Peugeot 5008 (2017 year). Manual - part 25

Bluetooth

audio system

Then select and confirm:
- "Connect telephone" /

"Disconnect telephone":

to connect / disconnect the

telephone or the hands-free kit
only.

- "Connect media player" /

"Disconnect media player":

to connect / disconnect streaming

only.

- "Connect telephone +

media player" / "Disconnect
telephone + media player":

to connect / disconnect the

telephone (hands-free kit and
streaming).

- "Delete connection": to delete

the pairing.

When you delete a pairing in the system,
remember to delete it from your telephone
as well.

Confirm with OK.

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Select the "YES" tab in the screen
using the buttons.

Confirm with OK.

Press this button at the steering
mounted controls to accept the call.

Making a call

In the "Telephone" menu.

Select "Call".

Select "Dial".

Select "Directory".

Select "Calls list".

Confirm with OK.

Press this button for more than
two seconds for access to your
directory, then navigate using the
thumb wheel.

Ending a call

In the "Telephone" menu.

Select "End call".

Confirm with OK to end the call.

During a call, press one of the
buttons for more than two seconds.

The system accesses the telephone's
contacts directory, depending on its
compatibility, and while it is connected via
Bluetooth.

With certain telephones connected by
Bluetooth you can send a contact to the
directory of the audio system.
Contacts imported in this way are saved
in a permanent directory visible to all,
whatever the telephone connected.
The menu for the directory is not
accessible if it is empty.

Managing calls

During a call, press OK to display
the contextual menu.

Bluetooth

audio system

End call

In the contextual menu, select
"Hang up" to end the call.

Confirm with OK.

Microphone off

(so that the caller cannot hear)

In the contextual menu:
-

select "Micro OFF" to switch off
the microphone.

deselect "Micro OFF" to switch
the microphone on.

Confirm with OK.

Telephone mode

In the contextual menu:
-

select "Telephone mode" to
transfer the call to the telephone
(for example, to leave the
vehicle while continuing a
conversation).

deselect "Telephone mode" to
transfer the call to the vehicle.

Confirm with OK.

If the contact has been cut off, when you
reconnect on returning to the vehicle,
the Bluetooth connection will be restored
automatically and sound returned to the
system (depending on the compatibility of the
telephone).
In some cases, the combined mode must be
activated from the telephone.

Interactive voice response

From the contextual menu, select
"DTMF tones" and confirm to use
the digital keypad to navigate in the
interactive voice response menu.

Confirm with OK.

Consultation call

From the contextual menu, select
"Switch" and validate to return to a
call left on hold.

Confirm with OK.

Directory

To access the directory, press and
hold SRC/TEL.

Select "Directory" to see the list of
contacts.

Confirm with OK.

To modify the contacts saved in the
system, press MENU then select
"Telephone" and confirm.
Select "Directory management"
and confirm.
You can:
- "Consult an entry",
- "Delete an entry",
- "Delete all entries".

The system accesses the
telephone's contacts directory,
depending on its compatibility, and
while it is connected via Bluetooth.

Bluetooth

audio system

With certain telephones connected
by Bluetooth you can send a contact
to the directory of the audio system.
Contacts imported in this way are
saved in a permanent directory
visible to all, whatever the telephone
connected.
The menu for the directory is not
accessible if it is empty.

Voice recognition

This function allows you to use your
smartphone's voice recognition via the system.

To start voice recognition, depending on the
type of steering mounted controls:

Make a long press on the end of the lighting
control stalk.

Press this button.

Voice recognition requires the use of a
compatible smartphone first connected to
the vehicle by Bluetooth.

Bluetooth

audio system

QUESTION

RESPONSE

SOLUTION

With the engine off, the audio system switches
off after a few minutes of use.

When the engine is switched off, the audio
system operating time depends on the state of
charge of the battery.
The switch-off is normal: the audio system
switches to economy mode and switches off to
prevent discharging the vehicle's battery.

Turn the ignition on to increase the charge of
the battery.

