Peugeot Traveller (2016 year). Manual - part 37

122

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Media

USB port

Selecting the source

Press the "SOURCES" button.

Press Radio Media to display the
primary page.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
The playlists are updated every time the
ignition is switched off or connection of a USB
memory stick. The lists are memorised: if they
are not modified, the subsequent loading time
will be shorter.

Insert the USB memory stick in the USB port or
connect the USB device to the USB port using
a suitable cable (not supplied).

Auxiliary socket (AUX)

First adjust the volume of your portable device
(to a high level). Then adjust the volume of your
audio system.
Display and management of the controls are
via the portable device.

This source is only available if "Auxiliary input"
has been checked in the audio settings.

Connect the portable device (MP3 player…) to
the auxiliary Jack socket using an audio cable
(not supplied).

Choose the source.

Bluetooth Streaming

Streaming allows you to listen to music from
your telephone.
The Bluetooth profile must be activated. First
adjust the volume on your portable device (to a
high level).
Then adjust the volume of your system.

If play does not start automatically, it may be
necessary to start the audio playback from the
smartphone.
Control is from the portable device or by using
the system's touch buttons.

Once connected in Streaming mode,
the smartphone is considered to be a
media source.

To protect the system, do not use a
USB hub.

123

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Connecting Apple

players

Connect the Apple

player to the USB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

The classifications available are those
of the portable device connected
(artists / albums / genres / playlists /
audiobooks / podcasts), you can also
use a classification structured in the
form of a library.
The default classification used is by
artist. To modify the classification used,
return to the first level of the menu
then select the desired classification
(playlists for example) and confirm
to go down through the menu to the
desired track.

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

The audio equipment will only play audio
files with ".wav, .wma, .aac, .ogg and .mp3"
file extensions and with a bit rate of between
32 Kbps and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other type of file (.mp4, ...) can be played.
".wma" files must be of the standard wma 9 type.
The sampling rates supported are 11, 22, 44
and 48 KHz.

It is advisable to restrict file names to
20 characters, without using of special
characters (e.g.: " " ? ; ù) to avoid any playing
and displaying problems.

In order to be able to play a burned CDR or
CDRW, select standards ISO 9660 level 1, 2 or
Joliet if possible when burning the CD.
If the disc is burned in another format, it may
not be played correctly.
It is recommended that the same burning
standard is always used on an individual disc,
with the lowest speed possible (4x maximum)
for the best acoustic quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

Information and advice

Use only USB memory sticks formatted FAT32
(file allocation table).

The system supports USB Mass
Storage devices, BlackBerry

devices

or Apple

players via USB ports. The

adaptor cable is not supplied.
Control of the peripheral device is with
the audio system controls.
Other peripherals, not recognised on
connection, must be connected to the
auxiliary socket using a Jack cable (not
supplied) or via Bluetooth streaming,
depending on compatibility.

It is recommended that the original USB
cable for the portable device is used.

To protect the system, do not use a
USB hub.

124

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Telephone

According to version

Level 1

Level 2

Level 3

125

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

Comments

Telephone

Bluetooth

search

PHONE

Bluetooth connection

Search

Start the search for a device to be connected.

Delete

Delete one or more devices.

MirrorLink

Open the MirrorLink function.

CarPlay

Open the CarPlay function.

Telephone

Bluetooth

search

Keypad

Enter a telephone number.

Telephone

Bluetooth

search

Recent calls

All

View the calls according to the presentation
selected.
Select a contact to make the call.

Outgoing

Missed

Incoming

Telephone

Bluetooth

search

Contacts

Search

Confirm

Search for a contact in the contacts directory.

Telephone

Go to the details of the contact sheet.

126

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

127

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Comments

Telephone

OPTIONS

On hold (auto)

ON - OFF

Activate or deactivate the automatic placing on
hold of the current conversation.

Telephone

OPTIONS

Sort contacts by name

Sort contacts by first

name

Sort the contacts by Surname-first name or First
name-surname.

Telephone

OPTIONS

Ring volume

Adjust the volume of the ringtone.

128

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

MirrorLink

smartphone connection

129

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

As a safety measure and because it
requires the sustained attention of
the driver, using a smartphone when
driving is prohibited.
Operation must be with the vehicle
stationary

The synchronisation of a
smartphone allows applications on a
smartphone that are adapted to the
MirrorLink

technology to be displayed

in the vehicle's screen.
The principles and standards
are constantly evolving. For the
communication process between
the smartphone and the system to
work correctly, the smartphone must
be unlocked; update the operating
system of your smartphone as
well as the date and time in the
smartphone and the system

For the list of eligible smartphones,
connect to the Brand's internet website
in your country.

The "MirrorLink

" function requires

a compatible smartphone and
applications.

There may be a wait for the availability
of applications, depending on the
quality of your network.

When connecting a smartphone to
the system, it is recommended that
"Bluetooth

" be started on the smartphone

Depending on the smartphone, it may be
necessary to activate the "MirrorLink

" function.

During the procedure, several screen
pages relating to certain functions
are displayed.
Accept to start and end the
connection.

Connect the USB cable. The
smartphone charges when
connected by a USB cable.

Press "MirrorLink

" to start the

application in the system.

