Renault Kadjar (2018 year). Manual

1.2

1  Locks all the opening elements.
2  Unlocks all the opening elements.
3  Ignition and front door key.
4  Locking/unlocking the tailgate only.
Remote control with switchblade

key:

5 Locking/unlocking using the switch-

blade key. To release the insert from

its housing, press button 5, it comes

out automatically. Press button 5 and

guide the insert back into its housing.

KEY, RADIO FREQUENCY REMOTE CONTROL: general information

(1/2)

The key must not be used for any

function other than those described

in the handbook (removing the cap

from a bottle, etc.).

Advice
Avoid leaving the remote control in

hot, cold or humid areas.

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

1.3

KEY, RADIO FREQUENCY REMOTE CONTROL: general information

(2/2)

Radio frequency remote

control operating range

This varies according to the surround-

ings: take care not to lock or unlock the

doors by inadvertently pressing the but-

tons on the remote control.
Note: If a door or the boot is open or

not closed properly, the doors and boot

lock/unlock in quick succession.

Interference

Interference by factors in the immediate

vicinity (external installations or the use

of equipment operating on the same

frequency as the remote control) may

affect the operation of the remote con-

trol.

Replacement and additional keys

or remote controls.
You must only contact an approved

dealer:
– If you need to replace a key it will

be necessary to take the vehicle

and all of its keys to an approved

Dealer in order to initialise the

system.

– Depending on the vehicle, you

have the option of using up to

four remote controls.

Remote control unit failure
Make sure that the correct battery

type is being used, and that the

battery is in good condition and in-

serted correctly. These batteries

have a service life of approximately

two years.
Refer to Section 5: “Radio fre-

quency remote control: batteries”

for the battery changing procedure.

1.4

Locking/unlocking only the

boot

Press the button 3.

RADIO FREQUENCY REMOTE CONTROL UNIT: use

The remote control A can be used to

lock or unlock the doors and boot.

It is powered by a battery which must

be replaced (refer to the information on

“Radio frequency remote control: bat-

teries” in Section 5).

Locking the doors

Press locking button 1.

The side indicator lights and hazard

warning lights flash twice to indicate

that the doors have been locked.

If a door or the boot is open or not prop-

erly shut, they will lock and unlock in

quick succession and the hazard warn-

ing lights and indicator lights will not

flash.

Unlocking the doors

Pressing button 2 unlocks the doors

and tailgate.
The side indicator lights and hazard

warning lights flash once to indicate

that the doors have been unlocked.

Note:

With the engine running, the ignition

switched on and in accessories position

(refer to “Ignition switch: vehicles with a

key” in Section 2), the remote control

buttons will be inactive.

Driver’s responsibility when parking or stopping the vehicle

Never leave an animal, child or adult who is not self-sufficient alone on

your vehicle, even for a short time.

They may pose a risk to themselves or to others by starting the engine,

activating equipment such as the electric windows or locking the doors.

Also, in hot and/or sunny weather, please remember that the temperature inside

the passenger compartment increases very quickly.

RISK OF DEATH OR SERIOUS INJURY.

1.5

RADIO FREQUENCY REMOTE CONTROL UNIT: deadlocking

Never use deadlocking if

someone is still inside the

vehicle.

If the vehicle is equipped with a dead-

locking function, this allows you to lock

the opening elements and to prevent

the doors from being unlocked using

the interior handles (for example, by

breaking the window and then trying to

open the door from the inside).

To activate deadlocking

Press button 1 twice in quick succes-

sion.
The hazard warning lights and indicator

lights give two slow flashes and three

quick flashes to indicate locking.
Special note: deadlocking is not pos-

sible if the hazard warning lights or the

side lights are lit.

To deactivate deadlocking

Unlock the vehicle using button 2.
The hazard warning lights flash once

to indicate that the doors have been un-

locked.

1.6

RENAULT CARD: general information

(1/2)

The RENAULT card is used

for:

– locking/unlocking the doors and boot

(see the following pages);

– switching on the vehicle lighting re-

motely (refer to the following pages);

– starting the engine; refer to the in-

formation on “Starting the engine” in

Section 2.

Battery life

Make sure that the correct battery type

is being used, and that the battery is in

good condition and inserted correctly.

Its service life is approximately two

years: replace it when the message

“Keycard battery low” appears on the

instrument panel (refer to the informa-

tion on the “RENAULT card: battery” in

section 5).

RENAULT card operating

range

This varies according to the surround-

ings. It is important to make sure when

handling the RENAULT card that you

do not lock or unlock the doors by inad-

vertently pressing the buttons.

When the battery is flat, you can

still lock/unlock and start your vehi-

cle. Please see the information on

“Locking and unlocking the doors”

in Chapter 1 and “Starting, stopping

the engine” in Chapter 2.

1  Unlocking the doors and tailgate.
2  Locking all doors and tailgate.
3  Unlocking/locking the boot.
4  Switching on the lighting remotely.