The message "the audio system is overheated"
appears on the display.

In order to protect the installation if the
surrounding temperature is too high, the audio
system switches to an automatic thermal
protection mode leading to a reduction in
volume or the CD play stopping.

Switch the audio system off for a few minutes to
allow the system to cool.

Frequently asked questions

The following information groups together the answers to the most frequently asked questions concerning your audio system.

Bluetooth

audio system

Radio

QUESTION

RESPONSE

SOLUTION

There is a difference in sound quality
between the different audio sources
(radio, CD, etc.).

To allow for optimal listening quality, the audio
settings (Volume, Bass, treble, Ambience,
Loudness) can be tailored to different sound
sources, which can generate audible differences
when changing source (radio, CD, etc.).

Check that the audio settings (Volume, Bass,
Treble, Ambience and Loudness) are adapted to
the sources listened to. It is advisable to set the
audio functions (Bass, Treble, Front-Rear Balance
and Left-Right Balance) to the middle position,
select the musical ambience "None" and set the
loudness correction to the "Active" position in CD
mode or to the "Inactive" position in radio mode.

The preset stations do not function (no
sound, 87.5 MHz is displayed, etc.).

An incorrect waveband is selected.

Press the BAND button to return to the waveband
(FM, FM2, DAB, AM) on which the stations are
preset.

The traffic announcement (TA) is displayed.
I do not receive any traffic information.

The radio station is not part of the regional traffic
information network.

Tune to a radio station which broadcasts traffic
information.

The reception quality of the tuned radio
station gradually deteriorates or the
stored stations are not working (no sound,
87.5 MHz is displayed , etc.).

The vehicle is too far from the transmitter of
the station or no transmitter is present in the
geographical area.

Activate the RDS function to allow the system to
see if a more powerful transmitter is within the
geographic area.

The environment (hills, buildings, tunnels,
basement car parks, etc.) block reception, including
in RDS mode.

This phenomenon is normal and does not indicate
a failure of the audio equipment.

The aerial is absent or has been damaged (for
example when going through an automatic car
wash or in an underground car park).

Have the aerial checked by a franchised dealer.

Sound cut-outs of 1 to 2 seconds in radio
mode.

During this brief sound cut-out, the RDS searches
for another frequency giving better reception of the
station.

Switch off the RDS function if the phenomenon is
too frequent and always on the same route.

Bluetooth

audio system

Media

QUESTION

RESPONSE

SOLUTION

The Bluetooth connection is cut.

The battery of the peripheral may not be
sufficiently charged.

Charge the battery of the peripheral device.

The message "USB device error" is displayed in
the screen.

The USB memory stick is not recognised.
The USB memory stick may be corrupt.

Reformat the USB memory stick.

The CD is ejected every time or is not played.

The CD is upside down, cannot be read, does
not contain audio files or contains audio files of
a format not recognised by the audio system.
The CD is protected by an anti-pirating system
not recognised by the audio system.

- Check that the CD is inserted in the player

the right way up.

- Check the condition of the CD: the CD

cannot be played if it is too badly damaged.

- Check the content in the case of a recorded

CD: consult the advice in the "Audio"
section.

- Due to insufficient quality, certain burned

CDs will not be read by the audio system.

The CD sound is of poor quality.

The CD used in scratched or of poor quality.

Insert good quality CDs and store them in
suitable conditions.

The audio settings (bass, treble, ambience) are
unsuitable.

Return bass and treble settings to 0, without
selecting an ambience.

I am unable to play the music files on my
smartphone via the USB port.

Depending on the smartphone, access by the
audio system to music on the smartphone may
have to be approved on the latter.

Manual activate the MTP profile on the
smartphone (USB settings menu).

Bluetooth

audio system

Telephone

QUESTION

RESPONSE

SOLUTION

I am unable to access my voicemail.

Few telephones or service providers allow the
use of this function.

Call the voicemail, via the telephone menu,
using the number provided by your operator.