Once connection is established, a page
is displayed with the applications already
downloaded to your smartphone and adapted
to the MirrorLink

technology.

Access to the different audio sources remains
accessible in the margin of the MirrorLink

display, using touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons

Telephone not connected by
Bluetooth

Telephone connected by Bluetooth

From the system, press "Telephone"
to display the primary page.

As a safety measure, applications
can only be viewed with the vehicle
stationary; display is interrupted once
the vehicle is moving.

Press the "PHONE" button to display
the secondary page.

Press "MirrorLink

" to start the

application in the system.

130

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

131

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

Comments

Telephone

MirrorLink

Go to or return to the applications already
downloaded to your smartphone and adapted to
the MirrorLink

technology.

Go to a menu list depending on the application
chosen.
"Back": abandon the current operation, go up one
level.
"Home": go to or return to the "Car mode" page on
your smartphone.

Go to the primary page of the "Telephone" menu.

132

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

CarPlay

smartphone connection

133

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

As a safety measure and because it
requires the sustained attention of
the driver, using a smartphone when
driving is prohibited.
Operation must be with the vehicle
stationary

The synchronisation of a smartphone
allows applications on a smartphone that
are adapted to the CarPlay

technology

to be displayed in the vehicle's screen,
having first activated the CarPlay

function in the smartphone.
As the principles and standards are
constantly changing, it is recommended
that you keep your smartphone's
operating system updated

For the list of eligible smartphones, go
to the Brand's internet website in your
country.

Connect the USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press Telephone
to display the CarPlay

interface.

Press "CarPlay" to display the
CarPlay

interface.

On connecting the USB cable, the
CarPlay

function deactivates the

system's Bluetooth

mode.

From the system, press Telephone
to display the primary page.

Press the "PHONE" button to go to
the secondary page.

If the smartphone is already
connected by Bluetooth

You can go to the CarPlay

navigation at any time by pressing
the system's Navigation button.

134

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Pairing a Bluetooth

telephone

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-
free system of your audio system must
be done with the vehicle stationary
and the ignition on.

Procedure from the telephone

Select the name of the system in the
list of devices detected.

In the system, accept the connection request
from the telephone.

Procedure from the system

Press Telephone to display the
primary page.

Press "Bluetooth search".
The list of telephones detected is
displayed.

If the pairing procedure fails, it is recommended
that you deactivate and then reactivate the
Bluetooth function in your telephone.

Depending on the type of telephone,
you may be asked to accept or not
the transfer of your contacts and
messages.

Select the name of the chosen
telephone in the list.

Activate the Bluetooth function on the
telephone and ensure that it is "visible
to all" (telephone configuration).

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.

135

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Press Telephone to display the
primary page.

Press "Bluetooth connection" to
display the list of paired devices.

On return to the vehicle, if the last
telephone connected is present again,
it is automatically recognised and
within about 30 seconds of switching
on the ignition, the connection is
established without any action on your
part (Bluetooth activated).

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used. Check in your telephone's
manual and with your service provider
for the services available to you.

The ability of the system to connect

with just one profile depends on the

telephone.

All three profiles may connect by

default.

Go to the Brand's website for more information
(compatibility, additional help, ...).

To modify the connection profile:

Automatic reconnection

Press the "details" button of a paired
device.

Press the "PHONE" button to go to
the secondary page.

Press "OK" to confirm.

Select one or more profiles.

The profiles compatible with the system
are HFP, OPP, PBAP, A2DP, AVRCP,
MAP and PAN.

The system offers to connect the telephone
with 3 profiles:
- "Telephone" (hands-free kit, telephone

only),

- "Streaming" (wireless playing of the audio

files on the telephone),

- "Internet data".

136

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Make a short press on the steering
mounted PHONE button to accept an
incoming call.

Make a long press

on the steering mounted PHONE
button to reject the call.

And

Press "End call".

Press on the name of the telephone
chosen in the list to disconnect it.
Press again to connect it.

Press the basket at the top right
of the screen to display a basket
alongside the telephone chosen.
Press the basket alongside the
telephone chosen to delete it.

Managing paired telephones

This function allows the connection or
disconnection of a peripheral device as
well as the deletion of a pairing.

Press Telephone to display the
primary page.

Press the "PHONE" button to go to
the secondary page.

Press "Bluetooth connection" to
display the list of paired peripheral
devices.

Deleting a telephone

Using the telephone is not
recommended while driving.
Park the vehicle.
Make the call using the steering
mounted controls.

Making a call

Calling a new number

Press Telephone to display the
primary page.

Enter the phone number using the
digital keypad.

Press "Call" to start the call.

137

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

on the steering mounted button.

Calling a contact

Setting the ringtone

Press Telephone to display the
primary page.

Or make a long press

on the steering mounted PHONE
button.

Press "Contacts".

Select the desired contact from the list offered.

Press "Call".

Calling a recently used number

Press Telephone to display the
primary page.

Make a long press

Press "Recent calls".

Select the desired contact from the list offered.

It is always possible to make a call
directly from the telephone; as a safety
measure, first park the vehicle.

Press Telephone to display the
primary page.

Press "Ring volume" to display the
volume bar.

Press the arrows or move the cursor
to set the ring volume.

Press the "OPTIONS" button to go to
the secondary page.

Content .. 35 36 37 38 ..
