you can use
mediate surroundings (front, rear and
the multimedia screen to change the
side).
bird’s eye view to the front side view.
In “bird’s eye view” mode, the ob-
Please refer to the multimedia instruc-
The 8 view indicates the vehicle posi-
jects displayed on the multimedia
tions for further information.
tion. 9 areas not covered by the cam-
screen are actually further away
eras are indicated in black.
than they seem.
Take this into account in order
to correctly assess the distance
before any manoeuvre.
2.63
CarManuals2.co
|
||
|
|
|