I am unable to access my directory of contacts.

Check the compatibility of your telephone.

You did not give access to your contacts when
pairing the telephone.

Accept or confirm access by the system to the
contacts on your telephone.

I am unable to continue a conversation when
getting into my vehicle.

Telephone mode is activated.

Deselect telephone mode to transfer the call to
the vehicle.

I am unable to pair my telephone by Bluetooth.

Telephones (models, versions of operating
systems) have their own specific aspects in the
pairing procedure and some telephones are not
compatible.

Before starting the pairing procedure, delete the
pairing of the telephone from the system and of
the system from the telephone, so as to see the
compatibility of the telephones.

Bluetooth

audio system

Bluetooth

audio system

Bluetooth

audio system

297

Alphabetical index

Accessories ..........................................138, 180
Active Safety Brake.....................16-17, 215-218
AdBlue

additive ............................. 32, 262-265

Adjusting headlamps ....................................128
Adjusting head restraints ................................79
Adjusting seats ......................... 76-77, 79, 85-87
Adjusting the air distribution ................... 99 -102
Adjusting the air flow ............................... 99 -102
Adjusting the date ......................... 38 -39, 36, 20
Adjusting the height and reach

of the steering wheel ....................................83

Adjusting the lumbar support ...............76-77, 79
Adjusting the seat belt height .......................149
Adjusting the temperature ...................... 99 -102
Adjusting the time ......................... 38 -39, 36, 20
Advanced Grip Control ..........................145 -146
Advice on driving ...................................175-176
Airbags ............................................18, 153, 158
Airbags, curtain ......................................155 -156
Airbags, front................................. 153 -154, 156
Airbags, lateral ......................................154, 156
Air conditioning .........................................96, 98
Air conditioning, automatic .............................95
Air conditioning, digital ...........................99, 103
Air conditioning, dual-zone automatic ....99, 103
Air conditioning, manual ................... 95-96, 103
Air conditioning, mono-zone ............. 97-98, 103
Air intake ................................................. 99 -102
Air vents ..........................................................94
Alarm ...............................................................61
Amplifier, audio ............................................. 112
Anti-lock braking system (ABS) .............. 15, 142
Anti-slip regulation (ASR) ............................. 142

Anti-theft .......................................................177
Armrest, front ................................................ 114
Assistance call .......................................139-141
Assistance, emergency braking ........... 142, 217
Audio streaming (Bluetooth) ..................... 27, 11
Auxiliary ..........................................26 -27, 10 -11

Cable, audio ..............................................26, 10
Cable, jack ................................................26, 10
Capacity, fuel tank ........................................245
CarPlay connection................................... 18, 13
Cartridge, fragrance .............................. 114-115
CD ........................................................26 -27, 11
CD, MP3 ...............................................26 -27, 11
Central locking ..........................................53, 60
Changing a bulb ..................... 278 -279, 281-283
Changing a fuse .................................... 284-285
Changing a wheel .................. 267-2 69, 273-274
Changing a wiper blade ........................136, 284
Changing the remote control battery ..............58
Charger, induction .................................. 112-113
Charger, wireless ................................... 112-113
Checking the engine oil level ..........................30
Checking the levels ............................... 258-2 60
Checking tyre pressures

(using the kit) .............................. 269-2 70, 272

Checks .......................................... 257, 260-262
Checks, routine ..................................... 260-262
Child lock ................................................ 173-174
Children ................................. 164, 166-168, 170
Children (safety) ..................................... 173-174
Child seats .............152, 157 -158, 162-164, 172
Child seats, conventional ...................... 163 -164
Child seats, i-Size ......................................... 170
Child seats, ISOFIX .......................166-168, 170
Cigarette lighter ............................................ 111
Closing the boot ............................ 51, 54-55, 65
Closing the doors .......................... 51, 53-55, 64
Configurations, seats ......................................92
Configuration, vehicle ......................... 38-42, 45
Connection, Bluetooth ........21-22, 28-30, 15 -17
Connection, MirrorLink ........................ 19, 12 -14
Connection, Wi-Fi network .............................22
Control, emergency door ................................57
Control, heated seats ................................ 81-82
Controls, steering mounted ...................185-189