1.7

RENAULT CARD: general information

(2/2)

Advice
Avoid leaving the card in hot, cold or

humid areas.
Do not keep the RENAULT card in

a place where it could be bent or

damaged accidentally, such as in a

back pocket of a garment.

Replacement: need for an

additional RENAULT Card
If you lose your RENAULT card or

require another, you can obtain one

from an approved dealer.
If a RENAULT card is replaced, it

will be necessary to take the vehi-

cle and all of its RENAULT cards

to an approved dealer to initialise

the system.
You may use up to four RENAULT

cards per vehicle.

Distance lighting function

Pressing button 4 switches on the

dipped beam headlights and the interior

lighting for approximately 20 seconds.

This can be used, for example, to iden-

tify the vehicle from a distance when

parked in a car park.

Note: Pressing button 4 again switches

off the lighting.

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

1.8

RENAULT "HANDS-FREE" CARD: use

(1/4)

Do not store the RENAULT card

anywhere it may come into con-

tact with other electronic equipment

(computer, phone, etc.) as this could

hinder its operation.

There are two ways to unlock/lock the

vehicle:

– the RENAULT card in “Hands-free”

mode;

– the RENAULT card in remote con-

trol mode.

Using the card in hands-free

mode

In “hands-free” mode, it is possible to

lock/unlock the vehicle without using

any of the RENAULT card’s buttons,

as long as the card is within the access

zone 1.
Note: It is possible to deactivate the

hands-free system – please refer to

the information on the “Vehicle settings

customisation menu” in Section 1.

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

1.9

RENAULT "HANDS-FREE" CARD: use

(2/4)

To indicate that the vehicle has been

locked, the hazard warning lights and

indicator lights flash once and then

light up for approximately four sec-

onds, and a beep sounds in confirma-

tion.

Locking using button 2

With the doors and boot closed, press

button 2 on one of the front door han-

dles. The vehicle will lock. The indicator

lights and hazard warning lights flash

twice to indicate that the doors have

locked.

Special features of the locking

system

After locking by pressing button 2, you

have to wait approximately 3 seconds

to be able to unlock the vehicle again.

During these three seconds, the door

handles can be tried to make sure that

the vehicle is locked properly. If a door

is open or not properly closed:

– when locking by pressing the 2

button, the vehicle is locked then

quickly unlocked without the hazard

warning lights and side indicator

lights flashing;

– the vehicle will not lock as you move

away.

“Hands-free” unlocking
With the RENAULT card in zone 1,

press button 2 on the handle of one of

the front doors: the vehicle unlocks.

Unlocking is indicated by one flash of

the hazard warning lights and the indi-

cator lights.
Pressing the button 3 unlocks the entire

vehicle and releases the boot.

The “hands-free” system may experi-

ence temporary difficulties if one of the

sensors built into the inside of the door

handle is obscured (by dirt, mud, snow,

gritting salt etc.).

Clean the sensors. If there is still a

problem, contact an approved dealer.

Remote “Hands-free” locking

(depending on vehicle)
With the RENAULT card on you, and

doors and boot closed, move away

from the vehicle: it will lock automati-

cally as soon as you leave the access

zone.
Note: The distance at which the vehicle

locks depends on the surroundings.

1.10

RENAULT "HANDS-FREE" CARD: use

(3/4)

Using the card as a remote

control

Unlocking with the card RENAULT

Press button 5.

Unlocking is indicated by one flash of

the hazard warning lights and the indi-

cator lights.

Locking using the RENAULT card

With the doors and boot closed, press

button 6: the vehicle locks.

The indicator lights and hazard warning

lights flash twice to indicate that the

doors have locked.
NB: The maximum distance at which

the vehicle locks depends on the sur-

roundings.

Special features

If an opening element (a door or the

luggage compartment) is open or not

properly closed, the vehicle cannot be

locked. The vehicle will lock/unlock in

quick succession, but the hazard warn-

ing lights and the side indicator lights

will not flash.

The card buttons are deactivated

when the engine is running.

Particular features of the locking

system (continued)
If provided with the vehicle, if the

RENAULT card has been in the detec-

tion zone for about 15 minutes, remote

locking is disabled.
The vehicle cannot be locked if the card

is within the zone 4.
If the vehicle is unlocked by pressing

the button on the RENAULT card, but

the doors or boot are not then opened;

remote “hands-free” locking is disabled.

1.11

Locking/unlocking only the

boot

Press the button 7 to lock/unlock the

boot only.

RENAULT "HANDS-FREE" CARD: use

(4/4)

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

If, while the engine is running, a door

is opened and closed, and the card is

no longer in the zone 4, the message

“Keycard not detected” indicates that the

card is not inside the vehicle. This will,

for example, prevent you from driving

away after dropping off a passenger

who has kept the card on them.
The warning disappears when the card

is detected again.

1.12

Never use deadlocking if

someone is still inside the

vehicle.

