Peugeot Traveller (2016 year). Manual

107

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

Comments

Applications

Trip computer

Instant

System providing information about the current
journey (range, consumption…).

Trip 1

Trip 2

Go to the Applications page.

Applications

Photos

Photo gallery

Photos

Go to the photo gallery.

Go back a level.

Applications

OPTIONS

Bluetooth connection

Search

Start the search for a device to be connected.

Delete

Delete one or more devices.

108

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

According to equipment

109

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

Comments

Applications

i-Cockpit Amplify

Relax

Boost

i-Cockpit Amplify

Relax

Boost

Settings

Fragrance

Select a fragrance.

Lighting

Adjust the intensity of the ambience lighting.

Ambience

Adjust the sound ambience.

Driver massage

Select and configure the driver massage.

Passenger Massage

Select and configure the passenger massage.

Dynamic

Set the driving mode.

Save settings

Save the settings.

Reset the mode

Reset the ambience parameters.

Confirm the selections and settings.

Deactivate

Deactivate the "i-Cockpit Amplify function.

Profile management

Profile 1

Configure the profiles.

Profile 2

Profile 3

Common profile

Save the settings.

Confirm the selections and settings.

111

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Insert a USB memory stick in the USB port.

The system can read folders and image files in
the formats: .tiff; .gif; .jpg/jpeg; .bmp; .png.

Viewing photos

Press Applications to display the
primary page.

Press "Photos".

Select a folder.

Press this button to display the
details of the photo.

Press the back arrow to go back a
level.

Select an image to view.

To protect the system, do not use a
USB hub.

112

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Radio Media

According to version

Level 1

Level 2

113

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Comments

Radio Media

SOURCES

Radio

Select change of source.

Bluetooth

AUX

USB

iPod

Radio Media

Frequency

FM / DAB / AM

Display the current radio station.

Radio Media

List

Update the list according to the stations received.

Preset

Make a short press to preset the station.

Radio Media

Preset

Select a preset station or preset a station.

Radio Media

OPTIONS

AM band / DAB band / FM band

Press the Band button to change waveband.

Audio settings

Configure the audio settings.

News

Activate or deactivate the options.

RDS

FM-DAB Follow-up

Radio Media

87.5 MHz

Enter a frequency of the FM and AM bands on the
virtual keypad.

114

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

115

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

Comments

Radio Media

SOURCES

Radio

Frequency

Display the current radio station.

List

Display the list of stations received.

Preset

Select a preset station or preset a station.

OPTIONS

FM band / DAB band /
AM band

Press the band button to change band.

Audio settings

Configure the audio settings.

News

Activate or deactivate the options.

RDS

FM-DAB Follow-up

Radio Media

SOURCES

Bluetooth

OPTIONS

Audio settings

Configure the audio settings.

Radio Media

SOURCES

Display the details of the music being played.

OPTIONS

Audio settings

Configure the audio settings.

116

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

117

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Level 1

Level 2

Level 3

Comments

Radio Media

SOURCES

AUX

OPTIONS

Audio settings

Configure the audio settings.

Radio Media

SOURCES

USB

Player

Display the details of the music being played.

Tracks list

Display the current selection.

Library

Display the music library.

OPTIONS

Audio settings

Configure the audio settings.

118

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Press Radio Media to display the
menu.

Press Radio Media to display the
primary page.

Press the frequency.

Enter the FM and AM waveband
values using the virtual keypad.

Press one of the buttons for an
automatic search for radio stations.

Radio

Selecting a station

Radio reception may be affected by
the use of electrical equipment not
approved by the Brand, such as a USB
charger connected to the 12V socket.
The exterior environment (hills,
buildings, tunnel, car park, below
ground...) may prevent reception,
even in RDS station tracking mode.
This phenomenon is normal in the
propagation of radio waves and is in no
way indicative of a fault with the audio
system.

Move the cursor for a manual search
for frequencies up or down.

Select a radio station or frequency.

Press "Preset".

Press the "OPTIONS" button to go to
the secondary page.

Make a short press on the star
outline. If the star is solid, the radio
station is already preset.

Make a long press on one of the
buttons to preset the station.

Press "Band" to change waveband.

Press in the grey zone to confirm.

Preset a station

Changing waveband

Press "OK" to confirm.

119

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Press in the grey zone to confirm.

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to
the secondary page.

Activate/deactivate "RDS".

Activate / Deactivate "News".

Activate / Deactivate "TA".

Activate/ Deactivate RDS

RDS, if activated, allows you to continue
listening to the same station by automatic
retuning to alternative frequencies.
However, in certain conditions, coverage
of an RDS station may not be assured
throughout the entire country as radio
stations do not cover 100 % of the
territory. This explains the loss of
reception of the station during a journey.

The "Radio Text" function allows
information transmitted by the radio
station and related to the station or the
song playing to be displayed.

Display text information

Play TA messages

The TA (Traffic Announcement)
function gives priority to TAalert
messages. To operate, this function
needs good reception of a radio station
that carries this type of message. While
traffic information is being broadcast,
the current media is automatically
interrupted so that the TA message can
be heard. Normal play of the media
previously playing is resumed at the
end of the message.

120

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

Audio settings

Press Radio Media to display the
primary page.

Press "Audio settings".

On-board audio: Arkamys

Sound

Staging optimises the distribution of
sound in the passenger compartment.

The sound distribution (or spatialisation
with the Arkamys

system) is audio

processing that allows the quality of the
sound to be adapted according to the
number of passengers in the vehicle.

On the "Tone" tab, the Ambience audio
settings and Bass, Medium and Treble
are different and independent for each
audio source.

On the "Balance" tab, the All
passengers

, Driver and Front only

settings are common to all sources.

On the "Sound" tab, activate or
deactivate "Volume linked to speed",
"Auxiliary input" and "Touch tones".

Press the "OPTIONS" button to go to
the secondary page.

Select the "Tone" or "Balance"
or "Sound" or "Ringtones" tab to
configure the audio settings.

Press the back arrow to confirm.

121

Audio and Telematics

Transversal-Peugeot_en_Chap02_RCC-2-2-0_ed01-2016

DAB radio (Digital Audio Broadcasting)

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to
the secondary page.

FM-DAB Follow-up

Terrestrial Digital Radio

"DAB" does not cover 100% of the
territory.
When the digital radio signal is poor,
the "FM-DAB Follow-up" allows you to
continue listening to the same station,
by automatically switching to the
corresponding "FM" analogue station
(if there is one).

If the "FM-DAB Follow-up" is activated,
there is a difference of a few seconds
when the system switches to "FM"
analogue radio with sometimes a
variation in volume.
Once the digital signal is restored, the
system automatically changes back to
"DAB".

Digital radio provides higher quality
reception.
The different multiplexes offer a
choice of radio stations arranged in
alphabetical order.

If the "DAB" station being listened
to is not available on "FM", or if the
"FM-DAB Follow-up" is not activated,
the sound will cut out while the digital
signal is too weak.

Activate / Deactivate "FM-DAB
Follow-up

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to
the secondary page.

Press "Band" to select "DAB band".

Press in the grey zone to confirm.