Backrest, folding .............................................78
Battery .....................13, 252, 260, 285 -286, 288
Battery charge (warning lamp) ....................... 13
Battery, charging ....................................287-288
Battery, remote control .............................56, 58
Blanking screen (snow shield) ......................253
Blind ................................................................70
Blind spot monitoring system .......... 23, 227-229
Blind spot monitoring system, active ......23, 229
Blind spot sensors .......................... 23, 227-229
Blinds, side .................................................... 119
BlueHDi .................................... 32, 34, 262, 266
Bluetooth (hands-free) ................... 28-29, 15 -16
Bluetooth (telephone) ..................... 28-30, 15-17
Bonnet ...........................................................256
Boot ............................................. 64-65, 67, 123
Boot (fittings) .................................................120
Brake discs ............................................ 261-262
Brake lamps ..................................................281
Brakes ..............................................15, 261-262
Braking assistance system ........................... 142
Braking, automatic emergency ...16 -17, 215-218
Braking, dynamic emergency ................181-184
Brightness .......................................................19
Bulbs .............................................................278
Bulbs (changing) .................... 278 -279, 281-283

180° rear vision .................................... 233, 235

298

Alphabetical index

Hands-free access ..........................................67
Hands-free tailgate ...................................65, 67
Hazard warning lamps ..........................139, 266
Headlamp adjustment ...................................128
Headlamps, automatic dipping ........ 25, 131-132
Headlamps, automatic illumination .....124, 128-1 30
Headlamps, dipped beam ..........24 -25, 279-2 80
Headlamps, halogen ............................. 278-2 79
Headlamps, main beam .............24 -25, 279-2 80
Head restraints, front ......................................79
Head restraints, rear .................................85, 90
Heating ........................................94, 96-98, 103
Heating, additional ........................................105
Heating, programmable ................................105
Hi-Fi system .................................................. 112
Hill Assist Descent Control .............. 23, 147-148
Hill Descent Control ............................... 147-148
Hill start assist ...............................................190

Gauge, fuel....................................................245
Gearbox, automatic .............. 185 -195, 261, 287
Gearbox, manual .................. 185, 190 -195, 261
Gear lever, automatic gearbox ..............185-189
Gear lever, manual gearbox .........................185
Gear shift indicator ~ Gear

efficiency indicator ..................................... 191

Glove box ...................................................... 111
G.P.S. .............................................................. 14
Grab handles ................................................ 110

Control stalk, lighting .................24 -25, 124, 127
Control stalk, wipers ..............................134-137
Courtesy lamps ...................................... 116-117
Cruise control ........................ 197 -198, 200-201,

204-211, 214-215

Cruise control by speed limit

recognition .......................................... 200-201

Cruise control, dynamic with

Stop function ......... 200-201, 207-211, 214 -215

Cup holder ..................................................... 110

Fatigue detection .................................. 219-220
Filling the fuel tank ................................ 245-247
Filter, air ........................................................261
Filter, oil .........................................................261
Filter, particle ........................................ 260 -261
Filter, passenger compartment .....................261
Fitting a wheel ....................................... 275 -278
Fitting roof bars .............................................255
Fittings, boot .................................................120
Fittings, interior ...................................... 110-111
Fittings, rear .................................................. 118
Flap, fuel filler ........................................ 245-246
Floor, concertina .............................................89
Foglamps ......................................................125
Foglamps, front ............... 24, 125, 133, 279 -280
Foglamps, rear ......................................125, 283
Folding the rear seats ............................... 85-87
Frequency (radio) ...................................... 24-25
Fuel........................................................ 246-247
Fuel tank................................................ 245-246
Fuses ..................................................... 284-285