To activate deadlocking

Press button 2 twice in quick succes-

sion.
With the vehicle unlocked, you can also

press the button 3 on the driver’s door,

passenger’s door or the boot twice in

quick succession (or, depending on the

vehicle, on the tailgate of the rear door).
In both cases, the indicator lights and

hazard warning lights flash five times

to indicate that the doors have locked.

If the vehicle is equipped with a dead-

locking function, this allows you to lock

the opening elements and to prevent

the doors from being unlocked using

the interior handles (for example, by

breaking the window and then trying to

open the door from the inside).

RENAULT CARD: deadlocking

Special feature
The deadlocking cannot be activated

when the hazard warning lights or the

side lights are lit.

To deactivate deadlocking

Unlock the vehicle using button 1 on

the RENAULT card.
Unlocking is indicated by one flash of

the hazard warning lights and the indi-

cator lights.

1.13

LOCKING, UNLOCKING THE DOORS

(1/3)

If the remote control or,

depending on the vehicle, the

RENAULT card does not work

In some cases, the radio frequency

remote control or the RENAULT card

may not work:
– RENAULT card/radio frequency

remote control battery worn or run

flat, vehicle battery flat, etc.

– use of appliances operating on the

same frequency as the card (mobile

phone, etc.);

– vehicle located in a high electromag-

netic radiation zone.

Never leave your vehicle

with the key or RENAULT

card inside.

It is then possible:
– depending on the vehicle, use the

radio frequency remote control or

the emergency key integrated in the

card to unlock the front left-hand

door;

– to lock each of the doors manually;
– to use the interior door locking/un-

locking control (refer to the following

pages).

Vehicles with key/remote

control

Using the key
Insert the key 2 into the lock 1 and lock

or unlock the front left-hand door.

1.14

LOCKING, UNLOCKING THE DOORS

(2/3)

Using the integrated key
Insert the key 4 into the lock 1 and lock

or unlock the front left-hand door.
Once you are inside the vehicle, put the

key back in its casing in the RENAULT

card.

Vehicles with RENAULT card

Access key 4 integrated in the card
Slide the rear casing 3 downwards

while pressing on zone A.

1.15

LOCKING, UNLOCKING THE DOORS

(3/3)

Interior locking/unlocking

door control

The switch 5 located on the driver and

passenger doors simultaneously con-

trols the doors and the boot.
Unlocking: press the switch 5 on the

side

‡

Locking: press the switch 5 on the side

…

If a door or the tailgate is open or not

closed properly, the doors and tailgate

lock/unlock quickly.

If transporting an object with the tail-

gate open, you can still lock the doors:

with the engine stopped, press and

hold the switch 5 on the side

…

for

more than five seconds to lock the

other doors.

Locking the opening

elements without the

RENAULT card or the key

For example, in the event of a dis-

charged battery or the RENAULT card

or key temporarily not working, etc.
With the engine switched off and

an opening element (door or boot)

open, press and hold the switch 5 on

side

…

for more than 5 seconds.

When the door is closed, all the doors

and the tailgate will be locked.

Unlocking the vehicle from the outside

is only possible with the RENAULT card

in the vehicle’s access zone or using

the key.

Door and tailgate status

indicator

With the ignition on, the warning

light 6 informs you of the locking status

of the opening elements:

– indicator light on, the doors and tail-

gate are locked;

– indicator light off, the doors and tail-

gate are unlocked.

When you lock the doors from the out-

side, the indicator light remains lit for a

moment, and then goes out.

Driver’s responsibility
If you decide to keep the

doors locked when you are

driving, remember that it

may be more difficult for those as-

sisting you to gain access to the

passenger compartment in the

event of an emergency.

1.16

Opening from the inside

Pull the handle 3.

Lights-on reminder buzzer

If you have switched off the ignition

and left the lights switched on, a re-

minder buzzer will sound when a door

is opened and if the light stalk is not in

position AUTO.

Opening the doors from the

outside

With the doors unlocked, pull handle 1.

Special feature on vehicles

equipped with a RENAULT card
With the doors locked, press button 2

on handle 1 of one of the two front

doors and pull towards you.

OPENING AND CLOSING THE DOORS

(1/2)

As a safety precaution,

the doors should only be

opened or closed when the

vehicle is stationary.

Door/tailgate open buzzer

At a standstill, the warning light 4 lights

up on the instrument panel alongside

the warning light 5

indicating the

opening elements (door, boot) are open

or incorrectly closed.
Once the vehicle reaches a speed of

approximately 12 mph (20 km/h), a

warning light indicates the opening

element(s) (door, boot) open of im-

properly closed, alongside the mes-

sage “Boot open” or “Door open” and a

beep will sound for around 40 seconds

or until the opening element is closed.

1.17

Vehicle with manual door locking
To make it impossible for the rear doors

to be opened from the inside, move

lever 6 on each door and check from

the inside that the doors are securely

locked.

OPENING AND CLOSING THE DOORS

(2/2)

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

Renault Kadjar (2018 year). Manual - part 1