DAB (Digital Audio

Broadcasting) - Digital radio .....................25, 9

Date (setting) ................................. 38 -39, 36, 20
Daytime running lamps .........................126, 279
Deactivating the passenger airbag ..... 153 -154, 158
Deadlocking .............................................. 51, 55
Demisting - defrosting ............................103-105
Dials and gauges .......................................... 8-9
Dimensions ...................................................295
Dipstick ............................................ 30, 258-259
Direction indicators ..........24, 127, 279, 281-282
Display screen, instrument panel ................. 191
Distance alert ~ Collision Risk Alert ......215-216
Door pockets ................................................. 110
Doors ...............................................................63
Doors, rear .................................................... 174
Driver’s attention warning .............................220
Driving ........................................................74 -75
Driving abroad...............................................126
Driving positions (storing) ...............................81
Driving time warning ............................. 219 -220
Dynamic pack ...............................................191
Dynamic stability control (DSC) .............142 -146

Economy mode .............................................252
Electronic brake force distribution (EBFD) ... 142
Emergency braking assistance (EBA) .......... 142
Emergency call ......................................139-141
Emergency switching off ........................180 -181
Energy economy mode .................................252
Engine compartment ....................................257
Engine, Diesel ........ 246-247, 257, 266, 293-294
Engine, petrol ................................ 247, 257, 292
Engines ................................................. 291-294
Environment ....................................................56
Electronic stability control (ESC) .................. 142

299

Alphabetical index

Key ...................................................... 49, 56-57
Key, electronic ........................................... 52-55
Keyless Entry and Starting ......... 52, 54-56, 179
Key not recognised ................................180-181
Key with remote control ................................177
Kit, hands-free ............................... 28-29, 15-1 6
Kit, puncture repair ............................... 267 -269
Kit, temporary puncture repair .......267-2 70, 272

Map reading lamps ................................ 116-117
Markings, identification .................................296
Massage function ...........................................82
Massage, multi-point ......................................82
Mat ................................................................ 116
Memorising a speed .............................. 197 -198
Menu ............................................................... 13
Menus (audio) ........................................4-5, 4-6
Messages ........................................................32
Messages, quick .............................................32
Mirror, rear view ..............................................84
Mirrors, door............... 83-84, 104 -105, 227-229
Mirror, vanity ................................................. 111
Misfuel prevention .........................................246
Modularity, seats .............................................92
Motorised tailgate ..................................... 65-67
Mountings, Isofix ...........................................166

Labels, identification .....................................296
Lamp, boot ....................................................123
Lamps, parking .............................................127
Lamps, rear ...................................................281
Lane Departure Warning
System, Active ................................ 17, 222, 229
Lane Departure Warning

System (LDWS) .............................17, 221-222

LEDs - Light-emitting

diodes ................................. 126, 278 -279, 281

Level, brake fluid ...........................................259
Level, Diesel additive ............................ 260 -261
Level, engine coolant ..............................31, 259
Level, engine oil .............................. 30, 258-259
Levels and checks .................................257-260
Level, screenwash fluid ................ 135, 259-2 60
Light-emitting

diodes - LEDs ..................... 126, 278 -279, 281

Lighting ............................................................25
Lighting, cornering ........................................133
Lighting dimmer ..............................................35
Lighting, exterior ........................................... 124
Lighting, guide-me home .................51, 129-1 30
Lighting, interior ..................................... 116-117
Lighting, ambient..................................... 35, 117
Lighting, welcome .........................................130
Loading .................................................122, 255
Load reduction mode ....................................252
Locating your vehicle ...................................... 51
Locking ............................................... 50, 54, 56
Locking from the inside ...................................60
Low fuel level ................................................245

Jack ................................... 268, 273-274, 26, 10
Jump starting ................................................286

i-Cockpit amplify function .... 82, 93, 114-115, 191
Ignition ............................................. 178, 180, 31
Immobiliser, electronic ............................56, 177
Indicator, AdBlue

range .................................32

Indicator, coolant temperature ........................31
Indicator, engine oil level ..........................30, 34
Indicator lamps, operation ........................ 12, 14
Indicator lamps, status .................................... 14
Indicators, direction .............................. 127, 279
Inflating tyres ................................................296
Inflating tyres (using the kit) .......... 269-2 70, 272
Instrument panel .............................. 8 -10, 34-37
Intelligent Traction Control ............................143
Internet browser ..............................................18
ISOFIX ..........................................................167
Isofix mountings ............................................166

Net ................................................................. 121
Net, high load retaining .................................122
Number plate lamps ......................................283

Oil change ............................................. 258-259
Oil consumption .................................... 258-259
Oil, engine ....................................... 13, 258-259
On-board tools ...................................... 267-2 69
Opening the bonnet ......................................256
Opening the boot ......................................52, 64
Opening the doors ....................................52, 63
Opening the fuel filler flap .............................245
Opening the windows .....................................50

300

Alphabetical index

Safety, children ..............153-154, 157 -158, 162,

164, 166-168, 170

Saturation of the particle filter (Diesel) .........261
Scented air freshener ............................ 114 -115
Screen menu map ........................................... 13
Screen, monochrome ............................... 38-39
Screens, very cold conditions .....................253
Screenwash, front .........................................135
Screenwash, rear ..........................................135
SCR (Selective Catalytic

Reduction) system ......................................262

Seat belts .......................................149-1 52, 163
Seat belts, rear .......................................149-1 50
Seats, additional ....................................... 88-91
Seats, electric .................................................81

Radio .......................................... 23-24, 27, 7, 11
Radio, digital (Digital Audio

Broadcasting - DAB) .................................25, 9

Range, AdBlue ................................................32
RDS ....................................................... 24 -25, 7
Rear air blower ..............................................102
Rear screen, demisting – defrosting..... 104-105
Recharging the battery ..........................287 -288
Reduction of electrical load ..........................252
Regeneration of the particle filter .................261

Pads, brake ........................................... 261 -262
Paint ..............................................................296
Paint colour code ..........................................296
Parcel shelf, rear ........................................... 119
Park Assist ............................................ 237, 239
Parking brake ........................................ 261 -262
Parking brake, electric .....................26, 181 -184
Parking sensors, front ........................... 230-231
Parking sensors, rear....................................230
Personalisation ............................................9-1 0
PEUGEOT Connect Nav ...................................1
PEUGEOT Connect Radio ...............................1
Plates, identification......................................296
Player, Apple

........................................... 27, 11

Player, MP3 CD ...............................................26
Player, USB ....................................... 112, 26, 10
Port, USB .......................................... 112, 26, 10
Pre-heater, Diesel ...........................................22
Pressures, tyres ....................................272, 296
Pre-tensioning seat belts ..............................152
Priming the fuel system ........................ 266-2 67
Profiles ......................................................34, 18
Protecting children .........153 -154, 157-158, 162,

164, 166 -168, 170

Puncture ........................................ 269-2 70, 272

Reinitialisation of the under-

inflation detection system ...........................196

Reinitialising the remote control .....................58
Reminder, key in ignition ............................... 178
Remote control .........................49-51, 53, 55-56
Removing a wheel ................................ 275 -278
Removing the mat ......................................... 116
Replacing bulbs ..................... 278 -279, 281-283
Replacing fuses .................................... 284-285
Replacing the air filter ...................................261
Replacing the oil filter ...................................261
Replacing the passenger compartment filter ......261
Reservoir, screenwash ......................... 259-2 60
Resetting the service indicator .......................30
Resetting the trip recorder ........................ 35-37
Rev counter ................................................... 8-9
Reversing lamps ....................................281-282
Roof bars .......................................................255
Running out of fuel (Diesel) .................. 266 -267

Seats, front ................................................76, 81
Seats, heated ............................................ 81-82
Seats, rear ................................................. 85-91
Selector, gear .........................................185-189
Serial number, vehicle ..................................296
Service indicator .......................................28, 34
Servicing .........................................................28
Settings, equipment ............................ 38-42, 45
Settings, system ........................................35, 19
Sidelamps .............................. 126-127, 279, 281
Side repeater ................................................281
Snow chains ..........................................195, 254
Snow screen .................................................253
Socket, 12 V .................................................. 271
Socket, 12 V accessory .........111, 119, 123, 271
Socket, 230 V ................................................ 118
Socket, auxiliary ........................................26, 10
Socket, JACK ............................................26, 10
Speakers ....................................................... 112
Speed limiter .......................... 197 -198, 200-203
Speed limit recognition ......................... 198 -199
Speedometer ................................................ 8 -9
Stability control (ESC)....................142, 144-146
Starting a Diesel engine ...............................247
Starting the engine .......................................177
Starting the vehicle ....26, 175, 177 -179, 185-189
Starting using another battery .......180-181, 286
Station, radio ......................................... 23-2 5, 7
Stay, bonnet ..................................................256
Steering mounted controls, audio ................3, 3
Steering wheel, adjustment ............................83
Stopping the vehicle ....26, 175, 177 -179, 185-189
Stop & Start .................22, 37, 95, 103, 192 -195,

245, 256, 260, 289

Storage ............................................110-111, 114
Storage boxes ...............................................120
Storage compartments ................................. 110
Storing driving positions .................................81
Sunroof, panoramic ........................................70
Sun visor ....................................................... 111

301

Alphabetical index

Under-inflation (detection) ......................18, 195
Unlocking ..................................................50, 52
Unlocking from the inside ...............................60
Unlocking the boot .................................... 52-53
Unlocking the tailgate ............................... 52-53
Updating the date ......................................36, 20
Updating the time ......................................36, 20
USB .................................................26 -27, 10 -11

Ventilation ......................................... 94-98, 103
Visibility .........................................................103
Vision, 180° forward .....................................235
Voice commands .........................................5 -10

Warning and indicator lamps .......................... 12
Warning lamp, braking system ....................... 15
Warning lamp, Diesel engine pre-heater .......22
Warning lamp, driver’s seat

belt not fastened ......................................... 151

Warning lamps ....................................12, 14, 34
Warning lamp, Service....................................16
Weights ................................................. 291-294
Welcome lighting..................................... 51, 130
Wheel, spare ..................267-2 69, 273-275, 296
Window controls .............................................69
Windscreen, heated ......................................104
Wiper blades (changing) .......................136, 284
Wiper, rear.....................................................135
Wipers ......................................23, 134, 136 -137
Wipers, automatic rain sensitive ......134, 136 -137

Table position ..................................................78
Tables, aircraft .............................................. 119
Tailgate ............................................................64
Tank, fuel ............................................... 245-246
Technical data ....................................... 292 -294
Telephone ........................112 -113, 28-33, 15-1 8
Temperature, coolant ......................................31
Third brake lamp ...........................................283
Three flashes (direction indicators) ..............127
Ticket holder ................................................. 110
Time (setting) ................................ 38 -39, 36, 20
TMC (Traffic info) ............................................14
Tools ....................................... 267-2 69, 273 -274
Total distance recorder ...................................35
Touch screen................................................. 1, 1
Touch screen ~ Touch screen tablet ......40, 42, 45
Towbar ...........................................144, 176, 248
Towbar with quickly

detachable towball .............................. 248-2 52

Towed loads .......................................... 291-294
Towing another vehicle ......................... 289 -290
Traction control (ASR) ...........................142 -146
Traffic information (TMC) ................................ 14
Trailer ............................................144, 176, 248
Trailer stability assist (TSA) ..........................144
Trajectory control systems ............................ 142
Triangle, warning...........................................266
Trip computer ............................................ 36-37
Trip distance recorder .....................................35
Tyres ..............................................................296
Tyre under-inflation detection .........18, 195, 272

Switching off the engine ...............................177
Synchronising the remote control ...................58

Content .. 23 24 25 26 ..
